UNICOM Electric FEP-32024T User Manual
908 Canada Court
City of Industry, CA 91748 U.S.A.
Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880
www.unicomlink.com e-mail: info@unicomlink.com
www.unihomenetworkingbox.com
©UNICOM 2005. UNICOM and “A Network Systems Solution” are trademarks of UNICOM Electric, Inc.
All rights reserved. Specifications subject to change without notice.
Rev: 01.05
24 Port 10/100Mbps
Desktop Fast Ethernet Switch
(Auto MDI/MDIX)
Micro-Switch/24
USER’S MANUAL
FEP-32024T
Content
1. Introduction .............................................................. 1
Features ...................................................................... 1
Package Contents...................................................... 2
Ethernet Switching Technology............................... 3
2. Hardware Description.............................................. 4
Front Panel ................................................................. 4
LED Indicators............................................................ 4
Rear Panel................................................................... 5
Desktop Installation................................................... 6
3. Network Application ................................................ 7
4. Troubleshooting..................................................... 10
5. Technical Specification ......................................... 12
1. Introduction
The 24 Port Micro-Switch/24 Desktop Fast Ethernet Switch is a multi-port
Switch that can be used to build high-performance switched workgroup
networks. This switch is a store-and-forward device that offers low latency
for high-speed networking. It is targeted at workgroup, department, or
backbone computing environments in SME (small, medium enterprise)
businesses.
The Micro-Switch/24 features a “store-and-forward “switching scheme. This
allows the switch to auto-learn and store source addresses on a 4K-entry
MAC address table.
Features
Conforms to IEEE 802.3, 802.3u and 802.3x
Twenty-four (24) 10/100 Base-TX RJ-45 Ethernet ports
Auto-MDIX on all ports
IEEE 802.3x flow control support
Flow control on full-duplex
Back pressure on half-duplex
N-Way Auto-Negotiation supported
Store-and-Forward switching architecture and no-blocking full wire
speed
Back plane Bandwidth 4.8 Gbps)
Embedded 1.25Mbits memory buffer
4K MAC address table
Compact 10” size
1
Package Contents
Unpack the contents of the Micro-Switch/24 Desktop Fast Ethernet Switch
and verify them against the checklist below.
Micro-Switch/24 Desktop Fast Ethernet Switch
User Guide
Power Cord
Four Rubber Feet
Micro-Switch/24 User Guide
Power Cord Rubber Feet
Figure 1-2. Package Contents
Compare the contents of your Micro-Switch/24 package with the standard
checklist above. If any item is missing or damaged, please contact your local
dealer for service.
2
