Union Community Smart-i User Manual

Copyright 2000 By Union Community Co., LTD.

Smart-i. User Guide

Version eng-1.01

Smart-i 사용자 가이드 2

㈜유니온커뮤니티 / 서울시 송파구 방이동 44-3 현대토픽스 빌딩 3층 (138-050)

Tel : [phone] , Fax : [phone], E-Mail :[e-mail]
http://www.unioncomm.co.kr

<Revison History>

Version Date Description Firmware Version

1.01 2012-08-30 Initial Release 10.51.00-000.13

< Glossary >

 Admin, Administrator

- As a user who can enter into the terminal menu mode, he can register/modify/delete

terminal users and change the operating environment by changing settings.

- If there is no administrator for a terminal, anyone can change the settings, so it is

recommended to register at least one administrator.

- Caution is required with registration and operation because an administrator has the

right to change critical environmental settings of the fingerprint recognition unit.

 Authentication Method

- Various Kinds of authentication including FP(fingerprint) authentication, RF(Card)

authentication, or a combination of these methods.
Ex) Card or FP: Card or fingerprint is used for authentication.

 Function Keys

- [F1], [F2], [F3], [F4] are used to get in the menu and each key represents each
authentication mode.

Smart-i 사용자 가이드 3

㈜유니온커뮤니티 / 서울시 송파구 방이동 44-3 현대토픽스 빌딩 3층 (138-050)

Tel : [phone] , Fax : [phone], E-Mail :[e-mail]
http://www.unioncomm.co.kr

Table of Contents

<Revison History>.................................................................................................... 2

< Glossary >.............................................................................................................. 2

Table of Contents ..................................................................................................... 3

1. Before use............................................................................................................. 4

1.1. Safety precautions ...................................................................................... 4

1.2. Terminal description.................................................................................... 5

1.3. LED signal during operation....................................................................... 5

1.4. Function key information during operation .............................................. 5

1.5. Voice information during operation ........................................................... 6

1.6. Buzzer sound during operation.................................................................. 6

1.7. Correct fingerprint registration and input methods ................................. 6

2. Introduction .......................................................................................................... 8

2.1. Features .......................................................................................................8

2.2. Configuration ............................................................................................... 9

2.2.1. Standalone Configuration (AP Mode) ................................................... 9

2.2.2. Network Configuration .......................................................................... 9

2.3. Specifications ............................................................................................ 10

3. Environment Settings ........................................................................................ 11

3.1. Check items before setting the environment .......................................... 11

3.1.1. Entering menu .................................................................................... 11

3.1.2. How to enter menu without admin authentication ............................... 11

3.2. Menu Configuration...................................................................................12

4. How to use the terminal ..................................................................................... 12

4.1. Changing authentication mode ................................................................ 12

4.2. Authentication............................................................................................12

4.2.1. Fingerprint authentication ................................................................... 12

4.2.2. Card authentication ............................................................................ 12

Smart-i 사용자 가이드 4

㈜유니온커뮤니티 / 서울시 송파구 방이동 44-3 현대토픽스 빌딩 3층 (138-050)

Tel : [phone] , Fax : [phone], E-Mail :[e-mail]
http://www.unioncomm.co.kr

1. Before use

1.1. Safety precautions

 Warning

Handling with wet hands or

allowing liquid to flow into it
is not advised.

-> it may cause an electric
shock or damage.

Do not place a fire source
near the unit.
 It may cause a fire.

Do not disassemble, repair,
or modify the unit.

-> It may cause an electric
shock, fire or damage.

Keep out of reach of

children.

-> It may cause an
accident or damage.

- If the above warnings are ignored, it may result in death or serious injury.

 Cautions

Keep away from direct
sunlight

-> It may cause
deformation or color
change.

Avoid high humidity or
dust

-> The unit may be
damaged.

Avoid using water,
benzene, thinner, or alcohol
for cleaning

-> It may cause an electric
shock or fire.

Do not place a magnet
close to the unit.

-> The unit may break
down or malfunction.

Do not contaminate the
fingerprint input area.

-> Fingerprints may not be
well recognized.

Avoid using insecticides
or flammable sprays near
the unit.

-> It may result in
deformation or color
change.

Avoid impacts or using
sharp objects on the unit.

-> The unit may be
damaged and broken.

Avoid severe temperature
changes.

-> The unit may be
broken.

- If the above cautions are ignored, it may result in property loss or human injury.

※

Under no circumstances will Union Community be responsible for accidents or damages

caused by inappropriate use of the product caused by not referring to the user manual.
