Ultratec LSX Operator's Manual
LSX Low Smoke Converter
Operator’s Manual
www.ultratecfx.com
VER. 04.11.12
Table of Contents
Introduction ................................................................................ 3
Warning ...................................................................................... 3
Important Safety Instructions: ................................................... 3
Safety Precautions ..................................................................... 3
Technical Specications ............................................................. 4
Technical Drawings ................................................................... 4
Operating Procedure ................................................................. 5
Control Panel Operations .......................................................... 5
Before Requesting Service ........................................................ 6
Recommended Fluids ................................................................. 6
Warranty ..................................................................................... 7
Contact Information .................................................................. 7
Note: Please read entire manual before operating the LSX
www.ultratecfx.com
2
Introduction
Congratulations on your purchase of a Ultratec Special Effects LSX Low Smoke Converter. With basic care,
your LSX will provide years of trouble-free performance. The LSX is a product of many years of research and
development resulting in a machine with many ne features and exceptional reliability.
This manual contains detailed information on the operation of your LSX. Please take a few moments to read it
over carefully before use, and keep it handy for your reference.
Warning
Important Safety Instructions:
1. Do not remove the outer case.
2. Persons suffering from asthma or allergenic sensitivity may experience irritation, discomfort or allergic
symptoms when exposed to fog effects.
3. Ensure that this unit is grounded at all times. Failure to do so may result in serious injury.
4. Contains refridgeration uid.
5. Use Ultratec Special Effects uid ONLY for accompanying fog machine.
Safety Precautions
1. Ensure that any operation of the machine is supervised by suitably trained and authorized personnel.
2. Do not modify the machine or use a machine which has been damaged in any way.
3. Allow sufcient air circulation around the machine at all times.
4. Protect the machine from direct weather effects and wet locations.
5. Only use uids manufactured by Ultratec Special Effects.
6. Do not continue to produce fog when visibility is reduced to 20” 50cm or below.
7. Avoid directing fog output continuously at people, structures or objects within close proximity of the discharge
nozzle.
8. Ensure that adequate exhausting arrangements are available in the event of an emergency.
9. Do not place hands or exposed skin within the rst 20” (50 cm) of the discharge nozzle at any time during fog
production.
10. Fog effects can trigger smoke alarms and detectors. Please take suitable precautions to prevent false alarms.
11. Unit must remain upright.
12. Protect from vibration and shock while transporting.
