User Guide
16-Port Gigabit +4G UTP+2G SFP PoE Switch with LCD Display
- 1 -
Package Contents
Check the following contents of your package:
PoE Switch x 1
User Guide x1
Power Cord x1
Accessories(Rack Mount Accessory Kit*2 ,Rubber Feet*4, screw*8)
If any part is lost and damaged, please contact your local agent immediately.
Introduction
16-Port Gigabit +4G UTP+2G SFP PoE switch is 16-port 10/100/1000Mbps PoE RJ45 and 4*10/100/1000 RJ45 Uplink Port
with 2 Gigabit SFP Slots. The PoE ports can automatically detect and supply power to IEEE802.3af/at compliant Powered
Devices (PD). The electrical power and data transmission on the same cable can expand your network to the places where
no power lines or outlets, where you can install devices such as APs, IP cameras, or IP phones etc.
The PoE Switch provides a simple, cost effective, and non-blocking wire-speed performance with 19-inch metal shape for
rack deployment in office or department network application.
Hardware Description
Front Panel
The Front Panel Consists of Ethernet Ports. The LCD and LED indicators are also located on the panel.
PoE Status
The PoE Switch is with the function of the LCD display and PoE. The LCD can display the working condition of PoE port not
only, still can accurately show the state of each port, such as: Output power, Overload, Short circuit, Light load, Low voltage,
Over voltage,High temperature, and so on...
- 2 -
LED indicator
LED
Color
Function
PWR
Green
Off: No Power supply.
Light: Indicates the switch has power.
LNK/ACT
Red
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully
established at 10/100Mbps.
Blink: Indicates that the Switch is actively sending or
receiving data over that port.
Green
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully
established at 1000Mbps.
Blink: Indicates that the Switch is actively sending or
receiving data over that port.
PoE
Orange
Off: No PoE powered device (PD) connected.
Light: There is a PoE PD connected to be port, which
supply power successfully.
Blink: Indicates port abnormal power supply.
DIP Switch
The DIP switch located on the left panel.
Standard the factory default mode, can normal communication between port 1~22.
VLAN: 1-16 port can be isolated each other but 1-16 port can connect to 17~22 port after open VLAN to stop broadcast
storm to increase forwarding rate of frame.
Extend: Up to 250m PoE distance allows you to expand you network via Ethernet cable to where there is no power line or
outlet but where you want to fix device such as IP Cameras.
Rear Panel
The rear panel of the PoE Switch indicates an AC inlet power socket, which accepts input power from 100 to 240V AC,
50/60HZ.
- 3 -
Power socket
Connect the female connector of the power cord here, and the male connector to the AC(Alternating Current) power
outlet. Please make sure the voltage of the power supply meets the requirement of the input voltage
Grounding column
The switch already comes with lightning protection mechanism. You can also ground the switch through the PE (Protecting
Earth) cable of AC cord or with Ground Cable.
Installation the Switch
This part describes how to install your Ethernet Switch and make connections to it. Please follow the following instructions
in avoid of incorrect installation causing device damage and security threat.
Before cleaning the switch, unplug the power plug of the switch first. Do not clean the switch with wet cloth or liquid;
Do not place the switch near water or any damp area. Prevent water or moisture from entering the switch chassis;
Do not place the switch on an unstable case or desk. The switch might be damaged severely in case of a fall;
Ensure proper ventilation of the equipment room and keep the ventilation vents of the switch free of obstruction;
Make sure that the operating voltage is the same one labeled on the switch;
Do not open the chassis while the switch is operating or when electrical hazards are present to avoid electrical shocks.
Desktop Installation
Install the Switch on a desktop, please attach these cushioning rubber feet provided on the bottom at each corner of the
Switch in case of the external vibration. Allow adequate space for ventilation between the device and the objects around it.
Rack-mountable Installation
The switch is rack-mountable and can be installed on an EIA-19 inch equipment rack. To do this, first, please install the
mounting brackets on the switch’s side panels (one on each side), secure them with the included screws, and then use the
screws provided with the equipment rack to mount the switch on the 19 inch rack.
- 4 -
Turn on the switch
Please connect the AC power cord into the rear of the switch and to an electrical outlet (preferably one that is grounded ).
When the switch is power on, the LED indicators flash momentarily for one second, which represents a resetting of the
system.The Power LED indicator turns on green.
Note: Please confirm the voltage is correct before power on, otherwise the switch will be damaged.
(The power input is:100V-240Vac, 50/60Hz.)
- 5 -
Specifications
Standard
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3az, IEEE802.3x
IEEE802.3af, IEEE802.3at
Network Media
10BASE-T: UTP category 3,4,5 cable (≤100m)
100BASE-TX: UTP category 5 cable (≤100m)
1000BASE-T: UTP category 5e cable (≤100m)
1000BASE-X: MMF, SMF
MAC Address Table
8K, Auto-learning, Auto-aging
Transfer mode
Store-and-Forward
Frame Forward Rate
10Base-T: 14881pps/Port
100Base-TX: 148810pps/Port
1000Base-T/X: 1488095pps/Port
Switching Capacity
44G
Dimensions (L*W*H)
440 *232 *45 mm
Fan Quantity
2
Power Input
AC: 100~240V, 50/60Hz
PoE Port
Port1~16
PoE Power on RJ45
Mode A 1/2(+),3/6(-)
PoE Power Output
Voltage: 55V DC Power: 32W(Max)
PoE Power Budget
300W
Temperature
Operating Temperature: 0°C ~ 40 °C (32 °F ~104°F )
Storage Temperature: -40 °C ~ 70 °C (-40 °F ~158°F )
Humidity
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
