UNICOM Electric Micro Net 5 User Manual
908 Canada Court
City of Industry, CA 91748 U.S.A.
Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880
www.unicomlink.com e-mail: info@unicomlink.com
www.unihomenetworking box
©UNICOM 2001. UNICOM and “A Network Systems Solution” are trademarks of UNICOM Electric, Inc.
All rights reserved. Specifications subject to change without notice.
Rev: 11.02
5 Port 10/100Mbps
Fast Ethernet Switch
(Auto MDI/MDIX)
Micro-Switch/5
USER’S MANUAL
FEP-32005T-1
Package Contents
Package contents include the following:
1 6
Performance Specifications
Transmission Method: Store and forward
MAC address table: 1K-entry MAC address table
Maximum Forwarding Rate: 14,880 pps /10Base-T
(64byte packets) 148,800 pps /100Base-TX
Maximum Filtering Rate: 14,880 pps /10Base-T
(64byte packets) 148,800 pps/100Base-TX
Flow control: Back-pressure (half-duplex)
Pause frame (full-duplex)
Duplex mode: Supports both Half-duplex and
Full-duplex mode
Physical & Environmental Specification
Power Supply: External power adapter, DC 9V, 700mA
Dimensions: 111mm x 70mm x 19mm (LxWxH)
4.37” x 2.77” x 0.76” (LxWxH)
Operating temperature: 0˚C to 45˚C (32˚F to 113˚F)
Storage temperature: -40˚C to 70˚C (-22˚F to 140˚F)
Humidity: 10% to 90% (non-conditioning)
EMI: FCC Class B, CE mark
Safety: UL, cUL
FCC Statement
This equipment has been tested and found to comply with the limits for a class B
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful inter ference in a commercial installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with instructions, may cause harmful
interference with radio communications. Operation of this equipment in a
residential area is likely to cause harmful inter ference, in which case, the user will
be required to correct the interference at the user’s expense.
■ Micro-Switch/5; 5-Port 10/100 Switch (Auto MDI/MDIX)
■ DC power adapter
■ Four (4) adhesive-backed rubber feet
■ User’s manual
■ Warranty card
Micro-Switch/5 User’s Guide Rubber Feet Power Adapter
5-Port Switch
Figure 1. Contents of package.
IMPORTANT: If any piece is missing or damaged, please contact your
local dealer or reseller for service.
For Your Records
Product Name:
Serial Number:
Date of Purchase:
Purchased from:
Notes:
