Unitech PA726 User Manual

Rugged Handheld Computer

- PA726 -

User's Manual

Version 1.5

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

Revision History Date Change Description Version

2018/2/9 first published version 1.0

2018/2/23 Update 1.2, 2.6, 2.11 information 1.1

2018/5/21 Add Battery Info 1.2

2018/12/28 Update programmable key 1.3

2019/1/7 Update SPEC information 1.4

2019/2/25 Add new function WLAN Advanced 1.5

Preface

About This Manual

Thank you for purchasing the unitech product.

This manual explains how to install, operate and maintain our product.

No part of this publication may be reproduced or used in any form, or by any

electrical or mechanical means, such as photocopying, recording, or

information storage and retrieval systems, without permission in writing from

the manufacturer. The material in this manual is subject to change without

notice.

Regulatory Compliance Statements

FCC Warning Statement

This device has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference with radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference with radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

–Reorient or relocate the receiving antenna.

–Increase the separation between the equipment and receiver.

–Connect the equipment into an outlet on a circuit different from that to

i

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

ii

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

which the receiver is connected.

–Consult the dealer or an experienced radio/TV technician for help.

1. This transmitter must not be co-located or operating in conjunction with

any other antenna or transmitter.

2. This device complies with FCC RF radiation exposure limits set forth for

an uncontrolled environment. To maintain compliance with FCC RF

exposure requirements, avoid direct contact to the transmitting antenna

during transmitting.

3. Any changes or modifications (including the antennas) made to this device

that are not expressly approved by the manufacturer may void the user’s

authority to operate the equipment.

FCC Label Statement

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference

that may cause undesired operation.

RF Radiation Exposure Statement

For body contact during operation, this device has been tested and meets FCC

RF exposure guidelines when used with an accessory that contains no metal

and that positions the handset a minimum of 1.0 cm from the body.

Use of other accessories may not ensure compliance with FCC RF exposure

guidelines.

European Conformity Statement

unitech Electronics co., Ltd herewith declares that the unitech product is in compliance with the essential requirements and all other provisions of the RED

2014/53/EU directive.

The declaration of conformity is available for download at :

https://portal.unitech.eu/public/Safetyregulatorystatement

iii

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

CE RF Exposure Compliance

For body-worn operation, this device has been tested and meets the ICNIRP

guidelines and the European Standard EN 62209-2, for use with dedicated

accessories, SAR is measured with this device at a separation of 0.5 cm to the

body, while transmitting at the highest certified output power level in all

frequency bands of this device. Use of other accessories which contain metals

may not ensure compliance with ICNIRP exposure guidelines.

CE Mark Warning

The highest CE SAR values for the device are as follows :

0.316W/kg @ 10g (Head)

1.593W/kg @ 10g (Body)

RoHS Statement

This device conforms to RoHS (Restriction Of

Hazardous Substances) European Union regulations

that set maximum concentration limits on hazardous

materials used in electrical and electronic equipment.

Waste electrical and electronic equipment (WEEE)

unitech has set up a policy and process to meet the

2012/19/EU concerning electronic waste disposal.

For more detailed information of the electronic waste

disposal of the products you have purchased from

unitech directly or via unitech’s resellers, you shall either

contact your local supplier or visit us at :

https://portal.unitech.eu/public/WEEE

iv

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

v

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

Taiwan NCC Warning Statement

低功率電波輻射性電機管理辦法

第十二條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。

第十四條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。

前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

注意事項:

1. 使用過度恐傷害視力。

2. 使用30分鐘請休息10分鐘；2歲以下幼兒不看螢幕，2歲以上每天看螢幕不要超過

1小時。

3. 減少電磁波影響，請妥適使用。

Laser Information

The unitech product is certified in the U.S. to conform to the requirements of

DHHS/CDRH 21CFR Subchapter J and to the requirements of IEC 60825-1.

Class II and Class 2 products are not considered to be hazardous. The unitech

product contains internally a Visible Laser Diode (VLD) whose emissions do

not exceed the maximum limits as set forth in the above regulations. The

scanner is designed so that there is no human access to harmful laser light

during normal operation, user maintenance or prescribed service operations.

The laser safety warning label required by the DHHS/IEC for the unitech

product’s optional laser scanner module is located on the memory

compartment cover, on the back of the unit.

* Laser information only applies to the products with laser components.

CAUTION! Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous laser

light. Use of optical instruments with the scanner, including

binoculars, microscopes, and magnifying glasses, with will

increase eye damage. This does not include eyeglasses worn by

the user.

LED Information

The unitech product contains LED indicator(s) or LED ring whose luminance is

not harmful to human eyes during normal operation, user maintenance or

prescribed service operations.

*LED information only applies to the products with LED components.

vi

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

Battery Notice

1. To guarantee optimal performance, it is recommended that rechargeable batteries be replaced every year, or after 500 charging cycles are completed. It is normal for the battery to balloon or expand after one year or 500 cycles. Although it does not cause damage, it cannot be used again and must be disposed of according to the location's safe battery disposal procedures.

2. If a battery performance decreases more than 20%, the battery is at the end of its life cycle. Stop use and ensure the battery is disposed of properly.

3. The length of time that a battery lasts depends on the battery type and how the device is used. Conserve the battery life by doing the following:

 Avoid fully uncharging the battery because this places additional

strain on it. Several partial uncharges with frequent charges are better

than a fully uncharged battery. Charging a partially charged battery

does not cause harm to the unit.

 Keep the battery cool. Avoid hot vehicles. For prolonged

storage, keep the battery at a 40% charge level.

 Do not leave the battery uncharged and unused for an extended

period of time, the battery will wear out and the longevity of the

battery will be at least half of one with frequent charges.

4. Protect battery life by not over or under charging the battery.

5. Please do not leave battery unused for long time without charging it.

Despite unitech’s safety precautions, the battery pack may begin to

change shape. If so, stop using it immediately. Please check to see if you

are using a proper power adapter to charge the battery or contact your

service provider for service.

6. If you cannot charge the battery after it has been idle for an extended

period of time and it begins to heat up, please do not try to charge it. It

may not be functional anymore.

7. Please only use the original battery from unitech. Using a third party

battery can damage our products. Please note that when such damage

occurs, it is not covered by unitech’s warranty policy.

vii

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

viii

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

 RISK OF EXPLOSION IF BATTERY IS

REPLACED INCORRECTLY.

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS.

 如果更換不正確之電池行事會有爆炸的風險

請依製造商說明書處理用過之電池

CAUTION!

 如果更换不正确之电池行事会有爆炸的风险

请依制造商说明书处理用过之电池

Battery charge notice

It is important to consider temperature when the battery pack is charging.

Charging is most efficient at normal room temperature or in a slightly cooler

environment. It is essential that batteries are charged within the stated range of 0°C to 40°C. Charging batteries outside of the specified range could damage

the batteries and shorten their life cycle.

CAUTION! Do not charge batteries at a temperature lower than 0°C. This will

make the batteries unstable and dangerous. Please use a battery temperature detecting device for a charger to ensure a safe charging temperature range.

CAUTION! To ensure the unit working properly, please keep all connectors

away from the contaminants staying inside of them such as dust,

grease, mud, and water. The negligence may cause the unit with

no communication, short circuited, overheated and so on.

CAUTION! If the connector is damaged, please ensure the connector is being

fully repaired before use the unit to avoid causing short circuited.

Storage and safety notice

Although charged batteries may be left unused for several months, their capacity may be depleted due to build up of internal resistance. If this happens, they will require recharging prior to use. Batteries may be stored at temperatures between -20°C to 60°C, however they may deplete more rapidly at higher temperatures. It is recommended to store batteries at room temperature.

* The message above only applies to the usage of the removable batteries.

For the products with non-removable batteries / without batteries, please refer to the specification of each product.

Product Operation and Storage Notice

The unitech product has applicable operation and storage temperature conditions. Please follow the limitation of suggested temperature conditions to avoid failure, damage or malfunction.

*For applicable temperature conditions, please refer to the specification of each

product.

Adapter Notice

1. Please do not leave the power adapter in the socket when it is not

connected to your unitech product for charging.

2. Please remove the power adapter when the battery is fully recharged.

3. The bundled power adapter that comes with your unitech product is not

meant to be used outdoors. An adapter exposed to water or rain, or a very

humid environment can cause damage to both the adapter and the

product.

4. Please only use the bundled power adapter or same specification of

adapter to charge your unitech product. Using the wrong power adapter

can damage your unitech product.

* The message above only applies to the product connected to the adapter.

For the products without using the adapters, please refer to the specification of each product.

ix

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

Hearing Damage Warning

To prevent possible hearing damage, do not listen at high volume levels for long periods.

x

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

Worldwide Support

unitech’s professional support team is available to quickly answer questions or

assist with technical-related issues. Should an equipment problem occur,

please contact the nearest unitech regional service representative.

For complete contact information please visit the Web sites listed below:

Taipei, Taiwan – Headquarters Europe

Tel:

+886-2-89121122

Tel:

+31-13-4609292

E-mail:

info@hq.ute.com

E-mail:

info@eu.ute.com

Address:

5F, No. 136, Lane 235, Baoqiao Road, Xindian

District, New Taipei City 231, Taiwan (R.O.C.)

Address:

Kapitein Hatterasstraat 19, 5015 BB,

Tilburg, the Netherlands

xi

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

Website:

http://www.ute.com

We

bsite:

http://eu.ute.com

China Japan

Tel:

+86-59-2310-9966

Tel:

+81-3-35232766

E-mail:

info@cn.ute.com

E-mail:

info@jp.ute.com

Address:

Website:

Room401C, 4F, RIHUA International Mansion,

Xinfeng 3nd Road, Huoju Hi-tech District,

Xiamen, Fujan , China

Addre

ss:

Website:

Kayabacho Nagaoka Building 8F.,1-5-19

Shinkawa, Chuo-Ku,

Tokyo, 104-0033, Japan

http://jp.ute.com http://cn.ute.com

Asia & Pacific / Middle East Latin America

Tel:

+886-2-27911556

Tel:

+52-55-5171-0528

E-mail:

info@apac.ute.com

info@india.ute.com

info@

mideast.ute.com

E-mail:

Address:

info@latin.ute.com

1717

1 Park Row, Suite 210

Houston, TX 77084USA (Rep.)

Address:

4F., No. 236, ShinHu 2nd Rd.,

NeiHu Chiu, 114, Taipei,Taiwan

Website:

http://latin.ute.com

Website:

http://apac.ute.com / http://mideast.ute.com

North America Please scan QR Code to visit us :

Tel:

+1-714-8916400

E-mail:

Address:

Website:

info@us.ute.com / info@can.ute.com 6182 Katella Ave, Cypress, CA 90630, USA

http://us.ute.com

Warranty Policy

The following items covered under the unitech Limited Warranty are free from defects during normal use:

The warranty period is varied from each country. Please consult with your supplier or unitech local office for actual length of warranty period to your purchased product.

Warranty becomes void if equipment is modified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user.

xii

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

Table of Contents

Preface............................................................................................................. i

Regulatory Compliance Statements ..............................................................i

Laser Information ........................................................................................ vi

LED Information .......................................................................................... vi

Battery Notice............................................................................................. vii

Adapter Notice............................................................................................. ix

Hearing Damage Warning............................................................................ x

Worldwide Support ....................................................................................... x

Warranty Policy .......................................................................................... xii

Chapter 1 - Overview................................................................................1

1.1 Package ................................................................................................. 1

1.2 Product Detail.........................................................................................2

1.3 Specifications .........................................................................................5

1.4 Getting Started .....................................................................................12

Chapter 2 – Installation & Operation.................................................20

2.1 Barcode Setting....................................................................................20

2.2 HF Setting ............................................................................................26

2.3 UHF Setting.......................................................................................... 27

2.4 MSR Setting .........................................................................................27

2.5 WWAN Setting......................................................................................28

2.6 WLAN Setting ( Wifi Scan Config) ........................................................ 30

2.7 PAN Setting .......................................................................................... 36

2.8 GPS Setting..........................................................................................37

2.9 PC Setting ............................................................................................39

2.10 Camera Setting ..................................................................................40

2.11 Performing a Hardware Reset ............................................................45

2.12 Performing Factory data reset ............................................................ 46

xiii

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

xiv

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

2.13 Programmable Keys...........................................................................47

2.14 Battery Swap ...................................................................................... 54

Chapter 3 – Introduction to Applications.........................................58

3.1 Scan Service ........................................................................................ 58

3.2 File Manager ........................................................................................63

3.3 Update Center ...................................................................................... 64

3.4 Sound Recorder ................................................................................... 65

3.5 MoboLink.............................................................................................. 67

PA726 User’s Manual

Chapter 1 - Overview

1.1 Package

Please make sure the following contents are in the PA726 gift box.

If something is missing or damaged, please contact your unitech

representative.

The standard package contents

 PA726 Terminal  Battery  Hand Strap  QR Code Card  Quick Start Guide  Regulatory Compliance Statements

Optional accessories

 4-slot Ethernet Cradle  4-slot Terminal Charging Cradle  1-slot USB Cradle  1-slot Ethernet Cradle  4-slot Battery Charger  Vehicle Charger  USB Holder Cable  Hand Strap with stylus loop  Stylus & Coiled Strap  Bumper  Gun Grip  Wrist-arm Mount  9H Glass Screen Protector

1

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

2

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

PA726 User’s Manual

1.2 Product Detail

PA726 Front View

Receiver

5 megapixel camera

Camera button

Home screen button

Menu button

Back button

Microphone

PA726 User’s Manual

PA726 Rear View

Cable / Cradle connector

Microphone

Speaker

16 megapixel / Autofocus camera

Knobs

Barcode scanner window

Flash LED

Battery cover

3

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

4

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

PA726 User’s Manual

PA726 Left and Right View

Earphone Jack

Programmable Key

Power key

Volume up/down

Scanner trigger button

PA726 User’s Manual

1.3 Specifications

System Features

CPU

MSM8953 2GHz Octa Core ARM A53 64bits

Memory 3GB SDRAM

32GB eMMC / MLC Flash

(2GB of ROM is completely independent partition that delivers

stable processes and flexible programs installation.)

Expanded slot

MicroSD, up to 128GB

OS

Android 7.1

Languages support

English, Simplified Chinese, Traditional Chinese, Japanese,

Spanish, German, French and multiple languages

Display

Gorilla GlassⅢ with 5-point capacitive touch panel

4.67" Color 450 cd/m

2

Brightness 720x1280 dots Color Transmissive type’s TFT

Keypad

4 x Function key 1 x Power key 1 x Programmable key 2 x Scan trigger button 2 x Volume key

Indicator

1 x LED Indicator

Vibrator

5

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

6

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

PA726 User’s Manual

Symbologies

1D (SE655)

 UPC/EAN

 UPC‐A  UPC‐E  UPC‐E1  EAN‐8  EAN‐13  BooklanEAN  BooklandISBNFormat  DecodeUPC/EAN/JANSupplementals  TransmitUPC‐ACheckDigit  TransmitUPC‐ECheckDigit  TransmitUPC‐E1CheckDigit  UPC‐APreamble  UPC‐EPreamble  UPC‐E1Preamble  ConvertUPC‐EtoA  ConvertUPC‐E1toA  EAN‐8/JAN‐8Extend  UCCCouponExtendedCode

 ISSNEAN  Code128  Code39  Code93  Code11  Interleaved2of5  Discrete2of5  Codabar  MSI  Chinese2of5  Matrix2of5  GS1DataBar(RSS)

7

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

PA726 User’s Manual

2D (SE4750)

(2D is only available when the 2D imager is on your device )

 2Dsymbologies

 PDF417

 MicroPDF417

 Code128Emulation

 DataMatrix

 DataMatrixInverse

 Maxicode

 QRcode

 MicroQR

 Aztec

 AztecInverse

 HanXin

 HanXinInverse



 1Dsymbologies  UPC/EAN

 UPC‐A

 UPC‐E

 UPC‐E1

 EAN‐8

 EAN‐13

 BooklanEAN

 BooklandISBNFormat

 DecodeUPC/EAN/JANSupplementals

 TransmitUPC‐ACheckDigit

 TransmitUPC‐ECheckDigit

 TransmitUPC‐E1CheckDigit

 UPC‐APreamble

 UPC‐EPreamble

 UPC‐E1Preamble

 ConvertUPC‐EtoA

 ConvertUPC‐E1toA

 EAN‐8/JAN‐8Extend

 UCCCouponExtendedCode

 ISSNEAN

 Code128  Code39  Code93  Code11  Interleaved2of5  Discrete2of5  Codabar  MSI  Chinese2of5  Matrix2of5  PostalCodes

 USPostnet  USPlanet  TransmitUSPostal

CheckDigit

 UKPostal  TransmitUKPostal

CheckDigit

 JapanPostal  AustralianPostal  NetherlandsKIX

Code

 USPS4CB/One

Code/Intelligent

Mail

 UPUFICSPostal  GS1DataBar(RSS)  Composite

 CompositeCC‐C

 CompositeCC‐A/B

 CompositeTLC‐39  Optional:DPM(Direct

partmarked barcodes)

8

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

PA726 User’s Manual

Engines

1D

SE655 :

Illumination/AIMER : LED 630 ± 30 nm

Optical Resolution : 5 mil (minimum readable bar code module size)

Scan Repetition Rate : Nominally 50 scans/second

Print Contrast : 20% (minimum print contrast)

Ambient Light Immunity Light Source: 4845(lux) ± 5%

2D

SE4750SR (Imager with laser aimer ) :

Sensor Resolution: 1280 x 960 pixels

Illumination Element: 2 x Warm white LED

Minimum Bar Code Print Contrast : 20%

Ambient Light: Max 107,639 lux (direct sunlight)

Wavelength: 655 ± 10 nm

Beam divergence: 48.0º horizontal, 38.0º vertical

Pulse duration: 1.7ms

Maximum power :0.6 mW

Audio

Speaker , 3.5mm Audio Jack, Receiver, 2 x Microphone

Regulatory Approvals

CE, RoHS compliance, FCC, NCC, VCCI,CCC, BSMI

Communication

USB

USB 2.0 Host / Client

WLAN

IEEE 802.11 a/b/g/n/ac/d/h/i/k/r/v

PAN

Bluetooth

®

4.2

WWAN

GSM/GPRS/EDGE 850/900/1800/1900 MHz

UMTS 850/900/1900/2100 MHz

LTE FDD Band 1/2/3/4/5/7/8/20 TDD Band 38/39/40/41

DL: 150Mbps/ UL: 50Mbps

2x Micro SIM slots

RFID/HF

Frequency: 13.56MHz

Tag Support: ISO15693, ISO14443A , ISO14443B

Support NFC

9

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

PA726 User’s Manual

GPS

 (Optional,availableonWWANversion)

12 x 12 mm patch antenna

Support GPS / GLONASS

Camera and Flash Light

16 MP CMOS sensor rear autofocus camera with LED flash light

5MP front camera

External Storage

Support MicroSD memory card up to 128GB

Other Sensors

G-sensor , Light + Proximity sensor , E-Compass, Gyroscope + 3-axis accelerometer

Power Source

Standard Battery

Minimum: 3120mAh/3.6V, full charge should over 95% capacity

Typical: 3220mAh/3.6V, full charge should over 95% capacity

Extended Battery

Minimum: 4660mAh/3.6V, full charge should over 95% capacity

Typical: 4800mAh/3.6V, full charge should over 95% capacity

Enclosure

Weight

Approximately 287g

(including standard battery, without hand strap)

Dimension

Approximately 171.3mm (L) x 29.3mm (H) x 80mm (W)

Environmental

Operating temperature

-4°F to 122°F (-20°C to 50°C)

Storage temperature

-22°F to 140°F (-30°C to 60°C)

Charging Temperature

32°F to 113°F (0°C to 45°C)

Relative Humidity

5% ~ 95% ( non-condensing )

Drop test to Concrete

1.5 meter, 1.8 meter with bumper

Environmental Sealing

IP65

Vibration and Shock test

MIL-STD-810G, 514.4 process II

Software

Android 7.1

Support camera API and Camera 2 API.

10

unitech is a registered trademark of unitech Electronics Co., Ltd.

All product and company names are trademarks, service marks, or registered trademarks of their respective owners

PA726 User’s Manual

Radio type / Description Transmitter Frequency Maximum Output Power

GSM900 880-915MHz 28.5dBm

GSM

DCS 1800 1710-1785MHz 31.5dBm

FDD 1 1920-1980MHz 23dBm

UMTS

FDD 8 880-915MHz 24dBm

FDD 1 1920-1980MHz 23dBm

FDD 3 1710-1785 MHz 24dBm

FDD 7 2500-2570MHz 23.5dBm

FDD 8 880-915MHz 24dBm

FDD 20 832-862MHz 24dBm

LTE

TDD 40 2300-2400MHz 23dBm

IEEE 802.11b 2400-2483.5MHz 16dBm

IEEE 802.11g 2400-2483.5MHz 16dBm

WLAN 2.4GHz

IEEE 802.11n 2400-2483.5MHz 15dBm

5180-5240MHz 15dBm

5260-5320MHz 15dBm

5500-5700MHz 15dBm

IEEE 802.11a

5745-5825MHz 10.5dBm

5180-5240MHz 15dBm

5260-5320MHz 15dBm

5500-5700MHz 15dBm

IEEE 802.11n

5745-5825MHz 10.5dBm

5180-5240MHz 15dBm

5260-5320MHz 15dBm

5500-5700MHz 15dBm

WLAN 5GHz

IEEE 802.11ac

5745-5825MHz 10.5dBm

Bluetooth®

Bluetooth® 2400-2483.5MHz 13.5dBm

RFID

NFC 13.56MHz <25dBuA/m

Unitech PA726 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
