Unitronics V130-33-TR20 Installation Manual

Unitronics
1
To enter Information Mode, press the <i> button for several seconds.
as Remote Access, refer to the VisiLogic Help system.
i4 Automation Ltd - 01480 395256
Vision™ OPLC™
The Unitronics V130-33-TR20 offers the following onboard I/Os:
12 Digital Inputs, configurable via wiring to include 2 Analog, and 3 HSC/Shaft-encoder Inputs 6 Relay Outputs 2 high-speed npn Transistor Outputs

General Description

V130 OPLCs are micro-OPLCs, rugged programmable logic controllers that comprise:
On-board I/O configuration Built-in operating panel containing a 2.4” screen and a keypad
Communications
1 built-in serial port: RS232/RS485 Optional: the user may order and
install one or both of the following modules:
- RS232/RS485/Ethernet
- CANbus
Communication Function Blocks
include: SMS, GPRS, MODBUS serial/IP. Protocol FB enables PLC to communicate with almost any external device, via serial or Ethernet communications
I/O Options
Information Mode
Programming Software, & Utilities
V130 supports digital, high-speed, analog, weight and temperature measurement I/Os via:
On-board I/O configuration
Model-dependent
I/O Expansion Modules Local or remote I/Os may be added via expansion port or CANbus.
This mode enables you to:
View & Edit operand values, COM port settings, RTC and screen
contrast/brightness settings
Stop, initialize, and reset the PLC
The Unitronics Setup CD contains VisiLogic software and other utilities.
VisiLogic Easily configure hardware and write both HMI and Ladder control applications; the Function Block library simplifies complex tasks such as PID. Write your application, and then download it to the controller via the programming cable included in the kit.
Utilities Includes UniOPC server, Remote Access for remote programming and diagnostics, and DataXport for run-time data logging.
To learn how to use and program the controller, as well as use utilities such
V130-33-TR20 Installation Guide
2
Unitronics
Data tables enable you to set recipe parameters and create datalogs.
Data Tables
Vision controller
Mounting brackets (x2)
I/O connectors (x2)
Rubber seal
Battery (installed)
Unitronics’ Setup CD
Programming cable + RS232 adapter
When any of the following symbols appear, read the associated information carefully.
Symbol
Meaning
Description
Caution
Caution
Use caution.
Removable
i4 Automation Ltd - 01480 395256
Memory Storage
Additional product documentation is in the Technical Library, located at www.unitronics.com, and on the Unitronics’ Setup CD.
Technical support is available at the site, and from support@unitronics.com.
Micro SD card: store datalogs, Alarms, Trends, Data Tables; export to Excel; backup Ladder, HMI & OS and use this data to ‘clone’ PLCs.
For more data, refer to the SD topics in the VisiLogic Help system.

Standard Kit Contents

Danger Symbols

Danger The identified danger causes physical and property damage. Warning The identified danger could cause physical and property damage.
Before using this product, the user must read and understand this document. All examples and diagrams are intended to aid understanding, and do not guarantee operation.
Unitronics accepts no responsibility for actual use of this product based on these examples.
Please dispose of this product according to local and national standards and regulations. Only qualified service personnel should open this device or carry out repairs.
Failure to comply with appropriate safety guidelines can cause severe injury or property damage.
Do not attempt to use this device with parameters that exceed permissible levels. To avoid damaging the system, do not connect/disconnect the device when power is on.

Environmental Considerations

Do not install in areas with: excessive or conductive dust, corrosive or flammable gas,
moisture or rain, excessive heat, regular impact shocks or excessive vibration, in accordance with the standards given in the product’s technical specification sheet.
Ventilation: 10mm space required between controller’s top/bottom edges & enclosure walls. Do not place in water or let water leak onto the unit. Do not allow debris to fall inside the unit during installation. Install at maximum distance from high-voltage cables and power equipment.
