T-1 3/4 PACKAGE
PIN PHOTODIODE
MID-54H19
Description Package Dimensions
(.200)
(.040)
(.230)
FLAT DENOTES CATHOD
The MID-54H19 is a photodiode mounted in special
dark end look plastic package and suitable for the
ψ5.05
Unit : mm ( inches )
IRED (850nm/880nm) type.
7.62
(.300)
5.90
1.00
Features
l High photo sensitivity
l Low junction capacitance
l High cut-off frequency
l Fast switching time
l Acceptance angle : 40°
0.50TYP.
(.020)
2.54
(.100)
23.40MIN.
(.920)
1.00MIN.
(.040)
5.47
(.215)
Application
l Data communication
Absolute Maximum Ratings
Parameter Maximum Rating Unit
Power Dissipation 150 mW
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
A
Notes :
1. Tolerance is ± 0.25 mm (.010") unless otherwise noted.
2. Protruded resin under flange is 1.0 mm (.040") max.
3. Lead spacing is measured where the leads emerge from the package.
C
@ TA=25oC
-55oC to +100oC
-55oC to +100oC
260oC for 5 seconds
Unity Opto Technology Co., Ltd.
02/04/2002
MID-54H19
Optical-Electrical Characteristics
Reverse Break Down Voltage
V
=10, Ee=0 mw/cm
100
80
60
40
20
Parameter Test Conditions Symbol Min. Type . Max. Unit
IR=100µA
Ee=0
Reverse Dark Current
VR=10V
Ee=0
V
(BR)R
I
D
30
30
@ TA=25oC
V
nA
Open Circuit Voltage λ=850nm
Ee=0.1mW/cm
Rise Time
Fall Time
Light Current
VR =10V λ=850nm
RL=50Ω
VR =5V, λ=850nm
Ee=0.1mW/cm
Total Capacitance
VR =3V, f=1MHZ
2
2
V
OC
Tr 30
Tf 30
I
L
C
Ee=0
Typical Optical-Electrical Characteristic Curves
4000
3000
2000
Dark Current - pA
1000
0
0 5 10 15 20
Reverse Voltage - V
R
FIG.1 DARK CURRENT VS REVERSE VOLTAGE
TEMP=25oC , Ee=0 mW/cm
2
350 mV
7 12
T
Capacitance C - pF
0
FIG.2 CAPACITANCE VS. REVERSE VOLTAGE
25 pF
0.01 0.1 1 10 100
Reverse Voltage- V
F=1MHZ, Ee=0mW/cm
R
nS
µA
2
Total Power Dissipation mW
Unity Opto Technology Co., Ltd.
200
150
100
50
0
0 20 40 60 80 100
Ambient Temperature -oC
FIG.3 TOTAL POWER DISSIPATION
VS. AMBIENT TEMPERATURE
1000
100
10
1
Dark Current IR - nA
0.1
0 20 40 60 80 100
Ambient Temperature-oC
FIG.4 DARK CURRENT VS AMBIENT
TEMPERATURE
2
02/04/2002
