Page 1
UNI-T
Programming Manual
UNI-T
UPO3000E&UPO2000E Series
Programmable Digital Oscilloscope
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 2
UNI-T
Warranty and Statement
Copyright
2017 U n i - T r e n d T e c h n o l o g y (Ch i n a ) C o . , L td .
Brand Information
UNI-T is the registered trademark of Uni-Trend Technology (China) Co., Ltd.
Software Version
00.00.01
Software upgrade may have some change and add more function, please subscribe
UNI-T website to get the new version or contact UNI-T.
Statement
UNI-T products are protected by patents (including obtained and pending) in China and
other countries and regions.
UNI-T reserves the right to change specifications and prices.
The information provided in this manual supersedes all previous publications.
Information provided in this manual is subject to change without prior notice.
UNI-T shall not be liable for any errors that may be contained in this manual. For any
incidental or consequential damages, arising out of the use or the information and
deductive functions provided in this manual.
Without the written permission of UNI-T, this manual cannot photocopied, reproduced
or adapted.
Product Certification
UNI-T has certified that the product conforms to China national product standard and
industry product standard as well as ISO9001:2008 standard and ISO14001:2004
standard. UNI-T will go further to certificate product to meet the standard of other
member of the international standards organization.
Contact Us
If you have any question or problem, you can contact us,
Website：https://www.uni-trend.com
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 3
UNI-T
SCPI
SCPI was defined as an additional layer on top of the IEEE 488.2-1987 specification
"Standard Codes, Formats, Protocols, and Common Commands".The standard
specifies a common syntax, command structure, and data formats, to be used with all
instruments. It introduced generic commands (such as CONFigure and MEASure) that
could be used with any instrument. These commands are grouped into subsystems.
SCPI also defines several classes of instruments. For example, any controllable power
supply would implement the same DCPSUPPLY base functionality class. Instrument
classes specify which subsystems they implement, as well as any instrument-specific
features.
The physical hardware communications link is not defined by SCPI. While it was
originally created for the IEEE-488.1 (GPIB) bus, SCPI can also be used with RS-232,
RS-422, Ethernet, USB, VXIbus, HiSLIP, etc.
SCPI commands are ASCII textual strings, which are send to the instrument over the
physical layer (e.g., IEEE-488.1). Commands are a series of one or more keywords,
many of which take parameters. In the specification, keywords are written
CONFigure: The entire keyword can be used, or it can be abbreviated to just the
uppercase portion. Responses to Query commands are typically ASCII strings.
However, for bulk data, binary formats can be used.
This section introduces the format, symbols, parameters, and abbreviations of the
SCPI command.
Instruction Format
The SCPI command is a tree-like hierarchy consisting of multiple subsystems, each
consisting of a root keyword and one or more hierarchical key words. The command
line usually begins with a colon ":"; Keywords are separated by the colon ":",
followed by optional parameter settings. The command keyword is separated by
spaces from the first parameter. The command string must end with a newline
<NL> character. Add the question mark "? " after the command line. It is
usually indicated that this feature is being queried.
Symbol Description
The following four symbols are not part of SCPI command, it cannot send with the
command. It usually used as supplementary description of command parameter.
Brace { } usually contains multiple optional parameters, it should select one
parameter when send command.
Such as DISPlay:GRID:MODE { FULL | GRID | CROSS | NONE} command
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 4
UNI-T
Vertical Bar | used to separated multiple parameters, it should select one parameter
when send command.
Such as DISPlay:GRID:MODE { FULL | GRID | CROSS | NONE} command
Square Brackets [ ] the contents in square brackets (command keywords) can
omissible. If the parameter is ignoret, the instrument will set the parameter as the
default value.
Such as MEASure:NDUTy? [<source>] command, it presents current channel
Triangular Brackets < > The parameter in the brackets must be replaced with a
valid value.
Such as use DISPlay:GRID:BRIGhtness 30 form to send DISPlay:GRID:BRIGhtness
<count> command
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 5
Parameter Description
The parameter in this manual can divide into five types: Boolean, Integer, Real,
Discrete, ASCII string
Boolean
Parameter value can set “ON” (1) or “OFF” (0)
Such as SYSTem:LOCK {{1 | ON} | {0 | OFF}}
Integer
Parameter can take any valid integer value unless there have some other
descriptions.
Such as command: DISPlay:GRID:BRIGhtness <count> , parameter of
<count> can take integer from 0~100
UNI-T
Note: Do not set decimal as parameter, otherwise it may occur error.
Real
Parameter can take any valid integer value unless there have some other
descriptions.
Such as for command CH1, CHANnell: OFFSet <offset> , parameter of <offset>
can take integer value.
Discrete
Parameter can only take some specified numbers or characters.
Such as command DISPlay:GRID:MODE { FULL | GRID | CROSS | NONE}
parameter can only take FULL, GRID, CROSS, NONE
ASCII Character String
String parameter contain all ASCII string sets. Strings must begin and end
with paired quotes; it can use single or double quotation marks. The quotation
and delimiter can also be part of a string by typing it twice and not adding any
characters.
Such as set IP SYST:COMM:LAN:IPAD "192.168.1.10"
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 6
UNI-T
Shorthand Rule
All command can identify capital and small letter, if command need enter shorthand,
it should be all capital letter.
Data Return
Data return is divided into single data and batch data. The single data return is the
corresponding parameter type, in which the real return type is presents by the
scientific notation method. The part before e retains three figure behind the decimal
point, and the e part retains three figure; the batch return must be obey IEEE
488.2# string data format, ‘#’+ the length of character bits[fixed to one character]+
ASCII valid value+ valid data+ end string[‘\n’]
Such as #3123xxxxxxxxxxxxxxxxxxx\n presents 123 strings batch data return format,
‘3’ presents “123” occupies three character bits.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 7
SCPI Command
IEEE488.2 Common Command
*IDN?
Command format：
*IDN？
Functional description：
For query manufacture name, model, product serial number and software version.
Return format：
Manufacture name, model, product serial number, software version separated by dot
mark.
For example：
UNI-T Technologies, UPO2000CS, UPO1000, 00.00.01
UNI-T
*RST
Command format：
*RST
Functional description：
Restore factory settings and clear the entire error message, send and receive queue buffers.
SYSTem Command
This command is for oscilloscope basic operation, including operating control, lock
full qwerty, error queue and system data.
:RUN
Command format：
:RUN
Functional description：
Start to sampling, execute :STOP command to stop it.
:STOP
Command format：
:STOP
Functional description：
Stop sampling, execute :RUN command to restart it.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 8
:AUTO
Command format：
:AUTO
Functional description：
Set the instrument control value automatically to display waveform to the best effect.
:SYSTem:LOCK
Command format：
:SYSTem:LOCK {{1 | ON} | {0 | OFF}}
:SYSTem:LOCK?
Functional description：
For lock/unlock full qwerty.
Return format：
Query return lock full qwerty status，0 presents unlock, 1 presents lock.
For example：
:SYSTem:LOCK ON/:SYST:LOCK 1 lock full qwerty
:SYSTem:LOCK OFF/:SYST:LOCK 0 unlock full qwerty
:SYSTem:LOCK? query return 1，it presents lock
UNI-T
:SYSTem:ERRor
Command format：
:SYSTem:ERRor
:SYSTem:ERRor?
Functional description：
Empty error message queue.
Return format：
Query return the last error message, like Undefined header.
For example：
:SYSTem:ERR empty error message queue
:SYSTem:ERR? query return Undefined header
:SYSTem:SETup
Command format：
:SYSTem:SETup <setup_data>
:SYSTem:SETup?
Functional description：
For system configuration data, <setup_data> is conform to binary data IEEE 488.2 # format.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 9
Return format：
Query return setup data, return data conform to binary data IEEE 488.2 # format.
:SYSTem:LANGuage
Command format：
:SYSTem:LANGuage {
:SYSTem:LANGuage?
Functional description：
Set system language.
Return format：
Query return{ ENGLish | SIMPlifiedchinese | TRADitionalchinese }。
For example：
:SYSTem:LANGuage ENGL set system language as English
:SYSTem:LANGuage? query return ENGLish
ENGLish | SIMPlifiedchinese | TRADitionalchinese }
UNI-T
:SYSTem:RTC
Command format：
:SYSTem:RTC <year>,<month>,<day>,<hour>,<minute>,<second>
:SYSTem:RTC?
Functional description：
Set system time.
Return format：
Query return year, month, date, hour, minute and second.
For example：
:SYSTem:RTC 2017,7,7,20,8,8 set system time at 20:08:08 July 7,2017
:SYSTem:RTC? query return 2017,7,7,20,8,8
:SYSTem:CAL
Command format：
:SYSTem:
Functional description：
Set system self-calibration, the instrument can not communicate when in self-calibration.
CAL
:SYSTem:CLEAr
Command format：
:SYSTem:
Functional description：
Empty system storage waveform and setup data.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
CLEAr
Page 10
:SYSTem:CYMOmeter
Command format：
:SYSTem:CYMOmeter {1 | ON} | {0 | OFF}
:SYSTem:CYMOmeter?
Functional description：
The switch of frequency meter.
Return format：
Query return frequency meter status，1 presents on, 0 presents off.
For example：
:SYSTem:CYMOmeter ON turn on frequency meter
:SYSTem:CYMOmeter? query return1
:SYSTem:SQUare:SELect
UNI-T
Command format：
:SYSTem:SQUare:SELect { 10Hz | 100Hz | 1KHz | 10KHz }
:SYSTem:SQUare:SELect?
Functional description：
Select square wave output.
Return format：
Query return{ 10Hz | 100Hz | 1KHz | 10KHz }.
For example：
:SYSTem:SQUare:SELect 10Hz select 10Hz square wave output
:SYSTem:SQUare:SELect? query return 10Hz
:SYSTem:OUTPut:SELect
Command format：
:SYSTem:OUTPut:SELect { TRIGger | PASS_FAIL }
:SYSTem:OUTPut:SELect?
Functional description：
Set output selection, TRIGger, PASS_FAIL（pass &fail）.
Return format：
Query return{ TRIGger | PASS_FAIL }.
For example：
:SYSTem:OUTPut:SELect TRIG select TRIG
:SYSTem:OUTPut:SELect? query return TRIG
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 11
:SYSTem:MNUDisplay
Command format：
:SYSTem:MNUDisplay { 1S | 2S | 5S | 10S | 20S | INFinite}
:SYSTem:MNUDisplay?
Functional description：
Set menu display time，INFinite present menu stay on.
Return format：
Query return{ 1S | 2S | 5S | 10S | 20S | INFinite }.
For example：
:SYSTem:MNUDisplay 1S set menu display time as 1s, fold menu fold automatically
:SYSTem:MNUDisplay? query return 1S
:SYSTem:BRIGhtness
Command format：
:SYSTem:BRIGhtness <count>
:SYSTem:BRIGhtness?
Functional description：
Set screen luminance, <count> take value from 1~100，the number greater the screen brighter .
Return format：
Query return the current screen luminance.
For example：
:SYSTem:BRIGhtness 50 set screen luminance as 50
:SYSTem:BRIGhtness? query return 50
UNI-T
:SYSTem:VERSion?
Command format：
:SYSTem:VERSion?
Return format：
Query return version information, character string information of 128 bytes.
HW is hardware version number, SW is software version number，PD is creation date，ICV is
protocol version number.
For example：
:SYST:VERS? query returnHW:1.0;SW:1.0;PD:2014-11-20;ICV:1.4.0
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 12
:SYSTem:COMMunicate:LAN:APPLy
Command format：
:SYSTem:COMMunicate:LAN:APPLy
Functional description：
Set the current internet parameter to take effect immediately.
:SYSTem:COMMunicate:LAN:GATEway
Command format：
:SYSTem:COMMunicate:LAN:GATEway <gateway>
:SYSTem:COMMunicate:LAN:GATEway?
Functional description：
Set the default gateway, <gateway> is belong to ASCII character string parameter，the format is
xxx.xxx.xxx.xxx.
Return format：
Query return the default gateway.
For example：
:SYST:COMM:LAN:GATE "192.168.1.1" set the default gateway as 192.168.1.1
:SYST:COMM:LAN:GATE? query return192.168.1.1
UNI-T
:SYSTem:COMMunicate:LAN:SMASK
Command format：
:SYSTem:COMMunicate:LAN:SMASK <submask>
:SYSTem:COMMunicate:LAN:SMASK?
Functional description：
Set subnet mask, <submask> is belong to ASCII character string, the format is xxx.xxx.xxx.xxx.
Return format：
Query return subnet mask.
For example：
:SYST:COMM:LAN:SMASK "255.255.255.0" set subnet mask 255.255.255.0
:SYST:COMM:LAN:SMASK? query return 255.255.255.0
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 13
:SYSTem:COMMunicate:LAN:IPADdress
Command format：
:SYSTem:COMMunicate:LAN:IPADdress <ip>
:SYSTem:COMMunicate:LAN:IPADdress?
Functional description：
Set IP address, <ip> is belong to ASCII character string, the format is xxx.xxx.xxx.xxx.
Return format：
Query return IP IP address.
For example：
:SYST:COMM:LAN:IPAD "192.168.1.10" set IP address 192.168.1.10
:SYST:COMM:LAN:IPAD? query return 192.168.1.10
:SYSTem:COMMunicate:LAN:DHCP
Command format：
:SYSTem:COMMunicate:LAN:DHCP {{1 | ON} | {0 | OFF}}
:SYSTem:COMMunicate:LAN:DHCP?
Functional description：
To switch configuration mode（auto IP）and（manual IP）.
Return format：
Query return dynamic configuration mode, 0 presents（manual IP）, 1 presents（auto IP）.
For example：
:SYST:COMM:LAN:DHCP ON turn on IP dynamic configuration mode
:SYST:COMM:LAN:DHCP? query return 1
UNI-T
:SYSTem:COMMunicate:LAN:MAC?
Command format：
:SYSTem:COMMunicate:LAN:MAC?
Return format：
Query return MAC physical address
For example：
:SYST:COMM:LAN:MAC? query return 00-2A-A0-AA-E0-56
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 14
KEY Command
This command is to control key and knob on oscilloscope panel.
:KEY:<key>
Command format：
:KEY:<key>
:KEY:<key>:LOCK { {1 | ON} | {0 | OFF} }
:KEY:<key>:LOCK?
:KEY:<key>:LED?
Functional description：
Set key function and lock/unlock this key. <key> definition and description see
<Key> List.
Return format：
Query return lock status or LED status.
Lock status：0 presents unlock, 1 presents lock；
LED status：0 presents light off，1 presents light on（green），2 presents light on（red）.
For example：
:KEY:AUTO set oscilloscope control value
:KEY:AUTO:LOCK ON/OFF lock/unlock key
:KEY:AUTO:LOCK? query return lock status of this key , 1 presents lock.
:KEY:AUTO:LED? query return LED status，0 presents light off
UNI-T
Appendix 1：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 15
UNI-T
CHANnel Command
This command is set channel independently, <n> take value as 1/2/3/4/5/6/7/8/9, it
presents {CH1/CH2/ CH3/ CH4/ MATH/ REF-A/ REF-B/ REF-C/ REF-D}.
:CHANnel<n>:BWLimit
Command format：
:CHANnel<n>:BWLimit {{1|ON}|{0|OFF}}
:CHANnel<n>:BWLimit?
Functional description：
Set bandwidth limit function is ON（turn on bandwidth limit to 20MHz，to reduce display noise）
or OFF（turn off bandwidth limit to achieve full display bandwidth）.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:BWL ON turn on channel 1 bandwidth limit.
:CHAN1:BWL? query return 1，it presents channel 1 bandwidth limit is turn on
:CHANnel<n>:COUPling
Command format：
:CHANnel<n>:COUPling {DC|AC|GND}
:CHANnel<n>:COUPling?
Functional description：
Set channel coupling mode, DC presents the AC and DC component of input signal; AC presents
blocked the DC component of input signal; GND presents cut off input signal.
Return format：
Query AC, DC or GND.
For example：
:CHAN1:COUP DC set channel 1 coupling mode as DC
:CHAN1:COUP? query return DC
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 16
:CHANnel<n>:DISPlay
Command format：
:CHANnel<n>:DISPlay { {1|ON} | {0|OFF} }
:CHANnel<n>:DISPlay?
Functional description：
The switch setting of the specified channel.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:DISP ON turn on channel 1
:CHAN1:DISP? query return 1，it presents channel 1 is turn on
:CHANnel<n>:INVert
Command format：
:CHANnel<n>:INVert { {1|ON} | {0|OFF} }
:CHANnel<n>:INVert?
Functional description：
Turn on/off inversion display function, ON（turn on inversion display function）or OFF（waveform
normal display）.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:INV OFF turn off channel 1 inversion display function
:CHAN1:INV?
Query return 0，it presents channel 1 inversion display function is turn off
UNI-T
:CHANnel<n>:OFFSet
Command format：
:CHANnel<n>:OFFSet <offset>
:CHANnel<n>:OFFSet?
Functional description：
Set waveform offset on vertical position, <n> take value as 1/2/3/4/5, it presents {CH1/CH2/CH3/
CH4/ MATH }.
Return format：
Query return offset value by scientific notation method，unit is V.
For example：
:CHAN1:OFFS 20V set channel 1 vertical offset as 20V
:CHAN1:OFFS? query return 2.000e001
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 17
:CHANnel<n>:PROBe
Command format：
:CHANnel<n>:PROBe { 0.001X | 0.01X | 0.1X | 1X | 10X | 100X | 1000X }
:CHANnel<n>:PROBe?
Functional description：
Set the probe attenuation factor corresponding to the probe.
Return format：
Query return { 0.001X | 0.01X | 0.1X | 1X | 10X | 100X | 1000X }.
For example：
:CHAN1:PROB 10X set channel 1 probe attenuation factor as 10
:CHAN1:PROB? query return 10X
:CHANnel<n>:SCALe
Command format：
:CHANnel<n>:SCALe {<scale> | UP | DOWN}
:CHANnel<n>:SCALe?
Functional description：
Set voltage base in vertical position.
<scale>：voltage base value；
UP：plus one position based on the current position；
DOWN ：minus one position based on the current position.
Return format：
Query return the current voltage position value by scientific notation method, unit is V.
For example：
:CHAN1:SCAL 20V set channel 1 voltage base as 20V
:CHAN1:SCAL? query return 2.000e001
:CHAN1:SCAL UP plus one position based on 20V voltage base
UNI-T
:CHANnel<n>:FILTer
Command format：
:CHANnel<n>:FILTer { {1|ON} | {0|OFF} }
:CHANnel<n>:FILTer?
Functional description：
The switch setting of digital filter function.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:FILT OFF turn off channel 1 digital filter function
:CHAN1:FILT? Query return 0，it presents channel 1 digital filter function is turn off
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 18
:CHANnel<n>:UNITs
Command format：
:CHANnel<n>:UNITs {VOLTs|AMPeres|WATTs|UNKNown}
:CHANnel<n>:UNITs?
Functional description：
Set channel unit as VOLTs, AMPeres, WATTs and UNKNown.
Return format：
Query return VOLTs, AMPeres, WATTs or UNKNown.
For example：
:CHAN1:UNIT VOLT set channel 1 unit as voltage
:CHAN1:UNIT? query return VOLTs
:CHANnel<n>:VERNier
Command format：
:CHANnel<n>:VERNier { {1|ON} | {0|OFF} }
:CHANnel<n>:VERNier?
Functional description：
Set position accommodation mode, ON presents Fine tuning，to further
tuning settings to improve vertical resolution; OFF presents Coarse tuning， based on 1-2-5
system to set vertical sensitivity.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:VERN ON turn on channel 1 fine tuning function
:CHAN1:VERN? query return 1
subdivides between coarse
UNI-T
:CHANnel<n>:BIAS
Command format：
:CHANnel<n>:
:CHANnel<n>:
Functional description：
The switch setting of channel bias voltage.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:BIAS ON turn on channel 1 bias voltage function
:CHAN1: BIAS? query return 1
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
BIAS { {1|ON} | {0|OFF} }
BIAS?
Page 19
:CHANnel<n>:BIASV
Command format：
:CHANnel<n>:
:CHANnel<n>:
Functional description：
Set channel bias voltage value.
Return format：
Query return bias voltage value by scientific notation method，unit is V.
For example：
:CHAN1:
:CHAN1:
BIASV <value>
BIASV?
BIASV 2 set channel 1 bias voltage value as 2V
BIASV? query return 2.000e000
:CHANnel<n>:BIASV:ZREO
Command format：
:CHANnel<n>:
Functional description：
Set channel bias voltage go to zero.
BIASV:ZERO
UNI-T
:CHANnel<n>:SELect
Command format：
:CHANnel<n>:
:CHANnel<n>:
Functional description：
For channel selection.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:
:CHAN1:
SELect
SELect?
SELect select channel 1
SELect? query return 1，it presents channel 1 has been selected
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 20
UNI-T
TIMebase Command
This command is to change the current channel horizontal scale (time base) and
horizontal position of trigger in memory (trigger offset). Horizontal scale change will
make waveform expand or shrink relative to screen center. Horizontal position change
will make wave shift relative to screen center.
:TIMebase:MODE
Command format：
:TIMebase:MODE {MAIN | WINDow}
:TIMebase:MODE?
Functional description：
Set timebase mode, MAIN or WINDow (zoom timebase <Zoomed>）
Return format：
Query return MAIN or WINDow.
For example：
:TIM:MODE MAIN set timebase mode as MAIN
:TIM:MODE? query return MAIN
:TIMebase:OFFSet
Command format：
:TIMebase:OFFSet <offset>
:TIMebase:OFFSet?
Functional description：
For adjust MAIN offset value,
Return format：
Query return<offset> value by scientific notation，unit is s.
For example：
:TIM:OFFS 1s set MAIN offset value as 1s
:TIM:OFFS? query return 1.000e000。
wave shift relative to screen center.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 21
:TIMebase:WINDow:OFFSet
Command format：
:TIMebase:WINDow:OFFSet <offset>
:TIMebase:WINDow:OFFSet?
Functional description：
For adjust WINDow offset value（zoom timebase <Zoomed>）,wave shift relative to screen center.
Return format：
Query return<offset> value by scientific notation method, unit is s.
For example：
:TIM:WIND:OFFS 1 set WINDow offset value as 1s
:TIM:WIND:OFFS? query return 1.000e000
:TIMebase:SCALe
Command format：
:TIMebase:SCALe {<scale> | UP | DOWN}
:TIMebase:SCALe?
Functional description：
Set timebase position of MAIN, s/div.
<scale>：timebase value；
UP：plus one position based on the current position；
DOWN ：minus one position based on the current position.
Return format：
Query return< scale> value by scientific notation method, unit is s/div.
For example：
:TIM:SCAL 2 set MAIN offset value as 2s/div
:TIM:SCAL? query return 2.000e000
UNI-T
:TIMebase:WINDow:SCALe
Command format：
:TIMebase:WINDow:SCALe < scale >
:TIMebase:WINDow:SCALe?
Functional description：
For adjust WINDow timebase（zoom timebase <Zoomed>）, that is s/div.
Return format：
Query return < scale> value by scientific notation method, in s/div.
For example：
:TIM:WIND:SCAL 2 set WINDow timebase offset value as 2s/div
:TIM:WIND:SCAL? query return 2.000e000
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 22
UNI-T
:TIMebase:INDPendent
Command format：
:TIMebase:INDPendent { {1|ON} | {0|OFF} }
:TIMebase:INDPendent?
Functional description：
The switch setting of independent mode of time base.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:TIM:INDP ON turn on independent mode of time base
:TIM:INDP? query return 1
FUNCtion Command
Display the operational result plus, minus, multiply, divide, AND, OR, negation,
exclusive OR and FFT of CH1,CH2,CH3,CH4 waveform, set filter to use expression
operation.
:FUNCtion:MATH:MODE
Command format：
FUNCtion:MATH:MODE {MATH|FFT|LOGic|FILTer|ADVance}
FUNCtion:MATH:MODE?
Functional description：
Select MATH function mode.
Return format：
Query return{MATH|FFT|LOGic|FILTer|ADVance}.
For example：
FUNC:MATH:MODE FFT select MATH mode as FFT mode
FUNC:MATH:MODE? query return FFT
:FUNCtion:OPERation
Command format：
:FUNCtion:OPERation {ADD | SUBTract | MULTiply | DIVide | AND|OR|NOT|XOR}
:FUNCtion:OPERation?
Functional description：
Set functional operator, including basic operation and logic operation, they are plus, minus,
multiply, divide, AND, OR, negation, exclusive OR.
Return format：
Query return{ADD | SUBTract | MULTiply | DIVide | AND|OR|NOT|XOR}.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 23
For example：
:FUNCtion:OPERation ADD use plus operator：src1+src2
:FUNCtion:OPERation? query return ADD
:FUNCtion:DIGital<n>:THReshold
Command format：
:FUNCtion:DIGital<n>:THReshold <value>
:FUNCtion:DIGital<n>:THReshold?
Functional description：
Set the logic threshold of specified channel, if great than the logic threshold take value as 1, less
than the logic threshold take value as 0, n take value as 1, 2, 3, 4.
Return format：
Query return 1.000e000，unit is V.
For example：
:FUNC:DIG1:THR 1V set the logic threshold value of channel 1 as 1V
:FUNC:DIG1:THR? query return 1.000e000
UNI-T
:FUNCtion:SOURce<m>
Command format：
:FUNCtion:SOURce<m> <
:FUNCtion:SOURce<m>?
Functional description：
SOURce <m> presents source 1 or source 2, <m> take vaule as 1, 2.
SOURce1 is to select the first source of operator and math function or it can be single source of
Filter and FFT.
SOURce2 is to select the second source of operator and math function. Single source of Filter,
and FFT is not applicable.
<value> presents CHANnel<n>，<n> take vaule as 1/2/3/4{CH1/ CH2/ CH3/ CH4}.
Return format：
Query return<n> take value as 1/2/3/4/5/6/7/8/9.
For example：
:FUNCtion:SOUR1 CHAN1 choose channel 1 as source 1
:FUNCtion:SOUR1? query return 1
:FUNCtion:SOUR2 CHAN2 choose channel 2 as source 2
:FUNCtion:SOUR2? query return 2
:FUNCtion:OPERation ADD add source 1 and source 2
value>
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 24
:FUNCtion:FFT:WINDow
Command format：
:FUNCtion:FFT:WINDow {RECTangular|HANNing|HAMMing|BMAN}
:FUNCtion:FFT:WINDow?
Functional description：
FFT windowing to intercept signal. RECT, HANN, HAMM, BMAN is rectangular window,
Hanning window, Hamming window and Blacman window respectively.
Return format：
Query return {RECTangular|HANNing|HAMMing|BMAN}.
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FFT:WIND HAMM windowing Hamming window
:FUNC:FFT:WIND? query return HAMMing
UNI-T
:FUNCtion:FFT:VTYPe
Command format：
:FUNCtion:FFT:VTYPe {VRMS|DBRMS}
:FUNCtion:FFT:VTYPe?
Functional description：
Set unit of FFT vertical diection as dbrms or VRMS. dbrms presents root mean square of power;
VRMS presents root mean square of voltage.
Return format：
Query return VRMS, DBRMS.
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FFT:VTYP VRMS
set unit of FFT vertical direction as root mean square of voltage
:FUNC:FFT:VTYP? query return VRMS
:FUNCtion:FFT:FREQuency
Command format：
:FUNCtion:FFT:FREQuency?
Functional description：
The center frequency of spectrum and waveform after obtaining FFT.
Return format：
Query return 1.000e003，unit is Hz.
For example：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 25
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FFT:FREQ? query return 1.000e003
:FUNCtion:FILTer:TYPE
Command format：
:FUNCtion:FILTer:TYPE {LP|HP|BP|BS}
:FUNCtion:FILTer:TYPE?
Functional description：
Set filter mode, LP、HP、BP、BS presents low-pass filter, high-pass filter, band-pass filter and
band-stop filer respectively.
Return format：
Query return LP, HP, BP, BS.
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FILT:TYPE BP set as band-pass filter
:FUNC:FILT:TYPE? query return BP
UNI-T
:FUNCtion:FILTer:FREQuency:HIGH
Command format：
:FUNCtion:FILTer:FREQuency:HIGH < freq>
:FUNCtion:FILTer:FREQuency:HIGH?
Functional description：
The setting of the upper frequency limit of filter. It is applicable for high-pass filter, band-pass
filer and band-stop filter.
Return format：
Query return 1.000e003，unit is Hz.
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FILT:FREQ:HIGH 1KHz set the upper frequency limit of filter as 1kHz
:FUNC:FILT:FREQ:HIGH? query return 1.000e003
:FUNCtion:FILTer:FREQuency:LOW
Command format：
:FUNCtion:FILTer:FREQuency:LOW <freq>
:FUNCtion:FILTer:FREQuency:LOW?
Functional description：
The setting of the low frequency limit of filter. It is applicable for high-pass filter, band-pass filer
and band-stop filter.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 26
Return format：
Query return 6.000e001，unit is Hz.
For example：
:FUNC:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FILT:FREQ:LOW 60Hz set the low frequency limit of filter as 60Hz
:FUNC:FILT:FREQ:LOW? query return 6.000e001
:FUNCtion:LOGic:INVert
Command format：
:FUNCtion:LOGic:INVert {{1|ON}|{0|OFF}}
:FUNCtion:LOGic:INVert?
Functional description：
The switch setting of logic inversion function.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:FUNCtion:LOGic:INVert OFF turn off inversion function
:FUNCtion:LOGic:INVert? query return 0，turn off inversion function
UNI-T
:FUNCtion:EXPRession
Command format：
:FUNCtion:EXPRession <expression>
Functional description：
Use free combination expression to mathematical calculation.
Expression format see Advance item in MATH manu，<expression> is belong to ASCII character
string parameter.
For example：
:FUNCtion:EXRP "CH1*CH2" channel 1 multiply channel 2
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 27
UNI-T
MEASure Command
This command is for oscilloscope basic measurement, return test result by scientific
notation method.
:MEASure:ALL
Command format：
:MEASure:ALL {{1 | ON} | {0 | OFF}}
:MEASure:ALL?
Functional description：
The switch setting of all measurement function.
Return format：
Query return whether all measurement function is turn on.
For example：
:MEASure:ALL ON turn on all measurement function
:MEASure:ALL? query return1
:MEASure:CLEar
Command format：
:MEASure:CLEar
Functional description：
Empty the current measured parameter value.
For example：
:MEAS:CLE delete the current measured parameter value
:MEASure:SOURce
Command format：
:MEASure:SOURce <source>
:MEASure:SOURce?
Functional description：
Select measurement source, <source> is CHANnel<n>，n take value as 1, 2, 3, 4.
Return format：
Query return{CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4}.
For example：
:MEAS:SOUR CHAN1 choose channel 1 as measurement source
:MEAS:SOUR? return CHANnel1
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 28
:MEASure:PDUTy?
Command format：
:MEASure:PDUTy? [<source>]
Functional description：
Measuring positive duty ratio of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 or CHANnel4. Ignore means the current channel.
Return format：
Query return 5.000e001，unit is %.
:MEASure:NDUTy?
Command format：
:MEASure:NDUTy? [<source>]
Functional description：
Measuring negative duty ratio of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, and CHANnel4. Ignore means the current channel.
Return format：
Query return 5.000e001，unit is %。
UNI-T
:MEASure:PDELay?
Command format：
:MEASure:PDELay? [<source1>,<source2>]
Functional description：
Measuring <source1> and <source2> relative to time delay of rise edge, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return-1.000e-004，unit is s.
For example：
Measuring the relative to time delay of rise edge
{
:MEAS:DEL:SOUR CHAN1,CHAN2
:MEASure:PDEL?
}
equivalent to
{
:MEASure:PDEL? CHAN1,CHAN2
}
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 29
:MEASure:NDELay?
Command format：
:MEASure:NDELay? [<source1>,<source2>]
Functional description：
Measuring <source1> and <source2> relative to time delay of fall edge, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4.
Return format：
Query return-1.000e-004，unit is s.
For example：
Measuring the relative to time delay of fall edge
{
:MEAS:DEL:SOUR CHAN1,CHAN2
:MEASure:NDEL?
}
equivalent to
{
:MEASure:NDEL? CHAN1,CHAN2
}
UNI-T
:MEASure:PHASe?
Command format：
:MEASure:PHASe? [<source1>,<source2>]
Functional description：
Timing measuring <source1> relative to <source2> the advance or hysteretic of time quantum, it
presents by degree, 360°as a period, source take value as CHANnel1, CHANnel2, CHANnel3,
and CHANnel4.
Return format：
Query return 1.000e001，unit is degree.
For example：
Measuring <source1> relative to <source2> the advance or hysteretic of time quantum
{
:MEAS:PHAS:SOUR CHAN1,CHAN2
:MEASure:PHAS?
}
equivalent to
{
:MEASure:PHAS? CHAN1,CHAN2
}
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 30
:MEASure:VPP?
Command format：
:MEASure:VPP? [<source>]
Functional description：
Measuring peak-to-peak value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return 3.120e000，unit is V.
:MEASure:VMAX?
Command format：
:MEASure:VMAX? [<source>]
Functional description：
Measuring the maximum value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return2.120e000，unit is V.
UNI-T
:MEASure:VMIN?
Command format：
:MEASure:VMIN? [<source>]
Functional description：
Measuring the minimum value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return -2.120e000，unit is V.
:MEASure:VAMPlitude?
Command format：
:MEASure:VAMPlitude? [<source>]
Functional description：
Measuring the amplitude value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return3.120e000，unit is V.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 31
:MEASure:VTOP?
Command format：
:MEASure:VTOP? [<source>]
Functional description：
Measuring the top value of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return 3.120e000，unit is V.
:MEASure:VBASe?
Command format：
:MEASure:VBASe? [<source>]
Functional description：
Measuring the bottom value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return-3.120e000，unit is V.
UNI-T
:MEASure:VMIDdle?
Command format：
:MEASure:VMIDdle? [<source>]
Functional description：
Measuring the middle value of the specified channel waveform,<source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return0.120e000，unit is V.
:MEASure:VAVerage?
Command format：
:MEASure:VAVerage? [<interval>][,<source>]
Functional description：
Measuring the average value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH. If there has no designated <source>,
the current channel as <source> by default; <interval> appoint the measurement separation, take
value as CYCLe and DISPlay, CYCLe presents integer cycle period, DISPlay presents full screen.
If there has no designated <interval>, take DISPlay by default.
Return format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 32
Query return1.120e000，unit is V.
:MEASure:VRMS?
Command format：
:MEASure:VRMS? [<interval>][,<source>]
Functional description：
Measuring the root mean square value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH. If there has no designated <source>,
the current channel as <source> by default; <interval> appoint the measurement separation, take
value as CYCLe and DISPlay, CYCLe presents integer cycle period, DISPlay presents full screen.
If there has no designated <interval>, take DISPlay by default.
Return format：
Query return1.230e000，unit is V.
:MEASure:AREa?
UNI-T
Command format：
:MEASure:AREa? [<interval>][,<source>]
Functional description：
Measuring the area of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3, CHANnel4 and MATH. If there has no designated <source>, the current
channel as <source> by default; <interval> appoint the measurement separation, take value as
CYCLe and DISPlay, CYCLe presents integer cycle period, DISPlay presents full screen. If there
has no designated <interval>, take DISPlay by default.
Return format：
Query return 3.456e002，unit is Vs.
:MEASure:OVERshoot?
Command format：
:MEASure:OVERshoot? [<source>]
Functional description：
Measuring overshoot of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return1.230e002，unit is V.
:MEASure:PREShoot?
Command format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 33
:MEASure:PREShoot? [<source>]
Functional description：
Measuring preshoot of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return1.230e-002，unit is V.
:MEASure:FREQuency?
Command format：
:MEASure:FREQuency? [<source>]
Functional description：
Measuring frequency of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return 2.000e003，unit is Hz.
UNI-T
:MEASure:RISetime?
Command format：
:MEASure:RISetime? [<source>]
Functional description：
Measuring rise time of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 CHANnel4. Ignore means the current channel.
Return format：
Query return 5.000e-005，unit is s.
:MEASure:FALLtime?
Command format：
:MEASure:FALLtime? [<source>]
Functional description：
Measuring fall time of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return 5.000e-005，unit is s.
:MEASure:PERiod?
Command format：
:MEASure:PERiod? [<source>]
Functional description：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 34
Measuring period of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:PWIDth?
Command format：
:MEASure:PWIDth? [<source>]
Functional description：
Measuring positive pulse width of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:NWIDth?
UNI-T
Command format：
:MEASure:NWIDth? [<source>]
Functional description：
Measuring negative pulse width of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:FRR?
Command format：
:MEASure:FRR? <source1>,<source2>
Functional description：
Measuring time of the first rise edge between <source1> and <source2>, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:FRF?
Command format：
:MEASure:FRF? <source1>,<source2>
Functional description：
Measuring time of the first fall edge between <source1> and <source2>, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4. Ignore means the current channel.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 35
Return format：
Query return 5.000e-003，unit is s.
:MEASure:FFR?
Command format：
:MEASure:FFR? <source1>,<source2>
Functional description：
Measuring time between the first fall edge of <source1> and the first rise edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and CHANnel4.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:FFF?
Command format：
:MEASure:FFF? <source1>,<source2>
Functional description：
Measuring time of the first fall edge between <source1> and <source2>, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and CHANnel4.
Return format：
Query return 5.000e-003，unit is s.
UNI-T
:MEASure:LRR?
Command format：
:MEASure:LRR? <source1>,<source2>
Functional description：
Measuring time between the first rise edge of <source1> and the rise edge of <source2>, <source>
take value as CHANnel1, CHANnel2, CHANnel3 and CHANnel4.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:LRF?
Command format：
:MEASure:LRF? <source1>,<source2>
Functional description：
Measuring time between the first rise edge of <source1> and the first fall edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and CHANnel4.
Return format：
Query return 5.000e-003，unit is s.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 36
:MEASure:LFR?
Command format：
:MEASure:LFR? <source1>,<source2>
Functional description：
Measuring time between the first fall edge of <source1> and the last rise edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and CHANnel4.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:LFF?
Command format：
:MEASure:LFF? <source1>,<source2>
Functional description：
Measuring time between the first fall edge of <source1> and the last fall edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and CHANnel4.
Return format：
Query return 5.000e-003，unit is s.
UNI-T
TRIGger Command
This command is to control trigger sweep mode and trigger standard, trigger decide
when oscilloscope start to collect data and display waveform.
Trigger Command
:TRIGger:MODE
Command format：
:TRIGger:MODE <mode>
:TRIGger:MODE?
Functional description：
Set trigger mode.
<mode> divided into EDGE（edge trigger）, PULSe（pulse width trigger）, VIDeo（video trigger）,
SLOPe（slope trigger）, RUNT（low level trigger）、WINDow（window trigger）、DELay
（delay trigger ）、TIMeout（timeout trigger）、DURation （duration trigger）、SHOLd（setup
hold trigger）、NE（N edge trigger）、PATTern（code pattern trigger）.
Return format：
Query return trigger mode.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 37
For example：
:TRIGger:MODE NE N edge trigger
:TRIGger:MODE? query return NE
:TRIGger:FORCe
Command format：
:TRIGger:FORCe
Functional description：
Execute the command if the oscilloscope has no apporiate trigger term. Force the oscilloscope to
produce a trigger signal to trigger and display the input waveform.
For example：
:TRIG:FORC force trigger
:TRIGger:SWEep
UNI-T
Command format：
:TRIGger:SWEep {AUTO|NORMal|SINGle}
:TRIGger:SWEep?
Functional description：
Select trigger sweep mode.
AUTO：If there has no trigger term, internal will produce trigger signal to force trigger
NORMal：Trigger only when in trigger term
SINGle：In trigger term, trigger one time and stop
Return format：
Query return trigger sweep mode {AUTO|NORMal|SINGle}.
For example：
:TRIGger:SWEep AUTO set channel 1 as auto trigger mode
:TRIGger:SWEep? query return AUTO
:TRIGger:LEVel:ASETup
Command format：
:TRIGger:LEVel:ASETup
Functional description：
Set trigger level on the vertical center point of signal amplitude.
For example：
:TRIG:LEVel:ASETup set trigger level on the center point
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 38
:TRIGger:LEVel
Command format：
:TRIGger:LEVel <level>
:TRIGger:LEVel?
Functional description：
Set the trigger level value of NORMal mode. <level> value must set based on the conversion of
voltage base and screen information.
Return format：
Query return <level> value, unit is V.
For example：
:TRIG:LEV 2 set trigger level as 2V
:TRIG:LEV? query return 2.000e000
:TRIGger:LEVel:LOW
UNI-T
Command format：
:TRIGger:LEVel:LOW <level>
:TRIGger:LEVel:LOW?
Functional description：
Set low level value of slope trigger. <level>value must set based on the conversion of voltage
base and screen information.
Return format：
Query return <level> value, unit is V.
For example：
:TRIG:LEV:LOW 2 set trigger level as 2V
:TRIG:LEV:LOW? query return 2.000e000
:TRIGger:LEVel:HIGH
Command format：
:TRIGger:LEVel:HIGH <level>
:TRIGger:LEVel:HIGH?
Functional description：
Set high level value of slope trigger. <level> value must set based on the conversion of voltage
base and screen information.
Return format：
Query return <level> value, unit is V.
For example：
:TRIG:LEV:HIGH 2 set trigger level as 2V
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 39
:TRIG:LEV:HIGH? query return 2.000e000
:TRIGger:SOURce
Command format：
:TRIGger:SOURce <source>
:TRIGger:SOURce?
Functional description：
Set single information source trigger, input channel(CHANnel1, CHANnel 2, CHANnel 3,
CHANnel 4）, external trigger( EXT, EXT5), AC Line. Only EDGE/ PULSe / VIDeo support AC
Line, EXT and EXT5.
<source> presents information source trigger,
CHANnel<n>|EXT|EXT5|ACLine，<n> take value as 1, 2, 3, 4.
Return format：
Query return information source trigger { CHANnel1| CHANnel2| CHANnel3|
CHANnel4|EXT|EXT5|ACLINE}.
For example：
:TRIGger:SOUR CHAN1 set channel 1 as edge trigger
:TRIGger:SOUR? query return CHANnel1
UNI-T
:TRIGger:COUPling
Command format：
:TRIGger:COUPling {DC|AC|LF|HF|NOISE}
:TRIGger:COUPling?
Functional description：
Set the coupling mode, DC, AC, LF, HF and NOISE, except VIDeo.
Return format：
Query return coupling mode {DC|AC|LF|HF|NOISE}.
For example：
:TRIGger:COUPling AC set edge trigger as AC
:TRIGger:COUPling? query return AC
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 40
Edge Trigger
:TRIGger:EDGE:SLOPe
Command format：
:TRIGger:EDGE:SLOPe {POSitive|NEGative|ALTernation}
:TRIGger:EDGE:SLOPe?
Functional description：
Set edge trigger mode，POSitive, NEGative and ALTernation.
Return format：
Query return edge trigger mode { POSitive | NEGative | ALTernation }.
For example：
:TRIGger:EDGE:SLOP POS set edge trigger mode as POSitive
:TRIGger:EDGE:SLOP? query return POSitive
UNI-T
Pulse Width Trigger
:TRIGger:PULSe:QUALifier
Command format：
:TRIGger:PULSe:QUALifier {GREaterthan | LESSthan | EQUal}
:TRIGger:PULSe:QUALifier?
Functional description：
Set the term of pulse time, GREaterthan, LESSthan and EQUal.
Return format：
Query return { GREaterthan | LESSthan | EQUal }.
For example：
:TRIGger:PULSe:QUALifier GRE set the pulse term as GREaterthan
:TRIGger:PULSe:QUALifier? query return GREaterthan
:TRIGger:PULSe:POLarity
Command format：
:TRIGger:PULSe:POLarity {POSitive | NEGative}
:TRIGger:PULSe:POLarity?
Functional description：
Set the pulse polarity, POSitive and NEGative.
Return format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 41
Query return{ POSitive | NEGative }.
For example：
:TRIGger:PULSe:POL POS set pulse polarity as POSitive
:TRIGger:PULSe:POL? query return POSitive
:TRIGger:PULSe:TIME
Command format：
:TRIGger:PULSe:TIME <time>
:TRIGger:PULSe:TIME?
Functional description：
Set time interval of pulse width trigger.
Return format：
Query return the current time interval, unit is s.
For example：
:TRIGger:PULSe:TIME 1 set pulse width as 1s
:TRIGger:PULSe:TIME? query return1.000e000
UNI-T
Video Trigger
:TRIGger:VIDeo:MODE
Command format：
:TRIGger:VIDeo:MODE {
:TRIGger:VIDeo:MODE?
Functional description：
Set the sync mode of video trigger, ODD, EVEN, LINE and ALINes.
Return format：
Query return{
For example：
:TRIGger:VIDeo:MODE ODD set the sync mode as ODD
:TRIGger:VIDeo:MODE? query return ODD
ODD | EVEN | LINE| ALIN}.
:TRIGger:VIDeo:STANdard
ODD | EVEN | LINE| ALINes}
Command format：
:TRIGger:VIDeo:STANdard {
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
NTSC | PAL | SECam }
Page 42
:TRIGger:VIDeo:STANdard?
Functional description：
Set the video standard.
Return format：
Query return{
For example：
:TRIGger:VIDeo:STANdard NTSC set the video standard as NTSC
:TRIGger:VIDeo:STANdard? query return NTSC
NTSC | PAL | SECam }.
:TRIGger:VIDEO:LINE
Command format：
:TRIGger:VIDEO:LINE <value>
:TRIGger:VIDEO:LINE?
Functional description：
Set the specified line of video sync, <value> presents the specified line and the range, which is
related to the video standard.
Return format：
Query return the specified line.
For example：
:TRIG:VIDEO:LINE 50 set the specified line of video sync as 50
:TRIG:VIDEO:LINE? query return 50
UNI-T
:TRIGger:VIDEO:SRATe?
Command format：
:TRIGger:VIDEO:SRATe?
Functional description：
To obtain the slew rate of video.
Return format：
Query return the current slew rate, return format is conform to binary data IEEE 488.2 # format.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 43
Slope Trigger
:TRIGger:SLOPe:QUALifier
Command format：
:TRIGger:SLOPe:QUALifier {GREaterthan | LESSthan | EQUal}
:TRIGger:SLOPe:QUALifier?
Functional description：
Set the term of slope time, GREaterthan, LESSthan and EQUal.
Return format：
Query return{GREaterthan | LESSthan | EQUal}.
For example：
:TRIGger:SLOPe:QUALifier GRE set the slope term as GREaterthan
:TRIGger:SLOPe:QUALifier? query return GREaterthan
UNI-T
:TRIGger:SLOPe:SLOPe
Command format：
:TRIGger:SLOPe:SLOPe {POSitive|NEGative}
:TRIGger:SLOPe:SLOPe?
Functional description：
Set the type of slope trigger, POSitive and NEGative.
Return format：
Query return{POSitive|NEGative}。
For example：
:TRIGger:SLOPe:SLOPe POS set the slope trigger as POSitive
:TRIGger:SLOPe:SLOPe? query return POSitive
:TRIGger:SLOPe:TIME
Command format：
:TRIGger:SLOPe:TIME <time>
:TRIGger:SLOPe:TIME?
Functional description：
Set the time interval of slope trigger.
Return format：
Query return the current time interval，unit is s.
For example：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 44
:TRIGger:SLOPe:TIME 1 set the time interval of slope trigger as 1s
:TRIGger:SLOPe:TIME? query return1.000e000
:TRIGger:SLOPe:THReshold
Command format：
:TRIGger:SLOPe:THReshold {LOW|HIGH|LH}
:TRIGger:SLOPe:THReshold?
Functional description：
Set the threshold mode of slope trigger.
Return format：
Query return{LOW|HIGH|LH}.
For example：
:TRIGger:SLOPe:THR HIGH set the threshold mode of slope trigger as HIGH
:TRIGger:SLOPe:THR? query return HIGH
UNI-T
Runt Trigger
:TRIGger:RUNT:QUALifier
Command format：
:TRIGger:RUNT:QUALifier {GREaterthan | LESSthan | EQUal | NONE}
:TRIGger:RUNT:QUALifier?
Functional description：
Set time term of low level, GREaterthan, LESSthan, EQUal and NONE.
Return format：
Query return{GREaterthan | LESSthan | EQUal | NONE}.
For example：
:TRIGger:RUNT:QUALifier GRE set the slope term as GREaterthan
:TRIGger:RUNT:QUALifier? query return GREaterthan
:TRIGger:RUNT:POLarity
Command format：
:TRIGger:RUNT:POLarity {POSitive | NEGative}
:TRIGger:RUNT:POLarity?
Functional description：
Set the polarity of low level, POSitive and NEGative.
Return format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 45
Query return{POSitive | NEGative}.
For example：
:TRIGger:RUNT:POL POS set the pulse polarity as POSitive
:TRIGger:RUNT:POL? query return POSitive
:TRIGger:RUNT:LEVel
Command format：
:TRIGger:RUNT:LEVel {LOW | HIGH}
:TRIGger:RUNT:LEVel?
Functional description：
Set the trigger mode of low level.
Return format：
Query return {LOW | HIGH}.
For example：
:TRIGger:RUNT:LEV HIGH set the trigger mode of low level as HIGH
:TRIGger:RUNT:LEV? query return HIGH
UNI-T
:TRIGger:RUNT:TIME
Command format：
:TRIGger:RUNT:TIME <time>
:TRIGger:RUNT:TIME?
Functional description：
Set the time interval of low level.
Return format：
Query return the current time interval，unit is s.
For example：
:TRIGger:RUNT:TIME 1 set the time interval of low level as 1s
:TRIGger:RUNT:TIME? query return 1.000e000
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 46
Exceed-amplitude Trigger
:TRIGger:WINDow:SLOPe
Command format：
:TRIGger:WINDow:SLOPe {POSitive|NEGative|ALTernation}
:TRIGger:WINDow:SLOPe?
Functional description：
Set edge trigger mode，POSitive, NEGative and ALTernation.
Return format：
Query return edge trigger mode {POSitive|NEGative|ALTernation}.
For example：
:TRIGger:WINDow:SLOP POS set the window trigger as POSitive
:TRIGger:WINDow:SLOP? query return POSitive
UNI-T
:TRIGger:WINDow:LEVel
Command format：
:TRIGger:WINDow:LEVel {LOW | HIGH}
:TRIGger:WINDow:LEVel?
Functional description：
Set the level mode of window trigger.
Return format：
Query return {LOW | HIGH}.
For example：
:TRIGger:WINDow:LEV HIGH set the level mode of window trigger as HIGH
:TRIGger:WINDow:LEV? query return HIGH
:TRIGger:WINDow:TIME
Command format：
:TRIGger:WINDow:TIME <time>
:TRIGger:WINDow:TIME?
Functional description：
Set the time interval of window trigger.
Return format：
Query return the current time interval，unit is s.
For example：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 47
:TRIGger:WINDow:TIME 1 set the time interval of window trigger as 1s
:TRIGger:WINDow:TIME? query return1.000e000
:TRIGger:WINDow:POSition
Command format：
:TRIGger:WINDow:POSition {ENTER|EXIT|TIME}
:TRIGger:WINDow:POSition?
Functional description：
Set the position of window trigger.
Return format：
Query return {ENTER|EXIT|TIME}.
For example：
:TRIGger:WINDow:POS TIME set the position of window trigger at TIME
:TRIGger:WINDow:POS? query return TIME
UNI-T
Delay Trigger
:TRIGger:DELay:ARM:SOURce
Command format：
:TRIGger:DELay:ARM:SOURce {CHANnel1 | CHANnel2| CHANnel3| CHANnel4}
:TRIGger:DELay:ARM:SOURce?
Functional description：
Set the focus source of delay trigger.
Return format：
Query return{CHANnel1 | CHANnel2| CHANnel3| CHANnel4}.
For example：
:TRIGger:DELay:ARM:SOUR CHAN1 set channel 1 as the focus source
:TRIGger:DELay:ARM:SOUR? query returnCHANnel1
:TRIGger:DELay:ARM:SLOPe
Command format：
:TRIGger:DELay:ARM:SLOPe {NEGative | POSitive}
:TRIGger:DELay:ARM:SLOPe?
Functional description：
Set edge trigger mode, POSitive and NEGative.
Return format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 48
Query return {NEGative | POSitive}.
For example：
:TRIGger:DELay:ARM:SOUR NEG set edge trigger source as NEGative
:TRIGger:DELay:ARM:SOUR? query return NEGative
:TRIGger:DELay:TRIGger:SOURce
Command format：
:TRIGger:DELay:
:TRIGger:DELay:
Functional description：
Set the delay trigger source.
Return format：
Query return{CHANnel1 | CHANnel2| CHANnel3| CHANnel4}。
For example：
:TRIGger:DELay:
:TRIGger:DELay:
TRIGger:SOURce {CHANnel1 | CHANnel2| CHANnel3| CHANnel4}
TRIGger:SOURce?
TRIGger:SOUR CHAN1 set channel 1 as the trigger source
TRIGger:SOUR? query return CHANnel1
UNI-T
:TRIGger:DELay:TRIGger:SLOPe
Command format：
:TRIGger:DELay:
:TRIGger:DELay:
Functional description：
Set edge trigger mode, POSitive and NEGative.
Return format：
Query return {NEGative | POSitive}.
For example：
:TRIGger:DELay:
:TRIGger:DELay:
TRIGger:SLOPe {NEGative | POSitive}
TRIGger:SLOPe?
TRIGger:SOUR NEG set edge trigger source as NEGative
TRIGger:SOUR? query return NEGative
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 49
:TRIGger:DELay:QUALifier
Command format：
:TRIGger:DELay:QUALifier {
:TRIGger:DELay:QUALifier?
Functional description：
Set the time interval term of delay trigger, GREaterthan, LESSthan, INRange and OUTRange.
Return format：
Query return{
For example：
:TRIGger:DELay:QUALifier GRE set the slope term as GREaterthan
:TRIGger:DELay:QUALifier? query return GREaterthan
GREaterthan | LESSthan | INRange | OUTRange }.
GREaterthan | LESSthan | INRange | OUTRange }
:TRIGger:DELay:MODE
Command format：
:TRIGger:DELay:MODE {
:TRIGger:DELay:MODE?
Functional description：
Set the time mode of delay trigger.
Return format：
Query return {
For example：
:TRIGger:DELay:MODE UPPER set the delay trigger mode as UPPER
:TRIGger:DELay:MODE? query return UPPER
NORMAL | UPPER | LOW }.
NORMAL | UPPER | LOW }
UNI-T
:TRIGger:DELay:TIME
Command format：
:TRIGger:
:TRIGger:
Functional description：
Set the time interval of delay trigger.
Return format：
Query return the current time interval，unit is s.
For example：
:TRIGger:
:TRIGger:
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
DELay:TIME <time>
DELay:TIME?
DELay:TIME 1 set the time interval of delay trigger as 1s
DELay:TIME? query return1.000e000
Page 50
:TRIGger:DELay:SELect
Command format：
:TRIGger:DELay:SELect <SOURce<n>>
:TRIGger:DELay:SELect
Functional description：
For switch selected source, SOURce<n>presents source，n take value as1, 2.
SOURce1 presents the focus source；SOURce2 presents trigger source.
Return format：
Query return{ SOURce1 | SOURce2 }.
For example：
:TRIGger:DELay:SELect SOURce1 select the focus source
:TRIGger:DELay:SELect? query return SOURce1
Timeout Trigger
UNI-T
:TRIGger:TIMEOUT:TIME
Command format：
:TRIGger:
:TRIGger:
Functional description：
Set the time interval of timeout trigger.
Return format：
Query return the current time interval，unit is s.
For example：
:TRIGger:
:TRIGger:
TIMEOUT:TIME <time>
TIMEOUT:TIME?
TIMEOUT:TIME 1 set the time interval of timeout trigger as 1s
TIMEOUT:TIME? query return 1.000e000
:TRIGger:TIMEOUT:SLOPe
Command format：
:TRIGger:TIMEOUT:SLOPe {POSitive|NEGative|ALTernation}
:TRIGger:TIMEOUT:SLOPe?
Functional description：
Set edge trigger mode, POSitive, NEGative and ALTernation.
Return format：
Query return edge trigger mode {POSitive|NEGative|ALTernation}.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 51
For example：
:TRIGger:TIMEOUT:SLOP POS set the edge trigger as POSitive
:TRIGger:TIMEOUT:SLOP? query return POSitive
Duration Trigger
:TRIGger:DURation:MODE
Command format：
:TRIGger:DURation:MODE {
:TRIGger:DURation:MODE?
Functional description：
Set the time mode of duration trigger.
Return format：
Query return{
For example：
:TRIGger:DURation:MODE UPPER set duration trigger as UPPER mode
:TRIGger:DURation:MODE? query return UPPER
NORMAL | UPPER | LOW }.
NORMAL | UPPER | LOW }
UNI-T
:TRIGger:DURation:PATTern
Command format：
:TRIGger:DURation:PATTern {
:TRIGger:DURation:PATTern?
Functional description：
Set the code pattern of duration trigger, HIGH(code pattern value as 1), LOW（code pattern
value as 0）, X (channel is invalid.)
Return format：
Query return{
For example：
:TRIGger:DURation:PATTern HIGH set the code pattern of duration trigger as 1
:TRIGger:DURation:PATTern? query return HIGH
HIGH | LOW | X }.
HIGH | LOW | X }
:TRIGger:DURation:QUALifier
Command format：
:TRIGger:DURation:QUALifier {
:TRIGger:DURation:QUALifier?
GREaterthan | LESSthan | INRange }
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 52
Functional description：
Set the time interval term of delay trigger, GREaterthan, LESSthan and INRange.
Return format：
Query return{
For example：
:TRIGger:DURation:QUALifier GRE set the slope terms as GREaterthan
:TRIGger:DURation:QUALifier? query return GREaterthan
GREaterthan | LESSthan | INRange }.
Setup Hold Trigger
:TRIGger:SHOLd:DATA:SOURce
Command format：
:TRIGger:SHOLd:DATA:SOURce {CHANnel1 | CHANnel2| CHANnel3| CHANnel4}
:TRIGger:SHOLd:DATA:SOURce?
Functional description：
Set data source of setup hold trigger.
Return format：
Query return {CHANnel1 | CHANnel2| CHANnel3| CHANnel4}.
For example：
:TRIGger:SHOLd:DATA:SOUR CHAN1 set channel 1 as data source
:TRIGger:SHOLd:DATA:SOUR? query return CHANnel1
UNI-T
:TRIGger:SHOLd:CLOCK:SOURce
Command format：
:TRIGger:SHOLd:CLOCK:SOURce {CHANnel1 | CHANnel2| CHANnel3| CHANnel4}
:TRIGger:SHOLd:CLOCK:SOURce?
Functional description：
Set clock source of setup hold trigger.
Return format：
Query return{CHANnel1 | CHANnel2| CHANnel3| CHANnel4}.
For example：
:TRIGger:SHOLd:CLOCK:SOUR CHAN1 set channel 1 as clock source
:TRIGger:SHOLd:CLOCK:SOUR? query return CHANnel1
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 53
:TRIGger:SHOLd:SLOPe
Command format：
:TRIGger:SHOLd:SLOPe {POSitive|NEGative}
:TRIGger:SHOLd:SLOPe?
Functional description：
Set edge trigger mode of setup hold, POSitive and NEGative.
Return format：
Query return {POSitive|NEGative}.
For example：
:TRIGger:SHOLd:SLOPe POS set setup hold trigger as POSitive
:TRIGger:SHOLd:SLOPe? query return POSitive
:TRIGger:SHOLd:PATTern
UNI-T
Command format：
:TRIGger:SHOLd:PATTern {
:TRIGger:SHOLd:PATTern?
Functional description：
Set the code pattern of setup hold trigger, HIGH(code pattern value as 1), LOW（code pattern
value as 0）.
Return format：
Query return{
For example：
:TRIGger:SHOLd:PATTern HIGH set the code pattern of setup hold trigger 1
:TRIGger:SHOLd:PATTern? query return HIGH
HIGH | LOW }.
HIGH | LOW }
:TRIGger:SHOLd:MODE
Command format：
:TRIGger:SHOLd:MODE {
:TRIGger:SHOLd:MODE?
Functional description：
Set the time of mode of trigger, SETup, HOLD and SH.
Return format：
Query return{
For example：
:TRIGger:SHOLd:MODE HOLD set the time mode as HOLD
:TRIGger:SHOLd:MODE? query return HOLD
SETup | HOLD | SH }.
SETup | HOLD | SH }
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 54
:TRIGger:SHOLd:TIME:STEP
Command format：
:TRIGger:SHOLd:TIME:STEP <step>
:TRIGger:SHOLd:TIME:STEP?
Functional description：
Set time interval of setup hold trigger to adjust stepped value.
Return format：
Query return the current stepped value, unit is s.
For example：
:TRIGger:SHOLd:TIME:STEP 0.001 set time interval of setup hold trigger as 1ms
:TRIGger:SHOLd:TIME:STEP? query return 1.000e-003
:TRIGger:SHOLd:TIME
Command format：
:TRIGger:SHOLd:TIME <time>
:TRIGger:SHOLd:TIME?
Functional description：
Set the time interval of setup hold trigger.
Return format：
Query return the current time interval, unit is s.
For example：
:TRIGger:SHOLd:TIME 1 set time interval of setup hold trigger as 1ms
:TRIGger:SHOLd:TIME? query return 1.000e000
UNI-T
:TRIGger:SHOLd:SELect
Command format：
:TRIGger:SHOLd:SELect <SOURce<n>>
:TRIGger:SHOLd:SELect
Functional description：
For switch selected source, SOURce<n> presents source, n take value as1, 2.
SOURce1 presents data source；SOURce2 presents clock source.
Return format：
Query return{ SOURce1 | SOURce2 }.
For example：
:TRIGger:SHOLd:SELect SOURce1 set the selected focus source
:TRIGger:SHOLd:SELect? query return SOURce1
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 55
N Edge Trigger
:TRIGger:NEDGE:SLOPe
Command format：
:TRIGger:NEDGE:SLOPe {POSitive|NEGative }
:TRIGger:NEDGE:SLOPe?
Functional description：
Set edge trigger mode, POSitive and NEGative.
Return format：
Query return edge trigger mode {POSitive|NEGative }.
For example：
:TRIGger:NEDGE:SLOP POS set edge trigger as POSitive
:TRIGger:NEDGE:SLOP? query return POSitive
UNI-T
:TRIGger:NEDGE:TIME
Command format：
:TRIGger:
:TRIGger:
Functional description：
Set time interval of N edge trigger.
Return format：
Query return the current time interval, unit is s.
For example：
:TRIGger:
:TRIGger:
NEDGE:TIME <time>
NEDGE:TIME?
NEDGE:TIME 1 set time interval of N edge trigger as 1s
NEDGE:TIME? query return 1.000e000
Code Pattern Trigger
:TRIGger:PATTern:PATTern
Command format：
:TRIGger:
:TRIGger:
Functional description：
Set the code pattern, HIGH（code pattern value as 1）, LOW（code pattern value as 0）, X（channel
is invalid）, POSitive and NEGative.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
PATTern:PATTern { HIGH | LOW | X | POSitive | NEGative }
PATTern:PATTern?
Page 56
Return format：
Query return{
For example：
:TRIGger:PATTern:PATTern HIGH set the code pattern as 1
:TRIGger:PATTern:PATTern? query return HIGH
HIGH | LOW | X | POSitive | NEGative }。
UNI-T
CURSor Command
This command is to set cursor parameter, to measure waveform data on the screen.
:CURSor:MODE
Command format：
:CURSor:MODE {
:CURSor:MODE?
Functional description：
Set cursor mode, TRACK and INDependent.
Return format：
Query return{
For example：
:CURSor:MODE TRACK set cursor mode as TRACK
:CURSor:MODE? query return TRACK
TRACK | INDependent }.
TRACK | INDependent }
:CURSor:TYPE
Command format：
:CURSor:TYPE {AMPlitude | TIME | CLOSe }
:CURSor:TYPE?
Functional description：
Set cursor mode, AMPlitude, TIME and CLOSe.
Return format：
Query return {AMPlitude | TIME | CLOSe }.
For example：
:CURSor:TYPE AMP set cursor mode as AMPlitude
:CURSor:TYPE? query return AMPlitude
:CURSor:SOURce
Command format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 57
:CURSor:SOURce <source>
:CURSor:SOURce?
Functional description：
Set cursor source of manual cursor mode, <source> take value as CHANnel<n>，n take value as 1,
2, 3, 4.
Return format：
Query return{ CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4 }.
For example：
:CURSor:SOURce CHAN1 set channel 1 as cursor source
:CURSor:SOURce? query return CHANnel1
:CURSor:CURA
Command format：
:CURSor:CURA <value>
:CURSor:CURA?
Functional description：
Set the horizontal or vertical position of A cursor line. It is related with directive CURSor:TYPE，
amplitude presents the vertical position, time presents the horizontal position. Vertical line range
[0,699]，horizontal line range [28,227].
Return format：
Query return the position of A cursor line.
For example：
:CURSor:CURA 50 set manual A cursor line position as 50
:CURSor:CURA? query return 50
UNI-T
:CURSor:CURB
Command format：
:CURSor:CURB <value>
:CURSor:CURB?
Functional description：
Set the horizontal or vertical position of B cursor line. It is related with directive CURSor:TYPE.
Return format：
Query return the position of B cursor line.
For example：
:CURSor:CURB 50 set manual B cursor line position as 50
:CURSor:CURB? query return 50
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 58
STORage Command
This command is to set and read waveform data and system setup.
:STORage:TYPE
Command format：
:STORage:TYPE {
:STORage:TYPE?
Functional description：
Set storage mode, SETUP and WAVE.
Return format：
Query return{ SETUP | WAVE}.
For example：
:STORage:TYPE WAVE set storage mode as WAVE
:STORage:TYPE? query return WAVE
SETUP | WAVE}
UNI-T
:STORage:WAVE:SOURce
Command format：
:STORage:WAVE:SOURce <source>
:STORage:WAVE:SOURce?
Functional description：
Select storage channel of waveform data.
<source> take value as CHANnel<n>，n take value as 1, 2, 3, 4.
Return format：
Query return {CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4}.
For example：
:STORage:WAVE:SOURce CHAN1 save channel 1 waveform
:STORage:WAVE:SOURce? query return CHANnel1
:STORage:CSV:STARt
Command format：
:STORage:CSV:STARt
Functional description：
Start storage CSV file function.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 59
:STORage:SAVE
Command format：
:STORage:SAVE
Functional description：
Based on the current storage mode to save waveform or set it.
:STORage:LOAD
Command format：
:STORage:LOAD
Functional description：
Based on the current storage mode to call out setup data.
:STORage:LOCation
UNI-T
Command format：
:STORage:LOCation <location>
:STORage:LOCation?
Functional description：
Set the current internal storage position. <location> 0~255，stepped as 1.
Return format：
Query return the current internal storage position.
For example：
:STORage:LOCation 5 set the fifth file as the internal storage position
:STORage:LOCation? query return 5
:STORage:DISK:SELect
Command format：
:STORage:DISK:SELect {FLASH | UDISK}
:STORage:DISK:SELect?
Functional description：
For select storage medium.
Return format：
Query return{FLASH | UDISK}.
For example：
:STORage:DISK:SELect FLASH select FLASH as internal storage medium
:STORage:DISK:SELect? query return FLASH
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 60
REF Command
This command is to set and read reference waveform.
:REF:LOCation
Command format：
:REF:LOCation <location>
:REF:LOCation?
Functional description：
Set load internal storage position of reference waveform, <location> 0~255，stepped as 1.
Return format：
Query return the current internal storage position.
For example：
:REF:LOCation 5 set the fifth file as the internal storage position
:REF:LOCation? query return 5
UNI-T
:REF:LOAD
Command format：
:REF:LOAD
Functional description：
Load local reference waveform data.
:REF:CLEar
Command format：
:REF:CLEar
Functional description：
Empty displayed reference waveform.
:REF:DISK:SELect
Command format：
:REF:DISK:SELect {FLASH | UDISK}
:REF:DISK:SELect?
Functional description：
For select storage medium of reference waveform.
Return format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 61
Query return{FLASH | UDISK}.
For example：
:REF:DISK:SELect FLASH reference waveform extract from internal storage
:REF:DISK:SELect? query return FLASH
ACQuire Command
This command is to set sampling mode.
:ACQuire:TYPE
Command format：
:ACQuire:TYPE {NORMal | AVERage | PEAKdetect | ENVelope | HRESolution }
:ACQuire:TYPE?
Functional description：
Set sampling mode, NORMal, AVERage, PEAKdetect, ENVelope and HRESolution.
Return format：
Query return {NORMal | AVERage | PEAKdetect | ENVelope | HRESolution }.
For example：
:ACQ:TYPE AVER set aquire mode as AVERage
:ACQ:TYPE? query return AVERage
UNI-T
:ACQuire:MODE
Command format：
:ACQuire:MODE {RTIMe | ETIMe }
:ACQuire:MODE?
Functional description：
Set sampling mode, RTIMe and ETIMe.
Return format：
Query return{RTIMe | ETIMe }.
For example：
:ACQ:MODE RTIM set sampling mode as real-time sampling
:ACQ:MODE? query return RTIMe
:ACQuire:AVERages:COUNt
Command format：
:ACQuire:AVERages:COUNt <count>
:ACQuire:AVERages:COUNt?
Functional description：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 62
Set average count of average sampling mode, <count> stepped in Nth power of 2, take value
from 2~8192 , 1≤N≤30.
Return format：
Query return the current average count.
For example：
:ACQ:AVER:COUN 32 set average count as 32
:ACQ:AVER:COUN? query return 32
:ACQuire:MEMory:DEPTh
Command format：
:ACQuire:MEMory:DEPTh { AUTO | 700 | 7K | 70K | 700K | 7M | 70M }
:ACQuire:MEMory:DEPTh?
Functional description：
Set depth mode of sampling storage.
Return format：
Query return{ AUTO | 700 | 7K | 70K | 700K | 7M | 70M }.
For example：
:ACQ:MEM:DEPT ATUO set storage depth as AUTO mode
:ACQ:MEM:DEPT? query return AUTO
UNI-T
DISPlay Command
This command is to set or query display function or data.
:DISPlay:DATA?
Command format：
:DISPlay:DATA?
Functional description：
For query the current image data on the screen.
Return format：
Query return BMP image data, return data is conform to binary data IEEE 488.2 # format.
For example：
:DISPlay:DATA? query return image data image data
data format：#800012345+bitmap data
:DISPlay:FORMat
Command format：
:DISPlay:
:DISPlay:FORMat?
FORMat { VECTors | DOTS }
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 63
Functional description：
Set display format of sampling point, VECTors and DOTS.
Return format：
Query return{ VECTors | DOTS }.
For example：
:DISPlay:FORMat VECT set display format as VECTors
:DISPlay:FORMat query return VECTors
:DISPlay:GRID:BRIGhtness
Command format：
:DISPlay:GRID:BRIGhtness <count>
:DISPlay:GRID:BRIGhtness?
Functional description：
Set grid luminance, <count> take value as 1~100, the number is greater the grid brighter.
Return format：
Query return the current grid luminance.
For example：
:DISPlay:GRID:BRIGhtness 50 set grid luminance as 50
:DISPlay:GRID:BRIGhtness? query return 50
UNI-T
:DISPlay:WAVE:BRIGhtness
Command format：
:DISPlay:WAVE:BRIGhtness <count>
:DISPlay:WAVE:BRIGhtness?
Functional description：
Set waveform luminance, <count> take value as 1~100，the number is greater the waveform
brighter.
Return format：
Query return the current waveform luminance.
For example：
:DISPlay:WAVE:BRIGhtness 50 set waveform luminance as 50
:DISPlay:WAVE:BRIGhtness? query return 50
:DISPlay:GRID:MODE
Command format：
:DISPlay:GRID:MODE { FULL | GRID | CROSS | NONE}
:DISPlay:GRID:MODE?
Functional description：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 64
Display format of grid, FULL（display grid and coordinate）、GRID（display grid）、CROSS
（display coordinate）、NONE（not display grid and coordinate）.
Return format：
Query return{ FULL | GRID | CROSS | NONE}.
For example：
:DISPlay:GRID:MODE FULL set display grid and coordinate
:DISPlay:GRID:MODE? query return FULL
:DISPlay:CLEar
Command format：
:DISPlay:CLEar
Functional description：
Empty waveform display on the screen.
:DISPlay:TYPE
UNI-T
Command format：
:DISPlay:TYPE {XY12| XY34|YT}
:DISPlay:TYPE?
Functional description：
Set the display type of time base as XY12 (X-Y method: display amplitude of channel 1 on the
horizontal axis, display amplitude of channel 2 on the vertical axis). XY34 (X-Y method: display
amplitude of channel 3 on the horizontal axis, display amplitude of channel 4 on the vertical axis).
YT (Y-T method: display the relative relationship of vertical voltage and horiziontal time).
Return format：
Query return XY12, XY34 and YT.
For example：
:DISP:TYPE YT set the time base as YT method
:DISP:TYPE? query return YT
WAVeform Command
This command is to read waveform data and relevant parameters.
:WAVeform:FORMat
Command format：
:WAVeform:FORMat { WORD |
:WAVeform:FORMat?
Functional description：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
BYTE | ASCII | CSV | DAT }
Page 65
Set return format of waveform AD data. This command is only valid for AD data.
BYTE：return 8 bits value, single byte binary data
WORD：return 16 bits valule, short type binary data
ASCII：return waveform AD data character string, single AD value turn to ASCII character string,
each data point separated by comma mark. In addition, it is conform to binary data IEEE488.2
format, for example #41234120,125,128..........\n.
CSV：return waveform AD data set of CSV file format <filed separated by comma mark, line
separated by\n >, single AD value turn to ASCII character string.
DAT： set return waveform data by built-in data format
For example：single point of AD value is 120
BYTE：return 0x78
WORD：return two bytes 0x78 and 0x00,（little end format）
ASCII：return '120' of ASCII character string
CSV：return '120' of ASCII character string by CSV standard format
Return format：
Query return { WORD |
For example：
:WAVeform:FORMat BYTE return format of waveform data is single byte mode
:WAVeform:FORMat? query return BYTE
BYTE | ASCII }.
UNI-T
:WAVeform:VOLtage:FORMat
Command format：
:WAVeform:VOLtage:FORMat { BYTE |
:WAVeform:VOLtage:FORMat?
Functional description：
Set return format of waveform point voltage data, this command is only valid for voltage data,
unit is the current channel unit.
BYTE：return float type binary data
ASCII：return waveform voltage data character string, single voltage value turn to ASCII character
string, each data separated by comma mark and it’s conform to binary data IEEE488.2 format. For
example#412342.0, 2.1, 2.3.............\n.
CSV：return waveform AD data set of CSV file format <file separated by comma mark, line
separated by\n >, single voltage value turn to ASCII character string
For example：voltage value of single point is 2.0V
BYTE：return 0x40、0x00、0x00、0x00
ASCII：return '2.0' of ASCII character string
CSV：return '2.0' of ASCII character string by
Return format：
Query return{ BYTE |
For example：
ASCII | CSV }
ASCII | CSV }
CSV standard format
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 66
:WAVeform:VOLtage:FORMat BYTE
return format of waveform data is single byte mode
:WAVeform:VOLtage:FORMat? query return BYTE
:WAVeform:SOURce
Command format：
:WAVeform:SOURce {CHANnel<n> }
:WAVeform:SOURce?
Functional description：
Set signal source of the cuurent query waveform data
Return format：
Query return{ CHANnel1 |
For example：
:WAVeform:SOURce CHAN1
set signal source of the current query waveform data as channel 1
:WAVeform:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
UNI-T
:WAVeform:POINts
Command format：
:WAVeform:POINts <points>
:WAVeform:POINts?
Functional description：
Set return waveform point, the default value is 0.
Return format：
Query return waveform point.
For example：
:WAVeform:POINts 120 set return waveform point as 120
:WAVeform:POINts? query return 120
:WAVeform:DATA?
Command format：
:WAVeform:DATA?
Functional description：
To read waveform data of the specified data source.
Return format：
Query return:WAVeform:POINts the specified quantity of waveform data, waveform data source
is related with :WAVeform:SOURc, data format is related with WAVeform:FORMat, returns data
is conform to format of binary data IEEE 488.2 # format.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 67
For example：
The execute order to obtain the specified data source the waveform data as
following,
:WAVeform:FORMat BYTE
:WAVeform:SOURce CHAN1
The return format of waveform data is AD single byte mode
Set channel 1 as singal source of query waveform data
:WAVeform:POINts 120 set return 120 waveform point
:WAVeform:DATA? acquire waveform data
:WAVeform:PREamble?
Command format：
:WAVeform:PREamble?
Functional description：
Query return the current setup parameter of system waveform.
Return format：
Query return separated by comma mark “,”
Return data format: Format,Type,Points,Count,Xinc,Xor,Xref,Yinc,Yor,Yref.
Format：BYTE (0), WORD (1), ASCII (2)
Type：NORMAL (0), PEAK (1), AVER (2), ENVelope (3), HRESolution (4)
Points：return point of waveform data
Count：average count in average sampling, other mode is 1
Xinc：the time difference between in two point of X direction of waveform data source
Xor：the relative time of trigger point
Xref：X reference
Yinc：unit voltage of Y direction
Yor：the relative position of Y direction and YREF zero position
Yref：the reference value of Y direction, the center point of screen
For example：
:WAVeform:PREamble?
return 1,0,0,1,8.000e-009,-6.000e-006,0,4.000e-002,0.000e000,100
UNI-T
:WAVeform:XINCrement?
Command format：
:WAVeform:XINCrement?
Functional description：
Query the time difference between two adjacent points in X direction of the specified waveform
data source.
Return format：
Query return time base count，unit is s.
For example：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 68
:WAV:XINC? query return 3.000e-003
:WAVeform:XORigin?
Command format：
:WAVeform:XORigin?
Functional description：
Query the time from trigger point to XREF of the specified waveform data.
Return format：
Query return time value，unit is s.
For example：
:WAV:XOR? query return 3.000e-002
:WAVeform:XREFerence?
Command format：
:WAVeform:XREFerence?
Functional description：
Query reference time baseline of X direction data point.
Return format：
Query reference time.
For example：
:WAV:XREF? query return 0
UNI-T
:WAVeform:YINCrement?
Command format：
:WAVeform:YINCrement?
Functional description：
Query unit voltage value in Y direction of the specified waveform data source.
Return format：
Query return unit voltage value in Y direction, unit is V.
For example：
:WAV:YINC? query return 2.000e000
:WAVeform:YORigin?
Command format：
:WAVeform:YORigin?
Functional description：
Query vertical offset of the specified waveform data source.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 69
Return format：
Query return offset, unit is V.
For example：
:WAV:YOR? query return 1.000e001
:WAVeform:YREFerence?
Command format：
:WAVeform:YREFerence?
Functional description：
Query reference position in Y direction, the system is fixed at half the height of the screen.
Return format：
Query return reference position.
For example：
:WAV:YREF? query return 100
UNI-T
SBUS Command
This command is to set the relevant parameter of RS232, SPI, I2C bus.
Basic attribute
:SBUS:DISPlay
Command format：
:SBUS:DISPlay { {1|ON} | {0|OFF} }
:SBUS:DISPlay?
Functional description：
The switch setting of bus encoding status.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:SBUS:DISPlay ON turn on bus encoding status to display encoding waveform
:SBUS:DISPlay? query return 1
:SBUS:MODE
Command format：
:SBUS:MODE { RS232 | I2C | SPI | CAN | USB | OFF}
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 70
:SBUS:MODE?
Functional description：
Select bus encoding mode, OFF presents encoding function is turn off.
Return format：
Query return{ RS232 | I2C | SPI | CAN | USB | OFF }.
For example：
:SBUS:MODE I2C select I2C bus encoding mode
:SBUS:MODE? query return I2C
:SBUS:BASE
Command format：
:SBUS:BASE {ASCii | BINary | HEX | DEC}
:SBUS:BASE?
Functional description：
Set display format of bus.
Return format：
Query return {ASCii | BINary | HEX | DEC}.
For example：
:SBUS:BASE BIN set display format of bus encoding as binary
:SBUS:BASE? query return BINary
UNI-T
:SBUS:EVENt
Command format：
:SBUS:EVENt { {1|ON} | {0|OFF} }
:SBUS:EVENt?
Functional description：
The switch setting of bus event.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:SBUS:EVENt ON turn on bus event
:SBUS:EVENt? query return 1
:SBUS:SQUare
Command format：
:SBUS:SQUare { {1|ON} | {0|OFF} }
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 71
:SBUS:SQUare?
Functional description：
The switch setting of pseudo square wave.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:SBUS:SQUare ON turn on pseudo square wave
:SBUS:SQUare? query return 1
:SBUS:VERTical:POSition
Command format：
:SBUS:VERTical:POSition <value>
:SBUS:VERTical:POSition?
Functional description：
Set vertical position value of bus, parameter type is integer, stepped as 6, range [-160,160]，
screen center as zero point, up to positive, down to negative.
Return format：
Query return vertical position value.
For example：
:SBUS:VERTical:POSition 10 vertical position value of bus is 10
:SBUS:VERTical:POSition? query return 10
UNI-T
:SBUS:TRIGger:SWEep
Command format：
:SBUS:TRIGger:SWEep {AUTO|NORMal}
:SBUS:TRIGger:SWEep?
Functional description：
Select the sweep mode of bus trigger.
AUTO：if there no trigger term, internal will produce trigger signal to force trigger.
NORMal：only trigger when in trigger term.
Return format：
Query return trigger sweep mode {AUTO|NORMal}.
For example：
:SBUS:TRIGger:SWEep AUTO set sweep mode of bus trigger as AUTO
:SBUS:TRIGger:SWEep? query return AUTO
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 72
:SBUS:TRIGger:COUPling
Command format：
:SBUS:TRIGger:COUPling {DC|AC|LF|HF|NOISE}
:SBUS:TRIGger:COUPling?
Functional description：
Set coupling mode of bus trigger, DC, AC, LF, HF and NOISE.
Return format：
Query return coupling mode {DC|AC|LF|HF|NOISE}.
For example：
:SBUS:TRIGger:COUPling AC set coupling mode as AC
:SBUS:TRIGger:COUPling? query return AC
RS232
UNI-T
:SBUS:RS232:BAUDrate
Command format：
:SBUS:RS232:BAUDrate <baudrate>
:SBUS:RS232:BAUDrate?
Functional description：
Set baud rate of RS232 bus encoding. Parameter is integer, range 120~5000000.
Return format：
Query return baud rate.
For example：
:SBUS:RS232:BAUDrate 500 set RS232 baud rate as 500b/s
:SBUS:RS232:BAUDrate? query return 500
:SBUS:RS232:BITorder
Command format：
:SBUS:RS232:BITorder {LSBFirst | MSBFirst}
:SBUS:RS232:BITorder?
Functional description：
Set byte order of RS232 bus encoding. LSBFirst (little-end mode), MSBFirst(big-end mode).
Return format：
Query return{LSBFirst | MSBFirst}.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 73
For example：
:SBUS:RS232:BITorder LSBF set RS232 byte order as LSB
:SBUS:RS232:BITorder? query return LSBFirst
:SBUS:RS232:SOURce
Command format：
:SBUS:RS232:SOURce { CHANnel1 |
:SBUS:RS232:SOURce?
Functional description：
Set encoding source of RS232.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:RS232:SOURce CHANnel1 set channel 1 as RS232 bus encoding source
:SBUS:RS232:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
CHANnel2 | CHANnel3 | CHANnel4 }
UNI-T
:SBUS:RS232:POLarity
Command format：
:SBUS:RS232:POLarity { POSitive | NEGative }
:SBUS:RS232:POLarity?
Functional description：
Set the polarity of RS232 bus encoding, POSitive and NEGative.
Return format：
Query return{ POSitive | NEGative }.
For example：
:SBUS:RS232:POLarity POSitive set the polarity of RS232 bus encoding as POSitive
:SBUS:RS232:POLarity? query return POSitive
:SBUS:RS232:PARity
Command format：
:SBUS:RS232:PARity {EVEN | ODD | NONE}
:SBUS:RS232:PARity?
Functional description：
Set parity of RS232 bus.
Return format：
Query return{EVEN | ODD | NONE}.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 74
For example：
:SBUS:RS232:PARity ODD et parity of RS232 bus as ODD
:SBUS:RS232:PARity? query return 6
:SBUS:RS232:DATA:BIT
Command format：
:SBUS:RS232:DATA:BIT {5 | 6 | 7 | 8 }
:SBUS:RS232:DATA:BIT?
Functional description：
Set data bit of RS232 bus.
Return format：
Query return{5 | 6 | 7 | 8 }.
For example：
:SBUS:RS232:DATA:BIT 6 set RS232 data bit as 6
:SBUS:RS232:DATA:BIT? query return 6
UNI-T
:SBUS:RS232:STOP:BIT
Command format：
:SBUS:RS232:STOP:BIT {1 | 2 }
:SBUS:RS232:STOP:BIT?
Functional description：
Set stop bit of RS232 bus.
Return format：
Query return{1 | 2 }.
For example：
:SBUS:RS232:STOP:BIT 6 set stop bit as 6
:SBUS:RS232:STOP:BIT? query return 6
:SBUS:RS232:DATA
Command format：
:SBUS:RS232:DATA <value>
:SBUS:RS232:DATA?
Functional description：
Set RS232 bus data,, parameter is character string of 0x format, range is related with setup
parameter of command SBUS:RS232:DATA:BIT, which is [0~2^databit – 1].
Return format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 75
Query return character string of 0x format of bus data.
For example：
:SBUS:RS232:DATA "0x7F" set RS232 bus data as 0x7F
:SBUS:RS232:DATA? query return 0x7F
:SBUS:RS232:QUALifier
Command format：
:SBUS:RS232:QUALifier {BEGFrame | ERRFrame | ECCError | DATA}
:SBUS:RS232:QUALifier?
Functional description：
Set RS232 bus term.
Return format：
Query return{BEGFrame|ERRFrame|ECCError|DATA}.
For example：
:SBUS:RS232:QUALifier ERRF set RS232 bus term as error frame
:SBUS:RS232:QUALifier? query return ERRFrame
UNI-T
I2C
:SBUS:I2C:CLOCk:SOURce
Command format：
:SBUS:I2C:CLOCk:SOURce { CHANnel1 |
:SBUS:I2C:CLOCk:SOURce?
Functional description：
Set clock source of I2C bus.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:I2C:CLOCk:SOURce CHANnel1 set channel 1 as I2C bus clock source
:SBUS:I2C:CLOCk:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
:SBUS:I2C:DATA:SOURce
CHANnel2 | CHANnel3 | CHANnel4 }
Command format：
:SBUS:I2C:DATA:SOURce { CHANnel1 |
:SBUS:I2C:DATA:SOURce?
Functional description：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
CHANnel2 | CHANnel3 | CHANnel4 }
Page 76
Set data source of I2C bus.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:I2C:DATA:SOURce CHANnel1 set channel 1 as I2C bus data source
:SBUS:I2C:DATA:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
:SBUS:I2C:ASIZe
Command format：
:SBUS:I2C:ASIZe {7 | 10}
:SBUS:I2C:ASIZe?
Functional description：
Set bit wide of I2C bus address.
Return format：
Query return{7 | 10}.
For example：
:SBUS:I2C:ASIZe 7 set bit wide as 7
:SBUS:I2C:ASIZe? query return 7
UNI-T
:SBUS:I2C:ADIRection
Command format：
:SBUS:I2C:ADIRection { READ | WRITE }
:SBUS:I2C:ADIRection?
Functional description：
Set direction of I2C bus address.
Return format：
Query return{ READ | WRITE }.
For example：
:SBUS:I2C:ADIRection READ et I2C bus address direction as read only
:SBUS:I2C:ADIRection? query return READ
:SBUS:I2C:ADDRess
Command format：
:SBUS:I2C:ADDRess <value>
:SBUS:I2C:ADDRess?
Functional description：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 77
Set I2C bus address, parameter is character string of 0x format, range is related with setup
parameter of command SBUS:I2C:ASIZe, which is [0~2^addressbit – 1].
Return format：
Query return character string address value of 0x format.
For example：
:SBUS:I2C:ADDRess "0x7F" I2C bus address as 0x7F
:SBUS:I2C:ADDRess? query return 0x7F
:SBUS:I2C:DATA:QUALifier
Command format：
:SBUS:I2C:DATA:QUALifier {EQUal | LESSthan | GREaterthan}
:SBUS:I2C:DATA:QUALifier?
Functional description：
Set data term of I2C bus.
Return format：
Query return{EQUal | LESSthan | GREaterthan}.
For example：
:SBUS:I2C:DATA:QUALifier EQUal set I2C bus term as EQUal
:SBUS:I2C:DATA:QUALifier? query return EQUal
UNI-T
:SBUS:I2C:DATA
Command format：
:SBUS:I2C:DATA <value>
:SBUS:I2C:DATA?
Functional description：
Set I2C bus data, parameter is character string of 0x format, data range is
0x0~0xFFFFFFFFFFFFFFFF.
Return format：
Query return data of character string of 0x format.
For example：
:SBUS:I2C:DATA "0xFFFFF" set I2C bus data as 0xFFFFF
:SBUS:I2C:DATA? query return 0xFFFFF
:SBUS:I2C:QUALifier
Command format：
:SBUS:I2C:QUALifier {STARt | RESTart | STOP | LOSS | ADDRess | DATA | ADATA}
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 78
:SBUS:I2C:QUALifier?
Functional description：
Set I2C bus term.
Return format：
Query return{STARt | RESTart | STOP | LOSS | ADDRess | DATA | ADATA}.
For example：
:SBUS:I2C:QUALifier STOP set I2C bus term as STOP
:SBUS:I2C:QUALifier? query return STOP
SPI
:SBUS:SPI:CS:SOURce
Command format：
:SBUS:SPI:CS:SOURce { CHANnel1 |
:SBUS:SPI:CS:SOURce?
Functional description：
Set chip selection source of SPI bus.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:SPI:CS:SOURce CHANnel1 set channel 1 as chip selection source
:SBUS:SPI:CS:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
CHANnel2 | CHANnel3 | CHANnel4 }
UNI-T
:SBUS:SPI:CLOCk:SOURce
Command format：
:SBUS:SPI:CLOCk:SOURce { CHANnel1 |
:SBUS:SPI:CLOCk:SOURce?
Functional description：
Set clock source of SPI bus.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:SPI:CLOCk:SOURce CHANnel1 set channel 1 as clock source of SPI bus
:SBUS:SPI:CLOCk:SOURce? query return CHANnel1
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
CHANnel2 | CHANnel3 | CHANnel4 }.
CHANnel2 | CHANnel3 | CHANnel4 }
Page 79
:SBUS:SPI:MISO:SOURce
Command format：
:SBUS:SPI:MISO:SOURce { CHANnel1 |
:SBUS:SPI:MISO:SOURce?
Functional description：
Set host computer input and slave computer output source of SPI bus.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:SPI:MISO:SOURce CHANnel1
set channel 1 as host computer input and slave computer output source of SPI bus
:SBUS:SPI:MISO:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 | OFF}.
CHANnel2 | CHANnel3 | CHANnel4 | OFF}
:SBUS:SPI:MOSI:SOURce
Command format：
:SBUS:SPI:MOSI:SOURce { CHANnel1 |
:SBUS:SPI:MOSI:SOURce?
Functional description：
Set host computer output and slave computer input source of SPI bus
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:SPI:MOSI:SOURce CHANnel1
set channel 1 as host computer output and slave computer input source of SPI bus
:SBUS:SPI:MOSI:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 | OFF}。
CHANnel2 | CHANnel3 | CHANnel4 | OFF}
UNI-T
:SBUS:SPI:BITorder
Command format：
:SBUS:SPI:BITorder {LSBFirst | MSBFirst}
:SBUS:SPI:BITorder?
Functional description：
Set encoding byte order of SPI bus, LSBFirst(little-end mode), MSBFirst(big-end mode).
Return format：
Query return {LSBFirst | MSBFirst}.
For example：
:SBUS:SPI:BITorder LSBF set byte order as LSB
:SBUS:SPI:BITorder? query return LSBFirst
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 80
:SBUS:SPI:CS:POLarity
Command format：
:SBUS:SPI:CS:POLarity {NEGative | POSitive}
:SBUS:SPI:CS:POLarity?
Functional description：
Set the polarity of SPI bus chip selection, POSitive and NEGative.
Return format：
Query return{NEGative | POSitive}.
For example：
:SBUS:SPI:CS:POLarity POSitive set the polarity of SPI bus chip selection as POSitive
:SBUS:SPI:CS:POLarity? query return POSitive
:SBUS:SPI:CLOCk:POLarity
UNI-T
Command format：
:SBUS:SPI:CLOCk:POLarity {NEGative | POSitive}
:SBUS:SPI:CLOCk:POLarity?
Functional description：
Set the clock polarity of SPI bus, POSitive and NEGative.
Return format：
Query return{NEGative | POSitive}.
For example：
:SBUS:SPI:CLOCk:POLarity POSitive set the clock polarity of SPI bus as POSitive
:SBUS:SPI:CLOCk:POLarity? query return POSitive
:SBUS:SPI:MISO:POLarity
Command format：
:SBUS:SPI:MISO:POLarity {NEGative | POSitive}
:SBUS:SPI:MISO:POLarity?
Functional description：
Set the polarity of host computer input slave computer output source of SPI bus, POSitive and
NEGative.
Return format：
Query return{NEGative | POSitive}.
For example：
:SBUS:SPI:MISO:POLarity POSitive
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 81
the polarity of host computer input slave computer output source as POSitive
:SBUS:SPI:MISO:POLarity? query return POSitive
:SBUS:SPI:MOSI:POLarity
Command format：
:SBUS:SPI:MOSI:POLarity {NEGative | POSitive}
:SBUS:SPI:MOSI:POLarity?
Functional description：
Set host computer output slave computer input polarity of SPI bus, POSitive and NEGative.
Return format：
Query return{NEGative | POSitive}.
For example：
:SBUS:SPI:MOSI:POLarity POSitive set the polarity as POSitive
:SBUS:SPI:MOSI:POLarity? query return POSitive
UNI-T
:SBUS:SPI:WIDTh
Command format：
:SBUS:SPI:WIDTh {4 | 8 | 12 | 16}
:SBUS:SPI:WIDTh?
Functional description：
Set bit wide of SPI bus data.
Return format：
Query return{4 | 8 | 12 | 16}.
For example：
:SBUS:SPI:WIDTh 4 set bit wide as 4
:SBUS:SPI:WIDTh? query return 4
:SBUS:SPI:TRIGger:TYPE
Command format：
:SBUS:SPI:TRIGger:TYPE {MOSI | MISO | ANY}
:SBUS:SPI:TRIGger:TYPE?
Functional description：
Set trigger mode of SPI bus, MOSI（host computer output slave computer input）. MISO（host
computer input slave computer input）and ANY.
Return format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 82
Query return{MOSI | MISO | ANY}。
For example：
:SBUS:SPI:TRIGger:TYPE MOSI set trigger mode of SPI bus as MOSI
:SBUS:SPI:TRIGger:TYPE? query return MOSI
:SBUS:SPI:TRIGger:TIMeout
Command format：
:SBUS:SPI:TRIGger:TIMeout <vlaue>
:SBUS:SPI:TRIGger:TIMeout?
Functional description：
Set timeout of SPI bus trigger, parameter type is integer.
<vlaue> equal to n * 4ns and value not exceed range [100ns,1s) .n range [25,25*10^8].
Return format：
Query return timeout value of trigger by scientific notation method，unit is s.
For example：
:SBUS:SPI:TRIGger:TIMeout 100ns set timeout of SPI bus trigger as 100ns
:SBUS:SPI:TRIGger:TIMeout? query return 1.000e-007
UNI-T
:SBUS:SPI:DATA
Command format：
:SBUS:SPI:DATA <value>
:SBUS:SPI:DATA?
Functional description：
Set SPI bus data, parameter is character string of 0x format，data range
0x0~0xFFFFFFFFFFFFFFFF.
Return format：
Query return data of character string of 0x format.
For example：
:SBUS:SPI:DATA "0xFFFFF" set SPI bus data as 0xFFFFF
:SBUS:SPI:DATA? query return 0xFFFFF
:SBUS:SPI:QUALifier
Command format：
:SBUS:SPI:QUALifier {CS | CS&MOSI | CS&MISO | CS&ANY |
IDLE&MISO | IDLE&ANY}
:SBUS:SPI:QUALifier?
IDLE | IDLE&MOSI |
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 83
Functional description：
Set SPI bus term.
Return format：
Query return{CS | CS&MOSI | CS&MISO | CS&ANY |
IDLE&ANY}.
For example：
:SBUS:SPI:QUALifier CS set I2C bus term as CS
:SBUS:SPI:QUALifier? query return CS
IDLE | IDLE&MOSI | IDLE&MISO |
:SBUS:SPI:FRAMelen
Command format：
:SBUS:SPI:
:SBUS:SPI:
Functional description：
Set frame length of SPI bus data.
Return format：
Query return<len>.
For example：
:SBUS:SPI:
:SBUS:SPI:
FRAMelen <len>
FRAMelen?
FRAMelen 1 set frame length of SPI bus data as 1
FRAMelen? query return 1
UNI-T
CAN
:SBUS:CAN:POSitive:SOURce
Command format：
:SBUS:CAN:POSitive:SOURce { CHANnel1 |
:SBUS:CAN:POSitive:SOURce?
Functional description：
Set input positive source of CAN bus.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:CAN:POSitive:SOURce CHANnel1 set channel 1 as CAN bus positive source
:SBUS:CAN:POSitive:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
CHANnel2 | CHANnel3 | CHANnel4 }
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 84
:SBUS:CAN:NEGative:SOURce
Command format：
:SBUS:CAN:NEGative:SOURce { CHANnel1 |
:SBUS:CAN:NEGative:SOURce?
Functional description：
Set input negative source of CAN bus
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:CAN:NEGative:SOURce CHANnel1 set channel 1 as CAN bus negative source
:SBUS:CAN:NEGative:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
CHANnel2 | CHANnel3 | CHANnel4 }
:SBUS:CAN:SIGNal:DEFinition
UNI-T
Command format：
:SBUS:CAN:SIGNal:DEFinition { CANH | CANL | RXTX | DIFFerential }
:SBUS:CAN:SIGNal:DEFinition?
Functional description：
Set signal mode of CAN bus.
Return format：
Query return{ CANH | CANL | RXTX | DIFFerential }.
For example：
:SBUS:CAN:SIGNal:DEFinition CANH set CANH as the signal of CAN bus
:SBUS:CAN:SIGNal:DEFinition? query return CANH
:SBUS:CAN:SAMPlepoint
Command format：
:SBUS:CAN:SAMPlepoint <percent>
:SBUS:CAN:SAMPlepoint?
Functional description：
Set the sampling percentage of CAN bus signal, <percent> range 1~99.
Return format：
Query return sampling percentage.
For example：
:SBUS:CAN:SAMPlepoint 30 sampling percentage as 30%
:SBUS:CAN:SAMPlepoint? query return 30
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 85
:SBUS:CAN:SIGNal:BAUDrate
Command format：
:SBUS:CAN:SIGNal:BAUDrate <baudrate>
:SBUS:CAN:SIGNal:BAUDrate?
Functional description：
Set the baud rate of CAN bus signal, <baudrate> range 10000~1000000, unit is bps.
Return format：
Query return the baud rate of signal.
For example：
:SBUS:CAN:SIGNal:BAUDrate 100000 set the baud rate as 100kbps
:SBUS:CAN:SIGNal:BAUDrate? query return 100000
:SBUS:CAN:QUALifier
UNI-T
Command format：
:SBUS:CAN:QUALifier {START |TYPE |ID | DATA | ACKerror | BITFILL | IDDATA | END}
:SBUS:CAN:QUALifier?
Functional description：
Set the the trigger term of CAN bus.
Return format：
Query return{START | TYPE | ID | DATA | ACKerror | BITFILL | IDDATA | END}.
For example：
:SBUS:SPI:QUALifier ACK set the trigger term as ACKerror
:SBUS:SPI:QUALifier? query return ACKerror
:SBUS:CAN:FRAMe:TYPE
Command format：
:SBUS:CAN:FRAMe:TYPE { DATA | REMote | OVERload | ERRor }
:SBUS:CAN:FRAMe:TYPE?
Functional description：
Set the trigger frame mode of CAN bus.
Return format：
Query return{ DATA | REMote | OVERload | ERRor }.
For example：
:SBUS:CAN:FRAMe:TYPE ERRor set CAN bus trigger mode as ERRor
:SBUS:CAN:FRAMe:TYPE? query return ERRor
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 86
:SBUS:CAN:ID:MODE
Command format：
:SBUS:CAN:ID:MODE {STANdard | EXTended}
:SBUS:CAN:ID:MODE?
Functional description：
Set ID frame format of CAN bus.
Return format：
Query return{STANdard | EXTended}。
For example：
:SBUS:CAN:ID:MODE STANdard set ID frame format as standars frame
:SBUS:CAN:ID:MODE? query return STANdard
:SBUS:CAN:ID:STANdard
UNI-T
Command format：
:SBUS:CAN:ID:STANdard <string>
:SBUS:CAN:ID:STANdard?
Functional description：
Set ID standard frame data of CAN bus, parameter is character string of 0x format. Standard
frame range 0x0~0xFFF.
Return format：
Query return character string of 0x format.
For example：
:SBUS:CAN:ID:STANdard "0xFFF" set ID standard frame data as 0xFFF
:SBUS:CAN:ID:STANdard? query return 0xFFF
:SBUS:CAN:ID:EXTend
Command format：
:SBUS:CAN:ID:EXTend <string>
:SBUS:CAN:ID:EXTend?
Functional description：
Set ID expand frame data of CAN bus, parameter is character string of 0x format. Expand frame
range 0x0~0xFFFFF.
Return format：
Query return character string of 0x format.
For example：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 87
:SBUS:CAN:ID:EXTend "0xFFFFF" set ID expand frame data as 0xFFFFF
:SBUS:CAN:ID:EXTend? query return 0xFFFFF
:SBUS:CAN:ID:DIRection
Command format：
:SBUS:CAN:ID:DIRection { READ | WRITE | ANY}
:SBUS:CAN:ID:DIRection?
Functional description：
Set ID direction of CAN bus.
Return format：
Query return{ READ | WRITE | ANY}.
For example：
:SBUS:CAN:ID:DIRection READ set ID direction as read only
:SBUS:CAN:ID:DIRection? query return READ
UNI-T
:SBUS:CAN:DATA:QUALifier
Command format：
:SBUS:CAN:DATA:QUALifier {EQUal|LESSthan|GREaterthan|NEQUal|LEQUal|GEQUal}
:SBUS:CAN:DATA:QUALifier?
Functional description：
Set compare term of CAN bus DATA.
Return format：
Query return{EQUal | LESSthan | GREaterthan | NEQUal | LEQUal | GEQUal}.
For example：
:SBUS:CAN:DATA:QUALifier EQUal set compare term as EQUal
:SBUS:CAN:DATA:QUALifier? query return EQUal
:SBUS:CAN:DATA
Command format：
:SBUS:CAN:DATA <string>
:SBUS:CAN:DATA?
Functional description：
Set DATA of CAN bus, parameter is character string of 0x format, data range
0x0~0xFFFFFFFFFFFFFFFF.
Return format：
Query return character string of 0x format.
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 88
For example：
:SBUS:CAN:ID "0xFFFFF" set DATA as 0xFFFFF
:SBUS:CAN:ID? query return 0xFFFFF
USB
:SBUS:USB:POSitive:SOURce
Command format：
:SBUS:USB:POSitive:SOURce { CHANnel1 |
:SBUS:USB:POSitive:SOURce?
Functional description：
Set input positive source of USB bus.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:USB:POSitive:SOURce CHANnel1 set channel 1 as positive source of USB bus
:SBUS:USB:POSitive:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
CHANnel2 | CHANnel3 | CHANnel4 }
UNI-T
:SBUS:USB:NEGative:SOURce
Command format：
:SBUS:USB:NEGative:SOURce { CHANnel1 |
:SBUS:USB:NEGative:SOURce?
Functional description：
Set input negative source of USB bus.
Return format：
Query return{ CHANnel1 |
For example：
:SBUS:USB:NEGative:SOURce CHANnel1 set channel 1 as negative source of USB bus
:SBUS:USB:NEGative:SOURce? query return CHANnel1
CHANnel2 | CHANnel3 | CHANnel4 }.
CHANnel2 | CHANnel3 | CHANnel4 }
:SBUS:USB:SPEED
Command format：
:SBUS:USB:SPEED { LOW | FULL}
:SBUS:USB:SPEED?
Functional description：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 89
Set speed of USB bus.
Return format：
Query return{ LOW | FULL}.
For example：
:SBUS:USB:SPEED LOW set speed as LOW
:SBUS:USB:SPEED? query return LOW
:SBUS:USB:QUALifier
Command format：
:SBUS:USB:QUALifier {SYNC|RESET|PAUSE|RESUME|END|TOKEN|HANDSHAKE|
DATA| ERRor }
:SBUS:USB:QUALifier?
Functional description：
Set trigger term of USB bus.
Return format：
Query return{SYNC|RESET|PAUSE|RESUME|END|TOKEN|HANDSHAKE|DATA| ERRor }.
For example：
:SBUS:USB:QUALifier ERRor set trigger term as errot frame
:SBUS:USB:QUALifier? query return ERRor
UNI-T
:SBUS:USB:TOKEN:TYPE
Command format：
:SBUS:USB:TOKEN:TYPE { ANY | OUT | IN | SOF | SETUP}
:SBUS:USB:TOKEN:TYPE?
Functional description：
Set token mode of USB.
Return format：
Query return{ ANY | OUT | IN | SOF | SETUP}.
For example：
:SBUS:USB:TOKEN:TYPE ANY set USB toke mode as ANY
:SBUS:USB:TOKEN:TYPE? query return ANY
:SBUS:USB:TOKEN:ENDPoint
Command format：
:SBUS:USB:TOKEN:ENDPoint <point>
:SBUS:USB:TOKEN:ENDPoint?
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 90
Functional description：
Set endpoint number of USB token pack, range 0~15.
Return format：
Query return token endpoint number.
For example：
:SBUS:USB:TOKEN:ENDPoint 10 set endpoint number as 10
:SBUS:USB:TOKEN:ENDPoint? query return 10
:SBUS:USB:TOKEN:QUALifier
Command format：
:SBUS:USB:TOKEN:QUALifier {EQUal|LESSthan|GREaterthan|NEQUal|LEQUal|GEQUal|
INRange|OUTRange}
:SBUS:USB:TOKEN:QUALifier?
Functional description：
Set trigger term of USB token pack.
Return format：
Query return{EQUal|LESSthan|GREaterthan|NEQUal|LEQUal|GEQUal|INRange|OUTRange}.
For example：
:SBUS:USB:TOKEN:QUALifier EQUal set trigger term as EQUal
:SBUS:USB:TOKEN:QUALifier? query return EQUal
UNI-T
:SBUS:USB:TOKEN:ADDRess
Command format：
:SBUS:USB:TOKEN:ADDRess <string>
:SBUS:USB:TOKEN:ADDRess?
Functional description：
Set address of USB token pack, parameter is character string of 0x format. Data range
0x00~0x7F.
Return format：
Query return character string of 0x format.
For example：
:SBUS:USB:TOKEN:ADDRess "0x5F" set address of USB toke packe as 0x5F
:SBUS:USB:TOKEN:ADDRess? query return 0x5F
:SBUS:USB:TOKEN:FRAMenum
Command format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 91
:SBUS:USB:TOKEN:FRAMenum <number>
:SBUS:USB:TOKEN:FRAMenum?
Functional description：
Set frame of SOF token pack of USB.
Return format：
Query return frame of SOF token pack.
For example：
:SBUS:USB:TOKEN:FRAMenum 20 set frame of SOF token pack as 20
:SBUS:USB:TOKEN:FRAMenum? query return 20
:SBUS:USB:HAND:TYPE
Command format：
:SBUS:USB:HAND:TYPE {ANY | STALL | ACK | NAK}
:SBUS:USB:HAND:TYPE?
Functional description：
Set handshake pack mode of USB.
Return format：
Query return{ANY | STALL | ACK | NAK}.
For example：
:SBUS:USB:HAND:TYPE ANY set handshake pack mode as ANY
:SBUS:USB:HAND:TYPE? query return ANY
UNI-T
:SBUS:USB:DATA:TYPE
Command format：
:SBUS:USB:DATA:TYPE {ANY | DATA0 | DATA1}
:SBUS:USB:DATA:TYPE?
Functional description：
Set data pack mode of USB.
Return format：
Query return{ANY | DATA0 | DATA1}.
For example：
:SBUS:USB:DATA:TYPE ANY set data pack mode as ANY
:SBUS:USB:DATA:TYPE? query return ANY
:SBUS:USB:DATA:QUALifier
Command format：
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 92
:SBUS:USB:DATA:QUALifier {EQUal|LESSthan|GREaterthan|NEQUal|LEQUal|GEQUal|
INRange|OUTRange}
:SBUS:USB:DATA:QUALifier?
Functional description：
Set trigger term of USB data pack.
Return format：
Query return{EQUal|LESSthan|GREaterthan|NEQUal|LEQUal|GEQUal|INRange|OUTRange}.
For example：
:SBUS:USB:DATA:QUALifier EQUal set trigger term as EQUal
:SBUS:USB:DATA:QUALifier? query return EQUal
:SBUS:USB:DATA:OFFSet
Command format：
:SBUS:USB:DATA:OFFSet <offset>
:SBUS:USB:DATA:OFFSet?
Functional description：
Set offset byte of USB data pack, <offset> is integer data, range 0~15.
Return format：
Query return offset of USB data pack.
For example：
:SBUS:USB:DATA:OFFSet 2 set offset byte as 2
:SBUS:USB:DATA:OFFSet? query return 2
UNI-T
:SBUS:USB:DATA:LOW
Command format：
:SBUS:USB:DATA:LOW <string>
:SBUS:USB:DATA:LOW?
Functional description：
Set low trigger data of USB data pack, parameter is character string of 0x format, data range
0x0~0xFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF.
Return format：
Query return character string of 0x format.
For example：
:SBUS:USB:DATA:LOW "0x5F" set negative data of USB signal line as 0x5F
:SBUS:USB:DATA:LOW? query return 0x5F
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 93
:SBUS:USB:DATA:HIGH
Command format：
:SBUS:USB:DATA:HIGH <string>
:SBUS:USB:DATA:HIGH?
Functional description：
Set high trigger data of USB data pack, parameter is character string of 0x format, data range
0x0~0xFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF.
Return format：
Query return character string of 0x format.
For example：
:SBUS:USB:DATA:HIGH "0x5F" set positive data of USB signal line as 0x5F
:SBUS:USB:DATA:HIGH? query return 0x5F
:SBUS:USB:ERRor:TYPE
UNI-T
Command format：
:SBUS:USB:ERRor:TYPE {PID | TOKEN | DATA | BITFILL}
:SBUS:USB:ERRor:TYPE?
Functional description：
Set error mode of USB.
Return format：
Query return{PID | TOKEN | DATA | BITFILL}.
For example：
:SBUS:USB:ERRor:TYPE PID set error mode as PID
:SBUS:USB:ERRor:TYPE? query return PID
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Page 94
Appendix 1：<Key> Table
Key Functional Description LED
AUTO Auto setting to display waveform
RS Control the operating status of oscilloscope, continuous to send the
command, oscilloscope will switch between stop and run status
TMENu Trigger menu
SINGle Single trigger √
TFORe Force trigger
HELP Help system
HMENu Horizontal system menu
DISPlay Display menu
MATH mathematical operation function and meue √
REF Reference waveform function and menu √
CH1 The switch of channel 1 √
CH2 The switch of channel 2 √
CH3 The switch of channel 3 √
CH4 The switch of channel 4 √
F1 Select the first menu item
F2 Select the second menu item
F3 Select the third menu item
F4 Select the fourth menu item
F5 Select the fifth menu item
MENu Menu display function
PSCReen One-button print or One-button save screen image
MEASure Measurement function
CURSor Cursor measurement function and menu
ACQuire Sampling menu
STORage Storage menu
UTILity Secondary system help menu
CLEar Clear display waveform
DECode Decode menu
DEFault Recovery default setting
FKNob Multifunction knob
FKNLeft Multifunction left knob
FKNRight Multifunction right knob
VPKNob Vertical postion knob
VPKNLeft Vertical postion left knob
VPKNRight Vertical postion right knob
UNI-T
√
UPO 3000E&UPO2000E Series Oscilloscope Programming Manual
Loading...
