Page 1
ASSEMBLY INSTRUCTIONS
REVISION 0 : 04/20/2017
REVISION 1 : 07/16/2019
REVISION 2 : 12/16/2019
PAGE 1 OF 13
950724
TALL CABINET
COASTERFURNITURE.COM
Page 2
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
ASSEMBLY TIME
A
B
C BOTTOM PANEL
LEFT SIDE
PAN EL
RIGHT SIDE
PAN EL
50 MINUTES
PARTS IDENTIFICATION
1 PC
1 PC
1 PC
G TOP PANEL 1 PC
H DOOR 2 PCS
UPPER BACK
I
PAN EL
3 PCS
LOWER CROSS
D
E BACK BRACE
F
PAN EL
ADJUSTABLE
SHELF
1 PC
1 PC
2 PCS
J
K
L
DRAWER
FRONT PANEL
DRAWER BACK
PAN EL
LEFT DRAWER
SIDE PANEL
2 PCS
2 PCS
2 PCS
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
PAGE 2 OF 13
Page 3
RIGHT DRAWER
M
SIDE PANEL
2 PCS
O
DRAWER
BOTTOM PANEL
2 PCS
N
Z
DRAWER
SUPPORT
2 PCS
HARDWARE IDENTIFICATION
NO DESCRIPTION FIGURE Q’TY
1 GLUE 40g 1 PC
WOODEN DOWEL
2
3
4
CA M BO LT
Ø 7x35.5mm
CAM LOCK
Ø 15x12mm
Ø 8x30mm
24 PCS
14 PCS
14 PCS
DOWN BACK
P
PAN EL
1 PC
NO DESCRIPTION FIGURE Q’TY
11 HANDLE 4 PCS
12 HANDLE BOLT
4 PCS
13 HINGE 6 PCS
14
HINGE SCREW
Ø 4x15mm
24 PCS
5
6
7
BOLT
Ø 9.5x55mm
DRAWER SCREW
Ø 4.3x35mm
PIN
Ø 4.9x8mm
8 DOOR CATCH
9
10
GLIDES
L = 350mm
GLIDES SCREW
Ø 3x12mm
CL
CR
DL
DR
8 PCS
10 PCS
8 PCS
2 PCS
2 SET
24 PCS
15 FOOT 4 PCS
16
FO OT B OLT
M6x42mm
17 FIXER
18
19
20
FIXER SCREW
Ø 3x19mm
PLASTIC BACK
BRACE
STICKER
Ø 20mm
Z9,Z11,Z12,Z13,Z15,Z19 not included in blister packaging.
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
4 PCS
6 PCS
6 PCS
1 PC
3 PCS
PAGE 3 OF 13
Page 4
STEP 1
3
10
x 12
CL
2
9 x 2
CR
B
9 (CR)
3
INCORRECT
CORRECT
A
Apply glue on all wooden dowels to
ensure integrity of the structure.
9 (CL)
10
10
2
9 (CL)
(CR)
PAGE 4 OF 13
Page 5
STEP 2
E
Apply glue on all wooden dowels to
ensure integrity of the structure.
2
x 8
8
x 2
G
8
D
2
STEP 3
Apply glue on all wooden dowels to
ensure integrity of the structure.
4
E
1
D
x 4
20
x 4
4
4
A
PAGE 5 OF 13
20
Page 6
STEP 4
Apply glue on all wooden dowels to
ensure integrity of the structure.
4
x 4
20
x 4
B
1
I
E
4
D
STEP 5
16
15
C
14
13
12
11
x 2
14
x 12
H x2
12
x 2
15
13
x 6
16
x 4x 4
PAGE 6 OF 13
11
Page 7
STEP 6
Apply glue on all wooden dowels to
ensure integrity of the structure.
5
x 4
A
B
1
5
P
C
STEP 7
5
G
5
1
x 4
x 1
19
20
x 4
Apply glue on all wooden dowels to
ensure integrity of the structure.
B
I
19
I
A
20
PAGE 7 OF 13
Page 8
STEP 8
7
x 8
F
F
7
STEP 9
14
H
14
x 12
(B)
(C)
(A)
(A)
H
(B)
(C)
PAGE 8 OF 13
Page 9
STEP 10-1
J x2
3
x 6
STEP 10-2
K
M
O
L x2
M x2
STEP10-3
2 x8
6 x10
1
J
Apply glue on all wooden dowels to
ensure integrity of the structure.
STEP 10-4
N
L
11 x2
12 x2
4 x6
20 x6
STEP10-5
(DL)
9
9
10 x12
(DR)
10
9 (DL)
(DR)
PAGE 9 OF 13
Page 10
STEP 11
J
STEP 12
J
17
x 6
I
17
18
17
18
18
x 6
P
PAGE 10 OF 13
Page 11
STEP 13
COMPLETE
PAGE 11 OF 13
Page 12
395mm(15.5")
405mm(15.75")
726mm(28.5")
401mm(15.75")
420mm(16.5")
792mm(31")
1256mm
(49.25")
350mm(13.75")
1836mm(72.25")
198mm(7.75")
381mm(15")
96mm(3.75")
130mm(5")
671mm(26.25")
334mm(13")
721mm(28.25")
Note : Dimension tolerance ±5%
PAGE 12 OF 13
Page 13
ANTI-TIPPING INSTALLMENT INSTRUCTIONS
FURNITURE TIPPING RESTRAINT
WARNING
Injury may result from tipping furniture.
This restraint may protect against tipping furniture.
Do not allow children to climb on furniture.
This restraint is not a substitute for proper adult supervision.
Failure to detach this restraint before moving the furniture
may result in injury and damage.
1. To attach the anti-tip strap, securely mount one end to the top of the case piece with
the 5/8” screw.
2. Position the case piece against the wall in the desired location.
3. Pull the anti-tip strap taut and mark the position of where you will secure the other end
on the wall.
4. Drill a 1-1/4” hole in the spot you marked.
5. Tap in plastic wall plug.
6. Fasten anti-tip strap with wall screw provided.
(Please install the anti-tiping kit in the middle of the case piece if only have one set of anti-tipping kit.)
WALL
PAGE 13 OF 13
