UNITED B4413, B3412 Instruction Manual

1

ELECTRIC UNDER-BLANKET

ΗΛΕΚΤΡΙΚΟ ΕΠΙΣΤΡΩΜΑ

Models/Μοντέλα: B3412 / B4413

INSTRUCTIONS MANUAL

ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ

.

IMPORTANT INSTRUCTIONS, RETAIN FOR FUTURE USE

ΣΗΜΑΝΤΙΚΕΣ ΟΔΗΓΙΕΣ. ΦΥΛΑΞΤΕ ΓΙΑ ΜΕΛΛΟΝΤΙΚΗ

ΠΑΡΑΠΟΜΠΗ

2

ENGLISH

READ THE INSTRUCTIONS BEFORE USE.
I Safety tips

(A) Safety instructions:

1. When the electric blanket is folded, crumpled or used abnormally the electric blank et can
overheat which will activate the permanent protection function. This cannot be repaired at
home and must be returned to an authorized technical center.

2. When the power for the electric blanket is lower in voltage than recommended, the temperature
of the blanket rises slowly, and the heating ability is relatively low. This situation is not a
malfunction of an electric blanket, and users should pay attention to checking the voltage of the
power supply.

3. The indicator lam p and electric blank et circuit are connected in parallel. The indi cator lamp
does not influence the electric blankets ability to generate heat when it is broken so care should
be taken to ensure the electric blanket is functioning properly.

4. This appliance can be used by children aged from 8years and above and persons with
reduced physical, sensory or mental capabilities, or lack of experienc e and k nowledge , only if
they have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children should be supervised to ensure that they do not
play with the appliance.

(B) Warnings and cautions

In order to prevent damage or malfunction, users must observe the following points while using the
product. Failing to do so will void any manufacturer responsibility.

1. Do not use folded or rucked. (Fig.1)

2. Do not roll and drape the appliance while being used. Ensure the bed on which the appliance is
being used on, will guarantee that the electric blanket is laid flat. Do not use the electric blanket
in any other circumstances to avoid overheating. (Fig.2)

3. Do not use pins on the appliance. Do not scratch with sharp devices or beat the electric blanket
with blunt devices. Do not attempt to secure the electric blanket with pins or other metal objects
(Fig.3)

4. Use the electric b lanket under the bo d y o nly. Do not wr ap t he bo d y wi th th e bla nk et or us e i n
any other way. (Fig.4)

5. To avoid scalding of the body, do not use with a helpless person, this appliance must not be
used by persons insensitive to heat or by very vulnerable persons who are unable to react to
overheating. (Fig.5)

6. Do not turn on the electric blanket when there is any folded bedding or heavy object on top of
it, so as not to cause the electric blanket to overheat. (Fig.6)

7. Do not expose the elec tric blank et to dir ect s unlight. D o not roast a nd do n ot ir on the e lectric
blanket. Avoid any damage to the insulation of the heating wires. (Fig.7)

8. Do not use together with any other heating appliances (such as foot warmer, hot-water bottle).
(Fig.8)

3

9. Do not use with anything that can ignite a fire on the bed such as cigarettes, sparks etc, which
can lead to fire. (Fig.9)

10. Switch off the electric blanket power or pull out the electric blanket plug when you are going out
or not using the electric blanket to avoid any accidental fires. (Fig.10)

11 12

11. Do not dry clean. (Fig.1 1)

12. Do not let the appliance to be used by very young children (0-3 years). (Fig.12) Children under
the age of three are not to use this appliance due to their inability to react to overheating.

13. Do not let the appliance to be used by young children over the age of three unless the controls
have been pre-set b y a parent or guardian and the use of the appliance is being per formed
under supervision by the parents or guardian.

14. After the electric blanket has been turned on, users can't leave for over an hour to prevent any
possible fire.

15. Do not unplug the power plug by pulling on the power cord and do not move the appliance by
pulling on the soft power cord.

16. Only use in combination with the supplied controllers.

17. The product is not intended for medical use in hospitals.

18. When not in use, the electric blanket should be stored in a dry place. When storing the
appliance, allow it to cool down before folding. Do not crease the appliance by placing items on
top of it during s torage. After storing, the blanket should be c arefully checked bef ore use to
make sure the control and cords are safe. Do not power on when the blanket is not totally safe.

19. Do not attempt to perf or m any repairs on the elec tric bla nket by yourself. An y us e contr ary to
the instructions can lead to unwanted and potentially dangerous consequences.

20. The power cord of the appl iance can not be cha nged or r epaired. If the cor d is dam aged, the
appliance must be disposed of.

21. Do not use the electric blanket on an adjustable bed.

22. Children should not use the electric blanket unless their parents or guardian have already set it
up in advance, or unless the child has bee n adequately instructed on ho w to use it safely.
Children should be supervised to ensure that they do not play with the appliance.

23. Do not use when crumpled.

24. If the heating wire has been cut, do not attempt to repair it b y yourself. Pleas e send it to the
authorized technical centers for maintenance or checking.

25. Do not try to repair a fuse link or thermal link. The appliance must be returned to an authorized
technical center if the link has ruptured.

Users must observe all the above points. Otherwise, there can be overheating or unusually
high temperature of part of the blanket due to improper use of the electric blanket, which
can lead to fire, cause bodily injury or property loss.

II Operation method

Lay the electric blank et f lat on the bed. The e nd with no c ontrol is the f oot of the bed. F ix the f our
corner fasteners of the electric blanket on the four corners of the bed or the mattress using
