ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201
User’s Manual
Rev. 1A
For GX201 PCB ver. 1C or later
03/02/2007
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Copyright Notice
The content of this manual has been checked for accuracy. The manufacturer
assumes no responsibility for any inaccuracies that may be contained in this
manual. The manufacturer reserves the right to make improvements or
modification to this document and/or the product at any time without prior
notice. No part of this document may be reproduced, transmitted, photocopied or
translated into any language, in any form or by any means, electronic, mechanical,
magnetic, optical or chemical, without the prior written permission of the
manufacturer.
AMD is registered trademark of AMD Technology Incorporation
GEODE and GEODE GX is registered trademark of AMD Technology Incorporation
Realtek is registered trademark of Realtek Technologi es Inc.
Multiscan is a trademark of Sony Corp of America
IBM, EGA, VGA, PC/XT, PC/AT, OS/2 and PS/2 are registered trademarks of
International Business Machines Corporation
Intel is a registered trademark of Intel Corporation
Plug and Play is registered trademarks of Intel Corporation
Microsoft, Windows and MS-DOS are trademarks of Microsoft Co rporation
AMI is a trademark of American Megatrends Inc.
PCI is a registered trademark of PCI Special Interest Group
Other product names mentioned herein are used for identification purpose only and
may be trademarks and/or registered trademarks of their respective companies.
Installation Notice
The manufacturer recommends using a grounded plug to ensure proper
motherboard operation. Care should be used in pro per conjunction with a grounded
power receptacle to avoid possible electrical shock. All integrated circuits on this
motherboard are sensitive to static electricity. To avoid damaging components from
electrostatic discharge, please do not remove the board from the anti-st atic packi ng
before discharging any static electricity to your body, by wearing a wrist-grounding
strap. The manufacturer is not responsible for any damage to the motherboard due
to improper operation.
- 1 -
- 2 -
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Specification:
Model ENDAT-GX201
Form Factor
CPU
System Chipset
DIMM Socket
VGA Adapter
LCD
Supporting
LAN Adapter
IDE Connector
FDD Connector
AC97’ Audio
USB Port
I/O Port
RS-422/485
Digital IO
WDT
Expansion Slot
Power Supply
Mini-ITX 170 mm x 170 mm (6.69”x6.69”)
AMD GEODE GX 500 processor @ 1.1W power consumption
AMD GEODE GX + CS5536
One DDR DIMM socket supports 200MHz up to 512MB DDR
Integrated 2D graphics engine by AMD GEODE GX CPU
9, 12, 18, 24bit TFT LCD Panel with TTL interface
18, 24bit LVDS interface (Optional)
2 x Realtek 8139D 10/100 Ethernet adapter
One IDE channel support up to 2 EIDE devices (1 x 40-pin + 1 x
44-pin shared), UDMA 33/66/100 mode and BIOS auto-detect
1 x FDD connector
Phone Jack + Pin Header
4 x USB2.0 onboard
4 x COMs w/+5V, +12V selector /1 x Parallel port
Optional via COM2
8 bit bi-directional I/O ports (standard on-board support) + 8 bit input
and 8 bit output while the IT8888 present (optional)
programmable 1~255 seconds / minutes
1 x 120Pin PCI connector
1 x PC104 (Optional)
1 x One mini-PCI socket onboard (Optional)
ATX power support
TABLE OF CONTENTS
CHAPTER 1. INTRODUCTION.......................................................6
1-1. FEATURES ................................................................................................ 7
1-2. UNPACKING..............................................................................................9
1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS....................................9
1-4. MOTHERBOARD LAYOUT......................................................................10
CHAPTER 2. SETTING UP THE MOTHERBOARD ..................... 11
2-1. JUMPERS AND CONNECTORS ............................................................. 11
2-2. INSTALLING MEMORY............................................................................ 24
2-3. SHARED VGA MEMOR Y.........................................................................24
2-4. IRQs MAPPING........................................................................................ 24
2-5. WATCH DOG TIMER ...............................................................................25
2-6. DIGITAL I/O…………………………………………………………………….28
2-7. PC104………………………………….……………………………………….31
CHAPTER 3. AWARD BIOS SETUP............................................33
3-1. STANDARD COMS FEATURES..............................................................34
3-2. ADV ANCED BIOS FEATURES................................................................ 35
3-3. ADV ANCED CHIPSET FEATURES.........................................................36
3-4. INTEGRATED PERIPHERALS ................................................................38
3-5. POWER MANAGEMENT SETUP............................................................42
3-6. PnP/PCI CONFIGURATIONS ..................................................................42
3-7. PC HEALTH STATUS...............................................................................43
- 3 -
- 4 -
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
CHPATER 4. VGA, L CD AND DRIVERS......................................44
4-1. VGA FEATURE.........................................................................................44
4-2. LCD FLAT PANEL....................................................................................45
4-3. DRIVER UTILITY INSTALLATION GUIDE...............................................49
CHPATER 5. LAN ADAPTER.......................................................50
5-1. FEATURES...............................................................................................50
5-2. UTP CABLE/RJ-45 JACK DEFINITION...................................................51
5-3. CONNECTING 100BASE-TX FAST ETHERNET NETWORK.................52
5-4. REMOTE BOOT ROM FUNCTION.......................................................... 52
5-5. DIAGNOSTIC PROGRAM (RSET8139) …..............................................52
APPENDIX A: FLASH MEMORY UTILITY...................................54
APPENDIX B: CONNECTOR PIN ASSIGNMENT........................ 55
APPENDIX C: LIMITED WARRANTY.......................................... 64
Chapter 1. Introduction
To rise to the challenges of the system heating issues and more and more demands of
diminutive embedded system in diverse applications, we designed and made ENDAT-GX201
system board as an ultimate solution integrated with AMD GEODE GX technology CPU.
ENDAT-GX201 is not only the ideal solution for Hi-End POS systems, but also could be well
adapted to various applications such as kiosks, networking systems, controlling terminals
and other embedded systems with FANLESS environment.
ENDAT-GX201 is designed with AMD GEODE GX 500 and the CS5536. One DDR
DIMM socket supports 200MHz up to 512MB DD R. Th e DR AM contr oller sup ports
standard DDR200 Synchronous DRAM (DDR SDRAM).
ENDAT-GX201 integrates 2D graphics controller which enables ENDAT-GX201 to
support TFT LCD panel or CRT/LCD monitor (not support LCD + CRT operate
mode).
ENDAT-GX201 suppo rts TFT LCD p anels through the TTL or L VDS interface, which
includes 9-bit, 12-bit, 18-bit, and 24-bit of TTL or LVDS interfaces.
Resolutions up to 1280 x 1024 for TFT LCD or 16 00 x 1200 for CRT/LCD monitor.
ENDAT-GX201 has one standard PCI slot as well as a miniPCI socket support
standard PCI adapter with PCI 2.2 compliant; moreover, it has PC104 module
connector reserved as optional feature.
The ideal solution of ENDA T-GX201
- POS system
- KIOSK
- Interactive system
- Airport Terminal Controller
- Industrial controller
- Digital entertainment
- Embedded system equipment
- 5 -
6
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
1-1. Features
Basic Feature:
z A cost effective platform with x86 architecture.
z Embedded AMD GEODE GX 500 processor @ 1.1W power
consumption to offer a totally FANLESS solution.
z One DDR DIMM socket supports 200MHz up to 512MB DDR.
z An internal 2D graphics controller with 4/6/8/12/16 MB frame buffer
share with system memory
z Integrated 2D graphics controller resolutions up to 1600 x 1200 for
CRT/LCD monitor.
z Direct Flat panel interface supports 24-bit TFT/L VDS LCD panel, the
resolution up to 1280 x 1024 x 24.
z 1-channel LVDS interface on-board by optional feature.
z 8 bit bi-directional I/O ports (8 bit input and 8 bit output) if IT8888
(PC104 feature) presents.
z Standard PCI slot supports standard PCI adapter with PCI 2.2
compliant. A miniPCI socket and PC104 module connector by
optional features.
z AC97’ Audio with 1.2W amplifier built-in.
Software Support
z Drivers for major embedded operating systems: Windows XP,
Windows XP embedded and Windows CE 5.0.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Ordering information:
1. ENDAT-GX201: Standard version.
2. ENDAT-GX201-P: Support 1 PC104 module connector.
3. ENDAT-GX201-M: Support 1 miniPCI socket.
4. ENDAT-GX201-L: Support 1 channel LVDS with 18, or 24-bit data
formats.
Note:
1. The standard version of ENDAT-GX201 will not equip any optional feature
listed above.
2. Both PC104 (ENDAT-GX201-P) and miniPCI (ENDAT-GX201-M) features
require a MOQ amount for production in UNICORN. Please co ntact the sales
department for more detail.
7
8
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
1-2. Unpacking
The motherboard comes securely packaged in a sturdy cardboard shipping carton. In
addition to the User's Manual, the motherboard package includes the following items:
•
ENDAT-GX201 System Board
•
HDD/FDD/Serial port Cables
•
LCD cable
•
IDE Driver includes: Drivers for Windows NT 3.x/4.x, Windows 95, 98, ME, 2000,
XP, Novell Netware and AMI / AWARD FLASH ROM utilities.
•
Driver utilities for on-board VGA drivers, LAN adapter
If any of these items are missing or damage, please contact the dealer from whom you
purchase the motherboard. Save the shipping material and carton in the event that you want
to ship or store the board in the future.
Note:
Leave the motherboard in its original package until you are ready to install it!
(Optional)
1-3. Electrostatic Discharge Precautions
Make sure you properly ground yourself before handling the motherboard, or other system
components. Electrostatic discharge can easily damage the components. Note: You must
take special precaution when handling the motherboard in dry or air-conditioned
environments.
1-4. MOTHERBOARD LAYOUT
9
10
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Chapter 2. Setting up the Motherboard
2-1. Jumpers and Connectors
Connectors Overview:
Function Jumpers/Connectors
ATX Power Connector
DDR SDRAM Socket
LAN/USB Connector
CRT Output Connector
CRT Box Header
COM1 Connector
COM2 Connector
COM3 Connector
COM3 Box Header
COM4 Box Header
LINE IN/SPEAKER OUT connector
LPT1 Box Header
FDD Connector
IDE Connector
PC104 Connector
MINI-PCI Socket
PCI Slot
LCD Panel Connector
LVDS Panel Connector
USB Port Header
Cooling Fan Connector
PS/2 MS/KB Pin Header
IR Pin Header
SM Bus Header
DIGITAL I/O Pin Header (w/ buffer)
DIGITAL I/O Pin Header (w/o buffer)
MIC IN Header
LINE IN Header
LINE OUT Header
CD In Header
SPEAKER OUT Header
Reserved for factory
ATX1
DIMM1
LAN1, LAN2
COMVGA (lower side)
VGABH1
CN6 (upper side)
CN6 (lower side)
COMVGA (upper side)
CN8 (shared)
CN4
LIN-SPK1
LPT1
FDD1
IDE1, IDE1B (shared IDE1)
CN1 + CN3
SLOT1
PCI1
TTL1
LVDS1
JUSB1
FAN1, FAN2
CN5
IRDA1
SMB1
JP7
UBIO1
CN10
CN9
CN11
CN12
CN13
ISP1
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Jumpers Overview:
Function Jumpers/Connectors
Clear CMOS
LCD Voltage Selector
LVDS Trigger Edge Selector
Header for Case Panel
HDD active LED
External Speaker
Buzzer On/Off
External/Internal power good
Hardware Reset Switch
Power LED
WDT Function Enable/Disable
ATX Power Supply On/Off Switch
COM Port Voltage Selector
RS232 / 422/ 485 Selector for COM2
DIGITAL I/O Voltage Selector (JP7 only)
LCD / CRT selector
Restore on AC power loss
Please double-check the insertion and orientation of the LCD cable before applying power.
Improper installation will result in permanent damage LC D pa n e l.
JBAT1
JP6
JP7
JP5
JP5: Pin 1(-), Pin 2(+)
JP5: Pin 3, Pin 6
JP5: Pin 4, Pin 5
JP5: Pin 7, Pin 8 (external)
JP5: Pin 8, Pin 9 (internal)
JP5: Pin 10, Pin 11
JP5: Pin 12(+), Pin 13(-)
JP5: Pin 14, Pin 15
JP5: Pin 16, Pin 17
JP2 (COM3/4), JP4 (COM1/2)
JP1 & JP3
J1
JP8
JP9
11
12
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Part 1: Onboard Jumpers
JBAT1: CMOS Data Clear (1x3 with 2.0mm)
Pin 1-2 *
Pin 2-3
JP8: LCD / CRT selector (1x3 with 2.0mm)
Pin 1-2
Pin 2-3*
JP6: LCD Voltage Selector (2x3 with 2.0mm)
Pin 1-2 *
Pin 3-4
Pin 5-6
Caution: Improper setting will damage LCD panel.
JP7: LVDS Trigger Edge Selector (1x3 with 2.0mm)
Pin 1-2 *
Pin 2-3
JP5: Pin Header for Case Panel (1x17 with 2.54mm)
Pin No. Function
1(-), 2(+)
3,6
4,5 *
7,8
8,9 *
10,11
12(+), 13(-)
14,15
16,17
JP1, JP3: RS232 / 422 / 485 Selectors for COM2 (2.0mm)
TYPE JP1 (3x4 with 2mm) JP3 (2x7 with 2mm)
RS-232 *
RS-422/485
Close for clear CMOS
+3.3V
Rising edge
Falling edge
Normal
LCD
CRT
+5V
+12V
HDD active LED
External Speaker
Buzzer On/Off
External power good
Internal power good
Hardware Reset Switch
Power LED
Close: Enable WDT function
ATX Power On/Off
1-2, 4-5, 7-8, 10-11 1-2
2-3, 5-6, 8-9, 11-12 3-4, 5-6
JP2, JP4: COM Port Voltage Selector (2x6 with 2.0mm)
Voltage +12V(DC) R.I. * +5V(DC)
COM1 (JP4) 1-2 3-4 5-6
COM2 (JP4) 7-8 9-10 11-12
COM3 (JP2) 1-2 3-4 5-6
COM4 (JP2) 7-8 9-10 11-12
J1: DIGITAL Output Voltage Selector (CN7 only, 1x3 with 2.0mm)
Pin 1-2 *
Pin 2-3
JP9: Restore on AC power loss (1x2 with 2.54mm)
Close
Open*
When JP9 was been closed, the system power will turn on automatically when AC
power apply.
+3.3V
+5V
Enable
Disable
13
14
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Part 2: Onboard connectors
VGABH1: CRT Box Header Connector (2x8 with 2.54mm)
Pin No. Description Pin No. Description
1
2
3
4
5
6
7
8
RED
GREEN
BLUE
N.C.
GND
GND
GND
9
10
11
12
13
14
15
GND
CN8/4: Box Header Type Connector for COM3/4 port (2x5 with 2.54mm)
Pin No. Function Pin No. Function
1
2
3
4
5
DCD
RXD
TXD
DTR
GND
6
7
8
9
10
LPT1: Printer Port Box Header (2x13 with 2.54mm)
Pin No. Description Pin No. Description
1
2
3
4
5
6
7
8
9
STB#
PD0
PD1
PD2
PD3
PD4
PD5
PD6
PD7
10
11
12
13
14
15
16
17
18-25
N.C / +5V
GND
N.C.
DDC DAT
H-Sync
V-Sync
DDC CLK
DSR
RTS
CTS
RI
N.C.
ACK#
BUSY
PE
SLCT
AFD#
ERR#
INIT#
SLIN#
GND
15
FDD1: FDD Box Header (2x17 with 2.54mm)
Pin No. Description Pin No. Description
1,3,5,7
9,11,13
15,17,19
21,23,25
27,29,31
33
2
4,6
8
10
12
GND
GND
GND
GND
GND
GND
RWC#
N.C
INDEX#
MOA#
DSB#
14
16
18
20
22
24
26
28
30
32
34
RDATA#
DSKCHG#
16
DSA#
MOB#
DIR
STEP#
WD#
WE#
TRAK0
WP#
HEAD#
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
IDE1 Box Header (2x20 with 2.54mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
IDE Reset#
IDE data7
IDE data6
IDE data5
IDE data4
IDE data3
IDE data2
IDE data1
IDE data0
GND
IDE REQ
IDE IOW#
IDE IOR#
IDE Ready
IDE ACK#
IDE IRQ
IDE A1
IDE A0
IDECS1#
HDLED#
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
IDE data8
IDE data9
IDE data10
IDE data11
IDE data12
IDE data13
IDE data14
IDE data15
P66DET
IDESC3#
GND
N.C.
GND
GND
GND
GND
GND
N.C.
IDE A2
GND
IDE1B: Slim IDE1 Connector (2x22 with 2.0mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
IDE Reset#
IDE data7
IDE data6
IDE data5
IDE data4
IDE data3
IDE data2
IDE data1
IDE data0
GND
IDE REQ
IDE IOW#
IDE IOR#
IDE Ready
IDE ACK#
IDE IRQ
IDE A1
IDE A0
IDECS1#
HDLED#
VCC (+5V)
GND
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
GND
IDE data8
IDE data9
IDE data10
IDE data11
IDE data12
IDE data13
IDE data14
IDE data15
N.C.
GND
GND
GND
GND
GND
N.C.
P66DET
IDE A2
IDESC3#
GND
VCC (+5V)
N.C.
17
18
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
TTL1: TTL LCD Panel Box Header (2x22 with 2.0mm)
Pin No. Signal Pin No. Signal
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
LVDS1: LVDS LCD Pin Header (2x8 with 2.54mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
Please make sure the Pin 1 location before inserting the LCD connector.
VBL (+12V)
GND
LCD-PWR
ENBKLT
B0
B2
B4
B6
G0
G2
G4
G6
R0
R2
R4
R6
GND
CLK
DE
GND
LCD-PWR
LCD-PWR
Y0-
Y0+
Y1-
GND
Y1+
CK-
CK+
VBL (+12V)
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42 KEY
44
2
4
6
8
10
12
14
16
VBL (+12V)
GND
LCD-PWR
GND
B1
B3
B5
B7
G1
G3
G5
G7
R1
R3
R5
R7
GND
V-SYNC
H-SYNC
LCD-PWR
LCD-PWR
Y2-
Y2+
LCD-PWR
Y3-
Y3
LCD-PWR
ENBKLT
GND
19
JUSB1: Pin Header for USB port (2x5 with 2.54mm)
Pin No. Function Pin No. Function
1
3
5
7
9
FAN1, FAN2: Cooling Fan Connector
Pin No. Function
1
2
3
CN5: PS/2 Keyboard / Mouse Pin Header (2x5 with 2.0mm)
Pin No. Signal (KB) Pin No. Signal (MS)
1
3
5
7
9
IRDA1: IR Pin Header (1x5 with 2.54mm)
Pin No. Function Pin No. Function
1
2
3
SMB1: SM Bus Pin Header (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
2
USB_VCC
USBD2-
USBD2+
USB_GND
USB_GND
GND
+12V
Sensor Pin
KB Data
KEY
GND
+5V(DC)
KB_CLK
+5V
N.C
IRRX
SMBCK
SMBDT
2
4
6
8
10
2
4
6
8
10
4
5
3
4
USB_VCC
USBD3-
USBD3+
USB_GND
USB_GND
MS Data
KEY
GND
+5V(DC)
MS_CLK
GND
IRTX
+3.3V
GND
20
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
CN7: DIGITAL I/O Pin Header (2x13 with 2.0mm)
Pin No. Function Pin No. Function
1
3
5
7
9
11
13
15
17
19
21
23
25
Note: Only available when PC104 function present
UBIO1: DIGITAL I/O (w/o buffer) Pin Header (2x6 with 2.0mm)
Pin No. Function Pin No. Function
1
3
5
7
9
11
CN10: MIC IN (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
CN9: LINE IN (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
DIO-O0
DIO-O1
DIO-O2
DIO-O3
GND
+12V
GND
+3.3V
+5V
DIO-I0
DIO-I1
DIO-I2
DIO-I3
+3.3V
GPIO0
GPIO1
GPIO2
GPIO3
GND
MIC POWER
GND
LINE IN-L
GND
2
4
6
8
10
12
14
16
18
20
22
24
26
2
4
6
8
10
12
2
4
2
4
DIO-O4
DIO-O5
DIO-O6
DIO-O7
+5V
+3.3V
KEY
+12V
GND
DIO-I4
DIO-I5
DIO-I6
DIO-I7
GND
GPIO4
GPIO5
GPIO6
GPIO7
+3.3V
GND
MIC IN
GND
LINE IN-R
21
CN11: LINE OUT (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
CN12: CD IN Pin Header (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
CN13: SPEAKER OUT (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
D-SUB Type Connector for COM2 port (RS-232)
Pin No. Description Pin No. Description
1
2
3
4
5
LINE OUT-R
GND
CD IN-R
GND
SPEAKER OUT-R
GND
DCD
RXD
TXD
DTR
GND
2
4
2
4
6
7
8
9
GND
LINE OUT-L
GND
CD IN-L
2
4
SPEAKER OUT-L
DSR
RTS
CTS
22
RI
GND
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
D-SUB Type Connector for COM2 port (RS-422Æ 4 Wire)
Pin No. Function Pin No. Function
1
2
3
4
5
D-SUB Type Connector for COM2 port (RS-485Æ 2 Wire)
Pin No. Function Pin No. Function
1
2
3
4
5
–TXD
+RXD
+TXD
NA
NA
Data –
NA
Data +
NA
NA
6
7
8
9
6
7
8
9
NA
NA
NA
–RXD
NA
NA
NA
NA
A TXPWR: ATX Power connector
ATX
3.3V 11 1 3.3V
–12V 12 2 3.3V
GND 13 3 GND
PS ON 14 4 +5V
GND 15 5 GND
GND 16 6 +5V
GND 17 7 GND
–5V 18 8 POWER OK
+5V 19 9 5V SB
+5V 20 10 +12V
2-2. Installing Memory
The ENDAT-GX201 CPU board offers one 184pin DDR DIMM socket supporting up to
512MB of memory. The DDR memory can be DDR200, DDR266, DDR333 or DDR400.
2-3. Shared VGA Memory
The ENDAT-GX201 is using built-in graphic controller with Unified Memory Architecture
(UMA) determines the number of colors and the video graphic resolution.
up to 16MB
of system memory. The amount of video memory on motherboard
2-4. IRQs Mapping
The IRQ number is automatically assigned to PCI expansion cards after those used by
onboard device. To install a PCI riser card, you need to set the correct "ADSEL" and "INT"
(interrupt) assignment.
IRQ Status Assignment
0 Occupied Timer
1 Occupied Keyboard
2 Occupied Second 8259
3 Occupied COM2/COM4 shared
4 Occupied COM1/COM3 shared
5 Occupied LPT1
6 Occupied Floppy Disk
7
8 Occupied RTC
9
10
11
12
13 Occupied Coprocessor
14
15 Occupied Reserved
Free Any
Shareable ACPI controller
Free Any
Free Any
Free When PS/2 mouse absent
Free When IDE device absent
23
24
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
2-5. Watch Dog Timer
z H/W jumper:
JP5: Pin 14, Pin 15, WDT Function Enable (close) Disable (open).
z S/W Port Address: Base address (0x800).
Offset: 0x47 (GPIO register)
Bit Function 00 01 10 11
1..0
3..2
7..4
Function selector Reserved WDT
Reserved
Reserved
Offset: 0x65 (Time unit regi ster)
Bit. Function 0 1
6..0
7
Minute/Second Minute Second
Reserved
Offset: 0x66 (Time out value regi ster)
Bit. 0x00~0xff
7..0
1~255 minutes/seconds (0x00 is disable WDT)
Offset: 0x67 (Configuration register)
Bit Function 0 1
0
1
2
7..3
Keyboard enable WDT ignore KB interrupt WDT reset by KB interrupt
Mouse enable WDT ignore MS interrupt WDT reset by MS interrupt
Reserved
Reserved
Offset: 0x68 (Control register)
Bit Function 0 1
0
1
2
7..3
WDT status (read only) WDT continue WDT time out occurred
Reserved
Force time out Keep status Force time out
Reserved
Sample code (using TurboC/C++ 3.0):
#include <dos.h>
#include <stdio.h>
#include <conio.h>
#include <iostream.h>
#include <process.h>
#define RUNTIME_REG_BASE 0x800
#define WDT_TIME_OUT_OFFSET 0x65 //Bit7=0(default) mean minute, bit7=1 mean second.
#define WDT_VAL_OFFSET 0x66 //Time out value (1~255), 0 (default) is mean disable.
#define WDT_CFG_OFFSET 0x67 //Bit1=1 (default) will clear WDT flag when KB interrupt,bit2=1 is MOUSE
interrupt.
#define WDT_CTRL_OFFSET 0x68 //Bit0=1 mean time out event occured (read only and it'll be clear
automatically),bit2=1 will force WDT event.
#define WDT_GP60_TYPE_OFFSET 0x47 //Bit3-2=11 mean WDT function, bit3-2=00 mean GPIO function.
Bit0=1 mean input, bit0=0 mean output or WDT.
void title(void);
void init(unsigned char,unsigned char);
unsigned char dec2hex(unsigned int);
void main()
{
unsigned char val,val1;
unsigned int val2;
clrscr();
title();
cout<<"\n Now testing the WDT function on GX platform!\n";
cout<<"Please select the time unit is minute (M) or second (S):";
cin>>val;
if ((val=='m')||(val=='M'))
{
val=0;
}
else
{
val=1;
}
cout<<"Please key in how many minutes/seconds for reset system(1~255):";
cin>>val2;
val1=dec2hex(val2);
init(val,val1);
cout<<"\nReady to start WDT count down ('s' to start or 'q' to quit)?";
cin>>val;
if((val=='q')||(val=='Q'))
{
exit(0);
}
else if ((val=='s')||(val=='S'))
{
outportb(RUNTIME_REG_BASE+WDT_GP60_TYPE_OFFSET,0x0c); //Enable WDT
and starting count down.
}
exit(0);
}
25
26
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
void init(unsigned char flag,unsigned char time)
{
unsigned char tmp0;
outportb(RUNTIME_REG_BASE+WDT_GP60_TYPE_OFFSET,0x0d); //Disable WDT function
(set it as input).
tmp0=inportb(RUNTIME_REG_BASE+WDT_TIME_OUT_OFFSET);
if (flag)
{
tmp0=tmp0|0x80; //Set time unit is second.
}
else
{
tmp0=tmp0&0x7f; //Set time unit is minute.
}
outportb(RUNTIME_REG_BASE+WDT_TIME_OUT_OFFSET,tmp0);
outportb(RUNTIME_REG_BASE+WDT_VAL_OFFSET,time); //Set time out vlaue.
tmp0=inportb(RUNTIME_REG_BASE+WDT_CFG_OFFSET);
tmp0=tmp0|0x06;
outportb(RUNTIME_REG_BASE+WDT_CFG_OFFSET,tmp0); //Set WDT interrupt by KB and
MOUSE.
}
void title(void)
{
cout<<"\nUNICORN COMPUTER Corp,. 2006/09/14(ver:0.1 beta)";
cout<<"\nDesigned by Robert Liou for testing WDT on GX2v1!\n\n";
}
unsigned char dec2hex(unsigned int number)
{
unsigned char tmp_num0,tmp_num1;
if(number>=255)
{
tmp_num0=number&0xff;
}
else
{
tmp_num1=(number/16)&0x0f;
tmp_num1=tmp_num1<<4;
tmp_num0=number%16;
tmp_num0=tmp_num0|tmp_num1;
}
return(tmp_num0);
}
2-6. Digital I/O
z 16 Bits Digital I/O (CN7)
I/O type: Unidirectional for 8 bits input and 8 bits output with buffer
Pin definition:
CN7: DIGITAL I/O Pin Header (2x13 with 2.0mm)
Pin No. H/W S/W Pin No. H/W S/W
1
3
5
7
9
11
13
15
17
19
21
23
25
Operating condition: Due to this feature is addressing from ISA bus!
So, the ISA Bridge (IT8888G) must present on system for this feature support.
OUTPUT-0 BIT0
OUTPUT-1 BIT1
OUTPUT-2 BIT2
OUTPUT-3 BIT3
GND N/A
+12V N/A
GND N/A
+3.3V N/A
+5V N/A
INPUT-0 BIT0
INPUT-1 BIT1
INPUT-2 BIT2
INPUT-3 BIT3
2
4
6
8
10
12
14
16
18
20
22
24
26
OUTPUT-4 BIT4
OUTPUT-5 BIT5
OUTPUT-6 BIT6
OUTPUT-7 BIT7
+5V N/A
+3.3V N/A
KEY N/A
+12V N/A
GND N/A
INPUT-4 BIT4
INPUT-5 BIT5
INPUT-6 BIT6
INPUT-7 BIT7
H/W jumper:
J1: DIGITAL Output Voltage Selector (CN7 only, 1x3 with 2.0mm)
Pin 1-2 *
Pin 3-4
S/W Port Address: Output (0x300), Input (0x301).
Sample code (using TurboC/C++ 3.0):
#define WRITE_OUT 0x300 //8bit I/O output
#define READ_IN 0x301 //8bit I/O input
unsigned char val=0;
val=inportb(READ_IN); //Read 8 bits data from DIO port
outportb(WRITE_OUT,val); //Write 8 bits data to DIO port
+3.3V
+5V
27
28
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
z 8 Bits Digital I/O (UBIO1)
I/O type: bidirectional for 8 bits I/O without buffer
Pin definition:
UBIO1: DIGITAL I/O (w/o buffer) Pin Header (2x6 with 2.0mm)
Pin No. Function Pin No. Function
1
3
5
7
9
11
Operating condition: None, all of the standard types of M/B support this feature.
This feature is sourcing from GPIO pin of super I/O chip (SCH3114 by SMSC).
Please refer to the datasheet of SMSC for detail describe of register or the sample
code of below.
+3.3V
GPIO0
GPIO1
GPIO2
GPIO3
GND
2
4
6
8
10
12
S/W Port address: Base address (0x800).
Register offset:
Pin No. Control Data Pin No. Control Data
GPIO0
GPIO1
GPIO2
GPIO3
Control register configuration (GPIO0 to GPIO3):
Pin No. Function 0 1
BIT0
BIT1
BIT2
BIT [7..3]
0x3A 0x4d/bit7
0x39 0x4d/bit 6
0x48 0x50/bit 2
0x33 0x4d/bit 1
Input/Output Output Input
Polarity No invert Invert
GPIO/other function GPIO Other function
GPIO4
GPIO5
GPIO6
GPIO7
Reserved
29
GND
GPIO4
GPIO5
GPIO6
GPIO7
+3.3V
0x6e 0x85/bit 4
0x6f 0x85/ bit 5
0x72 0x85/ bit 6
0x73 0x85/ bit 7
Control register configuration (GPIO4 to GPIO7):
Pin No. Function 0 1
BIT0
BIT1
BIT2
BIT [7..3]
Sample code (using TurboC/C++ 3.0):
#define BASE_ADDR 0x800 //Base address
#define GPIO0_IO_CTRL 0x3a //Control offset of GPIO0
#define GPIO0_DATA 0x4d //Data port of GPIO0
#define GPIO0_MASK 0x80 //Data mask of GPIO0
unsigned char tmp;
tmp=inportb(BASE_ADDR+GPIO0_IO_CTRL);
tmp=tmp|0x01; //Set GPIO0 as input
; tmp=tmp&0xfe; //Set GPIO0 as output
outportb(BASE_ADDR+GPIO0_IO_CTRL,tmp);
tmp=inportb(BASE_ADDR+GPIO0_DATA); //Get data from GPIO0
tmp=tmp&GPIO0_MASK; //Clear un-used bit
; outportb(BASE_ADDR+GPIO0_DATA,0x80); //Set GPIO0 as logical “1”
; outportb(BASE_ADDR+GPIO0_DATA,0x00); //Set GPIO0 as logical “0”
Input/Output Output Input
Polarity No invert Invert
GPIO/other function Other function GPIO
Reserved
30
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
2-8. PC104
z There have 4 items in “Integrated Peripherals” menu of
BIOS need to defined for PC104
1. IT8888 ISA Decode IO
There have 5 sets (4..0) of decode addresses available in this item:
a). Decode I/O Space [4..0]:
This item needs to set as “Enabled” to change the setting of below (from b to d).
b). Decode I/O Speed [4..0]: Subtractive Speed / Slow Speed / Medium Speed / Fast Speed.
Set decode speed as needs, generally is “Fast Speed”.
c). Decode I/O Addr. [4..0] [15:4]: 0001 to 0fff (HEX number).
Set decodes address according to the interface need.
d). Decode I/O Size [4..0]: 1 / 2 / 4 / 8 / 16 / 32 / 64 /128 Bytes
Set how many size will be used on the interface.
2. IT8888 ISA Decode Memory
There have 4 sets (3..0) of decode addresses available in this item:
a). Decode Memory Sp ace [3..0]:
This item needs to set as “Enabled” to change the setting of below (b to d).
b). Decode Memory Speed [3..0]: Subtractive Speed/Slow S peed/Medium Speed/Fast S peed.
Set decodes speed as needs.
c). Decode Momory Addr. [3..0] [23:12]:
Set decodes address according to the interface need.
d). Decode Momory Size [3..0]:
Set how many size will be used on the interface.
3. IT8888 DDMA
There have 6 DMA channels available on this item (0/1/2/3/5/6/7), please set one or more DMA channel
as interface needs.
Enabled / Disabled
Enabled / Disabled
0000 to 0fff (HEX number).
16K/32K/64K/128K/256K/512K/1M/2M Bytes
4. IRQ Resources
Please set the item “Resources Controlled By” as “Manual” from “Auto (ESCD)”, then reserved one or
more interrupt number for interface usage. Available number is: 3/4/5/7/10/11/14/15.
z Example operation (RS-232 card):
Step 1:
In this case, the port address of jumpers was been set as “3F8/IRQ4 (COM1)” and “2F8/IRQ3 (COM2)”.
Setting the IO card jumper to assign the IO port address and IRQ number.
Step 2:
“Integrated Peripherals” to set the decode address for RS-232 card. In the ”IT8888 ISA Decode IO”,
change these 5 items as follows:
a). Decode I/O Space 0 / 1: Enable.
b). Decode I/O Speed 0 / 1: Fast Speed.
c). Decode I/O Addr. 0 / 1: 03f (COM1) / 02f (COM2).
d). Decode I/O Size 0 / 1: 16 Bytes.
e). Change the item “Resources Controlled By” as “Manual” from “Auto (ESCD)” and change the number
3 and 4 of interrupt as “Legacy ISA” from “PCI/ISA PnP”.
Press “Del” key to get in the BIOS utility and disable all onboard COM ports, then select the
Step 3: Plug the RS-232 card in M/B and turn on the power, the COM1 and COM2 of RS-232 card
should be found in “System configuration table”. Then, continue boot up to WINDOWS system and
connect MODEM or other COM port devices to verify function.
31
32
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Chapter 3. AWARD BIOS SETUP
Phoenix – Award BIOS CMOS Setup Utility
> Standard CMOS Featu res
> Advanced BIOS Features
> Advanced Chipset Features
> Integrated Peripherals
> Power Management Setup
> PnP/PCI Configurations
Use the BIOS CMOS setup program to modify the system parameters to reflect the
environment installed in your system and to customize the system as desired.
Press the <DEL> key to enter into the BIOS CMOS setup program when you turn
on the power. Settings can be accessed via arrow keys. Press <Enter> to choose
an option to configure the system properly.
In the main menu, press F10 or “SAVE & EXIT SETUP” to save your changes and
reboot the system. Choose “EXIT WITHOUT SAVING” to ignore the changes and
exit the setup procedure. Pressing <ESC> at anywhere during the setup will return
to the main menu.
All of the above CMOS BIOS items require board knowledge on PC/AT system
architecture. Incorrect setup could cause system malfunctions.
> PC Health Status
Load Optimized Defaults
Set Password
Save & Exit Setup
Exit Without Saving
3-1. Standar d CMOS Features
The Stan dard Setup is used for the ba sic hard ware system configuration. The main
function is for Data/Time and Hard Disk Drive settings.
Item Optimized defaults
Date (mm:dd:yy)
Time (hh:mm:ss)
IDE Primary Master Press Enter
IDE Primary Slave Press Enter
Driver A
Video
Halt On
1.44M, 3.5 in.
All , But Keyboard
˙Video
Select the type of primary video subsystem.
<Choice: EGA / VGA, CGA 40, CGA 80, MONO>
˙Halt On
Set the system’s response to specific boot errors.
<Choice: All Errors, No Errors, All, But Keyboard,
All, But Diskette, All, But Disk/Key >
IDE Primary Master/Slaver
Item Optimized defaults
IDE HDD Auto-Detection Press Enter
IDE Channel Auto
Access Mode Auto
The specifications of your drive must match with the drive table. The hard disk will
not work properly if you enter incorrect information in this category. Select “Auto”
whenever possible. If you select “Manual”, make sure the information is from your
hard disk vendor or system manufacturer.
EGA/VGA
33
34
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
3-2. Advanced BIOS Features
This section allows you configuring your system for basic operation. You have the
opportunity to select the system’s default speed, boot-up priority, keyboard
operation and security.
Item Optimized defaults
Virus Warning Disabled
CPU Internal Cache Enabled
First Boot Device Floppy
Second Boot Device HDD-0
Third Boot Device LS120
Boot Other Device Enabled
Swap Floppy Drive Disabled
Boot Up Floppy Seek Disabled
Boot Up NumLock Status On
Gate A20 Option Fast
Typematic Rate Setting Disabled
Typematic Rate (Chars/Sec) 6
Typematic Delay (Msec) 250
Security Option Setup
OS Select For DRAM > 64MB Non-OS2
HDD S.M.A.R.T. Capability Disabled
Video BIOS Shadow Enabled
C8000-CBFFF Shadow Disabled
CC000-CFFFF Shadow Disabled
D0000-D3FFF Shadow Disabled
D4000-D7FFF Shadow Disabled
D8000-DBFFF Shadow Disabled
DC000-DFFFF Shadow Disabled
Small Logo(EPA) Show Enabled
Cyrix 6x86/MII CPUID Enabled
3-3. Advanced Chipset Features
This section allows you to configure the system based on the specific features of
the installed chipset. This chipset manages bus speeds and the access to the
system memory resources, such as DRAM and the external cache. It also
coordinates the communications with the PCI bus.
items should never be altered. The default settings have been chosen because they
provide the best operating conditions for your system. You might consider making
any changes only if you discover that the data has been lost while using your
system.
Item Optimized defaults
Video Memory Size
Flat Panel Configuration
Onboard Audio Enabled
Onboard USB1.1 Enabled
Onboard USB2.0 Enabled
˙Video Memory Size
This field is used to select the onboard VGA’s frame buffer size that is shared
from the system memory.
<Choice: Disabled, 4M, 6M,8M,12M,16M>
˙Flat Panel Configuration
Item Optimized defaults
Flat Panel Type CRT
Resolution 640x480
Bus Width 24 Bit
Data Type Normal
Refresh Rate 60 Hz
HSYNC Polarity Low
VSYNC Polarity Active Low
SHFCLK Active Period Free runing
LP Activ e Period Free runing
Flat Panel Type
˙
This field is used to select the type of display to use when the system boot.
<Choice: CRT/LCD>
It must be stated that these
16M
Press Enter
35
36
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
˙Resolution
This field is used to select the resolution of LCD panel.
<Choice: 640x480/800x600/1024x768/1152x864/1280x1024/1600x1200>
˙Bus Width
This field is used to select the bus width of LCD panel. Generally is “24bits”.
<Choice: 8/9/12/16/18/24>
˙Data type
This field is used to select the data type of LCD panel. Generally is “Normal”.
<Choice: Normal/2 X>
˙Refresh Rate
This field is used to select the refresh rate (VSYNC frequency) to LCD panel.
Default is “60 Hz”.
<Choice: 60/65/70/72/75/85>
˙HSYNC Polarity
This field is used to select the polarity of HSYNC for LCD. Default is “Low”.
<Choice: Low/High>
˙VSYNC Polarity Active
This field is used to select the polarity of VSYNC for LCD. Default is “Low”.
<Choice: Low/High>
˙SHFCLK Active Period
This field is used to select the working period of shift clock. Generally is “Free
running”.
<Choice: Free running/Active only>
˙LP Active Period
This field is used to select the working period of line pulse. Generally is “Normal”.
<Choice: Free running/Active only>
If you apply one of the standard panels shown above, select the appropriate
option according to the type of panel that you apply. Or, please contact your
dealer or sales representative for custom -made BIOS that will suit th e pan el that
you apply.
3-4. Integrated Peripherals
The IDE hard drive controllers support up to two separate hard drives. These dri ves
have a master/slave relationship that is determined by the cabling configuration
used to attach them to the controller. Your system supports two IDE controllers--a
primary and a secondary--so you can install up to four separate hard disks.
Integrated Peripherals
Item Optimized defaults
Master Drive PIO Mode Auto
Slave Drive PIO Mode Auto
IDE Primary Master UDMA Auto
IDE Primary Slave UDMA Auto
IDE DMA transfer access Enabled
IT8888 ISA Decode IO Press Enter
IT8888 ISA Decode Memory Press Enter
IT8888 DDMA Press Enter
IDE HDD Block Mode Enabled
Onboard Lan Boot ROM Disabled
Onboard FDC Controller: Enabled
Onboard Serial Port 1 3F8/IRQ4
Onboard Serial Port 2 2F8/IRQ3
Onboard Serial Port 3 3E8/IRQ4
Onboard Serial Port 4 2E8/IRQ3
Onboard Parallel Port 378/IRQ5
Parallel Port Mode Standard
ECP Mode Use DMA 3
˙Master/Slave PIO Mode
The two IDE PIO (programmed Input/Output) fields let you set a PIO mode (0-4)
for each IDE device that the internal PCI IDE interface supports. Modes 0
through 4 provide successively increased performance. In Auto mode, the
system automatically determines the best mode for each device.
˙IDE Primary Master/Slave UDMA
These fields allow you to set the Ultra DMA in use. When Auto is selected, the
BIOS will select the best available option after checking your hard drive or
CD-ROM.
37
38
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
˙IDE HDD Block Mode
Block mode is also called block transfer, multiple commands, or multiple sectors
read/write.
˙IT8888 ISA Decode IO
Item Optimized defaults
Decode I/O Space 0 Disable
Decode I/O Speed 0 Subtractive Speed
Decode I/O Addr. 0 [15:4] 001
Decode I/O Size 0 1 Bytes
Decode I/O Space 1 Disable
Decode I/O Speed 1 Subtractive Speed
Decode I/O Addr. 1[15:4] 001
Decode I/O Size 1 1 Bytes
Decode I/O Space 2 Disable
Decode I/O Speed 2 Subtractive Speed
Decode I/O Addr. 2[15:4] 001
Decode I/O Size 2 1 Bytes
Decode I/O Space 3 Disable
Decode I/O Speed 3 Subtractive Speed
Decode I/O Addr. 3[15:4] 001
Decode I/O Size 3 1 Bytes
Decode I/O Space 4 Disable
Decode I/O Speed 4 Subtractive Speed
Decode I/O Addr. 4[15:4] 001
Decode I/O Size 4 1 Bytes
Decode I/O Space 5 Disable
Decode I/O Speed 5 Subtractive Speed
Decode I/O Addr. 5[15:4] 001
Decode I/O Size 5 1 Bytes
˙Decode I/O Addr. 0~5 [15:4]
Set the Decode I/O base address (0~5, the available range of this value is “0001”
to “0FFF”).
˙Decode I/O Size 0~5
Set the Decode I/O size.
<Choice: 1/2/4/8/16/32/64/128 Bytes >
˙IT8888 ISA Decode Memory
Item Optimized defaults
Decode Memory Space 0 Disable
Decode Memory Speed 0 Subtractive Speed
Decode Memory Addr. 0 [23:12] 000
Decode Memory Size 0 16 KB
Decode Memory Space 1 Disable
Decode Memory Speed 1 Subtractive Speed
Decode Memory Addr. 1 [23:12] 000
Decode Memory Size 1 16 KB
Decode Memory Space 2 Disable
Decode Memory Speed 2 Subtractive Speed
Decode Memory Addr. 2 [23:12] 000
Decode Memory Size 2 16 KB
Decode Memory Space 3 Disable
Decode Memory Speed 3 Subtractive Speed
Decode Memory Addr. 3 [23:12] 000
Decode Memory Size 3 16 KB
˙Decode I/O Space 0~5
Enable or Disable the Decode I/O space function (0~5).
˙Decode I/O Speed 0~5
Set the Decode I/O speed (0~5)
<Choice: Subtractive Speed/Slow Speed/Medium Speed/Fast Speed>
39
˙Decode Memory Space 0~3
Enable or Disable the Decode memory space function (0~3).
40
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
˙Decode Memory Speed 0~3
Set the Decode Memory speed 0~3
<Choice: Subtractive Speed/Slow Speed/Medium Speed/Fast Speed>
˙Decode Memory Addr. 0~3 [23:12]
Set the Decode memory base address (0~3, the available range of this value is
“0001” to “0FFF”).
˙Decode Memory Size 0~3
Set the Decode memory size.
<Choice: 16 KB/32 KB/64 KB/128 KB/256 KB/512 KB/1 MB/2 MB>
˙IT8888 ISA DDMA
Item Optimized defaults
DDMA0 Support Disable
DDMA1 Support Disable
DDMA2 Support Disable
DDMA3 Support Disable
DDMA5 Support Disable
DDMA6 Support Disable
DDMA7 Support Disable
Enable or Disable the DMA channel for ISA device.
˙Onboard LAN Boot ROM
By default, this field is disabled. Enable this field if you wish to use the boot ROM
(instead of a disk drive) to boot-up the system and access the local area network
directly.
˙Parallel Port Mode
Set the parallel port mode.
<Choice: Standard/SPP/EPP1.7/EPP1.9/ECP/ECP+EPP>
3-5. Power Management Setup
The Power Management Setup allows users configuring the system to save energy
in a most effective way while operating in a manner consi stent with their own style of
computer use.
Item Optimized defaults
ACPI function Enabled
ACPI Suspend Type S1(POS)
Standby Mode Disabled
Suspend Mode Disabled
Soft-Off by PWRBTN Instant-Off
Power-On by Alarm Disabled
Time (hh:mm:ss) Alarm 0
0
0
IRQ Wakeup Events Press Enter
˙
ACPI Suspend Type
This field is used to select the type of Suspend mode.
S1(POS)
Enables the Power On Suspend function.
3-6. PnP/PCI Configurations
This section describes the configuration of the PCI bus system. PCI is a system
that allows I/O device to operate at speeds nearing the speed of the CPU itself,
when communicating with its own special components. This section covers some
very technical items. It is strongly recommended that only experienced users make
any changes to the default settings.
Item Optimized defaults
PNP OS Installed No
Init Display First PCI Slot
Reset Configuration Data Disabled
Resources Controlled By Auto(ESCD)
IRQ Resources Press Enter
DMA Resources Press Enter
Memory Resources Press Enter
PCI/VGA Palette Snoop Disabled
˙
41
42
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
˙Reset Configuration Data
The BIOS will reset the Extended System Configuration
Enabled
Disabled
˙Resources Controlled By
Auto(ESCD)
Manual
˙PCI/VGA Palette Snoop
When set to [Enabled], multiple VGA devices operating on different buses can
handle data from the CPU on each set of palette registers on every video device.
Bit 5 of the command register in the PCI device configuration space is the VGA
Palette Snoop bit (0 is disabled).
3-7. PC Health Status
This screen shows the information of temperature, Fan speed and Vcore etc. It also
can set CPU warning temperature to protect CPU.
Current CPU T empera ture
VCC
5 VTR
5 V
12 V
Fan1 Speed
Fan2 Speed
Data (ESCD) once automatically. It will then recreate a
new set of configuration data.
The BIOS will not reset the configuration data.
The system will automatically detect the settings for you.
Choose the specific IRQ in the “IRQ Resources” field.
PC Health Status
Item Optimized defaults
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Chapter 4. VGA, LCD and drivers
4-1. Graphic controller Feature
The ENDAT-GX201 integrated a high performance with low power consumption 2D
graphics engine. The graphics controller is full compliance and compatibility with
IBM® VGA and VESA™ extended VGA.
The display controller is integrated video DACs and TFT LCD interface for various
embedded application. The display operation is support CRT or TFT LCD o nly; the
simultaneous operation mode is not supported by this graphics controller.
The on-board Graphics Controller’s main system features include:
- High Performance 2D graphics controller
- Alpha BLT
- Hardware frame buffer compression improves UMA (Unified Memory
Architecture) memory efficiency
- Support up to 1600 x 1200 x 16 bpp and 1280 x 1024 x 24 bpp running at 85
HZ (CRT/LCD monitor)
- Hardware based VGA (Video Graphics Array)
- Hardware video up/down scalar
- Graphics/video alpha blending
- Integrated dot clock PLL (Phase Lock Loop) up to 230 MHZ
- Direct TFT LCD support up to 1280 x 1024 x 24.
43
44
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
4-2. LCD Flat Panel
z Flat Panel Interface
The on-board graphics controller also support industry standard TFT LCD panel,
the interface supports both of TTL and LVDS (optional):
TTL interface: 9, 12, 18 and 24bit by standard version support.
LVDS interface: 18 and 24bit by optional feature support.
LVDS interface provides a low voltage, high speed and low EMI serial DC-balanced
differential data via optional onboard LVDS.
The flat panel interface provides or supports the following functions for various
panels:
- Generates flat panel interface signals like FLM, LP, SCLK, and DE
- Generates different video data formats to directly drive different types of
panels
- Vertical and horizontal expansion of video displays to LCD panel resolution
- Vertical and horizontal centering
- Panel power sequence
Due to the ENDAT-GX201 is not support the simultaneous opera tion mode (CRT +
LCD), any mismatch timing setting in BIOS will affect the LCD screen display with
noise, shift, or other abnormally symptoms. Please refer to the operation guide of
next page to support all of the LCD application on ENDAT-GX201:
z Operation guide:
The graphics controller of ENDAT-GX201 is only support VESA timing for all LCD
configurations; please make sure the LCD which applies on this board is fully
compliant with VESA standard timing.
Operation procedure:
z Step 1: Set the JP8 as “CRT (close pin2 and pin3)”.
z Step 2: Press <Del> key when system boot up and enter the CMOS BIOS
setup utility.
z Step 3: Change the parameter of LCD setting in BIOS to match the LCD spec.
z Step 4: Press <F10> to save the change and exit the BIOS utility, turn off the
system power after system is finished all boot up procedure.
z Step 5: Set the LCD power by JP6 to match the LCD spec and set the JP8 as
“LCD (close pin1 and pin2)”.
z Step 6: Turn on the system and measure the LCD power by voltage meter,
turn off the system power and if the voltage is correct or change JP6 again if
voltage is not correct.
z Step 7: Turn off the power and connect LCD to M/B for verify the LCD display
screen is correct or not.
z Step 8: Change the JP8 as “CRT (close pin2 and pin3)” to continue testing the
LCD parameter in BIOS while LCD display cannot be seen.
z Step 9: Please contact the dealer or sales department of UNICORN and send
one set of LCD (LCD, INVERTER, cables) to them for more detail testing in
the configuration.
Note: The JP8 will affect anytime with any BIOS setting even with a wrong setting of LCD
parameter in BIOS. It can force the display device as “CRT/LCD monitor” when LCD
display not working with currently parameters of LCD.
45
46
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
H/W jumper:
JP8: LCD / CRT selector (1x3 with 2.0mm)
Pin 1-2
Pin 2-3*
JP6: LCD Voltage Selector (2x3 with 2.0mm)
Pin 1-2 *
Pin 3-4
Pin 5-6
Caution: Improper setting will damage LCD panel.
JP7: LVDS Trigger Edge Selector (1x3 with 2.0mm)
Pin 1-2 *
Pin 2-3
LCD
CRT
+3.3V
+5V
+12V
Rising edge
Falling edge
BIOS setting:
Flat Panel Type
˙
This field is used to select the type of display to use when the system boot.
<Choice: CRT/LCD>
˙Resolution
This field is used to select the resolution of LCD panel.
<Choice: 640x480/800x600/1024x768/1152x864/1280x1024/1600x1200>
˙Bus Width
This field is used to select the bus width of LCD panel. Generally is “24bits”.
<Choice: 8/9/12/16/18/24>
˙Data type
This field is used to select the data type of LCD panel. Generally is “Normal”.
<Choice: Normal/2 X>
˙Refresh Rate
This field is used to select the refresh rate (VSYNC frequency) to LCD panel.
Default is “60 Hz”.
<Choice: 60/65/70/72/75/85>
˙HSYNC Polarity
This field is used to select the polarity of HSYNC for LCD. Default is “Low”.
<Choice: Low/High>
˙VSYNC Polarity Active
This field is used to select the polarity of VSYNC for LCD. Default is “Low”.
<Choice: Low/High>
˙SHFCLK Active Period
This field is used to select the working period of shift clock. Generally is “Free
running”.
<Choice: Free running/Active only>
˙LP Active Period
This field is used to select the working period of line pulse. Generally is “Normal”.
<Choice: Free running/Active only>
Please note that the default setting is with “CRT only”. If the LCD display feature is
required, the setting will need to be revised in the system BIOS setting: “Select Display
Device” under “Advanced Chipset Features
”;
unless it is specified at the time of order.
47
48
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
4-3. Driver Utility Installation Guide
1.
When finishing the installation of Windows XP, please install the relative AMD display
and AUDIO driver manually for compliance compatibility of hardware environment.
2. Please contact sales department of UNICORN for Embedded OS user driver
(Windows CE and Windows XP embedded). All of embedded OS driver is not
be included in any versions of driver CD-ROM from UNICORN.
Please download or check from AMD Web site:
versions of driver as needs!
www.amd.com
for more information or last
Chapter 5. LAN Adapter
The ENDAT-GX201 integrated two 10/100 Fast Ethernet Controllers by two Realtek
RTL8100C chips. Both of two chips complies with the IEEE 802.3x standard, IEEE802.3
standard and PCI Local Bus version 2.2 and transmits data on the network at 100 Mbps or 10
Mbps. It also operates in full-duplex mode that
Mbps when working with Fast Switching Hub.
RTL8100C connection to 10/100 Ethernet network, and automatically senses the connection
type.
5-1. Features
•
Full compliancy with PCI Rev. 2.2
•
Complies with the Ethernet/IEEE 802.3u 100Base-TX and 10 Base-T industry standard
•
Supports full-duplex operations, thus doubling the network speed up to 20Mbps on 10
Base-T Ethernet or 200Mbps on 100 Base-TX Fast Ethernet when setting in full duplex
mode
•
Two LED indicators to report network status for each port
•
Two RJ-45 connector with Auto-sense cable type of 10 or 100Mbps network operation
•
Supports PCI clock speed up to 33MHz
•
Supports Remote Boot ROM by system BIOS (Only available on LAN1)
•
Support WOL (Wake On LAN) function on-board (Only available on LAN1)
•
Provides a comprehensive setup program for displaying the adapter configuration and
includes diagnostic on board or network tests
doubles the network speed up to 20/200
Built-in two RJ-45 ports for each
49
50
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
5-2. UTP Cable / RJ-45 Jack Definition
Straight through twisted pair cable is typically used to connect a hub to a server or workstati on.
In a straight through connection, Pin 1 at the server, Pin 2 at the hub connects to Pin 2 at the
server, and so on. Figure A-1 shows the locations of pins on a standard RJ-45 plug on a
twisted-pair cable.
Table A-1 shows the wiring in a straight-through twisted-pair cable (Pins 4, 5, 7 and 8 are not
used).
Twisted Pair
Number
1
2
Pin Number
1
2
3
6
Signal
Description
TD+
TD–
RD+
RD–
T able A-1
To Pin Number
Æ
Æ
1
2
3
6
Signal
Description
TD+
TD–
RD+
RD–
5-3. Connecting 100Base-TX Fast Ethernet Network
To connect the adapter to 100Base-TX Fast Ethernet Network, you need a twisted-pair
Category 5 cable with RJ-45 modular jacks at both ends. This cable can have a maximum
length of 300 feet (100 meters).
5-4. Remote BOOT ROM function
This function is available with the BIOS programming for indicated operation system. The
remote boot function allows the computer to boot up over the network, instead of using the
local operating system device. This enables the system to be a diskless workstation
environment.
5-5. Diagnostic Program (RSET8139)
This program allows you to verify the configuration and isolation of faults.
Program (RESET8139.exe) provides the following function:
•
Displays the current configuration of the adapter
•
Performs network diagnostic tests to verify the operation of the adapter’s basic
functions, and the adapter’s ability to communicate over the network with another
adapter.
•
Provides set up for new configuration to make a change specify settings: Remote
BOOT ROM, Flow Control and Full-Duplex mode Enable/or Disable
Full duplex operation is set automatically if the Full-duplex option is set to Disable. Please
follow the prompt instructions to set-up or change the system configuration.
Note:
Before running the setup program, make sure the adapter’s driver is not loaded,
otherwise unpredictable results may arise!
Figure A-1
51
The program can be set the on board configuration to provide diagnostic testing. It is for
testing the basic function verification, EEPROM data Access, loop back operation, and the
ability to communicate over the network with another adapter.
52
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
To access this program, insert the Driver Diskette into the floppy disk drive or other bootable
device (such as USB flash disk) and then type the following at the DOS prompt:
¾
A:\REST8139.EXE <ENTER>
1. View Current Configuration
This allows you to find the PCI Fast Ethernet adapter current configuration in your system.
2. Set Up New Configuration
Select Set Up New Configuration option from the main menu
The option settings can be changed, the table shown as below:
Option Default Setting Other Available Settings
Medium T y pe Auto Selection 100 Full – Fo rces to full du plex operatio n
Flow Control Tx Enable, Rx Enable Tx Disable, Rx Disable
Note:
Before setting the adapter for full duplex, make sure the hub switch is also set to full
duplex. Before you activate the switching hub to server con nection, make sure the
hub switch and adapter are configured for full duplex.
3. Run Diagnostics
Running diagnostic tests perform basic function verification for on board LAN adapters.
The basic Diagnostic tests include:
•
EEPROM T est
•
Diagnostics On Board
•
Diagnostics On Network
computer set up as a Responder to receive packets from the adapter being tested and
echo them back to the adapter. This checks the adapter’ s ability for communication over
the network with another adapter to receive and transmit network packets.
: EEPROM data read/write test
: Performs on board basic function verification
: To run this test on the network, you will need another
Appendix A: FLASH Memory Utility
Using this utility to update the system BIOS from a disk file to the on board Flash memory. Be
aware the improper change of the system BIOS will cause the system to malfunction.
Using utility as follows:
1. Insert the FLASH memory utility distribution floppy diskette in drive A:
2. At the DOS prompt, type A:>AWDFLASH and press <Enter>
AwardBIOS FLASH Utility V8.24G
C>Phoenix Technologies Ltd. All Rights Reserved
Flash Type –
File Name to Program:
Message:
3. Enter the name of the system BIOS disk file into the "File Name to Program" field.
The following message appears in the "Message" field
4. Do you want to save BIOS (y/n)?
5. To update the FLASH memory from the system BIOS disk file, type Y
6. After complete updating, please re-boot the system (press “
7.
For upgrade BIOS procedure, please refer to our web site:
http://www.uni corn-computer.com.tw
* Please turn off system and clear CMOS data by JBAT1.
* Please restart your system and load setup default
/
F1
” key)
53
54
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Appendix B: Connector Pin Assignment
VGABH1: CRT Box Header Connector (2x8 with 2.54mm)
Pin No. Description Pin No. Description
1
2
3
4
5
6
7
8
CN8/4: Box Header Type Connector for COM3/4 port (2x5 with 2.54mm)
Pin No. Function Pin No. Function
1
2
3
4
5
LPT1: Printer Port Box Header (2x13 with 2.54mm)
Pin No. Description Pin No. Description
1
2
3
4
5
6
7
8
9
RED
GREEN
BLUE
N.C.
GND
GND
GND
GND
DCD
RXD
TXD
DTR
GND
STB#
PD0
PD1
PD2
PD3
PD4
PD5
PD6
PD7
9
10
11
12
13
14
15
6
7
8
9
10
10
11
12
13
14
15
16
17
18-25
N.C / +5V
GND
N.C.
DDC DAT
H-Sync
V-Sync
DDC CLK
DSR
RTS
CTS
RI
N.C.
ACK#
BUSY
PE
SLCT
AFD#
ERR#
INIT#
SLIN#
GND
55
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
FDD1: FDD Box Header (2x17 with 2.54mm)
Pin No. Description Pin No. Description
1,3,5,7
9,11,13
15,17,19
21,23,25
27,29,31
33
2
4,6
8
10
12
GND
GND
GND
GND
GND
GND
RWC#
N.C
INDEX#
MOA#
DSB#
14
16
18
20
22
24
26
28
30
32
34
RDATA#
DSKCHG#
56
DSA#
MOB#
DIR
STEP#
WD#
WE#
TRAK0
WP#
HEAD#
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
IDE1 Box Header (2x20 with 2.54mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
IDE Reset#
IDE data7
IDE data6
IDE data5
IDE data4
IDE data3
IDE data2
IDE data1
IDE data0
GND
IDE REQ
IDE IOW#
IDE IOR#
IDE Ready
IDE ACK#
IDE IRQ
IDE A1
IDE A0
IDECS1#
HDLED#
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
IDE data8
IDE data9
IDE data10
IDE data11
IDE data12
IDE data13
IDE data14
IDE data15
P66DET
IDESC3#
57
GND
N.C.
GND
GND
GND
GND
GND
N.C.
IDE A2
GND
IDE1B: Slim IDE1 Connector (2x22 with 2.0mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
IDE Reset#
IDE data7
IDE data6
IDE data5
IDE data4
IDE data3
IDE data2
IDE data1
IDE data0
GND
IDE REQ
IDE IOW#
IDE IOR#
IDE Ready
IDE ACK#
IDE IRQ
IDE A1
IDE A0
IDECS1#
HDLED#
VCC (+5V)
GND
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
GND
IDE data8
IDE data9
IDE data10
IDE data11
IDE data12
IDE data13
IDE data14
IDE data15
N.C.
GND
GND
GND
GND
GND
N.C.
P66DET
IDE A2
IDESC3#
GND
VCC (+5V)
N.C.
58
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
TTL1: TTL LCD Panel Box Header (2x22 with 2.0mm)
Pin No. Signal Pin No. Signal
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
LVDS1: LVDS LCD Pin Header (2x8 with 2.54mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
Please make sure the Pin 1 location before inserting the LCD connector.
VBL (+12V)
GND
LCD-PWR
ENBKLT
B0
B2
B4
B6
G0
G2
G4
G6
R0
R2
R4
R6
GND
CLK
DE
GND
LCD-PWR
LCD-PWR
Y0-
Y0+
Y1-
GND
Y1+
CK-
CK+
VBL (+12V)
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42 KEY
44
2
4
6
8
10
12
14
16
VBL (+12V)
GND
LCD-PWR
GND
B1
B3
B5
B7
G1
G3
G5
G7
R1
R3
R5
R7
GND
V-SYNC
H-SYNC
LCD-PWR
LCD-PWR
Y2-
Y2+
LCD-PWR
Y3-
Y3
LCD-PWR
ENBKLT
GND
JUSB1: Pin Header for USB port (2x5 with 2.54mm)
Pin No. Function Pin No. Function
1
3
5
7
9
FAN1, FAN2: Cooling Fan Connector
Pin No. Function
1
2
3
CN5: PS/2 Keyboard / Mouse Pin Header (2x5 with 2.0mm)
Pin No. Signal (KB) Pin No. Signal (MS)
1
3
5
7
9
IRDA1: IR Pin Header (1x5 with 2.54mm)
Pin No. Function Pin No. Function
1
2
3
SMB1: SM Bus Pin Header (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
2
USB_VCC
USBD2-
USBD2+
USB_GND
USB_GND
GND
+12V
Sensor Pin
KB Data
KEY
GND
+5V(DC)
KB_CLK
+5V
N.C
IRRX
SMBCK
SMBDT
2
4
6
8
10
2
4
6
8
10
4
5
3
4
USB_VCC
USBD3-
USBD3+
USB_GND
USB_GND
MS Data
KEY
GND
+5V(DC)
MS_CLK
GND
IRTX
+3.3V
GND
59
60
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
CN7: DIGITAL I/O Pin Header (2x13 with 2.0mm)
Pin No. Function Pin No. Function
1
3
5
7
9
11
13
15
17
19
21
23
25
Note: Only available when PC104 function present
UBIO1: DIGITAL I/O (w/o buffer) Pin Header (2x6 with 2.0mm)
Pin No. Function Pin No. Function
1
3
5
7
9
11
CN10: MIC IN (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
CN9: LINE IN (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
DIO-O0
DIO-O1
DIO-O2
DIO-O3
GND
+12V
GND
+3.3V
+5V
DIO-I0
DIO-I1
DIO-I2
DIO-I3
+3.3V
GPIO0
GPIO1
GPIO2
GPIO3
GND
MIC POWER
GND
LINE IN-L
GND
2
4
6
8
10
12
14
16
18
20
22
24
26
2
4
6
8
10
12
2
4
2
4
DIO-O4
DIO-O5
DIO-O6
DIO-O7
+5V
+3.3V
KEY
+12V
GND
DIO-I4
DIO-I5
DIO-I6
DIO-I7
GND
GPIO4
GPIO5
GPIO6
GPIO7
+3.3V
GND
MIC IN
GND
LINE IN-R
61
CN11: LINE OUT (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
CN12: CD IN Pin Header (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
CN13: SPEAKER OUT (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
D-SUB Type Connector for COM2 port (RS-232)
Pin No. Description Pin No. Description
1
2
3
4
5
D-SUB Type Connector for COM2 port (RS-422Æ 4 Wire)
Pin No. Function Pin No. Function
1
2
3
4
5
LINE OUT-R
GND
CD IN-R
GND
SPEAKER OUT-R
GND
DCD
RXD
TXD
DTR
GND
–TXD
+RXD
+TXD
NA
NA
2
4
2
4
6
7
8
9
6
7
8
9
62
GND
LINE OUT-L
GND
CD IN-L
2
4
SPEAKER OUT-L
DSR
RTS
CTS
RI
NA
NA
NA
–RXD
GND
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
D-SUB Type Connector for COM2 port (RS-485Æ 2 Wire)
Pin No. Function Pin No. Function
1
2
3
4
5
Data –
NA
Data +
NA
NA
A TXPWR: ATX Power connector
ATX
3.3V 11 1 3.3V
–12V 12 2 3.3V
GND 13 3 GND
PS ON 14 4 +5V
GND 15 5 GND
GND 16 6 +5V
GND 17 7 GND
–5V 18 8 POWER OK
+5V 19 9 5V SB
+5V 20 10 +12V
6
7
8
9
NA
NA
NA
NA
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
Appendix C: LIMITED WARRANTY
Standard one year limited warranty on all our ENDAT series all-in-one
motherboards and embedded board. Products that become defective during the
warranty period shall be repaired, or subject to manufacturer’s option, replaced.
The limited warranty applies to normal proper usage of the hardware and does not
cover products that have been modified or subjected to unusual electrical or
physical stress. Unicorn Computer Corp is not liable to repair or replace defective
goods caused by improper using or use of unauthorized parts. The following
situations will be charged:
1. The products during the warranty but defective caused by improper using or
artificial external pressure and result in the components damages. According to
the damage situation, the manufacturer has the rights to decide to repair or not.
The manufacturer will charge the parts/repair cost and the returning shipping
charge.
2. The products out of warranty will charge the parts/repair cost and the returning
shipping charge as per the repair status.
3. The manufacturer has the right s to de ci d e to rep ai r or not based on the stock of
parts for the products which are phased out of the production.
4. Please e-mail or fax the RMA Service Request Form when have the defective
products.
63
64
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
ENDAT-GX201 USER’S MANUAL
UNICORN COMPUTER CORP.
RMA SERVICE REQUEST FORM
When requesting RMA service, please fill out this “RMA Service Request Form”.
This form needs to be shipped with your returns. Service cannot begin until we
have this information.
RMA NO.:
Company: Person to Contact:
Phone No: Purchase Date :
Fax No. : Applied Date :
Return Shipping Address:
Model No. Serial No. Problem Code Remark
65
z Issue Code of defect.
01 Second Times R.M.A. 11 Memory Socket Bad
02 No Screen (No Boot) 12 Hang Up Hardware
03 VGA (Display) Fail 13 Hang Up Software
04 CMOS Data Lost 14 PCB Problem
05 FDC Fail 15 CPU Socket Bad
06 HDC Fail 16 LAN Fail
07 Bad Slot 17 Audio Fail
08 BIOS Problem 18 Serial Port Fail
09 Keyboard Controller Fail 19 Parallel Port Fail
10 Cache RAM Problem 20 Others
Please specify the following when returning the RMA boards:
(1) Hardware Configuration (2) OS or Software (3) Testing Program
___________________
Authorized Signature
66
Loading...
