United Security Products CVD-2010, CVD-2010P, CVD-2010PS Specsheet
Specifications
Automatic AC Power Loss, AC Power Restored, Low
Cellular Providers Worldwide – Bluetooth Capability
CVD-2010 - your cell phone and service
CVD-2010P - comes with Cell Phone
CVD-2010PS - comes with Cell Phone and 1 year/400
minutes prepaid Cellular Service Included
Power source: 9-18VDC
Current (OPERATE mode - standby):
Current (OPERATE mode - dialing):
Activation:
1) N.C. Activation: dialer activates when an "open" is detected
2) N.O. Activation: dialer activates when a "close" is detected
3) Voltage Activation:
N.C. (applied voltage: Min. +5VDC, Max. +28VDC)
N.O. (loss of continuous voltage: Min. 0VDC, Max. 0.25VDC)
Max. Digits for outgoing numbers:
Operating temperature range:
Dimensions (inches):
Weight (ounces):
Mounting:
Case Material:
Color:
Warranty: 1 Year
Onsite or at Remote Locations,
USP’s Cellular Auto Voice Dialer
Security Systems offer Reliable
Low Cost Monitoring Solutions.
No phone line, No contract, and
No monitoring fees required.
Secures RVs, Cabins, Boats,
Storage Garages, Containers,
Shops, Manufacturing Plants,
etc. Monitors Signal Change in
Operating Status of Remote
Equipment or Machinery. Backs
Up primary alarm system if
phone lines are cut
United Security Products, Inc.
has supplied quality products to
the security alarm industry for
over 40 years, with proven
performance in more than 100
million installations. Security
systems dealers rely on USP for
the most innovative products in
the security industry. For your
next installation, be sure to
specify USP products.
Features
Models
United Security Products • 13250 Gregg St. Suite B • Poway, CA 92064
Toll Free: 800-227-1592 • Tel: 858-413-0149 • Fax: 858-413-0124
www.unitedsecurity.com
40 Years of Superior American Manufacturing
U.S. and FOREIGN PATENTS PENDING
CVD-2010 is a completely self-contained, weatherproof,
four-channel monitoring system and cellular automatic voice
dialer. Trigger event are announced via recorded voice
message delivered by the cell phone when the call is
answered. Representing an exciting new level of
achievement, the CVD-2010 combines technologically
advanced features, ease of programming and reliable
operation in a compact, unobtrusive dialer completely
compatible with any security alarm system.
The CVD-2010 features a Power Monitoring System (PMS)
that constantly operates in the background. In the event of a
blackout, or when battery voltage falls below a safe level, or
when power is restored, the PMS automatically dials out
and notifies by means of pre-recorded voice messages
which of the three conditions have been detected: “AC
POWER OFF”, “BATTERY LOW”, or “AC POWER
RESTORED”.
Battery Notification
AT&T / Verizon Compatible - Operates with Most
Model PS Includes $100 one year prepaid Cellular
Service – No Contracts and No Monthly Fee
Power Condition Voice Message in Any Language
plus Up to 4 Voice Messages
Automatic Power Loss Notification – Instant or 15Minute Delayed
4 Separate Voice Dialer Channels/Zones
Automatically Calls Up to 8 telephones, cell phones,
etc.
Can be used with landline – Instantly switches to
cellular calling if landline is cut
Metal Cabinet with Cam Lock included
EEPROM Memory retains programming if power is
lost
Made in U.S.A
28mA typical.
100mA max.
50
-18 to 55 C (0 to 130 F)
13.5x11.5x6.5in
11 Lbs
Wall or Flat Surface
Steel
Beige
