ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301
User’s Manual
Rev . A3
For ENDAT-LX301 PCB ver. A3 or later
10/29/2008
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Copyright Notice
The content of this manual has been checked for accuracy. The manufacturer
assumes no responsibility for any inaccuracies that may be contained in this
manual. The manufacturer reserves the right to make improvements or
modification to this document and/or the product at any time without prior
notice. No part of this document may be reproduced, transmitted, photocopied or
translated into any language, in any form or by any means, electronic, mechanical,
magnetic, optical or chemical, without the prior written permission of the
manufacturer.
AMD is registered trademark of AMD Technology Incorporation
GEODE LX is registered trademark of AMD T echnology Incorporation
Realtek is registered trademark of Realtek Technologi es Inc.
Multiscan is a trademark of Sony Corp of America
IBM, EGA, VGA, PC/XT, PC/AT, OS/2 and PS/2 are registered trademarks of
International Business Machines Corporation
Intel is a registered trademark of Intel Corporation
VIA is registered trademark of VIA Technology Incorporation
Plug and Play is registered trademarks of Intel Corporation
Microsoft, Windows and MS-DOS are trademarks of Microsoft Co rporation
Award is a trademark of Phoenix Software Inc.
PCI is a registered trademark of PCI Special Interest Group
Other product names mentioned herein are used for identification purpose only and
may be trademarks and/or registered trademarks of their respective companies.
Installation Notice
The manufacturer recommends using a grounded plug to ensure proper
motherboard operation. Care should be used in pro per conjunction with a grounded
power receptacle to avoid possible electrical shock. All integrated circuits on this
motherboard are sensitive to static electricity. To avoid damaging components from
electrostatic discharge, please do not remove the board from the anti-st atic packi ng
before discharging any static electricity to your body, by wearing a wrist-grounding
strap. The manufacturer is not responsible for any damage to the motherboard due
to improper operation.
- 1 -
- 2 -
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Specification:
Model ENDAT-LX301
Form Factor
System Chipset
CPU
Supporting
Memory
Ethernet
VGA
LVDS LCD
panel
Serial / Parallel
RS-422/485
IDE Connector
CF card socket
AUDIO
Expansion Slot
MME module
Back Panel I/O
I/O on board
Digital IO
Power input
Mini-ITX 170 mm x 170 mm (6.69”x6.69”) with 6 layers PCB
AMD GEODE LX + CS5536
Onboard AMD GEODE LX 700/800/900 series CPU integrate L1
64KB / L2 128KB cache Processor
One DDR socket support 200/266/333/400MHz up to 1GB
VIA VT6122 for 10/100/1000 Ethernet
Integrated 2D graphic engine by AMD GEODE LX with
8/16/32/64/128/254MB frame buffer
On-board support 18/24 bit LVDS
2 + 4 (by UCM-S MME module; optional) Serial Ports with +5V,
+12V Power Selector / 1 Parallel port
Via CO M2 (Optional)
1 x 40pin IDE connector support UDMA 33/66/100,
1 x 44pin connector support Slim type HDD
Shared with IDE interface (Optional)
AMD CS5536 w/ AC’97 2.0 compliant
One PCI expansion up to 3 PCI slot via riser card
with PCI 2.2 compliant
Reserved 1 set (2 connectors) of MME module connector for
various features (COM ports, PCI device, or Display interfaces)
(Optional)
PS/2 Keyboard / Mouse Connector
2 USB port + 1 RJ-45 LAN Connector(10/100/1000)
VGA and COM1/COM2/LPT (LPT connector will be removed for
MME module) with D-Sub connectors
Audio jack for SPEAKER-OUT
LVDS with 2.54mm 16-pin connector
VGA/LPT (shared from D-SUB) with 2.00mm Box Header
FDD with 2.54mm Box Header
Pin Header for KB/MS, 4 x USB, CD-in, Mic-in, Line-in, Line-out,
Speaker-out, SM Bus, SPDIF, IRDA, KB/MS for external device
2.0mm Pin Header for 12-bits Digital I/O with
CMOS/TTL level (Bi-direction without buffer)
ATX and DC +12V; Optional for Wide range DC (+5V to +27V)
TABLE OF CONTENTS
CHAPTER 1. INTRODUCTION.......................................................6
1-1. FEATURES ................................................................................................ 7
1-2. UNPACKING..............................................................................................8
1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS....................................8
1-4. MOTHERBOARD LAYOUT........................................................................9
CHAPTER 2. SETTING UP THE MOTHERBOARD.....................10
2-1. JUMPERS AND CONNECTORS ............................................................. 10
2-2. INSTALLING MEMORY............................................................................ 20
2-3. SHARED VGA MEMOR Y.........................................................................20
2-4. IRQs MAPPING........................................................................................ 21
2-5. WATCH DOG TIMER ...............................................................................21
2-6. DIGITAL I/O…………………………………………………………………….23
CHAPTER 3. AWARD BIOS SETUP............................................ 25
3-1. STANDARD COMS FEATURES..............................................................26
3-2. ADV ANCED BIOS FEATURES................................................................27
3-3. ADV ANCED CHIPSET FEATURES.........................................................27
3-4. INTEGRATED PERIPHERALS ................................................................ 29
3-5. POWER MANAGEMENT SETUP............................................................31
3-6. PnP/PCI CONFIGURATIONS .................................................................. 32
3-7. PC HEALTH STATUS...............................................................................33
- 3 -
- 4 -
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
CHPATER 4. VGA, L CD AND DRIVERS...................................... 34
4-1. VGA FEATURE.........................................................................................34
4-2. LCD FLAT PANEL....................................................................................35
4-3. DRIVER UTILITY INSTALLATION GUIDE...............................................37
CHPATER 5. LAN ADAPTER.......................................................38
5-1. FEATURES...............................................................................................38
5-2. UTP CABLE/RJ-45 JACK DEFINITION...................................................39
5-3. CONNECTING 100BASE-TX FAST ETHERNET NETWORK.................40
5-4. REMOTE BOOT ROM FUNCTION.......................................................... 40
APPENDIX A: FLASH MEMORY UTILITY................................... 41
APPENDIX B: LIMITED WARRANTY..........................................42
Chapter 1. Introduction
In order to cope with the challenges of the system heating issues and demand of much more
diminutive embedded system in diverse application, ENDAT-LX301 system board provides
the ultimate solution by integrating with AMD GEODE LX technology CPU. ENDAT-LX301
not only provide the ideal solution for Hi-End POS system, but also can be adapted in various
applications such as kiosks, networking systems, control terminals and other embedded
systems with FANLESS environment.
ENDAT-LX301 is designed and integrated with AMD GEODE LX processor and
CS5536. Supports
controller supports standard DDR200 Synchronous DRAM (DDR SDRAM).
ENDAT-LX301 is integrated 2D graphics controller. Based on integrated graphic
controller , it support s TFT LCD p anel or CR T/LCD mo nitor (simultaneou s mode) as
needs. The TFT LCD panels support through LVDS interface, which includes 9-bit,
12-bit, 18-bit, and 24-bit. All resolutions support up to 1024 x 768 for TFT LVDS
panel or 1920 x 1440 for CRT monitor.
ENDAT-LX301 provides one standard PCI slot to support standard PCI adapter
with PCI 2.2 compliant. More, this board offers more flexibility through a MME
module connector which is an optional feature.
The ideal solutions of ENDAT-LX301
- POS system
- KIOSK
- Vehicle system
- Interactive system
- Industrial controller
- Gaming system
- Medical system
- Fan-less system
- Network server
- Embedded system equipment
One DDR DIMM socket 200MHz up to 1GB DDR. The DRAM
- 5 -
- 6 -
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
1-1. Features
Basic Feature:
z A cost effective platform with x86 architecture.
z Embedded AMD GEODE LX 800 processor @ 1.8W power
consumption to offer a totally FANLESS solution.
z One DDR socket supports 200MHz (DDR400) up to 1GB DDR.
z An internal 2D graphic controller with 8/16/32/64/128/254 MB frame
buffer share with system memory
z Integrated 2D graphics controller resolutions up to 1920 x 1440 for
CRT/LCD monitor.
z Direct Flat panel interface support 18/24-bit LVDS LCD panel, the
resolution up to 1024 x 768.
z 12 bits bi-directional I/O ports by standard on-board support.
z Standard PCI slot to support standard PCI adapter with PCI 2.2
compliant (3 slots through PCI riser card). A
by optional features.
z AC97’ Audio support with 1.2W amplifier built-in.
Software Support
z Drivers for major embedded operating systems: Linux, Windows XP,
Windows XP embedded and Windows CE 5.0/6.0.
Ordering information:
1. ENDAT-LX301: Standard version. (ATX and DC+12V)
2. ENDAT-LX301W: Support Wide range.(DC+5V~+27V)
3. ENDAT-LX301A: Support ATX Power only.
MME module connector
1-2. Unpacking
The motherboard comes securely packaged in a sturdy cardboard shipping carton. In
addition to the User's Manual, the motherboard package includes the following items:
•
ENDAT-LX301 System Board
•
HDD/FDD Cables
•
LCD cable
•
CD with Driver utilities for on-board VGA and LAN adapter
If any of these items are missing or damage, please contact the dealer from whom you
purchase the motherboard. Save the shipping material and carton in the event that you want
to ship or store the board in the future.
Note:
Leave the motherboard in its original package until you are ready to install it!
(Optional)
1-3. Electrostatic Discharge Precautions
Make sure you properly ground yourself before handling the motherboard, or other system
components. Electrostatic discharge can easily damage the components. Note: You must
take special precaution when handling the motherboard in dry or air-conditioned
environments.
- 7 -
- 8 -
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
1-4. MOTHERBOARD LAYOUT.
Chapter 2. Setting up the Motherboard
2-1. Jumpers and Connectors
Connectors Overview:
Function Jumpers/Connectors
ATX Power Connector
DC Input connector
DC Output connector
DDR SDRAM Socket
LAN/USB Connector
CRT Output Connector
COM1/COM2 Connector
SPEAKER OUT connector
LPT connector
IDE Connectors
FDD Connector
CF socket
PCI, PCI Riser Slot
MME Module Connectors
Cooling Fan Connectors
PS/2 MS/KB Connector
LVDS Panel Header
VGA Box Header
TTL level serial port (COM1) Header
LPT Box Header
USB Port Headers
PS/2 MS/KB Pin Header
External PS/2 device Header
SPDIF Pin Header
IR Pin Header
SM Bus Header
DIGITAL I/O Pin Header
MIC, CD IN, LINE IN, LINE OUT Header
SPEAKER OUT Header
ATX1
DC-IN1
HDDPWR
DDRDIMM
CN2
VGA1
COM1, COM2
SPEKER
LPT1
IDE1, IDELIM
FDD1
CF1
PCI1, RISER1
PCIMM1, PCIMM2
FAN1, FAN2
CKBMS1
LVDS1
VGABH1
CM1TTL
LPTBH1
JUSB1, JUSB2
CN6
JKB1
SPDIF1
IRDA1
SMB1
GPIO1
CN5
CN1
- 9 -
- 10 -
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Jumpers Overview:
Function Jumpers/Connectors
Clear CMOS
COM Port Voltage Selector
RS232 / 422/ 485 Selector for COM2
LVDS trigger edge selector
LCD Voltage Selector
Restore on AC power loss
Header for Case Panel
HDD active LED
External Speaker
Buzzer On/Off
Hardware Reset Switch
Power LED
WDT Function Enable/Disable
ATX Power Supply On/Off Switch
CF card power / Master, Slaver selector
Please double-check the insertion and orientation of the LCD cable before applying power.
Improper installation will result in permanent damage LC D pa n e l.
JBAT1
JP1
JP2, JP3
JP4
JP5
JP6
JP7
JP7: Pin 1(-), Pin 2(+)
JP7: Pin 3, Pin 6
JP7: Pin 4, Pin 5
JP7: Pin 10, Pin 11
JP7: Pin 12(+), Pin 13(-)
JP7: Pin 14, Pin 15
JP7: Pin 16, Pin 17
JP8
Part 1: Onboard Jumpers
JBAT1: CMOS Data Clear (1x3 with 2.0mm)
Pin 1-2 *
Pin 2-3
JP1: COM Port Voltage Selector (2x6 with 2.0mm)
Voltage +12V(DC) R.I. * +5V(DC)
COM1 1-2 3-4 5-6
COM2 7-8 9-10 11-12
JP2, JP3: RS232 / 422 / 485 Selector for COM2 (2.0mm)
TYPE JP2 (3x4 with 2mm) JP3 (2x7 with 2mm)
RS-232 *
RS-422/485
JP4: LVDS chip trigger edge selector (1x3 with 2.0mm)
Pin 1-2
Pin 2-3 *
Note: Change default location since A5 PCB version.
JP5: LCD Voltage Selector (2x3 with 2.0mm)
Pin 1-2 *
Pin 3-4
Pin 5-6
Caution: Improper setting will damage LCD panel.
JP6: Restore on AC power loss (1x2 with 2.54mm)
Close
Open*
When JP6 was been closed, the system power will turn on automatically when AC
power applied.
Close for clear CMOS
Rising edge
Falling edge
+3.3V
Enable
Disable
Normal
1-2, 4-5, 7-8, 10-11 1-2
2-3, 5-6, 8-9, 11-12 3-4, 5-6
+5V
+12V
- 11 -
- 12 -
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
JP7: Box Header for Case Panel (1x17 with 2.54mm)
Pin No. Function
1(-), 2(+)
3,6
4,5 *
7,8
8,9 *
10,11
12(+), 13(-)
14,15
16,17
JP8: CF card power / Master, Slaver selector (2x3 with 2.0mm)
Pin 1-3 * Slaver Pin 3-5 Master
Pin 2-4 * +5V CF card Pin 4-6 +3.3V CF card
HDD active LED
External Speaker
Buzzer On/Off
Reserved
Reserved
Hardware Reset Switch
Power LED
Close: Enable WDT function
ATX Power On/Off
Part 2: Onboard Connectors and Headers
VGABH1: CRT Box Header Connector (2x8 with 2.0mm)
Pin No. Description Pin No. Description
1
2
3
4
5
6
7
8
TTL1: TTL LCD Panel Box Header (2x22 with 2.0mm)
Pin No. Signal Pin No. Signal
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
RED
GREEN
BLUE
N.C.
GND
GND
GND
GND
VBL (+12V)
GND
LCD-PWR
ENBKLT
B0
B2
B4
B6
G0
G2
G4
G6
R0
R2
R4
R6
GND
CLK
DE
GND
LCD-PWR
LCD-PWR
9
10
11
12
13
14
15
N.C / +5V
GND
N.C.
DDC DAT
H-Sync
V-Sync
DDC CLK
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42 KEY
44
VBL (+12V)
GND
LCD-PWR
GND
B1
B3
B5
B7
G1
G3
G5
G7
R1
R3
R5
R7
GND
V-SYNC
H-SYNC
LCD-PWR
LCD-PWR
- 13 -
- 14 -
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
LVDS1: LVDS LCD Pin Header (2x8 with 2.54mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
Please make sure the Pin 1 location before inserting the LCD connector.
Y0-
Y0+
Y1-
GND
Y1+
CK-
CK+
VBL (+12V)
2
4
6
8
10
12
14
16
IDE1 Box Header (2x20 with 2.54mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
IDE Reset#
IDE data7
IDE data6
IDE data5
IDE data4
IDE data3
IDE data2
IDE data1
IDE data0
GND
IDE REQ
IDE IOW#
IDE IOR#
IDE Ready
IDE ACK#
IDE IRQ
IDE A1
IDE A0
IDECS1#
HDLED#
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
- 15 -
Y2-
Y2+
LCD-PWR
Y3-
Y3
LCD-PWR
ENBKLT
GND
GND
IDE data8
IDE data9
IDE data10
IDE data11
IDE data12
IDE data13
IDE data14
IDE data15
N.C.
GND
GND
GND
GND
GND
N.C.
P66DET
IDE A2
IDESC3#
GND
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
IDELIM: Slim IDE Connector (Shared IDE1, 2x22 with 2.0mm)
Pin No. Description Pin No. Description
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
IDE Reset#
IDE data7
IDE data6
IDE data5
IDE data4
IDE data3
IDE data2
IDE data1
IDE data0
GND
IDE REQ
IDE IOW#
IDE IOR#
IDE Ready
IDE ACK#
IDE IRQ
IDE A1
IDE A0
IDECS1#
HDLED#
VCC (+5V)
GND
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
16
GND
IDE data8
IDE data9
IDE data10
IDE data11
IDE data12
IDE data13
IDE data14
IDE data15
N.C.
GND
GND
GND
GND
GND
N.C.
P66DET
IDE A2
IDESC3#
GND
VCC (+5V)
N.C.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
FDD1: FDD Box Header (2x17 with 2.54mm)
Pin No. Description Pin No. Description
1,3,5,7
9,11,13
15,17,19
21,23,25
27,29,31
33
2
4,6
8
10
12
CN6: PS/2 Keyboard / Mouse Pin Header (2x5 with 2.54mm)
Pin No. Signal (KB) Pin No. Signal (MS)
1
3
5
7
9
JKB1: External PS/2 Device Header (1x7 with 2.0mm)
Pin No. Signal (KB) Pin No. Signal (MS)
1
3
5
7
Note: Change to 2 hard wire jumpers (close pin 1 and 2, 3 and 4) from pin
header since A5 PCB version.
CM1TTL: COM1 TTL interface Pin Header (2x5 with 2.0mm)
Pin No. Function Pin No. Function
1
3
5
7
9
GND
GND
GND
GND
GND
GND
RWC#
N.C
INDEX#
MOA#
DSB#
KB Data
KEY
GND
+5V(DC)
KB_CLK
KB Data Out
KB Clk Out
Key
GND
DCD
SIN
SOUT
DTR
GND
14
16
18
20
22
24
26
28
30
32
34
2
4
6
8
10
2
4
6
2
4
6
8
10
DSA#
MOB#
DIR
STEP#
WD#
WE#
TRAK0
WP#
RDATA#
HEAD#
DSKCHG#
MS Data
KEY
GND
+5V(DC)
MS_CLK
KB Data In
KB Clk In
+5V(DC)
DSR
RTS
CTS
RI
+5V
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
JUSB1, JUSB2: Pin Header for USB port (2x5 with 2.54mm)
Pin No. Function Pin No. Function
1
3
5
7
9
FAN1, FAN2: Cooling Fan Connector
Pin No. Function
1
2
3
CN1: SPEAKER OUT (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
3
CN4: LINE OUT, LINE IN (2x4 with 2.54mm)
Pin No. Function Pin No. Function
1
2
3
4
CN5: MIC IN, CD IN Pin Header (2x4 with 2.54mm)
Pin No. Function Pin No. Function
1
2
3
4
SPDIF1: SPDIF Pin Header (1x5 with 2.54mm)
Pin No. Signal (KB) Pin No. Signal (MS)
1
2
3
USB_VCC
USBD2/4USBD2/4+
USB_GND
USB_GND
GND
+12V
Sensor Pin
SPEAKER OUT-R
GND
LINE OUT-R
GND
GND
LINE OUT-L
MIC POWER
GND
GND
MIC IN
+5V
N.C
SPDIF-OUT
2
4
6
8
10
4
5
2
4
5
6
7
8
5
6
7
8
USB_VCC
USBD3/5USBD3/5+
USB_GND
USB_GND
GND
SPEAKER OUT-L
LINE IN-L
GND
GND
LINE IN-R
CD IN-R
GND
GND
CD IN-L
GND
SPDIF-IN
17
18
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
SMB1: SM Bus Pin Header (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1
2
IRDA1: IR Pin Header (1x5 with 2.54mm)
Pin No. Function Pin No. Function
1
2
3
GPIO1: DIGITAL I/O Pin Header (2x9 with 2.0mm)
Pin No. Function Pin No. Function
1
3
5
7
9
11
13
15
17
D-SUB Type Connector for COM2 port (RS-422Æ 4 Wire)
Pin No. Function Pin No. Function
1
2
3
4
5
D-SUB Type Connector for COM2 port (RS-485Æ 2 Wire)
Pin No. Function Pin No. Function
1
2
3
4
5
SMBCK
SMBDT
+5V
N.C
IRRX
+5V
DIO-P0-0
DIO-P0-2
DIO-P0-4
DIO-P0-6
GND
DIO-P1-0
DIO-P1-2
+3.3V
–TXD
+RXD
+TXD
NA
NA
Data –
NA
Data +
NA
NA
3
4
4
5
2
4
6
8
10
12
14
16
18
6
7
8
9
6
7
8
9
+3.3V
GND
GND
IRTX
+3.3V
DIO-P0-1
DIO-P0-3
DIO-P0-5
DIO-P0-7
GND
DIO-P1-1
DIO-P1-3
+5V
NA
NA
NA
–RXD
NA
NA
NA
NA
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
A TXPWR: ATX Power connector
ATX
3.3V 11 1 3.3V
–12V 12 2 3.3V
GND 13 3 GND
PS ON 14 4 +5V
GND 15 5 GND
GND 16 6 +5V
GND 17 7 GND
–5V 18 8 POWER OK
+5V 19 9 5V SB
+5V 20 10 +12V
DC-IN1: DC Input Power
Pin No. Function
1
2
HDDPWR: DC Output Power for IDE device
Pin No. Function
1
2
3
4
2-2. Installing Memory
The ENDA T -LX301 CPU board offers one 184pin DDR DIMM socket supporti ng up to 1GB of
memory. The speed of DDR memory can be DDR200, DDR266, DDR333 or DDR400.
2-3. Shared VGA Memory
The ENDAT-LX301 is using built-in graphic controller with Unified Memory Architecture
(UMA) determines the number of colors and the video graphic resolution.
up to 254MB
+V
GND
+12V
GND
GND
+5V
of system memory. The amount of video memory on motherboard
19
20
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
2-4. IRQs Mapping
The IRQ number is automatically assigned to PCI expansion cards after those used by
onboard device. To install a PCI riser card, you need to set the correct "ADSEL" and "INT"
(interrupt) assignment.
IRQ Status Assignment
0 Occupied Timer
1 Occupied Keyboard
2 Occupied Second 8259
3 Occupied COM2/COM4 shared
4 Occupied COM1/COM3 shared
5 Occupied LPT1
6 Occupied Floppy Disk
7
8 Occupied RTC
9
10
11
12
13 Occupied Coprocessor
14
15 Occupied Reserved
2-5. Watch Dog Timer
Watchdog Timer (WDT) is a special design for system monitoring to secure the
system work normally . WDT has an independent clock from the oscillator an d could
set time and clear/refresh WDT counter function. When time is up, WDT will send
hardware RESET signal to reset system.
Timeout Value Range
-1 to 255
-Second or Minute
Free Any
Shareable ACPI controller
Free Any
Free Any
Free When PS/2 mouse absent
Free When IDE device absent
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Sample code (using TurboC/C++ 3.0):
#include <stdio.h>
#include <dos.h>
#include <dir.h>
void show_ver();
void main()
{
unsigned int tt;
clrscr();
show_ver();
tt=0;
while((tt==0)||(tt>255))
{
printf("\n\nPlease key in how many seconds you want to reset system (1~255):");
scanf("%d",&tt);
}
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x08); //Set Logic Device number
outportb(0x2e,0xF5); //Set WDT mode
outportb(0x2f,0x00); // bit2 : Enable the rising edgw of keyboard Reset to force Time-out
event. ( 0=Disable / 1= Enable). / bit3 : Select WDTO count mode (0 = second / 1= minute).
outportb(0x2e,0xf6); //Set Watch Dog Timer Time-out value.
outportb(0x2f,tt); //Set time out value of WDT
}
void show_ver()
{
unsigned char tmp0;
printf("Designed by ROBERT LIOU of UNICORN computer corp. \n2008/05/12 release
version:1.0a\n");
printf("This program is design for test Watch Dog Timer for ENADT-LX301(W83627).\n");
}
21
22
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
2-6. Digital I/O
Pin definition:
GPIO1: DIGITAL I/O Pin Header (2x9 with 2.0mm)
Pin No. Function Pin No. Function
1
3
5
7
9
11
13
15
17
This function is supported by onboard super I/O chip; it can be control easily by
change the register of super I/O chip via I/O port “2Eh” “2Fh”. Please see the
sample code of below for implement.
Voltage tolerance: +/- 5% with 0V to +5V.
DIGITAL I/O Pin (DIO-P0)Register configuration:
Bit No 7 6 5 4 3 2 1 0
Map
Sample code for input (using Turbo C/C++ 3.0)
#define input_port 0x2f // Read digital input data define.
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x07); //Set Logic Device number
outportb(0x2e,0xF0); //Set Digital I/O(DIO-P0) Input/Output
outportb(0x2f,0xFF); //Set register value (FF for Input / 00 for output ).
outportb(0x2e,0xF2); //Set Read digital input data
read_data=inportb(input_port); // Read digital input data
printf("DIO-Input=%02X\n",read_data); //Show digital input data on screen
+5V
DIO-P0-0
DIO-P0-2
DIO-P0-4
DIO-P0-6
GND
DIO-P1-0
DIO-P1-2
+3.3V
P0-7 P0-6 P0-5 P0-4 P0-3 P0-2 P0-1 P0-0
2
4
6
8
10
12
14
16
18
+3.3V
DIO-P0-1
DIO-P0-3
DIO-P0-5
DIO-P0-7
GND
DIO-P1-1
DIO-P1-3
+5V
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Sample code for output (using Turbo C/C++ 3.0):
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x07); //Set Logic Device number
outportb(0x2e,0xF0); //Set Digital I/O(DIO-P0) Output
outportb(0x2f,0x00); //Set register value (FF for Input / 00 for output ).
outportb(0x2e,0xF1); //Set active register is CRF1
outportb(0x2f,0x00); //Write data to digital output
DIGITAL I/O Pin (DIO-P1)Register configuration:
Bit No 3 2 1 0
Map
Sample code for input (using Turbo C/C++ 3.0)
#define input_port 0x2f // Read digital input data define.
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x09); //Set Logic Device number
outportb(0x2e,0xF0); //Set Digital I/O(DIO-P0) Input/Output
outportb(0x2f,0x0F); //Set register value (FF for Input / 00 for output ).
printf("DIO-Input=%02X\n",read_data); //Show digital input data on screen
Sample code for output (using Turbo C/C++ 3.0)
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x09); //Set Logic Device number
outportb(0x2e,0xF0); //Set Digital I/O(DIO-P0) Input/Output
outportb(0x2f,0x0F); //Set register value (FF for Input / 00 for output ).
P1-3 P1-2 P1-1 P1-0
outportb(0x2e,0xF2); //Set Read digital input data
read_data=inportb(input_port); // Read digital input data
outportb(0x2e,0xF1); //Set active register is CRF1
outportb(0x2f,0x00); //Write data to digital output
23
24
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Chapter 3. AWARD BIOS SETUP
Phoenix – Award BIOS CMOS Setup Utility
> Standard CMOS Featu res
> Advanced BIOS Features
> Advanced Chipset Features
> Integrated Peripherals
> Power Management Setup
> PnP/PCI Configurations
Use the BIOS CMOS setup program to modify the system parameters to reflect the
environment installed in your system and to customize the system as desired.
Press the <DEL> key to enter into the BIOS CMOS setup program when you turn
on the power. Settings can be accessed via arrow keys. Press <Enter> to choose
an option to configure the system properly.
In the main menu, press F10 or “SAVE & EXIT SETUP” to save your changes and
reboot the system. Choose “EXIT WITHOUT SAVING” to ignore the changes and
exit the setup procedure. Pressing <ESC> at anywhere during the setup will return
to the main menu.
All of the above CMOS BIOS items require board knowledge on PC/AT system
architecture. Incorrect setup could cause system malfunctions.
> PC Health Status
Load Optimized Defaults
Set Supervisor Password
Set Password
Save & Exit Setup
Exit Without Saving
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
3-1. Standar d CMOS Features
The Stand ard Setup is used for the basic ha rdware system configuration. The main
function is for Data/Time and Hard Disk Drive settings.
Item Optimized defaults
Date (mm:dd:yy)
Time (hh:mm:ss)
IDE Primary Master Press Enter
IDE Primary Slave Press Enter
Driver A
Driver B
Video
Halt On
1.44M, 3.5 in.
All , But Keyboard
˙Video
Select the type of primary video subsystem.
<Choice: EGA / VGA, CGA 40, CGA 80, MONO>
˙Halt On
Set the system’s response to specific boot errors.
<Choice: All Errors, No Errors, All, But Keyboard,
All, But Diskette, All, But Disk/Key >
IDE Primary Master/Slaver
Item Optimized defaults
IDE HDD Auto-Detection Press Enter
IDE Channel Auto
Access Mode Auto
The specifications of your drive must match with the drive table. The hard disk will
not work properly if you enter incorrect information in this category. Select “Auto”
whenever possible. If you select “Manual”, make sure the information is from your
hard disk vendor or system manufacturer.
None
EGA/VGA
25
26
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
3-2. Advanced BIOS Features
This section allows you configuring your system for basic operation. You have the
opportunity to select the system’s default speed, boot-up priority, keyboard
operation and security.
Item Optimized defaults
Virus Warning Disabled
CPU Internal Cache Enabled
External Cache Enabled
First Boot Device HDD-0
Second Boot Device CDROM
Third Boot Device LS120
Boot Other Device Enabled
Swap Floppy Drive Disabled
Boot Up Floppy Seek Enabled
Boot Up NumLock Status On
Gate A20 Option Normal
Typematic Rate Setting Disabled
Typematic Rate (Chars/Sec) 6
Typematic Delay (Msec) 250
Security Option Setup
OS Select For DRAM > 64MB Non-OS2
HDD S.M.A.R.T. Capability Disabled
3-3. Advanced Chipset Features
This section allows you to configure the system based on the specific features of
the installed chipset. This chipset manages bus speeds and the access to the
system memory resources, such as DRAM and the external cache. It also
coordinates the communications with the PCI bus.
items should never be altered. The default settings have been chosen because
they provide the best operating conditions for your system. You might consider
making any changes only if you discover that the data has been lost while using
your system.
Item Optimized defaults
CPU Frequency Auto
Memory Frequency Auto
CAS Latency Auto
Interleave Select LOI
XOR BA0 Disable
27
It must be stated that these
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Item Optimized defaults
XOR BA1
XOR MB0
XOR Bit Select 18
Video Memory Size
Output display CRT
Flat Panel Configuration Press Enter
Onboard Audio Enable
Onboard USB1.1 Enable
Onboard USB2.0 Enable
Onboard IDE Enable
Memory Hole At 15M-16M
˙Video Memory Size
This field is used to select the onboard VGA’s frame buffer size that is shared
from the system memory.
<Choice: Disabled, 8M,12M,16M,32M,64M,128M,254M>
˙Flat Panel Configuration
Item Optimized defaults
Flat Panel Type LVDS
Resolution 800x600
Data Bus Type 9-24 bits, 1 ppc
Refresh Rate 60 Hz
HSYNC Polarity Normal low
VSYNC Polarity Active Normal low
SHFCLK Active Period Free runing
LP Activ e Period Free runing
˙Resolution
This field is used to select the resolution of LCD panel.
<Choice:320x240/640x480/800x600/1024x768/1152x864/1280x1024/
1600x1200>.
˙Data Bus Type
This field is used to select the data type of LCD panel. Generally is “Normal”.
<9-24 bits, 1 ppc and 18,24 bits, 2 ppc>.
˙Refresh Rate
This field is used to select the refresh rate (VSYNC frequency) to LCD panel.
Default is “60 Hz”. <Choice: 60/65/70/72/75/85>
28
Disable
Disable
64M
Disable
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
˙HSYNC Polarity
This field is used to select the polarity of HSYNC for LCD. Default is “Normal
Low”. <Choice: Normal Low/Normal High>
˙VSYNC Polarity Active
This field is used to select the polarity of VSYNC for LCD. Default is “Normal
Low”. <Choice: Normal Low/ Normal High>
˙SHFCLK Active Period
This field is used to select the working period of shift clock. Generally is “Free
running”. <Choice: Free running/Active only>
˙LP Active Period
This field is used to select the working period of line pulse. Generall y is “Normal”.
<Choice: Free running/Active only>
If you apply one of the standard panels shown above, select the appropriate
option according to the type of panel that you apply. Or, please contact your
dealer or sales representative for custom-made BIOS that will suit the p anel that
you apply.
3-4. Integrated Peripherals
The IDE hard drive controllers support up to two separate hard drives. These driv es
have a master/slave relationship that is determined by the cabling configuration
used to attach them to the controller. Your system supports two IDE controllers--a
primary and a secondary--so you can install up to four separate hard disks.
Integrated Peripherals
Item Optimized defaults
Master Drive PIO Mode Auto
Slave Drive PIO Mode Auto
IDE Primary Master UDMA Auto
IDE Primary Slave UDMA Auto
IDE DMA transfer access Enabled
IDE HDD Block Mode Enabled
Onboard Lan Boot ROM Disabled
Onboard FDC Controller: Enabled
Onboard Serial Port 1 3F8/IRQ4
Onboard Serial Port 2 2F8/IRQ3
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
UART Mode Select Normal
RxD , TxD Active Hi,Lo
IR Transmission Enable
UR2 Duplex Mode: Half
Use IR Pins: IR-Rx2Tx2
Onboard Parallel 378/IRQ7
Parallel Port Mode: SPP
EPP Mode Select: EPP1.7
ECP Mode Use DMA 3
˙Master/Slave PIO Mode
The two IDE PIO (programmed Input/Output) fields let you set a PIO mode (0-4)
for each IDE device that the internal PCI IDE interface supports. Modes 0
through 4 provide successively increased performance. In Auto mode, the
system automatically determines the best mode for each device.
˙IDE Primary Master/Slave UDMA
These fields allow you to set the Ultra DMA in use. When Auto is selected, the
BIOS will select the best available option after checking your hard drive or
CD-ROM.
IDE HDD Block Mode
˙
Block mode is also called block transfer , multiple commands, or mu ltiple sectors
read/write.
˙Onboard LAN Boot ROM
By default, this field is disabled. Enable this field if you wish to use the boot ROM
(instead of a disk drive) to boot-up the system and access the local area network
directly.
˙UART Mode Select
Select an operating mode for the serial port 2.
<Choice: IrDA, ASKIR, Normal>
˙Parallel Port Mode
Set the parallel port mode.
<Choice: Standard/SPP/EPP1.7/EPP1.9/ECP/ECP+EPP>
29
30
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
3-5. Power Management Setup
The Power Management Setup allows users configuring the system to save energy
in a most effective way while operating in a manner consistent with their own style
of computer use.
Item Optimized defaults
ACPI function Enabled
ACPI Suspend Type S1(POS)
Power Management ACPI
** PM Timers **
Standby Mode Disabled
Suspend Mode Disabled
HDD Power Down Disabled
Soft-Off by PWRBTN Instant-Off
Power-On by Alarm Disabled
Time (hh:mm:ss) Alarm 0
0
0
IRQ Wakeup Events Press Enter
˙
ACPI Suspend Type
This field is used to select the type of Suspend mode.
S1(POS)
IRQ1 (KeyBoard) ON
IRQ3 (COM 2) OFF
IRQ4 (COM 1) OFF
IRQ5 (LPT 2) OFF
IRQ6 (Floppy Disk) OFF
IRQ7 (LPT 1) OFF
IRQ8 (RTC Alarm) OFF
IRQ9 (IRQ2 Redir) OFF
IRQ10 (Reserved) OFF
IRQ11 (Reserved) OFF
Enables the Power On Suspend function.
IRQ Wakeup Events
Item Optimized defaults
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Item Optimized defaults
IRQ12 (PS/2 Mouse) OFF
IRQ13 (Coprocessor) OFF
IRQ14 (Hard Disk) OFF
IRQ15 (Reserved) OFF
3-6. PnP/PCI Configurations
This section describes the configuration of the PCI bus system. PCI is a system
that allows I/O device to operate at speeds nearing the speed of the CPU itself,
when communicating with its own special components. This section covers some
very technical items. It is strongly recommended that only experienced users make
any changes to the default settings.
Item Optimized defaults
PNP OS Installed No
Init Display First PCI Slot
Reset Configuration Data Disabled
Resources Controlled By Auto(ESCD)
IRQ Resources Press Enter
DMA Resources Press Enter
Memory Resources Press Enter
PCI/VGA Palette Snoop Disabled
˙
˙
Reset Configuration Data
The BIOS will reset the Extended System Configuration
Enabled
Disabled
˙Resources Controlled By
Auto(ESCD)
Manual
˙PCI/VGA Palette Snoop
When set to [Enabled], multiple VGA devices operating on different buses can
handle data from the CPU on each set of palette registers on every video device.
Bit 5 of the command register in the PCI device configuration space is the VGA
Palette Snoop bit (0 is disabled).
Data (ESCD) once automatically. It will then recreate a
new set of configuration data.
The BIOS will not reset the configuration data.
The system will automatically detect the settings for you.
Choose the specific IRQ in the “IRQ Resources” field.
31
32
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
3-7. PC Health Status
This screen shows the information of temperature, Fan speed and Vcore etc. It also
can set CPU warning temperature to protect CPU.
PC Health Status
Item Optimized defaults
CPU Warning Temperature Disable
Current System Temp
Current CPU T empera ture
Fan1 Speed
Fan2 Speed
+3.3 V
+5 V
+12 V
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Chapter 4. VGA, LCD and drivers
4-1. Graphic controller Feature
The ENDAT-LX301 integrated a high performance with low power consumption 2D
graphics engine. The graphics controller is full compliance and compatibility with
IBM® VGA and VESA™ extended VGA.
The display controller is integrated video DACs and TFT LCD interface for various
embedded application. The display operation support CRT or TFT LCD only; the
simultaneous operation mode is not supported by this graphics controller.
The on-board Graphics Controller’s main system features include:
- High Performance 2D graphics controller
- Alpha BLT
- Hardware frame buffer compression improves UMA (Unified Memory
Architecture) memory efficiency
- Support up to 1920 x 1440 running at 85 HZ (CRT/LCD monitor)
- Hardware based VGA (Video Graphics Array)
- Hardware video up/down scalar
- Graphics/video alpha blending
- Integrated dot clock PLL (Phase Lock Loop) up to 230 MHZ
- Direct TFT LCD support up to 1024 x 768.
33
34
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
4-2. LCD Flat Panel
z Flat Panel Interface
The on-board graphics controller also supports indust ry standard LVDS TFT LCD:
LVDS interface: 18 and 24bit by standard feature support.
LVDS interface provides a low voltage, high speed and low EMI serial
DC-balanced differential data via optional onboard LVDS.
The flat panel interface provides or supports the following functions for various
panels:
- Generates flat panel interface signals like FLM, LP, SCLK, and DE
- Generates different video data formats to directly drive different types of
panels
- Vertical and horizontal expansion of video displays to LCD panel resolution
- Vertical and horizontal centering
- Panel power sequence
BIOS setting:
Flat Panel Type
˙
This field is used to select the type of display to use when the system boot.
<Choice: CRT/LCD>
˙Resolution
This field is used to select the resolution of LCD panel.
<Choice: 640x480/800x600/1024x768/1152x864/1280x1024/1600x1200>
˙Bus Width
This field is used to select the bus width of LCD panel. Generally is “24bits”.
<Choice: 8/9/12/16/18/24>
˙Data type
This field is used to select the data type of LCD panel. Generally is “Normal”.
<Choice: Normal/2 X>
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
˙Refresh Rate
This field is used to select the refresh rate (VSYNC frequency) to LCD panel.
Default is “60 Hz”.
<Choice: 60/65/70/72/75/85>
˙HSYNC Polarity
This field is used to select the polarity of HSYNC for LCD. Default is “Low”.
<Choice: Low/High>
˙VSYNC Polarity Active
This field is used to select the polarity of VSYNC for LCD. Default is “Low”.
<Choice: Low/High>
˙SHFCLK Active Period
This field is used to select the working period of shift clock. Generally is “Free
running”.
<Choice: Free running/Active only>
˙LP Active Period
This field is used to select the working period of line pulse. Generally is
“Normal”.
<Choice: Free running/Active only>
Please note that the default setting is with “CRT only”. If the LCD display feature is
required, the setting will need to be revised in the system BIOS setting: “Select Display
Device” under “Advanced Chipset Features
”;
unless it is specified at the time of order.
35
36
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
4-3. Driver Utility Installation Guide
1.
When finishing the installation of Windows XP, please install the relative AMD display
and AUDIO driver manually for compliance compatibility of hardware environment.
2. Please contact sales department of UNICORN for Embedded OS user driver
(Windows CE and Windows XP embedded). All of embedded OS driver is not
be included in any versions of driver CD-ROM from UNICORN.
Please download or check from AMD Web site:
versions of driver as needs!
www.amd.com
for more information or last
Chapter 5. LAN Adapter
5-1. FEATURES.
The on-board VIA Velocity VT6122 Gigabit Ethernet Controller
The VIA Velocity™ VT6122 Gigabit Ethernet controller enables leading-edge
performance in a small 14x14mm 128-pin LQFP package, optimized for 32-bit PCI
applications in space-constrained systems. Integrating a feature laden MAC and
Cicada's patented SimpliPHY™ transceiver, the VT6122 Controller is optimized for
space constrained systems with a low power, low profile design.
Supporting 10/100/1000 Mbps triple-speed and full/half-duplex capability at all
speeds, the integrated Cicada PHY is fully compliant to IEEE 802.3 (10BASE-T),
802.3u (100BASE-TX), and 802.3ab (1000BASE-T) standards. With Cicada's
proven SimpliPHY design, VIA Networking's Velocity controllers feature leading
narrow band noise tolerance that delivers superior performance for real world
PCBs and cables.
To minimize host-side CPU utilization, VIA Velocity Gigabit Ethernet Controllers
adopt an adaptive interrupt scheme to reduce interrupts made to the processor,
and maximize the use of packet bursts for efficient PCI bandwidth usage. The
Velocity controllers can further offload tasks from the host CPU to improve the
overall system performance with TCP/UDP/IP checksum, and TCP segmentation
offloading.
Applications
The Velocity VT6122 controller is optimized for 32-bit PCI client-end applications.
Its small form factor 14x14mm, 0.4mm pin-pitch, 128-pin LQFP p ackage provides a
low pin count body size that helps simplify signal routing, minimize board routing
area, resulting in a cost-effective board implementation. Furthermore, to allow a
flexible Gigabit Ethernet (10/100/1000-Mbps) or Fast Ethernet (10/100-Mbps)
implementations on the same board, VIA Networking offers a number of
configuration options integrating our wide range of Ethernet IC options.
37
38
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
5-2. UTP Cable / RJ-45 Jack Definition
Straight through twisted pair cable is typically used to connect a hub to a server or
workstation. In a straight through connection, Pin 1 at the server, Pin 2 at the hub connects
to Pin 2 at the server, and so on. Figure A-1 shows the locations of pins on a standard RJ-45
plug on a twisted-pair cable.
Table A-1 shows the wiring in a straight-through twisted-pair cable (Pins 4, 5, 7 and 8 are not
used).
Twisted Pair
Number
1
2
Pin Number
1
2
3
6
Signal
Description
TD+
TD–
RD+
RD–
T able A-1
To Pin Number
Æ
Æ
1
2
3
6
Signal
Description
TD+
TD–
RD+
RD–
5-3. Connecting 100Base-TX Fast Ethernet Network
To connect the adapter to 100Base-TX Fast Ethernet Network, you need a twisted-pair
Category 5 cable with RJ-45 modular jacks at both ends. This cable can have a maximum
length of 300 feet (100 meters).
5-4. Remote BOOT ROM function
This function is available with the BIOS programming for indicated operation system. The
remote boot function allows the computer to boot up over the network, instead of using the
local operating system device. This enables the system to be a diskless workstation
environment.
Figure A-1
39
40
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
Appendix A: FLASH Memory Utility
Using this utility to update the system BIOS from a disk file to the on board Flash memory.
Be aware the improper change of the system BIOS will cause the system to malfunction.
Using utility as follows:
1. Insert the FLASH memory utility distribution floppy diskette in drive A:
2. At the DOS prompt, type A:>AWDFLASH and press <Enter>
AwardBIOS FLASH Utility V8.24G
C>Phoenix Technologies Ltd. All Rights Reserved
Flash Type –
File Name to Program:
Message:
3. Enter the name of the system BIOS disk file into the "File Name to Program" field.
The following message appears in the "Message" field
4. Do you want to save BIOS (y/n)?
5. To update the FLASH memory from the system BIOS disk file, type Y
6. After complete updating, please re-boot the system (press “
7.
For upgrade BIOS procedure, please refer to our web site:
http://www.uni corn-computer.com.tw
* Please turn off system and clear CMOS data by JBAT1.
* Please restart your system and load setup default
/
F1
” key)
Appendix B: LIMITED WARRANTY
Standard Two years limited warranty on all our ENDAT series all-in-one
motherboards and embedded board. Products that become defective during the
warranty period shall be repaired, or subject to manufacturer’s option, replaced.
The limited warranty applies to normal proper usage of the hardware and does not
cover products that have been modified or subjected to unusual electrical or
physical stress. Unicorn Computer Corp is not liable to repair or replace defective
goods caused by improper using or use of unauthorized parts. The following
situations will be charged:
1. The products during the warranty but defective caused by improper using or
artificial external pressure and result in the components damages. According to
the damage situation, the manufacturer has the rights to decide to repair or not.
The manufacturer will charge the parts/repair cost and the returning shipping
charge.
2. The products out of warranty will charge the parts/repair cost and the returning
shipping charge as per the repair status.
3. The manufacturer has the rights to decide to rep air or not based on the stock of
parts for the products which are phased out of the production.
4. Please e-mail or fax the RMA Service Request Form when have the defective
products.
41
42
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
RMA SERVICE REQUEST FORM
When requesting RMA service, please fill out this “RMA Service Request Form”.
This form needs to be shipped with your returns. Service cannot begin until we
have this information.
RMA NO.:
Company: Person to Contact:
Phone No: Purchase Date :
Fax No. : Applied Date :
Return Shipping Address:
Model No. Serial No. Problem Code Remark
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
z Issue Code of defect.
01 Second Times R.M.A. 11 Memory Socket Bad
02 No Screen (No Boot) 12 Hang Up Hardware
03 VGA (Display) Fail 13 Hang Up Software
04 CMOS Data Lost 14 PCB Problem
05 FDC Fail 15 CPU Socket Bad
06 HDC Fail 16 LAN Fail
07 Bad Slot 17 Audio Fail
08 BIOS Problem 18 Serial Port Fail
09 Keyboard Controller Fail 19 Parallel Port Fail
10 Cache RAM Problem 20 Others
Please specify the following when returning the RMA boards:
(1) Hardware Configuration (2) OS or Software (3) Testing Program
___________________
Authorized Signature
43
44
Loading...
