u blox WIBEAR11N-SF2, WIBEAR11N-DF2 User Manual

WiBear11n
IEEE 802.11a/b/g/n WLAN, Bluetooth 3.0+EDR Module
Data Sheet
Version 1.18
December 2013
The information in this document is subject to change without notice. Please download latest version from www.lesswire.com
Copyright © 2013 lesswire AG
www.lesswire.com
Introduction
The WiBear11n industrial universal module is targeted for integration into different OEM products. The module is designed for both simultaneous and independent operation of the following:
IEEE 802.11a/b/g/n payload data rates for Wireless Local Area Network (WLAN), Bluetooth 3.0+High Speed (HS) and Bluetooth 2.1+EDR.
It provides a complete end-to-end solution for low­power applications. It includes an integrated MAC/Baseband processor and RF front-end components and can connect to a host processor through an SDIO interface.
The WiBear11n modules are offered in four versions (see ordering information and block diagram).
Host drivers for common operating systems such as Linux and Windows 7 are available.
The modules are radio type approved for Europe (CE), US (FCC) and Industry Canada (IC) (pending).
Applications
WiBear11n Data Sheet
Figure 1: Physical outlook
Version 1.18
WLAN and Bluetooth networks  Audio/video devices and accessories  Access to laptops, mobile phones etc.  Automotive and industrial networking  Home / building automation
Key Features
Standards: IEEE 802.11a/b/g/n/e/i/h/d/k/r/w  WLAN 802.11a/b/g/n station and micro access point operation (up to 8 clients supported)  Support of Wi-Fi direct mode  802.11n 1x1 SISO  802.11 PHY data rates up to 72 Mbps (20 MHz channel) and up to 150 Mbps (40 MHz channel)  Hardware 64- and 128-bit encryption AES engine performance  Embedded security supplicant  WAPI encryption is supported by hardware  Background scan mode  Bluetooth 3.0 + HS (High Speed)  Bluetooth 2.1 + EDR (backward compatibility)  Wide temperature operation range -40ºC to +85ºC  Compact 14.8mm x 14.8mm footprint, surface mounting  SDIO high-speed interface  Support for low-power modes  CE/FCC/IC compliant  RoHS compliant  Automotive qualification tests (climatic, mechanical, and operating life tests) according to VW 80000 /
ISO 16750-4 (report pending)
Copyright © 2013 lesswire AG
www.lesswire.com
Page 2 of 20
WiBear11n Data Sheet
Ordering Information
Table 1: Ordering information
Order Number Model Description
AN00J93170 WiBear11n-SF1 WiBear-SF1 Module AN00J93174 WiBear11n-SF2 WiBear-SF2 Module AN00J93172 WiBear11n-DF1 WiBear-DF1 Module AN00J93176 WiBear11n-DF2 WiBear-DF2 Module AN00J94359 WiBear11n-SF1 WiBear-SF1 Module, tape&reel package (500 pcs) AN00J94361 WiBear11n-SF2 WiBear-SF2 Module, tape&reel package (500 pcs) AN00J94360 WiBear11n-DF1 WiBear-DF1 Module, tape&reel package (500 pcs) AN00J94362 WiBear11n-DF2 WiBear-DF2 Module, tape&reel package (500 pcs) AN00J93704 WiBear11n-DF1_EK Evaluation Kit with WiBear11n-DF1 Module AN00J93705 WiBear11n-DF2_EK Evaluation Kit with WiBear11n-DF2 Module
Note: Shielded modules available on special request.
IMDS number: 355902511
Customs Tariff Numbers:
HTC / TARIC: 85177090 ECCN number: 3A001 EORI no.: DE4665759
Version 1.18
Product Variants
Table 2: Product variants
Model Description
WiBear11n-SF1 Single band WLAN (802.11 b/g/n, 2.4 GHz only) and Bluetooth module. Module has one
joint antenna connector for WLAN and Bluetooth operation (see block diagram). WiBear11n-SF1/-DF1 is recommended for cost effective AP solution, AP without or rare Bluetooth traffic or cost effective station with one system antenna.
WiBear11n-SF2 Single band WLAN (802.11 b/g/n, 2.5 GHz only) and Bluetooth module. Module has
separated antenna connectors for WLAN and Bluetooth operation (see block diagram). Overall performance (throughput) is maximized for AP mode with simultaneous Bluetooth traffic. Two system antennas are required (one for WLAN and one for Bluetooth) with 30 dB or better isolation between antennas (orthogonal oriented antennas with more than 50…60 mm. distance between). May be recommended for higher performance of AP.
WiBear11n-DF1 Dual band WLAN (802.11 a/b/g/n, 2.5 and 5 GHz) and Bluetooth module with one joint
antenna connector for WLAN and Bluetooth. Similar to WiBear11n-SF1.
WiBear11n-DF2 Dual band WLAN (802.11 a/b/g/n, 2.5 and 5 GHz) and Bluetooth module which has
separated antenna connectors for WLAN and Bluetooth. Similar to WiBear11n-SF2.
Note: For maximum throughput during simultaneous WLAN (AP) and Bluetooth operation, the Bluetooth Coexistence Arbiter (BCA) settings should be optimized by the host system software.
Copyright © 2013 lesswire AG
www.lesswire.com
Page 3 of 20
Block Diagrams
WiBear11n-SF1
SDIO
GPIOs
RESETn
PDn
SLEEP
CLOCK
3.3V
1.8V
VIO
WiBear11n-SF2
SDIO
GPIOs
RESETn
PDn
SLEEP
CLOCK
3.3V
1.8V
VIO
38.4 MHz
Crystal
802.11b/g/n MAC/BB/RADIO
38.4 MHz
Crystal
802.11b/g/n MAC/BB/RADIO BLUETOOTH 3.0+HS
EEPROM
Figure 2: Block diagram of WiBear11n-SF1
BLUETOOTH 3.0+HS
EEPROM
Figure 3: Block diagram of WiBear11n-SF2
2.5GHz WLAN TX
2.5GHz WLAN/BT RX
BT TX
2.5GHz WLAN TX
2.5GHz WLAN RX
2.4 GHz
RF FRONT
END
2.4 GHz
RF FRONT
END
BT TX/RX
WiBear11n Data Sheet
2.5GHz
2.4GHz BPF
WiBear11n-SF1
2.5GHz
2.4GHz BPF
2.4GHz BPF
WiBear11n-SF2
Version 1.18
WLAN & BT ANT
WLAN ANT
BT ANT
Copyright © 2013 lesswire AG
www.lesswire.com
Page 4 of 20
WiBear11n-DF1
SDIO
GPIOs
RESETn
PDn
SLEEP
CLOCK
3.3V
1.8V
VIO
WiBear11n-DF2
SDIO
GPIOs
RESETn
PDn
SLEEP
CLOCK
3.3V
1.8V
VIO
802.11a/b/g/n MAC/BB/RADIO BLUETOOTH 3.0+HS
38.4 MHz
EEPROM
Crystal
Figure 4: Block diagram of WiBear11n-DF1
802.11a/b/g/n MAC/BB/RADIO BLUETOOTH 3.0+HS
38.4 MHz
EEPROM
Crystal
Figure 5: Block diagram of WiBear11n-DF2
5GHz WLAN TX
5GHz WLAN RX
2.5GHz WLAN TX
2.5GHz WLAN/BT RX
BT TX
5GHz WLAN TX
5GHz WLAN RX
2.5GHz WLAN TX
2.5GHz WLAN RX
5 GHz
RF FRONT
END
2.4 GHz
RF FRONT
END
5 GHz
RF FRONT
END
2.4 GHz
RF FRONT
END
BT TX/RX
WiBear11n Data Sheet
5GHz BPF
5GHz
&
DIPLEXER
2.5GHz
2.4GHz BPF
WiBear11n-DF1
5GHz BPF
5GHz
&
DIPLEXER
2.5GHz
2.4GHz BPF
2.4GHz BPF
WiBear11n-DF2
Version 1.18
WLAN &
BT ANT
WLAN ANT
BT ANT
Copyright © 2013 lesswire AG
www.lesswire.com
Page 5 of 20
Pin Description
Table 3: Pin description
1 2 3 4 5 6 7 8
GND LED_0 LED_1 3V3 VIO 1V8 GND GND
30
29
28
27
GND
GND
GND
ANT1
PCM_DOUT
SLEEP_CLK
PDn
RESETn
SD_D2
SD_D3
SD_CMD
SD_CLK
SD_D0
9
10
11
Figure 6: Module pinout
14
12
15
13
26
25
GND
ANT2
PCM_DIN
PCM_CLK
PCM_SYNC
CFG
GND GND
SD_D1
16
WiBear11n Data Sheet
Version 1.18
24 23 22 21 20 19 18 17
Pin No.
Pin Name Pin Type Description
1 GND Ground Ground 2 LED_0 I/O LED output (GPIO_1 of Radio/Baseband processor), WLAN activity 1 3 LED_1 I/O LED output (GPIO_17 of Radio/Baseband processor), Bluetooth activity 1 4 3V3 Power 3.3V Power supply (3.0V...3.6V) 5 VIO Power VIO Supply (1.8V or 3.3V) 6 1V8 Power 1.8V Supply (1.7V...1.9V) 7 GND Ground Ground 8 GND Ground Ground 9 PDn I Full power down (active low), has internal pull-up to VIO pin 10 RESETn I Reset (active low), has weak internal pull-up to VIO pin 11 SD_D2 I/O SDIO Data line bit [2] 12 SD_D3 I/O SDIO Data line bit [3] 13 SD_CMD I/O SDIO Command 14 SD_CLK I SDIO Clock input 15 SD_D0 I/O SDIO Data line bit [0] 16 SD_D1 I/O SDIO Data line bit [1] 17 GND Ground Ground 18 GND Ground Ground 19 SLEEP_CLK I Clock input for external sleep clock source (32.768kHz) 2 20 CFG I/O Configuration pin 3 21 PCM_SYNC I/O GPIO_14 of Radio/Baseband processor, output if master, input if slave 22 PCM_CLK I/O GPIO_13 of Radio/Baseband processor, output if master, input if slave 23 PCM_DOUT O GPIO_12 of Radio/Baseband processor, output 24 PCM_DIN I GPIO_11 of Radio/Baseband processor, input 25 GND Ground Ground
Copyright © 2013 lesswire AG
www.lesswire.com
Page 6 of 20
