Uniden DECT 3136BT, DECT 3136BT+1, DECT 3136BT+2, DECT 3136BT+3, DECT 3136BT+4 Owner's Manual

For more exciting new products please visit our website:

Australia: www.uniden.com.au

New Zealand: www.uniden.co.nz

DECT 3136BT

1

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:

• This unit is NOT waterproof. DO NOT expose this unit to moisture.

• DO NOT expose this unit to rain.

• Do not use this product near water, for example, near a bath tub, wash

bowl, kitchen sink or laundry tub, in a wet basement or near a swimming
pool.

• Avoid using a telephone (other than a cordless type) during an electrical

storm. There may be a remote risk of electric shock from lightning.

• Do not use the telephone to report a gas leak in the vicinity of the leak.

• Use only the power cord and batteries indicated in this manual. Do not

dispose of batteries in a fire. They may explode. Check with local codes
for possible special disposal instructions.

• Do not place the handset in any charging cradle without the battery

installed and the battery cover securely in place.

SAVE THESE INSTRUCTIONS!

General Notices for New Zealand Model:

• The grant of a NZ Telepermit for any item of terminal equipment

indicates only that Telecom has accepted that the item complies with
minimum conditions for connection to its network. It indicates no
endorsement of the product by Telecom, nor does it provide any sort
of warranty. Above all, it provides no assurance that any item will work
correctly in all respects with another item of Telepermitted equipment
of a different make or model, nor does it imply that any product is
compatible with all of Telecom’s network services.

• The maximum volume setting of this telephone exceeds the Telecom

specified volume requirement. Telecom takes no responsibility for the
high volume available on this telephone, who believe this telephone is
too loud should contact the manufacturer at the website indicated on
owner’s manual warranty page.

• For telephone networks other than Telecom there may be a charge

incurred for local calls if the Insert 0 feature is on. Turn Insert 0 off.

• This equipment may not provide for the effective hand-over of a call to

another device connected to the same line.

2

WHAT’S IN THE BOX?

DECT 3136BT
base with
answering
system and
cordless handset

Not Pictured:

• Rechargeable battery

Accessory handset
and charger

Not Pictured:

• Rechargeable

battery
(BT- 694, BT­694s or BT-694n)

• AC adaptor

(AAD-600S(M))

• Battery cover

If you purchased
model number:

You should
have:

(BT-694, BT-694s or
BT-694n)

DECT 3136BT None

DEC T 313 6 BT+1 1 of each

• AC adaptor

(PS-S0635YL3)

• Telephone cord

• Wall mount bracket

• Battery cover

DEC T 313 6 BT+2 2 of each

DEC T 313 6 BT+3 3 of each

DEC T 313 6 BT+4 4 of each

DECT 3136BT+5 5 of each

• If any items are missing or damaged, contact your place of purchase

immediately. Never use damaged products!

• Need help? Get answers at our website:

www.uniden.com.au for Australian model
www.uniden.co.nz for New Zealand model.

3

CONTENTS

INSTALLING YOUR PHONE .................................................................. 5

Setting Up the MobileLink Bluetooth Connection ....................................................... 6

GETTING TO KNOW YOUR PHONE ...................................................... 8

Parts of the Handset .............................................................................................................. 8

Parts of the Base .................................................................................................................... 11

Using the Handset Menu .................................................................................................... 12

USING YOUR PHONE .......................................................................... 15

Using the Caller ID and Redial Lists ................................................................................. 16

Using Call Waiting ................................................................................................................. 17

Using the Phonebook .......................................................................................................... 17

USING SPECIAL FEATURES ................................................................ 19

Power Failure Back Up System ......................................................................................... 19

DND (Do Not Disturb) Mode ............................................................................................. 20

Multihandset Features ........................................................................................................ 20

Conference Calling (1 Line) ............................................................................................... 21

Conference Calling (2 Line) ............................................................................................... 21

Call Transfer ........................................................................................................................... 22

Privacy Mode ........................................................................................................................ 22

Handset to Handset Intercom ........................................................................................ 22

Chain Dialing ......................................................................................................................... 23

Voice Message Notification .............................................................................................. 23

USING THE ANSWERING SYSTEM .................................................... 24

Answering System Options (Ans. Setup) ...................................................................... 24

Personalizing the Greeting ............................................................................................... 25

Accessing the Answering System .................................................................................... 25

Getting Your Messages ....................................................................................................... 26

IMPORTANT INFORMATION ............................................................ 29

Solving Problems ................................................................................................................. 29

Resetting Handsets .............................................................................................................. 31

Registering Handsets .......................................................................................................... 31

AC Adaptor and Battery Information ............................................................................. 32

Wall Mounting the Base ..................................................................................................... 33

INDEX ................................................................................................. 35

ONEYEAR LIMITED WARRANTY ...................................................... 36

4

INSTALLING YOUR PHONE

Charge the Battery

1. Unpack all handsets, battery packs, and battery
covers.

2. If you need to remove a cover, press in on the
notch and slide the cover down and off.

3. Line up the battery connector with the jack
inside the handset; the connector only fits one
way.

4. Push the connector in until it clicks into place;
tug gently on the wires to make sure the battery is securely connected.

5. Replace the battery cover and slide it into place.

6. Use an AC adaptor to connect the power jack on the base to a regular
indoor (240V AC) power outlet. Connect any chargers the same way.

7. Place a handset in the base with the display facing forward. If the display
doesn’t light up, reseat the handset or connect the base to a different
outlet. For 2 or more handsets, place each handset in a charger.

# Charge all handsets completely (about 15 hours) before using.

Connect the Telephone Cord

Use the telephone cord to connect the TEL LINE jack on the base to a
standard telephone wall jack.

Test the Connection

1. Pick up the handset and press HOME/FLASH. The handset sounds a dial
tone, and the display shows Talk.

- If you don’t hear a dial tone or the display says Check Tel Line, check the
connection between the base and the phone jack.

2. Make a quick test call. (Press END to hang up.)

- If there’s a lot of noise, check for interference (see page 30).

3. Test all handsets the same way. If you can’t get a dial tone, move the
handset closer to the base.

5

Setting Up the MobileLink Bluetooth Connection

The new DECT 3136BT with MobileLink technology can connect with
mobile phones that support the Bluetooth V2.1 handsfree profile.

If you are not certain of the profiles supported by your Bluetooth phone or if
you have difficulty pairing your phone to the DECT 3136BT see the manual
that came with your phone.

With the MobileLink feature, you can essentially treat your mobile phone
as a second line. You can use the DECT 3136BT handset to make and
receive calls on your mobile phone number, put mobile calls on hold, and
transfer calls to other handsets. See page 7 for more information.

Bluetooth wireless devices have a maximum range of about 33 feet (10 m);
the actual range will vary depending on local conditions (obstacles, battery
power, interference, etc.).

Pair your Bluetooth phone

Pairing “introduces” the Bluetooth device and DECT 3136BT and gives
them permission to connect to each other. In most cases, once you pair
a phone to the DECT 3136BT, these two devices connect automatically
whenever they detect each other. (If you have to manually reconnect each
time, check the Bluetooth settings on your mobile phone.) You can pair
your Bluetooth devices through the DECT 3136BT handset.

1. Press MENU/SELECT to display the handset’s main menu.

2. Select the Bluetooth Setup menu, then select the Add Mobile submenu.
The base goes into pairing mode when the handset displays Search &
select from Mobile DECT 3136BT PIN: 0000.

3. On your Bluetooth phone, start a search for other Bluetooth devices.
(This process may take several seconds and it will be different for each
mobile phone. See your phone owner’s manual for detailed instructions.)

4. Your phone should discover a device called DECT 3136BT or Handsfree
device. When your phone asks if you want to pair with this device,
answer yes.

5. If your phone prompts you for a PIN code or password to pair with the
DECT 3136BT enter 0000 (four zeroes).

6. When your phone accepts the Bluetooth connection, the DECT 3136BT
sounds a confirmation tone. The Bluetooth device number icon on the
base and the handset display light up.

6

# Most mobile phones automatically transfer the audio to a Bluetooth device

as soon as it pairs; if yours does not, look in your mobile phone’s Bluetooth
setup for a “transfer audio” or “send audio to device” option.

To Test the Connection

1. Pick up the handset from the cradle.

2. Dial the number you want to call, then press MOBILE on the handset. You
may not hear a dial tone or ringing, but the handset display says Talk.

3. Make sure the call connects and you can hear clearly. (When you are
finished, press END/CLEAR to hang up.)

4. The DECT 3136BT remembers the pairing information for your mobile;
if it loses connection with your phone for any reason (e.g., the mobile
phone travels out of range, runs out of charge, etc.), the DECT 3136BT
can automatically reconnect the next time your phone becomes
available.

Using the DECT 3136BT+1 with two Bluetooth phones

The DECT 3136BT can save the pairing information for two different
Bluetooth phones, but it can only use one mobile line at any given time. For
example, if you pair the DECT 3136BT to two Bluetooth phones, when you
press MOBILE on the handset, the DECT 3136BT asks which phone you want
to connect to.

If you are using the DECT 3136BT to talk on one Bluetooth phone, the
DECT 3136BT will not ring if a call comes in on another phone.

You can set a different ring tone for each paired mobile phone (see page

13).

To pair another Bluetooth phone, just repeat the pairing procedure with
the new phone. (If the paired phone interferes when you’re pairing the new
one, just turn off Bluetooth on the paired phone until you finish pairing the
new one.)

7

GETTING TO KNOW YOUR PHONE

Parts of the Handset

Earpiece

LCD

MENU/

SELECT

HOME/
FLASH

PHONEBOOK

12-key

dial pad

REDIAL/PAUSE

CLEAR

END

UP

MOBILE

CID

DOWN

#DND

SPEAKER

Microphone

8

MESSAGE/MUTE

Charging

contacts

Key Icon What it does

PHONEBOOK

SPEAKER

HOME/FLASH

DOWN

REDIAL/PAUSE

UP

• In standby or during a call: open the phonebook.

• In the menu: go back to the previous screen.

• When entering text: move the cursor to the left.

Switch a normal call to the speakerphone (and back).

• In standby: start a telephone call on your land line (get

a dial tone).

• During a call: switch to a waiting call.

• In standby: decrease the ringer volume.

• During a call: decrease the audio volume.

• In any menu or list: move the cursor down one line.

• In standby: open the redial list.

• When entering a phone number: insert a 3-second

pause.

• In standby: increase the ringer volume.

• During a call: increase the audio volume.

MENU/SELECT

END/CLEAR

MOBILE

CID

MESSAGE/MUTE

• In any menu or list: move the cursor up one line.

• In standby: open the menu.

• In the menu or any list: select the highlighted item.

• During a call: hang up.

• In the menu or any list: go to previous menu.

• When entering text or numbers: erase the character at

the cursor.

• In standby: start a telephone call using a paired

Bluetooth phone.

• While a paired phone is ringing: answer the incoming

call.

• During a MobileLink call: switch to a waiting call.

• In standby: or during a call: open the Caller ID list.

• When entering text: move the cursor to the right.

• In standby: access your answering system.

• During a call: mute the microphone.

• While the phone is ringing: ignore this call (mute the

ringer).

#DND

Silence the ringers on the base and all handsets for a
specific period of time.

Press and hold to lock/unlock the keypad

9

Reading the Display

Status

icons

Current

call info

Time &

date

CID
record
status

The table shows the possible
status icons and what they
mean. Since the icons appear
based on what the phone is
doing, you won’t see all the
icons at the same time.

Icon What it means

Bluetooth device #1 or #2.

Home phone line.

The signal from base is 1) strong or 2) weak.

P

T

[Aa] - [aA]

The ringer is turned off and will not ring for new calls.

The speakerphone is on.

You have a voice message waiting.

Privacy Mode is on: no other handset can join the
call (see page 22). If the T-coil mode is ON , then T
will be displayed on the LCD and not P.

T-coil mode is on (see page 13).

The battery is 1) fully charged, 2) half charged, 3)
getting low, or 4) empty.

The handset is using ECO (power save) mode.

Enter 1) capital or 2) lower case letter (see page 14).

10

Appears when you are entering text.

Parts of the Base

1 2

DELETE

UP

DOWN

FWD

PLAY/STOP

REV

FIND HS

ANS

ON/OFF

BLUETOOTH

DEVICE NUMBER

Charging
Contacts

Key What it does

FIND HS

ANS ON/OFF

REV

In standby: page all handsets

In standby: turn the answering system on or off.

• While playing a message: restart the message.

• In the first 2 seconds of a message: play the

previous message.

PLAY/STOP

• In standby: start playing messages.

• While playing a message: stop playing messages.

• When the phone is ringing: ignore this call (mute

the ringer).

DELETE

• While playing a message: delete this message.

• In standby: delete all messages.

FWD

DOWN (

-)

While playing a message: skip to the next message.

• In standby: decrease the ringer volume.

• While playing a message: decrease the speaker

volume.

UP (+)

• In standby: increase the ringer volume.

• While playing a message: increase the speaker

Bluetooth Device
Number

• The number indicates the Bluetooth device

volume.

number linked to the DECT3136.

11

Using the Handset Menu

Press

Intercom

MENU/SELECT

open the menu.

to

Press

MENU/SELECT

the current option.

to choose

BluetoothSetup

AddMobile

Press

PHONEBOOK

go back a screen

press
the menu.

OR

END

to

to exit

Use UP and
rotate through the

DOWN

options.

to

If you don’t press any keys for about 30 seconds, the handset exits the
menu. During a call, use PHONEBOOK to back out of the menu without hanging
up.

Intercom Menu

Search&Select
fromMobile

The Intercom menu lets you connect 2 handsets without using the phone
line. Any handset can connect to an intercom call, but only two handsets
can be in the call at one time.

Bluetooth Setup Menu

The Bluetooth Setup menu provides the following operations:

Menu Option What it does

Add Mobile Pairs mobile phone with base.

Privacy Setup Determines which handsets will ring when a mobile

call comes in (default = off).

Download PB Downloads the mobile phonebook to the base.

Remove Mobile Un-pairs a mobile phone from the base.

12

Handset Setup Menu

You can change these settings separately for each handset.

Menu Option What it does

T-coil Turn on T-coil mode to reduce noise on hearing aids

equipped with a telecoil (T-coil) feature. T-coil mode
shortens talk time, so keep your battery fully charged.

Ringer Tones Choose this handset’s ring tone. As you highlight

each ring tone, the phone plays a sample. When you
hear the tone you want, press MENU/SELECT.

Personal Ring Turn on personal ring so you can assign a special

ring tone to people in your phonebook. With Caller ID,
this handset uses the assigned tone when the person
calls.

Auto Tal k Have this handset answer a call when you pick it up

from the cradle (without pressing any buttons).

Any Key Answer Have this handset answer a call when you press any

key on the 12-key dialpad.

Banner Change the name used on the handset’s display.

Key Touch Tone Have the keypad sound a tone when you press a key.

Answering Setup Menu

Refer to page 24 for details on setting up your answering system.

Date & Time Menu

Use this menu to set the clock. Enter the date and time (DD/MM/YY);

AM

or

PM

select

. Use

it. If you have CID service, you can set it to provide the time (

CID Time Setting)

.

CID

to move the cursor past a digit without changing

Global Setup/

13

Global Setup Menu

The settings on this menu affect all handsets. Only one handset at a time
can change these menu options.

Edit Voice Mail Enter, edit your voice mail access number (page 23)

Set Line Mode Do not change this setting unless instructed to by

customer service.

VMWI Reset Reset the Voice Message Waiting Indicator (see

page 23).

Insert 0 This feature adds “0” or “00” at the beginning of the

number received from Caller ID. The default setting
for New Zealand is ON. The default setting for
Australia is OFF.

CID Time Setting Select Set by Caller ID to allow phone network to

automatically set cordless phone system time.

Entering Text on your Phone

Use the 12-key dial pad anytime you want to enter text into your phone (a
name in the phonebook, the handset banner, etc.). If two letters in a row
use the same key, enter the first letter; wait for the cursor to move to the
next space and enter the second letter.

To... Press...

move the cursor left

move the cursor right

erase the character at the cursor

erase the entire entry

enter a blank space

switch between upper and lower
case letters

PHONEBOOK

CID

END/CLEAR

and hold END/CLEAR

#.

*

rotate through the punctuation and
symbols

14

0.

USING YOUR PHONE

This section explains the most common functions on the phone.

To... Earpiece Speakerphone

make a call, dial the
number, then

answer a call

hang up

ignore the call (mute
the ringer)

switch to/from the
speaker

mute the microphone

put a call on hold

Press HOME/FLASH. Press SPEAKER.

Press HOME/FLASH. Press SPEAKER.

Press END/CLEAR or place the handset in the
cradle.

Press MESSAGE/MUTE while the phone is ringing.

Press SPEAKER.

Press MESSAGE/MUTE.

Press again to turn the microphone back on.

Press MENU/SELECT and select Hold Transfer
(after 2 min 50 secs on hold the call will be
disconnected).

return to a call on hold

Press HOME/FLASH. Press SPEAKER.

Finding a Lost Handset

With the phone in standby, press
1 minute; to cancel, press

FIND HS

FIND HS

on the base. All handsets beep for

again or press any handset key.

Changing the Volume

To change the... When... Press...

earpiece or speaker
volume for each
handset

base speaker volume

ringer volume for each

you are listening to that
earpiece or speaker
(playing messages, etc.)

the phone is in standby

UP

to increase the

volume.

DOWN

to decrease it.

handset or the base

If you turn the ringer all the

(

way down, that particular
ringer turns off.)

15

Using the Caller ID and Redial Lists

Caller ID (CID) is a service available from your telephone provider that
shows the phone number (and sometimes the caller’s name) of incoming
calls. Contact your telephone provider for more information.

Caller ID list Redial list

• The phone saves the information

for the last 50 received calls to the

CID list. The

NEW

icon marks any
calls received since the last time
you checked the list.

• All handsets share the same CID

list so only one handset can access
the list at a time.

• In standby, handsets show how

many calls came in since the last
time you checked the CID list.

To... Press...

open the CID list

open the redial list

scroll through the lists

CID.

REDIAL/PAUSE.

DOWN

to scroll from newest to oldest.

• Each handset remembers

the last 10 numbers you
dialed on it.

• Only one handset can

access its redial list at a time

UP

to scroll from oldest to newest.

dial the highlighted number

close the lists

HOME/FLASH or

PHONEBOOK.

SPEAKER.

For individual record options, highlight a number and press MENU/SELECT.

Delete Entry Erase the number from the list.

Store Into PB Add the number to the phonebook. The

handset prompts you to edit the name and
number and select a personal ring

Delete All Erase all numbers from the list.

16

Using Call Waiting

• Call Waiting, a service available from your telephone provider, lets

you receive calls while you are on another call. Caller ID on Call
Waiting(CIDCW) service displays Caller ID information for a waiting call.

• If you get a Call Waiting call, the phone can sound a tone and display

any CID information received for the waiting call.

For Australia:

Press HOME/FLASH and then press 2 to accept the waiting call. The first caller
is put on hold, and you will hear the new caller after a short pause. To
return to the original caller, press HOME/FLASH and then 2 again.

For New Zealand:

Press HOME/FLASH to accept the waiting call. The first caller is put on hold,
and you will hear the new caller after a short pause. To return to the
original caller, press HOME/FLASH again.

Using the Phonebook

The phone can store up to 100 entries in its phonebook. All handsets share
the same phonebook, so only one handset can access it at a time.

To... Press...

open/close the phonebook

scroll through the entries

PHONEBOOK.

DOWN

to scroll through the entries from

A to Z.

UP

to scroll from Z to A.

jump to entries that start with a
certain letter

dial the current entry

edit the current entry

delete the current entry

the number key corresponding to the
letter you want.

HOME/FLASH or SPEAKER

MENU/SELECT, then select Edit

MENU/SELECT, then select

Delete

. When
the phone prompts you to confirm,
select

Yes.

17

Adding Phonebook Entries

With the phone in standby, open the phonebook. Press MENU/SELECT and
select

Create New.

Enter a name, number, and then assign a personal ring

if desired.

• Enter the phone number (up to 32 digits) exactly as you would dial it.

• If you need the phone to wait before sending the next set of digits, press

REDIAL/PAUSE to insert a 3-second pause. You can insert multiple pauses,

P

but each one counts as a digit (you’ll see

in the display).

Downloading Cellular Phonebooks

You can download up to 700 names per cellular phonebook (1400 total) to
the phonebook.

1. Press MENU/SELECT and select Bluetooth Setup. Scroll to Download PB and
select it.

2. The Bluetooth icon on the LCD display will show the device number of
the downloading phonebook (for Bluetooth device #1:

3. Download PB Completed displays when the download is completed.
Download PB Failed displays if the download fails.

Deleting All the Phonebook Entries

With the phone in standby, open the phonebook. Press MENU/SELECT and
select

Delete All

. When the phone prompts you to confirm, select

Yes

.

18

USING SPECIAL FEATURES

Power Failure Back Up System

When a power failure occurs, the charged handset temporarily supplies
power to the base unit. You can then make and receive calls using a
handset. However, none of the keys on the base unit are functional during
the power failure mode.

When a power failure occurs, place the charged handset on the base, the
handset LCD backlight is illuminated for about 10 secs and the message
“Supplying power Handset >> Base” is displayed on the LCD.

After 3 seconds, the message “Please don’t pick up the handset” is
displayed on the LCD.

If the handset is lifted from the base during the power back up mode, the
message “Please put on the base cradle” will be displayed on the LCD.

If the battery level is low, the unit will not work efficently during the power
failure mode. In addition, in case the handset battery power runs out, we
recommend connecting a corded-type telephone to the same telephone
line.

Making Calls

To make a call during the power failure mode, follow the steps given below:

1. Taking care not to lift the handset from the base, press TALK/FLASH (the
speakerphone is turned on automatically). Dial the number.

2. After you finish, press END.

When more than one handset is registered:

• You should leave one handset on the base unit for supplying the power,

and use another handset for making calls. Please refer to the “Using
your Phone’ section on page 15 for details.

• During a call with the handset placed on the base unit (power back-up

mode), the call may be disconnected if you touch the handset. In such a
case, try to call back.

• The range of the base unit is limited during a power failure. Please use

the handset close to the base.

Redial List/Phone book

1. Place the handset on the base and press REDIAL/PAUSE or phonebook icon.

2. Press the

3. Press HOME/FLASH to dial out the number.

or key and select the desired number.

19

# Some of the functions are not available under the power failure back up

stem. Examples are:

• You cannot edit the phonebook (For eg, store a number).

• Redial/CID will not be stored.

• You cannot operate the Answering System.

• You cannot operate the Bluetooth function.

DND (Do Not Disturb) Mode

You can silence the ringers on the base and all handsets for a specific
period of time; the answering system answers any incoming calls without
playing anything through the speaker.

#

1. With the phone in standby, press and hold

DND on any handset. The

phone prompts you to select the number of hours (1 - 9 or
that you want it to stay in the DND mode.

2. To confirm, press

DND Mode On

3. After the selected number of hours, the phone automatically exits DND
mode. To exit DND mode manually, press and hold

#

DND or just wait about 5 seconds. The phone displays

on each handset.

#DND

Always On

again.

)

# If the phone is in the DND mode and you turn off the answering system, the

phone exits the DND mode.

Multihandset Features

# To use the features in this section, you need at least 2 handsets.

• Your base supports a total of 6 cordless handsets: the one that came

with the base and up to 5 DECT 3105 accessory handsets.

• You must register accessory handsets to the base before using them.

(Handsets that came packaged with the base are already registered.)

• Handsets that aren’t registered display a Not Registered message. For

registration instructions, see page 31, or see the accessory handset
manual.

• If a handset was ever registered to a base, you must reset it before it

can register to a new base; see page 31, or see the accessory handset
manual.

20

Conference Calling (1 Line)

• When an outside call comes in on the land line or the via a mobile, two

handsets can join in a conference call with the outside caller.

• To join a call that’s already in progress, just press

HOME / FLASH

(to join a Landline call) or

MOBILE

(to join a Mobile call).

SPEAKER

on the base or

• To leave the conference call, hang up normally; the other handset

remains connected to the call.

Conference Calling (2 Line)

A landline call and a mobile call can be connected in conference using the
Line Conference feature.

• When an outside call comes in on the land line and then another

outside call via a mobile, two handsets can join in a conference call with
the outside callers (4-way conference).

• To conference a second outside call, answer the second line, press

MENU/SELECT and then select Conference.

• To join a call that’s already in progress, just press

Speaker.

• To leave the conference call, hang up normally; the other handset

remains connected to the call.

HOME / FLASH

or

21

Call Transfer

To... Press...

transfer a call

cancel a transfer

accept a transferred call

Press MENU/SELECT and select Hold/Transfer.
The phone puts the call on hold and prompts
you to select the handset you want to page.
When the other handset accepts the call,
you’ll be disconnected (press HOME/FLASH to
rejoin the call).

HOME/FLASH to return to the call.

END/CLEAR to answer the page and speak to

the other handset. Then, press HOME/FLASH to
speak to the caller.

Privacy Mode

• To activate privacy mode on a call in progress, press MENU/SELECT then

select Call Privacy. As long as privacy mode is on, you’ll see a in the
display, and no other handsets can join your call.

• Privacy mode turns off automatically when you hang up; you can also

turn it off by pressing MENU/SELECT and selecting Call Privacy.

# If the T-coil mode is ON , then T will be displayed on the LCD and not P.

Handset to Handset Intercom

• Whenever the phone is in standby, you can make an intercom call

between handsets without using the phone line.

• You can make an intercom call from any handset, but only two handsets

can be in an intercom call at any time.

• If an outside call comes in during an intercom page, the phone cancels

the page so you can answer the incoming call.

• If an outside call comes in during an intercom call, press HOME/FLASH to

hang up the intercom call and answer the outside call.

To... Press...

make an intercom page

MENU/SELECT and select Intercom. Then,
select the handset you want to talk with, or

All

to page all handsets at the same time

cancel a page

answer a page

end an intercom call

22

END/CLEAR

HOME/FLASH or select Intercom from Menu.

END/CLEAR. Both handsets return to standby.

Chain Dialing

If you often have to enter a series of digits or a code number during a
call, you can save that code number to a phonebook entry and use the
phonebook to send the code number.

1. Enter the code number (up to 32 digits) into the phonebook just like a
regular phonebook entry. Be sure to enter the code number into the
phonebook exactly as you would enter it during a call.

2. When you hear the prompt that tells you to enter the number, open the
phonebook and find the entry that contains your code number.

3. Press

MENU/SELECT

to send the code. If you change your mind, just close

the phonebook.

Voice Message Notication

If you subscribe to a voice mail service, your phone displays the voice
mail icon (
Frequency-Shift Keying (FSK) notification.

After you listen to your messages, the message icon turns off. If it doesn’t,
you can reset it: With the phone in standby, open the menu and select

Global Setup

) when you have a new message. This feature supports

; select

VMWI Reset

, then select

Yes.

23

USING THE ANSWERING SYSTEM

Answering System Options (Ans. Setup)

You can set or change the answering system options from any handset.
Just open the menu and select
following:

Menu Option What it does

Security Code Enter a 2-digit PIN so you can access your

answering system from any touch-tone phone (see
page 27).

Ring Time Set the number of rings (6, 9, or 12) before the

system answers. Toll Saver makes the system
answer after 2 rings if you have new messages or
after 4 rings if you don’t.

Record Time Set the amount of time (1 or 4 minutes) callers have

to leave a message. Choose Announce Only if
you don’t want the system to let callers to leave a
message.

Message Alert Have the system beep every 15 seconds when you

Answering Setup

. Select one of the

have a new message. The alert stops after you
listen to all your new messages or if you press any
key on the base.

Call Screen Turn on the call screen feature so you can hear

callers as they leave messages on the base
speaker (see page 27).

Ans. On/off Turn your answering system on or off.

Record Greeting Record an outgoing message or greeting (see page

25).

Greeting Options Switch greetings or delete your greeting (see page

25).

24

Personalizing the Greeting

Your personal outgoing message or greeting can be from 2 to 30 seconds
long. If you don’t record a greeting, the system uses a pre-recorded
greeting: Hello, no one is available to take your call. Please leave a

message after the tone.

To... Follow these steps:

Record a personal
greeting

Switch between
greetings

Delete your
greeting

1. Open the menu with the phone in standby. Select

Answering Setup

2. Press MENU/SELECT to start recording. Wait until the
system says,“Record greeting” before speaking.

3. Press MENU/SELECTto stop recording. The system
plays back your new greeting.

4. To keep the greeting, press END/CLEAR. To re­record it, press MENU/SELECT.

1. Open the menu with the phone in standby.
Select

2. The system plays back the current greeting.
Press MENU/SELECT to switch greetings.

Switch to your personal greeting, press END/CLEAR
“Delete Greeting?” is displayed. Select “Yes” to
clear greeting.

Answering Setup

, then

Record Greeting

, then

Greeting Options

.

.

Accessing the Answering System

When the phone’s in standby, you can access the system from any
handset:

• Only 1 handset can access the system at a time.

• If you do nothing for 30 seconds, the phone returns to standby.

• During remote access, the phone beeps so you know it’s waiting for the

next command.

• You can press the number key shown next to each command instead of

scrolling through the screens.

25

Getting Your Messages

To From the base From a Handset

Press PLAY/STOP

.

play new messages

The system announces the number of new & old
messages, then plays each new message (followed
by the day and time) in the order it was received.

restart this
message

replay an earlier
message

skip a message

Wait at least 5 seconds after the message starts
playing,

press REV

.

Within 2 seconds after a message starts playing,

press REV

.

Press FWD.

delete a message While a message

is playing, press
DELETE.

Press MESSAGE/MUTE and select
‘Play Message’.

select

select

Select

1:Repeat

1:Repeat

3:Skip

.

.

.

While a message is playing,
select

4:Delete

.

delete all
messages

With the phone
in standby, press

Not available.

DELETE; press
DELETE again to

confirm.

play old messages After the system plays all new messages,

press PLAY/STOP

select

2:Play

.

again.

stop playback

Press PLAY/STOP.

Select

5:Stop

.

26

Screening your Calls

You can use the answering system for call screening. While the system
takes a message, you can listen on the base speaker (if you turn on

Screen)

or from a handset. Only one handset can screen calls at a time. If

another handset tries to screen calls, it beeps and returns to standby.

To... From the base From the handset

hear the caller
leaving a message

answer the call NA

mute the call
screen without

Listen to the caller over

Press MESSAGE/MUTE

the speaker.

Press HOME/FLASH

Press P LAY/ STOP. Press END or return the

handset to the cradle.
answering (if you
mute the call
screen, the system
continues taking
the message: it
just stops playing

Call

through the
speaker)

Using the System While You’re Away from Home

You can dial in to your answering system from any touch-tone phone.
Before you can use this feature, you must program a security code.

Programming a Security Code

You can dial in to your answering system from any touch-tone phone.
Before you can use this feature, you must program a security code. Use
the number keypad to enter a two-digit security code (01 to 99). Press
MENU/SELECT when you’re finished (see page 24).

# Remember to make a note of your new security code!

27

Dialing In to Your System

1. Call your phone number & wait until the system answers. (If the system is
turned off, it answers after 10 rings & sounds a series of beeps.)

2. During the greeting or beeps, press

“#”

and immediately enter your
security code. If you enter it incorrectly 3 times, the system hangs up and
returns to standby.

3. The system announces the time, the number
of messages in memory, and a help prompt. It beeps to let you know it’s
waiting for a command.

4. When you hear
beeping, enter a
2-digit command
from the chart.

#1 Repeat message #5 Stop playback
#2 Play message #6 Turn the system on
#3 Skip message #9 Turn the system off

#4 Delete message #0 Hear help prompts

# If you don’t press any keys for 15 seconds, the phone will hang up and

return to standby.

28

IMPORTANT INFORMATION

Solving Problems

If you have any trouble with your phone, check this section first. If you
need help, visit the customer support page of our website listed on the front
cover.

General Problems Possible Solutions

No handsets can make or receive
calls.

A handset can’t make or receive
calls.

A handset can make calls, but it
won’t ring.

A handset is not working.

The phone keeps ringing when I
answer on an extension.

• Check the telephone cord

connection.

• Disconnect the base AC

adaptor for a few minutes; then
reconnect it.

Move the handset closer to the
base.

• Make sure the ringer is turned

on.

• Make sure DND Mode is turned

off (see page 19).

• Charge the battery for 15-20

hours.

• Check the battery connection.

• You may have to change the

line mode. Contact Customer
Service for instructions.

Audio Issues Possible Solutions

Callers sound weak or soft.

• Move the handset closer to the

base.

• Keep the handset’s battery fully

charged.

• Increase the earpiece volume.

29

There’s a lot of noise or static on
the line

• Check for interference from

appliances (microwave ovens,
TVs, etc.) or wireless devices
(baby monitors, WiFi equipment,
etc.). Move the handset or base
away from the interference
source.

• If you use a telecoil hearing aid,

turn on T-coil mode (see page

13).

• If you have any service that uses

the phone line, add a DSL or
telephone line filter (see page

31).

Caller ID Issues Possible Solutions

No handsets display Caller ID
information.

• Let calls ring twice before

answering.

• Make sure your Caller ID service

is active.

Caller ID displays briefly and then
clears.

• You may have to change the

line mode. Contact Customer
Service for instructions.

Multi-handset problems Possible Solutions

I can’t transfer calls

• Reset the handset (see page

31).

Two handsets can’t talk to a caller

• See if any handset is in Privacy

Mode.

A handset says

Unavailable

. • Move the handset closer to the

base.

• See if any handset is in Privacy

Mode.

I can’t register a new handset.

Voice mail issues Possible Solutions

The new message icon doesn’t
turn off after I’ve listened to all my
messages.

30

• Reset the handset (see page

31).

• See if you have 6 registered

handsets

• Reset the Voice Message

Indicator (see page 21)

Installing a Line Filter or DSL Filter

A telephone line filter or DSL filter prevents services that use the phone
line from causing interference on your phone. To get a line filter, contact
your service provider or look in an electronics store.

Plug the filter into the telephone wall jack and plug the base into the filter.
Make a test call to make sure the noise is gone.

Liquid Damage

CAUTION: If the base is covered in liquid, disconnect the adaptor and
phone cord from the wall before touching it.

If the liquid is only on the exterior housing of the base or handset, wipe it
off and use as normal. If you can hear liquid inside the housing:

1. Remove all compartment covers, and disconnect all cables and cords.

2. If liquid is leaking from any vent or hole, turn the phone so that vent
faces down. If not, place the largest vent face down.

3. Let dry for at least 3 days. Check for liquid inside the phone before
replacing compartment covers and reconnecting cords.

Resetting Handsets

If you have trouble with a handset or if you want to replace one, clear the
registration information from the base and the handset:

1. Press & hold END and # at the same time until you see the System Reset
menu.

2. If you still have the base the handset is registered to, select Deregister
HS, then select the handset you want to reset. If you don’t have that base
anymore, select Base Unavailable.

3. To confirm, select Yes. The handset displays Handset not registered.

Registering Handsets

If you see a “not registered” message on a handset, you must register it to
a base before using it.

1. Place the handset in the base; the display should say Handset
Registering.

2. Wait until the display says Registration Complete (about 30 seconds),
then pick up the handset and press HOME/FLASH.

3. If you don’t hear a dial tone or the display says Registration Failed,
charge the battery completely, then try again.

31

AC Adaptor and Battery Information

AC Adaptor Base Charger

Part number PS-S0635YL3 AAD-600S(M)

Input voltage 100-240V AC, 50/60Hz 100-240V AC,

50/60Hz

Output voltage 6V DC @ 350mA 9V DC @ 210mA

• Use only the supplied AC adaptors.

• Use the proper adaptor for the base and any chargers.

• Do not place the unit in direct sunlight or subject it to high temperatures.

Battery Pack with Normal Use

Part number BT- 694, BT- 694s or BT- 694n

Capacity 650mAh (BT-694) or 500mAh (BT-694s) or

400mAh(BT-694n)

Talk time about 10 hours

Standby time about 7 days

Battery life about 1 year

• Replace the battery when the talk or standby time becomes noticeably

reduced. For replacements, visit the online shop on our website (see
the front cover).

• When the battery gets low, the handset beeps and shows a low battery

alert; put the handset in the cradle for recharging.

32

Wall Mounting the Base

This phone can be mounted on any standard telephone wall plate using the
supplied wall-mount bracket.

Route the telephone cord through the

1

hole of the wall-mount bracket.

Connect the AC adaptor and

2

the telephone cords as shown.

Line up the four tabs on

3

the wall-mount bracket
(two at the top and two at
the center) with the four
notches on the bottom of
the base. Slide the bracket
into place.

Plug the telephone cord

5

into the wall jack. Tuck the
excess cord into the open
space in the bracket.

Wall plate

Let the AC

4

adaptor cord
hang below
the base

33

Place the mounting slots over

(To AC outlet)

Wall plate

6

the pins on the wall plate.
Slide the base down to lock it

7

into place.

Removing the wall-mount bracket

At the bottom of the base, pinch the
two “nose” of the wall-mount bracket
as ahown, and then slide the bracket
away from the base.

Note: Mounting the phone directly on the wall

• Be sure the wall is capable of supporting the weight of the phone, and

use the proper type of anchoring device for the wall material.

• Insert two #10 screws (minimum length of 35mm, not supplied) into the

wall, 100mm apart.

• Leave the screw heads 3mm away from the wall to allow room for

mounting the phone.

• Align the mounting slots over the screws and slide the base down into

place as shown above.

34

INDEX

A

Answer Machine 24
Any Key Answer 13
Auto Talk 13

B

Battery 32

C

Caller ID 16
Call Transfer 22
Call Waiting 17
Chain Dialing 23
Conference Calling 21

Power Failure 19
Privacy Mode 22

R

Redial 9
Register a Handset 31
Resetting the Handset 31
Ringer 13

V

Voice Mail 23

W

Wall Mounting 33
Warranty 36

D

Date&Time 13
DND 20

I

Intercom 22

K

Key Touch Tone 13

L

Line Filter 31
Liquid Damage 31

M

Multihandset Feature 20

P

Personal Ring 13
Phonebook 17

35

ONEYEAR LIMITED WARRANTY

DECT 3136BT
IMPORTANT Satisfactory evidence of the original purchase is

required for warranty service

Please refer to our Uniden website for any details or warranty durations
offered in addition to those contained below.

Warrantor

The warrantor is either Uniden Australia Pty Limited ABN 58 001 865 498
(“Uniden Aust”) or Uniden New Zealand Limited (“Uniden NZ”) as the case
may be.

Terms of Warranty

Uniden Aust/NZ warrants to the original retail purchaser only that the
DECT 3136BT (“the Product”), will be free from defects in materials
and craftsmanship for the duration of the warranty period, subject to the
limitations and exclusions set out below.

Warranty Period

This warranty to the original retail purchaser is only valid in the original
country of purchase for a Product first purchased either in Australia or New
Zealand and will expire one (1) year from the date of the original retail sale.

If a warranty claim is made, this warranty will not apply if the Product is found
by Uniden to be:

(A) Damaged or not maintained in a reasonable manner or as recommended

in the relevant Uniden Owner’s Manual;

(B) Modified, altered or used as part of any conversion kits, subassemblies

or any configurations not sold by Uniden Aust or Uniden NZ;

(C) Improperly installed contrary to instructions contained in the relevant

Owner’s Manual

(D) Repaired by someone other than an authorized Uniden Repair Agent in

relation to a defect or malfunction covered by this warranty; or

(E) Used in conjunction with any equipment, parts or a system not

manufactured by Uniden.

Parts Covered

This warranty covers the Product and included accessories.

36

User-generated Data

This warranty does not cover any claimed loss of or damage to user­generated data (including but without limitation phone numbers, addresses
and images) that may be stored on your Product.

Statement of Remedy

If the Product is found not to conform to this warranty as stated above, the
Warrantor, at its discretion, will either repair the defect or replace the Product
without any charge for parts or service. This warranty does not include any
reimbursement or payment of any consequential damages claimed to arise
from a Product’s failure to comply with the warranty.

Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount
to a major failure.

This warranty is in addition to and sits alongside your rights under either the
COMPETITION AND CONSUMER ACT 2010 (Australia) or the CONSUMER
GUARANTEES ACT (New Zealand) as the case may be, none of which can
be excluded.

Procedure for Obtaining Warranty Service

Depending on the country in which the Product was first purchased, if
you believe that your Product does not conform with this warranty, you
should deliver the Product, together with satisfactory evidence of your
original purchase (such as a legible copy of the sales docket) to Uniden
at the addresses shown below. You should contact Uniden regarding any
compensation that may be payable for your expenses incurred in making
a warranty claim. Prior to delivery, we recommend that you make a backup
copy of any phone numbers, images or other data stored on your Product, in
case it is lost or damaged during warranty service.

UNIDEN AUSTRALIA PTY LTD

Service Division
345 Princes Highway,
Rockdale, NSW 2216
Phone number: 1300 366 895
Email: [e-mail]

UNIDEN NEW ZEALAND LTD

Service Division
150 Harris Road, East Tamaki
Auckland 2013
Phone number: [phone]
Email: [e-mail]

37

©2012 Uniden Australia Pty Ltd/Uniden New Zealand Limited
Printed in Vietnam U01UN508BZZ(0)

38
