Unitech TB128 User Manual

unitech is a registered trademark of unitech Electronics Co., Ltd.

7” Rugged Tablet Computer

- TB128 -

User's Manual

Version 1.1

unitech is a registered trademark of unitech Electronics Co., Ltd.

Revision History

Date Change Description Version

2017/5/25 first published version 1.0

2017/6/21 Update 1.2 & 1.4 & 1.4.5

Update HF & UHF

Add Hot swap

1.1

i

unitech is a registered trademark of unitech Electronics Co., Ltd.

About This Manual

Preface

Thank you for purchasing the unitech product.

This manual explains how to install, operate and maintain our product.

No part of this publication may be reproduced or used in any form, or by any

electrical or mechanical means, such as photocopying, recording, or

information storage and retrieval systems, without permission in writing from

the manufacturer. The material in this manual is subject to change without

notice.

Regulatory Compliance Statements

FCC Warning Statement

This device has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference with radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference with radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

ii

unitech is a registered trademark of unitech Electronics Co., Ltd.

–Reorient or relocate the receiving antenna.

–Increase the separation between the equipment and receiver.

–Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

–Consult the dealer or an experienced radio/TV technician for help.

1. This transmitter must not be co-located or operating in conjunction with

any other antenna or transmitter.

2. This device complies with FCC RF radiation exposure limits set forth for

an uncontrolled environment. To maintain compliance with FCC RF

exposure requirements, avoid direct contact to the transmitting antenna

during transmitting.

3. Any changes or modifications (including the antennas) made to this device

that are not expressly approved by the manufacturer may void the user’s

authority to operate the equipment.

Operation on the 5.15 - 5.25GHz frequency band is restricted to indoor use

only. The FCC requires indoor use for the 5.15-5.25GHz band to reduce the

potential for harmful interference to co-channel Mobile Satellite Systems.

Therefore, it will only transmit on the 5.25-5.35 GHz, 5.47-5.725 GHz and

5.725–5.850 GHz band when associated with an access point (AP).

FCC Label Statement

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference

that may cause undesired operation.

RF Radiation Exposure Statement

For body contact during operation, this device has been tested and meets FCC

RF exposure guidelines when used with an accessory that contains no metal

and that positions the handset a minimum of 0.5 cm from the body.

Use of other accessories may not ensure compliance with FCC RF exposure

guidelines.

iii

unitech is a registered trademark of unitech Electronics Co., Ltd.

Canadian Compliance Statement

This Class B Digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Cet appareil numerique de la classe B respecte les exigences du Reglement

sur le material broilleur du Canada.

European Conformity Statement

unitech Electronics co., Ltd herewith declares that the unitech product is in compliance with the essential requirements and all other provisions of the RED 2014/53/EU directive, the EMC 2014/30/EU directive and the Low Voltage 2014/35/EU directive. The declaration of conformity is available for download at :

https://portal.unitech.eu/public/Safetyregulatorystatement

CE RF Exposure Compliance

This device meets EU requirements (2014/53/EU) on the limitation of exposure

of the general public to electromagnetic fields by way of health protection.

For body-worn operation, this device has been tested and meets the ICNIRP

guidelines and the European Standard EN 62209-2, for use with dedicated

accessories, SAR is measured with this device at a separation of 0.5 cm to the

body, while transmitting at the highest certified output power level in all

frequency bands of this device. Use of other accessories which contain metals

may not ensure compliance with ICNIRP exposure guidelines.

CE Mark Warning

This equipment complies with the requirements of Directive 2014/53/EU of the

European Parliament and Commission from 24 May, 2014 governing Radio

and Telecommunications Equipment and mutual recognition of conformity. The

highest CE SAR values for the device are as follows :

0.274 W/kg @ 10g (Head)

1.470 W/kg @ 10g (Body)

iv

unitech is a registered trademark of unitech Electronics Co., Ltd.

RoHS Statement

This device conforms to RoHS (Restriction Of

Hazardous Substances) European Union regulations

that set maximum concentration limits on hazardous

materials used in electrical and electronic equipment.

Waste electrical and electronic equipment (WEEE)

unitech has set up a policy and process to meet the EU

directive 2002/96/EC and update 2003/108/EC

concerning electronic waste disposal.

For more detailed information of the electronic waste

disposal of the products you have purchased from

unitech directly or via unitech’s resellers, you shall either

contact your local supplier or visit us at :

https://portal.unitech.eu/public/WEEE

v

unitech is a registered trademark of unitech Electronics Co., Ltd.

Taiwan NCC Warning Statement

低功率電波輻射性電機管理辦法

第十二條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。

第十四條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。

前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

注意事項:

1. 使用過度恐傷害視力。

2. 使用30分鐘請休息10分鐘；2歲以下幼兒不看螢幕，2歲以上每天看螢幕不要超過

1小時。

3. 減少電磁波影響，請妥適使用。

SAR 標準值 2.0W/Kg，送測產品實測值為 W/kg@10g

vi

unitech is a registered trademark of unitech Electronics Co., Ltd.

Laser Information

The unitech product is certified in the U.S. to conform to the requirements of

DHHS/CDRH 21CFR Subchapter J and to the requirements of IEC 825-1.

Class II and Class 2 products are not considered to be hazardous. The unitech

product contains internally a Visible Laser Diode (VLD) whose emissions do

not exceed the maximum limits as set forth in the above regulations. The

scanner is designed so that there is no human access to harmful laser light

during normal operation, user maintenance or prescribed service operations.

The laser safety warning label required by the DHHS/IEC for the unitech

product’s optional laser scanner module is located on the memory

compartment cover, on the back of the unit.

* Laser information only applies to the products with laser components.

CAUTION! Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous laser

light. Use of optical instruments with the scanner, including

binoculars, microscopes, and magnifying glasses, with will

increase eye damage. This does not include eyeglasses worn by

the user.

LED Information

The unitech product contains LED indicator(s) or LED ring whose luminance is

not harmful to human eyes during normal operation, user maintenance or

prescribed service operations.

*LED information only applies to the products with LED components.

vii

unitech is a registered trademark of unitech Electronics Co., Ltd.

Battery Notice

1. To guarantee optimal performance, it is recommended that rechargeable batteries be replaced every year, or after 500 charging cycles are completed. It is normal for the battery to balloon or expand after one year or 500 cycles. Although it does not cause damage, it cannot be used again and must be disposed of according to the location's safe battery disposal procedures.

2. If a battery performance decreases more than 20%, the battery is at the end of its life cycle. Stop use and ensure the battery is disposed of properly.

3. The length of time that a battery lasts depends on the battery type and how the device is used. Conserve the battery life by doing the following:

 Avoid fully uncharging the battery because this places additional

strain on it. Several partial uncharges with frequent charges are better

than a fully uncharged battery. Charging a partially charged battery

does not cause harm to the unit.

 Keep the battery cool. Avoid hot vehicles. For prolonged

storage, keep the battery at a 40% charge level.

 Do not leave the battery uncharged and unused for an extended

period of time, the battery will wear out and the longevity of the

battery will be at least half of one with frequent charges.

4. Protect battery life by not over or under charging the battery.

5. Please do not leave battery unused for long time without charging it.

Despite unitech’s safety precautions, the battery pack may begin to

change shape. If so, stop using it immediately. Please check to see if you

are using a proper power adapter to charge the battery or contact your

service provider for service.

6. If you cannot charge the battery after it has been idle for an extended

period of time and it begins to heat up, please do not try to charge it. It

may not be functional anymore.

7. Please only use the original battery from unitech. Using a third party

battery can damage our products. Please note that when such damage

occurs, it is not covered by unitech’s warranty policy.

viii

unitech is a registered trademark of unitech Electronics Co., Ltd.

CAUTION!

 RISK OF EXPLOSION IF BATTERY IS

REPLACED INCORRECTLY.

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS.

 如果更換不正確之電池行事會有爆炸的風險

請依製造商說明書處理用過之電池

 如果更换不正确之电池行事会有爆炸的风险

请依制造商说明书处理用过之电池

Battery charge notice

It is important to consider temperature when the battery pack is charging.

Charging is most efficient at normal room temperature or in a slightly cooler

environment. It is essential that batteries are charged within the stated range of 0°C to 40°C. Charging batteries outside of the specified range could damage

the batteries and shorten their life cycle.

CAUTION! Do not charge batteries at a temperature lower than 0°C. This will

make the batteries unstable and dangerous. Please use a battery temperature detecting device for a charger to ensure a safe charging temperature range.

CAUTION! To ensure the unit working properly, please keep all connectors

away from the contaminants staying inside of them such as dust,

grease, mud, and water. The negligence may cause the unit with

no communication, short circuited, overheated and so on.

CAUTION! If the connector is damaged, please ensure the connector is being

fully repaired before use the unit to avoid causing short circuited.

ix

unitech is a registered trademark of unitech Electronics Co., Ltd.

Storage and safety notice

Although charged batteries may be left unused for several months, their capacity may be depleted due to build up of internal resistance. If this happens, they will require recharging prior to use. Batteries may be stored at temperatures between -20°C to 60°C, however they may deplete more rapidly at higher temperatures. It is recommended to store batteries at room temperature.

* The message above only applies to the usage of the removable batteries.

For the products with non-removable batteries / without batteries, please refer to the specification of each product.

Product Operation and Storage Notice

The unitech product has applicable operation and storage temperature conditions. Please follow the limitation of suggested temperature conditions to avoid failure, damage or malfunction.

*For applicable temperature conditions, please refer to the specification of each

product.

Adapter Notice

1. Please do not leave the power adapter in the socket when it is not

connected to your unitech product for charging.

2. Please remove the power adapter when the battery is fully recharged.

3. The bundled power adapter that comes with your unitech product is not

meant to be used outdoors. An adapter exposed to water or rain, or a very

humid environment can cause damage to both the adapter and the

product.

4. Please only use the bundled power adapter or same specification of

adapter to charge your unitech product. Using the wrong power adapter

can damage your unitech product.

* The message above only applies to the product connected to the adapter.

For the products without using the adapters, please refer to the specification of each product.

x

unitech is a registered trademark of unitech Electronics Co., Ltd.

Hearing Damage Warning

Zx.3 Warning

The warning shall be placed on the equipment, or on the packaging, or in the instruction

manual and shall consist of the following:

- the symbol of Figure 1 with a minimum height of 5 mm; and

- the following wording, or similar :

To prevent possible hearing damage, do not listen at high volume levels for long periods.

Alternatively, the entire warning may be given through the equipment display during use, when

the user is asked to acknowledge activation of the higher level.

xi

unitech is a registered trademark of unitech Electronics Co., Ltd.

Worldwide Support

unitech’s professional support team is available to quickly answer questions or

assist with technical-related issues. Should an equipment problem occur,

please contact the nearest unitech regional service representative.

For complete contact information please visit the Web sites listed below:

Taipei, Taiwan – Headquarters

Europe

Tel:

+886-2-89121122

Tel:

+31-13-4609292

E-mail:

info@hq.ute.com

E-mail:

info@eu.ute.com

Address:

5F, No. 136, Lane 235, Baoqiao Road, Xindian

District, New Taipei City 231, Taiwan (R.O.C.)

Address:

Website:

Kapitein Hatterasstraat 19, 5015 BB,

Tilburg, the Netherlands

http://eu.ute.com

Website:

http://www.ute.com

China

Japan

Tel:

+86-59-2310-9966

Tel:

+81-3-35232766

E-mail:

info@cn.ute.com

E-mail:

info@jp.ute.com

Address:

Website:

Room401C, 4F, RIHUA International Mansion,

Xinfeng 3nd Road, Huoju Hi-tech District,

Xiamen, Fujan , China

http://cn.ute.com

Address:

Website:

Kayabacho Nagaoka Building 8F.,1-5-19

Shinkawa, Chuo-Ku,

Tok y o , 104-0033, Japan

http://jp.ute.com

Asia & Pacific / Middle East

Latin America

Tel:

+886-2-27911556

Tel:

+52-55-5171-0528

E-mail:

info@apac.ute.com

info@india.ute.com

info@mideast.ute.com

E-mail:

Address:

info@latin.ute.com

17171 Park Row, Suite 210

Houston, TX 77084USA (Rep.)

Address:

4F., No. 236, ShinHu 2nd Rd.,

NeiHu Chiu, 114, Taipei,Taiwan

Website:

http://latin.ute.com

Website:

http://apac.ute.com / http://mideast.ute.com

North America

Please scan QR Code to visit us :

Tel:

+1-714-8916400

E-mail:

Address:

Website:

info@us.ute.com / info@can.ute.com 6182 Katella Ave, Cypress, CA 90630, USA

http://us.ute.com

xii

unitech is a registered trademark of unitech Electronics Co., Ltd.

Warranty Policy

The following items covered under the unitech Limited Warranty are free from defects during normal use:

The warranty period is varied from each country. Please consult with your supplier or unitech local office for actual length of warranty period to your purchased product.

Warranty becomes void if equipment is modified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user.

xiii

unitech is a registered trademark of unitech Electronics Co., Ltd.

Table of Contents

Preface ............................................................................................................. i

Regulatory Compliance Statements .............................................................. i

Laser Information ........................................................................................ vi

LED Information .......................................................................................... vi

Battery Notice ............................................................................................. vii

Adapter Notice ............................................................................................. ix

Hearing Damage Warning ............................................................................ x

Worldwide Support ...................................................................................... xi

Warranty Policy .......................................................................................... xii

Chapter 1 - Overview ................................................................................ 1

1.1 Package ................................................................................................. 1

1.2 Product Detail ......................................................................................... 2

1.3 Specifications ......................................................................................... 5

1.4 Getting Started ....................................................................................... 9

Chapter 2 – Installation & Operation ................................................. 15

2.1 Barcode Setting .................................................................................... 15

2.2 HF Setting ............................................................................................ 22

2.3 UHF Setting .......................................................................................... 24

2.4 MSR Setting ......................................................................................... 27

2.5 WWAN Setting...................................................................................... 27

2.6 WLAN Setting ....................................................................................... 31

2.7 PAN Setting .......................................................................................... 33

2.8 GPS Setting .......................................................................................... 35

2.9 PC Setting ............................................................................................ 38

2.10 Camera Setting .................................................................................. 39

2.11 Performing a Hardware Reset ............................................................ 43

2.12 Performing Factory data reset ............................................................ 44

2.13 Programmable Keys ........................................................................... 47

2.14 Battery Swap (Hot Swap) ................................................................... 54

xiv

unitech is a registered trademark of unitech Electronics Co., Ltd.

Chapter 3 – Introduction t o Applications ......................................... 55

3.1 Scan Service ........................................................................................ 55

3.2 File Manager ........................................................................................ 59

3.3 Update Center ...................................................................................... 61

3.4 Sound Recorder ................................................................................... 63

3.5 MoboLink .............................................................................................. 68

1

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

Chapter 1 - Overview

1.1 Package

Please make sure the following contents are in the TB128 gift box.

If something is missing or damaged, please contact your unitech

representative.

The standard package contents

 TB128  Battery  Hand Strap  USB cable (Standard USB to Micro USB)  Power Adapter  Regulatory Compliance Statements  Quick start Guide  QR code card

Optional accessories

 Desk Dock Cradle

2

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

1.2 Product Detail

TB128 Overview

1. 7" LCD touchscreen 7. 8M pixels rear camera with AF

2. 2M pixels front camera

8. Speaker

3. LED indicator 9. Two screws for battery cover

4. Physical keyboard (37 keys) 10. Bar code Scan Engine

5. Trigger button 11. Reset button

6. LED flashlight 12. UHF antenna

13. NFC antenna

3.

2.

1.

4. 7. 6.

8.

9.

5.

10. 11.

12.

13.

3

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

12

. Micro USB port

14. Earphone jack

13. DC-IN port 15. Cradle connector

14.

12.

13.

15.

4

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

Physical keyboard overview

1. Power on/off key 8. Escape key

2. Android BACK key

9. Alpha/Numeric keys

3. Android HOME key 10. Enter key

4. Android APP List key 11. H.E.S. keys (programmable)

5. Soft keypad on/off key

12. Volume up/down keys

6. Function keys to enter F1-F10 13. 4 directional keys

7. Alpha key 14. Scan key

1.

6.

7.

8.

2.

3.

4.

5.

9.

10.

13.

14.

12.

11.

5

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

1.3 Specifications

System Features

CPU

MTK MT8735 1.3Ghz Quad Core Processor

Memory

3GB Mobile DDR RAM 16GB eMMC NAND Flash

OS

Android 6.0

Languages support

English, Simplified Chinese, Traditional Chinese, Japanese, Spanish, German, French and multiple languages

Display

Gorilla Glass II with capacitive touch panel 7" Color Transmissive TFT IPS LCD

720x1280 dots LCD

Keypad

37 physical keys. Numeric and functionable keys

1 x LED indicate charge/Message/ Scan

Symbologies

2D (SE4750)

 PDF417  MicroPDF417  Code128Emulation  DataMatrix  DataMatrixInverse  Maxicode  QRcode  MicroQR  Aztec  Aztec Inverse  Han Xin  Han Xin Inverse

6

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

Engines

2D

SE4750SR ( LASER AIMER ) :

Sensor Resolution: 1280 x 960 pixels

Field of View: Horizontal: 48°, Vertical: 36.7°

Aiming : 655 nm Laser

Illumination Element: 2 x Warm white LED

Minimum Bar Code Print Contrast : 20%

Ambient Light: Max 107,639 lux (direct sunlight)

Regulatory Approvals

CE, NCC, FCC, RoHS compliance, CB

Certificate

Microsoft Azure IOT

Communication

Camera and Flash Light

2M Pixels Front Camera

8M Pixels Rear Camera CMOS Sensor Camera with Auto

focus, 2x LED flash light

External storage

Support MicroSD memory card up to 128 GB

USB

USB 2.0

WLAN

IEEE 802.11 a/b/g/n

PAN

Bluetooth 4.1

WWAN (Optional)

4G LTE (Optional )

GPS

Support Galileo, GPS/GLONASS, GPS/Beido

Other Sensors

eCompass

Light sensor

G-sensor

RFID (HF)

Frequency: 13.56MHz

Tag Support: ISO15693, ISO14443A , ISO14443B

Support NFC

RFID (UHF)

Frequency 902~928 MHz

Frequency 865.6~867.6 MHz

TX Power 24dBm (2.5W)

Vertical polarized antenna

Reading distance : 1m (Depends on the tag and environment )

7

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

Power Source

Main Battery

3.8V Li-Polymer battery pack ,

Support hot swap.

Weight

735g with 2D SE4750 Engine version (with Battery)

Dimension

264.5x143.7x18.8 (mm)

Environmental

Operating temperature

14°F to 122°F (-10°C to 50°C)

Storage temperature

-4°F to 140°F (-20°C to 60°C)

Relative Humidity

5% ~ 95% ( non-condensing )

Drop test

1.2 meter

Environmental Sealing

IP65

Vibration and Shock test

MIL-STD-810G

Mobile Device Management Software and Service

MoboLink®

Rating label for Direct Current

: To indicate on the rating plate that the equipment is suitable for direct current only.

Radio Type / Description

Transmitter Frequency

Maximum Output Power

GSM

GSM900 880-915MHz 32.5dBm

DCS 1800 1710-1785MHz 29.5dBm

UMTS FDD 1 1920-1980MHz 22.5dBm

FDD 8 880-915MHz 22.5dBm

LTE FDD 1 1920-1980MHz 22.5dBm

FDD 3 1710-1785 MHz 22.5dBm

FDD 7 2500-2570MHz 22.5dBm

FDD 8 880-915MHz 22.5dBm

FDD 20 832-862MHz 22.5dBm

WLAN 2.4GHz IEEE 802.11b 2400-2483.5MHz 20dBm

IEEE 802.11g 2400-2483.5MHz 17.5dBm

IEEE 802.11n 2400-2483.5MHz 18dBm

WLAN 5GHz

IEEE 802.11a

5150-5350MHz 17dBm

5470-5725MHz 17dBm

8

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

WLAN 5GHz IEEE 802.11n

5150-5350MHz

16dBm

5470-5725MHz

16dBm

Bluetooth

2400-2483.5MHz

8dBm

RFID NFC 13.56MHz

<25dBuA/m

UHF

865~868MHz and

902~928MHz

30dBm

NOTE:

Requirements in AT/BE/BG/CZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/ SE/CH/UK/HR. 5150MHz~5350MHz is for indoor use only.

9

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

1.4 Getting Started

1.4.1 Installing the Battery

1. Release the two latches on the

battery cover by turning

counterclockwise.

2. Put battery into battery

compartment and put back cover.

3. Lock the two latches on the battery

cover by turning clockwise.

10

unitech is a registered trademark of unitech Electronics Co., Ltd.

TB128 User’s Manual

NOTE: After installing the battery, make sure the battery cover is secu rely closed, or

you may be unable to turn ON the terminal.

WARNING! There is a risk of fire and burns if the battery pack is handled improperly . DO

NOT disassemble, crush, puncture, short external contacts, or dispose the battery pack in fire or water. DO NOT attempt to open or service the battery pack. Dispose of used batteries according to local recycling guidelines in your area.

1.4.2 Charging the Battery

Connect TB128 to the charger, it will be charged automatically.

1. Plug the power adapter into the DC-IN port at the bottom.

2. Plug the power adapter into a wall outlet. If needed, attach a plug converter

onto the power adapter.

Unitech TB128 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
