UniGuard UM206 User Manual

UniGuard Technology Limited

- - www.uniguardgps.com

1

Mini GPS Vehic le Track er

Us er Ma nu al

UM206

UniGuard Technology Limited

- - www.uniguardgps.com

2

1 Product Instructions

It is a mini GPS Tracker, built-in GPS Antenna and GSM Antenna, Size:

94*45*10mm, Weight: 85g, it can send vehicle location and status to mobile

and Internet. It can track the vehicles remotely. Tracker the vehicle on the

Internet and Mobile. (Wide working voltage 9V-75V.)

UniGuard Technology Limited

- - www.uniguardgps.com

3

1.1 Interface

Item Descriptions

Dimension 94*45*10 mm

Weight 90g

GSM Frequency 850/900/1800/1900Mhz

GPS Module Ulbox

GPS Sensitivity -159dBm

GPS Accuracy 10m

Time to first fix

Cold start 35-80s

Warm start 35s

Hot start 1s

Working voltage 9-75V

Battery Built-in 3.7V 450Ma Li-ion battery

Storage Temperature -40°C to +85°C

Working Temperature -20°C to +55°C

Working Humidity 5%--95% non-condensing

UniGuard Technology Limited

- - www.uniguardgps.com

4

LED Status Explanation

RED-Power

Blink OK

OFF No Turn on Or Low Power

GREEN-GSM

ON Initialize GSM Signal

Blink GPRS OK

OFF GSM Standby

Blue-GPS

ON Search GPS Signal

Blink GPS OK

OFF GPS Not Working

1.2 Installation Figure

1.2.1 Check products to see if there is any accessory missing. Please

contact us immediately.

You can hear “click” sound is insert is correct.

1.2.2 Insert SIM card

1

2
