Ultrafryer Systems, Inc.
FM-99
Portable Filter Machine
Benefi ts:
● Fast Flow impregnated
fi lter envelope for
more effi cient fi ltration
● All stainless steel
construction
● 1/3 HP / 7.6 GPM
pump/motor
● Lightweight,
Project __________________
Item ____________________
Quantity _________________
Approval _________________
Date ____________________
FM-99 Portable Filter Machine
easy to clean
● Wash hose and nozzle
standard
● Stainless steel fi lter
scraper
(Shown with permanent stainless steel screen.)
Specifi cations
Ultrafryer® Systems presents the Ultrafilter™ — the portable filtering machine
line with the widest possible range of operator advantages. Advanced
engineering allows maximum speed and efficiency for polishing shortening
with the fast flow impregnated filter envelope for more efficient filtration and
less tub cleaning.
Ultrafryer Systems, Inc. • 302 Spencer Lane • San Antonio, TX 78201 • (800) 545-9189 • (210) 731-5000 • FAX (210) 731-5099 • www.ultrafryer.com
Page 2
OFF
ON
SLUDGE PAN
BREADING STRAINER
SLUDGE SCREEN
25
[648]
[559]
[495]
19 "
8 "
[203]
TOP VIEW
SIDE VIEW
FRONT VIEW
2
"
1
22”
1
2
Crumb Catcher
Sludge Screen
Sludge Pan
Triple Stage Filtration Option
Dimensions - inches (mm)
Model Fill Overall Size Net Shipping Info
No. Capacity Weight
FM-99
89 lbs. (50 liters)
Height Depth
25” (635 mm)
22” (558.8 mm)
Width
19.5” (495.3 mm)
75 lbs. (34 kgs)
F.O.B. Factory
San Antonio, Texas
Power Requirements: Notes:
ELECTRICAL REQUIREMENTS
120 V, 60 HZ, 1 phase,
3 prong grounded plug,
8” cord
Ultrafryer Systems, Inc. • 302 Spencer Lane • San Antonio, TX 78201 • (800) 545-9189 • (210) 731-5000 • FAX (210) 731-5099 • www.ultrafryer.com
Due to continuing engineering development and improvements, specications are subject to change without notice.
• Removable handle for
easy storage under fryer
• 6’ wash hose with nozzle
• 15” suction line hose
• casters
© January 24, 2010 Ultrafryer Systems, Inc.
OPTIONS:
• Permanent S/S Filter Screen
• Fast Flow Filter Pad
• Triple Stage Filtration
• Boil-out Drain Valve
