SIDE LOOK PACKAGE
SOLID STATE LAMP
MSL-824SYG
Description Package Dimensions
ad
af
R
opr
stg
The MSL-824SYG is designed based on in an industry
standard package for ease of handing and use. Units : mm
The package is water clear epoxy within white plastic.
Applications
l LCD backlighting
l Symbol backlighting
l Front panel indicator
Features
l High performance
l Excellent chip to chip consistency
l High reliability
Absolute Maximum Ratings
Power Dissipation P
Continuous Forward Current I
Reverse Current(VR=5V) I
Operating Temperature Range T
Storage Temperature Range T
Lead Soldering Temperature 260oC for 5 second (2.0mm From Body)
A C
Notes :
1. All dimensions are in millimeters.
2. Tolerance is ± 0.1 mm unless otherwise noted.
'@ TA=25oC
Parameter Symbol Maximum Rating Unit
100 mW
35 mA
10
-40oC to +85oC
-40oC to +85oC
µA
Unity Opto Technology Co., Ltd.
11/06/2000
MSL-824SYG
Optical-Electrical Characteristics
Relative Luminous Intensity
Relative Luminous Intensity
FORWARD CURRENT VS.
RELATIVE LUMINOUS INTENSITY
500
600
700
400
1
Spectral
Halfwidth
∆λ(nm)
15 2.0 2.4 70 100
PART NO
MSL-824SYG
Color
Dominant
Wave
Langth
λD
Emitted Lens TYP MAX MIN TYP
(nm)
Green Water Clear 570
Typical Optical-Electrical Characteristic Curves
0.5
0
Relative Luminous Intensity
Wavelength (nm)
FIG.1 RELATIVE LUMIINOUS INTENSITY VS. WAVELENGTH
35
30
25
20
15
10
5
Forward Current (mA)
0
1.0 1.5 2.0 2.5
Forward Voltage (V)
FIG.2
FORWARD VOLTAGE
1.0
0.8
=35mA
F
0.6
0.4
0.2
Normalized at I
0.0
0 5 10 15 20 25 30 35
Forward Current (mA)
FIG.4
VS. FORWARD CURRENT
Forward Luminous
Voltage Intensity
@IF=20mA @IF=20mA
(V) (mcd)
40
35
30
(mA)
F
25
20
15
10
5
Forward Current I
FIG.5 RADIATION PATTERN DIAGRAM
0
0 10 20 30 40 50 60 70 80 90 100
Ambient Temperature T
FIG.3 FORWARD CURRENT
VS. AMBIENT TEMPERATURE
0o 10o 20
1.0
0.9
0.8
0.5 0.3 0.1 0.2 0.4 0.6
A
(oC)
o
30°
40°
50°
60°
70°
80°
90°
'@ TA=25oC
Viewing Angle
2θ
1/2
(deg)
110
Unity Opto Technology Co., Ltd.
11/06/2000
