Abstract
Technical data sheet describing TOBY-L4 series cellular modules. The modules are a complete and
cost efficient LTE-FDD, LTE-TDD, DC-HSPA+, (E)GPRS multi-mode and multi-band solution with
uCPU embedded Linux programming capability. The modules offer up to 301.5 Mb/s download and
up to 51.0 Mb/s upload data rates with Category 6 LTE-Advanced carrier aggregation technology in
the compact TOBY form factor.
TOBY-L4 series
LTE Advanced (Cat 6) modules with 3G and 2G fallback
Data sheet
UBX-16009856 - R09 C1-Public www.u-blox.com
TOBY-L4 series - Data sheet
Title
TOBY-L4 series
Subtitle
LTE Advanced (Cat 6) modules with 3G and 2G fallback
Document type
Data sheet
Document number
UBX-16009856
Revision and date
R09
30-Jul-2020
Disclosure restriction
C1-Public
Product status
Corresponding content status
Functional sample
Draft
For functional testing. Revised and supplementary data will be published later.
In development /
prototype
Objective specification
Target values. Revised and supplementary data will be published later.
Engineering sample
Advance information
Data based on early testing. Revised and supplementary data will be published later.
Initial production
Early production information
Data from product verification. Revised and supplementary data may be published later.
Mass production /
End of life
Production information
Document contains the final product specification.
Product name
Type number
Modem version
Application version
PCN reference
Product status
TOBY-L4006
TOBY-L4006-01A-00
40.35
A10.21
UBX-20032733
Engineering sample
TOBY-L4006-51A-00
40.35
A00.21
UBX-20032733
Engineering sample
TOBY-L4106
TOBY-L4106-01A-00
40.35
A10.21
UBX-20032733
Engineering sample
TOBY-L4106-51A-00
40.35
A00.21
UBX-20032733
Engineering sample
TOBY-L4206
TOBY-L4206-01A-00
40.35
A10.21
UBX-20032733
Engineering sample
TOBY-L4206-51A-00
40.35
A00.21
UBX-20032733
Engineering sample
TOBY-L4906
TOBY-L4906-01A-00
40.35
A10.21
UBX-20032733
Engineering sample
TOBY-L4906-50A-01
40.25
A00.17
UBX-18069505
End of life
TOBY-L4906-50A-02
40.35
A05.25
UBX-20026425
Initial production
TOBY-L4906-51A-00
40.35
A00.21
UBX-20032733
Engineering sample
u-blox or third parties may hold intellectual property rights in the products, names, logos and designs included in this document.
Copying, reproduction, modification or disclosure to third parties of this document or any part thereof is only permitted with the
express written permission of u-blox.
The information contained herein is provided “as is” and u-blox assumes no liability for its use. No warranty, either express or
implied, is given, including but not limited to, with respect to the accuracy, correctness, reliability and fitness for a particular
purpose of the information. This document may be revised by u-blox at any time without notice. For the most recent documents,
visit www.u-blox.com.
Copyright © u-blox AG.
Document information
This document applies to the following products:
UBX-16009856 - R09 Document information Page 2 of 58
C1-Public
TOBY-L4 series - Data sheet
Contents
Document information ................................................................................................................................ 2
Contents .......................................................................................................................................................... 3
1 Functional description ......................................................................................................................... 5
1.1 Overview ........................................................................................................................................................ 5
1.2 Product features ......................................................................................................................................... 6
1.3 Block diagram .............................................................................................................................................. 7
1.4 Product description .................................................................................................................................... 8
1.5 AT command support ................................................................................................................................ 9
1.6 u-blox uCPU on-chip processor for OEM applications ......................................................................... 9
2 Interfaces ............................................................................................................................................... 10
2.1 Power management ................................................................................................................................. 10
2.1.1 Module supply input (VCC) ............................................................................................................. 10
2.1.2 RTC supply input / output (V_BCKP) ............................................................................................ 10
2.1.3 Generic digital interfaces supply output (V_INT) ....................................................................... 10
2.2 Antenna interfaces ................................................................................................................................... 10
2.2.1 Antenna RF interfaces ..................................................................................................................... 10
2.2.2 Antenna detection ............................................................................................................................ 10
2.3 System functions ...................................................................................................................................... 10
2.3.1 Module power-on .............................................................................................................................. 10
2.3.2 Module power-off ............................................................................................................................... 11
2.3.3 Module reset ....................................................................................................................................... 11
2.3.4 Module configuration selection by host processor ..................................................................... 11
2.4 SIM ................................................................................................................................................................12
2.4.1 SIM interfaces ....................................................................................................................................12
2.4.2 SIM detection .....................................................................................................................................12
2.5 Serial communication ...............................................................................................................................12
2.5.1 USB interface ..................................................................................................................................... 13
2.5.2 UART interfaces ................................................................................................................................ 14
2.5.3 SPI interfaces .................................................................................................................................... 15
2.5.4 DDC (I2C) interfaces ......................................................................................................................... 16
2.5.5 SDIO interface ................................................................................................................................... 16
2.5.6 RGMII interface .................................................................................................................................. 17
2.6 eMMC interface .......................................................................................................................................... 17
2.7 Audio interfaces ........................................................................................................................................ 18
2.8 ADC interfaces ........................................................................................................................................... 19
2.9 GPIO interfaces .......................................................................................................................................... 19
2.10 RSVD pins ................................................................................................................................................... 20
3 Pin definition ......................................................................................................................................... 21
3.1 Pin assignment ...........................................................................................................................................21
4 Electrical specifications ....................................................................................................................29
UBX-16009856 - R09 Contents Page 3 of 58
C1-Public
TOBY-L4 series - Data sheet
4.1 Absolute maximum rating....................................................................................................................... 29
4.1.1 Maximum ESD ................................................................................................................................... 29
4.2 Operating conditions ................................................................................................................................30
4.2.1 Operating temperature range ........................................................................................................30
4.2.2 Module thermal parameters ...........................................................................................................30
4.2.3 Supply/power pins ............................................................................................................................ 31
4.2.4 Current consumption ....................................................................................................................... 32
4.2.5 LTE RF characteristics .................................................................................................................... 33
4.2.6 3G RF characteristics ...................................................................................................................... 36
4.2.7 2G RF characteristics ...................................................................................................................... 37
4.2.8 PWR_ON pin ....................................................................................................................................... 38
4.2.9 RESET_N pin ...................................................................................................................................... 38
4.2.10 SIM pins .............................................................................................................................................. 39
4.2.11 USB pins ............................................................................................................................................. 39
4.2.12 DDC (I2C) pins .................................................................................................................................... 40
4.2.13 RGMII pins .......................................................................................................................................... 40
4.2.14 eMMC pins ......................................................................................................................................... 41
4.2.15 Generic digital interfaces pins ....................................................................................................... 41
4.2.16 Analog audio pins .............................................................................................................................. 44
4.2.17 ADC pins ............................................................................................................................................. 44
5 Mechanical specifications ............................................................................................................... 45
6 Qualification and approvals.............................................................................................................. 47
6.1 Reliability tests .......................................................................................................................................... 47
6.2 Approvals .................................................................................................................................................... 47
7 Product handling & soldering .......................................................................................................... 48
7.1 Packaging ................................................................................................................................................... 48
7.1.1 Reels .................................................................................................................................................... 48
7.1.2 Tapes ................................................................................................................................................... 49
7.2 Moisture sensitivity levels .......................................................................................................................50
7.3 Reflow soldering ........................................................................................................................................50
7.4 ESD precautions ........................................................................................................................................50
8 Labeling and ordering information ................................................................................................ 51
8.1 Product labeling ......................................................................................................................................... 51
8.2 Explanation of codes ................................................................................................................................ 51
8.3 Ordering information ................................................................................................................................ 52
Appendix ....................................................................................................................................................... 53
A Glossary ................................................................................................................................................. 53
Related documents ................................................................................................................................... 55
Revision history .......................................................................................................................................... 56
Contact .......................................................................................................................................................... 58
UBX-16009856 - R09 Contents Page 4 of 58
C1-Public
TOBY-L4 series - Data sheet
1
1 Functional description
1.1 Overview
The TOBY-L4 series modules support multi-band LTE-FDD, LTE-TDD, DC-HSPA+ and (E)GPRS radio
access technologies (see Table 1) in the very small TOBY 248-pin LGA form factor (35.6 x 24.8 mm),
which is easy to integrate in compact designs.
TOBY-L4 series modules are form factor compatible with the other u-blox cellular module families
(including SARA, LISA, LARA, and TOBY form factors): this allows customers to take the maximum
advantage of their hardware and software investments, and provides very short time-to-market.
With LTE-Advanced carrier aggregation category 6 data rates up to 301.5 Mb/s (downlink) / 51.0 Mb/s
(uplink), the modules are ideal for applications requiring the highest data-rates and high-speed
internet access. Reduced cost variants supporting LTE Cat 4 or LTE Cat 1 will be available for lower
speed or “pure” telematics devices.
TOBY-L4 series include the following LTE Cat 6 modules with 3G and 2G fallback:
TOBY-L4006 modules, mainly designed for operation in North America
TOBY-L4106 modules, mainly designed for operation in Europe
TOBY-L4206 modules, mainly designed for operation in Asia-Pacific and South America
TOBY-L4906 modules, mainly designed for operation in China
TOBY-L4 series modules include the following product versions:
The "01" product versions, or "smart modem" product versions, which allow customers to run their
own dedicated applications on an embedded Linux distribution based on Yocto, with RILCore
connectivity APIs in the u-blox uCPU on-chip processor 1
The "50" and the "51" product versions, or "slim modem" product versions, which can be controlled
by an external application processor through standard and u-blox proprietary AT commands
described in the u-blox AT commands manual [1]
TOBY-L4 series modules are the ideal product for the development of all kinds of automotive devices,
such as smart antennas and in-dash telematics / infotainment devices. The modules support a
comprehensive set of HW interfaces (including RGMII for Ethernet and analog audio) over an extended
temperature range that allows the establishment of an emergency call up to +95 °C, and
complemented by a set of state-of-the art security features.
TOBY-L4 series modules are also the perfect choice for consumer fixed-wireless terminals, mobile
routers and gateways, applications requiring video streaming, and many other industrial (M2M)
applications.
TOBY-L4 series modules are manufactured in ISO/TS 16949 certified sites, with the highest
production standards and the highest quality and reliability. Each module is fully tested and inspected
during production. Modules are qualified according to automotive requirements as for systems
installed in vehicles.
By default, the "01" product version modules are shipped by u-blox with the "slim modem" firmware, and consequently these
modules behave as the "51" product version unless the factory-programmed firmware is replaced by the uCPU firmware build.
In this document, the "01" product version is described as it behaves with the uCPU firmware build, as it is delivered by u-blox,
without any modifications.
UBX-16009856 - R09 Functional description Page 5 of 58
C1-Public
TOBY-L4 series - Data sheet
Model
Region
Bands
Interfaces
Features
Grade
supervisor
TOBY-L4006-01
North
America
2,4,5
7,12
13,29
2
4,5
850
1900
4 1 1 2 1 1 1 2 2
14
2
● ● ● ● ● ● ● ● ● ● ● ● ●
●
TOBY-L4006-51
North
America
2,4,5
7,12
13,29
2
4,5
850
1900
1 1 1 1 2 9
● ● ●
●
●
●
●
●
TOBY-L4106-01
EMEA
1,3
7,8
20
38
1,8
900
1800
4 1 1 2 1 1 1 2 2
14
2
● ● ● ● ● ● ● ● ● ● ● ● ●
●
TOBY-L4106-51
EMEA
1,3
7,8
20
38
1,8
900
1800
1 1 1 1 2 9
● ● ●
●
● ● ●
●
TOBY-L4206-01
APAC,
South
America
1,3,5
7,8,9
19,28
1,5,6
8,19
Quad 4 1 1 2 1 1 1 2 2 14 2 ● ● ● ● ● ● ● ● ● ● ● ● ●
●
TOBY-L4206-51
APAC,
South
America
1,3,5
7,8,9
19,28
1,5,6
8,19
Quad 1 1 1 1 2 9
● ● ●
●
● ● ●
●
TOBY-L4906-01
China
1,3
39
40,41
1,8
900
1800
4 1 1 2 1 1 1 2 2
14 2 ● ● ● ● ● ● ● ● ● ● ● ● ●
●
TOBY-L4906-50
China
1,3
39
40,41
1,8
900
1800
1 1 2 9
● ● ●
●
●
●
●
●
TOBY-L4906-51
China
1,3
39
40,41
1,8
900
1800
1 1 1 1 2 9
● ● ●
●
●
●
●
●
* USB 2.0 host role not supported by "50" and "51" product versions
** USB 3.0 interface supported by future firmware versions
1.2 Product features
Table 1: TOBY-L4 series main features summary
UBX-16009856 - R09 Functional description Page 6 of 58
C1-Public
TOBY-L4 series - Data sheet
Cellular
Base-band
Processor
Memory
Power Management Unit
26 MHz
32.768 kHz
ANT
1
RF
Transceiver
ANT
2
V_INT (I/O)
V_BCKP (RTC)
VCC (Supply)
2 x SIM
USB 2.0 / 3.0
2 x ADC
Power on
External reset
PAs
LNAsFilters
Filter
s
Duplexer
Filters
PAs
LNAsFilter
s
Filter
s
Duplexer
Filters
LNAsFilter
s
Filters
LNAsFiltersFilter
s
Switch
Switch
2 x DDC (I2C)
SDIO
4 x UART
Analog audio
Antenna detection
Host Select
2 x SPI
RGMII
eMCC
2 x Digital audio (I2S)
GPIOs
1.3 Block diagram
Figure 1: TOBY-L4 series block diagram
☞ TOBY-L4 series modules "01" product versions do not support the following interfaces, which
☞ TOBY-L4 series modules "50" product versions do not support the following interfaces, which
☞ TOBY-L4 series modules "51" product versions do not support the following interfaces, which
should be left unconnected and should not be driven by external devices:
o USB 3.0 interface
o Second digital audio interface (I2S1)
should be left unconnected and should not be driven by external devices:
o USB 3.0 interface
o 4 x UART interfaces
o 2 x SPI interfaces
o SDIO interface
o 2 x DDC (I2C) interfaces
o RGMII / RMII interface
o eMMC interface
o Second digital audio interface (I2S1)
o ADC pins
o Host Select pins
should be left unconnected and should not be driven by external devices:
o USB 3.0 interface
o 4 x UART interfaces
o 2 x SPI interfaces
o SDIO interface
o Second DDC (I2C) interface
o eMMC interface
o Second digital audio interface (I2S1)
o ADC pins
o Host Select pins
UBX-16009856 - R09 Functional description Page 7 of 58
C1-Public
TOBY-L4 series - Data sheet
LTE
3G
2G
LTE-Advanced Carrier Aggregation
Frequency Division Duplex (LTE FDD)
Time Division Duplex (LTE TDD)
Down-Link CA / MIMO / Rx diversity
Dual-Cell High Speed Packet Access
Frequency Division Duplex (UMTS FDD)
Down-Link Rx diversity
Enhanced Data rate GSM Evolution (EDGE)
Time Division Multiple Access (TDMA)
DL Advanced Rx Performance Phase 1
LTE FDD Power Class
Class 3 (23 dBm)
LTE TDD Power Class
Class 3 (23 dBm)
UMTS FDD Power Class
Class 3 (24 dBm)
GMSK Power Class
Class 4 (33 dBm) for GSM/E-GSM bands
Class 1 (30 dBm) for DCS/PCS bands
8-PSK Power Class
Class E2 (27 dBm) for GSM/E-GSM bands
Class E2 (26 dBm) for DCS/PCS bands
LTE category 6:
up to 301.5 Mb/s DL
up to 51.0 Mb/s UL
FDD UE categories:
DL cat.24, up to 42.2 Mb/s
UL cat.6, up to 5.76 Mb/s
GPRS multi-slot class 33, CS1-CS4:
up to 107.0 kbit/s DL
up to 85.6 kbit/s UL
EDGE multi-slot class 33, MCS1-MCS9
up to 296.0 kbit/s DL
up to 236.8 kbit/s UL
Module
Region
LTE FDD bands
LTE TDD bands
LTE CA
UMTS FDD bands
GSM bands
TOBY-L4006
North America
12 (700 MHz)
29 (700 MHz)
13 (750 MHz)
5 (850 MHz)
4 (1700 MHz)
2 (1900 MHz)
7 (2600 MHz)
4 + 12
2 + 13
2 + 12
2 + 29
4 + 5
4 + 4
4 + 13
4 + 29
5 (850 MHz)
4 (1700 MHz)
2 (1900 MHz)
GSM 850
PCS 1900
TOBY-L4106
EMEA, APAC
20 (800 MHz)
8 (900 MHz)
3 (1800 MHz)
1 (2100 MHz)
7 (2600 MHz)
38 (2600 MHz)
3 + 20
7 + 20
3 + 3
3 + 7
8 (900 MHz)
1 (2100 MHz)
E-GSM 900
DCS 1800
TOBY-L4206
APAC,
South America
28 (750 MHz)
19 (850 MHz)
5 (850 MHz)
8 (900 MHz)
9 (1800 MHz)
3 (1800 MHz)
1 (2100 MHz)
7 (2600 MHz)
3 + 28
3 + 7
7 + 28
3 + 3
1 + 8
3 + 19
1 + 19
6 (800 MHz)
19 (800 MHz)
5 (850 MHz)
8 (900 MHz)
1 (2100 MHz)
GSM 850
E-GSM 900
DCS 1800
PCS 1900
TOBY-L4906
China
3 (1800 MHz)
1 (2100 MHz)
39 (1900 MHz)
40 (2300 MHz)
41 (2500 MHz)
3 + 3
40 + 40
41 + 41
39 + 41
8 (900 MHz)2
1 (2100 MHz)
E-GSM 900
DCS 1800
2
1.4 Product description
TOBY-L4 series modules provide multi-band 4G / 3G / 2G multi-mode radio access technologies, based
on the 3GPP Release 10 protocol stack, with main characteristics summarized in Table 2 and Table 3.
Table 2: TOBY-L4 series LTE, 3G and 2G main characteristics summary
Table 3: TOBY-L4 series supported Bands and Carrier Aggregation combinations summary
Down-Link Rx diversity not supported on this band
UBX-16009856 - R09 Functional description Page 8 of 58
C1-Public
TOBY-L4 series - Data sheet
Virtual Machine Manager (VM)
On-Chip Peripherals
MODEM VM
• LTE, UMTS, GSM
Protocol Stack
• VoLTE, IMS
Multi-core CPU
Drivers
Security VM
Drivers
• SHA encryption IMS
• Secure boot
• Secure file system
• HSM
• Certificates
• Encryption
• Decryption
• Acceleration
OEM VM
Drivers
• Yocto/Linux BSP
• Customer Application
• u-blox AT commands
• Wi-Fi and GNSS drivers
• Audio, eCall
1.5 AT command support
☞ The TOBY-L4 series modules "01" product versions are intended to be controlled by means of uCPU
programming rather than by AT commands, which are only partially supported.
TOBY-L4 series modules support the standard AT commands according to the 3GPP specifications
TS 27.007 [4], TS 27.005 [5], and u-blox proprietary AT commands.
For the complete list of all supported AT commands and their syntax, see the u-blox AT commands
manual [1].
1.6 u-blox uCPU on-chip processor for OEM applications
☞ The u-blox uCPU on-chip processor for OEM applications is not supported by "50" and "51" product
versions.
The TOBY-L4 series modules "01" product versions integrate the u-blox uCPU on-chip processor,
based on a powerful quad-core CPU, to allow customers to run their dedicated applications on an
embedded Linux distribution based on Yocto, with RIL-Core connectivity APIs.
The Hardware Virtual Machine Manager is implemented for low latency, fault tolerance, security and
protection, providing hardware virtualization between the modem and application systems, including
a dedicated virtual machine for security management (see Figure 2).
Figure 2: TOBY-L4 series SW architecture
Full separation between the modem, security and application virtual machines is implemented, with
the latest Yocto available for customers with full access to the HW and Kernel (Yocto BSP).
Advanced security implementation is available, with
Secure boot and secure update
Crypto HW accelerator / true random number generator
Secure debugging
Secure file system
Secure services provided by dedicated security Virtual Machine / trusted execution environment
For more information regarding u-blox uCPU architecture and OEM applications development, please
contact the u-blox office or sales representative nearest you (for complete contact information, visit
us at www.u-blox.com).
UBX-16009856 - R09 Functional description Page 9 of 58
C1-Public
TOBY-L4 series - Data sheet
2 Interfaces
2.1 Power management
2.1.1 Module supply input (VCC)
TOBY-L4 series modules must be supplied through the VCC pins by a DC power supply. Voltage must
be stable, because the current drawn from VCC can vary significantly during operation, based on the
power consumption profile of the LTE/3G/2G technologies (described in the TOBY-L4 series system
integration manual [2]).
2.1.2 RTC supply input / output (V_BCKP)
When the VCC voltage is within the valid operating range, the internal Power Management Unit (PMU)
supplies the Real Time Clock (RTC) through the rail available at the V_BCKP pin. If the VCC voltage is
under the minimum operating limit (e.g. during not powered mode), the RTC can be externally supplied
through the V_BCKP pin.
2.1.3 Generic digital interfaces supply output (V_INT)
TOBY-L4 series modules provide a 1.8 V supply rail output on the V_INT pin, which is internally
generated when the module is switched on. The same voltage domain is used internally to supply the
generic digital interfaces of the modules. The V_INT supply output can be used in place of an external
discrete regulator.
2.2 Antenna interfaces
2.2.1 Antenna RF interfaces
The modules have two RF pins with a characteristic impedance of 50 . The primary antenna pin
(ANT1) supports both Tx and Rx, providing the main antenna interface, while the secondary antenna
pin (ANT2) supports Rx only for Carrier Aggregation (CA), Multiple-Input Multiple Output (MIMO) and
Rx diversity.
2.2.2 Antenna detection
The ANT_DET pin is an Analog to Digital Converter (ADC) input with a current source provided by the
TOBY-L4 modules to sense the antenna presence (as an optional feature). It evaluates the resistance
from the ANT1 and ANT2 pins to GND by means of an external antenna detection circuit implemented
on the application board. For more details, see the TOBY-L4 series system integration manual [2].
2.3 System functions
2.3.1 Module power-on
TOBY-L4 series can be switched on in the following way:
Low pulse on the PWR_ON pin, which is normally set high by an internal pull-up, for a valid time
period when the applied VCC voltage is within the valid operating range (see section 4.2.8, module
switch-on). The PWR_ON line should be driven by an open drain, open collector or contact switch.
UBX-16009856 - R09 Interfaces Page 10 of 58
C1-Public
TOBY-L4 series - Data sheet
3
4
3
4
2.3.2 Module power-off
TOBY-L4 series can be properly switched off, saving current parameter settings in the module’s nonvolatile memory and performing a proper network detach, by:
+CPWROFF AT command
poweroff command on the Linux shell
Low pulse on the PWR_ON pin, which is normally set high by an internal pull-up, for a valid time
period (see section 4.2.8, module normal graceful switch-off)
An abrupt under-voltage shutdown occurs on TOBY-L4 series modules when the VCC supply is
removed. If this occurs, it is not possible to store the current parameter settings in the module’s nonvolatile memory or to perform the proper network detach.
An abrupt emergency shutdown occurs on TOBY-L4 series modules when a sufficiently long low pulse
is set at the PWR_ON pin (see section 4.2.8, module emergency switch-off). In this case, storage of
the current parameter settings in the module’s non-volatile memory and a proper network detach are
not performed.
An over-temperature shutdown occurs on TOBY-L4 modules when the temperature measured within
the cellular module reaches a critical range. For more details, see the TOBY-L4 series system
integration manual [2].
(see the u-blox AT commands manual [1])
2.3.3 Module reset
TOBY-L4 series modules can be properly reset (rebooted), performing an “internal” or “software” reset
of the module, saving current parameter settings in the module’s non-volatile memory and
performing a proper network detach, by:
+CFUN AT command
reboot command on the Linux shell
3
(see the u-blox AT commands manual [1])
4
An abrupt “external” or “hardware” reset occurs when a low level is applied to the RESET_N pin, which
is normally set high by an internal pull-up, for a valid time period (see the section 4.2.9). The current
parameter settings are not saved in the module’s non-volatile memory and a proper network detach
is not performed. The RESET_N line should be driven by an open drain, open collector or contact
switch.
2.3.4 Module configuration selection by host processor
☞ Host Select pins are not supported by the "50" and "51" product version.
TOBY-L4 series modules include two 1.8 V digital pins (HOST_SELECT0, HOST_SELECT1), which can
be configured for External Interrupt detection or as GPIO by means of uCPU application.
Not supported by "01" product version
Not supported by "50" and "51" product version
UBX-16009856 - R09 Interfaces Page 11 of 58
C1-Public
TOBY-L4 series - Data sheet
6
8
9
10
5
6
7
8
9
10
2.4 SIM
2.4.1 SIM interfaces
TOBY-L4 series modules provide two SIM interfaces for the direct connection of two external SIM
cards/chips, which can be alternatively used (only one SIM at a time can be used for network access):
SIM0 interface (VSIM, SIM_IO, SIM_CLK, SIM_RST pins), which is enabled by default
SIM1 interface (VSIM1, SIM1_IO, SIM1_CLK, SIM1_RST pins), which can be alternatively enabled by
dedicated AT command (see the u-blox AT commands manual [1]), or by means of uCPU API5.
Both 1.8 V and 3 V SIM types are supported. Activation and deactivation with an automatic voltage
switch from 1.8 V to 3 V is implemented, according to ISO-IEC 7816-3 specifications. The high-speed
SIM/ME interface and PPS procedure for baud rate selection are implemented according to the values
proposed by the SIM card/chip.
2.4.2 SIM detection
TOBY-L4 series modules provide the SIM detection function over GPIO to detect the mechanical /
physical presence of an external SIM card connected to the SIM0 interface (as an optional feature)
when the specific GPIO of the module is properly connected to the mechanical switch of the SIM card
holder (for more details, see the TOBY-L4 series system integration manual [2]).
2.5 Serial communication
TOBY-L4 series provides the following serial communication interfaces:
USB interface: USB Super-Speed 3.0 compliant interface
interface available for communication with an external host application processor or device7
Up to four UART interfaces
: Universal Asynchronous Receiver/Transmitter serial interfaces
available for communication with an external host application processor and/or other serial
devices
Up to two SPI interfaces
5
: Serial Peripheral Interfaces available for communication with external
SPI devices
Two DDC interfaces
: I2C bus compatible interfaces available for communication with external
u-blox GNSS positioning chips and modules, and/or other I2C devices as an audio codec
SDIO interface
5
: Secure Digital Input Output interface available for communication with external
u-blox short range radio communication Wi-Fi / Bluetooth modules, or other SDIO devices
RGMII interface
: Reduced Gigabit Media-Independent Interface, where the module represents an
Ethernet MAC, which can be connected to a compatible external Ethernet PHY for communication
with a remote processor
and USB High-Speed 2.0 compliant
Not supported by "50" and "51" product versions
USB 3.0 interface will be supported by future firmware versions
USB 2.0 host role is not supported by "50" and "51" product versions
UART interfaces are not supported by "50" and "51" product version, except for diagnostic purposes and Ring Indicator
function over UART0
I2C interfaces are not supported by "50" product versions. Second I2C interface is not supported by "51" product versions.
Not supported by "50" product versions
UBX-16009856 - R09 Interfaces Page 12 of 58
C1-Public
TOBY-L4 series - Data sheet
11
12
13
CDC port
Linux VM device
Function on "50" and "51" product versions
Function on "01" product versions
CDC-ACM0
/dev/ttyGS0
AT interface for audio tuning purpose only
Generic serial communication
CDC-ACM1
/dev/ttyGS1
Trace log capture (diagnostic purpose)
Trace log capture (diagnostic purpose)
CDC-ACM2
/dev/ttyGS2
AT interface to control the module
AT interface to control the module
CDC-ACM3
/dev/ttyGS3
Audio parameters tuning and FW update
Linux console
CDC-NCM
usb0
Ethernet-over-USB virtual channel
Ethernet-over-USB virtual channel
11
12
13
2.5.1 USB interface
☞ USB Super-Speed 3.0 compliant interface will be supported by future firmware version.
☞ USB High-Speed 2.0 host role is not supported by "50" and "51" product versions.
TOBY-L4 series modules include a USB Super-Speed 3.0 compliant interface, supporting up to 5 Gb/s
data rate, and also including a USB High-Speed 2.0 compliant interface, supporting up to 480 Mb/s
data rate.
The USB High-Speed 2.0 compliant interface consists of the following pins:
USB_D+/USB_D–, USB High-Speed differential data lines as per USB 2.0 specification [11]
VUSB_DET input pin, which senses the USB VBUS presence (nominally 5 V at the source) to detect
the host connection and enable the USB 2.0 interface with the module acting as USB device.
Neither the USB interface, nor the whole module is supplied by the VUSB_DET input pin, which
senses the VBUS USB supply voltage presence and absorbs only a few microamperes.
USB_ID pin, available for USB ID resistance measurement:
o if the USB_ID pin is externally connected to GND, then the module acts as a USB host
o if the USB_ID pin is externally left unconnected (floating), than the module acts as a USB device
The USB High-Speed 2.0 compliant interface, with the module acting as a USB device, provides:
AT commands
Generic serial communication
Ethernet-over-USB virtual channel
Auxiliary channel for audio tuning
Trace log capture (diagnostic purpose)
Linux console for uCPU applications development and debug
FW upgrades by means of the +UDWNFILE and +UFWINSTALL AT commands
FW upgrades by means of the u-blox EasyFlash tool
13
12
12
, and/or the dedicated DownloadTool13
Table 4 shows the USB functions available in module normal operative mode, acting as a USB device.
Table 4: USB functions with the TOBY-L4 series module acting as a USB device
The USB High-Speed 2.0 compliant interface, with the module acting as USB host (OTG), provides:
Communication with external device by means of uCPU application
The USB Super-Speed 3.0 compliant interface as per the USB 3.0 specification [10], with the module
acting as a USB device, consists of the following additional pins:
USB_SSTX+/USB_SSTX–, USB Super-Speed differential transmitter data lines
USB_SSRX+/USB_SSRX–, USB Super-Speed differential receiver data lines
TOBY-L4 series modules are compatible with standard Linux/Android USB kernel drivers.
Partially supported by "01" product version
Not supported by "01" product version
Not supported by "50" and "51" product version
UBX-16009856 - R09 Interfaces Page 13 of 58
C1-Public
TOBY-L4 series - Data sheet
14
15
2.5.2 UART interfaces
☞ UART interfaces are not supported by the "50" and "51" product versions, except for trace logging
(diagnostic purposes) and Ring Indicator functionality over the UART0 interface.
2.5.2.1 UART0 interface
The UART0 Universal Asynchronous Receiver/Transmitter serial interface has CMOS compatible
signal levels (0 V for ON / active state and 1.8 V for OFF / idle state), providing:
Communication with external devices by means of the uCPU API, over the following pins:
o RXD module output and TXD module input data lines
o CTS module output and RTS module input hardware flow control lines
Trace logging (diagnostic purpose), over the following pins:
o RXD module output and TXD module input data lines
Ring Indicator functionality, over the following pin:
o RI module output line
UART0 interface can operate at 9.6 kbit/s, 19.2 kbit/s, 38.4 kbit/s, 57.6 kbit/s, 115.2 kbit/s, 230.4 kbit/s,
460.8 kbit/s, 921.6 kbit/s, 3 Mbit/s, 3.25 Mbit/s and 6.5 Mbit/s baud rates, with 8N1 frame format, and
with hardware flow control output (CTS line) driven to OFF state when the module is not prepared to
accept data by the UART0 interface.
The DTR, DSR, DCD and RI pins can be alternatively configured for External Interrupt detection or as
GPIO by means of the uCPU API14. The RI pin can be alternatively configured as GPIO by AT command15.
For more details see the TOBY-L4 series system integration manual [2], and the u-blox AT commands
manual [1] +CNMI, +URING15 AT commands.
2.5.2.2 UART1 interface
The UART1 Universal Asynchronous Receiver/Transmitter serial interface has CMOS compatible
signal levels (0 V for ON / active state and 1.8 V for OFF / idle state), providing:
Communication with external devices by means of uCPU API, over the following pins:
o RXD1 module output and TXD1 module input data lines
o CTS1 module output and RTS1 module input hardware flow control lines
UART1 interface can operate at 9.6 kbit/s, 19.2 kbit/s, 38.4 kbit/s, 57.6 kbit/s, 115.2 kbit/s, 230.4 kbit/s,
460.8 kbit/s, 921.6 kbit/s, 3 Mbit/s, 3.25 Mbit/s and 6.5 Mbit/s baud rates, with 8N1 frame format, and
with hardware flow control output (CTS1 line) driven to OFF state when the module is not prepared to
accept data by the UART1 interface.
The UART1 interface can be alternatively, in mutually exclusive way, configured as SPI1 interface by
means of uCPU API, for communication with external devices with the following pins:
RXD1 pin, alternatively configured as SPI1 Master Output Slave Input (module output)
TXD1 pin, alternatively configured as SPI1 Master Input Slave Output (module input)
CTS1 pin, alternatively configured as SPI1 Chip Select (module output)
RTS1 pin, alternatively configured as SPI1 Clock (module output)
Not supported by "50" and "51" product version
Not supported by "01" product version
UBX-16009856 - R09 Interfaces Page 14 of 58
C1-Public
TOBY-L4 series - Data sheet
2.5.2.3 UART2 interface
The UART2 Universal Asynchronous Receiver/Transmitter serial interface has CMOS compatible
signal levels (0 V for ON / active state and 1.8 V for OFF / idle state), providing:
Communication with external devices by means of uCPU API, over the following pins:
o RXD2 module output and TXD2 module input data lines
UART2 interface can operate at 9.6 kbit/s, 19.2 kbit/s, 38.4 kbit/s, 57.6 kbit/s, 115.2 kbit/s, 230.4 kbit/s,
460.8 kbit/s, 921.6 kbit/s, 3 Mbit/s, 3.25 Mbit/s and 6.5 Mbit/s baud rates, with 8N1 frame format.
2.5.2.4 UART3 interface
The UART3 Universal Asynchronous Receiver/Transmitter serial interface has CMOS compatible
signal levels (0 V for ON / active state and 1.8 V for OFF / idle state), providing:
Linux console for uCPU API development and debug, over the following pins:
o RXD3 module output and TXD3 module input data lines
UART3 interface can operate at 9.6 kbit/s, 19.2 kbit/s, 38.4 kbit/s, 57.6 kbit/s, 115.2 kbit/s, 230.4 kbit/s,
460.8 kbit/s, 921.6 kbit/s, 3 Mbit/s, 3.25 Mbit/s and 6.5 Mbit/s baud rates, with 8N1 frame format.
2.5.3 SPI interfaces
☞ SPI interfaces are not supported by "50" and "51" product versions.
2.5.3.1 SPI0 interface
The SPI0 1.8 V Serial Peripheral Interface supports communication with an external SPI slave devices,
with the module acting as SPI master, by means of uCPU API, with the following pins:
SPI_MOSI pin, SPI0 Master Output Slave Input (module output)
SPI_MISO pin, SPI0 Master Input Slave Output (module input)
SPI_SCLK pin, SPI0 Serial Clock (module output)
SPI_CS pin, SPI0 Chip Select 0 (module output)
GPIO4 pin, alternatively configured as SPI0 Chip Select 1 (module output)
The SPI0 Serial Clock signal can be configured to different operating frequencies: 26 MHz (maximum
frequency), and 26 / n MHz, where n is 2, 3, 4, etc.
For more details regarding the SPI0 interface usage and the integration with an external application
processor and/or other SPI devices, see the TOBY-L4 series system integration manual [2].
2.5.3.2 SPI1 interface
The SPI1 1.8 V Serial Peripheral Interface supports communication with an external SPI slave devices,
with the module acting as SPI master, by means of the uCPU API, with the following UART1 pins
configured as alternative functions, in a mutually exclusive way:
RXD1 pin, alternatively configured as SPI1 Master Output Slave Input (module output)
TXD1 pin, alternatively configured as SPI1 Master Input Slave Output (module input)
RTS1 pin, alternatively configured as SPI1 Serial Clock (module output)
CTS1 pin, alternatively configured as SPI1 Chip Select (module output)
The SPI1 Serial Clock signal can be configured to various operating frequencies: 26 MHz (maximum
frequency), and (26 / n) MHz, where n is 2, 3, 4, etc.
For more details regarding the SPI1 interface usage and the integration with an external application
processor and/or other SPI devices, see the TOBY-L4 series system integration manual [2].
UBX-16009856 - R09 Interfaces Page 15 of 58
C1-Public
TOBY-L4 series - Data sheet
16
16
17
2.5.4 DDC (I2C) interfaces
☞ DDC (I2C) interfaces are not supported by the "50" product version.
☞ The second DDC (I2C) interface (I2C1) is not supported by the "51" product version.
2.5.4.1 I2C0 interface
The SDA and SCL pins represent the I2C0 1.8 V I2C bus compatible Display Data Channel (DDC)
interface, with the module acting as I2C master, available for
communication with u-blox GNSS chips / modules by means of uCPU API
communication with external I2C devices by means of uCPU API
16
or AT commands17
I2C0 interface pins of the module are open drain outputs conforming to the I2C bus specifications [12],
supporting up to 100 kbit/s data rate in Standard-mode, and up to 400 kbit/s data rate in Fast-mode.
External pull up resistors to a suitable 1.8 V supply (e.g. V_INT) are required for operations.
For more details regarding the I2C0 interface usage and the integration with a u-blox GNSS receiver,
see the TOBY-L4 series system integration manual [2], and the I2C AT commands description in the
-blox AT commands manual [1].
2.5.4.2 I2C1 interface
The SDA and SCL pins represent the I2C1 I2C bus compatible Display Data Channel (DDC) interface,
with the module acting as I2C master, available for
communication with external I2C devices by means of uCPU API
I2C1 interface pins of the module are open drain outputs conforming to the I2C bus specifications [12],
supporting up to 100 kbit/s data rate in Standard-mode, and up to 400 kbit/s data rate in Fast-mode.
External pull up resistors to a suitable 1.8 V supply (e.g. V_INT) are required for operations.
For more details regarding the I2C1 interface usage, see the TOBY-L4 series system integration
manual [2].
2.5.5 SDIO interface
☞ SDIO interface is not supported by the "50" and "51" product versions.
TOBY-L4 series modules include a 4-bit Secure Digital Input Output interface (SDIO_D0, SDIO_D1,
SDIO_D2, SDIO_D3, SDIO_CLK, SDIO_CMD), where the module acts as an SDIO host controller
designed to:
communicate with compatible u-blox short range radio communication modules by means of the
uCPU API
communicate with external SDIO devices by means of the uCPU API
The SDIO interface supports up to SD 3.0 SDR104 bus speed mode.
For more details regarding the SDIO interface usage, see the TOBY-L4 series system integration
manual [2].
Not supported by the "51" product version
Not supported by "01" product version
UBX-16009856 - R09 Interfaces Page 16 of 58
C1-Public
TOBY-L4 series - Data sheet
2.5.6 RGMII interface
☞ RGMII interface is not supported by the "50" product version.
TOBY-L4 series modules include an Ethernet Media Access Control (MAC) block supporting up to
1 Gbit/s data rate via a Reduced Gigabit Media-Independent Interface compliant with the RGMII
version 1.3 specification [13].
The module represents an Ethernet MAC controller, which can be connected to a compatible external
Ethernet physical transceiver (PHY) chip for communication with a remote processor over Ethernet.
The following signals are provided for communication and management of an external Ethernet PHY:
V_ETH Interface supply output
ETH_TX_CLK RGMII Transmit reference Clock (TXC) output
ETH_TX_CTL RGMII Transmit Control output, driven on both edges of Transmit clock (TXC)
ETH_TXD0 RGMII Transmit Data [0], from MAC to PHY (module output)
ETH_TXD1 RGMII Transmit Data [1], from MAC to PHY (module output)
ETH_TXD2 RGMII Transmit Data [2], from MAC to PHY (module output)
ETH_TXD3 RGMII Transmit Data [3], from MAC to PHY (module output)
ETH_RX_CLK RGMII Receive reference Clock (RXC) input
ETH_RX_CTL RGMII Receive Control input, sampled on both edges of Receive clock (RXC)
ETH_RXD0 RGMII Receive Data [0], from PHY to MAC (module input)
ETH_RXD1 RGMII Receive Data [1], from PHY to MAC (module input)
ETH_RXD2 RGMII Receive Data [2], from PHY to MAC (module input)
ETH_RXD3 RGMII Receive Data [3], from PHY to MAC (module input)
ETH_INTR Ethernet Interrupt Input, from PHY to MAC (module input)
When this signal is high, it indicates an interrupt event in the PHY
ETH_MDIO Management Data Input Output, bidirectional signal (module input/output)
ETH_MDC Management Data Clock, from MAC to PHY (module output)
For more details regarding the RGMII interface usage and its integration, see the TOBY-L4 series
system integration manual [2].
2.6 eMMC interface
☞ eMMC interface is not supported by the "50" and "51" product versions, except for diagnostic.
TOBY-L4 series modules include a 4-bit embedded Multi-Media Card interface compliant with the
JESD84-B451 Embedded Multimedia Card (eMMC) electrical standard 4.51 [14]. The following signals
are provided for connection and management of an external eMMC / SD memory, by means of the
uCPU API:
V_MMC Interface supply output (module output)
MMC_D0 Multi-Media Card Data [0], bidirectional signal (module input/output)
MMC_D1 Multi-Media Card Data [1], bidirectional signal (module input/output)
MMC_D2 Multi-Media Card Data [2], bidirectional signal (module input/output)
MMC_D3 Multi-Media Card Data [3], bidirectional signal (module input/output)
MMC_CMD Multi-Media Card Command, bidirectional signal (module input/output)
MMC_CLK Multi-Media Card Clock (module output)
MMC_RST_N Multi-Media Card Reset (module output)
MMC_CD_N Multi-Media Card Detect (module input)
For more details regarding the eMMC interface usage and the integration with an external memory,
see the TOBY-L4 series system integration manual [2].
UBX-16009856 - R09 Interfaces Page 17 of 58
C1-Public
TOBY-L4 series - Data sheet
18
18
19
Supported Bus Speed Modes:
SD2.0 Default Speed mode: 2.85V signaling, up to 25 MHz, up to 12.5 MB/s
SD2.0 High Speed Mode: 2.85V signaling, up to 50 MHz, up to 25 MB/s
SD3.0 SDR12: 1.8V signaling, up to 25 MHz, up to 12.5 MB/s
SD3.0 SDR25: 1.8V signaling, up to 50 MHz, up to 25 MB/s
SD3.0 SDR50: 1.8V signaling, up to 100 MHz, up to 50 MB/s
SD3.0 DDR50: 1.8V signaling, up to 50 MHz, sampled on both clock edges, up to 50 MB/s
eMMC Backward Compatibility Mode: 1.8V / 2.85V signaling, up to 26 MHz, up to 26 MB/s
eMMC High Speed SDR Mode: 1.8V / 2.85V signaling, up to 52 MHz, up to 52 MB/s
eMMC High Speed DDR Mode: 1.8V / 2.85V signaling, up to 52 MHz, up to 104 MB/s
The HS200 SDR and the SD3.0 SDR104 Bus Speed Modes are not supported
2.7 Audio interfaces
☞ Since the NTT DoCoMo certification is only valid for data-only applications, the TOBY-L4206-01A
and TOBY-L4206-51A product versions operate as data-only devices if the Mobile Network
Operator profile is set to NTT DoCoMo as defined by the factory-programmed value of the
AT+UMNOPROF command (for further details, see the u-blox AT commands manual [1]).
TOBY-L4 series modules provide analog and digital audio interfaces:
Analog audio inputs:
o First differential analog audio input (MIC1_P, MIC1_N), which can be connected to the output
of an external analog audio device, or an external microphone
o Second differential analog audio input (MIC2_P, MIC2_N), which can be connected to the
output of an external analog audio device, or an external microphone
o Supply output for external microphones (MIC_BIAS), which can provide the bias / supply for
external microphones by means of a circuit implemented on the application board
o Local ground for the external microphone (MIC_GND), internally connected to ground,
representing a clean ground reference for the analog audio input
Analog audio output:
o Differential analog audio output (SPK_P, SPK_N), which can be connected to the input of an
external analog audio device, or an external speaker
Digital audio interfaces:
o I2S0 digital audio interface (I2S_TXD, I2S_RXD, I2S_CLK, I2S_WA), configurable in PCM mode
(short synchronization signal) or in normal I2S mode (long synchronization signal) to transfer
digital audio data with an external digital audio device
o I2S1 digital audio interface
(I2S1_TXD, I2S1_RXD, I2S1_CLK, I2S1_WA), configurable in PCM
mode (short synchronization signal) or in normal I2S mode (long synchronization signal) to
transfer digital audio data with an external digital audio device
For more details regarding the I2S digital audio interface usage and the integration with an external
digital audio device as an audio codec, see the TOBY-L4 series system integration manual [2] and the
audio AT commands19 description in the u-blox AT commands manual [1].
I2S1 digital audio interface will be supported by future FW versions
Not supported by "01" product version
UBX-16009856 - R09 Interfaces Page 18 of 58
C1-Public
TOBY-L4 series - Data sheet
Function
Description
Configurable GPIOs
SPI Chip Select
SPI0 Chip Select 1 (module output)
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6, GPIO7,
GPIO8, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
Wi-Fi enable
Switch-on/off the external u-blox Wi-Fi module
connected to the cellular module over the SDIO
interface
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6, GPIO7,
GPIO8, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
GNSS supply
enable
Enable/disable the supply of u-blox GNSS receiver
connected to the cellular module over the I2C0
interface
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6, GPIO7,
GPIO8, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
GNSS data ready
Sense when u-blox GNSS receiver connected to
the module is ready for sending data over the
I2C0 interface
GPIO3, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
External Interrupt
External Interrupt detection (module input)
GPIO3, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
Wake-up
Wake-up the module from Suspend to RAM state
(low power idle mode)
GPIO3, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
SIM card detection
External SIM card physical presence detection
GPIO5
SIM card hot
insertion/removal
Enable / disable SIM interface upon detection of
external SIM card physical insertion / removal
GPIO5
PWM
Pulse-Width Modulation output signal
GPIO7
Core dump
Indicates core dump sent over Ethernet RGMII
interface
GPIO8
Input
Input to sense high or low digital level
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6, GPIO7,
GPIO8, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
Output
Output to set the high or the low digital level
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6, GPIO7,
GPIO8, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
Pin disabled
Output tri-stated with an internal active pulldown enabled
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6, GPIO7,
GPIO8, HOST_SELECT0, HOST_SELECT1, DTR, DSR,
DCD, RI
2.8 ADC interfaces
☞ ADC pins are not supported by the "50" and "51" product versions.
TOBY-L4 series modules include Analog to Digital Converter inputs (ADC1, ADC2), which can be
handled by means of dedicated uCPU API. For more details, see the TOBY-L4 series system
integration manual [2].
2.9 GPIO interfaces
TOBY-L4 series modules "01" product versions include 14 pins (GPIO1, GPIO2, GPIO3, GPIO4, GPIO5,
GPIO6, GPIO7, GPIO8, HOST_SELECT0, HOST_SELECT1, DTR, DSR, DCD, and RI) that can be
configured by the uCPU application as general purpose input/output or to provide custom functions
as summarized in Table 5.
Table 5: TOBY-L4 series modules "01" product versions GPIO custom functions summary
UBX-16009856 - R09 Interfaces Page 19 of 58
C1-Public
TOBY-L4 series - Data sheet
Function
Description
Configurable GPIOs
Ring Indicator
UART0 Ring Indicator functionality (Circuit 125 in ITU-T V.24)
RI
SIM card detection
External SIM card physical presence detection
GPIO5
SIM card hot
insertion/removal
Enable / disable SIM interface upon detection of external
SIM card physical insertion / removal
GPIO5
Core dump 20
Indicates core dump sent over Ethernet RGMII interface
GPIO8
Input
Input to sense high or low digital level
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6,
GPIO7, GPIO8, RI
Output
Output to set the high or the low digital level
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6,
GPIO7, GPIO8, RI
Pin disabled
Output tri-stated with an internal active pull-down enabled
GPIO1, GPIO2, GPIO3, GPIO4, GPIO5, GPIO6,
GPIO7, GPIO8, RI
20
TOBY-L4 series modules "50" and "51" product versions include 9 pins (GPIO1, GPIO2, GPIO3, GPIO4,
GPIO5, GPIO6, GPIO7, GPIO8, and RI) that can be configured by AT commands as general purpose
input/output or to provide custom functions as summarized in Table 6.
Table 6: TOBY-L4 series modules "50" and "51" product versions GPIO custom functions summary
2.10 RSVD pins
TOBY-L4 series modules have pins reserved for future use, marked as RSVD. They can all be left
unconnected on the application board, except the RSVD pin number 6, which has special function:
the RSVD pin #6 must be externally connected to ground, if eFuse programming is unnecessary
the RSVD pin #6 must be temporarily driven to 1.8 V, if eFuse programming is necessary
Not supported by the "50" product version
UBX-16009856 - R09 Interfaces Page 20 of 58
C1-Public
TOBY-L4 series - Data sheet
11
RI
10
DSR
7
RSVD
5
V_INT
4
VUSB_DET
2
GND
1
RSVD
21
GPIO1
19
RXD3
18
TXD3
16
TXD
15
CTS
13
DTR
12
DCD
29
ETH_TX_CLK
27
USB_D–
26
HOST_SELECT0
24
GPIO3
23
RESET_N
8
RSVD
6
RSVD
3
V_BCKP
22
GPIO2
20
PWR_ON
17
RXD
14
RTS
28
USB_D+
25
GPIO4
9
RSVD
65
SDIO_CMD
66
SDIO_D0
69
GND
71
VCC
72
VCC
74
GND
75
ANT_DET
55
SDA
57
SIM_IO
58
SIM_RST
60
GPIO5
61
GPIO6
63
SDIO_D2
64
SDIO_CLK
47
RSVD
49
RSVD
50
I2S_WA
52
I2S_CLK
53
I2S_RXD
68
SDIO_D1
70
VCC
73
GND
54
SCL
56
SIM_CLK
59
VSIM
62
HOST_SELECT1
48
RSVD
51
I2S_TXD
67
SDIO_D3
90
GND
91
RSVD
92
GND
78
GND
77
RSVD
76
GND
93
GND
100
GND
79
GND
80
GND
83
GND
85
GND
86
GND
88
GND
89
GND
82
GND
84
RSVD
87
ANT2
81
ANT1
32
GND
31
RSVD
30
GND
44
GND
45
RSVD
46
GND
145
GND
152
GND
43
ETH_
RX_CLK
42
ETH_
RX_CTL
39
ETH_
RXD1
37
ETH_
TXD0
36
ETH_
TXD1
34
ETH_
TXD3
33
ETH_
TX_CTL
40
ETH_
RXD2
38
ETH_
RXD0
35
ETH_
TXD2
41
ETH_
RXD3
99
GND
98
GND
97
GND
96
GND
95
GND
94
GND
106
GND
105
GND
104
GND
103
GND
102
GND
101
GND
108
GND
107
GND
124
GND
123
GND
130
GND
129
GND
128
GND
127
GND
126
GND
125
GND
136
GND
135
GND
134
GND
133
GND
132
GND
131
GND
138
GND
137
GND
144
GND
143
GND
142
GND
141
GND
140
GND
139
GND
151
GND
150
GND
149
GND
148
GND
147
GND
146
GND
114
GND
113
GND
112
GND
111
GND
110
GND
109
GND
120
GND
119
GND
118
GND
117
GND
116
GND
115
GND
122
GND
121
GND
TOBY-L4
155
RSVD
153
RSVD
157
RSVD
156
RSVD
154
RSVD
158
RSVD
195
CTS1
193
RTS1
197
RSVD
196
RSVD
194
RSVD
198
RSVD
207
I2S1_RXD
206
I2S1_TXD
203
SCL1
201
RSVD
200
RSVD
217
MMC_D2
215
MMC_CMD
214
MMC_D0
212
MMC_D1
211
MMC_RST_N
209
GND
208
I2S1_CLK
222
ETH_MDIO
220
ETH_INTR
219
GND
204
SDA1
202
RSVD
199
RSVD
218
MMC_CD_N
216
MMC_CLK
213
MMC_D3
210
V_MMC
221
V_ETH
205
I2S1_WA
223
ETH_MDC
240
ADC1
241
GND
244
RSVD
246
RSVD
247
GPIO8
230
MIC_GND
232
GND
233
MIC2_N
235
GND
236
MIC1_N
238
GND
239
ADC2
225
RSVD
227
SPK_P
228
SPK_N
243
RSVD
245
RSVD
248
GPIO7
229
GND
231
MIC_BIAS
234
MIC2_P
237
MIC1_P
226
GND
242
RSVD
224
RSVD
162
RXD2
161
TXD2
160
RXD1
159
TXD1
168
USB_ID
163
RSVD
167
RSVD
166
RSVD
165
RSVD
164
RSVD
172
VSIM1
171
USB_SSRX–
170
USB_SSRX+
169
SPI_MISO
182
SIM1_CLK
181
RSVD
180
RSVD
179
SPI_SCLK
178
SIM1_IO
173
SPI_CS
177
SIM1_RST
176
USB_SSTX–
175
USB_SSTX+
174
SPI_MOSI
188
RSVD
183
RSVD
187
RSVD
186
RSVD
185
RSVD
184
RSVD
192
RSVD
191
RSVD
190
RSVD
189
RSVD
Top view
3 Pin definition
☞ For more information about the pin-out, see the TOBY-L4 series system integration manual [2].
☞ See appendix A for an explanation of abbreviations and terms used.
3.1 Pin assignment
Figure 3: TOBY-L4 series pin assignment (top view: module through view)
UBX-16009856 - R09 Pin definition Page 21 of 58
C1-Public
TOBY-L4 series - Data sheet
No
Name
Power
I/O
Description
Remarks
1
RSVD
-
N/A
RESERVED pin
Leave unconnected.
2
GND
GND
N/A
Ground
All GND pins must be connected to ground.
3
V_BCKP
-
I/O
RTC backup supply
If the VCC module main supply input voltage is below
the operating range, the RTC block can be externally
supplied through the V_BCKP pin.
See section 4.2.3 for detailed electrical specs.
4
VUSB_DET
USB I VBUS USB detect input
VBUS (5 V typical) must be connected to this pin to
enable the module USB device interface.
See section 4.2.11 for detailed electrical specs.
5
V_INT
GDI
O
Generic Digital Interfaces
supply output
1.8 V (typical) output voltage generated by the module
when it is switched-on.
See section 4.2.3 for detailed electrical specs.
6
RSVD
-
N/A
RESERVED pin
This pin has special function: it must be connected to
GND, if eFuse programming is unnecessary; It must be
temporarily driven to 1.8 V, if eFuse programming is
necessary
7
RSVD
-
N/A
RESERVED pin
Leave unconnected.
8
RSVD
-
N/A
RESERVED pin
Leave unconnected.
9
RSVD
-
N/A
RESERVED pin
Leave unconnected.
10
DSR
GDI
I/O / I GPIO /
External Interrupt
Alternately settable as GPIO by uCPU API
Alternately settable as External Interrupt by uCPU API
See section 4.2.15 for detailed electrical specs.
11
RI
GDI
O /
I/O /
I
UART0 ring indicator /
GPIO /
External Interrupt
Circuit 125 (RI) in ITU-T V.24.
Alternately settable as GPIO by uCPU API / AT+UGPIOC
Alternately settable as External Interrupt by uCPU API
See section 4.2.15 for detailed electrical specs.
12
DCD
GDI
I/O / I GPIO /
External Interrupt
Alternately settable as GPIO by uCPU API
Alternately settable as External Interrupt by uCPU API
See section 4.2.15 for detailed electrical specs.
13
DTR
GDI
I/O / I GPIO /
External Interrupt
Alternately settable as GPIO by uCPU API
Alternately settable as External Interrupt by uCPU API
See section 4.2.15 for detailed electrical specs.
14
RTS
GDI I UART0 ready to send
Circuit 105 (RTS) in ITU-T V.24.
See section 4.2.15 for detailed electrical specs.
15
CTS
GDI O UART0 clear to send
Circuit 106 (CTS) in ITU-T V.24.
See section 4.2.15 for detailed electrical specs.
16
TXD
GDI I UART0 data input
Circuit 103 (TxD) in ITU-T V.24.
See section 4.2.15 for detailed electrical specs.
17
RXD
GDI O UART0 data output
Circuit 104 (RxD) in ITU-T V.24.
See section 4.2.15 for detailed electrical specs.
18
TXD3
GDI I UART3 data input
Circuit 103 (TxD) in ITU-T V.24.
See section 4.2.15 for detailed electrical specs.
19
RXD3
GDI O UART3 data output
Circuit 104 (RxD) in ITU-T V.24.
See section 4.2.15 for detailed electrical specs.
20
PWR_ON
POS I Power-on/off input
Active-low module power-on/off input.
Internal 35 k pull-up resistor to 1.3 V rail.
See section 4.2.8 for detailed electrical specs.
21
GPIO1
GDI
I/O
GPIO
GPIO configurable as described in section 2.9.
See section 4.2.15 for detailed electrical specs.
22
GPIO2
GDI
I/O
GPIO
GPIO configurable as described in section 2.9.
See section 4.2.15 for detailed electrical specs.
UBX-16009856 - R09 Pin definition Page 22 of 58
C1-Public
TOBY-L4 series - Data sheet
No
Name
Power
I/O
Description
Remarks
23
RESET_N
ERS I External reset input
Active-low module reset input.
Internal 100 k pull-up resistor to V_INT.
See section 4.2.9 for detailed electrical specs.
24
GPIO3
GDI
I/O / I GPIO /
External Interrupt
GPIO configurable as described in section 2.9.
Alternately settable as External Interrupt by uCPU API
See section 4.2.15 for detailed electrical specs.
25
GPIO4
GDI
I/O / O GPIO /
SPI0 Chip Select 1
GPIO configurable as described in section 2.9.
Alternately settable as SPI0 Chip Select 1 by uCPU API.
See section 4.2.15 for detailed electrical specs.
26
HOST_SELECT0
GDI
I / I/O
Input for selection of
module setting by the host
processor
Alternately settable as GPIO by uCPU API
Alternately settable as External Interrupt by uCPU API
See section 4.2.15 for detailed electrical specs.
27
USB_D–
USB2
I/O
USB High-Speed 2.0
differential transceiver (–)
90 nominal differential characteristic impedance
Pull-up, pull-down, series resistors as per USB 2.0 [11]
are part of the pin driver: not needed externally.
See section 4.2.11 for detailed electrical specs.
28
USB_D+
USB2
I/O
USB High-Speed 2.0
differential transceiver (+)
90 nominal differential characteristic impedance
Pull-up, pull-down, series resistors as per USB 2.0 [11]
are part of the pin driver: not needed externally.
See section 4.2.11 for detailed electrical specs.
29
ETH_TX_CLK
ETH
O
Ethernet Transmission
Clock
RGMII: Transmit reference clock (TXC)
See section 4.2.13 for detailed electrical specs.
30
GND
GND
N/A
Ground
All GND pins must be connected to ground.
31
RSVD
-
N/A
RESERVED pin
Leave unconnected.
32
GND
GND
N/A
Ground
All GND pins must be connected to ground.
33
ETH_TX_CTL
ETH O Ethernet Transmit Control
RGMII: Control signal for the transmit data (TXEN on
TXC rising edge; TXEN xor TXER on TXC falling edge).
See section 4.2.13 for detailed electrical specs.
34
ETH_TXD3
ETH O Ethernet Transmit Data [3]
RGMII: Tx data bit 3 / 7 on TXC rising / falling edges.
See section 4.2.13 for detailed electrical specs.
35
ETH_TXD2
ETH O Ethernet Transmit Data [2]
RGMII: Tx data bit 2 / 6 on TXC rising / falling edges.
See section 4.2.13 for detailed electrical specs.
36
ETH_TXD1
ETH O Ethernet Transmit Data [1]
RGMII: Tx data bit 1 / 5 on TXC rising / falling edges.
See section 4.2.13 for detailed electrical specs.
37
ETH_TXD0
ETH O Ethernet Transmit Data [0]
RGMII: Tx data bit 0 / 4 on TXC rising / falling edges.
See section 4.2.13 for detailed electrical specs.
38
ETH_RXD0
ETH I Ethernet Receive Data [0]
RGMII: Rx data bit 0 / 4 on RXC rising / falling edges.
See section 4.2.13 for detailed electrical specs.
39
ETH_RXD1
ETH I Ethernet Receive Data [1]
RGMII: Rx data bit 1 / 5 on RXC rising / falling edges.
See section 4.2.13 for detailed electrical specs.
40
ETH_RXD2
ETH I Ethernet Receive Data [2]
RGMII: Rx data bit 2 / 6 on RXC rising / falling edges.
See section 4.2.13 for detailed electrical specs.
41
ETH_RXD3
ETH I Ethernet Receive Data [3]
RGMII: Rx data bit 3 / 7 on RXC rising / falling edges.
See section 4.2.13 for detailed electrical specs.
42
ETH_RX_CTL
ETH I Ethernet Receive Control
RGMII: Control signal for receive data (RXDV on RXC
rising edge; RXDV xor RXER on RXC falling edge).
See section 4.2.13 for detailed electrical specs.
43
ETH_RX_CLK
ETH I Ethernet Receive Clock
RGMII: Receive reference clock (RXC).
See section 4.2.13 for detailed electrical specs.
44
GND
GND
N/A
Ground
All GND pins must be connected to ground.
UBX-16009856 - R09 Pin definition Page 23 of 58
C1-Public
TOBY-L4 series - Data sheet
No
Name
Power
I/O
Description
Remarks
45
RSVD
-
N/A
RESERVED pin
Leave unconnected.
46
GND
GND
N/A
Ground
All GND pins must be connected to ground.
47
RSVD
-
N/A
RESERVED pin
Leave unconnected.
48
RSVD
-
N/A
RESERVED pin
Leave unconnected.
49
RSVD
-
N/A
RESERVED pin
Leave unconnected.
50
I2S_WA
GDI
I/O
I2S0 word alignment
I2S word alignment.
See section 4.2.15 for detailed electrical specs.
51
I2S_TXD
GDI O I2S0 transmit data
I2S transmit data out.
See section 4.2.15 for detailed electrical specs.
52
I2S_CLK
GDI
I/O
I2S0 clock
I2S serial clock.
See section 4.2.15 for detailed electrical specs.
53
I2S_RXD
GDI
I
I2S0 receive data
I2S receive data.
See section 4.2.15 for detailed electrical specs
54
SCL
DDC O I2C0 clock
I2C bus serial clock line.
Fixed open drain. No internal pull-up.
See section 4.2.12 for detailed electrical specs.
55
SDA
DDC
I/O
I2C0 data
I2C bus serial data line.
Fixed open drain. No internal pull-up.
See section 4.2.12 for detailed electrical specs.
56
SIM_CLK
SIM O SIM0 clock
See section 4.2.10 for detailed electrical specs.
57
SIM_IO
SIM
I/O
SIM0 data
Internal 4.7 k pull-up resistor to VSIM.
See section 4.2.10 for detailed electrical specs.
58
SIM_RST
SIM O SIM0 reset
See section 4.2.10 for detailed electrical specs.
59
VSIM
- O SIM0 supply output
VSIM = 1.8 V or 2.9 V generated by the module
according to the external SIM card/chip voltage type.
See section 4.2.3 for detailed electrical specs.
60
GPIO5
GDI
I/O
GPIO
GPIO configurable as described in section 2.9.
See section 4.2.15 for detailed electrical specs.
61
GPIO6
GDI
I/O
GPIO
GPIO configurable as described in section 2.9.
See section 4.2.15 for detailed electrical specs.
62
HOST_SELECT1
GDI
I / I/O
Input for selection of
module setting by the host
processor
Alternately settable as GPIO by uCPU API
Alternately settable as External Interrupt by uCPU API
See section 4.2.15 for detailed electrical specs.
63
SDIO_D2
GDI
I/O
SDIO serial data [2]
See section 4.2.15 for detailed electrical specs.
64
SDIO_CLK
GDI O SDIO serial clock
See section 4.2.15 for detailed electrical specs.
65
SDIO_CMD
GDI
I/O
SDIO command
See section 4.2.15 for detailed electrical specs.
66
SDIO_D0
GDI
I/O
SDIO serial data [0]
See section 4.2.15 for detailed electrical specs.
67
SDIO_D3
GDI
I/O
SDIO serial data [3]
See section 4.2.15 for detailed electrical specs.
68
SDIO_D1
GDI
I/O
SDIO serial data [1]
See section 4.2.15 for detailed electrical specs.
69
GND
GND
N/A
Ground
All GND pins must be connected to ground.
70
VCC
VCC I Module supply input
All VCC pins must be connected to external supply.
See section 4.2.3 for detailed electrical specs.
71
VCC
VCC I Module supply input
All VCC pins must be connected to external supply.
See section 4.2.3 for detailed electrical specs.
72
VCC
VCC I Module supply input
All VCC pins must be connected to external supply.
See section 4.2.3 for detailed electrical specs.
73
GND
GND
N/A
Ground
All GND pins must be connected to ground.
UBX-16009856 - R09 Pin definition Page 24 of 58
C1-Public
TOBY-L4 series - Data sheet
No
Name
Power
I/O
Description
Remarks
74
GND
GND
N/A
Ground
All GND pins must be connected to ground.
75
ANT_DET
ADC I Antenna detection
Antenna presence detection function.
76
GND
GND
N/A
Ground
All GND pins must be connected to ground.
77
RSVD
-
N/A
RESERVED pin
Leave unconnected.
78
GND
GND
N/A
Ground
All GND pins must be connected to ground.
79
GND
GND
N/A
Ground
All GND pins must be connected to ground.
80
GND
GND
N/A
Ground
All GND pins must be connected to ground.
81
ANT1
ANT
I/O
Primary antenna
50 nominal characteristic impedance.
Main Tx / Rx antenna interface.
See section 4.2.5 / 4.2.6 / 4.2.7 for details.
82
GND
GND
N/A
Ground
All GND pins must be connected to ground.
83
GND
GND
N/A
Ground
All GND pins must be connected to ground.
84
RSVD
-
N/A
RESERVED pin
Leave unconnected.
85
GND
GND
N/A
Ground
All GND pins must be connected to ground.
86
GND
GND
N/A
Ground
All GND pins must be connected to ground.
87
ANT2
ANT I Secondary antenna
50 nominal characteristic impedance
Rx only for Down-Link MIMO and Rx diversity.
See section 4.2.5 / 4.2.6 / 4.2.7 for details.
88
GND
GND
N/A
Ground
All GND pins must be connected to ground.
89
GND
GND
N/A
Ground
All GND pins must be connected to ground.
90
GND
GND
N/A
Ground
All GND pins must be connected to ground.
91
RSVD
-
N/A
RESERVED pin
Leave unconnected.
92
GND
GND
N/A
Ground
All GND pins must be connected to ground.
93152
GND
GND
N/A
Ground
All GND pins must be connected to ground.
153
RSVD
-
N/A
RESERVED pin
Leave unconnected.
154
RSVD
-
N/A
RESERVED pin
Leave unconnected.
155
RSVD
-
N/A
RESERVED pin
Leave unconnected.
156
RSVD
-
N/A
RESERVED pin
Leave unconnected.
157
RSVD
-
N/A
RESERVED pin
Leave unconnected.
158
RSVD
-
N/A
RESERVED pin
Leave unconnected.
159
TXD1
GDI
I / I UART1 data input /
SPI1 Master Input Slave
Output
Circuit 103 (TxD) in ITU-T V.24.
Alternatively configurable as SPI1 Master In Slave Out.
See section 4.2.15 for detailed electrical specs.
160
RXD1
GDI
O / O UART1 data output /
SPI1 Master Output Slave
Input
Circuit 104 (RxD) in ITU-T V.24.
Alternatively configurable as SPI1 Master Out Slave In.
See section 4.2.15 for detailed electrical specs.
161
TXD2
GDI I UART2 data input
Circuit 103 (TxD) in ITU-T V.24.
See section 4.2.15 for detailed electrical specs.
162
RXD2
GDI O UART2 data output
Circuit 104 (RxD) in ITU-T V.24.
See section 4.2.15 for detailed electrical specs.
163
RSVD
-
N/A
RESERVED pin
Leave unconnected.
164
RSVD
-
N/A
RESERVED pin
Leave unconnected.
165
RSVD
-
N/A
RESERVED pin
Leave unconnected.
166
RSVD
-
N/A
RESERVED pin
Leave unconnected.
UBX-16009856 - R09 Pin definition Page 25 of 58
C1-Public
TOBY-L4 series - Data sheet
No
Name
Power
I/O
Description
Remarks
167
RSVD
-
N/A
RESERVED pin
Leave unconnected.
168
USB_ID
USB2
I
USB device identification
Pin for USB ID resistance measurement.
169
SPI_MISO
GDI
I
SPI0 Master Input Slave
Output
SPI0 data input
See section 4.2.15 for detailed electrical specs.
170
USB_SSRX+
USB3
I
USB Super-Speed 3.0
differential receiver (+)
90 nominal differential characteristic impedance
Compliant with USB Revision 3.0 specification [10].
See section 4.2.11 for detailed electrical specs.
171
USB_SSRX–
USB3
I
USB Super-Speed 3.0
differential receiver (–)
90 nominal differential characteristic impedance
Compliant with USB Revision 3.0 specification [10].
See section 4.2.11 for detailed electrical specs.
172
VSIM1
- O SIM1 supply output
VSIM1 = 1.8 V or 2.9 V, generated by the module
according to the external SIM card/chip voltage type.
See section 4.2.3 for detailed electrical specs.
173
SPI_CS
GDI O SPI0 Chip Select 0
SPI0 chip select output
See section 4.2.15 for detailed electrical specs.
174
SPI_MOSI
GDI
O
SPI0 Master Output Slave
Input
SPI0 data output
See section 4.2.15 for detailed electrical specs.
175
USB_SSTX+
USB3
O
USB Super-Speed 3.0
differential transmitter (+)
90 nominal differential characteristic impedance.
Internal series 100 nF capacitor for AC coupling.
Compliant with USB Revision 3.0 specification [10].
See section 4.2.11 for detailed electrical specs.
176
USB_SSTX–
USB3
O
USB Super-Speed 3.0
differential transmitter (–)
90 nominal differential characteristic impedance.
Internal series 100 nF capacitor for AC coupling.
Compliant with USB Revision 3.0 specification [10].
See section 4.2.11 for detailed electrical specs.
177
SIM1_RST
SIM O SIM1 reset
See section 4.2.10 for detailed electrical specs.
178
SIM1_IO
SIM
I/O
SIM1 data
Internal 4.7 k pull-up resistor to VSIM1.
See section 4.2.10 for detailed electrical specs.
179
SPI_SCLK
GDI O SPI0 Shift Clock
SPI0 clock output
See section 4.2.15 for detailed electrical specs.
180
RSVD
-
N/A
RESERVED pin
Leave unconnected.
181
RSVD
-
N/A
RESERVED pin
Leave unconnected.
182
SIM1_CLK
SIM O SIM1 clock
See section 4.2.10 for detailed electrical specs.
183
RSVD
-
N/A
RESERVED pin
Leave unconnected.
184
RSVD
-
N/A
RESERVED pin
Leave unconnected.
185
RSVD
-
N/A
RESERVED pin
Leave unconnected.
186
RSVD
-
N/A
RESERVED pin
Leave unconnected.
187
RSVD
-
N/A
RESERVED pin
Leave unconnected.
188
RSVD
-
N/A
RESERVED pin
Leave unconnected.
189
RSVD
-
N/A
RESERVED pin
Leave unconnected.
190
RSVD
-
N/A
RESERVED pin
Leave unconnected.
191
RSVD
-
N/A
RESERVED pin
Leave unconnected.
192
RSVD
-
N/A
RESERVED pin
Leave unconnected.
193
RTS1
GDI
I / O UART1 ready to send /
SPI1 Shift Clock
Circuit 105 (RTS) in ITU-T V.24.
Alternatively configurable as SPI1 Shift Clock.
See section 4.2.15 for detailed electrical specs.
194
RSVD
-
N/A
RESERVED pin
Leave unconnected.
UBX-16009856 - R09 Pin definition Page 26 of 58
C1-Public
TOBY-L4 series - Data sheet
No
Name
Power
I/O
Description
Remarks
195
CTS1
GDI
O / O UART1 clear to send /
SPI1 Chip Select
Circuit 106 (CTS) in ITU-T V.24.
Alternatively configurable as SPI1 Chip Select.
See section 4.2.15 for detailed electrical specs.
196
RSVD
-
N/A
RESERVED pin
Leave unconnected.
197
RSVD
-
N/A
RESERVED pin
Leave unconnected.
198
RSVD
-
N/A
RESERVED pin
Leave unconnected.
199
RSVD
-
N/A
RESERVED pin
Leave unconnected.
200
RSVD
-
N/A
RESERVED pin
Leave unconnected.
201
RSVD
-
N/A
RESERVED pin
Leave unconnected.
202
RSVD
-
N/A
RESERVED pin
Leave unconnected.
203
SCL1
DDC O I2C1 clock
I2C bus serial clock line. Fixed open drain. No internal
pull-up. See section 4.2.12 for detailed electrical specs.
204
SDA1
DDC
I/O
I2C1 data
I2C bus serial data line.
Fixed open drain. No internal pull-up.
See section 4.2.12 for detailed electrical specs.
205
I2S1_WA
GDI
I/O
I2S1 word alignment
I2S word alignment.
See section 4.2.15 for detailed electrical specs.
206
I2S1_TXD
GDI O I2S1 transmit data
I2S transmit data out.
See section 4.2.15 for detailed electrical specs.
207
I2S1_RXD
GDI I I2S1 receive data
I2S receive data.
See section 4.2.15 for detailed electrical specs.
208
I2S1_CLK
GDI
I/O
I2S1 clock
I2S serial clock.
See section 4.2.15 for detailed electrical specs
209
GND
GND
N/A
Ground
All GND pins must be connected to ground.
210
V_MMC
MMC
O
Multi-Media Card Interface
supply output
1.80 V / 2.85 V (typical) output voltage generated by the
module.
See section 4.2.3 for detailed electrical specs.
211
MMC_RST_N
MMC
O
Multi-Media Card Reset
See section 4.2.14 for detailed electrical specs
212
MMC_D1
MMC
I/O
Multi-Media Card Data [1]
See section 4.2.14 for detailed electrical specs
213
MMC_D3
MMC
I/O
Multi-Media Card Data [3]
See section 4.2.14 for detailed electrical specs
214
MMC_D0
MMC
I/O
Multi-Media Card Data [0]
See section 4.2.14 for detailed electrical specs
215
MMC_CMD
MMC
I/O
Multi-Media Card
Command
See section 4.2.14 for detailed electrical specs
216
MMC_CLK
MMC
I/O
Multi-Media Card Clock
See section 4.2.14 for detailed electrical specs
217
MMC_D2
MMC
I/O
Multi-Media Card Data [2]
See section 4.2.14 for detailed electrical specs
218
MMC_CD_N
MMC
I
Multi-Media Card Detect
See section 4.2.14 for detailed electrical specs
219
GND
GND
N/A
Ground
All GND pins must be connected to ground.
220
ETH_INTR
ETH I Ethernet Interrupt Input
When this signal is high, it indicates an interrupt event
in the PHY.
See section 4.2.13 for detailed electrical specs.
221
V_ETH
ETH
O
Ethernet Interface supply
output
3.3 V (typical) output voltage generated by the module
when it is switched-on.
See section 4.2.3 for detailed electrical specs.
222
ETH_MDIO
ETH
I/O
Ethernet Management
Data Input Output
See section 4.2.13 for detailed electrical specs.
223
ETH_MDC
ETH
O
Ethernet Management
Data Clock
See section 4.2.13 for detailed electrical specs.
224
RSVD
-
N/A
RESERVED pin
Leave unconnected.
UBX-16009856 - R09 Pin definition Page 27 of 58
C1-Public
TOBY-L4 series - Data sheet
No
Name
Power
I/O
Description
Remarks
225
RSVD
-
N/A
RESERVED pin
Leave unconnected.
226
GND
GND
N/A
Ground
All GND pins must be connected to ground.
227
SPK_P
AUDIO
O
Differential analog audio
output (+)
See section 4.2.16 for detailed electrical specs.
228
SPK_N
AUDIO
O
Differential analog audio
output (–)
See section 4.2.16 for detailed electrical specs.
229
GND
GND
N/A
Ground
All GND pins must be connected to ground.
230
MIC_GND
AUDIO
I
Microphone analog
reference
Local ground for the external microphone.
See section 4.2.16 for detailed electrical specs.
231
MIC_BIAS
AUDIO
O
Microphone supply output
See section 4.2.16 for detailed electrical specs.
232
GND
GND
N/A
Ground
All GND pins must be connected to ground.
233
MIC2_N
AUDIO
I
MIC2 differential analog
audio input (–)
See section 4.2.16 for detailed electrical specs.
234
MIC2_P
AUDIO
I
MIC2 differential analog
audio input (+)
See section 4.2.16 for detailed electrical specs.
235
GND
GND
N/A
Ground
All GND pins must be connected to ground.
236
MIC1_N
AUDIO
I
MIC1 differential analog
audio input (–)
See section 4.2.16 for detailed electrical specs.
237
MIC1_P
AUDIO
I
MIC1 differential analog
audio input (+)
See section 4.2.16 for detailed electrical specs.
238
GND
GND
N/A
Ground
All GND pins must be connected to ground.
239
ADC2
ADC I ADC input
See section 4.2.17 for detailed electrical specs.
240
ADC1
ADC I ADC input
See section 4.2.17 for detailed electrical specs.
241
GND
GND
N/A
Ground
All GND pins must be connected to ground.
242
RSVD
-
N/A
RESERVED pin
Leave unconnected.
243
RSVD
-
N/A
RESERVED pin
Leave unconnected.
244
RSVD
-
N/A
RESERVED pin
Leave unconnected.
245
RSVD
-
N/A
RESERVED pin
Leave unconnected.
246
RSVD
-
N/A
RESERVED pin
Leave unconnected.
247
GPIO8
GDI
I/O
GPIO
GPIO configurable as described in section 2.9.
See section 4.2.15 for detailed electrical specs.
248
GPIO7
GDI
I/O
GPIO
GPIO configurable as described in section 2.9.
See section 4.2.15 for detailed electrical specs.
Table 7: TOBY-L4 series pin-out
UBX-16009856 - R09 Pin definition Page 28 of 58
C1-Public
TOBY-L4 series - Data sheet
Symbol
Description
Condition
Min.
Max.
Unit
VCC
Module supply voltage
Input DC voltage at VCC pin
–0.3
5.5
V
VUSB_DET
USB detection pin
Input DC voltage at VUSB_DET pin
–0.3
5.5
V
USB2
USB 2.0 pins
Input DC voltage at USB 2.0 interface pins
–0.3
3.6 V DDC
DDC interface
Input DC voltage at DDC interface pins
–0.3
2.3 V GDI
Generic digital interfaces
Input DC voltage at Generic digital interfaces pins
–0.3
2.3 V SIM
SIM interface
Input DC voltage at SIM interface pins
–0.3
3.3 V ERS
External reset signal
Input DC voltage at RESET_N pin
–0.3
2.3 V POS
Power-on input
Input DC voltage at PWR_ON pin
–0.3
1.7
V
Tstg
Storage Temperature
–40
+95
°C
Parameter
Min
Typical
Max
Unit
Remarks
ESD sensitivity for all pins
except ANT1 / ANT2 pins
1000
V
Human Body Model according to JESD22-A114
ESD sensitivity for ANT1 / ANT2 pins
1000
V
Human Body Model according to JESD22-A114
4 Electrical specifications
⚠ Stressing the device above one or more of the ratings listed in the Absolute Maximum Rating
section may cause permanent damage. These are stress ratings only. Operating the module at
these or at any conditions other than those specified in the Operating Conditions sections (section
4.2) of the specification should be avoided. Exposure to Absolute Maximum Rating conditions for
extended periods may affect device reliability.
☞ Operating condition ranges define those limits within which the functionality of the device is
guaranteed.
☞ Electrical characteristics are defined according to verification on a representative number of
samples or according to simulation.
☞ Where application information is given, it is advisory only and does not form part of the
specification.
4.1 Absolute maximum rating
☞ The values given below are in accordance with the Absolute Maximum Rating System (IEC 134).
Table 8: Absolute maximum ratings
⚠ The product is not protected against overvoltage or reversed voltages. If necessary, voltage spikes
exceeding the power supply voltage specification, given in table above, must be limited to values
within the specified boundaries by using appropriate protection devices.
4.1.1 Maximum ESD
Table 9: Maximum ESD ratings
⚠ u-blox cellular modules are Electrostatic Sensitive Devices and require special precautions when
handling. See section 7.4 for ESD handling instructions.
UBX-16009856 - R09 Electrical specifications Page 29 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Typical
Max.
Unit
Remarks
Normal operating temperature
–20
+25
+75
°C
Normal operating temperature range
(fully functional and meet 3GPP specifications)
Extended operating temperature
–40 +85
°C
Extended operating temperature range
(RF performance may be affected outside
normal operating range, though the module is
fully functional)
eCall operating temperature
–40 +95
°C
eCall operating temperature range
(emergency call sustained for at least 2
minutes)
Symbol
Parameter
Min.
Typical
Max.
Unit
Remarks
θ
J-B
Junction-to-Board
thermal resistance
12.8 °C/W
Part of the Two-Resistor Compact Thermal
Model of the module, defined according to
JEDEC standard no. 51 and/or JEDEC standard
no. 15
θ
J-Ctop
Junction-to-Case
thermal resistance
17.5 °C/W
Part of the Two-Resistor Compact Thermal
Model of the module, defined according to
JEDEC standard no. 51 and/or JEDEC standard
no. 15
Symbol
Parameter
Min.
Typical
Max.
Unit
Remarks
θ
J-A
Junction-to-Ambient
thermal resistance
20.9 °C/W
Standardized thermal figure, defined according
to JEDEC standard no. 51
4.2 Operating conditions
☞ Unless otherwise indicated, all operating condition specifications are at an ambient temperature
of 25 °C.
⚠ Operation beyond the operating conditions is not recommended and extended exposure beyond
them may affect device reliability.
4.2.1 Operating temperature range
Table 10: Environmental conditions
4.2.2 Module thermal parameters
Table 11: Two-Resistor Compact Thermal Model of the TOBY-L4 series module
Table 12: Junction-to-Ambient thermal resistance of the TOBY-L4 series module
UBX-16009856 - R09 Electrical specifications Page 30 of 58
C1-Public
TOBY-L4 series - Data sheet
Pin name
Parameter
Min.
Typical
Max.
Unit
VCC
Module supply normal operating input voltage21
3.40
3.80
4.40 V
Module supply extended operating input voltage22
3.00
3.80
4.50 V V_BCKP
Real Time Clock supply input voltage
1.60 3.40
V
Real Time Clock supply average current consumption,
at V_BCKP = 2.5 V
2 5
µA
Pin name
Parameter
Min.
Typical
Max.
Unit
VSIM
SIM supply output voltage with external 1.8 V SIM
1.80 V
SIM supply output voltage with external 3.0 V SIM
2.90 V
V_BCKP
Real Time Clock supply output voltage
2.50 V Real Time Clock supply output current capability
0.5
mA
V_INT
Generic Digital Interfaces supply output voltage
1.80 V
Generic Digital Interfaces supply output current capability
70
mA
V_ETH
RGMII interface supply output voltage
3.30 V
RGMII interface supply output current capability
100
mA
V_MMC
eMMC interface supply output voltage
1.80 V eMMC interface supply output voltage
2.85 V eMMC interface supply output current capability
250
mA
21
22
4.2.3 Supply/power pins
Table 13: Input characteristics of the Supply/Power pins
Table 14: Output characteristics of the Supply/Power pins
Input voltage at VCC must be above the normal operating range minimum limit to switch-on the module. RF performance
may be affected when the input voltage at VCC is outside the herein stated normal operating range limits, though the module
is still fully functional when the input voltage at VCC is inside the extended operating range limits.
Ensure that input voltage at VCC never drops below the extended operating range minimum limit during module operation:
the cellular module may switch-off when the VCC voltage value drops below the herein stated extended operating range
minimum limit.
UBX-16009856 - R09 Electrical specifications Page 31 of 58
C1-Public
TOBY-L4 series - Data sheet
Mode
Condition
Tx power
Min
Typ23
Max24
Unit
Power Off Mode
Average current with module switched off,
VCC supply present
-- 0.1 mA
Idle-Mode
Base current, equivalent to Airplane Mode,
in Low Power mode, with interfaces not used
-- 2.1 mA Base current, equivalent to Airplane Mode,
in Low Power mode, with USB suspended, RGMII not used
-- 3.1 mA
Base current, equivalent to Airplane Mode,
in Low Power mode, with USB not used, RGMII suspended
-- 16.9 mA
Cyclic Idle/Active-Mode
Average current in Discontinuous Reception,
in Low Power mode, with interfaces not used
-- 3.9 mA
Average current in Discontinuous Reception,
in Low Power mode, with USB suspended, RGMII not used
-- 4.9 mA
Average current in Discontinuous Reception,
in Low Power mode, with USB not used, RGMII suspended
-- 18.7 mA
Active-Mode
Average current in Discontinuous Reception,
outside Low Power mode, with interfaces not suspended
-- 136 mA
2G Connected Mode
Average current during a 1-slot GMSK call,
with interfaces suspended
Minimum
0.11 A
Average current during a 1-slot GMSK call,
with interfaces not suspended
Minimum
0.25 A
Average current during a 1-slot GMSK call,
with interfaces not suspended
Maximum
0.38 A
Pulse current25 during a 1-slot GMSK Tx burst,
with interfaces not suspended
Maximum
1.90
2.50 A 3G Connected Mode
Average current during 3G call, with Low data rate,
with interfaces suspended
0 dBm
0.10 A Average current during 3G call, with Low data rate,
with interfaces not suspended
0 dBm
0.23 A
Average current during 3G call, with Low data rate,
with interfaces not suspended
Maximum
0.65 A
LTE Connected Mode
Average current during LTE call, with Low data rate,
with interfaces suspended
0 dBm
0.14 A
Average current during LTE call, with Low data rate,
with interfaces not suspended
0 dBm
0.27 A
Average current during LTE call, with Low data rate,
with interfaces not suspended
Maximum
0.69 A
Average current25 during LTE call, with Max data rate,
with interfaces not suspended
Maximum
1.20
1.50
A
Average current25 during LTE call, with Max data rate,
with interfaces not suspended, with Max uCPU usage
Maximum
1.50
1.90
A
23
24
25
4.2.4 Current consumption
Table 15: Module VCC current consumption
Typical values with a matched antenna.
Maximum values with a mismatched antenna.
Figure recommended to be considered with adequate safe design margin to properly dimension the power supply capability.
UBX-16009856 - R09 Electrical specifications Page 32 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Max.
Unit
Remarks
Frequency range
FDD Band 12 (700 MHz)
Uplink
699
716
MHz
Module transmit
Downlink
729
746
MHz
Module receive
Frequency range
FDD Band 29 (700 MHz)
Uplink
1850
1910
MHz
Module transmit (carrier aggregation using band 2)
Downlink
717
728
MHz
Module receive
Frequency range
FDD Band 28 (750 MHz)
Uplink
703
748
MHz
Module transmit
Downlink
758
803
MHz
Module receive
Frequency range
FDD Band 13 (750 MHz)
Uplink
777
787
MHz
Module transmit
Downlink
746
756
MHz
Module receive
Frequency range
FDD Band 20 (800 MHz)
Uplink
832
862
MHz
Module transmit
Downlink
791
821
MHz
Module receive
Frequency range
FDD Band 5 (850 MHz)
Uplink
824
849
MHz
Module transmit
Downlink
869
894
MHz
Module receive
Frequency range
FDD Band 19 (850 MHz)
Uplink
830
845
MHz
Module transmit
Downlink
875
890
MHz
Module receive
Frequency range
FDD Band 8 (900 MHz)
Uplink
880
915
MHz
Module transmit
Downlink
925
960
MHz
Module receive
Frequency range
FDD Band 4 (1700 MHz)
Uplink
1710
1755
MHz
Module transmit
Downlink
2110
2155
MHz
Module receive
Frequency range
FDD Band 3 (1800 MHz)
Uplink
1710
1785
MHz
Module transmit
Downlink
1805
1880
MHz
Module receive
Frequency range
FDD Band 9 (1800 MHz)
Uplink
1749.9
1784.9
MHz
Module transmit
Downlink
1844.9
1879.9
MHz
Module receive
Frequency range
FDD Band 2 (1900 MHz)
Uplink
1850
1910
MHz
Module transmit
Downlink
1930
1990
MHz
Module receive
Frequency range
FDD Band 25 (1900 MHz)
Uplink
1850
1915
MHz
Module transmit
Downlink
1930
1995
MHz
Module receive
Frequency range
TDD Band 39 (1900 MHz)
Uplink
1880
1920
MHz
Module transmit
Downlink
1880
1920
MHz
Module receive
Frequency range
FDD Band 1 (2100 MHz)
Uplink
1920
1980
MHz
Module transmit
Downlink
2110
2170
MHz
Module receive
Frequency range
TDD Band 40 (2300 MHz)
Uplink
2300
2400
MHz
Module transmit
Downlink
2300
2400
MHz
Module receive
Frequency range
TDD Band 41 (2500 MHz)
Uplink
2555
2655
MHz
Module transmit
Downlink
2555
2655
MHz
Module receive
Frequency range
TDD Band 38 (2600 MHz)
Uplink
2570
2620
MHz
Module transmit
Downlink
2570
2620
MHz
Module receive
Frequency range
FDD Band 7 (2600 MHz)
Uplink
2500
2570
MHz
Module transmit
Downlink
2620
2690
MHz
Module receive
4.2.5 LTE RF characteristics
The LTE bands supported by each TOBY-L4 series module are defined in Table 3, while Table 16
describes the Tx / Rx frequencies for each LTE band according to 3GPP TS 36.521-1 [6].
Table 16: LTE operating RF frequency bands
UBX-16009856 - R09 Electrical specifications Page 33 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
Band 12 (700 MHz)
–111.0
dBm
Channel bandwidth = 1.4 MHz
–105.0
dBm
Channel bandwidth = 5 MHz
–102.5
dBm
Channel bandwidth = 10 MHz
Receiver input sensitivity
Band 13 (750 MHz)
–104.5
dBm
Channel bandwidth = 5 MHz
–102.0
dBm
Channel bandwidth = 10 MHz
Receiver input sensitivity
Band 5 (850 MHz)
–111.5
dBm
Channel bandwidth = 1.4 MHz
–105.5
dBm
Channel bandwidth = 5 MHz
–103.0
dBm
Channel bandwidth = 10 MHz
Receiver input sensitivity
Band 2 (1900 MHz)
–110.0
dBm
Channel bandwidth = 1.4 MHz
–104.0
dBm
Channel bandwidth = 5 MHz
–98.5
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 4 (1700 MHz)
–110.5
dBm
Channel bandwidth = 1.4 MHz
–104.5
dBm
Channel bandwidth = 5 MHz
–99.0
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 7 (2600 MHz)
–103.0
dBm
Channel bandwidth = 5 MHz
–97.5
dBm
Channel bandwidth = 20 MHz
Condition: 50 source, Throughput > 95%, dual receiver, QPSK modulation, Other settings as per 3GPP TS 36.521-1 [6]
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
Band 20 (800 MHz)
–105.5
dBm
Channel bandwidth = 5 MHz
–100.0
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 8 (900 MHz)
–111.0
dBm
Channel bandwidth = 1.4 MHz
–105.0
dBm
Channel bandwidth = 5 MHz
–102.5
dBm
Channel bandwidth = 10 MHz
Receiver input sensitivity
Band 3 (1800 MHz)
–109.5
dBm
Channel bandwidth = 1.4 MHz
–104.0
dBm
Channel bandwidth = 5 MHz
–98.5
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 1 (2100 MHz)
–103.5
dBm
Channel bandwidth = 5 MHz
–98.0
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 38 (2600 MHz)
–103.0
dBm
Channel bandwidth = 5 MHz
–97.5
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 7 (2600 MHz)
–102.0
dBm
Channel bandwidth = 5 MHz
–96.5
dBm
Channel bandwidth = 20 MHz
Condition: 50 source, Throughput > 95%, dual receiver, QPSK modulation, Other settings as per 3GPP TS 36.521-1 [6]
TOBY-L4 series modules include an LTE-FDD / LTE-TDD Power Class 3 transmitter (see Table 2) and
LTE-FDD / LTE-TDD receivers with RF characteristics according to 3GPP TS 36.521-1 [6]. Conducted
receiver sensitivity performance is described in Table 17, Table 18, Table 19 and Table 20.
Table 17: TOBY-L4006 LTE receiver sensitivity performance
Table 18: TOBY-L4106 LTE receiver sensitivity performance
UBX-16009856 - R09 Electrical specifications Page 34 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
Band 28 (750 MHz)
–107.0
dBm
Channel bandwidth = 3 MHz
–105.0
dBm
Channel bandwidth = 5 MHz
–99.5
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 5 / 19 (850 MHz)
–111.5
dBm
Channel bandwidth = 1.4 MHz
–105.5
dBm
Channel bandwidth = 5 MHz
–103.0
dBm
Channel bandwidth = 10 MHz
Receiver input sensitivity
Band 8 (900 MHz)
–111.0
dBm
Channel bandwidth = 1.4 MHz
–105.0
dBm
Channel bandwidth = 5 MHz
–102.5
dBm
Channel bandwidth = 10 MHz
Receiver input sensitivity
Band 3 / 9 (1800 MHz)
–109.5
dBm
Channel bandwidth = 1.4 MHz
–104.0
dBm
Channel bandwidth = 5 MHz
–98.5
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 1 (2100 MHz)
–103.0
dBm
Channel bandwidth = 5 MHz
–97.5
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 7 (2600 MHz)
–102.0
dBm
Channel bandwidth = 5 MHz
–96.5
dBm
Channel bandwidth = 20 MHz
Condition: 50 source, Throughput > 95%, dual receiver, QPSK modulation, Other settings as per 3GPP TS 36.521-1 [6]
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
Band 3 (1800 MHz)
–110.0
dBm
Channel bandwidth = 1.4 MHz
–104.0
dBm
Channel bandwidth = 5 MHz
–98.5
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 39 (1900 MHz)
–104.5
dBm
Channel bandwidth = 5 MHz
–99.0
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 1 (2100 MHz)
–104.5
dBm
Channel bandwidth = 5 MHz
–99.0
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 40 (2300 MHz)
–104.0
dBm
Channel bandwidth = 5 MHz
–98.5
dBm
Channel bandwidth = 20 MHz
Receiver input sensitivity
Band 41 (2500 MHz)
–103.0
dBm
Channel bandwidth = 5 MHz
–97.0
dBm
Channel bandwidth = 20 MHz
Condition: 50 source, Throughput > 95%, dual receiver, QPSK modulation, Other settings as per 3GPP TS 36.521-1 [6]
Table 19: TOBY-L4206 LTE receiver sensitivity performance
Table 20: TOBY-L4906 LTE receiver sensitivity performance
UBX-16009856 - R09 Electrical specifications Page 35 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Max.
Unit
Remarks
Frequency range
Band 6 (800 MHz)
Uplink
830
840
MHz
Module transmit
Downlink
875
885
MHz
Module receive
Frequency range
Band 19 (800 MHz)
Uplink
830
845
MHz
Module transmit
Downlink
875
890
MHz
Module receive
Frequency range
Band 5 (850 MHz)
Uplink
824
849
MHz
Module transmit
Downlink
869
894
MHz
Module receive
Frequency range
Band 8 (900 MHz)
Uplink
880
915
MHz
Module transmit
Downlink
925
960
MHz
Module receive
Frequency range
Band 4 (AWS, 1700 MHz)
Uplink
1710
1755
MHz
Module transmit
Downlink
2110
2155
MHz
Module receive
Frequency range
Band 2 (1900 MHz)
Uplink
1850
1910
MHz
Module transmit
Downlink
1930
1990
MHz
Module receive
Frequency range
Band 1 (2100 MHz)
Uplink
1920
1980
MHz
Module transmit
Downlink
2110
2170
MHz
Module receive
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
Band 5 (850 MHz)
–115.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Receiver input sensitivity
Band 2 (1900 MHz)
–113.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Receiver input sensitivity
Band 4 (1700 MHz)
–113.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Condition: 50 source, dual receiver, other settings as per 3GPP TS 34.121-1 [7]
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
Band 8 (900 MHz)
–115.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Receiver input sensitivity
Band 1 (2100 MHz)
–114.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Condition: 50 source, dual receiver, other settings as per 3GPP TS 34.121-1 [7]
4.2.6 3G RF characteristics
The 3G bands supported by each TOBY-L4 series module are defined in Table 3, while Table 21
describes the Tx / Rx frequencies for each 3G band compliant with 3GPP TS 34.121-1 [7].
Table 21: 3G operating RF frequency bands
TOBY-L4 series modules include a W-CDMA (FDD) Power Class 3 transmitter (see Table 2) and
receivers with RF characteristics compliant with 3GPP TS 34.121-1 [7]. Conducted receiver sensitivity
performance is described in Table 22, Table 23, Table 24 and Table 25.
Table 22: TOBY-L4006 3G receiver sensitivity performance
Table 23: TOBY-L4106 3G receiver sensitivity performance
UBX-16009856 - R09 Electrical specifications Page 36 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
Band 5 / 6 / 19 (850 MHz)
–115.5
dBm
Downlink RF level for RMC @ BER < 0.1%
Receiver input sensitivity
Band 8 (900 MHz)
–115.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Receiver input sensitivity
Band 1 (2100 MHz)
–113.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Condition: 50 source, dual receiver, other settings as per 3GPP TS 34.121-1 [7]
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
Band 8 (900 MHz)
–115.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Receiver input sensitivity
Band 1 (2100 MHz)
–114.0
dBm
Downlink RF level for RMC @ BER < 0.1%
Condition: 50 source, dual receiver, other settings as per 3GPP TS 34.121-1 [7]
Parameter
Min.
Max.
Unit
Remarks
Frequency range
GSM 850
Uplink
824
849
MHz
Module transmit
Downlink
869
894
MHz
Module receive
Frequency range
E-GSM 900
Uplink
880
915
MHz
Module transmit
Downlink
925
960
MHz
Module receive
Frequency range
DCS 1800
Uplink
1710
1785
MHz
Module transmit
Downlink
1805
1880
MHz
Module receive
Frequency range
PCS 1900
Uplink
1850
1910
MHz
Module transmit
Downlink
1930
1990
MHz
Module receive
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
GSM 850
–110.0
dBm
Downlink RF level @ BER Class II < 2.4%
Receiver input sensitivity
PCS 1900
–107.0
dBm
Downlink RF level @ BER Class II < 2.4%
Condition: 50 source, other settings as per 3GPP TS 51.010-1 [8]
Table 24: TOBY-L4206 3G receiver sensitivity performance
Table 25: TOBY-L4906 3G receiver sensitivity performance
4.2.7 2G RF characteristics
The 2G bands supported by each TOBY-L4 series module are defined in Table 3, while Table 26
describes the Tx / Rx frequencies for each 2G band according to 3GPP TS 51.010-1 [8].
Table 26: 2G operating RF frequency bands
TOBY-L4 series modules include a GMSK Power Class 4 transmitter for GSM/E-GSM bands, a GMSK
Power Class 1 transmitter for DCS/PCS bands, an 8-PSK Power Class E2 transmitter for all 2G bands
(see Table 2), and related 2G receivers with RF characteristics compliant with 3GPP TS 51.010-1 [8].
Conducted receiver sensitivity performance is described in Table 27, Table 28, Table 29 and Table 30.
Table 27: TOBY-L4006 2G receiver sensitivity performance
UBX-16009856 - R09 Electrical specifications Page 37 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
E-GSM 900
–110.5
dBm
Downlink RF level @ BER Class II < 2.4%
Receiver input sensitivity
DCS 1800
–109.5
dBm
Downlink RF level @ BER Class II < 2.4%
Condition: 50 source, other settings as per 3GPP TS 51.010-1 [8]
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
GSM 850 / E-GSM 900
–110.5
dBm
Downlink RF level @ BER Class II < 2.4%
Receiver input sensitivity
DCS 1800 / PCS 1900
–108.5
dBm
Downlink RF level @ BER Class II < 2.4%
Condition: 50 source, other settings as per 3GPP TS 51.010-1 [8]
Parameter
Min.
Typical
Max.
Unit
Remarks
Receiver input sensitivity
E-GSM 900
–110.0
dBm
Downlink RF level @ BER Class II < 2.4%
Receiver input sensitivity
DCS 1800
–108.5
dBm
Downlink RF level @ BER Class II < 2.4%
Condition: 50 source, other settings as per 3GPP TS 51.010-1 [8]
Parameter
Min.
Typical
Max.
Unit
Remarks
Internal supply for
PWR_ON input
1.3 V
Internal 1.3 V supply rail
Low-level input
–0.3 0.45 V
High-level input
0.85 1.6 V
Pull-up resistance
35
k
Internal pull-up to 1.3 V supply rail
PWR_ON low time
35 250
ms
Low time to trigger module switch-on
PWR_ON low time
500 1000
ms
Low time to trigger module normal graceful switch-off
PWR_ON low time
2000
ms
Low time to trigger module abrupt emergency switch-off
Parameter
Min.
Typical
Max.
Unit
Remarks
Internal supply for
RESET_N input
1.8 V
Digital I/O Interfaces supply (V_INT)
Low-level input
0.0 0.6 V
High-level input
1.2 1.8 V
Pull-up resistance
100
k
Internal pull-up to V_INT
RESET_N low time
50
ms
Low time to trigger module abrupt hardware reset (reboot)
Table 28: TOBY-L4106 2G receiver sensitivity performance
Table 29: TOBY-L4206 2G receiver sensitivity performance
Table 30: TOBY-L4906 2G receiver sensitivity performance
4.2.8 PWR_ON pin
Table 31: PWR_ON pin characteristics
4.2.9 RESET_N pin
Table 32: RESET_N pin characteristics
UBX-16009856 - R09 Electrical specifications Page 38 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Typical
Max.
Unit
Remarks
Low-level input
–0.30
0.36 V SIM supply = 1.8 V
–0.30
0.58 V SIM supply = 2.9 V
High-level input
1.26 2.10 V SIM supply = 1.8 V
2.03 3.20 V SIM supply = 2.9 V
Low-level output
0.00
0.36 V SIM supply = 1.8 V, Max value at IOL = +1.0 mA
0.00
0.58 V SIM supply = 2.9 V, Max value at IOL = +1.0 mA
High-level output
1.26
1.80 V
SIM supply = 1.8 V, Max value at IOL = +1.0 mA
2.03
2.90 V
SIM supply = 2.9 V, Max value at IOL = +1.0 mA
Input / Output leakage current
0.7
µA
0.2V < VIN < 3.2V
Clock frequency on SIM clock
3.9 MHz
Internal pull-up resistor on SIM data
4.7
k
Internal pull-up to SIM supply
Parameter
Min.
Typical
Max.
Unit
Remarks
Baud rate
5
Gbit/s
Transmitter differential peak-to-peak voltage
1.0 V Transmitter de-emphasis
3.5 dB Transmitter differential characteristic impedance
90
Receiver differential peak-to-peak voltage
1.2 V
Receiver differential sensitivity
0.1 V
Receiver differential characteristic impedance
90
Parameter
Min.
Typical
Max.
Unit
Remarks
Baud rate
480 Mbit/s
High-speed squelch detection threshold
100 150
mV
Input differential signal amplitude
High speed disconnect detection threshold
525 625
mV
Input differential signal amplitude
High-speed data signaling input
common mode voltage range
–50 500
mV
High-speed idle output level
–10 10
mV High-speed data signaling output high level
360 440
mV
High-speed data signaling output low level
–10 10
mV
4.2.10 SIM pins
SIM pins are dedicated for connecting external SIM cards/chips. The electrical characteristics fulfill
the regulatory specification requirements. The values in Table 33 are for information only.
Table 33: SIM pins characteristics
4.2.11 USB pins
USB Super-Speed 3.0 differential transmitter data lines (USB_SSTX+ / USB_SSTX–) and USB SuperSpeed 3.0 differential receiver data lines (USB_SSRX+ / USB_SSRX–) comply with the USB Revision
3.0 specification [10]. The values in Table 34 are for information only.
Table 34: USB Super-Speed 3.0 pin characteristics
USB High-Speed 2.0 differential transceiver data lines (USB_D+ / USB_D–) are compliant with the
Universal Serial Bus revision 2.0 specification [11]. The values in Table 35 are for information only.
Table 35: USB High-Speed 2.0 pins characteristics
UBX-16009856 - R09 Electrical specifications Page 39 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min.
Typical
Max.
Unit
Remarks
VUSB_DET pin, High-level input
3.00
5.00
5.25 V
Parameter
Min
Typical
Max
Unit
Remarks
Internal supply for DDC domain
1.80 V
Digital I/O Interfaces supply (V_INT)
Low-level input
–0.30
0.54 V
High-level input
1.26 2.00 V
Low-level output
0.00
0.36 V Max value at IOL = +3.0 mA
Clock frequency
100
kHz
I2C-bus standard-mode
400
kHz
I2C-bus fast-mode
Parameter
Min
Typical
Max
Unit
Remarks
Internal supply for ETH domain
3.30 V Low-level input
–0.30
0.80 V
High-level input
2.60 3.60 V
Low-level output
0.00 V
High-level output
3.30 V
Input / Output leakage current
10
µA
Pad in tri-state
VUSB_DET input pin for VBUS USB supply sense is compliant with USB Revision 3.0 specification [10]
and USB revision 2.0 specification [11]. The values in Table 36 are for information only.
Table 36: VUSB_DET pin characteristics
4.2.12 DDC (I2C) pins
The DDC (I2C) lines are compliant to the I2C-bus standard-mode and fast-mode specification. See the
I2C-bus specification [12] for detailed electrical characteristics. The values in Table 37 are for
information only.
Table 37: DDC (I2C) pin characteristics
4.2.13 RGMII pins
The Reduced Gigabit Media-Independent Interface complies with the RGMII version 1.3
specification [13]. The values in Table 38 are for information only.
Table 38: ETH pin characteristics
UBX-16009856 - R09 Electrical specifications Page 40 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min
Typical
Max
Unit
Remarks
Internal supply for MMC domain
1.80 V
eMMC interface supply (V_MMC)
2.85 V
eMMC interface supply (V_MMC)
Low-level input
–0.30
0.63 V V_MMC = 1.80 V
–0.30
0.71 V V_MMC = 2.85V
High-level input
1.17 2.10 V V_MMC = 1.80 V
1.78 3.15 V V_MMC = 2.85V
Low-level output
0.00 V
V_MMC = 1.80 V
0.00 V
V_MMC = 2.85V
High-level output
1.80 V
V_MMC = 1.80 V
2.85 V
V_MMC = 2.85V
Input / Output leakage current
0.7
µA
0.2V < VIN < 2.0V
Parameter
Min
Typical
Max
Unit
Remarks
Internal supply for GDI domain
1.80 V
Digital I/O Interfaces supply (V_INT)
Low-level input
–0.20
0.36 V
High-level input
1.26 2.00 V
Low-level output
0.00 V High-level output
1.80 V Input / Output leakage current
0.7
µA
0.2V < VIN < 2.0V
4.2.14 eMMC pins
The embedded Multi-Media Card interface complies with the JESD84-B451 Embedded Multimedia
Card (eMMC) electrical standard 4.51 [14]. The values in Table 39 are for information only.
Table 39: MMC pin characteristics
4.2.15 Generic digital interfaces pins
Table 40: GDI pin characteristics
UBX-16009856 - R09 Electrical specifications Page 41 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Description
Min
Typical
Max
Unit
Remarks
1/T1
I2S_WA frequency
8.000
kHz
<I2S_sample_rate>=0
11.025
kHz
<I2S_sample_rate>=1
12.000
kHz
<I2S_sample_rate>=2
16.000
kHz
<I2S_sample_rate>=3
22.050
kHz
<I2S_sample_rate>=4
24.000
kHz
<I2S_sample_rate>=5
32.000
kHz
<I2S_sample_rate>=6
44.100
kHz
<I2S_sample_rate>=7
48.000
kHz
<I2S_sample_rate>=8
96.000
kHz
<I2S_sample_rate>=9
192.000
kHz
<I2S_sample_rate>=10
1/T2
I2S_CLK frequency
32 1/T1
<I2S_mode> = 2,..,13
T3
I2S_TXD invalid before I2S_CLK edge
24
ns
<I2S_mode> = 2,..,13
T4
I2S_TXD valid after I2S_CLK edge
32
ns
<I2S_mode> = 2,..,13
T5
I2S_RXD setup time before I2S_CLK edge
60
ns
<I2S_mode> = 2,..,13
T6
I2S_RXD hold time after I2S_CLK edge
10
ns
<I2S_mode> = 2,..,13
Parameter
Description
Min
Typical
Max
Unit
Remarks
1/T1
I2S_WA frequency
8.000
kHz
<I2S_sample_rate>=0
11.025
kHz
<I2S_sample_rate>=1
12.000
kHz
<I2S_sample_rate>=2
16.000
kHz
<I2S_sample_rate>=3
22.050
kHz
<I2S_sample_rate>=4
24.000
kHz
<I2S_sample_rate>=5
32.000
kHz
<I2S_sample_rate>=6
44.100
kHz
<I2S_sample_rate>=7
48.000
kHz
<I2S_sample_rate>=8
96.000
kHz
<I2S_sample_rate>=9
192.000
kHz
<I2S_sample_rate>=10
1/T2
I2S_CLK frequency
32
1/T1
<I2S_mode> = 2,..,13
T3
I2S_TXD invalid before I2S_CLK edge
12
ns
<I2S_mode> = 2,..,13
T4
I2S_TXD valid after I2S_CLK edge
79
ns
<I2S_mode> = 2,..,13
T5
I2S_RXD setup time before I2S_CLK edge
22
ns
<I2S_mode> = 2,..,13
T6
I2S_RXD hold time after I2S_CLK edge
24
ns
<I2S_mode> = 2,..,13
4.2.15.1 AC characteristics of I2S pins
Table 41: AC characteristics of digital audio interface (I2S) pins in Normal I2S mode (long synchronization signal), Master role
Table 42: AC characteristics of digital audio interface (I2S) pins in Normal I2S mode (long synchronization signal), Slave role
UBX-16009856 - R09 Electrical specifications Page 42 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Description
Min
Typical
Max
Unit
Remarks
1/T1
I2S_WA frequency
8.000
kHz
<I2S_sample_rate>=0
11.025
kHz
<I2S_sample_rate>=1
12.000
kHz
<I2S_sample_rate>=2
16.000
kHz
<I2S_sample_rate>=3
22.050
kHz
<I2S_sample_rate>=4
24.000
kHz
<I2S_sample_rate>=5
32.000
kHz
<I2S_sample_rate>=6
44.100
kHz
<I2S_sample_rate>=7
48.000
kHz
<I2S_sample_rate>=8
96.000
kHz
<I2S_sample_rate>=9
192.000
kHz
<I2S_sample_rate>=10
1/T2
I2S_CLK frequency
18 1/T1
<I2S_mode> = 0
17 1/T1
<I2S_mode> = 1
T3
I2S_WA high begin after I2S_CLK high begin
-24 32
ns
<I2S_mode> = 0, 1
T4
I2S_WA high end after I2S_CLK low end
-24 32
ns
<I2S_mode> = 0, 1
T5
I2S_TXD invalid before I2S_CLK low end
24
ns
<I2S_mode> = 0, 1
T6
I2S_TXD valid after I2S_CLK high begin
22
ns
<I2S_mode> = 0, 1
T7
I2S_RXD setup time before I2S_CLK high end
60
ns
<I2S_mode> = 0, 1
T8
I2S_RXD hold time after I2S_CLK low begin
12
ns
<I2S_mode> = 0, 1
Parameter
Description
Min
Typical
Max
Unit
Remarks
1/T1
I2S_WA frequency
8.000
kHz
<I2S_sample_rate>=0
11.025
kHz
<I2S_sample_rate>=1
12.000
kHz
<I2S_sample_rate>=2
16.000
kHz
<I2S_sample_rate>=3
22.050
kHz
<I2S_sample_rate>=4
24.000
kHz
<I2S_sample_rate>=5
32.000
kHz
<I2S_sample_rate>=6
44.100
kHz
<I2S_sample_rate>=7
48.000
kHz
<I2S_sample_rate>=8
96.000
kHz
<I2S_sample_rate>=9
192.000
kHz
<I2S_sample_rate>=10
1/T2
I2S_CLK frequency
18
1/T1
<I2S_mode> = 0
17
1/T1
<I2S_mode> = 1
T3
I2S_WA high begin before I2S_CLK low begin
37
ns
<I2S_mode> = 0, 1
T4
I2S_WA low begin before I2S_CLK low begin
37
ns
<I2S_mode> = 0, 1
T5
I2S_TXD invalid before I2S_CLK rising edge
12
ns
<I2S_mode> = 0, 1
T6
I2S_TXD valid after I2S_CLK rising edge
79
ns
<I2S_mode> = 0, 1
T7
I2S_RXD setup time before I2S_CLK falling edge
22
ns
<I2S_mode> = 0, 1
T8
I2S_RXD hold time after I2S_CLK falling edge
24
ns
<I2S_mode> = 0, 1
Table 43: AC characteristics of digital audio interface (I2S) pins in PCM mode (short synchronization signal), Master role
Table 44: AC characteristics of digital audio interface (I2S) pins in PCM mode (short synchronization signal), Slave role
UBX-16009856 - R09 Electrical specifications Page 43 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Min
Typical
Max
Unit
Remarks
Microphone supply output voltage
2.2 V
Provided by MIC_BIAS output pin
Microphone supply output current
4.0
mA
Provided by MIC_BIAS output pin
Load capacitance
680
pF
Proper internal bypass capacitor already
provided to guarantee stable operations:
external capacitor directly connected to
MIC_BIAS pin not required, but can be
provided after a proper series resistor.
Load resistance
1
k
Microphone reference ground
0 V MIC_GND pin is internally connected to ground
Parameter
Min
Typical
Max
Unit
Remarks
Differential input voltage
1.6
Vpp
Full scale differential voltage
Differential input resistance
25
k
Common mode DC voltage
0.5 V
No internal DC blocking capacitor
Input capacitance
5 10
pF
No internal DC blocking capacitor
Dynamic range
72
dB FS CCIR-RMS
Gain stage = 0 dB,
Bandwidth 300-8000 Hz,
Input signal 0.8 Vpp differential
Total Harmonic Distortion plus
Noise (THD+N)
–55
dB
Reference signal –10 dB FS
Power supply rejection
45
66 dB
Parameter
Min
Typical
Max
Unit
Remarks
Maximum differential output
voltage
3.3
3.7
4.1
Vpp
Full scale differential open circuit voltage
Common mode output voltage
1.25 V
No internal DC blocking capacitor
Output power
50
mW
Load = 16…32
Output current limit
200
mA Output load resistance
14
Output load capacitance
250
pF
Between output pins and GND
Dynamic range
75
80 dB FS CCIR-RMS
Load = 16 , Gain stage = +6 dB
Total Harmonic Distortion plus
Noise (THD+N)
–50
–60 dB
Load = 16 , Gain stage = +6 dB,
Reference signal –10 dB FS
Parameter
Min.
Typ.
Max.
Unit
Remarks
Resolution
12 Bits Input voltage range
0 1.2 V
Input resistance
102
k
With respect to GND
4.2.16 Analog audio pins
Table 45: Microphone analog supply output (MIC_BIAS/MIC_GND) characteristics
Table 46: Differential analog audio transmit paths input (MIC1_P/MIC1_N and MIC2_P/MIC2_N) characteristics
Table 47: Differential analog audio receive path output (SPK_P, SPK_N) characteristics
4.2.17 ADC pins
Table 48: Analog to Digital Converter input pin (ADC1, ADC2) characteristics
UBX-16009856 - R09 Electrical specifications Page 44 of 58
C1-Public
TOBY-L4 series - Data sheet
C
I
A
G1 H1 J1D F
K M1 M1 M2
P2
B
G1
H1
J1
H2
J2
J2
H2
ANT1 pin
O
O
L
N
H2
J2
J2
H2
ANT2 pin
M1 M1 M3
I
I
I
O
J1
J1
J1
E
P3
F
P1
I
H1
O
Pin 1
Indicator
M1
H1
G2
G2
Parameter
Description
Typical
Tolerance
A Module height [mm]
35.6
(1401.6 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
B
Module width [mm]
24.8
(976.4 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
C
Module thickness [mm]
2.6
(102.4 mil)
+0.27/–0.17
(+10.6/–6.7 mil)
D
Horizontal edge to lateral pin pitch [mm]
2.4
(94.5 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
E
Vertical edge to lateral pin pitch [mm]
2.25
(88.6 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
F
Edge to lateral pin pitch [mm]
1.45
(57.1 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
G1
Lateral pin to pin pitch [mm]
1.1
(43.3 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
G2
Lateral pin to pin pitch [mm]
2.0
(78.7 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
H1
Lateral pin height [mm]
0.8
(31.5 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
H2
Lateral pin close to ANT1 and ANT2 height [mm]
0.9
(35.4 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
I
Lateral pin width [mm]
1.5
(59.1 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
J1
Lateral pin to pin distance [mm]
0.3
(11.8 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
J2
Lateral pin to pin close to ANT distance [mm]
0.2
(7.9 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
K
Horizontal edge to central pin pitch [mm]
3.15
(124.0 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
L
Vertical edge to central pin pitch [mm]
7.15
(281.5 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
M1
Central pin to pin horizontal pitch [mm]
1.8
(70.9 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
M2
Central pin to pin horizontal pitch [mm]
3.4
(133.9 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
5 Mechanical specifications
Figure 4: TOBY-L4 series dimensions (bottom and side views)
UBX-16009856 - R09 Mechanical specifications Page 45 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Description
Typical
Tolerance
M3
Central pin to pin horizontal pitch [mm]
2.25
(88.6 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
N
Central pin to pin vertical pitch [mm]
2.1
(82.7 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
O
Central pin height and width [mm]
1.1
(43.3 mil)
+0.02/–0.02
(+0.8/–0.8 mil)
P1
Horizontal edge to corner pin pitch [mm]
1.1
(43.3 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
P2
Horizontal edge to corner pin pitch [mm]
1.25
(49.2 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
P3
Horizontal edge to corner pin pitch [mm]
2.85
(112.2 mil)
+0.20/–0.20
(+7.9/–7.9 mil)
Weight
Module weight [g]
4.8
Table 49: TOBY-L4 series dimensions
☞ The module height tolerance +/– 0.20 mm may be exceeded close to the corners of the PCB due to
cutting process: in worst case the height could be + 0.40 mm longer than the typical value.
☞ For guidelines regarding footprint and paste mask, see the TOBY-L4 series system integration
manual [2].
UBX-16009856 - R09 Mechanical specifications Page 46 of 58
C1-Public
TOBY-L4 series - Data sheet
Certification Scheme
TOBY-L4006
TOBY-L4106
TOBY-L4206
TOBY-L4906
GCF (Global Certification Forum)
•
PTCRB (PCS Type Certification Review Board)
•
CE (European Conformity)
• •
•
FCC (US Federal Communications Commission)
FCC identification number
•
XPY1EHQ37NN
ISED (Innovation Science Economic Development Canada)26
ISED certification number
•
8595A-1EHQ37NN
CCC (China Compulsory Certification)
•
GITEKI (Japanese Regulatory Certification)
•
RCM (Australian Regulatory Certification)
•
AT&T (US network operator)
•
T-Mobile (US network operator)
•
NTT DoCoMo (Japanese network operator)
•
26
6 Qualification and approvals
6.1 Reliability tests
Tests for product family qualifications according to ISO 16750 “Road vehicles – Environmental
conditions and testing for electrical and electronic equipment”, and appropriate standards.
Extended qualification for automotive grade products.
6.2 Approvals
TOBY-L4 series modules comply with the directive 2011/65/EU of the European Parliament and the
Council on the Restriction of Use of certain Hazardous Substances in Electrical and Electronic
Equipment (EU RoHS 2) and its amendment directive (EU) 2015/863 (EU RoHS 3).
TOBY-L4 series modules are RoHS 3 compliant.
No natural rubbers, hygroscopic materials, or materials containing asbestos are employed.
Table 50 summarizes the main approvals achieved or planned for TOBY-L4 series modules.
Table 50: TOBY-L4 series main certification approvals summary
For the complete list of approvals and for specific details on all country and network operators’
certifications, please contact the u-blox office or sales representative nearest you (for complete
contact information, visit us at www.u-blox.com).
Formerly known as IC (Industry Canada)
UBX-16009856 - R09 Qualification and approvals Page 47 of 58
C1-Public
TOBY-L4 series - Data sheet
Parameter
Specification
Reel type
B3
Delivery quantity
150
7 Product handling & soldering
7.1 Packaging
TOBY-L4 series modules are delivered as hermetically sealed, reeled tapes to enable efficient
production, production lot set-up and tear-down. For more information about packaging, see the
u-blox package information user guide [3].
7.1.1 Reels
TOBY-L4 series modules are deliverable in quantities of 150 pieces on a reel. The modules are delivered
on the reel described in the Figure 5.
Figure 5: TOBY-L4 series modules reel
Table 51: Reel information for TOBY-L4 series modules
Quantities of less than 150 pieces are also available. Contact u-blox for more information.
UBX-16009856 - R09 Product handling & soldering Page 48 of 58
C1-Public
TOBY-L4 series - Data sheet
Feed direction
Pin 1 Sprocket hole
7.1.2 Tapes
Figure 6 shows the position and the orientation of TOBY-L4 modules as they are delivered on the tape,
while the Figure 7 specifies the TOBY-L4 series modules’ reeled tape dimensions.
Figure 6: Orientation for TOBY-L4 modules on tape
Figure 7: TOBY-L4 series modules tape
UBX-16009856 - R09 Product handling & soldering Page 49 of 58
C1-Public
TOBY-L4 series - Data sheet
7.2 Moisture sensitivity levels
⚠ TOBY-L4 series modules are Moisture Sensitive Devices (MSD) in accordance to the IPC/JEDEC
specification.
The moisture sensitivity level (MSL) relates to the packaging and handling precautions required.
TOBY-L4 series modules are rated at MSL level 3. For more information regarding moisture sensitivity
levels, labeling, storage and drying, see the u-blox package information user guide [3].
☞ For the MSL standard, see IPC/JEDEC J-STD-020 (can be downloaded from www.jedec.org).
7.3 Reflow soldering
Reflow profiles are to be selected according to u-blox recommendations (see TOBY-L4 series system
integration manual [2]).
⚠ Failure to observe these recommendations can result in severe damage to the device!
7.4 ESD precautions
⚠ TOBY-L4 series modules contain highly sensitive electronic circuitry and are electrostatic
sensitive devices (ESD). Handling TOBY-L4 series modules without proper ESD protection may
destroy or damage them permanently.
TOBY-L4 series modules require special ESD precautions as typically applied to ESD sensitive
components.
Table 9 reports the maximum ESD ratings of the TOBY-L4 series modules.
Proper ESD handling and packaging procedures must be applied throughout the processing, handling
and operation of any application that incorporates a TOBY-L4 series module.
ESD precautions should be implemented on the application board where the module is mounted, as
described in the TOBY-L4 series system integration manual [2].
⚠ Failure to observe these recommendations can result in severe damage to the device!
UBX-16009856 - R09 Product handling & soldering Page 50 of 58
C1-Public
TOBY-L4 series - Data sheet
TOBY-L4xxx
xxA-xx
Format
Structure
Product Name
PPPP-TGVVL
Ordering Code
PPPP-TGVVL-MMQ
Type Number
PPPP-TGVVL-MMQ-XX
Code
Meaning
Example
PPPP
Form factor
TOBY
TG
Platform (technology and generation)
Dominant technology: G: GSM; U: HSUPA; C: CDMA 1xRTT; N: NB-IoT;
R: LTE low data rate (Cat 1 and below); L: LTE high data rate (Cat 3 and above)
Generation: 1…9
L4
VV
Variant function set based on the same platform: 00…99
90 L LTE category: 6, 4, 3, 1
6
MM
Major product version: 00…99
50
Q
Product grade
B = professional
A = automotive
A
XX
Minor product version (not relevant for certification)
Default value is 00
8 Labeling and ordering information
8.1 Product labeling
The labels of TOBY-L4 series modules include important product information as illustrated in the
Figure 8: u-blox logo, production lot, lead-free marking, product type number, IMEI number, MAC
address, certifications identification numbers, CE marking (if applicable), and the production country.
Figure 8: TOBY-L4 series module label
8.2 Explanation of codes
Three different product code formats are used. The product name is used in documentation such as
this data sheet and identifies all the u-blox products, independent of packaging and quality grade. The
ordering code includes options and quality, while the type number includes the hardware and
firmware versions. Table 52 details these 3 different formats:
Table 52: Product code formats
Table 53 explains the parts of the product code.
Table 53: Part identification code
UBX-16009856 - R09 Labeling and ordering information Page 51 of 58
C1-Public
TOBY-L4 series - Data sheet
Ordering No.
Product
TOBY-L4006-01A
LTE Cat 6 module with 3G and 2G fallback, supporting u-blox uCPU for OEM applications
Mainly designed for operation in North America,
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
TOBY-L4006-51A
LTE Cat 6 module with 3G and 2G fallback, supporting AT commands
Mainly designed for operation in North America
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
TOBY-L4106-01A
LTE Cat 6 module with 3G and 2G fallback, supporting u-blox uCPU for OEM applications
Mainly designed for operation in EMEA
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
TOBY-L4106-51A
LTE Cat 6 module with 3G and 2G fallback, supporting AT commands
Mainly designed for operation in EMEA
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
TOBY-L4206-01A
LTE Cat 6 module with 3G and 2G fallback, supporting u-blox uCPU for OEM applications
Mainly designed for operation in APAC / South America
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
TOBY-L4206-51A
LTE Cat 6 module with 3G and 2G fallback, supporting AT commands
Mainly designed for operation in APAC / South America
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
TOBY-L4906-01A
LTE Cat 6 module with 3G and 2G fallback, supporting u-blox uCPU for OEM applications
Mainly designed for operation in China
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
TOBY-L4906-50A
LTE Cat 6 module with 3G and 2G fallback, supporting AT commands
Mainly designed for operation in China
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
TOBY-L4906-51A
LTE Cat 6 module with 3G and 2G fallback, supporting AT commands
Mainly designed for operation in China
Automotive grade, 35.6 x 24.8 x 2.6 mm, 150 pcs/reel
8.3 Ordering information
Table 54: Product ordering codes
UBX-16009856 - R09 Labeling and ordering information Page 52 of 58
C1-Public
TOBY-L4 series - Data sheet
Abbreviation
Definition
ADC
Analog to Digital Converter
API
Application Program Interface
BER
Bit Error Rate
BSP
Board Support Package
CA
Carrier Aggregation
DDC
Display Data Channel (I2C compatible) Interface
DL
Down-link (Reception)
EDGE
Enhanced Data rates for GSM Evolution
eMMC
Embedded Multi-Media Card
ERS
External Reset Input Signal
ESD
Electrostatic Discharge
ETH
Ethernet RGMII interface (power domain)
FDD
Frequency Division Duplex
FOAT
Firmware update Over AT commands
FOTA
Firmware update Over The Air
FW
Firmware
GDI
Generic Digital Interfaces (power domain)
GMSK
Gaussian Minimum-Shift Keying modulation
GND
Ground
GNSS
Global Navigation Satellite System
GPIO
General Purpose Input Output
GSM
Global System for Mobile Communication
HSDPA
High Speed Downlink Packet Access
HSM
Hardware Security Module
HSUPA
High Speed Uplink Packet Access
I2C
Inter-Integrated Circuit Interface
I2S
Inter-IC Sound Interface
IMEI
International Mobile Equipment Identity
IMS
IP Multimedia Subsystem
LGA
Land Grid Array
LTE
Long Term Evolution
MBIM
Mobile Broadband Interface Model
MIMO
Multi-Input Multi-Output
MMC
Embedded Multi-Media Card / SD memory interface (power domain)
NCM
Network Control Model
OEM
Original Equipment Manufacturer (company integrating a u-blox product)
PCN / IN
Product Change Notification / Information Note
POS
Power-On Input Signal
QPSK
Quadrature Phase-Shift Keying modulation
RGMII
Reduced Gigabit Media Independent Interface
RIL
Radio Interface Layer
RMC
Reference Measurement Channel
RNDIS
Remote Network Driver Interface Specification
SDIO
Secure Digital Input Output
SDK
Software Development Kit
SDR
Single Data Rate
Appendix
A Glossary
UBX-16009856 - R09 Appendix Page 53 of 58
C1-Public
TOBY-L4 series - Data sheet
Abbreviation
Definition
SHA
Secure Hash Algorithm
SIM
Subscriber Identity Module
SPI
Serial Peripheral Interface
TBD
To Be Defined
TDD
Time Division Duplex
UART
Universal Asynchronous Receiver-Transmitter serial interface
uCPU
u-blox universal Central Processing Unit
UL
Up-link (Transmission)
UMTS
Universal Mobile Telecommunications System
USB
Universal Serial Bus
VoLTE
Voice over LTE
W-CDMA
Wideband Code Division Multiple Access
Table 55: Explanation of the abbreviations and terms used
UBX-16009856 - R09 Appendix Page 54 of 58
C1-Public
TOBY-L4 series - Data sheet
Related documents
[1] u-blox AT commands manual, UBX-13002752
[2] u-blox TOBY-L4 series system integration manual, UBX-16024839
[3] u-blox package information guide, UBX-14001652
[4] 3GPP TS 27.007 – AT command set for User Equipment (UE)
[5] 3GPP TS 27.005 – Use of Data Terminal Equipment – Data Circuit terminating Equipment (DTE
– DCE) interface for Short Message Service (SMS) and Cell Broadcast Service (CBS)
[6] 3GPP TS 36.521-1 – Evolved Universal Terrestrial Radio Access; User Equipment conformance
specification; Radio transmission and reception; part 1: conformance testing
[7] 3GPP TS 34.121-1 – User Equipment conformance specification; radio transmission and
reception (FDD); part 1: conformance specification
[8] 3GPP TS 51.010-1 – Mobile Station conformance specification; part 1: conformance
specification
[9] ITU-T recommendation V.24, 02-2000. List of definitions for interchange circuits between
Data Terminal Equipment (DTE) and Data Circuit-terminating Equipment (DCE),
https://www.itu.int/rec/T-REC-V.24-200002-I
[10] Universal Serial Bus revision 3.0 specification, https://www.usb.org/
[11] Universal Serial Bus revision 2.0 specification, https://www.usb.org/
[12] I2C-bus specification and user manual – NXP semiconductors,
https://www.nxp.com/docs/en/user-guide/UM10204.pdf
[13] Reduced Gigabit Media-Independent Interface (RGMII) Version 1.3
[14] JESD84-B451 – Embedded Multimedia Card (eMMC), Electrical Standard 4.51
☞ For regular updates to u-blox documentation and to receive product change notifications, register
on our homepage (www.u-blox.com).
UBX-16009856 - R09 Related documents Page 55 of 58
C1-Public
TOBY-L4 series - Data sheet
Revision
Date
Name
Status / Comments
R01
27-Apr-2016
sses / smoi
Initial release
R02
07-Oct-2016
sses
Noted supported RATs: LTE-FDD, LTE-TDD, UMTS FDD, (E)GPRS.
Updated temperature range: normal operating range –20 °C – +75 °C,
Extended operating range –40 °C – +85 °C, eCall operating range –40 °C – +95 °C
Added UMTS band 8 on TOBY-L4906.
Added I2S1 and UART3 interfaces. Added USB_ID pin.
Updated RGMII / RMII interface electrical characteristics.
Remarked Moisture Sensitivity Level: MSL 3.
Added remark in mechanical description.
Other minor corrections.
R03
13-Dec-2016
sses
Added GPIO, external Interrupt and SPI Chip Select functions support by
specific pins. Other minor corrections.
R04
28-Jul-2017
sses
Added document applicability to “50” product versions.
Updated FW features supported by “00” product versions.
Updated 3G and 2G maximum data rate. Updated supported LTE CA.
Updated LTE TDD band 41 Frequency range.
Clarified Rx diversity support.
Updated power-on, power-off sections and PWR_ON pin specifications.
Updated USB and UART supported functions / features.
Updated SPI supported frequency.
Clarified I2C and SDIO supported functions.
Updated GPIOs supported functions.
Renamed pin 230 from GND to MIC_GND.
Updated support of digital audio interfaces.
Added some absolute maximum ratings, module thermal parameters, module
VCC current consumption, receivers sensitivity performances, and V_INT
current capability.
Updated main certification approvals.
Minor other corrections.
R05
21-Nov-2017
sses
Added data rate supported by UART, SPI, I2C, SDIO interfaces
Added USB capabilities
Added GPIOs capabilities
Added V_BCKP characteristics
R06
23-Nov-2018
sses
Added document applicability to “01” and “51” product versions
Removed document applicability to “00” product versions
Removed document applicability to TOBY-L4006-50A, TOBY-L4106-50A, and
TOBY-L4206-50A product versions
Updated TOBY-L4906-50A product status
Removed LTE FDD band 17 support by TOBY-L4006
Updated module VCC supply normal operating input voltage range
Corrected naming of pin 237 from MIC2_P to MIC1_P
Clarified supported modes of SDIO, RGMII and eMMC interfaces
Added and updated V_ETH and V_MMC pins’ characteristics
Updated VUSB_DET input characteristics
Added GPIOs capabilities
Added special function of RSVD pin number 6
Added and updated current consumption and Rx sensitivity figures
Updated label description and explanations of ordering codes
Minor other corrections
Revision history
UBX-16009856 - R09 Revision history Page 56 of 58
C1-Public
TOBY-L4 series - Data sheet
Revision
Date
Name
Status / Comments
R07
08-May-2019
lpah / sses
Updated TOBY-L4906-50A product status
Added 3G Band 6 and Band 19 support by TOBY-L4206
Revised AT commands support
Revised power-on, power-off and reset sections
Added USB capabilities details
Clarified TOBY-L4206 audio capability
Added GPIOs capabilities
Added Rx sensitivity figures
Revised approval section
Minor other corrections
R08
22-Jun-2020
lpah / sses
Updated TOBY-L4206-01A, TOBY-L4206-51A and TOBY-L4906-50A-01 product
status
Extend document applicability to TOBY-L4906-50A-02.
Added and clarified current consumption data
Added and clarified audio interfaces characteristics
Minor other corrections
R09
30-Jul-2020
lpah / sses
Updated application version of TOBY-L4 "01" and "51" product versions
UBX-16009856 - R09 Revision history Page 57 of 58
C1-Public
TOBY-L4 series - Data sheet
u-blox Offices
North, Central and South America
u-blox America, Inc.
Phone: +1 703 483 3180
E-mail: info_us@u-blox.com
Regional Office West Coast:
Phone: +1 408 573 3640
E-mail: info_us@u-blox.com
Technical Support:
Phone: +1 703 483 3185
E-mail: support@u-blox.com
Headquarters
Europe, Middle East, Africa
u-blox AG
Phone: +41 44 722 74 44
E-mail: info@u-blox.com
Support: support@u-blox.com
Asia, Australia, Pacific
u-blox Singapore Pte. Ltd.
Phone: +65 6734 3811
E-mail: info_ap@u-blox.com
Support: support_ap@u-blox.com
Regional Office Australia:
Phone: +61 2 8448 2016
E-mail: info_anz@u-blox.com
Support: support_ap@u-blox.com
Regional Office China (Beijing):
Phone: +86 10 68 133 545
E-mail: info_cn@u-blox.com
Support: support_cn@u-blox.com
Regional Office China (Chongqing):
Phone: +86 23 6815 1588
E-mail: info_cn@u-blox.com
Support: support_cn@u-blox.com
Regional Office China (Shanghai):
Phone: +86 21 6090 4832
E-mail: info_cn@u-blox.com
Support: support_cn@u-blox.com
Regional Office China (Shenzhen):
Phone: +86 755 8627 1083
E-mail: info_cn@u-blox.com
Support: support_cn@u-blox.com
Regional Office India:
Phone: +91 80 405 092 00
E-mail: info_in@u-blox.com
Support: support_in@u-blox.com
Regional Office Japan (Osaka):
Phone: +81 6 6941 3660
E-mail: info_jp@u-blox.com
Support: support_jp@u-blox.com
Regional Office Japan (Tokyo):
Phone: +81 3 5775 3850
E-mail: info_jp@u-blox.com
Support: support_jp@u-blox.com
Regional Office Korea:
Phone: +82 2 542 0861
E-mail: info_kr@u-blox.com
Support: support_kr@u-blox.com
Regional Office Taiwan:
Phone: +886 2 2657 1090
E-mail: info_tw@u-blox.com
Support: support_tw@u-blox.com
Contact
For complete contact information, visit us at www.u-blox.com.
UBX-16009856 - R09 Contact Page 58 of 58
C1-Public
Loading...
