Unitron Shine Rev M BTE, Shine Rev S BTE, Shine Rev HPm BTE, Shine Rev HP BTE, Shine Rev ITE User Manual
Shine™ Rev
behind-the-ear (BTE)
and in-the-ear (ITE)
hearing aid guide
Thank you
Thank you for choosing Unitron hearing aids.
At Unitron, we care deeply about people with
hearing loss. We work closely with hearing
healthcare professionals to make advanced,
purpose-driven solutions available to everyone.
Because hearing matters.
This user guide applies to the following models:
Shine Rev M BTE
Shine Rev S BTE
Shine Rev HPm BTE
Shine Rev HP BTE
Shine Rev ITE
Your BTE hearing aids
Hearing healthcare professional: _______________
___________________________________________
Telephone: _________________________________
Model: ____________________________________
Serial number: ______________________________
Replacement batteries:
Size 312 Size 13 Size 675
Warranty: __________________________________
Program 1 is for: ____________________________
Program 2 is for: ____________________________
Program 3 is for: ____________________________
Program 4 is for: ____________________________
Date of purchase: ___________________________
Your ITE hearing aids
Hearing healthcare professional: _______________
___________________________________________
Telephone: _________________________________
Model: ____________________________________
Serial number: ______________________________
Replacement batteries:
Size 10 Size 312 Size 13
Warranty: __________________________________
Program 1 is for: ____________________________
Program 2 is for: ____________________________
Program 3 is for: ____________________________
Program 4 is for: ____________________________
Date of purchase: ___________________________
Quick reference
Changing batteries Low battery warning
2 beeps every
30 minutes
312
On/O
Lever
volume control;
up=louder, down=soer
Push button
switching programs
13
Plus
(+) signs
On O Open
675
ITE quick reference
Changing batteries
2 beeps
every
30 minutes
10
312
13
On/O
Battery size
Low battery
warning
Plus (+) signs
Plus (+) signs
Push button
switching programs
Rotary dial
volume control;
forward=louder, back=soer
Table of contents
Warnings .................................................................................... 2
Tips for wearing hearing aids for the rst time ........................... 6
Your BTE hearing aids at a glance...............................................8
Putting your BTE hearing aids on your ears ............................... 11
Turning your micro BTE hearing aids onando ........................13
Turning your S/HP/HPm BTE hearing aids onando ...............14
BTE battery information ............................................................15
BTE operating instructions .......................................................19
Cleaning your hearing aids ....................................................... 22
Assistive listening devices for BTEs .........................................26
BTE troubleshooting guide....................................................... 27
Your ITE hearing aids at a glance .............................................. 32
Putting your ITE hearing aids inyourears ................................ 34
Turning your ITE hearing aids onando .................................. 36
ITE battery information ............................................................ 37
Operating instructions ............................................................. 40
Cleaning your ITE hearing aids ................................................. 42
Assistive listening devices for ITEs .......................................... 43
ITE troubleshooting guide ........................................................ 44
Using the telephone ................................................................. 48
Protecting your hearing aids .................................................... 49
Information and explanation of symbols ................................. 50
Patient feedback ...................................................................... 52
Additional notes ....................................................................... 53
On O
2 3
Warnings
The intended use of hearing aids is to
amplify and transmit sound to the ears and
hereby compensate for impaired hearing.
The hearing aids (specially programmed for
each hearing loss) must only be used by the
intended person. They should not be used
by any other person as they could damage
hearing.
Hearing aids should only be used as
directed by your physician or hearing
healthcare professional.
Hearing aids will not restore normal
hearing and will not prevent or improve a
hearing impairment resulting from organic
conditions.
Do not use your hearing aids in explosion
hazard areas.
Allergic reactions to hearing aids are unlikely.
However, if you experience itching, redness,
soreness, inflammation or a burning
sensation in or around your ears, inform
your hearing healthcare professional and
contact your physician.
In the unlikely case that any parts remain
in the ear canal aer the removal of the
hearing aid, contact a physician immediately.
Remove your hearing aids for CT and
MRI scans or for other electromagnetic
procedures.
Special care should be exercised in wearing
hearing aids when maximum sound
pressure levels exceed 132 decibels. There
may be a risk of impairing your remaining
hearing. Speak with your hearing healthcare
professional to ensure the maximum output
of your hearing aids is suitable for your
particular hearing loss.
Battery warnings
Never leave hearing aids or batteries where
small children and pets can reach them.
Never put hearing aids or batteries in
your mouth. If a hearing aid or battery is
swallowed, call a physician immediately.
4 5
This hearing aid is not designed to be used
for children under 36 months. The hearing
aid contains small parts that can cause
choking if swallowed by children. Keep
out of reach of pets, children and mentally
challenged people. If swallowed, consult a
physician or hospital immediately.
External devices may only be connected if
they have been tested in accordance with
corresponding IECXXXXX standards. Only
use accessories approved by Unitron, to
avoid any electrical shock.
Note to hearing healthcare professional
Domes should never be tted on patients
with perforated eardrums, exposed middle
ear cavities, or surgically altered ear
canals. In the case of such a condition, we
recommend to use a customized ear mold.
Labeling
The serial number and year of manufacture are
located inside the battery door.
Precautions
The use of hearing aids is only part of
hearing rehabilitation; auditory training and
lip reading instruction may be required as
well.
In most cases, infrequent use of hearing
aids does not provide full benet. Once you
have become accustomed to your hearing
aids, wear your hearing aids everyday all
day.
Your hearing aids use the most modern
components to provide the best possible
sound quality in every listening situation.
However, communication devices such as
digital cell phones can create interference
(a buzzing sound) in hearing aids. If you
experience interference from a cell phone
being used close by, you can minimize this
interference in a number of ways. Switch
your hearing aids to another program, turn
your head in a dierent direction or locate
the cell phone and move away from it.
6 7
Tips for wearing hearing aids for the
rst time
• Start in a quiet room at home rst to get
used to the new sound quality. Sounds like
the ticking of a clock, the humming of the
computer, the beep of the microwave or the
rustling of clothes or paper may seem loud
to you at rst, because you have not been
hearing them properly for a long time.
• Read aloud to yourself and learn to correct
the volume of your own voice when you are
wearing the hearing aids.
• Talk to dierent people and learn how
to distinguish between dierent sound
patterns again.
• It will take some time before you are
completely used to your hearing aids and
can fully enjoy the benets.
• Wear your hearing aids for as many hours a
day as you can, and for a little longer each
day.
• Make notes at the back of this booklet,
write down dicult situations and describe
what any unpleasant noises were like.
This information will help your hearing
healthcare professional to ne-tune the
hearing aids better for your needs.
• Involve your family and friends in this
familiarization period. For example,
ask someone to set the television to a
comfortable volume.
• When you are beginning to get used to
wearing the hearing aids, wear them in more
dicult listening environments such as the
oce, at parties or in restaurants. This can
be dicult even for people who can hear
normally. Give yourself time to regain your
ability to hear in these dicult situations.
• Make your hearing aids part of your
everyday life and be patient with yourself
while you are learning to hear sounds
correctly.
8 9
Your BTE hearing aids at a glance
1 Earhook - your custom made earmold attaches to
your hearing aids using the earhook
2 Microphone - sound enters your hearing aids
through the microphones. Microphone shield -
protects microphones from dirt & debris
3 Push button - switches between listening programs
4 Lever - controls the volume
5 Battery door (on & o) - close the door to turn on
your hearing aids, partly open the door to turn o
your hearing aids. Opening the door all the way
gives you access to change the battery
6 Tubing - part of the earmold that attaches it to the
earhook
7 Earmold - allows the sound to pass from the
hearing aids to the ear and holds the hearing aids
in place
8 Power slim tube/slim tube - sound travels down
the slim tube to the ear canal
9 Dome - holds the slim tube in place in your ear canal
10 Retention piece - helps prevent the dome and slim
tube from moving out of the ear canal
Micro BTE hearing aids
2
3
2
5
2
3
2
5
1
6
7
8
10
9
10 11
Putting your BTE hearing aids on your
ears
Your hearing aids may be color-coded with a
small dot on the battery door: red = right ear;
blue = le ear.
Hearing aids with earmolds
1. Hold the earmold between
your thumb and index
nger. The opening should
be pointing in towards
your ear canal with
the hearing aid resting
upwards above your ear.
2. Carefully insert the earmold
in your ear. You may need
to twist it slightly to the
back. The earmold should
t into your ear snugly and
comfortably. Gently pull
down and back on your
earlobe to help you insert
the earmold into your ear
canal more easily.
S/HP/HPm BTE hearing aids
2
3
4
5
1
6
7
2
3
4
5
8
7
2
3
4
5
8
9
1.
2.
3.
12 13
3. Place the hearing aid over the top of your ear.
Hearing aids with slim tubes
1. Place the hearing aid over
the top of your ear. The
slim tube should lie flush
against your head and not
stick out.
2. Hold the slim tube where it
attaches to the dome and
gently push the dome into
your ear canal.
3. Place the retention piece
in your ear so it rests at the
bottom of the opening of
your ear canal.
Turning your micro BTE hearing aids
onando
Your hearing aids have a three-position battery
door that acts as an on/o switch and that
allows access to the battery compartment.
1. On: Close the battery door
fully.
Note: It may take 5 seconds
before the hearing aid turns
on. Your hearing healthcare
provider can increase the
start up delay if required.
2. O: Partially open the
battery door.
3. Open: Fully open the
battery door to access and
change the battery.
Note: When turning your
hearing aid on and o while
it is on the ear, grasp the top
and bottom of the device with
your index nger and thumb.
Use your thumb to open and
close the battery door.
1.
3.
2.
1.
2.
3.
Loading...
