ITEM # 182584

Tabletop Charcoal Grill

DANGER!

DO NOT use charcoal briquettes for indoor cooking or heating. TOXIC carbon monoxide fumes can accumulate and cause asphyxiation. DO NOT USE on boats or recreational vehicles. Live hot charcoal could create a fire hazard.

WARNING

For Outdoor Use Only (Outside any enclosure)

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE REFERENCE.

FOR CUSTOMER SERVICE, CALL 1-877-885-8227, 6 A.M. – 5 P.M. PST, MONDAY-FRIDAY.

Printed in China

Table of Contents



For Your Safety.......................................................................................................................

1

Illustrated Parts List ...............................................................................................................

2

Assembly Instructions............................................................................................................

3-6

Cooking Styles.........................................................................................................................

7

Helpful Hints.............................................................................................................................

7

Lighting Your Grill....................................................................................................................

7

AwardWinning Barbecue Recipes........................................................................................

8

Warranty Program....................................................................................................................

9

Manufacturer Information........................................................................................................

9

Dear Valued Customer,



Congratulations on your new barbecue grill! You’ve made the right choice. In this manual, you will find assembly instructions, suggestions for grilling and helpful hints, as well as guidelines for the safe operation, proper care and use of your grill. Our expert staff strives to provide you with an easy to assemble product. Should you have any questions, problems or missing parts, please call our customer service department at 1-877-885-8227, 6:00AM to 5:00PM (PST), Monday through Friday.

IMPORTANT NOTICE: READ ALL INSTRUCTIONS PRIOR TO ASSEMBLY AND USE

WARNING

FOR YOUR SAFETY

DO NOT store or use gasoline or other flammable vapors and liquids within 25 feet (8m) of this or any other appliance.

For Your Safety

Safety First!

Read and understand all warnings and cautions prior to operating your grill.

WARNING

1.This grill is for outside use only, and should not be used in a building, garage or any other enclosed area.

2.This grill is for use with charcoal only.

3.The use of alcohol, prescription or non-prescription drugs may impair the user's ability to properly assemble or safely operate the appliance.

4.Do not use gasoline, kerosene or alcohol for lighting. This grill is not intended to be installed in or on recreation vehicles and/or boats.

5.Always open grill lid carefully and slowly as heat and steam trapped within the grill could cause severe burns.

6.Always place your grill on a hard and level surface far away from combustible materials. An asphalt or blacktop surface may not be acceptable for this purpose.

7.Do not attempt to move the grill while it is lit.

8.Do not leave a lit grill unattended. Keep children and pets away from the grill at all times.

9.Do not use grill in high winds.

10.Do not use the grill until it is COMPLETELY assembled and all parts are securely fastened and tightened.

11.Keep all combustible items and surfaces at least 12 inches (30 cm) away from the grill at all times. DO NOT use this grill or any gas product under any enclosure near any unprotected combustible constructions.

CAUTION

1.Do not touch metal parts of grill until it has completely cooled (at least 30 minutes) to avoid burns, unless you are wearing protective gear (pot holders, gloves, BBQ mittens, etc.).

2.Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids.

3.Do not alter grill in any manner.

4.Do not repair or replace any part of the grill unless specifically recommended in this manual. All other service should be referred to a qualified technician.

BC1401 Owner’s Manual

1

Bbq Grillware Bc1401, Bc1401 Owner's Manual

Illustrated Parts List

1.Top lid……………..............1pc 2. Bottom bowl..................…1pc 3. Cooking grid.…................1pc

4. Charcoal grid……….….....1pc

5.

Lid handle.......…....…...…1pc

6. Bowl damper.............….2 pcs













7. Lid vent..........................

2 pcs

8.

Legs assembly..................

1pc

9. Wire handle....…........……1pc

Hardware List

A

Bolt

1pc

F

Flat washer

2 pcs

M6 x15mm

6.5mm



















Bolt





Flat washer



B

2 pcs

G

6.5mm

5 pcs

M4 x12mm



















C

Bolt



H

Wing nut M6



M5 x 12mm

1pc

3 pcs















D

Lock washer

3 pcs

I

Wing nut M5

3 pcs

6.5mm























Lock washer









E

5.5mm

1pc



























BC1401 Owner’s Manual

2
