UNIQVOICE

Bluetooth Speaker
USER GUIDE

For correctly operang, please read this User Guide carefully before
using. Any content revise of the manual won’t declare again and we
are not responsible for consequences caused by fault or oversight of
this manual.

Features

1. 2.1 channel portable Bluetooth Speaker with 8 inch subwoofer;

2. O u t p u t v e r y c l e a r s o u n d a n d h e a v y b a s s , d y n a m i c s o u n d e  e c t ;

3. Features A2DP Bluetooth: wireless stream music from any Bluetooth­enabled device;

4. Secure simple pairing for user-friendly operaon;

5. 10 meters operang range;

6. USB and SD card inputs;

7. FM radio;

8. With2 Microphone input;

9. W i t h L i n e - i n f u n c  o n , s u i t a b l e f o r P C , M I D ,T V a n d o t h e r a u d i o d e v i c e s ;

10. Side panel control for volume and bass;

11. Built-in lithium rechargeable baery 4400mAh;

Specification

Product size: Φ 306*428(L)mm
Horn Size: 4 inch
Subwoofer Size: 8 inch
Horn output: 9.5W*2,4Ω
Subwoofer output: 38W,4Ω
Baery Capacity: 4400mAh
Frequency Response: 100-20Khz
Power supply: DC5V
USB/SD support: MAXIMUM 32GB

Control Panel

1. Mic input 1

2. Mic input 2

3. Backward

4. Play/Pause

5. Mode (Switch Bluetooth, USB disk,
SD, FM and AUX-IN state)

6. USB port

7. AUX-in jack

8. Charging jack

9. Mic volume knob

10. Mic Echo knob

11. Bass knob

12. Volume knob

13. LED display

14. On/O buon

15. SD slot

16. Forward

Playing music

1. Turn the Power buon to “ON”

2. Insert SD/MMC card or USB ash disk into slot, audio les play
automacally.

3. Under playing mode, short PREV or NEXT to select songs you like,
long press to fast forward or backward the song.

4. Spin VOL knob to adjust the volume up or down. Spin Bass-vol knob
to adjust the bass volume

5. Press PLAY/PAUSE to play or pause.

6. For other compable music devices or your MP3/MP4 players, use
the supplied audio cable to connect from the device’s “Line Out”
to the “Aux In” of this device. When using an external device, all
funcons will be controlled by the external device.

7. Please turn the Power buon to “OFF” while not using.

Bluetooth function

1. Turn the power buon to “ON”, The LED screen will display bt and
beep twice, twinkling quickly.

2. Acvate Bluetooth of mobile phone and search for device name
“Uniqvoice” then connect it. The bt on the screen stop twinkling and
beep three mes once connected successful.

3. Play the music from your mobile phone and enjoy.

4. Press PREV or NEXT buon on the devices or on Mobile phones to
select songs you like.

5. Press Play/pause buon on the devices or on Mobile phones to play/
stop the music

6. Use the “Volume “to adjust volume up and down. Or adjust the
mobile phones’ volume.

7. Use the “Bass knob” to adjust bass.

FM Radio

1. Under FM radio state, the audio cable provided treat as antenna.
Please insert the audio cable to get best FM signal before using.

2. Turn the power buon to “ON” without SD or USB Card inserted.
Then press the “MODE” buon to switch to FM.(The order of the
mode is Bluetooth, SD,USB,FM and AUX-IN)

3. Under playing mode, short press “Play/pause” buon to auto search
the FM Channel and store it automacally.

4. Press LAST or NEXT buon to change the stored FM channel.

AUX-IN

For other compable music devices or your MP3/MP4 players, use the
supplied audio cable to connect from the device’s “Line Out” to the “Aux In”
of this devices. Then press the “MODE” buon to switch to AUX-IN state.
Enjoy…
When using an external device, all funcons will be controlled by the
external devise except the volume adjusng..

wired or Wireless Microphones

Just plug the 6.5mm microphone into either one of the microphone inputs.
Or turn your wireless microphone included with speaker to “ON”. Wired
and wireless microphones can work together. The Microphone Volume and
Microphone Echo can be adjusted by the “MIC-VOL” and “MIC-ECHO” knobs.
(Please note that a microphone cannot be used while in FM radio mode)

Charging

1. Put the provided charge cable into the charging jack, connect the
other end to the provided adapter,the charging indicator beside the
LED screen will keep lighng.

2. (When playing music during charging, please put the volume to
middle,because for some music with heavy bass, the adapter may can
not aord the high current temporarily under the maximum volume)

3. Charge me should be 4-6 hours. When charging full, the indicator
light will switch o.

4. To prolong the life of baery, DO NOT CHARGE CONTINUOUSLY FOR
LONGER THAN 8 HOURS.

Accessories

Adapter, charging cable, audio cable, 1 wireless microphone, 1 wired
microphone, USER GUIDE
