Union Community Virdi AC-2100 User Manual

AC-2100.User Guide

Version Eng-1.06

Copyright 2000 By Union Community Co., LTD.

AC-2100 User Guide 2

< Revison History>

Version Date Description Firmware Version

1.00 2009-08-20 Initial Release 10.51.00

1.01 2009-10-29 Change the menu key

- Menu : F2~  F3~

1.02 2010-03-08 <Multi Fn-Key > added (P.34)

<Print Out> added (P.35)
<Time Sync> added (P.42)

1.03 2010-04-05 <F3 Time>, <F4 Time> added (P.34)
<Template OnCard> added (P.36)

1.04 2010-04-20 Add 12=Danish in <Language> (P.47) 10.51.04-000.00 ~

1.05 2010-10-05 Add 13=Russian in <Language> (P.47)
<Blocking Time> added (P.37)

1.06 2010-11-25 Add 14=French, 15=Farsi
in <Language> (P.48)
<Calendar> added (P.42)
Add 3.Message in <Show User ID>
(p36)

1.07 2011-04-06 <Key On/Off> menu added (p34)
‘4.Format 5’ added on<Card Format>
(p47)

1.08 2011-08-09 4. Wireless Lan menu added on 2.
Network (p31)

6.External Device menu added on 6.
Device (p51)

1.09 2011-09-30 ‘16=Srpski’ (Serbian) added on
<Language> (p46)
‘3.FireNO, 4.FireNC, 5.PanicNO,

6.PanicNC, 7=Emergency NO
8=Emergency NC’ added on <Alarm
Sensor2> (p45)

1.10 2013-04-01 UDL (USB Data Loger) function added
(p52)

10.51.01~

10.51.03~

10.51.03-000.03 ~

10.51.06-000.00 ~

10.51.06-000.01 ~

10.51.06-000.04 ~

10.51.06-000.05 ~

10.51.07-000.00 ~

10.51.07-000.02 ~

30.51.08.000.01 ~

(Only apply to
higher than H/W
version 30)

10.51.07-000.03 ~

10.51.07-000.04 ~

3x.51.10-000.00 ~

(Only apply to
higher than H/W
version 3x)

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 3

< Terminology Description >

 Admin, Administrator

- As a user who can access using terminal menu mode, the administrator has

rights to change the operating environment through
registration/modification/deletion of terminal users.

- In case no registered administrator is available, anyone can access the

terminal menu to change a particular setting. Therefore, it is
recommended to have at least one administrator.

- As the administrator has rights to change important environment setting of

fingerprint recognition device, special caution is required during registration
and operation.

 1:1 Authentication (1 to 1, Verification)

- This is a method that authenticates fingerprint after entering user ID or card

- This method is called 1:1 authentication because the fingerprint of a user

registered in a user ID or card.

 1:N Authentication (1 to N, Identification)

- This is a method that searches a corresponding user only with fingerprint.

- This method is called 1:N authentication because it searches the identical

fingerprint from the registered fingerprints without user ID or card input.

 Authentication Level

- This is a level used during fingerprint authentication. 1~9 levels are available

for display according to the level of fingerprint correspondence. The
correspondence level of two fingerprints during authentication must be higher
than the authentication level in the setting.

- A higher authentication level provides a higher security level. However, a

relatively higher correspondence rate may lead to a higher authentication
failure rate.

- 1:1 authentication level: Authentication level used during 1:1 authentication

- 1:N authentication level: Authentication level used during 1:N authentication

 Authentication Method

- This represents the various types of authentication methods formed with

combination of FP (fingerprint) authentication and RF (card) authentication.
Example) Card or FP: Authentication with card or fingerprint

 Function Key

- [F1], [F2], [F3] and [F4] keys are available. These keys allow a user to enter
the menus or change modes such as office start/leave.

 LFD (Live Finger Detection): Imitation Fingerprint Prevention Function

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 4

- This function allows the input of only real fingerprints and blocks the input of
imitation fingerprints produced using rubber, paper, film and silicone.

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 5

Table of Contents

< Revison History>...................................................................................................2

< Terminology Description > ................................................................................... 3

Table of Contents....................................................................................................5

1. Check before Device Use .................................................................................... 7

1.1. Cautions for Safety ..................................................................................... 7

1.2. Terminal Component Name........................................................................8

1.3. Information on Button Required during Operation .................................. 8

1.4. Information on LED Signal Displayed during Operation..........................9

1.5. Information on Screen Displayed during Operation ................................9

1.6. Information on LCD Icon Displayed during Operation ........................... 11

1.7. Information on Voice Message Issued during Operation....................... 11

1.8. Information on Buzzer Sound Issued during Operation........................ 11

1.9. Proper Fingerprint Registration and Input Method ................................ 12

2. Product Introduction..........................................................................................14

2.1. Product Features.......................................................................................14

2.2. Configuration Figure ..............................................................................15

2.2.1. Independent Use (Access).................................................................15

2.2.2. Connection with PC server (Access, Time & Attendance and Meal

Service Management).................................................................................. 16

2.3. Product Specifications..............................................................................17

3. Environment Setting..........................................................................................18

3.1. Items to Check before Setting Environment...........................................18

3.1.1. Entering Menu....................................................................................18

3.1.2. Modifying Setting Values ....................................................................18

3.1.3. Saving after Completion of Environment Setting................................19

3.1.4. Procedures to Enter Menu without Administrator Authentication........19

3.2. Menu Configuration .................................................................................. 20

3.3. User Control...............................................................................................22

3.3.1. User Registration................................................................................ 22

3.3.2. User Deletion......................................................................................25

3.3.3. User Change......................................................................................25

3.3.4. Administrator Registration ..................................................................29

3.3.5. All User Deletion................................................................................. 29

3.4. Network Setting.........................................................................................30

3.4.1. Terminal ID .........................................................................................30

3.4.2. IP Setting............................................................................................31

3.4.3. Server IP Setting................................................................................33

3.4.4. Wireless LAN Setting..........................................................................34

3.5. Option Setting............................................................................................34

3.5.1. Application Setting..............................................................................34

3.5.2. Authentication Method Setting............................................................37

3.5.3. Door Setting .......................................................................................39

3.5.4. Volume Setting...................................................................................41

3.5.5. LCD Setting........................................................................................42

3.5.6. Time Setting .......................................................................................43

3.6. Terminal Information Inquiry....................................................................45

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 6

3.7. Extra Function........................................................................................... 46

3.7.1. Terminal Lock Setting .........................................................................46

3.7.2. Card Number Inquiry..........................................................................47

3.7.3. Sensor Monitor Input Port Setting ......................................................47

3.8. Device Setting............................................................................................49

3.8.1. System Configuration.........................................................................49

3.8.2. Card Reader Setting........................................................................... 50

3.8.3. Fingerprint Sensor Setting..................................................................50

3.8.4. Wiegand Output Setting .....................................................................52

3.8.5. Terminal Initialization .......................................................................... 53

3.8.6. External Device Setting......................................................................55

4. How to Use Terminal .......................................................................................... 57

4.1. In Case of Operating as [0.Access Ctrl] ..................................................57

4.1.1. Authentication Mode........................................................................... 57

4.1.2. Authentication Using Fingerprint.........................................................57

4.1.3. Authentication Using Card..................................................................58

4.2. In Case of Operating as [1.T&A Ctrl]........................................................59

4.2.1. Authentication Mode........................................................................... 59

4.2.2. Fingerprint Authentication...................................................................60

4.2.3. Authentication Using Card..................................................................60

4.3. In Case of Operating as [2.Meal Ctrl]....................................................... 60

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 7

1. Check before Device Use

1.1. Cautions for Safety

 Warning

Do not operate the device
with wet hand, and do not
let liquid such as water to
flow into the device.

-> It may cause device

failure or electric shock.

Do not disassemble, repair
or modify the device
without permission.

-> It may cause device
failure, electric shock or
fire.

- If displayed instructions are not followed, it may cause death or serious injury of a user.

Do not place the device
near fire.

-> It may cause fire.

Do not let children play
with the device. ->
It may cause children
safety accident or device
failure.

 Caution

Do not expose the device to
direct sunlight.

-> It may cause
malfunction, deformation
and discoloration of the
device.

Do not spray water for
cleaning the device. Do not
wipe the device with
benzene, thinner or alcohol.

-> It may cause electric
shock or fire.

Do not contaminate the
fingerprint input area.

-> Fingerprint may not be
properly recognized.

Do not apply impact on the
device. Do not let a sharp
object touch the device.

-> It may damage the
device leading to device
failure.

- If displayed instructions are not followed, it may cause injury of a user or property damage.

Do not install the device
in a humid or dusty
location.

-> It may cause device
malfunction.

Do not place the device
near magnets.

-> It may cause device
failure or malfunction.

Do not spray pesticide or
flammable liquid on the
device.

-> It may cause
deformation and
discoloration.

Do not install the device
in a place with a large
variation of temperature.

-> It may cause device
failure.

 We are not reliable for the accidents and damages caused by not following the

user guide.

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 8

1.2. Terminal Component Name

1.3. Information on Button Required during Operation

- Change to office start mode

- At menu mode,

F1

F2

F3

used as [ESC] or move to left [] button,

used as [ESC] button if pressed down for longer then 2 seconds:

[ESC~]

- Change to office leave mode

- At menu mode, used as move up or increase [󰄬] button

- Change to work outside mode

- Entry to menu mode if pressed down for longer than 2 seconds

[F3~]

- At menu mode, used as move down or decrease [󰄮] button

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 9

- Change to return to office/access mode

- At menu mode,

F4

used as [ENT] or move to right [] button

used as [ENT] button if pressed down for longer than 2 seconds:

[F4~]

1.4. Information on LED Signal Displayed during Operation

●

●

Power
source

Red

Door Green

Light on: Normal
Light on and off: Cover open

Light on: Door open
Light off: Door closed

1.5. Information on Screen Displayed during Operation

Connection State with Server
Door State
Reading Card

Menu and current meal service hour count display during meal service

Office start, office leave mode display during time & attendance control

START

2009/08/25 16:58

Access mode display during access control (F1, F2, F3 and F4)

(Office start, office leave, work outside and return to office)

management

Guidance message

Current Time

- Default screen of AC2100

2009/08/25 16:58

- Under fingerprint input or waiting for fingerprint

2009/08/25 16:58

input

- Authentication success

2009/08/25 16:58

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 10

- Authentication failure

2009/08/25 16:58

2009/08/25 16:58

2009/08/25 16:58

2009/08/25 16:58

2009/08/25 16:58

2009/08/25 16:58

2009/08/25 16:58

- Fingerprint input failure
In case the finger is removed too early before the

fingerprint is entered

- Unregistered card input

- In case 1:N authentication is attempted when
authentication priority is SN and a user with 1:N
authentication permission is not available in the
terminal

- Passback failure

- In case processing is difficult during server
authentication because too many authentication
requests are made from the terminal

- In case the same user attempts authentication more
than twice during the same meal service hour when
the terminal is set and used as meal service
management

- In case the server is not responding during
authentication attempt to the server

- In case network is disconnected during
authentication attempt to the server

- In case connection attempt continues because no
registered user is available in the terminal and

2009/08/25 16:58

connection to the server cannot be made

- Waiting for card input

2009/08/25 16:58

- In case authentication is attempted with proper
registration during the time when access is not

2009/08/25 16:58

2009/08/25 16:58

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

permitted

- Waiting for response after authentication attempt to
the server

AC-2100 User Guide 11

- In case terminal is in lock state

- In case it is not meal service hour when setting as

2009/08/25 16:58

meal service management

- When upgrading terminal program
(Do not switch off terminal power while this

2009/08/25 16:58

message is displayed.)

1.6. Information on LCD Icon Displayed during Operation

Server
connection
state

Door
open/closed

Reading card

: LAN cable not connected

: LAN cable connected but not connected to server program

: Connected to server program

: Door closed
: Door open

: Disappears 1 second after a card is read

1.7. Information on Voice Message Issued during Operation

Operation Voice guidance

Fingerprint input Please enter your fingerprint.

Authentication
success
Authentication
failure

You are authorized.

Please try again.

1.8. Information on Buzzer Sound Issued during Operation

ppi

k

Alarm sound
during button
or card
operation

In case button is pressed or card is read
In case finger can be removed after fingerprint
input is completed

ppibik Failure In case authentication fails or user input is wrong

ppiriririk

ppiririk

Waiting for
input

Success In case authentication succeeds or the setting of a

When informing that the system is waiting for
fingerprint input

current user is completed

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 12

1.9. Proper Fingerprint Registration and Input Method

 Proper fingerprint input method

If possible, use the index finger and enter fingerprint as if you are making a
thumbprint. Just touching a finger to the fingerprint input window is not the
proper way for registration/input. The proper way is to touch the center of
fingerprint on the fingerprint input window.

 If possible, use the fingerprint of the index finger for input.

With the index finger, a more accurate and stable fingerprint can be entered.

 Check whether the fingerprint is clear or it has wound.

Too dry or wet fingerprint, blurred fingerprint and fingerprint with wound are
difficult to recognize. In such a case, use the fingerprint of a different finger
for registration.

 Cautions according to the conditions of user’s fingerprint

A fingerprint may not be usable or may be inconvenient to use depending on
the conditions of fingerprint.

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 13

 This product is a fingerprint recognition system. If a fingerprint is

damaged or weak, it cannot be used. If that happens, use a password for
operation.

 If your hand is too dry, breathe into it for a while to ensure smooth

operation.

 In case of children, fingerprint may be too small or weak to use. It is

necessary to register the fingerprint every six months.

 In case of seniors, registration may be difficult if fingerprint has

excessive fine wrinkles.

 It is recommended to register at least 2 fingerprints.

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 14

2. Product Introduction

2.1. Product Features

 Access control system using network (LAN)

- As communication between fingerprint recognition device and

authentication server is done using UTP cable and TCP/IP protocol, existing

local area network can be used for good scalability. 10/110 Mbps auto
detect provides fast speed and allows easy management and monitoring

through a network.

 Convenient auto sensing function

- Authentication operation requires only fingerprint input without additional

key input.

 Simple authentication using fingerprint

- The use of fingerprint recognition technology, one of biometrics

technologies, prevents loss of password, card, key or theft. As fingerprint
is used, the security level of authentication is substantially increased.

 Convenient guidance message using LCD and voice

- Using voice and LCD display window, every authentication operation is

processed with guidance message. Especially, the built-in backlight of LCD
display window allows for easy screen identification and key operation
even in dark areas. As voice is saved in the memory, making change to a
desired voice is possible at the server.

 Provides various and flexible access control methods

- Convenient to use while preventing lending, forgery and loss of key or card

- Provides perfect access control function by granting access rights for each

user group

- Provides flexibility in access control by granting limited access hour

- Provides low maintenance and development cost compared to other access

control devices

- Removes inconvenience of obtaining additional card from management

office for visitors

 Applied in various operation systems such as crime prevention,
access, time & attendance and meal service

- Supports various operation systems according to operation method setting

of the terminal menu

 Sufficient processing capacity of server

- In case of managing information of accessed people using the server,

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 15

nearly limitless processing is possible.

 Provides various registration and authentication methods

There are 4 registration and authentication methods available for general
users. The registration and authentication method must be chosen before
registering a user or administrator.

FP Fingerprint registration

Fingerprint authentication

RF Card registration

Card authentication

RF|FP Card and fingerprint registration

Card or fingerprint authentication

RF&FP Card and fingerprint registration

Fingerprint authentication after card authentication

2.2. Configuration Figure

2.2.1. Independent Use (Access)

Electric Lock

(Lock+, Lock-, Monitor)

DC12V Adapter

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 16

T

T

T

T

r

T

2.2.2. Connection with PC server (Access, Time & Attendance and Meal Service Management)

CP/IP

Internet /
WAN / LAN

CP/IP

CP/IP

Fingerprint Recognition Server
(Static IP)
UDB Server
Database (MDB or MSSQL)

CP/IP

Remote Administrato
Program (User and Terminal
Setting Management)

TCP/IP

CP/IP

Meal Service

Management Program

Time/Attendance

Control Program

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

AC-2100 User Guide 17

2.3. Product Specifications

Classification Specification Remarks

CPU 32Bit RISC CPU(266MHz)

8M SDRAM

MEMORY

4M FLASH

100 User

100 Finger

5,119 Log

Fingerprint Sensor Optical

Authentication Speed Within 1 second

Scan Area / Resolution 13 * 15mm / 500 DPI

FRR / FAR 0.1% / 0.001%

Authentication

TCP/IP

server

communication

RS-232

Communication Port

RS-485

Meal service

printer
External device
communication

Card reader or

Wiegand In/Out

external device
communication

Temperature /

Humidity

-20 ~ 50 /

Lower than 90% RH

LCD 128 X 64 Graphic LCD

SIZE 92.3mm * 169.9mm * 39.5mm

INPUT : Universal AC 100 ~ 250V

AC / DC Adapter

OUTPUT : DC 12V
(Option : DC 24V)

UL, CSA, CE Approved

Card Reader Smart Card Reader

Option Door phone

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu

A-type,

13.56MHz

AC-2100 User Guide 18

3. Environment Setting

3.1. Items to Check before Setting Environment

3.1.1. Entering Menu

If [F3] button is pressed for longer than 2 seconds, the following administrator
authentication screen is displayed.

<Verify Admin>

Input Admin card

or fingerprint

[ESC]

If administrator authentication with card or fingerprint according to the
registered authentication method succeeds, the system enters the menu as
shown below.

1.User

2.Network

3.Option

4.Terminal Info

5.Ext Function

6.Device

After selecting a desired menu with

[󰄬](F2) and [󰄮](F3) button, press
[ENT](F4) button to enter the lower

menu.

[ESC] [󰄬] [󰄮][ENT]

F1 F2 F3 F4

The description of F1, F2, F3 and F4 button functions are displayed in order at
the bottom of the screen as shown in the above figure. Move up and down and
make selection by pressing [ENT](F4). The system can transfer to the upper
menu by pressing [ESC](F1).

 The administrator authentication is displayed only when there is a registered

administrator. Authentication is required only once during entry to the menu.
Access rights to all menus are valid until the system leaves completely from
the main menu.

3.1.2. Modifying Setting Values

Setting values can be modified by pressing [󰄬][󰄮] button.

If a setting value is longer than 2 digits, move to the location of a digit to

change by pressing [󰄫][󰄭] button and change the value by pressing [󰄬][󰄮]

button.

UNIONCOMMUNITY
Seoul, Korea (138-050)
Tel : [phone] , Fax : [phone], E-Mail :[e-mail]

://www.unioncomm.co.kr

http

Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu
