LX Series Power Amplifier Assembly Chapter 1, Introduction

Chapter 1

Introduction

This manual explains the installation,
setup, alignment, and maintenance
procedures for the Power Amplifier
Assembly for the Innovator LX Series
translator. It is important that you read
all of the instructions, especially the
safety information in this chapter, before
you begin to install or operate the unit.

1.1 Manual Overview

This instruction manual is divided into
five chapters and supporting appendices.
Chapter 1, Introduction, contains
information on the assembly numbering
system used in the manual, safety,
maintenance, return procedures, and
warranties. The second chapter describes
the amplifier assembly and includes
discussions on control and status
indicators and remote control
connections. Chapter 3 explains how to
unpack, install, setup, and operate the
power amplifier assembly. Chapter 4
contains circuit-level descriptions for
boards and board-level components in
the power amplifier. Chapter 5, Detailed
Alignment Procedures, provides
information on adjusting the power
amplifier and the system for optimal
operation. The appendices contain
assembly and subassembly drawings and
parts lists and the system specifications.

1.2 Assembly Designators

Axcera has assigned assembly numbers,
such as Ax (x=1,2,3…), to all assemblies,
trays, and boards that are referenced in
the text of this manual and shown on the
block diagrams and interconnect
drawings provided in the appendices.
These supporting documents are
arranged in increasing numerical order in
the appendices. Section titles in the text
for assembly or tray descriptions or
alignment procedures contain the
associated part number(s) and the

relevant appendix that contains the
drawings for that item.

1.3 Safety

The translators and associated power
amplifier assemblies manufactured by
Axcera are designed to be easy to use
and repair while providing protection
from electrical and mechanical hazards.
Listed throughout the manual are notes,
cautions, and warnings concerning
possible safety hazards that may be
encountered while operating or servicing
the translator. Please review these
warnings and familiarize yourself with the
operation and servicing procedures
before working on the assembly.

Read All Instructions – All of the
operating and safety instructions should
be read and understood before operating
this equipment.

Retain Manuals – The manuals for the
power amplifier assembly and the
translator should be retained at the
translator site for future reference. We
provide two sets of manuals for this
purpose; one set can be left at the office
while one set can be kept at the site.

Heed all Notes, Warnings, and
Cautions – All of the notes, warnings,

and cautions listed in this safety section
and throughout the manual must be
followed.

Follow Instructions – All of the
operating and use instructions for the
amplifier assembly should be followed.

Cleaning – Unplug or otherwise
disconnect all power from the equipment
before cleaning. Do not use liquid or
aerosol cleaners. Use a damp cloth for
cleaning.

LX Series, Rev. 0 1-1

LX Series Power Amplifier Assembly Chapter 1, Introduction

Ventilation – Openings in the cabinets
and modules front panels are provided
for ventilation. To ensure the reliable
operation of the amplifier assembly, and
to protect the unit from overheating,
these openings must not be blocked.

Servicing – Do not attempt to service
this product yourself until becoming
familiar with the equipment. If in doubt,
refer all servicing questions to qualified
Axcera service personnel.

Replacement Parts – When
replacement parts are used, be sure that
the parts have the same functional and
performance characteristics as the
original part. Unauthorized substitutions
may result in fire, electric shock, or other
hazards. Please contact the Axcera
Technical Service Department if you have
any questions regarding service or
replacement parts.

1.4 Maintenance

The LX Series Translator is designed with
components that require little or no
periodic maintenance except for the
routine cleaning of the fans and the front
panels of the modules.

The amount of time between cleanings
depends on the conditions within the
translator room. While the electronics
have been designed to function even if
covered with dust, a heavy buildup of
dust, dirt, or insects will affect the
cooling of the components. This could
lead to a thermal shutdown or the
premature failure of the affected
modules.

When the front panels of the modules
become dust covered, the top covers
should be taken off and any accumulated
foreign material should be removed. A
vacuum cleaner, utilizing a small, wand­type attachment, is an excellent way to
suction out the dirt. Alcohol and other
cleaning agents should not be used
unless you are certain that the solvents
will not damage components or the silk-

screened markings on the modules and
boards. Water-based cleaners can be
used, but do not saturate the
components. The fans and heatsinks
should be cleaned of all dust or dirt to
permit the free flow of air for cooling
purposes.

It is recommended that the operating
parameters of the amplifier assembly and
translator be recorded from the LEDs on
the modules and the LCD system
metering on the control/monitoring
module at least once a month. It is
suggested that this data be retained in a
rugged folder or envelope.

1.5 Material Return Procedure

To insure the efficient handling of
equipment or components that have been
returned for repair, Axcera requests that
each returned item be accompanied by a
Material Return Authorization Number
(MRA#).

An MRA# can be obtained from any
Axcera Field Service Engineer by
contacting the Axcera Field Service
Department at [phone] or by fax
at [phone]. This procedure
applies to all items sent to the Field
Service Department regardless of
whether the item was originally
manufactured by Axcera.

When equipment is sent to the field on
loan, an MRA# is included with the unit.
The MRA# is intended to be used when
the unit is returned to Axcera. In
addition, all shipping material should be
retained for the return of the unit to
Axcera.

Replacement assemblies are also sent
with an MRA# to allow for the proper
routing of the exchanged hardware.
Failure to close out this type of MRA# will
normally result in the customer being
invoiced for the value of the loaner item
or the exchange assembly.

LX Series, Rev. 0 1-2

LX Series Power Amplifier Assembly Chapter 1, Introduction

When shipping an item to Axcera, please
include the MRA# on the packing list and
on the shipping container. The packing
slip should also include contact
information and a brief description of why
the unit is being returned.

Please forward all MRA items to:

AXCERA, LLC
103 Freedom Drive
P.O. Box 525
Lawrence, PA 15055-0525 USA

For more information concerning this
procedure, call the Axcera Field Service
Department.

Axcera can also be contacted through e­mail at [e-mail] and on the
Web at www.axcera.com.

1.6 Limited One-Year Warranty for
Axcera Products

Axcera warrants each new product that
it has manufactured and sold against
defects in material and workmanship
under normal use and service for a
period of one (1) year from the date of
shipment from Axcera's plant, when
operated in accordance with Axcera's
operating instructions. This warranty
shall not apply to tubes, fuses,
batteries, or bulbs.

Warranties are valid only when and if
(a) Axcera receives prompt written
notice of breach within the period of

warranty, (b) the defective product is
properly packed and returned by the
buyer (transportation and insurance
prepaid), and (c) Axcera determines, in
its sole judgment, that the product is
defective and not subject to any misuse,
neglect, improper installation,
negligence, accident, or (unless
authorized in writing by Axcera) repair
or alteration. Axcera's exclusive liability
for any personal and/or property
damage (including direct, consequential,
or incidental) caused by the breach of
any or all warranties, shall be limited to
the following: (a) repairing or replacing
(in Axcera's sole discretion) any
defective parts free of charge (F.O.B.
Axcera’s plant) and/or (b) crediting (in
Axcera's sole discretion) all or a portion
of the purchase price to the buyer.

Equipment furnished by Axcera, but not
bearing its trade name, shall bear no
warranties other than the special hours­of-use or other warranties extended by
or enforceable against the manufacturer
at the time of delivery to the buyer.

NO WARRANTIES, WHETHER
STATUTORY, EXPRESSED, OR
IMPLIED, AND NO WARRANTIES OF
MERCHANTABILITY, FITNESS FOR
ANY PARTICULAR PURPOSE, OR
FREEDOM FROM INFRINGEMENT,
OR THE LIKE, OTHER THAN AS
SPECIFIED IN PATENT LIABILITY
ARTICLES, AND IN THIS ARTICLE,
SHALL APPLY TO THE EQUIPMENT
FURNISHED HEREUNDER.
