BTSC1700
Bluetooth
For more exciting new products please
visit our website:
Australia: www.uniden.com.au
New Zealand: www.uniden.co.nz
®
Car Kit
1
234
5
UNIDEN
1
2 34
5
What’s In The Box?
1. Carkit 2. Visor Clip 3. Car charger 4. Owner’s Manual
5.AC Adaptor
Getting to Know the BTSC1700
CHARGING PORT
TALK/END/MULTIFUNCTION BUTTON
VOLUME BUTTON
OLED DISPLAY
MIC
2
VISOR CLIP
SPEAKER
ON/OFF SWITCH
VOICE COMMAND
BUTTON [A]
5
UNIDEN
UNIDEN
5
Charge the Battery
Connect an adapter to the charging port of the
BTSC1700 and plug it into automobile (or any standard
12V~24V) or home power outlet. When charging is
completed, charging indication OLED will be turned off .
[NOTE] Please use supplied power
adaptor only.
Low Battery Alarm
When the battery is low, the
BTSC1700 will sound a beep alarm every 30sec. Once you
hear the alert, please charge immediately. It will turn off in
about 10 minutes if not recharged.
OLED Display
BATTERY STATUS
BLUETOOTH
CONNECTION STATUS
[NOTE] OLED screen will be turned o 30sec. after your last action. You can
turn on OLED screen by touching any button.
3
“Say command”“Pairing mode”
Turning ON
Turning OFF
Using Your BTSC1700
Turning ON
Turning OFF
Turning ON/OFF
Using the Voice Command Mode
Voice commands listed in the table are available when
Voice Command mode is activated.
Voice Command mode is activated automatically on an
incoming call. To activate Voice Command in standby
mode: Press the Voice Command button. Voice commands
can be made after “Say Command” is announced.
[NOTE] Voice Command mode is cancelled when the Voice Command
button is pressed again or when the BTSC1700 is turned o.
4
Voice
Command
Explanation
“PAIRING MODE” Device will go to pairing mode
“ANSWER” Answer the incoming call.
“CHECK” Check received E-mail & SMS .
“IGNORE”
Reject calls, check E-mail & SMS as
you receive them.
Check the last received text
“CHECK message”
message. The BTSC1700 will read
it out.
Check the last received E-mail. The
“CHECK E-mail”
BTSC1700 will read out the sender
& title only.
“CHECK schedule”
Check today’s schedule (updated
from your Google Calendar ™)
“CHECK weather” Check today’s weather.
“What can I say?” Check list of available commands.
“CHECK” Commands are only available if you install the
“Uniden BTSC1700” application on your mobile phone and
set up details. For details refer to the Uniden BTSC1700
Android ™ Application section on page 8.
5
Pair The BTSC1700 To Your Mobile Phone
Full Automatic Pairing
1. Set your mobile phone to Bluetooth discoverable mode
(visibility on).
2. Turn the BTSC1700 on. When turned on for the rst
time it will go to pairing mode.
3. Place your mobile phone near to (within 10cm) the
BTSC1700 for optimal result.
4. When the connection conrmation message appears
on your mobile phone, conrm it. PIN number “0000”
(4 zeros).
[NOTE] Please make sure that your mobile phone supports Bluetooth
version 2.1 or higher version. This feature is only available when
you pair for the rst time. If not, please reset your unit (see page
11) and try again.
Voice Pairing
1. Turn on the BTSC1700 and press the voice command
button.
2. After “Say Command” is announced please say “PAIRING
MODE”.
3. Set your mobile phone to search for Bluetooth devices.
• For the most mobile phones, you can nd Bluetooth
mode by selecting Setting/Tools - Connections –
Bluetooth. (For further information, please refer to your
mobile phone’s manual)
6
4. When your mobile phone nds the BTSC1700, conrm
it by selecting YES or OK. PIN number “0000”(4 zeros)
Auto Connection
The BTSC1700 supports auto connection. And it will try to
re-connect to the last connected mobile phones when you
turn on the BTSC1700.
Caller Name Announce & Display
When there is an incoming call, the BTSC1700 will announce
& display the caller’s name.
[NOTE] For this function, you should download phonebook data from your
phones to the BTSC1700. If you do not download phonebook data,
the BTSC1700 will announce & display caller’s number only.
Phonebook Download
You can manually download phonebook. Please press
volume up (+) button for 3 seconds. Then the BTSC1700
will start to download phone book data from your mobile
phone automatically.
It will take more than 1min. or more based on your phone
book data size.
[NOTE] To cancel phonebook download, press Volume down (-) button for
3 seconds.
7
Uniden Btsc1700 Android ™ Application
You can check E-mail, SMS, today’s schedule & weather with
this free application. Go to the Android ™ market and search
“Uniden BTSC1700”. Download and install it on your mobile
phone and activate. Once you install it, please go to the
setting menu and check the services you desire.
SMS Setting
SMS Setting
SMS Message Read On/O
Mail Setting
Email
Email Message Read Setting
Mail Setting
Mail POP3 / IMAP Setting
Calender Setting
Calender
Calender Reading On / O
Weather Setting
Weather
Weather Reading On / O
Text to Speech Setting
TTS
TTS Setting
This service is
powered by Google
TTS. Currently
available languages
are; UK/US English,
French, Spanish,
Germany and Italian.
[NOTE] To use the T TS (Text
to Speech) function, please
activate the TTS option on
your mobile phone’s Voice
or TTS setting menu.
8
Making and Receiving Calls
Making A Call
1. Last call-Redialing
Press the Multi-Function button.
2. Voice Dialing
Press the Multi-Function button for 1 second until you
hear a beep sound, then voice dialing is activated on
the BTSC1700. If you want to cancel voice dialing, press
the Multi-Function button for 1 second during the voice
dial Mode.
[NOTE] Please make sure that your phone supports the voice dialing
feature. (See your phone’s manual for detailed instructions)
Receiving A Call
When you receive phone calls, the BTSC1700 will announce
“PLEASE SAY ANSWER or IGNORE”. Say “ANSWER” to take
the call. You can take the call at any time by pushing the
multifunction button.
Rejecting A Call
When you receive phone calls, the BTSC1700 will announce
“PLEASE SAY ANSWER or IGNORE”. Say “IGNORE” to reject
the call. Or press the Multi-Function button for over 1
second.
9
Ending A Call
Press the Multi-Function button during the call or just press
the “End” button on the phone.
Transferring A Call
To transfer a call from the BTSC1700 to your mobile phone
and vice versa, press the Multi-Function button on the
BTSC1700 during the call for 1 second until you hear a beep.
Adjusting The Volume
You can adjust the volume by pressing the volume up (+) or
down (-) button during the call.
Mic Mute
If you press the Volume down (-) for 1 sec., the microphone
will be muted and you will hear a beep every 10 seconds
during the mute mode.
[NOTE] The MIC mute mode can be deactivated by pressing Volume down
(-) for 1 sec. again.
10
Call Waiting
To activate call waiting function, you must subscribe to call
waiting through your service provider, and your phone must
support the hands-free profile.
1. To put your current call on hold and switch between
the two calls, press and hold volume up (+) for about
3 seconds. When you release the button, you’ll be
connected to the waiting call.
2. To hang up your current call and switch to the waiting
call, press and hold volume down (-) for about 3
seconds. When you release the button, you’ll be
connected to the waiting call.
[RECOMMENDED] Press the “SEND” button of your mobile
phone to activate the call waiting function.
[NOTE] Some features may not be compatible with certain mobile.
Inverting The OLED Display
To reverse the OLED display, please press both MultiFunction button and Volume up (+) button for 3 seconds.
Resetting The BTSC1700
Press and hold Multi-Function button and volume down(-)
button simultaneously for 3 seconds until you hear 2 rings.
Then all information in the BTSC1700 will be deleted.
[NOTE] Resetting is only possible when in standby mode after
disconnecting with your mobile phone.
11
Multipoint: Using The BTSC1700 With Two Phones
[NOTE] Some mobile phones are not available for Multipoint.
1. Multi-point Connect
• Set the handsfree unit into pairing mode rst. After
then search BTSC1700 from each mobile phones at the
same time.
• Please connect rst mobile phone. Once the
connection is completed, please connect the second
mobile phones.
[NOTE] Some mobile phones need to perform the connection process at
the same time.
2. Making a call [via the second mobile phone]
• Press the Multi-Function button twice shortly for last
call-redialing from the second mobile phone.
• Press the Multi-Function button for about 3 seconds to
activate the voice dialing of the second mobile phone.
[NOTE] Making a call via the rst mobile phones, please follow the same
instruction as described on “MAKING A CALL”.
3. Receiving a call
Please use the general rule as you receive calls
[NOTE] Each mobile phone plays dierent ring tones.
GPS Guide
If your mobile phone has GPS navigation guide then you can
listen to the guide through the BTSC1700. To activate this
feature, please make sure your mobile phone supports the
A2DP profile.
12
Specications
Model Name BTSC1700
Bluetooth Core Spec Bluetooth Speci cation 3.0
Prole HSP, HFP, A2DP, PBAP, SPP
Carrier Frequency 2402 MHz to 2480 MHz
Audio Output 2W (4Ω)
Modulation Method GFSK, 1Mbps, 0.5BT Gaussian
Asynchronous: 2178.1 kbps /
Maximum Data Rate
Bluetooth Class Class 2
Hopping
Transmit Power 0 dBm
Coverage Range 10 Meters
Receiver Sensitivity -80 dBm / 0.1 % BER
Continuous Talk
Time
Standby Time 400 Hours
Charging Voltage DC 5.0 V
Charging Time 3 Hours
Operating
Temperature
Storage Temperature -40° to +90°C
Battery Lithium Polymer 3.7V 700mAH
177.1 kbps
Synchronous: 1306.9 kbps /
1306.9 kbps
1600 hops/sec, 1MHz Channel
Space
Max. 15 Hours
-20° to +70°C
13
SAFETY AND GENERAL INFORMATION
1. Please read this manual carefully and follow the
instructions.
2. To avoid any damage or malfunction of the unit, do not
drop it from a high place.
3. Keep unit away from humidity, water and any other
liquid. If the unit is exposed to water, moisture and
other liquid directly, then do not operate it to avoid any
electrical shock, explosion or damage to the unit.
4. Do not place or keep the unit near heat sources such
as direct sunlight, radiators, stoves or other apparatus
which produce heat. It may cause explosion, degrade
performance and reduce battery life.
5. Do not modify, repair or disassemble the unit
(especially battery: it may cause an explosion).
6. Do not place heavy objects on the unit.
7. Use only the supplied approved car and AC charger.
8. Replacement or service must be done at a qualied
service center or manufacturer.
9. Unplug this unit when unused for long period of time
or during lightening storms.
[CAUTIONS] ELECTRIC SHOCK HAZARD The battery used in this device may
present a risk of re or chemical burn if mis-treated.
14
Two Year Limited Warranty
UNIDEN BTSC1700 Bluetooth Wireless Speaker
IMPORTANT: Evidence of the original purchase is required for warranty service.
Warrantor: Uniden Australia Pty Limited ABN 58 001 865 498
Uniden New Zealand Limited
Elements of Warranty: Uniden warrants to the original retail owner for the duration of this
warranty its BTSC1700 (hereinafter referred to as the Product), to be free from defec ts in
materials and craftsmanship with only the limitations or exclusions set out below.
Warranty Duration: This warranty to the original retail owner only is only valid in the
original country of purchase and shall be of no further eect 2 years after the date of
original retail sale. This warranty will be deemed invalid if the Product is: (A) Damaged or
not maintained as reasonable and necessary, (B) Modied, altered or used as part of any
conversion kits, subassemblies, or any congurations not sold by Uniden, (C ) Improperly
installed, (D) Repaired by someone other than an authorized Uniden Repair Agent for a
defect or malfunction covered by this warranty, (E) Used in conjunction with any equipment
or parts or as a part of a system not manufactured by Uniden. (F) Only available in the
original country of sale.
Parts Covered: This warranty covers for two (2) years, the Product and included accessories.
Statement of Remedy: In the event that the Product does not conform to this warranty
at any time while this warranty is in eect, the warrantor, at its discretion, will repair the
defect or replace the Product and return it to you without charge for parts and service. This
warranty does not provide for reimbursement or payment of incidental or consequential
damages. This EXPRESS WARRANT Y is in addition to and does not in any way aect your
rights under the TRADE PRACTICES ACT 1974 (Cth) (Australia) or the CONSUMER GUARANTEES
ACT (New Zealand).
Procedure for obtaining performance or warranty: in the event that the Product does
not conform to this warranty, the Product should be shipped or delivered, freight prepaid,
with evidence of original purchase (e.g. a copy of the sales docket) to the warrantor at:
UNIDEN AUSTRALIA PTY LTD UNIDEN NEW ZEALAND LTD
Service Division Service Division
345 Princes Highway, 150 Harris Road, East Tamaki,
Rockdale, NSW 2216 Auckland 2013
Fax (02) 9599 3278 Fax (09) 274 4253
www.uniden.com.au ww w.uniden.co.nz
15
© 2011 Uniden Australia Pty Ltd/Uniden New Zealand Limited
Printed in PRC
Loading...
