Uniden DECT2035+2, DECT2035+1, DECT2035 User Manual

DECT2035
DECT2035+1
DECT2035+2
DECT 2035+1 OM.indb iDECT 2035+1 OM.indb i 15/7/08 11:59:34 AM15/7/08 11:59:34 AM
Table of Contents
Welcome ....................................................................... 5
Installing the Phone ....................................................6
Choosing the Best Location ......................................6
Connecting the AC adapter ....................................... 8
To the base ...........................................................8
To the charging cradle
(for multi-handset packs only) ......................8
Charging the Handset ...............................................9
Connecting to the Phone Line ................................. 10
Testing the Connection ........................................... 11
Expanding Your Phone ........................................... 13
Adding accessory handsets ............................... 13
Registering accessory handsets ........................ 13
Using Multiple Bases ..............................................14
Registering the handset to another base ........... 14
Selecting the base .............................................. 15
Getting to Know Your New Phone ........................... 16
Features .................................................................. 16
Answering system features ................................ 16
Terminology Used in this Manual ............................ 17
Manual Conventions ............................................... 17
Parts of the Handset ............................................... 18
Parts of the Base ....................................................19
Using the Interface .................................................... 20
Reading the Display ................................................ 20
Using the Four-way Function Key ........................... 21
Using the Handset Menu ........................................21
Entering Text from Your Handset ............................ 22
Basic Setup ................................................................ 23
Setting the Day & Time ........................................... 23
Activating Personal Ring ......................................... 23
Activating the Key Touch Tone ................................ 24
Name Tag ................................................................ 24
Insert 0 .................................................................... 24
Setting Up the Phonebook ........................................ 25
Creating Phonebook Entries ................................... 25
Finding a Phonebook Entry ..................................... 26
Editing an Existing Phonebook Entry ...................... 26
Storing Caller ID or Redial Numbers
in the Phonebook........................................ 27
Deleting a Single Phonebook Entry ........................ 27
Deleting all Phonebook Entries ............................... 28
Copying Phonebook Entries to Another Handset ....28
2
DECT 2035+1 OM.indb 2DECT 2035+1 OM.indb 2 15/7/08 11:59:37 AM15/7/08 11:59:37 AM
Customizing Your Handsets ..................................... 29
Changing the Handset Banner ................................ 29
Selecting a Ring Tone .............................................29
Activating Any Key Answer ..................................... 30
Using Your Phone ...................................................... 31
Making a Call from the Phonebook ......................... 32
Chain dialing from the phonebook ...................... 32
Switching to the Handset Speakerphone
During a Call ............................................... 32
Using Caller ID, Call Waiting, and Redial Lists ....... 33
Using the Caller ID List .......................................... 33
Making a Call from a Caller ID Record ...................33
Deleting Caller ID Numbers .................................... 34
Using Call Waiting ................................................... 34
Redialing a Number ................................................ 35
Deleting a Redial Record ........................................ 35
Adjusting the Ringer, Earpiece and
Speaker Volume ............................................. 36
Adjusting the Ringer Volume ...................................36
Muting the Ringer (One call only) ...........................36
Adjusting the Earpiece Volume ............................... 36
Adjusting the Speaker Volume ................................ 36
Adjusting the Audio Tone ........................................ 37
Finding a Lost Handset ............................................. 37
Using Hold, Conference and Transfer ..................... 38
Placing a Call on Hold ............................................. 38
Conferencing ........................................................... 38
Transferring a Call...................................................38
Answering a transferred call ...................................39
Using Special Features ............................................. 40
Privacy Mode .......................................................... 40
Making an intercom page ................................... 41
Answering an intercom page .............................. 42
Muting the Microphone ............................................. 42
Setting Up the Answering System ........................... 43
Recording a Personal Greeting ............................... 43
Selecting a Greeting ........................................... 43
Deleting Your Personal Greeting ........................ 44
Setting the Number of Rings ................................... 45
Setting the Record Time (or Announce only) .......... 45
Activating the Message Alert ...................................46
Activating the Base Call Screen .............................. 46
Using the Answering System ................................... 47
Turning Your Answering System On and Off ........... 47
Remote Operation from the Handset ...................... 48
Reviewing Messages .............................................. 49
3
DECT 2035+1 OM.indb 3DECT 2035+1 OM.indb 3 15/7/08 11:59:38 AM15/7/08 11:59:38 AM
Screening Calls ....................................................... 50
Turning Off the Message Alert Tone ........................ 50
Operating the Answering System While
You Are Away from Home ........................... 50
Setting a security code or
Personal Identifi cation Number (PIN) ......... 50
Dialing in to your answering system ................... 50
Wall Mounting the Base ............................................ 52
Maintenance ............................................................... 54
Specifi cations .......................................................... 54
Battery Information .................................................. 54
Battery life .......................................................... 54
Low battery alert ................................................ 55
Cleaning the charging contacts .......................... 55
Battery replacement and handling ..................... 55
Power Failures ........................................................ 55
Troubleshooting ........................................................56
Common Issues ...................................................... 56
Weak or Hard to Hear Audio .................................. 59
Noise or Static on the Line ...................................... 59
Installing a telephone line fi lter or DSL fi lter ....... 60
Resetting the Handset ............................................60
Resetting the Handset Without the Base ................ 61
Changing the Line Mode for Multiple Extensions .... 62
Traveling Out of Range ........................................... 62
Liquid Damage ........................................................ 63
Precautions! .............................................................. 64
Rechargeable Nickel-Cadmium Battery Warning ...64
Important Safety Instructions .................................. 64
Index ......................................................................... 65
Remote Operation Card ............................................ 67
Warranty ..................................................................... 71
4
DECT 2035+1 OM.indb 4DECT 2035+1 OM.indb 4 15/7/08 11:59:39 AM15/7/08 11:59:39 AM
Welcome
Thank you for purchasing a Uniden Multi-Handset phone.
Note: Illustrations in this manual are used for explanation purposes. Some illustrations in this manual may differ
from the actual unit.
Welcome
5
DECT 2035+1 OM.indb 5DECT 2035+1 OM.indb 5 15/7/08 11:59:40 AM15/7/08 11:59:40 AM
Installing the Phone
Choosing the Best Location
When choosing a location for your new phone, here are some important guidelines you should consider:
PLACE YOUR BASE
• Microwave ovens
• Refrigerators
Near an AC outlet and a telephone wall jack.
• TVs
• TVs
• Other electronics
• Other electronics
Installing the Phone
• Direct sunlight
In a centrally-located
open area.
• Direct sunlight
• Extreme temperatures
• Extreme temperatures
Notes: For maximum range:
Keep both the base and handset antennas free of obstruction.
• When the handset is not in use, place the handset in an upright position.
• Metal and reinforced concrete may affect cordless telephone performance.
•
• Fluorescent lighting
• Personal computers
• Personal computers
• Wireless LAN
• Wireless LAN
equipment
equipment
• Dust
• Dust
• Excessive
• Excessive
moisture
moisture
6
TRY TO AVOID
• Other cordless telephones
• Areas with
• Areas with
a lot of
a lot of
background
background
noise
noise
• Shock
• Shock
• Vibration
• Vibration
DECT 2035+1 OM.indb 6DECT 2035+1 OM.indb 6 15/7/08 11:59:40 AM15/7/08 11:59:40 AM
Installing the Battery
Use only the Uniden BT-904 rechargeable battery pack supplied with your cordless telephone.
Unpack all handsets, battery packs, and battery covers. (If the battery cover is on the handset, press in on the notch and slide the cover off.)
Line up the red and black wires on the battery pack connector with the sticker in the handset’s battery compartment.
RED
BLACK
Push the battery pack connector in firmly. (You should hear it click into place.) Gently tug on the battery wires to make sure the connection is secure.
Place the cover over the battery compartment and slide it up into place.
Installing the Phone
7
DECT 2035+1 OM.indb 7DECT 2035+1 OM.indb 7 15/7/08 11:59:53 AM15/7/08 11:59:53 AM
Connecting the AC adapter
To the base
To avoid risk of fi re and shock, only use the Uniden AAD-041S(M) adapter with the base.
Connect the AC adapter to the DC IN 9V jack
Connect the AC adapter to the DC IN 9V jack on the back of the base.
on the back of the base.
Don’t put any power cord where it people might
Don’t put any power cord where it people might trip over it or step on it. If a power cord becomes
trip over it or step on it. If a power cord becomes chafed or worn out, it can create a fire or
Route the cord through the
Route the cord through the molded wiring channel.
molded wiring channel.
To the charging cradle (for multi-handset packs only)
Installing the Phone
Connect the AC adapter to the
Use only the Uniden AAD-600S(M) adapter with the charging cradle.
Connect the AC adapter to the
DC IN 9V jack as shown.
DC IN 9V jack as shown.
(It may already be connected.)
(It may already be connected.)
chafed or worn out, it can create a fire or electrical hazard.
electrical hazard.
Connect the AC
Connect the AC adapter to a
adapter to a standard 240V
standard 240V AC wall outlet.
AC wall outlet.
Connect the AC adapter
Connect the AC adapter to a standard 240V AC
to a standard 240V AC wall outlet.
wall outlet.
8
DECT 2035+1 OM.indb 8DECT 2035+1 OM.indb 8 15/7/08 11:59:53 AM15/7/08 11:59:53 AM
Charging the Handset
Make sure that the charge LED illuminates when the handset is seated.
Place the handset in the base cradle with the display facing forward.
If you have an accessory handset, place it in the charging cradle with the display facing forward.
Charge your handset at least 15 to 20 hours before plugging into the phone line.
DECT 2035+1 OM.indb 9DECT 2035+1 OM.indb 9 15/7/08 11:59:54 AM15/7/08 11:59:54 AM
Installing the Phone
Make sure that the charge LED illuminates when the handset is seated.
What if the charge LED doesn’t light up?
Reseat the handset; make sure the contacts on the bottom of the handset are lined up with the contacts in the charging cradle. Check the AC adapter connection. Make sure you are not using an outlet that’s controlled by a wall switch.
9
Connecting to the Phone Line
Make sure that the battery pack is fully charged.
Connect the telephone cord to the TEL LINE jack.
Installing the Phone
Connect the telephone cord to a telephone wall jack.
What if Check TEL Line appears on the handset display?
The telephone cord may not be connected correctly. Check the telephone cord connection.
10
DECT 2035+1 OM.indb 10DECT 2035+1 OM.indb 10 15/7/08 11:59:55 AM15/7/08 11:59:55 AM
Do you have DSL or any high-speed Internet service delivered through your phone line?
Telephone wall jack
Try putting a DSL fi lter between the base and the wall jack. Without a fi lter, telephone-line- based Internet services can interfere with standard phones.
Telephone cord
DSL filter
Testing the Connection
Pick up the handset from the cradle and press TALK/FLASH. You should hear a dial tone, and the display should show Talk.
What if I can’t hear a dial tone?
Check the telephone cord connection on the base.
What if the display doesn’t show Talk?
Check the battery pack connection in the handset.
• Make sure the battery pack is fully charged.
• Make sure the AC adapter cord is securely connected to the
• DC IN 9V jack and a standard power outlet. Try resetting the handset (see page 60).
•
11
Installing the Phone
DECT 2035+1 OM.indb 11DECT 2035+1 OM.indb 11 15/7/08 11:59:56 AM15/7/08 11:59:56 AM
Make a quick test call, and then press END to hang up.
What if there is a lot of static?
Check the sources of interference described in Choosing the Best Location (see page 6): is the base near any of those?
Note: Make sure you can get a dial tone on any accessory handsets that
were packaged with your phone.
NOW YOU ARE READY TO USE YOUR PHONE!
Installing the Phone
12
DECT 2035+1 OM.indb 12DECT 2035+1 OM.indb 12 15/7/08 11:59:58 AM15/7/08 11:59:58 AM
Expanding Your Phone
Adding accessory handsets
Your phone supports a total of six cordless handsets, including any that were supplied with your phone. You can now place a fully-featured cordless handset anywhere AC power is available to connect the charging cradle.
•
Your phone is compatible with the following Uniden DECT accessory handsets: DECT2015, DECT2035 and DECT2005. (Please visit our website at www.uniden.com.au for Australian models or www.uniden.co.nz for New
•
Zealand models for the most up-to-date list of compatible handsets.)
•
For instructions on connecting the charging cradle, see page 8.
•
If you purchase any accessory handsets separately, you must register the handsets to the base before you can use them. (Accessory handsets that come packaged with a base are already registered to that base.)
Registering accessory handsets
When charged, registered handsets display a handset ID number. Handsets that have not been registered display:
↔
To register a DECT2005 accessory handset:
1)
Charge the handset for 15-20 hours.
2)
Place the handset in the base cradle for about thirty seconds. Handset Registering will appear in the LCD.
3)
When the handset has registered to the base, the LCD will display Registration complete then show the handset ID number.
4)
On the handset, press and hold # until the handset beeps and displays Handset Registering.
5)
When the handset has registered to the base, the LCD will display Registration complete then show the handset ID number.
If the display shows Registration failed, repeat the process again.
Note: If a handset has ever been registered to a base, reset the handset before you register it to a new base (see
13
Installing the Phone
DECT 2035+1 OM.indb 13DECT 2035+1 OM.indb 13 15/7/08 11:59:59 AM15/7/08 11:59:59 AM
Resetting the Handset on page 60). Or to use multiple bases, see the next section.
Using Multiple Bases
The handsets supplied with your phone can be registered to a total of four different bases. Compatible bases include the DECT 2015 and DECT 2035 series. (See our website or contact Customer Service for an up-to-date list of compatible models.)
Note: To confi rm how many bases the handset is registered to, open the Select Base submenu (follow the step 1 of
Selecting the base on page 15). Press END to close the list and return to standby.
Registering the handset to another base
To register a handset to another base:
1)
Make sure the handset battery is fully charged.
2)
If the other base has an LCD display:
•
With the phone in standby, press MENU/SELECT on the base. Move the cursor to select the Register Handset menu, and then press MENU/SELECT. Handset Registering will appear.
If the other base does not have an LCD display:
•
Disconnect the base AC adapter. Then press and hold the Find Handset key* while you reconnect the
Installing the Phone
adapter. Keep holding the Find Handest key until the charge LED starts to blink. *This key might be labeled Find or Find HS.
3)
On the handset, press MENU/SELECT. Select the Register Base menu. Handset Registering will appear in the display. (After step 2, you have thirty seconds to complete this step 3 before the system returns to standby.)
4)
Wait approximately thirty seconds. Registration complete will be displayed to indicate the handset has been registered to the base and a handset ID will be automatically assigned. The handset assigns its own ID to this base, too. (Since the base ID is based on the order in which the handset was registered to the different bases, a base may have different IDs on each handset.)
If Registration failed appears in the LCD, please try these steps again.
Note: The handset will stay connected to the new base until you select a different base (see below).
14
DECT 2035+1 OM.indb 14DECT 2035+1 OM.indb 14 15/7/08 12:00:00 PM15/7/08 12:00:00 PM
Selecting the base
After you register your handset to more than one base you can set the handset to automatically search for a new base if the base it’s currently connected is unavailable or out of range. You can also manually select which base you want the handset to connect to; for example, if you have one base with an answering machine, you can connect to that base to check messages from the handset.
1)
With the phone in standby, press MENU/SELECT. Select the Handset Setup menu, and then the Select Base submenu.
2)
Move the cursor to select the base you want to connect to, or choose Auto to have the handset automatically search for and select base.
3)
Press MENU/SELECT. Searching will appear in the display.
4)
When the base is found, the handset will return to standby. If the base is not found, “Searching” continues to appear. You can repeat the procedure listed above to return back to the original connection or to fi nd the different base.
Note: You cannot change bases during a call.
Installing the Phone
15
DECT 2035+1 OM.indb 15DECT 2035+1 OM.indb 15 15/7/08 12:00:01 PM15/7/08 12:00:01 PM
Getting to Know Your New Phone
Features
1.8GHz DECT expandable system
• Expands up to 6 handsets
• Caller ID/Call Waiting with phonebook match
• Store 30 Caller ID numbers
• 70-number phonebook with alphabetical search
• Personalized ring and display name by party
• Transfer single listing or entire phonebook
•
Answering system features
Digital tapeless recording
• Up to 14 minutes of recording time
• Call screening
• Personal or pre-recorded outgoing messages
• Day and time announcement
• Remote message retrieval
• Toll saver
•
Speakerphone on handset
• 7 ringer options on handset (3 tones/4 melodies)
• Last 5 number redial
• Call transfer
• Conferencing
• Intercom
•
Message alert
• Records up to 59 messages
•
Getting to Know Your New Phone
DECT 2035+1 OM.indb 16DECT 2035+1 OM.indb 16 15/7/08 12:00:02 PM15/7/08 12:00:02 PM
16
Terminology Used in this Manual
Accessory Handsets
Base The main part of the phone that connects to your phone line and lets you make and receive calls.
Charging cradle
CID
CID/CW
Global Settings
Standby
Talk A dial tone has been enabled, so you can dial and carry on a conversation with an outside party.
Additional handsets that can register to the base, allowing you to add handsets without connecting another phone line. This base supports a total of six cordless handsets; see page 13 for compatible handsets.
A cradle that comes with an accessory handset and charges the handset battery pack. It connects to power but does not connect to a phone line.
Caller ID is available from your telephone provider and is offered to users on a subscription basis. With this service, you will be able to see the incoming caller information such as name and phone number.
Caller ID with Call Waiting is available by subscription from your telephone provider. With this service, you will be able to view incoming caller information while on a call with another user.
Any settings that apply to all registered handsets and the base. These features are available by selecting “Global Setup” or “Day & Time” in the handset menu. Only one handset can change global settings at a time, and you have to make sure the phone is not currently being used. If you have multiple bases, the different bases have each global settings; select the base before changing the global setting (see Selecting the base on page 15).
The handset and the base are not in use. (It doesn’t matter whether the handset is in the cradle: the TALK/ FLASH or
hasn’t been pressed, and there is no dial tone.)
Manual Conventions
Getting to Know Your New Phone
This manual uses several different type styles to help you distinguish between different parts of the phone:
Bold italic text indicates a key or button on the phone
• Italic text indicates text on the display, such as menu options, prompts, and confi rmation messages
• lower case bold text indicates a status light on the phone
• ALL CAPITALS BOLD indicates a connection jack on the base or charging cradle
•
17
DECT 2035+1 OM.indb 17DECT 2035+1 OM.indb 17 15/7/08 12:00:03 PM15/7/08 12:00:03 PM
Parts of the Handset
new message LED
Earpiece
Display (LCD)
CLEAR/INT'COM key (clear/intercom)
key (phonebook/left)
TALK/FLASH key
key (speaker)
/TONE key
REDIAL/PAUSE key
Microphone
key (up)
MENU/SELECT key
key (caller ID/right)
END key
key (down)
Twelve-key dial pad
# key
/MUTE key
(messages/mute)
Charging contacts
Speakerphone
speaker and ringer
Battery compartment
Getting to Know Your New Phone
DECT 2035+1 OM.indb 18DECT 2035+1 OM.indb 18 15/7/08 12:00:04 PM15/7/08 12:00:04 PM
18
A
Parts of the Base
Speaker
FIND key
NSWER
ON/OFF key
key (delete)
message counter LED
key (repeat/right)
key (volume up)
Charging contacts
charge LED
key (volume down)
key (play/stop)
key (skip/left)
Getting to Know Your New Phone
19
DECT 2035+1 OM.indb 19DECT 2035+1 OM.indb 19 15/7/08 12:00:04 PM15/7/08 12:00:04 PM
Using the Interface
Reading the Display
In standby During a call
Using the Interface
Handset ID and banner
Number of new Caller ID calls received
The ringer off icon indicates that the ringer is turned off.
The voice mail icon appears when you have messages waiting in your voice mailbox.
The privacy icon appears when the Privacy Mode is turned on.
The speaker icon appears when the speaker phone is in use.
The mute icon appears while the microphone is muted.
The battery icon indicates the handset battery status: full, medium, low, and empty.
Time
20
Call duration
DECT 2035+1 OM.indb 20DECT 2035+1 OM.indb 20 15/7/08 12:00:05 PM15/7/08 12:00:05 PM
Using the Four-way Function Key
Increase the volume
Your handset has a four-way function key that allows you to move the cursor on the display and access the most commonly used features at the touch of a button.
•
Press the left side of the key to open the phonebook.
•
Press the right side of the key to open the Caller ID list. Press the top of the key to increase the ringer
• volume (while the phone is in standby) or speaker volume (while you are on a call). Press the bottom of the key to decrease the
• ringer volume (while the phone is in standby) or speaker volume (while you are on a call).
Open the
Open the phonebook
phonebook
Four-way
Four-way Function Key
Function Key
Increase the volume
Decrease the volume
Decrease the volume
Open the
Open the Caller ID list
Caller ID list
Using the Handset Menu
•
To open the menu, press the MENU/SELECT key.
•
The arrow cursor on the left side of the line shows which menu item is currently highlighted. Use way function key to move the cursor up and
•
To select the highlighted option, press MENU/SELECT.
•
To go back to the previous screen, press LEFT on the four-way function key.
•
To exit the menu, press END.
•
If you don’t press any keys for thirty seconds, the phone will time out and exit the menu. (When setting the day and time, the time-out period is extended to two minutes.)
•
For Ans. Setup, Global Setup and Day & Time menu options, make sure the line is not in use and the handsets are within range of the base.
to move the cursor down.
on the four-
Using the Interface
21
DECT 2035+1 OM.indb 21DECT 2035+1 OM.indb 21 15/7/08 12:00:07 PM15/7/08 12:00:07 PM
Entering Text from Your Handset
You can use the number keypad on your handset to enter text by referring to the letters printed on each number key. When you press the number key in a text entry fi eld, the phone displays the fi rst letter printed on the number key. Press the number key twice to display the second letter and three times to display the third.
•
When [Aa] appears on the display, capital letters are displayed fi rst, then lower case letters, and then the number on the key.
•
When [aA] appears on the display, lower case letters are displayed fi rst, then the number on the key, and then
Using the Interface
capital letters.
•
When you input the fi rst letter or a letter after a blank space, the default mode is [Aa]. From the next letter, the mode changes to [aA] automatically.
•
You can switch back and forth the mode manually between [Aa] and [aA]. Press of the letter entered changes also.
If two letters in a row use the same number key, enter the fi rst letter, then use RIGHT on the four-way function key to move the cursor to the next position to enter the second letter.
For example, to enter the word “Movies”:
1.
Press 6 once to enter M.
2.
Use RIGHT on the four-way function key to move the
Number of times key is pressed (when [Aa] appears on the display)Number of times key is pressed (when [Aa] appears on the display)
cursor to the right.
3.
Press 6 three times to enter o.
4.
Press 8 three times to enter v.
5.
Press 4 three times to enter i.
6.
Press 3 two times to enter e.
7.
Press 7 four times to enter s.
8.
Press MENU/SELECT to end your text entry.
If you make a mistake while entering a name, use RIGHT or LEFT on the four-way function key to move the cursor to the incorrect character. Press CLEAR/INT’COM to erase the wrong character, and then enter the correct character. To delete all characters, press and hold CLEAR/INT’COM.
22
/TONE; the case (small/capital)
DECT 2035+1 OM.indb 22DECT 2035+1 OM.indb 22 15/7/08 12:00:08 PM15/7/08 12:00:08 PM
Loading...
+ 50 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
