Page 1

Quick Start

Guide

DSS 2455/

2465

Digital Spread Spectrum provides the longest range, the clearest sound and the best privacy.

Page 2

•This symbol

AVOID -

connecting

more than

phones as ringing

may be impaired

AVOID multi power boards.

CHARGE the new phone for 17 - 20 hrs.

AVOID Moisture

Don’t overload the power outlet.

indicates important operating and servicing instructions.

•The earcap of this telephone may attract and retain small metallic objects.

[ i ]

INSTALLATION & SAFETY

Choosing the best location for your phone. When choosing a location for your phone there are a number of appliances the phone should not be near, and areas you should avoid.

AVOID Television sets and other electronic appliances

AVOID Microwave ovens

AVOID moisture

AVOID Computers

CHOOSE a central location

AVOID other cordless telephones

Note: Ringing will not be impaired by

adding extra cordless handsets.

Page 3

QUICK START GUIDE

S tart

Here!

The Quick Start Guide is a very condensed version of the Owner’s Manual. It is designed to allow you to get your phone installed and operating as quickly as possible - however it does not attempt to explain any of the advanced features of the DSS2455 and DSS2465 series.

Installing the Base Unit

1) Install the desk top/wall mount bracket into the notches on the base top for desk top mounting.

For wall mounting, see “Mounting the Base Unit on a Wall” on page 6.

2) Connect the AC adapter to the AC ADAPTER jack and to a standard AC wall outlet.

AC adapter (supplied)

3) Connect the telephone line cord to the TEL LINE jack and to a telephone socket on the wall.

New Zealand

Australia

To AC outlet

To telephone socket

Telephone line cord (supplied)

To AC adapter

To TEL LINE

Make sure the AC Adapter/s remains switched ON at all times. Use only the Uniden AC Adapter/s supplied with this unit.

[ ii ]

Page 4

4) Set the base on a desk or tabletop.

5) Rise the antenna to a vertical position.

Connecting the charger - DSS2465 only

1) Connect the AC adapter into the charging cradle and to a AC wall outlet.

2) Set the charger on a desk or tabletop, and place the handset in the charger with the keypad facing forward (see “Installing the AA batteries” below to install the batteries.

•Use only “AA”

rechargeable Ni-MH batteries. Do Not use

Alkaline, Lithium, or non-rechargeable batteries. Using incorrect batteries could damage or limit the performance of this unit.

•Recharge your phone on a regular basis by returning the handset to the charger after each phone call.

[ iii ]

Installing the AA batteries

1) Press down on the battery cover release and slide the cover down until it comes off.

2) Install the batteries supplied with your phone, observing correct + - polarity.

Page 5

3) Securely close the battery compartment cover by sliding it up until it snaps into place.

Charging the handset

1) Place the handset in the charging cradle with the keypad facing up.

The DSS2455 and DSS2465 series will only work with “AA” Ni-MH rechargeable batteries. If you use any other type of batteries, the display will show “Use rechargeable battery only”.

2) Make sure the charge LED illuminates. If the LED does not illuminate, check to see that the AC adapter is plugged in and switch on. Clean the handset and base charge contacts with a pencil eraser.

• After installing the batteries in the handset, charge your handset at least 17-20 hours.

During a power cut or if the AC Adapter is switched off, this telephone will not operate.

[ iv ]

Page 6

CONTENTS

INSTALLATION & SAFETY i QUICK START GUIDE ii CONTENTS v GETTING STARTED 1

Controls and Functions 1 Uniden Company Philosophy 3 Welcome 3 Features 4 Checking the Package Contents 5 Terminology 5 Mounting the Base Unit on a Wall 6 Battery Maintenance 6 Installing the Beltclip 7 Headset Installation 8 Display and Icons 8 About Soft Key Function 9 DSS2455/DSS2465 Flow Chart 10 About the Menu 12 Setting up the Menu 15

BASICS 23

Making and Receiving Calls 23 Placing a Call on Hold 24 Redialing a Call 24 Adjusting the Earpiece and Handset Speaker Volume 26 Clarity Booster 26 Ringer Mute (temporarily) 27 Mute Microphone 27 Traveling Out-of-Range 27 Flash and Call Waiting 28 New Message LED 28

PHONEBOOK 29

Storing Phone Numbers, Names,

Distinctive Rings, and Speed Dial 29

[ v ]

Steps for Entering Names and Special Characters 31 Viewing the Phonebook 33 Making Calls Using the Phonebook 34 Speed Dialing 34 Editing or Erasing a Stored Name, Phone Number,

Distinctive Ring, and Speed Dial 35 Chain Dialing 36 Memory Dialing (base only) 36

CALLER ID 37

Viewing the Caller ID List 38 Deleting Information from the Caller ID List 39 Using the Caller ID Message List 40

THE INTEGRATED ANSWERING DEVICE 41

Turning the Answering System On/Off 42 Setting up your Answering System 42 Using your Answering System 49 Remote Operation 52

EXPANDING YOUR PHONE 55

Connecting the Charger 55 Register the Handset 56 Using Two Way Communication between the Handsets

Anywhere without the Base (DirectLink) 57 3-Way Conferencing 58 4-Way Conferencing 58 Intercom/Call Transfer Feature 59

ADDITIONAL INFORMATION 61

Changing the Digital Security Code 61 Note on Power Sources 62

TROUBLESHOOTING 63 INDEX 66 REMOTE OPERATION CARD 67 WARRANTY 69

Page 7

10 11

16 17

GETTING STARTED

CONTROLS AND FUNCTIONS

1. Handset Antenna

2. Headset Jack Cover

3. Beltclip Hole

4. Hands Free Speaker

5. Handset Battery Compartment

6. New Message LED

7. Handset Earpiece

8. LCD Display

9. Key

10. Key

11. Key

12. Soft Keys

13. /

14. Key

15. /

16. Key

17. Key

18. Handset Microphone

19. Handset Charging Contacts

▲ (up) Key

▼ (down) Key

[ 1 ]

Page 8

28 29 30

31 32

21 2223 24 25 26

34 35

36 37

38 39 40 41

42 43 44

46 47

(DSS2465 only)

20. Base Speaker

21. (repeat)/SELECT Key

22. (delete) Key

23. Key

24. Message Counter Display

25. Key

26. (answer on) Key

27. Charge LED

28. Key

29. Key

30. Key

31. Key

32. Key

[ 2 ]

33. Base Charging Contacts

34. Base Antenna

35. (skip)/SELECT Key

36. In use LED

37. (play/stop) Key

38. Key

39. (record) Key

40. Key

41. Key

42. (talk) Key/speaker LED

43. (volume) / ▲ (up) Key

44. (volume) /

▼ (down) Key

45. Microphone

46. Telephone Input

47. DC Power Input

48. Charging Contacts (DSS2465 only)

49. Charge LED (DSS2465 only)

50. DC Power Input (DSS2465 only)

Page 9

UNIDEN COMPANY PHILOSOPHY

To bring outstanding wireless communication products to people’s lives throughout the world.

WELCOME

Congratulations on your purchase of this Uniden DSS2455 or DSS2465 series Multi Handset Cordless System telephone. This unit is different from conventional cordless telephones. It can support up to 4 handsets. Using extra handsets (optional), you can establish a 4-way conference call (2 handsets-Base Speaker Phone-an outside line, or 3 handsets-an outside line). Additionally, with 4-way conference using 2 handsets, another 2 handsets can establish an intercom call. You can now place a fully featured cordless handset anywhere in your home or office where AC power is available to connect the handset chargers.

Note: Some illustrations in this manual may differ from the actual unit for explanation purposes.

[ 3 ]

Page 10

FEATURES

Great features of this cordless phone include:

• Designed and Engineered in Japan

• 2.4GHz Digital Spread Spectrum

• Integrated Digital Answering Machine

• Multi (4) Handset Capable (2 handsets Included (DSS2465 only))

• Long Range (up to 1km)

• Dual Keypad (Backlit on Handsets)

• Digital Duplex Speakerphones on Handset and Base Advanced Alpha Display Caller ID Features:

• Alpha Memory Dialling

• POP ID - Caller Name Identification*

• 16 Indi vidua l Caller Tone Allocation (8 Rings/8 Melodies)

• 100 Caller ID * Memories with Phonebook

• 4 Line Backlit Full Dot Matrix LCD Display with Clock

• Maxi-Sound - Extra Loud Handset Volume Control

• Intercom/Announce Call Transfer

• Handset Conferencing (for example, 2 handsets + Base + Outside Call)

• Two-Way Communication between Handsets Anywhere without the Base

• Conversation Record

• And More!

* Caller ID and POP ID features work only if you subscribe to the service provided by your local telephone company.

There is usually a fee for this service.

Range may vary depending on environmental and/or topographical conditions.

[ 4 ]

Page 11

CHECKING THE PACKAGE CONTENTS

Make sure you have received the following items in the package. If any of these items are missing or damaged, contact your retailer.

• Base unit (1)

• Handset [DSS2455 (1) / DSS2465 (2)]

• AC adapter [DSS2455 (1) / DSS2465 (2)]

• Rechargeable batteries [DSS2455 (2) / DSS2465 (4)]

Also included:

• This Owner’s Manual

• Other Printed Material

• Telephone cord or adapter (1) (Australia)

• Telephone cord (1) (New Zealand)

• Beltclip [DSS2455 (1) / DSS2465 (2)]

• Charger (1) [DSS2465 only]

Uniden Australia Pty Limited Service Division

Ph : 1300 366 895 We can also be reached

at www.uniden.com.au

Uniden New Zealand Limited Service Division Ph : 0800 4 UNIDEN

(0800 4864 336) We can also be reached at www.uniden.co.nz

TERMINOLOGY

Throughout this manual, terms such as Standby and Talk Mode are used. Below is the terminology explanation. Standby Mode - The handset is not in use, is off the cradle, and or has not been pressed.

A dial tone is not present. Talk Mode - The handset is not in the cradle and or has been pressed enabling a dial tone. “Talk” appears on the display. DirectLink - Two way communication between the handset anywhere without the base.

[ 5 ]

Page 12

MOUNTING THE BASE UNIT ON A WALL

3mm

10cm

35mm

You can mount your base directly to the wall. Before doing this, consider the following:

• Avoid electrical cables, pipes, or other items behind the mounting location that could cause a hazard when inserting screws into the wall.

• Mount your phone within distance of a working phone jack.

• Make sure the wall material is capable of supporting the weight of the base and handset.

• Use screws with anchoring devices suitable for the wall material where the base unit will be placed.

1) Insert two mounting screws into the wall (with their appropriate anchoring device),

10cm apart. Allow about 3mm between the wall and screwheads for mounting the phone.

2) Snap the desk top/wall mount bracket into the notches on the base bottom.

3) Plug the AC adapter into the AC ADAPTER jack on the telephone and then into a

Standard AC wall outlet.

4) Plug the telephone line cord into the TEL LINE jack on the telephone and then into

the telephone socket on the wall.

5) Align the mounting slots on the base with the mounting posts on the wall.

6) Then push in and down until the phone is firmly seated.

This phone also can be mounted on any standard telephone wall plate (for Australia).

1) Snap the desk top/wall mount bracket into the notches on the base bottom.

2) Refer to step 3 through 6 to mount the base.

BATTERY MAINTENANCE

Battery use time (per charge)

Fully charged (17-20 hours charge time)

• Up to 7 hours continuous use (up to 5 hours when the clarity booster is on)

• Up to 14 days when the handset is in the standby mode (up to 24 hours when in DirectLink mode)

Recharge your phone on a regular basis by returning the handset to the charger after each phone call.

[ 6 ]

Page 13

Low battery alert

When the batteries are very low and need to be charged, the phone is programmed to eliminate functions in order to save power. The batteries need to be charged when:

- The empty battery icon appears.

- “Low Battery” appears in the display. If the phone is in the standby mode, none of keys will operate. If you are on a call,

complete your conversation as quickly as possible, and return the handset to the cradle.

Low Battery

Cleaning the battery charging contacts

To maintain a good charge, it is important to clean the charging contacts on both the handset and the base unit once a month. Use a dry cloth or pencil eraser to clean.

Battery replacement and handling

When the operating time becomes short, even after a battery is recharged, please replace the battery. Please use only “AA” rechargeable Ni-MH batteries.

Caution

• Use only “AA” rechargeable Ni-MH batteries.

• Do not remove the batteries from the handset to charge them.

• Never throw the batteries into a fire, disassemble them, or heat them.

• Do not remove or damage the battery casing.

To avoid the risk of personal injury or property damage from fire or electrical shock, only use the Uniden adapter model specifically designated for this product, and “AA” rechargeable Ni-MH batteries.

contacts

INSTALLING THE BELTCLIP

To attach the beltclip

Insert the beltclip into the holes on each side of the handset. Press down until it clicks into place.

To remove the beltclip

Pull both sides of the beltclip to release the tabs from the holes.

[ 7 ]

Page 14

HEADSET INSTALLATION

Handset ID and Banner Number of new Caller ID calls received

Battery icon

Soft keys (These will not be displayed while the handset is charging in the cradle.)

Ringer off icon (when the ringer is Off)

Day of the week and time (hh:mm/A/P)

SUN 12:00A Handset #1 New: 5

MENU CID RDL PB

Your phone may be used with an optional headset, the Uniden HS910. To use this feature, insert the headset plug into the headset jack. Your phone is ready for hands-free conversations.

DISPLAY AND ICONS

Example of the standby mode display

ICON STATUS DESCRIPTION

Standby/Talk

[ 8 ]

Battery icons indicate the handset battery status. This icon cycles depending on the battery status (empty, low, medium, and full).

indicates that the batteries installed are not for use with this

phone, remove the batteries immediately.

Standby Standby Handset Remote soft key is used to play an incoming message remotely.

Talk Mute icon appears when you mute the handset. Talk Speaker icon appears when the handset speaker phone is used. Talk Recording icon appears while recording a conversation.

Ringer off icon indicates that ringer is set to Off.

Page 15

ABOUT SOFT KEY FUNCTION

SUN 12:00A Handset #1 New: 5

MENU CID RDL PB

Soft key 1 Soft key 2 Soft key 3

Talk 999:59 1234567890

MUTE MENU

CALL WAIT

Soft key 1 Soft key 2 Soft key 3

Talk 999:59 1234567890

MUTE MENU

Soft key 1 Soft key 2

In the standby mode In the talk mode

Soft key functions consists of soft key icons and soft keys (No. 1, 2, and 3). Each soft key corresponds to the icon displayed above, and each icon will be changed depending on the operation. Press the corresponding soft key to enter a menu, or select an item. In this manual, we refer to this combination of icons and keys as the soft key.

For example, you will use the soft keys when you want to:

- Access the main menu

- Access Caller ID messages stored

- Store or edit phone numbers

- Redial one of the last three numbers dialed from the handset

- Etc…. Note: The soft key icons will not appear while charging the handset.

(Australia model) (New Zealand model)

[ 9 ]

Page 16

DSS2455/DSS2465 FLOW CHART

• From the standby mode

Caller ID

▲

Redial History

Phonebook

▼

BACK BACK OK

Select a menu, then press the OK soft key.

Setup the menu:

• See page 37 for Caller ID.

• See page 24 for Redial.

• See page 29 for Phonebook.

[ 10 ]

SUN 12:00A

CID

Handset #1

RDL

New: 5

MENU CID RDL PB

Play incoming messages remotely (see page 52).

DirectLink Mode

Handset Setup

Answ. Setup

BACK OK

OK soft key

To enter DirectLink mode press [ENTER]

BACK BACK ENTER

ENTER soft key

SUN 12:00A Handset #1 DirectLink Mode

CANCEL DirectLink

DirectLink soft key

Go to DirectLink operation (see pages 16, 57).

SUN 12:00A Handset #1 DirectLink Mode

CANCEL DirectLink

CANCEL soft key, then OK.

Normal standby mode

▼

DirectLink Mode Handset Setup Answ. Setup

OK soft key

▲

Ringer Volume

Ringer Tones

▼

Distinct. Ring Auto Talk Anykey Answer Banner Contrast

OK soft key

Setup the menu (see pages 16-18).

▼

OKBACK

Page 17

• From the Talk mode

DirectLink Mode

▼

Handset Setup Answ. Setup

BACK OK

OK soft key

<ANSW. SETUP>

▲

Security Code

Ring Time

▼

Record Time Message Alert Call Screen Answer Mode

OK soft key

Setup the menu (see pages 19-20).

Handset Setup

▼ ▼

Answ. Setup Global Setup

OK soft key

▲

Name Tag

Insert 0

▼

Day & Time

OKBACK

OK soft key

Setup the menu (see pages 21).

“Insert 0” is available only for New Zealand model.

Answ. Setup Global Setup

OKBACK

System Reset

OK soft key

▲

Deregister HS

Replacing Base

▼

OKBACK

BACK BACK OK

OK soft key

Setup the menu (see page 22).

Talk 999:59 1234567890

OKBACK

MUTE MENU

• Press the MUTE soft key to mute a call (see page 27).

• Press the MENU soft key, then select:

- “Booster On” to improve

the sound quality (see page 26).

- “Recording” to record the

conversation (see page 51).

CALL WAIT

- “Caller ID” to view Caller

ID list (see page 38).

- “Phonebook” to view

phonebook locations (see page 33).

- “Redial History” to view

the last three numbers dialed (see page 24).

• Press the CALL WAIT soft key to access the Call Waiting (see page 28) (Australia only).

[ 11 ]

Page 18

For Answ. Setup, Global Setup, and System Reset (Deregister HS) menu, make sure the line is not in use, and the handsets are within the range limits of the base.

[ 12 ]

ABOUT THE MENU

Most of the handset settings are set from the menu. The menu has 5 main menus (DirectLink Mode, Handset Setup, Answ. Setup, Global Setup, and System Reset) and submenus respectively.

Summary of the Main Menu and Submenu

Two Way Communication between the Handsets Anywhere without the Base (DirectLink)

Select this menu to enter the Two Way Communication between the Handsets Anywhere without the Base (DirectLink) mode. If you have 2 or more handsets, a pair of handsets work as transceivers. Use them at a shopping mall to stay in contact with family and friends. To use this feature, you must set the two handsets to the DirectLink mode first (see page 16).

DirectLink menu only applies when you have 2 or more handsets.

Handset Setup

All settings must be set separately for each handset in the Handset Setup menu.

Submenu name Description

Ringer Volume Adjust the ringer volume (see page 16). Ringer Tones Adjusting the ringer tone (see page 17). Distinct. Ring Set the distinctive ring (see page 17). “Distinctive Ring” allows you to

(Distinctive ring) preset memory locations with a designated ring tone. When an incoming call

is received and the Caller ID information matches the information in one of the memory locations, the distinctive ring that has been stored for that particular Caller will sound. If you have set multiple memory locations with distinctive rings, switching the setting to “Distinctive Off” will result in no distinctive ringing. All incoming calls will have a normal ring tone. Switching to “Distinctive On” will activate all programmed distinctive ring memory locations.

Page 19

Submenu name Description

Auto Talk Allows you to answer the phone without pressing or .

When the AutoTalk is set to On, simply remove the handset from the cradle and the phone automatically answers the call (see page 17).

Anykey Answer Allows you to answer the phone without pressing or .

When the Anykey Answer is On, you can answer a call by pressing any number key, , or on the handset (see page 18).

Banner Customize the name of your handset, and display it in the LCD in the standby

mode. For example, you can name the handset “John” (see page 18).

Contrast Adjust the handset LCD brightness for better viewing (10 levels) (see page 18).

Answering Setup

This menu allows you to set up Answering Machine settings from your handset. You can also set these setup menus from the base (see page 44).

Submenu name Description

Security Code Select a two-digit Personal Identification Number (PIN) code. A PIN code is

required to play your messages from a remote location, you will need to enter a two-digit PIN code (see page 19).

Ring Time Allows you to set the number of rings the caller hears before your answering

system plays the outgoing message. You can set the ring time to answer after 4, 6, or 9 rings. Setting “TS” (Toll Saver), the answering system picks up after 6 rings if you have new messages, and after 9 rings if there are none (see page 19).

Record Time Set the duration for recording the incoming messages. You have three record

time options. The options “1 minute” or “4 minutes” set the duration for recording the incoming messages. “Announce only” answers the call with the preset greeting or your personal greeting but prevents the caller from leaving a message (see page 19)

Message Alert Lets you know when you have a new incoming message by sounding a short

alert tone (see page 20). Call Screen Set the call screening feature to On or Off (see page 20). Answer Mode Set your answering system to On or Off (see page 20).

[ 13 ]

Page 20

Global Setup

If you change the setting in one of the handsets, you change the settings for all handset(s) in the Global Setup menu. Only one handset can change a setting at a time.

Submenu name Description

Name Tag (POP ID) Display the stored name with the Caller ID telephone number, if the displayed

Insert 0 Add “0” or “00” to the number, when you receive the Caller ID message (New Zealand only) (see page 21).

Day & time Set the day and time of your display (see page 21).

Caller ID telephone number is exactly the same as a number stored in the phone book (see page 21).

System Reset

This menu is used to clear the handset ID from the base, or the base ID from the handset.

Submenu name Description

Deregister HS Clear the handset ID from the base. Use this menu, for example when

Replacing Base Clear the base ID. Use this menu, for example, if you wish to deregister

you change the digital security code (see page 22).

the base to use the handset with another base of the DSS series (DSS2415/DSS2455/DSS2465 series) (see page 22).

[ 14 ]

Page 21

SETTING UP THE MENU

Entering the Menu

1) Press the MENU soft key in the standby mode.

2) Use / desired main menu (DirectLink Mode, Handset Setup, Answ. Setup, Global Setup, and System Reset).

3) Press the OK soft key to enter the menu. To return to the previous screen, press the BACK soft key.

4) Use / then press the OK soft key to enter.

In the submenu, /

▲ or ▼ to move the pointer to a

▲ or ▼ to select a desired submenu,

▲ or ▼ is used to select an item. Press the OK soft key to

SUN 12:00A Handset #1 New: 5

MENU CID RDL PB

DirectLink Mode Handset Setup Answ. Setup

BACK OK

confirm your selection. To return to the previous screen, press the BACK soft key. For detailed instructions, see the following sections for the desired submenu.

5) To exit the menu, press .

•If any of the following occurs during the menu operation, the operation will be cancelled.

- Press .

- Press or .

- Charge the handset.

- Receive an outside/intercom call or page.

•If the handset remains idle for 30 seconds, the phone will return to the standby mode.

For Answering Setup menu, you can also set them from the base (see page 44).

[ 15 ]

Page 22

•If you select “Ringer Volume Off”,

icon appears in

the display.

DirectLink Mode

Entering the Two Way Communication between the Handsets Anywhere without the Base

1) Enter the “DirectLink Mode” menu (see “Entering the Menu” on page 15).

2) Press the ENTER soft key to enter the DirectLink mode. You will hear a confirmation tone, and “DirectLink Mode Complete” appears.

3) To return back to the normal mode, exit the DirectLink mode. To exit the DirectLink mode, press the CANCEL soft key, then the OK soft key, or return the handset to the cradle.

To enter DirectLink mode press [ENTER]

BACK BACK ENTER

Handset Setup

Setting a Ringer Volume

1) Enter the “Handset Setup” menu, then the “Ringer Volume” submenu (see “Entering the Menu” on page 15).

2) Press / (Ringer Volume Off, Ringer Volume Low, or Ringer Volume High). You will hear a ringer or melody at the Selected volume (if you select “Ringer Volume Off”, no ringer or melody will sound).

3) Press the OK soft key. You will hear a confirmation tone.

▲ or ▼ to adjust the ringer settings

Ringer Volume

High

BACK OK

[ 16 ]

Page 23

Selecting a Ringer Tone

1) Enter the “Handset Setup” menu, then the “Ringer Tones” submenu (see “Entering the Menu” on page 15).

You can choose from 8 ringers or 8 melodies:

- Ringers [Flicker, Clatter, Soft Alert, Wake Up, Light Bug, Beep Boop, Tone Board, Chip Chop]

- Melodies [Beethoven’s Symphony #9 (Beethoven9), For

Ringer Tones Flicker Clatter

Elise (Elise), We Wish You A Merry Christmas (MerryXmas), Home Sweet Home (Hm Swt Hm), Lorri Song #6 (Lorri Song), When the Irish Eyes Are Smiling (Irish Eyes), Aura Lee, Let Me Call You Sweet Heart (Sweetheart)]

2) Press /

▲ or ▼ to move the pointer. You will hear the ringer or melody as

you scroll through the options.

3) Press the OK soft key. You will hear a confirmation tone.

Distinctive Ringer Setup

1) Enter the “Handset Setup” menu, then the “Distinct. Ring” submenu (see “Entering the Menu”

on page 15).

2) Press /

▲ or ▼ to select “On” or “Off”.

3) Press the OK soft key. You will hear a confirmation tone.

Distinctive Ring On Off

BACK BACK OK

Setting the Auto Talk

1) Enter the “Handset Setup” menu, then the “Auto Talk” submenu (see “Entering the Menu” on page 15).

2) Press / ▲ or ▼ to change the selection, “On” or “Off”.

3) Press the OK soft key. You will hear a confirmation tone.

Auto Talk On Off

BACK BACK OK

If you set the ringer volume to Off ,

OKBACK

the ringer tone will not sound.

[ 17 ]

Page 24

If you don’t enter a banner, the phone will use the handset ID for the banner (for example: Handset #1).

Setting the Anykey Answer

Enter the “Handset Setup” menu, then the “Anykey Answer” submenu (see “Entering the Menu” on page 15).

2) Press / ▲ or ▼ to change the selection,

Anykey Answer On Off

“On” or “Off”.

3) Press the OK soft key and you will hear a confirmation tone.

Setting the Banner

1) Enter the “Handset Setup” menu, then the “Banner” submenu (see “Entering the Menu” on page 15).

2) Use the number keypad ( - ), , , or the DELETE soft key to enter or edit the name. To delete all characters, press and hold the DELETE soft key, then enter the new name.

3) Press the OK soft key. You will hear a confirmation tone.

Banner

Adjusting the LCD Contrast

1) Enter the “Handset Setup” menu, then the “Contrast” submenu (see “Entering the Menu”

on page 15).

2) Press /

▲ or ▼ to adjust the contrast

of the LCD (10 levels).

3) Press the OK soft key. You will hear a confirmation tone.

Contrast

- +

BACK BACK OK

BACK OK

BACK BACK OK

[ 18 ]

Page 25

Answering System Setup

Setting a PIN Code

1) Enter the “Answ. Setup” menu, then the “Security Code” submenu (see “Entering the Menu” on page 15).

2) Enter a two-digit PIN code (01-99) using the number keypad ( - ).

3) Press the OK soft key. You will hear a confirmation tone.

Security Code 80

BACK OK

For Answering Setup menu, you can also set them from the base (see page 44).

Setting the Ring Time

1) Enter the “Answ. Setup” menu, then the “Ring Time” submenu (see “Entering the Menu” on page 15).

2) Press /

▲ or ▼ to select a Ring Time (Toll

Saver, 4 Times, 6 Times, or 9 Times).

3) Press the OK soft key. You will hear a confirmation tone.

Setting the Record Time

1) Enter the “Answ. Setup” menu, then the “Record Time” submenu (see “Entering the Menu” on page 15).

2) Press / (1 Minute, 4 Minutes, or Announce Only).

3) Press the OK soft key. You will hear a confirmation tone.

▲ or ▼ to select Record Time

Ring Time Toll Saver 4 Times

OKBACK

Record Time 1 Minute 4 Minutes

OKBACK

[ 19 ]

Page 26

Setting the Message Alert On or Off

1) Enter the “Answ. Setup” menu, then the “Message Alert” submenu (see “Entering the Menu” on page 15).

2) Press /

▲ or ▼ to choose “On” or “Off”.

3) Press the OK soft key. You will hear a confirmation tone.

Setting the Call Screen

1) Enter the “Answ. Setup” menu, then the “Call Screen” submenu (see “Entering the Menu” on page 15).

2) Press /

▲ or ▼ to choose “On” or “Off”.

3) Press the OK soft key. You will hear a confirmation tone.

Setting the Answer Mode

1) Enter the “Answ. Setup” menu, then the “Answer Mode” submenu (see “Entering the Menu” on page 15).

2) Press /

3) Press the OK soft key. You will hear a confirmation tone.

▲ or ▼ to choose “On” or “Off”.

Message Alert On Off

BACK BACK OK

Call Screen On Off

BACK BACK OK

Answer Mode On Off

BACK BACK OK

[ 20 ]

Page 27

Global Setup

Setting Name Tag (POP ID)

1) Enter the “Global Setup” menu, then the “Name Tag” submenu (see “Entering the Menu” on page 15).

2) Press / or “Off”.

3) Press the OK soft key. You will hear a confirmation tone.

Setting Insert Zero (New Zealand only)

1) Enter the “Global Setup” menu, then the “Insert 0” submenu (see “Entering the Menu” on page 15).

2) Press / or “Off”.

3) Press the OK soft key. You will hear a confirmation tone.

Setting Day and Time

1) Enter the “Global Setup” menu, then the “Day & Time” submenu (see “Entering the Menu” on page 15).

2) Press / then press the NEXT soft key.

3) Press the number keypad ( - ) to set the time, then press the NEXT soft key.

4) Press / press the OK soft key. You will hear a confirmation tone.

▲ or ▼ to change the selection, “On”

▲ or ▼ to select the day of the week,

▲ or ▼ to choose “AM” or “PM”, then

Name Tagging On Off

Insert 0 On Off

BACK BACK OK

Day & Time SUN 12:00 AM

BACK BACK NEXT

OKBACK

•When a Global setting is changed from one handset, this affects all registered handsets.

•For setting the Day and Time, the idle time-out is extended to 2 minutes.

[ 21 ]GETTING STARTED

Page 28

System Reset

Deregister the Handset

1) Enter the “System Reset” menu, then the “Deregister HS” submenu (see “Entering the Menu” on page 15).

2) Press / deregistered from the list, then press the OK soft key.

3) Press the OK soft key. You will hear a confirmation tone. When deregistration is complete, “Deregistration

Complete” appears.

4) After deregistering the handset, move to “Deregister the Base Setting” below.

Deregister the Base Setting

1) Enter the “System Reset” menu, then the “Replacing Base” submenu (see “Entering the

Menu” on page 15). “Do you want to replace Base?” appears.

2) Press the OK soft key. You will hear a confirmation tone. The base information will be deleted.

When replacing the base is complete, “Please Register” appears, register the handset(s) to the new base (see page 56).

▲ or ▼ to select the handset ID to be

Which Handset? Handset #1 Handset #2

BACK BACK OK

Are you sure to deregister Handset #1?

BACK BACK OK

Do you want to replace Base?

BACK BACK OK

[ 22 ]

Page 29

MAKING AND RECEIVING CALLS

On the handset, you may also use the speakerphone while talking to an outside call. Using the handset speakerphone is called “hands-free conversation”. This feature allows you to easily communicate while performing other tasks, such as cooking.

appears on the handset display during hands-free conversations.

You can easily switch a call from normal conversation to “hands-free conversation”. To switch a call, press during the call.

From the Handset From the Base

Normal conversation Hands-free conversation

To answer a call Handset On the Cradle Press (talk).

To make a call Handset Off the Cradle Handset Off the Cradle

To h ang up To enter a pause When you dial the number in the standby mode, Press (talk).

within the press the PAUSE soft key. When you dial the number, dialing sequence “

Pick up the handset (AutoTalk) or pick up the handset and press .

Handset Off the Cradle Handset Off the Cradle

Press any number key, , Press . or (Anykey Answer), or press .

1) Press . 1) Press . 1) Press (talk).

2) Listen for the dial tone. 2) Listen for the dial tone. 2) Listen for the dial tone.

3) Dial the number. 3) Dial the number. 3) Dial the number.

OR OR

Dial the number, then Dial the number, then press . press .

Press , or return the handset to the cradle (Auto Standby).

P” appears in the display, which represents a pause. press .

Press (talk).

•To set “Auto talk”, see page 17 or “Anykey Answer”, see page 18.

•The handset microphone is located at the bottom of the handset (see “Controls and Functions” on page 1). Position yourself as near to the handset as possible and speak clearly.

•If the line is in use by another handset(s),

“Line In Use”

BASICS

appears in all registered handset’s display, that are not in use.

•The base microphone is located under the base. Position yourself as near to the base as possible and speak clearly.

[ 23 ]

Page 30

PLACING A CALL ON HOLD

BACK DELETE

<Redial2> 5452930

BACK DELETE

BACK DELETE

6567983

0295979035

•If you press , the operation is canceled.

•When the telephone is automatically redialing a number, the speaker function is disabled for a few seconds.

[ 24 ]

1) During a call, press (or on the base).

Once 10 seconds has passed or when you press , the call will be put on hold.

2) To talk to the caller, press or on a handset (or (talk) on the base). The phone will return back to the call.

You can hold a call for 5 minutes, when 5 minutes has passed, the call is disconnected and the phone returns to the standby mode.

REDIALING A CALL

The last three phone numbers dialed can be quickly redialed.

Redialing from Standby Mode

1) Press the CID RDL PB soft key in the standby mode.

2) Press / History”, then press the OK soft key. The phone number that was last dialed appears in the display.

3) Press / three phone numbers dialed.

4) Press or . The selected number is dialed.

5) To hang up, press .

▲ or ▼ to select “Redial

▲ or ▼ to toggle through the last

Hold,to transfer Handset #2 Handset #3

BACK BACK OK

Line On Hold Handset #1 New: 1

MENU CID RDL PB

Page 31

Redialing from Talk Mode

1) Press or , then press the MENU soft key.

2) Select the number you dialed by following steps 2-3 in “Redialing from Standby Mode”. To return to go back, press the BACK soft key.

3) Press the DIAL soft key.

4) To hang up, press .

Redialing from the Base

1) Press (talk).

2) Press on the base. The last number dialed from the base is redialed.

3) To hang up, press (talk).

Deleting a Redial Record

1) In the standby mode, recall the desired number by following steps 1-3 in “Redialing from Standby Mode”.

2) Press the DELETE soft key.

3) Press /

4) Press the OK soft key. The redialed number is deleted.

▲ or ▼ to choose “Yes”.

Delete Redial1? Yes No

BACK BACK OK

[ 25 ]

Page 32

Talk 0:15

- Volume +

MUTE MENU

Talk 0:15

- Volume +

MUTE MENU

CALL WAIT

•To adjust the base ringer or speaker volume, see page 43-44.

ADJUSTING THE EARPIECE AND HANDSET SPEAKER VOLUME

You can select different volume levels for the handset earpiece and the handset speaker (4 levels: Low to Max). The volume can only be adjusted during a call. Press

▲ or ▼ to select the volume settings. When you

hang up, the phone keeps the last volume setting selected.

•If you press / ▲ in the maximum volume level or / ▼ in the lowest volume level, you will hear a beep.

•CALL WAIT soft key appears only for Australia model.

CLARITY BOOSTER

•Normally, the talk time duration is 7 hours, however, when the Clarity Booster is On, the talk time duration will be up to 5 hours with fully charged batteries.

•Clarity booster automatically turns off after each call.

[ 26 ]

If you encounter interference while using your phone, you can manually improve the sound quality for clear operation. This works only when you make an outside call.

1) Press the MENU soft key.

2) Select “Booster On”, then the OK soft key. “Clarity Booster” appears in the display.

To turn Off the Clarity Booster, press the MENU soft key, select “Booster Off”, then press the OK soft

Booster On Recording Caller ID

BACK BACK OK

key again.

Page 33

RINGER MUTE (temporarily)

You can temporarily mute the handset and the base ringer tone. To mute the handset ringer tone, when the handset is off the cradle and the phone is ringing, press the MUTE soft key. To mute the base ringer tone, press on the base. The ringer tone will return to the previous setting starting with the next incoming call.

MUTE MICROPHONE

With the handset

You can temporarily turn Off the microphone so that the person you are talking with cannot hear you.

During a telephone call, press the MUTE soft key to turn Off the microphone. “Mute” and

appear in the display. Press the MUTE OFF soft key to cancel muting.

With the base

While using the base speakerphone, press on the base to turn Off the microphone. Press again, or press (talk) to cancel muting.

TRAVELING OUT-OF-RANGE

During a call, as you begin to move your handset too far from your base unit, noise may increase. If you pass the range limits of the base unit, you will hear a beep and “Out of Range” appears, then the handset returns to the standby mode. You may return back to the call if you move your handset within the range limits of the base, and press or within 30 seconds.

If you press to cancel muting, the call is disconnected and the phone will return to the standby mode.

[ 27 ]

Page 34

FLASH AND CALL WAITING

You must subscribe through your local telephone company to receive Call Waiting Service.

If the call waiting tone sounds during a call:

Talk 0:09 0295679035

AUSTRALIA: Press the CALL WAIT soft key.

NEW ZEALAND: Press to switch between callers.

To return to the original caller, press again.

MUTE MENU

CALL WAIT

NEW MESSAGE LED

The new message LED on the handset is designed to work with your answering system. The LED flashes when you have new messages in your answering system.

The LED stops flashing when all new messages are played back (see “Using your Answering System” on page 49).

[ 28 ]

Page 35

PHONEBOOK

Phonebook allows you to dial a number using just a few key presses. Your phone stores names/numbers in the phonebook memory location, and you can search names in alphabetical order. You have a total of 100 locations that can be used for the phonebook (including the Speed dials) and Caller ID messages.

•If any of the following occurs during a phonebook operation, the operation will be canceled.

Press . The phone will return to the standby mode (or the call will be disconnected).

-Press or .

-Receive an outside/intercom call or page.

-Charge the handset

•If the handset remains idle for 30 seconds, the phone will return to the standby mode (or back to the call).

You have a total of 100 locations. However, Caller ID messages and Phonebook share the memory locations.

STORING PHONE NUMBERS, NAMES, DISTINCTIVE RINGS, AND SPEED DIAL

1) When the phone is in the standby mode, press the CID RDL PB soft key.

2) Press / the OK soft key. The handset displays the following items: (1st line) The number of the phonebook locations used (2nd line) How to search (press the number keypad, / (3rd line) How to enter the storing operation (press the STORE soft key) (4th line) The BACK and the STORE soft keys.

▲ or ▼ to move pointer to “Phonebook”, then press

▲ or ▼)

Phonebook : 50 Search [A-Z/ / ] Store [STORE]

BACK BACK STORE

PHONEBOOK

[ 29 ]

Page 36

3) Press the STORE soft key, “Store/Edit Name” appears.

•When the memory is

full, you will hear a beep and “Memory Full” appears. You cannot store names and numbers.

•The pause key counts as one digit. Pressing the PAUSE soft key more than once increases the length of the pause between numbers. Each pause represents a 2 second delay.

•Distinctive ringing will only operate if you subscribe to the Caller ID service.

•Selecting a speed dial location where a number is already stored, releases the old number’s speed dial setting. The new number will be stored in the speed dial location.

4) Enter the name (up to 16 characters) by using the number keypad (see the “Steps for Entering Names and Special Characters” on page 31).

If a name is not required, go to step 5. <No Name> will be used as the name.

5) Press the OK soft key to store the name, “Store/Edit No.” appears.

6) Press the number keypad to enter the phone number (up to 20 digits), press the OK soft key to store the number.

7) “Distinctive Ring” appears. Press /

▼ to move the pointer to one of the Distinctive Ring

▲ or

options, then press the OK soft key.

If you choose not to store a “Distinctive Ring”, simply select the “No Selectn” option.

8) “Speed Dial” appears. Press / ▲ or ▼ to move the pointer to select the Speed dial location (10 locations: SPD1-SPD0).

If you choose not to store the name/number as a Speed Dial, simply select the “No Selectn” option.

9) Press the OK soft key. You will hear a confirmation tone and “Done!” appears in the display.

Store/Edit Name Movies

BACK DELETE OK

Store/Edit No. 8007303456

DELETE PAUSE OK

Distinctive Ring No Selectn Flicker

BACK OK

Speed Dial No Selectn SPD1:<Empty>

BACK OK

Movies 0800123456789 Flicker /SPD2

BACK DELETE EDIT

[ 30 ]

Page 37

STEPS FOR ENTERING NAMES AND SPECIAL CHARACTERS

Number of times key is pressed

Refer to the letters on the number keys to select the desired characters. With each press of a number key ( - ), the displayed character appears in the following order: Upper case letters first, lower case letters next and finally the number corresponding to the key.

[ 31 ]

Page 38

If the next character uses the same number key, you must press

to move the cursor over. Otherwise the next time you press the number key, it changes the character that was previously set.

If you make a mistake while entering a name

Use or to move the cursor to the incorrect character. Press the DELETE soft key to erase the wrong character, then enter the correct character. To delete all characters, press and hold the DELETE soft key.

For example, to enter Movies:

1) When the phone is in the standby mode, recall the “Phonebook” menu by following steps 1-2 in “Storing Phone Numbers, Names, Distinctive Rings, and Speed Dial” on page 29.

2) Press the STORE soft key, “Store/Edit Name” appears.

3) Press 6 once to select “M”, then press to move the cursor to the right.

4) Press 6 six times to select “o”.

5) Press 8 six times to select “v”.

6) Press 4 six times to select “i”.

7) Press 3 five times to select “e”.

8) Press 7 eight times to select “s”.

9) When finished, press the OK soft key.

To continue to store the telephone number, proceed to step 6 on page 30.

[ 32 ]

Page 39

VIEWING THE PHONEBOOK

Your phone stores names/numbers in the phonebook memory locations, and you can search names in alphabetical order. You can view the phonebook even while the phone is in use.

1) Press the CID RDL PB soft key (or the MENU soft key during a call).

2) Press / “Phonebook”, then press the OK soft key.

If you recall the phonebook during a call, the following screen appears.

3) Press / locations. Phonebook locations appear in alphabetical order (from first to last when you press /

Or, refer to the letters on the number keys to select the first letter of the desired name.

Press a number key ( - and ) once for the first letter, press twice for the second letter, and so on. The first location that begins with the letter you entered appears.

For example, to search for “Movies”, press 6 once. Press /

4) To finish the viewing operation, press the BACK soft key repeatedly or .

▲ or ▼ to move the pointer to

Phonebook : 50 Search [A-Z/ / ] Store [STORE]

BACK BACK STORE

Phonebook : 50 Search [A-Z/ / ]

BACK BACK OK

▲ or ▼, or the number keypad to scroll through the phonebook

▼, from last to first when you press / ▲).

▲ or ▼ until the phonebook location is displayed.

•“/SPDn” appears when you view a speed dial.

Movies 0800123456789 Flicker /SPD2

BACK DELETE EDIT

•During a call, don’t press or the call will be disconnected.

[ 33 ]

Page 40

MAKING CALLS USING THE PHONEBOOK

While the telephone is automatically dialing a number form speed dial memory, the speaker phone function is disabled for a few seconds.

[ 34 ]

From Standby Mode

1) When the phone is in the standby mode, view the phonebook location to dial (see “Viewing the Phonebook” on page 33).

2) Press or . The displayed number is dialed.

3) To hang up press .

Movies 0800123456789 Flicker /SPD2

BACK DELETE EDIT

From Talk Mode

1) Press or .

2) View the phonebook location to dial (see “Viewing the Phonebook” on page 33).

3) Press the DIAL soft key. The number in the displayed phonebook location is dialed.

4) To hang up press .

SPEED DIALING

If you store a phone number in a speed dial memory location (10 locations: SPD1 SPD0), you can use the speed dialing feature. When the phone is in the standby mode, press and hold a number key ( - ) associated with the speed dial until the phone number appears, then press or . The number stored in the speed dial (SPD1 - SPD0) is dialed.

Page 41

EDITING OR ERASING A STORED NAME, PHONE

NUMBER, DISTINCTIVE RING, AND SPEED DIAL

1) When the phone is in the standby mode, press the CID RDL PB soft key.

2) Press / ▲ or ▼ to move the pointer to “Phonebook”, then press the OK soft key.

3) Press / ▲ or ▼ , or the number keypad to view the phonebook locations (see “Viewing the Phonebook” on page 33).

a. Editing the Stored Data

1) When the phonebook location to be edited appears, press the EDIT soft key.

“Store/Edit Name” appears.

2) Follow the steps 4 to 8 under “Storing Phone

Numbers, Names, Distinctive Rings, and Speed Dial” on page 30 to complete the editing operation.

3) Press the OK soft key. You will hear a confirmation tone.

b. Deleting the Stored Data

1) When the phonebook location to be deleted appears, press the DELETE soft key.

“Delete Memory?” appears.

Phonebook : 50 Search [A-Z/ / ] Store [STORE]

BACK BACK STORE

Store/Edit Name Movies

BACK DELETE OK

Delete Memory? Yes

2) Press /

3) Press the OK soft key. You hear a confirmation tone.

“Deleted!” appears in the display.

▲ to move the pointer to “Yes”.

BACK BACK OK

[ 35 ]

Page 42

CHAIN DIALING

The memory locations in the handset are not limited to phone numbers. You can also store a group of numbers (up to 20 digits), that you need to enter once your call connects. This is referred to as Chain Dialing. An example of this is a bank account number. Store a special number in the phonebook location (refer to “Storing Phone Numbers, Names, Distinctive Rings and Speed Dial” on page 29). Once you have called your bank, and when you are prompted to enter the account number, just as you do when viewing the phonebook location, view the special number, then press the DIAL soft key.

MEMORY DIALING (base only)

•The 10 memory locations in the base are indep ende nt f ro m the handset.

•If you have not pressed any key for 30 seconds, the phone returns to the standby mode.

•If you make or receive a call, the operation is canceled.

[ 36 ]

You can store 10 phone numbers in the base, and make calls with memory dialing from the base.

Storing Phone Numbers

1) Press in the standby mode.

2) Enter the number you wish to store. (The number cannot exceed 20 digits.)

3) Press . Enter the memory location number (0-9) on the keypad. You will hear a confirmation tone.

Deleting the Stored Data

1) Press in the standby mode.

2) Press again.

3) Enter the memory location number (0-9) you wish to delete. You will hear a confirmation tone.

Making Calls with Memory Dialing

1) Press (talk) in the standby mode.

2) Press . Enter the memory location number (0-9) to dial the number.

Page 43

CALLER ID

You must subscribe to Caller ID service to use this feature.

When the telephone rings, the Caller ID feature allows you to view the caller’s name and phone number in the display before you answer the phone. Additionally, you can dial the displayed number and store the information for memory dialing.

Important:

Memory locations for Caller ID messages and Phonebook locations (including Speed Dials) are common, you can store up to 100 in total. A Caller ID message is not stored when you have stored 100 of the phonebook locations. The earliest Caller ID message is overwritten when you have stored 100 of the phonebook locations and Caller ID messages in total.

•If any of the following occurs during Caller ID operation, the operation will be canceled.

Press . The phone will return to the standby mode (or the call will be disconnected).

-Press or .

-Receive an outside/intercom call or page.

-Charge the handset.

•If the handset remains idle for 30 seconds, the phone will return to the standby mode (or back to the call).

1) When the Caller ID message is received, the display shows the caller’s phone number along with the date and time. The incoming call information is stored in the Caller ID record. The current telephone network in Australia and New Zealand does not show the caller name.

The date and time received Caller’s name Caller’s phone number Soft keys

31/12 12:30AM Jane Smith 0295979035

MUTE

•If you answer a call before the Caller ID message is received (Example: before the second ring), the Caller ID message will not appear.

•When the call is received via a

CALLER ID

telephone company that does not offer Caller ID service, the caller´s phone number does not appear. (This includes some international calls.)

•When the call is via a private branch exchange (PBX), the caller´s phone number may not appear.

[ 37 ]

Page 44

You may receive any one of the following messages: When invalid data is received “Incomplete Data” When a private name or number is received “Private” When a unknown name or number is received “Unavailable” When the mobile phone number and date are received “Mobile” When a call is coming from a payphone (Australia only) “Payphone” When a overseas call is received (New Zealand only) “OVERSEAS CALL”

2) When you pick up the phone, the display changes to “Talk” (AutoTalk feature is set to on).

VIEWING THE CALLER ID LIST

•The number of calls from the same Caller ID appears next to the received time. Once you have reviewed the new message, the number will be cleared and disappears.

•During a call, don’t press or the call will be disconnected.

[ 38 ]

The Caller ID list stores information for incoming calls – even unanswered calls. You can store 100 of the Caller ID messages and Phonebook locations (including Speed Dials) in total. You can view the Caller ID list during a call or when the phone is in the standby mode.

1) Press the CID RDL PB soft key in the standby mode (or the MENU soft key during a call).

2) Press /

▲ or ▼ to move the pointer to “Caller ID”, then press the OK soft

key. The screen shows the number of new messages and the total number of messages.

3) To view the Caller ID messages in historical order (from new to old or from old to new), repeatedly press / to the earliest, or /

▼ to scroll through the messages from the latest

▲ to scroll back through the messages.

Or, to view the Caller ID messages with alphabetical search, press the number key pad ( - and ) with the letter associated with the first letter of the desired message.

Once you view the Caller ID list with alphabetical search, you cannot switch back to historical order (from new to old or from old to new) unless you exit and re-enter the operation.

4) To finish the viewing operation, press the BACK soft key repeatedly or .

Page 45

DELETING INFORMATION FROM THE CALLER ID LIST

Deleting a Caller ID message

1) When the phone is in the standby mode, view the Caller ID information to be deleted (see “Viewing the Caller ID List” on page 38).

2) Press the DELETE soft key. “Delete Caller ID” appears.

3) Press /

▲ or ▼ to choose “Yes”.

4) Press the OK soft key.You will hear a confirmation tone.

Deleting all Caller ID names/numbers

1) When the phone is in the standby mode, press the CID RDL PB soft key.

2) Press / “Caller ID”, then press the OK soft key. The number of new and total records appear.

3) Press the DELETE soft key.

4) Press /

5) Press the OK soft key.You will hear a confirmation tone.

▲ or ▼ to move the pointer to

▲ or ▼ to choose “Yes”.

Delete Caller ID Yes No

BACK BACK OK

Caller ID New : 5 Total: 25

BACK DELETE

Delete All? Yes No

BACK OK

Once the Caller ID data has been deleted, the information cannot be retrieved.

[ 39 ]

Page 46

•You cannot make a call from the Caller ID list if your phone is connected to a private branch exchange (PBX).

•If a call comes in via a telephone system that does not offer Caller ID service, no information is stored.

•If the Caller ID message was received as a private/unknown number, or the message does not have the number, you cannot store the message in the Phonebook.

•Even if the 100 memory locations are full, the message will be stored in the Phonebook. However, the message will be erased from the Caller ID list.

USING THE CALLER ID MESSAGE LIST

Calling a party from the Caller ID list

From Standby mode

1) When the phone is in the standby mode, view the Caller ID message (see “Viewing the Caller ID List” on page 38).

2) Press or . The displayed phone number dials automatically.

From Talk mode

1) Press or . View the Caller ID message you want to dial (see “Viewing the Caller ID List” on page 38).

3) Press the DIAL soft key. The displayed phone number will be dialed.

Adding Zero to Caller ID message (New Zealand only)

While you review Caller ID information while the Insert Zero option is set to On, “0” is inserted. Refer to page 21 “Setting Insert Zero (New Zealand only)” to set the Insert Zero option to On or Off. New Zealand Telecom customers should leave Insert Zero to On. Other New Zealand companies may require Insert Zero set to Off.

Storing Caller ID messages in the Phonebook

Messages shown in the Caller ID list can be stored in the phonebook. Using the incoming call information (i.e., Caller ID list), the phone number and name of the party on the Caller ID list can be stored in memory.

1) When the phone is in the standby mode, view the Caller ID message to be stored. Then press the STORE soft key. “Store/Edit Name” appears.

2) To complete the setting, follow the steps 5-9 in “ Storing Phone Numbers, Names, Distinctive Rings, and Speed dial” on page 30.

12/12 12:30AM Jane Smith 0295979035

BACK DELETE STORE

[ 40 ]

Page 47

THE INTEGRATED ANSWERING DEVICE

The phone has a built-in answering system that answers and records incoming calls. You can also use your answering system to record a conversation, leave a voice memo message, or to announce a special outgoing message to callers when you’re away from your phone.

Features

• Digital Tapeless Recording • Approx. 14 Minutes of Recording Time

• Call Screening On/Off • Selectable Outgoing Messages

• Voice Prompts for Menu Setup Guidance • Time and Day Announcement

• Remote Message Retrieval • Toll Saver

• Conversation Recording • Voice Memo

• Remote Operation from the Handset • Message Alert

Digital Tapeless Recording allows you to quickly review, save, or delete the messages you choose. You will never have to worry about a tape wearing out, jamming, or resetting improperly.

The Integrated Answering System is easy and convenient to use, but please read through all of the instructions carefully.

ANSWERING DEVICE

THE INTEGRATED

[ 41 ]

Page 48

•When the answering system is full, “” appears on the base. You should delete some messages so that the system can record new messages.

•Position yourself as near to the base as possible and speak clearly when recording your outgoing message.

•If you make an outside call, or a call is received on this base during the operation, the operation is canceled.

TURNING THE ANSWERING SYSTEM ON/OFF

1) To turn the answering system On, press in the standby mode. After the announcement “Answering System is on”, the current greeting message will be played and you will hear a confirmation tone. The message counter displays the number of messages stored in memory. If the display flashes, then there are new messages waiting for you.

2) To turn the answering system Off, press . After the announcement “Answering System is off”, the message counter display will no longer be illuminated.

You can also turn the Answering System On or Off from the handset using the menu mode (see page 20).

SETTING UP YOUR ANSWERING SYSTEM

Setting your outgoing message (Greeting)

When you receive a call, the answering system automatically plays either the pre-recorded message or your own greeting.

Pre-recorded message

The following message is pre-recorded: “Hello, no one is available to take your call. Please leave a message after the tone.”

Recording a personal outgoing message (Greeting)

You can record a greeting up to 30 seconds long (must be more than 2 seconds long).

1) When the phone is in the standby mode, press and hold .

2) Start your recording after the announcement “Record greeting”. The message counter displays “”, then begins to count down.

3) When you have finished recording your greeting, press , or . You will hear a confirmation tone and your recorded greeting plays back for you.

[ 42 ]

Page 49

Choosing between the two outgoing messages

When the phone is in the standby mode, press . Press again when the outgoing message is played. Each time is pressed, the outgoing message is switched between the pre-recorded and the personal outgoing message.

Deleting an outgoing message

To delete the personal outgoing message, press while the message is playing. The system announces “Greeting has been deleted”.

Setting the base ringer volume

You have four ringer volume options. One allows you to turn the base ringer off. The other three are volume levels.

1) When the phone is in the standby mode, press / ringer at the current volume level (“” High, “” Medium, “” Low, or “” Off) (if you set the base ringer volume to off “Ringer Off” is announced), and it appears on the base.

2) Press /

▲ or ▼ repeatedly until the desired ringer volume appears. You

will hear a ringer at the selected volume level. The system returns to the standby mode.

You can also set the base ringer volume while the phone is ringing. Press

▲ or ▼ repeatedly to select the desired ringer volume.

▲ or ▼. You hear the

•If an outside call is received during this operation, the operation is canceled.

•If you press in the maximum

volume level (3) or the ringer off (0), you

will hear a beep.

▲

/ ▼ in

[ 43 ]

Page 50

Press and hold

CLOCK/MENU

on the base to scroll quickly through the volume levels.

/ ▲ or ▼

Adjusting the speaker volume level

When the base speaker is in use, press / ▲ or ▼ on the base to adjust the volume. Press /

▲ for louder or / ▼ for softer.

The numbers 1-10 appear on the base indicating the volume levels. 1 being the softest and 10 being the loudest.

Using the menu mode

The Menu mode allows you to set the following Answering System functions.

• To scroll through the menu options, repeatedly press The system returns to standby after the last menu

option. A confirmation tone sounds to indicate the standby mode.

• If you press , the operation is canceled.

• If the system remains idle for about 5 seconds after

the announcement, the system returns to standby. Once /SELECT or /SELECT is pressed, the idle time is extended to 10 seconds.

• If there is an incoming call, the operation is canceled.

• When you have completed the setting, press to

exit the menu mode, or to move to the next menu option.

• You can also set these menus from the handset. See “Answering System Setup” on page 19 for instructions.

For your convenience, voice prompts will guide you through the menu setup mode.

on the base in the standby mode.

[ 44 ]

Page 51

Setting the Time

Follow these steps to set the clock on the answering system to the correct time.

1) Press .

2) Press /SELECT or /SELECT until the correct day is announced and the corresponding number (from “” Sunday to “” Saturday) appears.

3) Press to select the day.

4) Press /SELECT or /SELECT until you hear the correct hour setting. The numbers “” through “” appear on the base as each hour is announced.

5) Press to select the hour.

6) Press /SELECT or /SELECT until you hear the correct minute setting. The numbers “” through “” appears on the base as each minute is announced.

7) Press to select the minute.

8) Press /SELECT or /SELECT until you hear the correct AM or PM setting. The message counter displays “” or “”.

9) Press to select the AM/PM setting. A confirmation tone sounds, the day and time you set are announced for your review.

Setting a PIN code

To play your messages from a remote location, you will need to enter a two-digit Personal Identification Number (PIN) code ( - ). To select a PIN code, perform the following steps:

1) Press twice. The current PIN code appears on the base and it is announced.

2) Press /SELECT or /SELECT until the desired number appears. Press and hold

/SELECT or /SELECT to quickly scroll through the numbers on the display.

3) Press to select the PIN code. A confirmation tone sounds, the system announces the new PIN code.

•Normally, if the system remains idle for 10 seconds after

/SELECT or /SELECT is

pressed, the system will return to standby. However, for setting the time, the idle time is extended to 2 minutes.

•Press and hold

/SELECT or /SELECT to

quickly scroll through the numbers on the display.

•Time stamp will not be heard until you have set the time.

[ 45 ]

Page 52

Setting the ring time

The ring time setting allows you to set the number of rings the caller hears before your answering system plays the outgoing message. You can set the ring time to answer after four, six, or nine rings. Setting “TS” (Toll Saver), the answering system picks up after six rings if you have new messages, and after nine rings if there are none. This way, if you make a long distance call to check your messages, you can hang up after the sixth ring to avoid billing charges.

1) Press three times. The current ring time setting (“” 4, “” 6, “” 9 or “” Toll saver) appears on the base and it is announced.

2) Press /SELECT or /SELECT until the desired ring time appears.

3) Press to select the new ring time. A confirmation tone sounds, the system announces the new ring time.

Selecting the message record time

You have three record time options. The options “1 minute” or “4 minutes” set the duration for recording the incoming messages. “Announce only” answers the call with the preset greeting or your personal greeting but prevents the caller from leaving a message.

1) Press four times. The current recording time (“” 1 minute, “” 4 minutes, “” Announce only No recording) appears on the base and it is announced.

2) Press /SELECT or /SELECT until the desired message record time appears.

3) Press to select the new recording time. A confirmation tone sounds, the system announces the new record time.

[ 46 ]

Page 53

Announce only feature

The Announce only feature plays a pre-recorded outgoing message “Hello, no one is available to take your call. Please call again.”, and it will not allow the caller to leave a message. To set “Announce only”, follow the steps on page 46. The outgoing message automatically switches to announce only message. To choose between the pre-recorded message or your own personal greeting, press , when the outgoing message is played. If you want to use your own greeting, or want to change your greeting to omit the prompt to leave a message, refer to “Recording a personal outgoing message (Greeting)” on page 42.

Setting the message alert

Message Alert feature lets you know when you have a new incoming message by sounding a short alert tone. If you set the Message Alert On, and when a new message is received, the alert tone will sound every 15 seconds.

1) Press five times. The current setting (On or Off) appears on the base and it is announced.

2) Press /SELECT or /SELECT to choose “” or “”.

3) Press . A confirmation tone sounds, the system announces the current setting you have selected. When the first new message is received, the alert tone will begin to sound.

Turning the message alert tone Off by pressing any key

To quickly turn Message Alert tone Off, press any key on the base unit and the tone will automatically deactivate.

Turning the message alert tone Off when you are away from your phone

When all new messages are played back using the remote playback feature (see pages 52-54) the Message Alert will automatically deactivate. The tone will not deactivate until all new messages are played back.

[ 47 ]

Page 54

Setting the call screen

You can screen calls when the Call Screen function is set to On.

1) Press six times. The current Call Screen setting (On or Off) appears on the base.

2) Press /SELECT or /SELECT to choose “” or “”.

3) Press . A confirmation tone sounds, and the system announces the new setting.

You can mute the Call Screen temporarily. When the system is answering, press . The Call Screen function resumes when the system is no longer in answering mode. Additionally, to adjust the volume, press /

If you set the answering system to Off, you cannot screen a call.

Screening a call

To screen an incomming call, do the steps as follows:

After the answering system answers, the base speaker will let you hear the calls as the machine records the message. To answer the call, press (talk) or pick up the handset from the base (when AutoTalk is set to On). If the handset is away from the base, press ,

or any number key, , or (when Anykey Answer is set to On). The

answering system will disconnect automatically.

▲ or ▼.

[ 48 ]

Page 55

USING YOUR ANSWERING SYSTEM

The message counter displays the number of messages stored in memory. If the display flashes, then there are new messages waiting for you. The answering system is designed to play your new messages first. After you play all your new messages, you can then play your old messages.

Playing your messages

1) When the phone is in the standby mode, press . The system announces the number of new and old messages while the message counter displays only the number of new messages. The time and day that each message was received is announced after the message is played.

2) When all new messages have been played, you hear a confirmation tone and the system announces “End of message”. The system returns to standby. After you have reviewed your new messages, you can play your old messages by again pressing . Once you have listened to a new message, it then becomes an old message. The old messages will be played in the order in which they were received.

Repeating a message

1) Press to review your messages. The number of stored messages is announced.

2) To repeat the current message, press /SELECT after a few seconds of beginning the message. To quickly scroll backwards through a message, press and hold /SELECT.

To repeat the previous message, press /SELECT within a few seconds (about 4 seconds during remote operation) after a message begins playing. If you have several messages, press /SELECT repeatedly until you return to the message you want to replay. If the current message is the first new message, the system plays back from the beginning of the current message (it does not go back into the old message group).

3) Press at any time to stop reviewing messages and return to standby. The message counter shows the number of messages stored in memory.

•If an outside call is received during this operation, the operation is canceled.

•To stop playing your messages, press again at any time.

•When the answering system is full, “” appears on the base. You should delete some messages so that the system can record new messages. (Refer to “Deleting a message” on page 50.)

[ 49 ]

Page 56

Skipping a message

1) Press to review your messages. The number of stored messages is announced.

2) Press /SELECT at anytime to skip to the next message. Each time /SELECT is pressed, the system scans forward one message. If you have several messages, press /SELECT repeatedly to find the message you want to play. To quickly scroll through a message, press and hold /SELECT. The system advances through the playback at double speed.

3) Press at anytime to stop reviewing your messages and return to standby. The message counter shows the number of messages stored in memory.

Deleting a message

To maintain maximum record time, delete the old messages.

1) Press to review your messages.

2) Press at anytime during the message to delete the message. You hear a confirmation tone and the message is deleted.

To delete all messages, press in the standby mode. Press again after the announcement “To delete all message, press delete again”.

When you try to delete all messages without first listening to your new messages, you hear several short beeps followed by an announcement “Please playback all messages”. This protects you from accidentally erasing messages you have not yet reviewed.

Important:

When you press , you are permanently deleting the message. Once deleted, the message cannot be replayed or retrieved.

[ 50 ]

Page 57

Voice memo

The voice memo function allows the user to record messages (more than 2 seconds and within 4 minutes).

1) Press and hold . You hear a beep.

2) Start your recording after the announcement “Record Memo Message” and a confirmation tone. The message counter displays “”.

3) When you have finished, press , , or to stop recording. The system returns to standby.

•The voice memo messages are recorded as an incoming messages.

•When the answering system is full, “” appears on the display and recording is terminated.

•If an outside call is received during the operation, the operation is canceled.

Recording a conversation

You can record a conversation from the handset or the base (more than 2 seconds and within 10 minutes).

•A recorded conversation is treated as an incoming message and will be added to the stored messages.

•You cannot record 3-way or intercom conversations.

•When the answering system becomes full, “” appears on the display and recording

is terminated.

From the handset

1) During a conversation, press the MENU soft key on the handset.

2) Press / appears on the handset, and “” flashes on the base. A tone, that can be heard by both parties, sounds during recording.

3) Press the STOP soft key to finish recording. You will hear a confirmation tone.

From the base

1) During a conversation using the base speaker phone, press and hold on the base until you hear a confirmation tone. The unit begins recording and “” flashes on the display. A tone, that can be heard by both parties, sounds during recording.

2) To stop recording, press or . You hear a confirmation tone.

▲ or ▼ to select “Recording”, then press the OK soft key.

[ 51 ]

Page 58

For your convenience a remote operation card is provided for you to use while away from home (refer to page 67).

REMOTE OPERATION

You can operate your answering system from a remote location using any touch-tone telephone or the handset.

Remote access away from home

You can check, play, or delete messages, even record a new greeting message when you are away from home. Additionally, you can turn On or Off your answering system from a remote location.

•Time stamp will not be heard until you have set the time. See “Setting the Time” on page 45.

•The system will only playback messages for four minutes and then it returns to the command waiting mode. To continue playing your messages, press # then 2 again within 15 seconds.

•

If you enter an incorrect PIN code three times, you will hear a beep and the system will return to standby.

•During the remote operation, “” appears on the base.

1) Call your telephone number and wait for the system to answer. If the answering system is off, it will answer after about 15 rings and sounds a series of beeps.

2) During the greeting message (or a series of beeps when the answering system is off), press # and enter your PIN code within 2 seconds (see “Setting a PIN Code” on page 19 or 45).

3) The answering system announces the current time and the number of messages stored in memory. You hear “To play incoming messages, press pound two. For help, press pound-zero”. You will hear a beep.

4) Enter a command within 15 seconds, each command there after must be entered within 2 seconds. You may select a command from the following chart:

[ 52 ]

Page 59

Command Function

then Repeat a Message* then Playing incoming Messages then Skipping a Message then Deleting a Message then Stop Operation

Command Function

then Answering System On then Memo Record/Stop ** then Greeting Message Record/Stop ** then Answer System Off then Help Guidance

* For Repeat a Message function, press # then within about four seconds to

repeat the previous message, or press # then after about four seconds to repeat the current message.

** For Memo Record and Greeting Message Record function, the first time you enter

the corresponding command, it starts the Recording function. If you want to stop the recording, press then or .

5) After the command has finished, you hear intermittent beeps indicating that the system is in the command waiting mode. You may enter another command at this time from the chart above.

6) When you are finished, hang up to exit the system. The answering system automatically returns to standby.

Remote access with the handset

You can check your new incoming messages, skip, repeat, or delete your incoming messages with the handset. For example, you can install the answering system in the living room, and check your incoming message from a bedroom with the handset. You can also use speakerphone on the handset for remote operation (see “Making and receiving calls” on page 23).

•If you press before the answering system answers, the phone will return to standby.

•When the answering system does not answer within 6 seconds, you hear a beep and the

phone will return to standby.

•The base’s keypad is disabled during remote operation.

•When you receive a call, the remote operation is canceled.

•You can change the handset volume during a remote operation.

•During the remote operation “” appears on the base.

[ 53 ]

Page 60

•If you have new messages and old messages, only the new messages will be played. After you have reviewed your new messages, you can play your old messages by again pressing the soft key. Once you have listened to a new message, it then becomes an old message.

Playing incoming messages

1) When the phone is in the standby mode, press the soft key on the handset. “Remote Playback” appears on the handset display. The answering system

announces the current time and the number of messages stored in the memory. Messages will be played in the order in which they were received. The time and day that each message was received is announced after the message is played.

2) When you are finished, hang up to exit the system. The answering system automatically returns to standby.

When the last message has been played, the system announces “End of messages”. And the system returns to standby.

•If you have new messages and old messages, only the new messages will be repeated.

•If you press the

soft key while the earliest message is playing, you can repeat only the current message.

[ 54 ]

Repeating a message

After a message begins playing, press the soft key within about four seconds to repeat the previous message, or press the soft key after about four seconds to repeat the current message.

Skipping a message

While the message is playing, press the soft key on the handset. Each time the soft key is pressed, the system scans forward one message.

Deleting a message

While the message is playing, Press the DELETE soft key on the handset. The message playing is deleted.

Page 61

EXPANDING YOUR PHONE

Your phone supports up to 4 handsets (including the handset(s) supplied with your phone). You can now place a fully featured cordless handset anywhere AC power is available to connect the handset charger.

Effective combinations, for example:

- 4-way conferencing (the base, 2 handsets, and one outside line), while on an intercom call using the other 2 handsets, or

- 4-way conferencing (3 handsets and an outside line)

IMPORTANT:

• If you purchase a DSS2405 extra handset, please register the handset to the DSS2455 or DSS2465 series base before use. The DSS2405 will not operate until it is registered.

• If you change a setting of the Global Setup and Answering Setup menu in one of the handsets, you change settings for all the handsets. For all other features they must be set separately through each handset.

CONNECTING THE CHARGER

1) Connect the AC adapter into the charging cradle and to a AC wall outlet.

2) Set the charger on a desk or tabletop, and place the handset in the charger with the keypad facing forward (see “Installing the AA batteries” on page iii to install the batteries.

•To use the DSS2405, register it to the

YOUR PHONE

DSS2455 or DSS2465 series base.

•Save this manual for detailed operation.

•All of the handsets ring when a call is received.

EXPANDING

[ 55 ]

Page 62

DSS2415

Main Base

DSS2455/2465

Main Base

Charger

If you purchase an extra handset, you need to register the handset to the main base before use. Only one handset can be registered at a time.

The handset ID for the supplied handset(s) was assigned at the factory, which has #1 (#1 and #2 for DSS2465) in the display. When you register additional handset to the base, the handset ID will be assigned.

An extra handset can be registered when the base is in the standby mode.

1) Before registering the extra handset, charge the phone’s battery for 10 minutes.

2) Place the extra handset in the main base unit to begin registration.

3) While the handset is registering, “Handset Registering” will appear in the LCD. When “Registration Complete” is displayed, the handset has been registered to the base. If “Registration Failed” appears, please try these steps again.

4) Place the handset back in the charging cradle and fully charge the phone’s battery for 17 to 20 hours.

[ 56 ]

Page 63

USING TWO WAY COMMUNICATION BETWEEN THE HANDSETS

SUN 12:00A Handset #1 DirectLink Mode

CANCEL DirectLink

ANYWHERE WITHOUT THE BASE (DIRECTLINK)

To use this feature, you must enter the two handsets into the DirectLink mode first.

To enter the DirectLink mode eeSee page 16

•During DirectLink mode, batteries use time when fully charged is as follows:

- Up to 7 hours continuous use.

- Up to 24 hours in the standby mode.

•Placing the handset in the cradle causes the handset to exit the DirectLink mode.

DirectLink call

1) When the phone is in the DirectLink standby mode, press the DirectLink soft key (example of DirectLink from handset #1).

2) Select the party by pressing the number keys (1-4). Your handset will page the other handset.

3) On the receiving handset, press or the ANSWER soft key, or if Anykey Answer is On, press any number key, , or .

4) When you finish your conversation, press or

END soft key on either handset. Return the handset to the cradle, or press the CANCEL soft key then the OK soft key to return to normal mode.

To DirectLink press 1-4

BACK

DirectLink from Handset #1

BACK ANSWER OK

[ 57 ]

Page 64

3-WAY CONFERENCING

The phone permits 3-way conversations between the handset, base, and an outside line.

When speaking on the handset

1) Press (talk) on the base to initiate the 3-way conversation.

2) To hang up, press (talk) on the base. The handset will still be connected to the call.

When speaking on the base

1) Press or on the handset to initiate the 3-way conversation.

2) To hang up, return the handset to the cradle, or press on the handset. The base will still be connected to the call.

For DSS2455, if you purchase a DSS2405 extra handset, the phone permits 4-way conversation, see “4-way Conferencing” below for details.

4-WAY CONFERENCING

Fourth person, at either the handset or the base, may be added to the conference call. For example, to add a fourth party to an ongoing conference call at the base or another

handset, press on the fourth party’s handset (or (talk) on the base). To remove either caller from your conversation, press on the party’s handset (or (talk) on the base). The other parties will still be connected to the call.

[ 58 ]

Page 65

INTERCOM/CALL TRANSFER FEATURE

Intercom and Call Transfer features are available for your phone.

•If the party is busy or out of range, you will hear a beep and the handset returns to the standby mode.

•If any of the following occurs, the operation will be canceled.

- Press or on the handset, and (talk) on the base.

- Receive an outside/intercom call or page (while selecting the other handset).

•When the party does not answer within 1 minute, Intercom or Call Transfer is canceled.

Intercom

From handset to handset or to the base

1) Press in the standby mode.

2) Select the base or the handset you want to talk with from the selection list within 30 seconds. To select the handset (or the base), press / press the OK soft key. If you select “All”, all handsets will be paged. An intercom tone sounds.

3) On the receiving handset (or the base), to answer the call, press ,

, or the ANSWER soft key (or or (talk) on the base). Or press any number key, , or (when Anykey Answer is On), or pick up the handset from the cradle (when AutoTalk is On).

4) To hang up the intercom call, press or the END soft key on either handset (or press on the base).

▲ or ▼, then

From the base to a handset

1) Press on the base in the standby mode.

2) Select the handset you want to talk with by pressing the number key (1-4). To page all the handsets press .

3) Follow the steps 3-4 under “From handset to handset or to the base”.

To intercom Handset #2 Handset #3

BACK BACK OK

[ 59 ]

Page 66

Call Transfer Feature

From handset to handset or to the base

1) During a call, press on the handset.

2) Select a handset or the base to transfer the call to within 10 seconds (refer to step 2 under “From handset to handset or to the base” in the intercom section). The call will automatically be placed on hold, and an intercom tone sounds. To cancel the transfer, press the CANCEL soft key, ,

or the BACK soft key on the initiating handset.

3) On the receiving handset, to answer the page, press , , or the ANSWER soft key (or or (talk) on the base). Or press any number key,

, or (when Anykey Answer is On), or pick up the handset from the cradle

(when AutoTalk is On). The intercom mode is activated, but the caller is still on hold.

4) To speak to the caller, press or on the receiving handset (or (talk) on the base).

From the base to a handset

1) During a call, press on the base. The call will automatically be placed on hold.

2) Select the handset you want to talk with by pressing the number key (1-4). To page all the handsets press . An intercom tone sounds. To cancel the transfer, press

or (talk) on the base.

3) On the receiving handset, to answer the page, press , , or the ANSWER soft key. Or press any number key, , or (when Anykey Answer is On), or pick up the handset from the cradle (when AutoTalk is On). The intercom mode is activated, but the caller is still on hold.

4) To speak to the caller, press or on the receiving handset

Hold,to transfer Handset #2 Handset #3

BACK BACK OK

[ 60 ]

Page 67

CHANGING THE DIGITAL SECURITY CODE

The digital security code is an identification code used to connect the handset and the base unit. Normally, setting the code is not necessary. In the rare situation that you suspect another cordless telephone is using the same security code, you can change the code. To change the digital security code:

1. Perform the “System Reset” menu options (“Deregister the Handset” and “Replacing the Base Setting”) for all the handsets you have (see page 14).

2. To register all the handsets do the following steps:

1) Place a handset, one at a time in the base.

2) Registration starts automatically. While registering “Handset Registering” appears in the display.

3) When the registration is complete, “Registration Complete” appears in the display.

4) Repeat steps 1 - 3 for another handsets.

If the registration fails, “Registration Failed” appears in the display. Try the steps above again.

INFORMATION

ADDITIONAL

[ 61 ]

Page 68

NOTE ON POWER SOURCES

Battery replacement and handling

When the operating time becomes short, even after a battery is recharged, please replace the battery. Please use only “AA” rechargeable Ni-MH batteries.

Warning

Caution

• Use only “AA” rechargeable Ni-MH batteries.

• Do not remove the batteries from the handset to charge them.

• Never throw the batteries into a fire, disassemble them, or heat them.

• Do not remove or damage the battery casing.

[ 62 ]

Page 69

TROUBLESHOOTING

If your phone is not performing to your expectations, please try these simple steps first.

Symptom Suggestion

The charge LED won’t illuminate •Make sure the AC adapter is plugged into the base (or the charger when the handset is placed in (for DSS2465 only)) and wall outlet. the cradle. •Make sure the handset is properly seated in the cradle.

The audio sounds weak •Move the handset and/or base to a different location away from metal and/or scratchy. objects or appliances and try again.

Can’t make or receive calls. •Check both ends of the base telephone line cord.

Can’t make an internal call. •Make sure that the receiving handset is not already in use.

•Make sure the charging contacts on the handset and the base (or the charger (for DSS2465 only)) are clean.

•Make sure that you are not too far from the base.

•Make sure the AC adapter is plugged into the base and wall outlet.

•Disconnect the AC adapter for a few minutes, then reconnect it.

•Remove the base ID (see “Deregister the Base Setting” on page 22) and register the handset to the base (see “Register the Handset” on page 56).

•Make sure that you are not too far from the base.

•

If an outside call is already established, you may not be able to make another outside call.

•Make sure that the handset or the base is in the standby mode.

•When a handset is recording a conversation, an intercom call from or to the

base is not available. Make sure a handset is not recording a conversation.

[ 63 ]

Page 70

Symptom Suggestion

The handset or the base doesn’t •Charge the batteries in the handset for 17-20 hours by placing the handset ring or can’t receive an on the base or charging cradle. intercom call. •The handset may be too far away from the base unit.

“Unavailable” appears in •Make sure that another handsets or the base is not in use, and try the the display. phone again.

Severe noise interference. •Keep the handset away from microwave ovens, computers, remote control

The Caller ID does not display. •The handset was picked up before the second ring.

You cannot register the •Please make sure your batteries are charged at least 10 minutes handset at the base. (see “Register the Handset” on page 56).

The handset doesn’t communicate •Remove the base ID (see “Deregister the Base Setting” on page 22) and with the base or other handsets. register the handset to the base (see “Register the Handset” on page 56).

•Place the base unit away from appliances or metal objects.

•Remove the base ID (see “Deregister the Base Setting” on page 22) and register the handset to the base (see “Register the Handset” on page 56).

•If more than 3 handsets are in use, you may not be able to page.

•Make sure that you are not too far from the base.

toys, wireless microphones, alarm systems, intercoms, room monitors, fluorescent lights, and electrical appliances.

•Move to another location or turn off the source of interference.

•The call was placed through a switchboard.

•Call your local telephone company to verify your Caller ID service is current.

•Remove the base ID (see “Deregister the Base Setting” on page 22) and register the handset to the base (see “Register the Handset” on page 56).

•Only 4 handsets can be registered to the base.

•Make sure that you have registered all handsets.

[ 64 ]

Page 71

Symptom Suggestion

The handset or the base can’t •Make sure that more than 3 handsets (or 2 handsets when the base is used join the conversation. for the conference) are not in use.

The answering system •Make sure the base unit is plugged in. does not work. •Make sure that the answering system is turned On.

Messages are incomplete. •The incoming messages may be too long. Remind callers to leave a

After a power failure, the •Record your greeting again. The default message should remain. outgoing message is deleted.

No sound on the base unit •Adjust the speaker volume on the base unit. speaker during call monitoring •Make sure the call screen feature is set to On. or message playback.

Cannot access remote call-in •Make sure you are using the correct PIN number. features from another •Make sure that the touch-tone phone you’re using can transmit the tone touch-tone phone. for at least two seconds. If it cannot, you may have to use another phone

Time stamp cannot be heard. •Make sure you have set the time (see “Setting Day and Time” on page 21

If you still have a problem. •Call our customer Service Division at

•When recording a conversation, the 2nd handset (or the base) cannot join the conversation.

•Make sure that the message record time is not set to Announce only (see page 47).

brief message.

•The memory may be full. Delete some or all of the saved messages.

to access your phone.

or “Setting the Time” on page 45).

1300 366 895 (Australia) or 0800 4864 336 (New Zealand).

[ 65 ]

Page 72

INDEX

0 - 9

3-way conferencing ....................58

4-way conferencing ....................58

16 ring options ..........................17

Announce only feature ................47

Answering system

Deleting a message ..................50

Playing your messages ..............49

Recording a conversation ..........51

Remote access..........................52

Repeating a message ................49

Skipping a message ..................50

Turning On/Off ........................42

Anykey answer............................18

AutoTalk....................................17

Banner ......................................18

Base speaker volume ..................44

Battery

Preparing and charging ..............iv

Replacement and handling ..........7

Beltclip ......................................7

Booster ....................................26

Caller ID

Caller ID service ......................37

Calling....................................40

Call Waiting ............................28

Deleting..................................39

Storing....................................40

Using......................................40

Viewing ..................................38

Call transfer feature ....................60

Chain dialing ............................36

Clock ........................................45

Conversation, recording ..............51

Deregister the handset ................22

Digital security code ..................61

Distinctive ringer........................17

E, F, G, H

Earpiece volume..........................26

Expanding your phone ................55

Hands-free conversation ..............23

Headset installation......................8

I, J, K, L

Intercom ..................................59

LCD contrast ..............................18

M, N, O

Making a call ............................23

Memory dialing ..........................36

Mute ........................................27

New Message LED ........................28

Outgoing Message ......................42

Overseas Calls ............................38

P, Q

Package contents..........................5

Phonebook ................................29

Editing....................................35

Erasing....................................35

Making calls ............................34

Storing....................................29

Viewing ..................................33

Receiving a call ..........................23

Redialing a call ..........................24

Remote access

away from home ......................52

from your handset ....................53

Ringer volume............................16

Setting up

base unit..................................ii

handset ..................................iii

Soft key function..........................9

Speed dialing ............................34

T, U, V, W, X, Y, Z

Transferring a call ......................60

Troubleshooting ..........................63

Voice memo ..............................51

Warranty....................................69

[ 66 ]

Page 73

REMOTE OPERATION CARD

CUT

REMOTE OPERATION CARD

Remote access away from home

1. Call your phone number from a touch-tone phone.

2. During the outgoing message, press # and enter your PIN code. The answering system announces the number of messages stored in memory and the help guidance.

3. To quit, hang up the phone.

Turn on the answering system remotely

1. Call your phone and let it ring 15 times until you hear a beep.

2. Press # and then enter your PIN code.

3. Press # then 5 to stop the announcement.

4. Press # then 6 to turn the answering system on.

[ 67 ]

Page 74

Task Key

Repeat a Message Playing incoming Messages Skipping a Message Deleting a Message Stop Operation Answering System On Memo Record/Stop Greeting Message Record/Stop Answer System Off Help Guidance

[ 68 ]

CUT

Page 75

WARRANTY

One Year Limited Warranty Important: Evidence of original purchase is required for warranty service. Warrantor: Uniden Australia Pty Limited A.B.N. 58 001 865 498

ELEMENT OF WARRANTY: Uniden warrants to the original retail owner for the duration of this warranty, its DSS2455/DSS2465

(herein after referred to as the Product), to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below. Warranty is only valid in the original country of purchase.

WARRANTY DURATION: This warranty to the original retail owner only, shall terminate and be of no further effect 12 months after the date of original retail sale. This warranty will be deemed invalid if the product is;

(A) Damaged or not maintained as reasonable and necessary, (B) Modified, altered or used as part of any conversion kits, subassemblies, or any configurations not sold by Uniden, (C) Improperly installed, (D) Repaired by someone other than an authorized Uniden Repair Agent for a defect or malfunction covered by this warranty, (E) Used in conjunction with any equipment or parts or as part of a system not manufactured by Uniden.

PARTS COVERED: This warranty covers for one (1) year, the Base Unit and Handset only. All accessories (AC Adapter etc)are covered for 90 days only.

STATEMENT OF REMEDY: In the event that the product does not conform to this warranty at any time while this warranty is in effect, the warrantor at its discretion, will repair the defect or replace the product and return it to you without charge for parts or service. THIS WARRANTY DOES NOT COVER OR PROVIDE FOR THE REIMBURSEMENT OR PAYMENT OF INCIDENTAL OR CONSEQUENTIAL DAMAGES. THIS GUARANTEE IS IN ADDITION TO AND DOES NOT IN ANY WAY AFFECT YOUR RIGHTS UNDER THE CONSUMER GUARANTEE ACT.

PROCEDURE FOR OBTAINING PERFORMANCE OR WARRANTY: In the event that the product does not conform to this warranty, the Product should be shipped or delivered, freight pre-paid, with evidence of original purchase (eg. a copy of the sales docket), to the warrantor at:

UNIDEN AUSTRALIA PTY LIMITED SERVICE DIVISION UNIDEN NEW ZEALAND LIMITED SERVICE DIVISION

345 Princes Highway, Rockdale NSW 2216 150 Harris Road, East Tamaki, Auckland Ph 1300 366 895 Fx (02) 9599 3278 Ph 0800 4 UNIDEN (4 864 336) Fx (09) 274 4253 We can also be reached on the We can also be reached on the

www.uniden.com.au www.uniden.co.nz

Customers in other States should ship or deliver the Product freight pre-paid to their nearest Uniden Authorized Repair Centre (Contact Uniden for the nearest Warranty Agent to you).

Uniden New Zealand Limited

[ 69 ]

Page 76

Additional Handset & Charger

Expand Your System!

DSS2405 HANDSET & CHARGER

Easily expand your cordless phone system by adding the DSS2405 Handset and Charger*. The DSS2405 gives you the mobility you need to stay connected with friends and family. Place this handset and charger in any convenient location, no need for an extra phone jack! Another innovation from Uniden, the company that bring outstanding wireless communication products to people's lives throughout the world.

* Operates with

Multi Handset Cordless Systems: DSS2415 DSS2455/2465

AVAILABLE AT PARTICIPATING RETAIL STORES

Optional 2.4 Ghz Cordless Handset and Charging Cradle

For use with Multi Handset Cordless Systems: DSS2415, DSS2455/2465

Digital Spread Spectrum

Call Transfer

Caller ID

No Phone Jack Needed

Uniden 2465, DSS 2455 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
