Welcome

Congratulations on your purchase of the Uniden single (DSS7815) or dual (DSS7815+1)
handset cordless phone.
This phone is designed and engineered to exacting standards for reliability, long life, and
outstanding performance.

Features

Note: Some illustrations in this manual may differ from the actual unit for

• 5.8GHz Digital Expandable

• 10 Multi- Handset Expandability

• Hands- Free Duplex Speakerphone in the Handset

• Caller ID*

• 100

• Intercom/ Call Transfer Between Handsets**

• 20 Distinctive Ring Options (10 ringer tones and 10 melody ringers)*

• Mute and Hold Features

• Direct Link Mode**

• Room/ Baby Monitoring**

• Battery Level Indicator

• Clock Display

• Animation Displays

** Requires the use of multiple handsets.

expanation purposes.

programmable Memory Locations

* Requires subscription to Caller ID service provided by Network supplier. There is

usually a fee for this service.

[2]

This series features and AutoTalk allows you to answer a call by just removing the
handset from the cradle so you don't have to waste time pushing buttons. Auto Standby
allows you to hang up by simply returning the handset to the cradle.

To protect you against mis-billed calls that might result from your phone being activated by other equipment, this
series has digital security, which automatically selects one of more than 10,00 0,000 digital
security codes for the handset and base. Digital Spread Spectrum Technology uses a wider frequency band than
standard digital transmissions. The result is a more secure conversation with the clarity of digital sound, extended
range, and minimal interference from other cordless phones.

Random Cod

AutoTalk AutoStandb

e

.

y

IntegriSoun

With mode, you can use 2 or more handsets as radio transceivers (walkie-talkies).
Be sure to visit our web site:

d

DirectLin

Built in sound quality which provides life-like conversations.

k

www.uniden.com.au or www.uniden.co.nz

Terminology

• Standby Mode

• Talk Mode

- The handset is not in use, and or has not been pressed. No
dial tone is present.

- The hand set is not in the cradle, and or has been pressed,
enabling a dial tone. appears on the display.

Talk

talk/flash speaker

talk/flash speaker

[3]

Controls & Functions

1

5

6

2

7

3

8

9

4

10
11
12

1. Handset Antenna

2. Beltclip Hole

3. Speakerphone Speaker and Ringer

13

4. Handset Battery Compartment

5. New Message LED

6. Handset Earpiece

7. LCD Display

soft

8. Keys (P.8)

/vol /

9. (volume up/down) (P.31 & 17)

.

/tone/<

10 (P.32 & 37)

14
15

16

17
18

19

*

speaker

11. (P.27)

intcom/hold

12. (P.51 & 29)

13. Headset Jack Cover

talk/ flash

14. (P.28 & 29)

end

15. (P.28)

cid

16. (P.45)

#/>

.

17 (P.37)

phonebook

18. (P.35)

19. Handset Microphone

20. Handset Charging Contacts

20

[4]

21. Base Charging Contacts

22. Base Antenna

23. Charge LED

24. (P.53)

find handset

25. Jack

DC IN 9V

26. Jack

TEL LINE

[5]

Display and Icons

Example of the standby mode display

Handset

SUN 12:00A
Handset #1
New CID: 5

REDIAL MENU

ICON Appears During DESCRIPTION

Ringer off icon (when the ringer is off)/Day of the week and time /battery icon
Handset ID and Banner
Number of new Caller ID calls received

Standby/Talk icons indicate the handset battery status.

Standby off icon indicates that ringer is turned off.

Talk The icon appears when you mute the handset.

Talk The con appears when the handset

speaker phone is used.

Talk The icon appears when the Privacy Mode

Battery

This icon cycles depending on the battery status (full,
medium, low, and empty).

Ringer

Mute

Speaker i

Privacy

is turned on.

[6]

Animation Displays

The handsets have a variety of animation displays. Below are examples of the animation screens and
what they mean:

Turning on the phone Hanging up the phone Confirmation (Done!) Deleting (Deleted!)

Welcome!

Please wait.....

Making a call Find Handset/Paging the Handset

Talk

REDIAL MENU

End Done! Deleted!

Paging

1:53

1:54

MUTE

Also, the animation display changes depending on the ringer volume setting.

Ringer Volume

REDIAL MENU

Out of Range Unavailable Low Battery

Out Of Range

REDIAL MENU

PRIVACY

Ringer Volume

REDIAL MENU

Unavailable

REDIAL MENU

Ringer Volume

REDIAL MENU

Low Battery

[7]

Soft Key Function

"Soft" keys are keys that change function during the operation of the phone. There are three soft keys on each
handset.

Soft Keys allow you to:

- Access the main menu - Access stored Caller ID messages

- Set up CIDCW options - Redial one of the last three numbers dialed from the handset

- Store or edit phone numbers - Access Voice mail waiting

The soft keys will not appear while the handsets charging.

Note:

The function of each soft key is determined by the icon that appears directly above it. For example, when the
handset is in standby mode, pressing soft key 1 will redial the last dialed number. When the handset is in talk
mode, pressing soft key 1 will mute the microphone.
Complete information on the features controlled by the soft keys can be found under each feature.

In standby mode In talk mode

SUN 12:00A
Handset #1
New CID: 5

REDIAL MENU MUTE PRIVACY

Talk

0:00

[8]

For maximum
range:

!

Keep the antenna
free of obstruction.
When the handset

!

is not in use place
the handset in an
upright position.
Do not hold the

!

handset where you
would block the
signal.

Setting up the Phone

Do the following steps:

A. Choose the best location
B. Connect the base unit
C. Install the rechargeable battery pack into the handset
D. Connect the charger
E. Mount the base unit on a wall

A. Choose the best location

Here are some important guidelines you should consider:

Avoid heat sources, such as
radiators, air ducts, and sunlight

Avoid television sets and
other electronic equipment

Avoid noise sources such as a window
by a street with heavy traffic

Avoid microwave ovens

Avoid excessive
moisture, extremely
low temperatures,
dust, mechanical
vibration, or shock

Avoid personal computers

Choose a central location

Avoid other cordless telephones

[9]

B. Connect the base unit

GETTING STARTED

1) Connect the AC adapter to the jack

DC IN 9V

and to a standard 240VAC wall outlet. Connect
the AC adapter to a continuous power supply
(i.e., an outlet that is not controlled by a switch).

2) Set the base on a desk or tabletop, and place
the handset in the base unit. Place the base
unit close to the AC outlet so that you can
unplug the AC adapter easily.

3) Make sure that the charge LED illuminates. If
the LED does not illuminate, check to see that
the AC adapter is plugged in and the handset
makes good contact with the base charging
contacts.

4) After install the battery pack in the handset,
charge your handset for at least 15-20 hours
before plugging into the phone line.

5) Once the handset battery pack is fully charged,
connect the telephone line cord to the

TEL LINE

jack and to a telephone outlet. If your telephone
outlet isn't modular, contact your telephone
company for assistance.

!!Use only the

supplied [AAD­041S] AC adapter.
Do not use any
other AC adapter.

Do not place the
power cord where
it creates a trip
hazard or where it
could become
chafed and create
a fire or electrical
hazard.

[10]

!!Use only the

Uniden (BT-446)
rechargeable
battery pack
supplied with your
cordless
telephone.
Replacement
battery packs are
available. See our
website for
information.

www.uniden.com.au
www.uniden.co.nz

C. Install the rechargeable battery pack into the handset

The handset is powered by a rechargeable battery pack.
The battery recharges automatically when the handset is placed in
the base unit. To maximize the charge capacity of your battery pack,
DO NOT plug the telephone cord into the base
unit and wall jack until the battery is fully charged.

1) Press down on the handset battery case cover (use
the finger indention for a better grip) and slide the
cover downward to remove.

2) Turn the battery pack so that the connector with the
red and black wires is near the jack inside the battery
compartment. Match the connector's wire colors to the
polarity label in the battery compartment (the connector
notches fit into the grooves of the jack only one way).
Push the battery pack connector into the jack until it
clicks into place.

3) Make sure you have a good connection by gently pulling
on the battery wires. If the connection is secure, the battery
jack will remain in place.

4) Place the battery case cover back on the handset and
slide it upwards until it clicks into place.

[11]

Mounting the Base Unit on a Wall

Standard wall plate mounting

This phone can be mounted on any standard wall plate.

1) Make the AC adapter and the telephone line cord through
the hole on the wall mount adapter.

GETTING STARTED

2) Plug the AC adapter into the jack.

3) Plug the telephone line cord into the jack.

4) Slide the wall mount adapter into the notches on the base.

5) Plug the AC adapter into a standard wall outlet.
Hook the cord on the notch of the wall mount adapter.

6) Plug the telephone line cord into the telephone outlet.
Hook the cord on the notch of the wall mount adapter.

7) Align the mounting slots on the base with the mounting
posts on the wall. Then push in and down until the phone
is firmly seated. To remove, push up a tab on the wall
mount adapter as shown.

DC IN 9V

TEL LINE

240V AC

[12]

Direct wall mounting

If you don't have a standard wall plate, you can mount your phone directly to the wall. Before
doing this, consider the following:

Avoid electrical cables, pipes, or other items behind the mounting location that could

!

cause a hazard when inserting screws into the wall.
Try to mount your phone within 1.5m of a working phone jack to avoid excessive lengths.

!

Make sure the wall material is capable of supporting the weight of the base and handset.

!

Use #10 screws (minimum length of 35mm) with anchoring devices suitable for the wall

!

material where the base unit will be placed.

1) Insert two mounting screws into the wall
(with their appropriate anchors). 100mm
apart. Allow about 3mm between the wall
and screw heads for mounting the phone.

2) Refer to steps 1 through 7 on page 12 to
mount the telephone.

3mm

100mm

35mm

[13]

Expanding Your Phone

10 Handsets Expandability

Your phone supports up to 10 handsets,
including any handsets supplied with your
phone. You can now place a fully­featured cordless handset anywhere
AC power is available to connect the
handset charger. Up to 2 handsets can be used in DirectLink Mode or on an
intercom call without interfering with incoming calls. If possible to have a 3-way conference
among 2 handsets and an outside line. All of handsets ring when a call
is received.

IMPORTANT: If you purchase a DSS7805 extra handset, please register the handset to
the original/main base before use. The DSS7805 will not operate until it is registered. If
you change a global setting in one handset, you change that particular setting for all
registered handsets. All other settings (not included under Global Setup) must be set
separately through each handset.

Connecting the Charger

GETTING STARTED

! Charge the

handset battery
pack for at least
15-20 hours before
using your new
cordless telephone
for the first time.

1) Connect the AC adapter to the jack and to
a standard wall outlet.

240VAC

DCIN9V

2) Set the charger on a desk or tabletop, and place the
handset in the charger with
the keypad facing forward. (See“C. Install the
rechargeable battery pack into the handset”
on page 11).

[14]

Register the Handset

If you purchase an extra handset, you need to register the handset before use. Only one
handset can be registered at a time.

! An extra

handset can be
registered
when the main
base is in standby
mode.

If you have

!

purchased the
DSS7815+1 your
extra handset
would have been
pre-registered at
factory as
handset 2.

Handsets supplied with the phone are registered to the base by
the factory. When charged, pre- registered handsets display a
handset ID number. Handsets that have not been registered
display . When

Place handset on main base to register

you register an extra handset to the base, the handset ID will be
assigned.

1) Before registering the extra handset, the battery
pack MUST be charged for 15-20 hours.

2) Place the extra handset in the main
base unit to begin registration.

3) While the handset is registering,

Handset Registering

will appear in
the LCD.
When is

Registration Complete

displayed, the handset has been
registered to the base.
If appears,

Registration Failed

please try these steps again.

[15]

Registration

Complete

Place handset
on main base
to register

Main Menu Options

GETTING STARTED

Your phone has five main menu options:

Handset Setup, Global Setup Deregister HS

and .

DirectLink Mode, Room/Baby Monitor,

Default Settings

The default settings set from the factory match the features that most people use.
You may not need to change them. However, there are a number of options you
must set and entries you must make in memory to take full advantage of all the phone
features. The table below lists the default settings.

Function Default Settings Function Default Settings

Edit Voice Mail Day & Time SUN 12:00 AM

Ringer Tone Flicker

None(Aus)/ 083210(NZ)

CIDCW Off

Distinctive Ring On Dial Mode Tone

Auto Talk On Insert O On (NZ)/Off (AUS)

Anykey Answer On

Name Tagging On

Banner “ “

Contrast level 5

Key touch tone On

Animation Screen On

[16]

!!For Global

Setup and
Deregister HS
menu options,
make sure the
line is not in use
and the handsets
are within range
of the base.

Main menu flow
chart is provided
on page 64.

! You must have at

least two handsets
to use Direct Link
Mode.

Setting Menu Options

Using the interface

Below are some tips for using the software interface on your phone.

• Press the soft key to access the main menu.

• Use and to scroll through options.

• Press the soft key to make a selection.

• Press the soft key to return to the previous screen.

• Press to exit the menu.

MENU

/vol/ /vol/

OK
BACK

end

DirectLink Mode

In DirectLink mode, a pair of handsets can function as two-way radios. DirectLink
Mode allows two handsets to communicate with each other without the base unit or
a telephone line. Use them at sporting events or while shop ping to stay in contact
with family members or friends. You must set both handsets to DirectLink Mode to activate
this feature.

Directlink Mode

Room Monitor
Handset Setup

BACK OK

Using DirectLink Mode

1) Press the soft key and select the DirectLink
Mode menu.

[ENTER]

2) Press the soft key to enter DirectLink mode.
You will hear a confirmation tone, and appears.

3) To return to normal mode, press the soft key and then the soft
key, or return the handset to the cradle.

MENU

To enter DirectLink mode press

appears.

ENTER

DirectLink Mode Complete

CANCEL OK

[17]

To enter
Directlink mode
press [ENTER]

BACK

ENTER

Room/Baby Monitor

This feature allows you to monitor
sounds in another room. Place a
handset in the room you wish to
monitor; it will function as a
microphone. A second handset can
be set to function as a remote
speaker, allowing you to monitor
sounds in the room.

Using Room/Baby Monitor

1) Press the soft key and select the
Room Monitor menu.
appears.

2) Select the handset you want to monitor by using

MENU

/vol/ /vol/

or .

To Room Monitor

GETTING STARTED

!!This feature only

works when the
handset(s) is
within the range
of the base.

You must have at
least two handsets
to use Room/
Baby Monitor.

3) Press the soft key. appears, and you hear sounds in the

OK

Room Monitor

room where the handset is installed.

4) To turn off the Room Monitor, press the soft key, or

END

.

end

Room Monitor
<- -> Handset # 2

END

[18]

Handset Setup

The following submenu options must be set separately for each handset.

Programming your Voice Mail Access Number

1) Press the soft key. Select the Handset Setup menu, and
then the Edit Voice Mail submenu. appears.

2) Enter your personal access number using the number keypad

(0 ,

(up to 20 digits).

3) Press the soft key. You will hear the confirmation tone. To delete the current Voice Mail Access
Number, delete all numbers in step 2 using the soft key and the soft key.

MENU

*/tone #/

9) , the soft key, or the soft key

/<, > DELETE PAUSE

OK

Edit V_mail No.

DELETE OK

Selecting a Ringer Tone

Ringer Tone lets you choose from 10 ringer tones or 10 melodies:

- Ringers

Clap, Reminder)

- Melodies

Christmas [Merry-Xmas], Home Sweet Home [Hm Swt Hm], Lorri Song #6 [Lorri Song], When Irish Eyes
Are Smiling [Irish Eyes], Aura Lee, Let Me Call You Sweet Heart [Sweet heart], Waltzing Matilda[W
Matilda], Old MacDonald [Old MacDld])

(Flicker, Clatter, Soft Alert, Wake Up, Light Bug, Beep Boop, Tone Board, Chip Chop, Party

(Beethoven's Symphony #9 [Beethoven9], For Elise [Elise], We Wish You A Merry

Edit V_mail No.
123456789

DELETE

PAUSE OK

You must set the separate ringer tone on each handset.

1) Press the soft key. Select the Handset Setup menu, and
hen the Ringer Tone submenu.

2) Press to move the pointer. You will hear
the ringer or melody as you scroll through the options.

3) When you reach the ringer tone you want, press the soft key.
You will hear a confirmation tone.

MENU

or

/vol/ /vol/

OK

[19]

Ringer Tones

Flicker

Clatter

BACK OK

Distinctive Ringer Setup

Distinctive Ringer allows you to assign a designated ring tone to a stored phonebook number (100
stored locations available). When a call is received and the Caller ID information matches the
information in one of the phonebook memory locations, the phone uses the distinctive ring assigned to
that particular Caller. You can assign distinctive rings to multiple phonebook memory locations.
Switching the setting to Distinctive Off disables distinctive ringing: all incoming calls will have normal
ring tone. Switching to Distinctive On activates all programmed distinctive ring memory locations.

1) Press the soft key. Select the Handset
Setup menu, and then the Distinctive Ring submenu.

2) Press to select On or Off.

3) Press the soft key. You will hear a confirmation tone.

MENU

or

/vol/ /vol/

OK

Distinctive Ring

On

Off

BACK OK

Setting the Autotalk

Autotalk allows you to answer the phone simply by removing the handset from the cradle. You do not
have to push any buttons to answer the call.

1) Press the soft key. Select the Handset
Setup menu, and then the Autotalk submenu.

2) Press to select On or Off.

3) Press the soft key. You will hear a confirmation tone.

MENU

/vol/ /vol/

or

OK

On

Off

Auto Talk

BACK OK

Setting Anykey Answer

Anykey Answer allows you to answer the phone by pressing any number key,

on the handset.

#/

1) Press Select the Handset Setup

2) Press to select or

3) Press the soft key. You will hear a confirmation tone.

menu/del

Menu, and then the Anykey Answer submenu.

.

or

/vol/ /vol/ On Off

OK

On

Off

BACK OK

/tone/

Anykey Answer

or

GETTING STARTED

[20]

Setting the True Banner

True Banner lets you customize the name your handset displays.
The name will be displayed on the LCD screen during Standby Mode,
Intercom, Intercom Hold, Room Monitor, and Copy Phonebook operation.
The banner name will be displayed on the receiving handset as well.

1) Press the soft key.
Select the Handset Setup menu,
and then the Banner submenu.

2) Use the number keypad ( - ), ,
Or to enter or edit the name.

3) Press the soft key.
You will hear a confirmation tone.

DELETE

MENU

OK

0 9 /tone/ #/

,

Moms Phone #1

------------

Banner

BACK OK

DELETE

Adjusting the LCD Contrast

Contrast adjusts the Handset LCD brightness. Choose one of the ten levels for optimum
viewing.

1) Press the soft key. Select the Handset Setup
menu, and then the Contrast submenu.

2) Press to adjust the contrast of the
LCD (ten levels).

3) Press the soft key.
You will hear a confirmation tone.

MENU

or/vol/ /vol/

OK

[21]

Setting the Key Touch Tone

Key Touch Tone is the tone your keypad makes when keys are pressed. You can turn this
tone on or off.

GETTING STARTED

1) Press the soft key.
Select the Handset Setup menu, and then the Key
Touch Tone submenu.

2) Press to select On or Off

3) Press the soft key.
You will hear a confirmation tone.

MENU

/vol/ /vol/

or

OK

Setting the Animation Screen

The Animation screen displays animation on the handset
LCD. The animations will be displayed on the LCD screen
during a call, ringer volume setting, when you hang up, and
so on.

1) Press the soft key. Select the Handset
Setup menu and then the Animation Screen
submenu.

2) Press to select On or Off.

3) Press the soft key. You will hear a
confirmation tone. See "Animation Displays" on
page 7 for all the available screens.

MENU

/vol/ /vol/

or

OK

[22]

Key Touch Tone

On

Off

BACK OK

Ringer Volume

REDIAL

Animation Screen

On

Off

BACK OK

MENU

Global Setup

If you change one of the global settings, you change that setting for all registered
handsets and the base. Only one handset or the base can change global settings at a time.

!!For setting the

Day and Time, the
idle time-outs
extended to 2
minutes.

Caller ID on Call
Waiting is
currently
unavailable in New
Zealand.

Setting Day and Time

Day & Time sets the day and time of your display.

Day Time

1) Press soft key. Select the Global Setup menu,

MENU

and then the Day & Time submenu option.

2) Press to select the day
of the week, and then the soft key.

3) Press to set hour, and then the soft key

4) Press to set minute, and then the soft key

5) Press to choose or and then the soft key.

/vol/ /vol/

/vol/ /vol/

or

/vol/ /vol/

or

/vol/ /vol/

or

or SAVE

AM PM,

BACK

&

MON 12:00 AM

[/]

SAVE

You will hear a confirmation tone.

Setting Caller ID on Call Waiting (CIDCW)

Caller ID on Call Waiting (CIDCW) displays the name and number of an incoming call while
you are on the line.

1) Press the soft key. Select the Global Setup menu,
and then the CIDCW submenu.

2) Press to select or

3) Press the soft key.
You will hear a confirmation tone.

MENU

/vol/ /vol/

or

OK

[23]

On Off.

CIDCW
On

Off

BACK OK

Setting the Dial Mode (Australia Only)

Dial Mode sets the dial mode to tone or pulse. Most phone systems use tone dialing; the
default setting is tone dialing. Set the dialing mode to match the dialing system used by your
local phone service.

If you are not sure of your dialing system, make a trial call. If the call connects,

!

leave the setting as is; otherwise set the unit to pulse dialing.

If your phone system requires pulse dialing and you need to send DTMF tones in

!

certain situations during a call, you may switch over to tone dialing (refer to "Tone
Dialing Switch-over" on page 32).

GETTING STARTED

1) Press the soft key. Select the Global Setup menu,
and then the Dial Mode submenu.

2) Press to select Tone or Pulse (the
initial setting is Tone).

3) Press the soft key. You will hear a confirmation tone.

MENU

/vol/ /vol/

OK

or

[24]

Tone

Dial Mode

Pulse

BACK OK

Setting Name Tag

The Name Tag feature works with the Caller Display number from Caller ID. A subscription
to this service is required from your network provider. There is usually a fee for this service.
When the phone rings the caller display number, when received will be compared to
numbers stored in the phonebook. If there is a match any name stored with the phonebook
number will be displayed.

1) Press the soft key. Select the Global Setup menu,
and then the Name Tag submenu.

2) Press to select or

Off

3) Press the soft key.

MENU

/vol/ /vol/

or

(the initial setting is On).

OK

On

Name Tagging

On

Off

BACK OK

You will hear a confirmation tone.

Setting the Insert Zero

This feature adds '0' or '00' to the number, when you receive Caller ID messages. The
default setting for New Zealand is On. The default setting for Australia is Off.

1) Press soft key. Select the Global Setup menu,

2) Press to select or .

3) Press the soft key.

MENU

and then the Insert 0 submenu.

/vol/ /vol/

or

OK

You will hear a confirmation tone.

[25]

On Off

On

Insert 0

Off

BACK OK

De-register the Handset

1) In standby mode, select Deregister HS in the
menu and press the soft key.

De register HS?

2) Press to select ,/vol/ /vol/or Yes
and then the OK soft key When de­registration is complete you will hear a
confirmation tone and

Complete

3) After de-registering the handset, place the
handset to the base to register. You must re­register the handset before you can use it.

appears.

OK

appears.

.

De-registration

GETTING STARTED

De register HS?
Yes

No

BACK OK

[26]

Making and Receiving Calls

With the handset's duplex speakerphone, you can have
hands-free conversations.

! For best

performance talk
alternately with the
caller in a quiet
room. You can
decrease the
speaker volume if
you or the other
party has difficulty
hearing

The icon appears on the display screen during hands-free
conversations.

You can easily switch a call from normal conversation to
hands-free conversation. To switch a call, press

speaker

during the call.

[27]

Talk

0:00

MUTE Privacy

From the handset

From the Handset

Normal conversation Hands-free conversation

To answer a call Handset On the Cradle

To make a ca ll Handset Off the Cradle

To hang up

To enter a pause
within the dialing
sequence

Pickup the handset (AutoTalk is:
on) or pick up the handset and

talk/flash

press (AutoTalk is: off).

Handset Off the Cradle Handset Off the Cradle

Press any number key, Press

#

(Any Key Answer),or

or />

talk/flas

press .

1) Press 1) Press

2) Listen for the dial tone.

3) Dial the number. OR Dial the
number, and then press

talk/flas

Press or return the handset to the cradle (AutoStandby).

When you dial the number in standby mode, press the
soft key. P appears in the display, which represents a pause.

h

h. r.

talk/flas speake

h.

end

/<, r.

*/tone speake

Handset Off the Cradle

2) Listen for the dial tone.

3) Dial the number. OR Dial
the number, and then press

.

r

speake

[28]

PAUSE

!

To set "Autotalk",
see page 20 or to
set "Anykey
Answer" see page

20.

The handset

!

microphone is
located at the
bottom of the
handset. (see
"Controls and
Functions" on
page 4). Position
yourself as near to
the handset as
possible and speak
clearly.

If the line is in use

!

by another
handset(s),

Line In Use

""
appears in the
display of all
registered
handsets that are
not in use.

BASICS

!!You must

subscribe
through your local
telephone
company to
receive Call
Waiting or Caller
ID on call waiting
service.

While a call is on
hold, CIDCW can
not be received.

Call Waiting

If you have Call Waiting service and a call waiting tone sounds
while you are on a call:

AUSTRALIA:

Press then to switch between callers.

talk/flash

2

NEW ZEALAND:

Press to switch between callers.

talk/flash

Placing a Call on Hold

You can place a call on hold for 5 minutes. When 5 minutes has passed the call is
disconnected

1) During a call, press .

intcom/hold

The call will be put on hold.

If you leave a call on hold for more than ten seconds, the display screen
will read,

2) To talk to the caller press or on a handset. The phone will return back

Line On Hold

talk/flash speaker

to the call.

Hold, to transfer

Handset #2

Handset #3

BACK OK

[29]

Redialing a Call

The last three phone numbers dialed can be quickly redialed
from the handset. Redial numbers stored in the handset are

<Redial1>

8007303456

BACK DELETE STORE

independent from each other.

Redialing from Standby Mode

1) Press the soft key.

2) Press to scroll through the last

REDIAL

/vol/ /vol/

or

<Redial2>

2749763990

BACK DELETE STORE

three numbers dialed.

3) Press or on the handset. The selected

4) To hang up, press

talk/flash speaker

number is dialed.

end.

<Redial3>

2453678300

BACK DELETE STORE

Deleting a Redial Record

1) With the phone in standby mode, press the soft key.

2) Press to display the number

/vol/ /vol/

or

REDIAL

to be

deleted.

3) Press the soft key.

4) Press to choose

5) Press the soft key. The redialed number is deleted.

DELETE

/vol/ /vol/

or

OK

Yes.

Delete redial1?

Yes

No

BACK OK

Storing a Redial Record

1) With the phone in standby mode, press the soft key.

2) Press repeatedly to display the

/vol/ /vol/

or

REDIAL

number to be stored.

3) Press the key. Store/Edit Name appears.

STORE

4) To complete the setting, follow the steps 3-8 in "Phonebook (Storing Phone Numbers,
Names, Distinctive Rings, and Speed dial)" on page 35.

!!If the number

exceeds 32 digits,
only the first 32
digits are retained
in redial memory.

If the redial
memory is empty,
you will hear a
beep.

BASICS

[30]

Adjusting the Ringer, Earpiece and Speaker Volume

Ringer volume

! While charging the

handset you
cannot mute the
ringer tone for the
handset.

In standby mode press on the handset
to select one of three ringer volumesor(Off, Low or High)

/vol/ /vol/

Earpiece and Speaker Volume

You can select earpiece volume from among four volume
levels on the handset earpiece and six levels on the handset
speaker. Pressing the volume up key or volume down key on
the handset during a call will change the earpiece or speaker
volume. This setting will remain in effect after the telephone
call has ended.

If you press the volume up key when the earpiece is at the maximum volume level,
an error tone sounds. The error tone also sounds if you press the volume down key
at the lowest volume.

Temporarily Muting the Ringer

To mute the ringer tone temporarily for each handset, while the phone
is ringing, press the soft key on the handset you want to mute. The mute will last for
the current incoming call only. The ringer tone will return to the previous setting starting with
the next incoming call.

MUTE

[31]

Mute Microphone

You can temporarily mute the microphone so that the caller
cannot hear you.

1) Press the soft key during talk mode

(while the phone is in use) to mute the microphone

MUTE

Talk

Mute On

2) and appear in the display. To cancel

Mute On

muting, repeat above step again when Mute is set to
on, appears.

Mute Off

MUTE

PRIVACY

Tone Dialing Switch-over

(Australia only)

If your telephone company requires pulse dialing,
you can switchover to tone dialing after the call connects. This
feature is useful when you need tone dialing to use any automated
menu systems, such as telephone bank tellers, telephone
prescription refills, customer support menus, etc.

If your phone is set to pulse dialing mode, make your call normally. Once your call connects,
press the key. Any digits you enter from then on will be sent as tone digits. When
this particular call ends, the phone automatically returns to pulse dialing mode.

/tone/

[32]

BASICS

! You can only mute

the handset ringer
if the handset is
off the cradle
when the phone
starts ringing.

Traveling Out of Range

During a call, as you begin to move your handset too far from your base unit, noise
may increase. If you pass the range limits of the base unit, you will hear a beep and see

of Range

the call if you move your handset within the range limits of the base and press or

speaker

on the display, and then the handset returns to standby mode. You may return to

talk/flash

within 30 seconds

Out

Privacy Mode

Privacy Mode prevents interruption from other registered handsets or the base.
This works only when the phone is in use.

Press the soft key

during talk mode.

PRIVACY on the handset

Privacy Mode On

and
appear in the display. To exit the Privacy Mode, repeat
above step again. appears.

Privacy Mode Off

[33]

Talk
Privacy Mode On

MUTE PRIVACY

Using One Touch Voice Mail Access

If you subscribe to voice mail service, you can use your phone to access your voice
mailbox. The new message LED flashes whenever you have messages waiting in your
voice mailbox. Just program the handset with your access number,
and you can get your messages at the touch of a button on the handset. (The voice mail
service provider will supply you with the access number. This number may be simply a
phone number. Refer to the provider's literature.)

To program or delete your Voice Mail Access Number, See page 19.

Dialing your Voice Mail Service

Once you've programmed your personal access number, you can dial your mailbox
with the touch of a button. When you have messages, simply press the soft key. If you
have not entered the access number or it has been deleted, when you press
the soft key, appears and you
will hear a beep. The phone returns to standby mode.

Resetting the New Message LED

The LED flashes when you have new messages in the voice mail service. If the LED
remains on after you’ve retrieved your messages, you may need to reset the
indicators. With the phone is in standby mode, press and hold find handset on the
base until the paging sound stops (about 5 seconds).

No Number Stored To store number press [MENU]

!!You must

subscribe to voice
mail service from
your telephone
company in order
to use this feature.
The voice mail
service company
will provide you
with the access
number.

For New Zealand:
The Telecom Voice
Mail Access
Number is pre­programmed into
speed dial location

4.

BASICS

[34]

!!When the memory

is full, you will hear
a beep and

Memory Full

appears. You
cannot store
names and
numbers.

The pause key
counts as one
digit. Pressing

PAUSE

soft key
more than once
increases the
length of the pause
between numbers.
Each pause
represents a 2
second delay.

Phonebook(Storing Phone Numbers, Names, Distinctive Rings, and Speed Dial)

You can store names and numbers in your phone’s phonebook, search for names
Alphabetically, and dial phonebook entries with just a few key presses. Phonebook
memory is stored independently in the base and handsets. You can store up to 100
numbers in the base and in each handset.

The phone uses the same memory locations to store phonebook entries and Caller ID
messages. Any empty phonebook locations are used to store Caller ID messages. For
example, if you have stored 100 phonebook entries on your base unit, the base unit will not
store Caller ID messages.

1) When the phone is in standby mode, press .
The following items appear.
(1st Line) The number of the phone book locations used
(2nd Line) How to search (press the number keypad,

/vol/ /vol/ )

or

(3rd Line) How to store (Press the STORE soft key)
(4th Line) The and soft keys.

2) Press the soft key. appears

BACK, COPY STORE

STORE Store/Edit Name

3) Enter the name (up to 16 characters) by
using the number keypad (see "Steps for entering
Names and Special Characters" on page 37.
If a name is not required, go to step 4. <No Name> will
be used as the name.

phonebook

Phonebook : 1
Search [A-Z/ / ]
Store [STORE]

BACK STORECOPY

Store/Edit Name

Movies

BACK OKDELETE

[35]

4) Press soft key to store the name;

No.

OK

appears.

Store/Edit

Store/Edit No.
8009675543

5) Use the number keypad, to enter the
phone number (up to 20 digits). If you make an error,
use the soft key to erase the incorrect digits.

DELETE

When you are finished, press the soft key to store
the number.

6) appears. Press

Distinctive Ring

to move the pointer to one of the

/vol

Distinctive Ring options and then press the soft key.

7) appears. Press
To move the pointer to select the

location

8) Press the soft key. You will hear a confirmation
tone, and appears in the display.

(10 locations: SPD1-SPD0).

OK

Done!

Chain Dialing

The memory locations in the handset are not limited to phone numbers. You can
also store a group of numbers (up to 20 digits) that you need to enter once your call
connects. This is referred to as Chain Dialing. An example of this is a bank account number.
Store the account number in one of the phonebook locations (refer to "Phonebook (Storing
Phone Numbers, Names, Distinctive Rings and Speed Dial)" on page 35). When you call
your bank and are prompted to enter the
account number, scroll through your phonebook locations until you find your account
number, and then press the soft key.

DIAL

or

/tone/ #/

OK

/vol/ /volSpeed Dial

Speed dial

/vol/

or

OK

or

DELETE OKPAUSE

Distinctive Ring

No Selectn

Flicker

BACK OK

Speed Dial

No Selectn

SPD1:<Empty>

BACK OK

Movies
8007303456

Beethoven9/SPD1

BACK EDITDELETE

[36]

PHONEBOOK

!!If you choose not

to store a
Distinctive Ring,
simply select the
"No selection"
option.
If you choose not
to store the
name/number as a
speed dial simply
choose the "No
selection" option.

Steps for Entering Names and Special Characters

Refer to the letters on the number keys to select the desired characters. With each
press of a number key ), the displayed character appears in the following order: Upper
case letters first, lower case letters next and finally the number corresponding to the key.

If you make a mistake while entering a name

Use to move the cursor to the incorrect character. Press the soft

*/ tone/ #/

< or > DELETE

key to erase the wrong character, and then enter the correct character. To delete all
characters press and hold the soft key

(0-9

DELETE

[37]

.

For example, to enter :

1) When the phone is in standby mode, press and the soft

Store/Edit Name

key. appears.

Movies

phonebook

STORE

PHONEBOOK

2) Press once, and then press to move the cursor to the right.

3) Press six times.

4) Press six times.

5) Press six times.

6) Press five times.

7) Press eight times.

6#/

6

8

4

3

7

8) When finished, press the soft key.

>

OK

To continue to store the telephone number, proceed to step 5 in “Phonebook (Storing
Phone Numbers, Names, Distinctive Rings, and Speed dial)” on page 35.

[38]

! If the next

character uses the
same number key,
you must press

#/

> to move the
cursor over.
Otherwise the next
time you press the
number key, it
changes the
character that was
previously set.

! During a call, don't

end

press on the
handset or the call
will be
disconnected.

Viewing the Phonebook

Your phone stores names/numbers in the phonebook memory locations, and you
can search names in alphabetical order. You can view the phonebook even while
the phone is in use.

1) Press . If you recall the phonebook during a

2) Press or the number keypad to

phonebook

call, the and soft key will not appear.

COPY STORE

or

/vol/ /vol/

scroll through the phonebook locations. Phonebook
locations appear in alphabetical order (from first to last
when you press from last to first when you
press ).

/vol/

/vol/

You can also use the letters on the number keys to select the first letter of the
desired name. Press a number key ( - and ) once for the first letter, twice for

29 0

the second letter, and so on. The first location that begins with the letter you
entered appears.

Phonebook : 100
Search [A-Z/ / ]
Store [STORE]

BACK STORECOPY

For example, to search for an entry beginning with the letter M, press once.
Press , until the phonebook location is displayed.

or

/vol/ /vol/

6

3) To finish the viewing operation:
From the Handset-press the soft key or during a call).

end talk/flash

(or

[39]

BACK

Making Calls Using the Phonebook

From Standby Mode

1) When the phone is in standby mode, view the phonebook
location to dial (see "Viewing the Phonebook" on page 39).

2) Press or on the handset. The

talk/flash speaker

displayed number is dialed.

3) To hang up, press

end

.

From Talk Mode

1) Press or .

talk/flash speaker

2) View the phonebook location to dial (see "Viewing the Phonebook" on page 39).

3) Press the soft key. The number displayed in the phonebook location is dialed.

DIAL

Movies
8007303456

Beethoven9/SPD1

BACK EDITDELETE

For New Zealand:

!

Telecom access
numbers are pre­programmed into
speed dial
locations as
follows.
Divert On : SPD1

!

Divert Off : SPD2

!

Block CID: SPD3

!

Messages: SPD4

!

Directory: SPD6

!

PHONEBOOK

4) To hang up, press

end.

Speed Dialing

You can program up to ten speed dial numbers in each handset and the base.
You must program a speed dial number before you can use the speed dialing feature. When
the phone is in standby mode, press and hold a number key ( - )
associated with the speed dial location desired until the phone number appears;
then press or The number stored in that speed dial location (SPD1 -

talk/flash speaker.

SPD0) is then dialed.

09

[40]

Editing or Erasing a Stored Name, Phone Number, Distinctive
Ring and Speed Dial

1) When the phone is in standby mode, press .

2) Use or the number keypad to select
desired phonebook entry (see "Viewing the Phonebook"
on page 39).

or

/vol/ /vol/

phonebook

Phonebook : 100
Search [A-Z/ / ]
Store [STORE]

BACK STORECOPY

a. Editing the stored data.

1) When the phonebook location to be edited appears, press

EDIT

the soft key. appears.

2) Follow the steps 3-7 under "Phone book (Storing phone
numbers, names, distinctive rings and speed dial)" on

page 35 to complete the editing operation.

3) Press the soft key. You will hear a confirmation tone.

OK

Store/Edit Name

b. Deleting the stored data.

1) When the phonebook location to be deleted appears,
press the soft key. appears.

2) Press to move the pointer to yes.

3) Press the soft key. You will hear a confirmation tone and appears.

DELETE

/vol/ /vol/

or

OK

Delete Memory?

[41]

Store/Edit Name
Uniden Corp

BACK OKDELETE

Delete Memory?
Yes

No

BACK OK

Deleted!

Copying Phonebook Locations

Copy Phonebook allows you to transfer stored phonebook locations from handset to other
handset without having to manually re-enter names and numbers. You can transfer one
memory (phonebook location) at a time, or all memory locations at once.

1) When the phone is in standby mode, press

2) Press the key.

3) Press to select the handset to

COPY

/vol/ /vol/

or

which you want to transfer the phonebook locations and
then press the soft key.

4) Press to select or

All Memory

select All Memory, appears on the

OK

/vol/ /vol/

or

, and then press the soft key. If you

OK

Are you sure?

display screen.
Press to select ,

/vol/ /vol/

and then press the soft key.
If you select , press ,
or the number key ( ) to select the phonebook

or

OK

One Memory

2-9 0

/vol/ /vo/

and

location you want to export and then press the
soft key.

5) The phonebook locations will be transferred to the
handset. appears along with the name of the

Copying

receiving handset. When the transfer is completed,

Done!

Appears.

phonebook.

One Memory

Yes

or

COPY

To which unit?

Handset #2

Handset #3

BACK OK

Copy Phonebook

One Memory

All Memories: xxx

BACK OK

To select
Phonebook
press [A-Z/ / ]

BACK

Copying

Handset #2

CANCEL

PHONEBOOK

!!This feature can

only be used with
multiple handsets.

If the memory
location on the
receiving handset
is full, and cannot
store the
phonebook
locations, you will
hear a beep.

[42]

!

If you answer a
call before the
Caller ID message
is received, the
Caller ID message
will not appear.
When the call is

!

received via a
Telephone
company that does
not offer Caller ID
service, the
caller’s phone
number and name
does not appear.
(This includes
some international
Calls.)
When the call is

!

received via a
private branch
exchange (PBX),
the caller's phone
number and name
may not appear.

Caller ID and CIDCW (Caller ID on Call Waiting)

You must subscribe to Caller ID services through your local telephone provider to
use these features. CIDCW (Caller ID on Call Waiting) is available in Australia only.
When the telephone rings, the Caller ID feature allows you to view the caller’s name, phone
number, date and time of call. With CIDCW (Caller ID on Call Waiting), you will hear a call
waiting tone while you are on a call, and the Caller ID data is displayed. To accept the
waiting call, press on the handset. Additionally, you can dial a number stored in
the Caller ID list or save data to your phonebook locations.

Important:

Memory locations for Caller ID messages and phonebook locations (including Speed Dials)
are common; you can store up to all 100 locations for each handset and the base. A Caller
ID message is not stored when you have stored 100 of the phonebook locations. When you
have stored all 100 of the phonebook locations and Caller ID messages in total, the earliest
Caller ID message is overwritten.

The date and time received

When the Caller ID message is received, the display shows the caller's phone number along
with the date and time. The incoming call information is stored in the Caller ID record. If the
Caller ID service includes the caller's name, the name will appear in the display (up to 15
characters).

talk/flash

Caller's name

Caller's phone number

[43]

10/12 11:20AM
Jane Smith
2145551234

You may receive any one of the following messages:

When a private name is received;

When a private number is received;

When a unknown name is received;

When a unknown number is received;

When invalid data is received;

When an overseas call(0000) is received (New Zealand only);

Data errors appear as " .”

Private

Private

Unavailable

Unavailable

Incomplete Data

[44]

overseas call

CALLER ID

! The number of

calls from the
same Caller ID
appears next to
the received time.
Once you view the
new message,
the number will
disappear.

Viewing the Caller ID List

The Caller ID list stores information for incoming calls - even unanswered calls. You can
store up to 100 Caller ID messages and phonebook locations (including Speed Dials) for
each handset and the base. You can view the Caller ID list through the handset and base
during a call or when the phone is in standby mode.

1) Press

2) To view the Caller ID messages in historical

cid .

The summary screen appears. The screen
shows the number of new messages and total
messages.

order (newest to oldest or from oldest to newest),
use, to scroll through the messages

/vol/ /vol/

from the latest to the earliest, or to

or

or

/vol/ /vol/

scroll back through the messages.

Caller ID

New:5

Total : 25

BACK DELETE

[45]

To view the Caller ID messages with alphabetical search, press the number key pad (
and ) with the letter associated with the first letter of the desired message.

0

Once you view the Caller ID list with alphabetical search, you cannot
switch back to historical order unless you exit and re-enter the operation.

3) To finish the viewing operation:
Press or the soft key or during a call).

end talk/flash

BACK

(

Deleting a Caller ID Message

1) When the phone is in standby mode, view the Caller ID
information to be deleted (see "Viewing the Caller ID List"
on page 45).

2) Press the soft key on.

DELETE

Delete Caller ID

appears

3) Press to select .or/vol/ /vol/ Yes

Delete Caller ID

Yes

No

BACK OK

29

-

!!During a call,

don’t press

end

or the call

will disconnect.

Once the Caller ID
data has been
deleted, the
information cannot
be retrieved

4) Press the soft key. You will hear a confirmation tone.

OK

[46]

CALLER ID

Deleting all Caller ID names/numbers

! Once the Caller ID

data has been
deleted, the
information cannot
be retrieved

1) When the phone is in standby mode, press

2) Press the soft key.

Delete All?

DELETE

Appears.

cid.

3) Press to chooseor/vol/ /vol/ Yes.

4) Press the soft key. You will hear a

OK

confirmation tone.

[47]

Caller ID

New:50

Total : 50

BACK DELETE

Delete All?
Yes

No

BACK OK

Using the caller ID Message List

Calling a Party from the Caller ID List

1) When the phone is in standby mode, select the

Caller ID message (see "Viewing the Caller ID
List" on page 45).

2) Press or . The displayed phone

talk/flash speaker

10/12 11:20AM
Jane Smith
2145551234

BACK STOREDELETE

Number will be dialed automatically

Talk mode

1) When the phone is in talk mode, select the Caller ID message you want to dial

(see "Viewing the Caller ID List" on page 45).

2) Press the soft key, and the number will be dialed.

DIAL

[48]

!!If the CallerID

message does not
have the number,
you cannot store
the message in the
Phonebook. If it
was received as
private/unknown
name, the
message will be
stored as <No
Name>.
Even if the 100
memory locations
are full, the
message will be
stored in the
Phonebook.
However, the
message will be
erased from the
Caller ID list.

CALLER ID

Storing Caller ID messages in the Phonebook

Messages shown in the Caller ID list can be stored in the phonebook. The phone number
and name of the party on the Caller ID list can be stored in memory.

1) When the phone is in standby mode, select the Caller ID message to be stored.
Then press the soft key. Store/Edit Name appears. If the Caller ID message is
already stored in memory, you will hear a beep and This data is already stored!! appears.
The number will not be stored.

2) To complete the setting, follow the steps 3-8 in "Phonebook (Storing Phone Numbers,
Names, Distinctive Rings, and Speed dial)" on page 35

STORE

[49]

Multi-Handset Features

The features in this section require a minimum of two handsets
to operate. To add additional handsets to your system, see
“Expanding Your Phone” on page 14.

Using DirectLink Mode

To use this feature you must enter the handsets into
Directlink Mode first. To enter Directlink Mode see page 17.

DirectLink call

1) When the phone is in DirectLink standby mode, press

Directlink

handset #1).

2) Select the handset to which you wish to DirectLink with by
pressing the number keys ( ). Your handset will then
page the other handset.

3) On the receiving handset, press ,
the soft key, or if Any Key Answer is
on, press any number key,

4) When you finish your conversation, press or the
soft key on either handset. Return the handset to the
cradle, or press soft key, and then soft key
to return to normal standby mode (canceling
DirectLinkmode).

soft key (example of DirectLink from

-

09

ANSWER

/tone/ /

CANCEL OK

talk/flash

,or .

end

END

Sun 12:00A

Handset #1

Directlink Mode

CANCEL

To DirectLink

a handset

press [1-9,0]

BACK

DirectLink

Handset #2

MULTI - HANDSET FEATURES

! Handsets can be in

Direct Link mode
while other
handsets are in
use.

DirectLink

END

[50]

3-Way Conferencing

The phone permits 3-way conversations between 2 handsets and an outside line.

1) Initiate the call normally. Once the call is in progress, other people can join the call.

2) To join a conference call, press or to use the handset speaker phone.

3) To leave a conference call, simply hang up as you normally would. All other parties will
remain connected.

4) To end a conference call completely, all local parties must hang up. The conference call
will also end when the calling party hang up.

talk/flash speaker

Intercom/Call Transfer Feature

The intercom feature lets you communicate with another handset without using the phone
line.

Intercom

1) With the phone in standby mode, press

2) Select the handset you want to talk with within 30

seconds. To select the handset press,
and then press the soft key. If you select , all other
handsets will be paged. An intercom tone
sounds. To cancel intercom, Press the soft key on
the initiating handset.

OK

[51]

intcom/hold.

/vol/ /vol/

CANCEL

or

All

To Intercom

Handset #2

Handset #3

BACK OK

MULTI - HANDSET FEATURES

3) To answer a page, press or or
the soft key.

ANSWER

talk/flash intcom/hold

,

Intercom

Handset #1

If Any Key Answer is enabled, pressing a number key,

/tone/ /

,or

enabled, you can answer the page simply by picking up

will answer the page. If AutoTalk is

ANSWER

the handset.

4) To hang up the intercom call, press or the soft key on either handset.

end

END

Call Transfer Feature

1) During a call, press on the handset.intcom/hold

2) Select the handset you want to talk with within 10

seconds. To select the handset press,

/vol/ /vol/

or OK

If you select , all other handsets and the base will be paged. An intercom tone

All

sounds. To cancel intercom, Press the soft key on the initiating handset.

3) To answer a page, press or or the soft key.

and then press the soft key.

CANCEL

talk/flash intcom/hold

, ANSWER

If Any Key Answer is enabled, pressing a number key, will answer
the page. If AutoTalk is enabled, you can answer the page simply by picking up the
handset.

4) To speak to the caller, press on the receiving handset.

talk/flash

Hold, to transfer

Handset #2

Handset #3

BACK OK

/tone/ /

,or

!!If you receive an

outside/intercom
call or page while
selecting the other
handset (or the
base), the
operation will be
canceled.

If the party does
not answer within
one minute, the
operation is
canceled.

[52]

! If the battery pack

is completely
drained, the
handset will not
beep when
paging.

Changing the Digital Security Code

The digital security code is an identification code used to connect the handset and the base
unit. Normally, setting the code is not necessary. In the rare situation that you suspect
another cordless telephone is using the same security code, you can change the code. To
change the digital security code:

1) De-register all the handsets you have (see “De-register the handset“ on page 26).

2) Register the handsets by following step 2-3 in “Registering the handset“ on page 15.

Find Handset

To locate the handset, press on the base when the phone is in standby mode.
All registered handsets beep for 60 seconds, and appears on the handset display.
To cancel paging, press any key on the handset or on the base.

find handset

Paging

find handset

Installing the Beltclip

To attach the beltclip

Insert the beltclip into the holes on each side of the handset.
Press down until it clicks.

To remove the beltclip

Pull either side of the beltclip to release the tabs from the holes.

Headset Installation

Your phone can be used with an optional headset. To use this
feature, insert the headset plug into the headset pack. Your phone is
ready for hands-free conversations. (Headset can be purchased
from a retailer or by visiting the web site. See page 56.)

[53]

Note on Power Sources

Power Failure

During the period that the power is off, you will note be able to make or receive calls with the
telephone.

Battery replacement and handling

When the operating time becomes short even after a battery is recharged, please
replace the battery. With normal usage, your battery should last about one year.
Please contact your place of purchase or the Uniden Parts Department for a
replacement battery.

Warning

To avoid the risk of personal injury or property damage from fire or electrical shock,
only use the Uniden battery model and Uniden adapter model specifically
designated for this product.

Caution

• Use only the specified Uniden battery pack (BT- 446).

• Do not remove the batteries from the handset to charge them.

• Never throw the battery into a fire, disassemble them, or heat them.

• Do not remove or damage the battery casing.

ADDITIONAL INFORMATION

[54]

Low Battery Alert

When the battery pack is very low, the phone is programmed to eliminate functions
in order to save power.

The battery pack needs to be charged when:

- The empty battery icon appears.

- Low Battery appears in the display.
If the phone is in standby mode, none of keys will
operate. If you are on a call, complete your conversation as
quickly as possible, and return the handset to the cradle.

Cleaning the battery charging contacts

To maintain a good charge, clean the charging contacts on the handset once a
month. Dampen a cloth with plain water. Gently rub the damp cloth over the
charging contacts until all visible dirt is removed.
Dry the contacts thoroughly before returning the handset to the
base.

Low Battery

Caution:

Do not use paint thinner, benzene,
alcohol, or other chemical products.
Doing so may discolour the surface of the
telephone and damage the finish.

[55]

General Information

Operating temperature:
0 °C to +50 °C (+ 32 °F to +122 °F)

AC Adapter Information

AC Adapter part number: AAD-041S for the base AAD-210 for the charger
Input Voltage: 230-240VAC 50Hz 230-240 VAC 50Hz
Output Voltage: 9V DC 350mA 9V DC 210mA

Battery Information

Battery part number: BT- 446
Capacity: 800mAh, 3.6V

• To avoid damage to the phone use only Uniden AAD-041S and BT- 446, and

AAD-210 with your phone.

• If the handset is left off of the base, the actual Talk mode duration will be

reduced respective to the amount of time the handset is off the base.

Recharge your phone on a regular basis by returning the handset to the base after
each phone call. When the operating time becomes short even after the battery is
recharged, please replace the battery. With normal usage, the battery should last
about one year.

Please contact your retailer for replacement adapters or batteries or visit our website
at .

www.uniden.com.au or www.uniden.co.nz

Specifications, features, and availability of optional accessories are all subject to
change without prior notice.

[56]

ADDITIONAL INFORMATION

Troubleshooting

If your phone is not performing to your expectations, please try these simple steps first. If these steps do not solve
your problem, visit our website for further information (www.uniden.com.au or www.uniden.co.nz).

Symptom Suggestion

The charge LED won't

illuminate when the handset
is placed in the cradle.

• Make sure the AC adapter is plugged into the charger and wall outlet.

• Make sure the handset is properly seated in the cradle.

• Make sure the charging contacts on the handset are clean.

The audio sounds weak.

Can't make or receive calls.

The handset doesn't ring or
receive a page.

During power failure, can't

make or receive a call.

• Move the handset and/ or base away from metal objects or appliances and try again.

• Make sure that you are not too far from the base.

• Make sure that you are not too far from the base.

• Make sure the line is not in use. If call is already using a line, you cannot use that
line to make another outside call.

• Check both ends of the base telephone line cord.

• Make sure the AC adapter is plugged into the base and wall outlet.

• Disconnect the AC adapter for a few minutes, and then reconnect it.

• De- register the handset (see “De- register the Handset” on page 26) and register
the handset (see “Register the Handset” on page 15).

• Make sure that you are not too far from the base.

• Charge the batteries in the handset for 15- 20 hours by placing the handset on
charging cradle.

• De- register the handset (see “De- register the Handset” on page 26) and register
the handset (see “Register the Handset” on page 15).

• Make sure to use corded base handset to make or receive a call.

• Make sure that TEL line cord is connected firmly.

[57]

Symptom Suggestion

Severe noise interference.

The Caller ID does not
display.

You cannot register the
handset
at the base.

The handset doesn't
communicate with other
Handsets.

An extra handset can't join
the conversation.

• Keep the handset away from microwave ovens, computers, remote control toys,
wireless microphones, alarm systems, intercoms, room monitors, fluorescent lights,
and electrical appliances.

• Move to another location or turn off the source of interference.

• The handset was picked up before the second ring.

• The call was placed through a switchboard.

• Call your local telephone company to verify your Caller ID service is current. There
may be a problem with your Caller ID service.

• Charge the battery pack for 15- 20 hours.

• De- register the handset (see “De- register the Handset” on page 26) and register
the handset (see “Register the Handset” on page 15).

• Make sure that you have registered all handsets.

• De- register the handset (see “De- register the Handset” on page 26) and register
the handset (see “Register the Handset” on page 15).

• Make sure there are not two handsets already using the conference feature.

• Make sure that another handset or base is not in privacy mode.

• Make sure that another handset is not in privacy mode.

TROUBLESHOOTING

[58]

Liquid Damage

Moisture and liquid can damage your cordless phone. In case of accidental submersion, please
read the following steps.

Case Action

If the handset or base is
exposed to moisture or
liquid, but it only affects the
exterior plastic housing.

Wipe off the liquid, and use as normal.

If moisture or liquid has
entered the plastic- housing
(i. e. liquid can be heard in
the phone or liquid has
entered the handset battery
compartment or vent
openings on the base).

Handset:

1) Remove the battery cover and leave it off for ventilation.

2) Remove the battery pack by disconnecting.

3) Leave the battery cover off and the battery pack disconnected for at least 3 days.

4) Once the handset is completely dry, reconnect the battery pack and he battery
cover.

5) Recharge the handset's battery pack for 20 hours before using again.

Base:

1) Disconnect the AC adapter from the base unit, cutting off electrical power.

2) Disconnect the telephone cord from the base unit.

3) Let dry for at least 3 days.

IMPORTANT:

to avoid charge interruption.

CAUTION:

cause permanent damage to the handset, base and the microwave oven. After
following these steps, if your cordless telephone does not work, please visit our
website for further information (www.uniden.com.au or www.uniden.co.nz).

You must unplug the telephone line while recharging the battery pack

DO NOT use a microwave oven to speed up the drying process. This will

[59]

Memory List

MEMORY LIST

[60]

Memo

[61]

Memo

MEMO

[62]

Index

0- 9

20 ring options 19
3- Way Conferencing 51

A

Animation screen 7
Anykey Answer 20
AutoTalk 20

B

Banner 21
Battery
Replacement and handling 54
Beltclip 53

C

Call transfer feature 52
Caller ID

Call Waiting 29
Caller ID services 43
Calling 48
CIDCW 43
Deleting 47
Setting 23
Storing 49

Viewing 45
Chain dialing 36
Clock 23
Contrast 21
Copying phonebook 42

D

De- register the handset 26
Dial mode 24
Digital security code 53
DirectLink 17
Distinctive ringer 20

E, F, G, H

Earpiece volume 31
Expanding your phone 14
General information 56
Global Setup 23
Hands- free conversation 28
Headset installation 53
Hold 29

I, J, K, L

Intercom 51
Key touch tone 22
Liquid damage 59

M, N, O

Making a call 27
Mute 32

P, Q

Page 53
Phonebook

Editing 41
Erasing 41
Making calls 40
Storing 35
Viewing 39

[63]

Privacy Mode 33

R

Receiving a call 27
Redialing a call 30
Register the handset 15
Ringer Adjusting 31
Room / baby monitor 18

S

Setting up 9

Base unit 10
Extra handset 14
Handset 11, 19

Menu options 17
Soft Key 8
Speed dialing 40

T, U, V, W, X, Y, Z

Transferring a call 52
Troubleshooting 57
Voice Mail Tone 34
Warranty 66

Main Menu Flow Chart

SUN 12:00A
Handset #1
New CID: 5

REDIAL

MENU

MENU

Directlink Mode

Room Monitor
Handset Setup

BACK

To enter
Directlink mode
press [ENTER]

BACK

SUN 12:00A

Handset #1

Directlink mode

CANCEL

OK

OK

ENTER

ENTER

Directlink

Directlink Mode

Room Monitor

Handset Setup

BACK

OK

OK

To Room Monitor

Handset #2

Handset #3
Handset #4
Handset #5
Handset #6

or or

Handset #7
Handset #8
Handset #9
Handset #0

BACK

[64]

Directlink Mode
Room Monitor

OK

OK

Handset Setup

BACK

<HANDSET SETUP>

Edit Voice mail

Ringer Tones
Distinctive Ring
Auto Talk
Anykey Answer
Banner
Contrast
Key Touch Tone
Animation Screen

BACK

OK

OK

OK

Main Menu Flow Chart

Room Monitor
Handset Setup

Global Setup

BACK

<Global SETUP>

Day Time&

or

CIDCW
Dial Mode
Name Tag
Insert 0

BACK

Australia Version

<Global SETUP>

Day Time&

or

CIDCW
Name Tag
Insert 0

BACK

New Zealand Version

Handset Setup
Global Setup

OK

Deregister HS

<Global Setup>

Deregister HS?

Yes

No

OK

Place handset
on main base
to register

OK

BACK

BACK

Deregistration

Complete

OK

OKOK

OK

OK

[65]

One Year Limited Warranty

Important:

Warrantor:
Warranty is only valid in the original country of purchase.

ELEMENT OF WARRANTY:

referred to as the Product), to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below.

WARRANTY DURATION:

after the date of original retail sale. This warranty will be deemed invalid if the product is;

PARTS COVERED:

All accessories (AC Adapter etc)are covered for 90 days only.

STATEMENT OF REMEDY:

effect, the warrantor at its discretion, will repair the defect or replace the product and return it to you without charge for parts
or service. THIS WARRANTY DOES NOT COVER OR PROVIDE FOR THE REIMBURSEMENT OR PAYMENT OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES. THIS GUARANTEE IS IN ADDITION TO AND DOES NOT IN ANY WAY AFFECT YOUR RIGHTS UNDER THE
CONSUMER GUARANTEE ACT.

PROCEDURE FOR OBTAINING PERFORMANCE OR WARRANTY:

should be shipped or delivered, freight pre-paid, with evidence of original purchase (eg. a copy of the sales docket), to
the warrantor at:

UNIDEN AUSTRALIA PTY LIMITED
SERVICE DIVISION

345 Princes Highway,
Rockdale,
NSW 2216,
AUSTRALIA
Fax: [phone]
www.uniden.com.au

Evidence of original purchase is required for warranty service.

Uniden Australia Pty Limited A.B.N. 58 001 865 498 Uniden New Zealand Limited

Uniden warrants to the original retail owner for the duration of this warranty, its DSS7815/DSS7815+1 (herein after

This warranty to the original retail owner only, shall terminate and be of no further effect 12 months

(A) Damaged or not maintained as reasonable and necessary,
(B) Modified, altered or used as part of any conversion kits, subassemblies, or any configurations not sold by Uniden,
(C) Improperly installed,
(D) Repaired by someone other than an authorized Uniden Repair Agent for a defect or malfunction covered by this warranty,
(E) Used in conjunction with any equipment or parts or as part of a system not manufactured by Uniden.

This warranty covers for one (1) year, the Base unit and handset ((DSS7815) or base, charger and handsets (DSS7815+1).

In the event that the product does not conform to this warranty at any time while this warranty is in

In the event that the product does not conform to this warranty, the Product

UNIDEN NEW ZEALAND LIMITED
SERVICE DIVISION

150 Harris Road,
East Tamaki,
Auckland,
NEW ZEALAND
Fax: [phone]

[66]

www.uniden.co.nz

WARRANTY

THANK YOU FOR BUYING A UNIDEN PRODUCT.

(c) 2005 Uniden Australia Pty Limited. Uniden New Zealand Ltd. Printed in China UPZZ01748BA(0)
