UNIMO Technology BIT 3 User Manual
BiT-3 Headset User Guide
Answer
Put on hold
Please read the instructions before use
Designs and Features are subject to change for improvement
1. GETTING STARTED
Main Feature
Package Contents
Battery and Battery charging
2. INSTALLATION
Installation Microphone & Speaker
Installation Unit & Cradle
3. BUTTONS AND INPUTS
4. BASIC FUNCTION
Power On / Off
Volume Up / Down
Audio-Power-Off
5. MOBILE PHONE CONNECTION
First Mobile Pairing
Second Mobile Pairing
New Mobile Replacement
6. PHONE
Reject
Hang up
Voice calling
Last number redial
Automatic answer call
Audio Transfer
Put the current call on hold, Answer an incoming call
Hang up the current call, Answer an incoming call
Put the current call on hold, Reject an incoming call
Switch to the other phone
Switch to the music
7. MUSIC
Enter Music Mode / Exit Music Mode
Music Play / Stop / Mute
Fast Forward/ Rewind
8. VOX
VOX ON
VOX sensitivity control / OFF
9. INTERCOM
Intercom pairing
Intercom connection / disconnection
10. UNIVERSAL INTERCOM
Intercom pairing
Intercom connection / disconnection
11. LANGUAGE
Language setting
12. FM RADIO
Radio on/off/mute
Channel up/down
Saved channel up/down
13. RESET
Factory Reset (To initialize all the settings)
Cold Reset (To restart the stopped unit)
Software Download
14. CERTIFICATIONS
15. SUPPORT
1. GETTING STARTED
Thank you for choosing our ChatterBox BiT-3, Motorcycle Bluetooth
Intercom Headset
(1) Main Feature
Bluetooth V 4.1
1:1 Intercom Max up to 400M
Universal Intercom with Non-ChatterBox unit
FM Radio
5 Languages Voice Prompt
Water resistance
Usable during charging
Dual pairing with two Bluetooth devices
Precaution
Limited Warranty
Technical Data
Home Page / Contact Info
(2) BiT-3 PACKAGE CONTENTS
① Main unit with a pre-installed battery
② USB charging cable and AC adaptor
③ Headset with microphones for open and full face helmets.
④ Velcro speaker disks, foam microphone-covers, microphone Velcro
sticker
⑤ Helmet Mounting bracket with Cradle, 2 Screws and Allen Wrench
⑥ Manual and ChatterBox logo sticker
(3) Battery Charging
Connect the supplied USB cable into a PC or wall Charger.
(4) Battery
This product has an irreplaceable rechargeable battery inside. Therefore,
when using the product, make sure to adhere to the following:
Never separate the battery from the product as this may damage
the product
The battery performance may be reduced over time with usage
Store the battery at the temperatures of -20°C ~+50°C / -
4°F~+122°F. Higher or lower temperatures may reduce the capacity
and life of the battery or may cause temporary non-operation.
Do not use the product in sub-zero temperature, because it may
cause serious reduction of the battery performance.
If you apply heat to the battery or throw it into fire, it may explode.
Do not use the product with a damaged battery. It may explode
and/or cause accidents.
Battery life may vary depending on conditions, environmental
factors, functions of the product in use, and devices used with it.
2. INSTALLATION
(1) HEADSET AND MICROPHONE
① The Headset comes with both with open and full face microphones.
In recharging the battery, make sure to use an approved charger
provided by the manufacture. Use of a non-approved charger may
cause fire, explosion, leakage, and other hazards may also reduce
the life time or performance of the battery.
Do not use cigarette chargers other than the included cigarette
charger to charge the unit.
Please choose the one that you intend to use and plug it in the
connector on the cradle.
② For full face helmet, attach soft Velcro disk to the helmet chin bar and
attach hard Velcro disk to the microphones.
③ Apply the soft Velcro disks on the liner of your helmet. Mound them in
the indentation of the helmet padding where your ears would line up.
BUTTONS & INPUTS
A
POWER Button
B
USB port
C
MAIN FUNCTION Button
D
PLUS Button
E
MINUS Button
Please keep in mind that you need to mount the speakers in a location
that is directly next to your ears.
④ Attach the right speaker (with the longer wire) to the corresponding
Velcro disk that you applied on the helmet liner. Attach the left speaker
(with the shorter wire) to the other Velcro disk. For helmets with speaker
pockets, simply insert the speakers in each corresponding pocket.
(2) MIAN UNIT AND CRADLE
① Unscrew the cradle and let the cradle snuggle up to the bottom
left side of the helmet.
② Fasten the mounting bracket by using the bolts supplied.
③ Make sure that the back side of the Unit is aligned with the
grooves on the mounting bracket.
3. BUTTONS AND INPUTS
4. BASIC FUNCTION
④ Slide the BiT-3 unit down on the mounting bracket until it
latches firmly into the place.
Power ON : Long press POWER button(A) for 3 seconds
Power OFF: Long press POWER button(A)for 6 seconds
Volume up : Short press PLUS button(D)
Volume down : Short press MINUS button (E)
Automatic power-off : As no-operation is running for 60 minutes,
the unit is automatically turned off to prevent self-discharge
