Uni Art Precise HP5992 001R, HP5991 001T User Manual
900MHz Wireless Headphone
English
Contents
HP5990A, HP5990, HP5990J, HP5990AJ
!!!Please ensure you read the user manual
thoroughly before use!!!
!!!Please refer to our website: www.geemarc.com
for an up to date user guide, as there may be
important updates and changes you need to be
aware of!!!
INTRODUCTION ......................................................... 3
SAFETY & CARE ADVICE ............................... 4
PACK COMPONENTS ................................................ 5
FUNCTION IDENTIFICATION ..................................... 6
● Function Identification: Headset Receiver ............... 6
● Function Identification: Charging Cradle ................. 7
INSTALLATION .......................................................... 8
● Transmitter .............................................................. 8
● Headset .................................................................. 9
OPERATION ............................................................... 10
● Initial Operation ....................................................... 10
● Routine Operation ................................................... 11
● Improving Sound by Switching Channels .................. 12
● Controlling the Tone (Bass & Treble) ...................... 13
● Adjusting the Sound Balance (left-right) .................. 14
● Using the Mute Button and Microphone for
Conversation ........................................................... 14
● Charging the Battery ............................................... 15
TECHNICAL SPECIFICATIONS ................................. 17
1
TROUBLESHOOTING ....................................... 18
Contents
INTRODUCTION
● No Sound ................................................................ 18
● Distortion ................................................................. 18
Cleaning & Maintenance ........................................... 19
Spare/replacement parts ........................................... 19
Customer support ...................................................... 19
GUARANTEE .............................................................. 20
CE DECLARATION ..................................................... 20
BATTERY WARNINGS ..................................... 21
DISPOSAL INFORMATION ........................................ 21
INTRODUCTION
2
The Geemarc Wireless Audio Listener is an audio amplification
system specifically designed for people with hearing difficulties.
The Geemarc Audio Listener can be used with all kinds of audio
systems for interference-free listening enjoyment – TV set,
Smartphone, DVD player, CD player, Hi-Fi system, iPod or
other.
Audio output from a TV or audio device is transmitted by the
Charging Cradle, the wireless Headset receives the signal and
amplifies the audio sound for the listener.
● The listener’s comfort and long-term enjoyment has been built
into every feature of the Geemarc Wireless Audio Listener:
● Lightweight wireless headset fitted with soft silicone ear buds
for prolonged listening comfort;
● Rich, adjustable audio quality:
o Broad audio bandwidth;
o Adjustable bass, treble and balance to compensate for
hearing loss.
● Up to 60 meters transmit-receive range keeps you within
hearing distance all over the house and garden;
● Auto-tune button on your headset – tune in for the best sound
exactly where you are;
● Listen but keep in touch with your surroundings:
o Multiple Headsets can be paired with one Charging Cradle;
o Single-touch Mute function switches the Audio Listener into
a conversation assistant enabling you to talk with and listen
to the people around you with the Headset on, taking
advantage of its built-in audio amplifier to hear everything
better.
● Up to 6 hours of rechargeable battery life per full charge –
never lose the soundtrack in mid-program;
● Only 3 hours to fully recharge the Headset simply by replacing
the Headset in its Charging Cradle.
3
SAFETY & CARE ADVICE
SAFETY & CARE ADVICE
To make the best use of this product and to use it safely, please
read these instructions thoroughly before use and keep safe for
future reference.
Warning: This product can be very loud. Take care to prevent
others from using this product, if they do not have the same level
of hearing loss. Excessive sound pressure from earphones and
headphones can cause hearing loss.
Caution: Electric shock. DO NOT insert unattached plug heads
in to mains power sockets. Plug heads MUST be fitted to the
power adaptor.
Electrical connection: The unit is designed to operate from a
100-240VAC - 50/60Hz supply. (Classified as 'hazardous voltage'
according to EN 60650 standard).
Caution: Batteries should only be replaced by Geemarc or
authorised Vendor. Please refer to the chapter:
<Spare / replacement parts> for more information.
Keep the unit away from heat sources.
DO NOT expose the unit to direct sunlight.
Do not expose the Headset, which contains batteries, to excessive
heat such as sunshine, fire etc.
Clean the Headset and ear pads regularly. For details on cleaning,
please refer to the chapter: <Clearning & Maintenance>.
DO NOT modify the unit in any way.
Please note: The unit may be subject to interference from
appliances that generate strong electrical or magnetic fields e.g.
wireless Internet routers, microwaves, mobile phones, lighting
transformers etc. To avoid this interference, place the Charging
Cradle unit away from such sources.
4
PACK
PACK COMPONENTS
COMPONENTS
(1) Headset Receiver/TV Receiver(with Belt Clip)
(2) Charging Cradle and Transmitter
(3) Power Supply
(4) Optical Cable
(5) Ear Phone
5
FUNCTION IDENTIFICATION
FUNCTION IDENTIFICATION
Function Identification: Headset Receiver
FRONT
REAR
(1) Earbuds
(2) Volume Control
(3) Power/Signal LED Indicator
6
(4) Mute Button for Verbal Communications
FUNCTION IDENTIFICATION
(5) Microphone
(6) Auto Tune Button for Frequency Channel
(7) Sound Balance Control
(8) Power On/Off Switch
(9) Battery Contact
Function Identification: Charging Cradle
7
