warranty information
Ultimate Support Systems offers a Limited Lifetime Warranty on Tour Mic Stand Series.
For Full Details, Exclusions and Limitations as well as information on Obtaining Warranty
Service, please see full warranty details available online at www.ultimatesupport.com.
To purchase the Ultimate Protection Plus Premium Service and Support Plan,
please visit www.ultimatesupport.com or call customer support at 800 - 525 - 5628
for more information.
warranty registration
Visit www.ultimatesupport.com for a quick and convenient process for registering your
new Ultimate Support product. Warranty Registration and Proof of Purchase are required for
warranty fulfi lment. Full Limited Lifetime Warranty and Ultimate Protection Plus Premium
Service and Support Plan details are available online.
Product Manual
for Ultimate Support
TOUR MIC
STAND SERIES
TOUR-T
ITEM #17191
TOUR-T-TALL
ITEM #17193
TOUR-T-SHORT
ITEM #17192
TOUR-MT
ITEM #17194
970.776.1920 . www.ultimatesupport.com . Copyright 2009, Ultimate Support Systems . All Rights Reserved
4
TOUR-LT
ITEM #17197
TOUR-RB
ITEM #17196
TOUR-T-T
ITEM #17208
TOUR-T-TALL-T
ITEM #17209
TOUR-T-SHORT-T
ITEM #17207
TOUR-RB-SHORT-T
ITEM #17110
Revision 1, 03.18.09 . Product Manual Item #TR-M
set -up fea t ur es
1 2
Legs Lock
in Place
STEP 1
Tripod Base: Fold out legs until they
are fully extended. No tightening of
nobs is necessary.
Weighted Base: Shaft screws into
weighted base.
Modular Base Design: Allows any
Tour shaft to be used with any Tour
base, tripod or weighted.
3
US Mic Lock
US
Metric
Mic Tool or
1.5 Allen Wrench
Ergonomic
Patented
Quarter-Turn
Clutch
STEP 2
Turn the ergonomic Patented QuarterTurn Clutch counter clockwise a quarter
turn. Adjust stand height up or down.
Securely retighten clutch by turning
clockwise.
4
4
Metric
MIC-Lock
US
MIC-Lock
LOCKED
LOCKED
LEG REPLACEMENT
The legs on the Tour and Pro Series Mic Stands are built to be extra durable, withstanding
the rigors of everyday use. However, if a leg should get damaged, the stand is designed to be
fi eld repairable and the legs can be replaced. Please visit www.ultimatesupport.com or call
customer support at 800-525-5628 for more details.
Same Tour Mic Shaft
THE SHAFT OF ANY TOUR STAND CAN BE USED WITH ANY TOUR BASE!
Ergonomic knobs
Universal Mic
Attachment
Ergonomic knobs
Oversized
Rotation Hub
Heavy-duty
Counter-weight
STEP 3
Universal Mic Attachment
To adjust US to metric, use tool provided or
1.5 Allen Wrench to unlock threads. Turn
US threads counter clockwise until it is
removed. US MIC-Lock will come off too.
STEP 4
After choosing desired thread, place
microphone on universal mic attachment.
Then turn MIC-Lock counter clockwise to
lock mic in place.
Universal Mic Attachment
STAND & BOOM PACKAGE MODELS:
TOUR-T-T, TOUR-T-TALL-T, TOUR-T-SHORT-T, TOUR-RB-SHORT-T
The “Ulti-boom” telescoping mic boom features an oversized “rotation hub” - the place
on a boom where everything comes together. Ultimate Support’s center hub is the largest
on the market, increasing friction, and reducing any chance of slipping. Adjust it once and
forget about it!
