LED Vanity
Features
Modern design featuring wood and metal finishes. Glass-in-glass diffuser.
Available in 2, 3, or 4 light models. Can be mounted up or down.
Fixture mounts standard to junction box (not included).
Construction
Die-cast metal diffuser bracket, stamped metal
backplate and hand-blown glass diffuser. Power
supply connections must be made inside a junction
box (not included).
Finish
Walnut finish, all cast metal components are finished in satin nickel
or oil-rubbed bronze.
Diffuser
Clear outer glass diffuser, white inner glass diffuser.
PREPARED
BY
COMMENTS
CATALOG
NUMBER
QUANTITY
FIXTURE TYPE
Electrical
This unit it direct wired with a constant current LED driver rated for 120VAC.
Compatible with residential TRIAC and ELV dimming.
Lamping
2-Light model = 15.5W LED, 1200 source lumens.
3-Light model = 22.5W LED, 1800 source lumens.
4-Light model = 30W LED, 2400 source lumens.
3000K (CCT). Rated for 50,000 Hrs., 90 CRI.
Certification
All fixtures are cETLus listed for damp locations.
ADA
Warranty
L
Specifications and dimensions
subject to change without notice.
H
D
L L
Ordering Information:
Satin Nickel Oil-Rubbed Bronze LED Lumens CCT L H D
30W 2400 3000K 30” 8-3/8” 4”
LED
Source
15.5W 1200 3000K 15-1/2” 8-3/8” 4”
22.5W 1800 3000K 23-3/4” 8-3/8” 4”
