Uniden DS 805 User Manual

Start

Here!

Quick Start Guide next page -

DS 805

Optional Handset and Charge Base

Suits models DS815 DS825 DS845 DS875

QUICK START

GUIDE

INSTALLATION & SAFETY

Choosing the best location for your telephone

When choosing a location for your phone there are a number of appliances the phone

should not be near, and areas you should avoid.

This symbol indicates important operating and servicing instructions.

CHOOSE -

a central location

AVOID -

Television sets and other electronic appliances

AVOID -

Other Cordless phones

CHARGE -

the new phone for 14 - 20 hrs and raise the antenna before making a call.

Raise the Antenna

AVOID -

Microwave

ovens

AVOID -

Moisture

AVOID -

Computers

AVOID -

moisture

DON’T -

overload the power oulet.

(i)

AVOID -

multi

power boards

AVOID -

connecting more than

base unit telephones as

ringing may be impaired.

PRECAUTIONS

NOTE: Ringing will not be impaired by adding extra cordless handsets.

This page is a very condensed version of the Owners Manual. It is designed to allow you to get your phone installed and operating as quickly as possible

- however it does not attempt to explain any of the advanced features of the DS805.

Start

Here!

Quick Start Guide

Installing the

The AC Adaptor must remain plugged in and switched on at all times.

Use only the AC Adaptor supplied with this unit.

Power point

Installing the Handset Batteries

Connect the battery plug to the socket at the rear of the battery compartment.

Make sure the plug is the right way round.

The RED and BLACK battery wires must match the RED and BLACK printed on the phone case for the plug to fit properly.

Press firmly until it clicks into place.

Place the handset on the Base Unit and charge it uninterrupted for 20 hours.

Charge Base

Press the battery cover and slide it off.

Position the battery in the compartment and slide the cover into place.

Plug the power cable into the Base Unit, then into the wall power point.

Press the power cable into the curved recess under the Charge Base.

ION

fire,

T860

RED

BLACK

(ii)

Registering your phone

This additional Handset is able to be used in conjunction with models DS815, DS825, DS845 and DS875 cordless telephones.

The new handset needs to be allocated a handset number and registered to the Main Base (DS815, DS825, DS845 & DS875). The Main Base has a telephone cord plugged

into it and also has an Antenna, not to be confused with the additional charger(s).

DS815 Main Base

The original handset supplied with the Main Base is already registered as handset 1, this leaves handset numbers 2 - 7 available. It is very important to allocate each handset a different number to enable functions such as Call Transfer.

Registration Process Follow this process for each DS805 additional handset that needs to be registered to the Main Base.

1. Remove the handset from its charger

2. Press flash/reg on the handset (Fig 1). 3 Press the number 2 (Fig 2) for handset 2.

4. Place the handset in the Main Base Unit (Fig 4).

5. Press and hold the Registration button located on the back of the Main Base unit near the DC power jack (Fig 4). Hold the Registration button in until a long beep confirms the handset has been registered.

Fig 1.

DS805 ChargerDS845 Main BaseDS825 Main Base

If you have additional handsets, repeat the same process, but at Step 2 select a number from 3 - 7 to register the next handset as (fig 3)

Fig 2.

The Registration process needs to be completed within 15 seconds, 3 beep tones will indicate that the time has been exceeded. Please start the process again.

Fig 3.

(iii)

HANDSET: 1 NEW: 1 TOTAL: 1

Fig 4.

After Registration the handset number is shown on the Display screen either during a call or while the handset is charging (Fig 5).

Charging On a Call

TALK HIGH 1

Fig 5.

If a handset is registered at any time as handset 1, all other handsets will need to be registered again from Step 1.

Handset Registration number displayed

CONTENTS

Installation & Safety Quick Start Guide Contents Introduction

Welcome Features

Included in your Package Battery Maintenance

Preparing the Battery Pack Battery use time (per charge) When the Battery Charge becomes Low Cleaning the Battery Contacts Adjusting the Ringer and Earpiece Volume Installing the Belt Clip Headset Installation

Using Your New Phone

Making and Receiving Calls Call Transfer

OF YOUR OWNERS MANUAL

Redialling a Call Travelling out of Range Keylock / Unlock Paging Storing Phone Numbers and Names Making Calls with Memory Dialling Editing a Stored Name and Phone Number Erasing a Stored Name and Phone Number Caller ID Options - Dial Prefix

Troubleshooting Warranty

i ii, iii

1 4 4 4 5 6 6 6

6 6 7 7 7 8 8 9 9 10 10 10 11 12 13 14 15 17 18 19

CONTENTS

The DS805 is an optional handset and charger. It can only be used in conjunction with a compatible telephone such as the DS815, DS825, DS845 and DS875.

CONTROLS & FUNCTIONS

28/09 12:30 01 JIM STATEN 02 9597 9035

memory

vol

talk

abc

ghi

jkl

pqrs

tuv

oper

tone

redial/p

options

select

flash/ reg

cid

def

mno

wxy

9 #

delete/ page

Headset jack

Belt clip slot

Battery compartment

Memory key

Talk key

Redial/Pause key

Handset aerial

Handset speaker

Display screen

Flash/Reg key

CID key

Volume control keys

Alpha Numeric keypad

Delete/Page key

Select key

Handset Microphone

Options key

Charge Base

Charging contacts

Charge LED

Non functional key

AC power adaptor input

Rear

Top

900MHz

DIGITAL SPREAD SPECTRUM

charge

19 20

WELCOME

Congratulations on your purchase of the Uniden DS805 extra handset.

This phone is designed for reliability, long life and outstanding performance utilising the latest in 900MHz Digital Spread Technology.

The DS805 is an optional handset and charger . It can only be used in conjunction with a compatible telephone such as the DS815, DS825, DS845 and DS875.

FEATURES

900MHz Digital Spread Spectrum Technology

Caller ID Function

60 Number Caller ID Memories

Backlit Keypad

3-Line, 16 Character Backlit Handset Display

TO YOUR NEW PHONE

32 Digit Redial

3 Redial Memories

Flash

Pause

10 Days Standby Battery Life

4.5 Hours Talk Time

Handset Earpiece and Ringer Volume Control

Hearing Aid Compatible

Name Tagging

29 Alpha Numeric Speed Dial Memories

Digital Spread Spectrum Technology

utilises a digital transmission and a “wider frequency band” compared to a “single narrow band” 30/39 Standard Analogue transmission. The result is a more secure conversation with the clarity of digital sound, extended range, and minimal interference from other cordless phones.

Random Code

digital security automatically selects one of over 16 million codes for the handset and base. This feature prevents unauthorised calls as a result of your phone being activated by other equipment.

INTRODUCTION
