ODIN-W2 series

Stand-alone multiradio modules with Wi-Fi and Bluetooth

Data sheet

Abstract

This technical data sheet describes the ODIN-W2 series short range multiradio modules with Wi-Fi and Bluetooth® dual-mode (Bluetooth BR/EDR and Bluetooth Low Energy v4.2). ODINcompact and powerful stand-alone multiradio module, designed for Internet-ofapplications. The Wi-Fi support conforms to IEEE 802.11a/b/g/ and has support for dual-band Wi-Fi (2.4 GHz and 5 GHz bands), 2x2 MIMO.

UBX-14039949 - R25 C1-Public www.u-blox.com

ODIN-W2 series - Data sheet

u document. Copying, reproduction, modification or disclosure to third parties of this document or any part thereof is only permitted with the The information contained herein is provided “as is” and u implied, is given, including but not limited purpose of the information. This document may be revised by u documents, visit www.u Copyright © u

Document information

Title ODIN-W2 series

Subtitle Stand-alone multiradio modules with Wi-Fi and Bluetooth

Document type Data sheet

Document number UBX-14039949

Revision and date R25 3-Mar-2021

Disclosure restriction C1-Public

Product status Corresponding content status

Functional sample Draft For functional testing. Revised and supplementary data will be published later.

In development / Prototype

Engineering sample Advance information Data based on early testing. Revised and supplementary data will be published later.

Initial production Early production information Data from product verification. Revised and supplementary data may be published later.

Mass production / End of life

This document applies to the following products:

Product name Type number Software version Hardware version PCN reference Product status

ODIN-W260 ODIN-W260-05B-01 6.0.0, 6.0.1 07 UBX-20017190 Mass production

ODIN-W262 ODIN-W262-05B-01 6.0.0, 6.0.1 07 UBX-20017190 Mass production

ODIN-W263 ODIN-W263-06B-01 7.1.0 07 UBX-20017190 Initial production

Objective specification Target values. Revised and supplementary data will be published later.

Production information Document contains the final product specification.

ODIN-W260-06B-01 7.1.0 07 UBX-20017190 Initial production

ODIN-W262-06B-01 7.1.0 07 UBX-20017190 Mass production

-blox or third parties may hold intellectual property rights in the products, names, logos and designs included in this

UBX-14039949 - R25 Document information Page 2 of 53 C1-Public

express written permission of u-blox.

-blox assumes no liability for its use. No warranty, either express or

to, with respect to the accuracy, correctness, reliability and fitness for a particular

-blox at any time without notice. For the most recent

-blox.com.

-blox AG.

ODIN-W2 series - Data sheet

Document information ............................................................................................................................. 2

Contents ....................................................................................................................................................... 3

1 Functional description ....................................................................................................................... 6

1.1 Overview ........................................................................................................................................................ 6

1.2 Applications ................................................................................................................................................. 6

1.3 Product features ......................................................................................................................................... 7

1.4 Block diagram .............................................................................................................................................. 8

1.5 Product description .................................................................................................................................... 9

1.6 AT command support ................................................................................................................................ 9

1.7 IEEE 802.11d and additional regulatory domains ................................................................................ 9

1.7.1 ODIN-W2 IEEE 802.11d implementation description ............................................................... 10

1.8 MAC addresses ......................................................................................................................................... 11

2 Interfaces ........................................................................................................................................... 12

2.1 Power management ................................................................................................................................. 12

2.1.1 Module supply input (VCC) ............................................................................................................. 12

2.1.2 Digital I/O interfaces supply output (V_INT) ............................................................................... 12

2.2 Antenna interfaces ................................................................................................................................... 12

2.2.1 Antenna connectors and internal antenna ................................................................................. 12

2.3 Data communication interfaces ............................................................................................................ 13

2.3.1 UART interface .................................................................................................................................. 13

2.3.2 Ethernet interface ............................................................................................................................ 13

3 System functions ............................................................................................................................. 15

3.1 Module power modes ............................................................................................................................... 15

3.2 Module reset .............................................................................................................................................. 15

3.3 IO signals ..................................................................................................................................................... 15

3.3.1 System status IO signals ................................................................................................................ 15

3.3.2 System control IO signals ............................................................................................................... 15

3.3.3 UART IO signals ................................................................................................................................ 16

4 Pin definition...................................................................................................................................... 17

4.1 Pin assignment .......................................................................................................................................... 17

5 Electrical specification ................................................................................................................... 21

5.1 Absolute maximum ratings .................................................................................................................... 21

5.1.1 Maximum ESD ................................................................................................................................... 21

5.2 Operating conditions ................................................................................................................................ 21

5.2.1 Temperature range .......................................................................................................................... 21

5.2.2 Power supply ...................................................................................................................................... 21

5.2.3 I/O DC characteristics ...................................................................................................................... 22

5.2.4 Reset characteristics ....................................................................................................................... 22

5.2.5 LPO clock ............................................................................................................................................ 22

5.2.6 Universal asynchronous serial interface (UART) ....................................................................... 23

UBX-14039949 - R25 Contents Page 3 of 53 C1-Public

ODIN-W2 series - Data sheet

5.3 Power consumption .................................................................................................................................. 23

5.3.1 General power consumption ........................................................................................................... 23

5.3.2 Wi-Fi 2.4 GHz power consumption ................................................................................................ 24

5.3.3 Wi-Fi 5 GHz power consumption ................................................................................................... 24

5.3.4 Classic Bluetooth power consumption ......................................................................................... 24

5.3.5 Bluetooth Low Energy (LE) power consumption ........................................................................ 25

5.4 RF characteristics ..................................................................................................................................... 25

5.4.1 Wi-Fi radio characteristics.............................................................................................................. 25

5.4.2 Wi-Fi receiver characteristics 2.4 GHz ......................................................................................... 25

5.4.3 Wi-Fi receiver characteristics 5 GHz ............................................................................................ 26

5.4.4 Wi-Fi transmitter characteristics 2.4 GHz .................................................................................. 26

5.4.5 Wi-Fi transmitter characteristics 5 GHz ..................................................................................... 27

5.4.6 Classic Bluetooth receiver characteristics .................................................................................. 27

5.4.7 Bluetooth Low Energy receiver sensitivity .................................................................................. 27

5.4.8 Classic Bluetooth transmitter characteristics ........................................................................... 28

5.4.9 Bluetooth Low Energy transmitter characteristics .................................................................. 28

6 Mechanical specifications ............................................................................................................. 29

6.1 Dimensions ................................................................................................................................................. 29

6.2 Module weight ........................................................................................................................................... 30

7 Qualification and approvals .......................................................................................................... 31

7.1 Compliance with the RoHS directive ..................................................................................................... 31

7.2 European Union regulatory compliance ............................................................................................... 31

7.3 Safety compliance .................................................................................................................................... 31

7.4 FCC and IC Compliance ............................................................................................................................ 31

7.4.1 IC compliance ..................................................................................................................................... 31

7.4.2 Conformité aux orms d’IC................................................................................................................ 32

7.4.3 FCC statement .................................................................................................................................. 32

7.4.4 Labeling requirements for end product ....................................................................................... 33

7.5 Japan radio equipment compliance ...................................................................................................... 34

7.6 SRRC China Radio Transmission Equipment Type Approval .......................................................... 35

7.6.1 ODIN-W262 labeling requirements for end product ................................................................. 35

7.7 NCC Taiwan compliance .......................................................................................................................... 35

7.7.1 Taiwan NCC Warning Statement .................................................................................................. 35

7.7.2 ODIN-W260 labeling requirements for end product ................................................................. 35

7.7.3 ODIN-W262 labeling requirements for end product ................................................................. 36

7.8 Korean KCC certification ......................................................................................................................... 36

7.9 Brazil compliance ...................................................................................................................................... 36

7.10 Australia and New Zealand regulatory compliance ........................................................................... 37

7.11 South Africa regulatory compliance ..................................................................................................... 37

7.12 Bluetooth qualification information ...................................................................................................... 38

8 Antennas ............................................................................................................................................ 39

8.1 Antenna accessories ................................................................................................................................ 40

UBX-14039949 - R25 Contents Page 4 of 53 C1-Public

ODIN-W2 series - Data sheet

8.2 Approved antennas .................................................................................................................................. 40

8.2.1 Single band antennas ...................................................................................................................... 40

8.2.2 Dual-band antennas ......................................................................................................................... 42

9 Product handling and soldering ................................................................................................... 44

9.1 Packaging ................................................................................................................................................... 44

9.1.1 Reels .................................................................................................................................................... 44

9.1.2 Tapes ................................................................................................................................................... 44

9.2 Moisture sensitivity levels ....................................................................................................................... 45

9.3 Reflow soldering ........................................................................................................................................ 45

9.4 ESD precautions ........................................................................................................................................ 45

10 Labeling and ordering information ............................................................................................. 46

10.1 Label information ...................................................................................................................................... 46

10.2 Explanation of codes ................................................................................................................................ 47

10.3 Ordering information ................................................................................................................................ 47

Appendix .................................................................................................................................................... 48

A Glossary .............................................................................................................................................. 48

Related documents ................................................................................................................................ 50

Revision history ....................................................................................................................................... 51

Contact ....................................................................................................................................................... 53

UBX-14039949 - R25 Contents Page 5 of 53 C1-Public

ODIN-W2 series - Data sheet

1 Functional description

1.1 Overview

The ODIN-W2 is a compact and powerful stand-alone multiradio module, designed for Internet-of-Things gateway applications. The module includes an embedded Bluetooth stack, Wi-Fi driver, IP stack, and an application for wireless data transfer, all configurable using AT commands. The wireless support includes dual-mode Bluetooth v4.2 (BR/EDR and low energy) and dual-band Wi-Fi (2.4 and 5 GHz bands).

The module supports point-to-point and point-to-multipoint configurations and can have concurrent Bluetooth and Wi-Fi connections. It can operate in Wireless Multidrop™ or Extended Data Mode for advanced multipoint capabilities. Operation in Point-to-Point Protocol (PPP) mode gives the host a UART-based IP interface for advanced use cases. The software provides support for RMII with a micro Access Point.

The module is professional grade with an extended temperature range and is radio type approved for multiple countries, which reduces the integration work and cost.

1.2 Applications

• Internet of Things (IoT)

• Wi-Fi and Bluetooth networks

• Medical and industrial networking

• Access to laptops, mobile phones, and similar consumer devices

• Home/building automation

• Ethernet/Wireless Gateway

UBX-14039949 - R25 Functional description Page 6 of 53 C1-Public

ODIN-W2 series - Data sheet

1.3 Product features

Table 1: Key features of ODIN-W2 series

UBX-14039949 - R25 Functional description Page 7 of 53 C1-Public

ODIN-W2 series - Data sheet

1.4 Block diagram

The block diagram of the ODIN-W2 series is shown below:

Figure 1: Block diagram of ODIN-W2 series

UBX-14039949 - R25 Functional description Page 8 of 53 C1-Public

ODIN-W2 series - Data sheet

1.5 Product description

The ODIN-W2 series module supports Wi-Fi, Bluetooth BR/EDR, and Bluetooth Low Energy (dualmode / Bluetooth Smart Ready). The Wi-Fi support conforms to IEEE 802.11a/b/g/n, and has support for dual-band 2.4 GHz and 5 GHz operations and 2×2 MIMO (2.4 GHz).

Wi-Fi Classic Bluetooth Bluetooth Low Energy

IEEE 802.11°/b/g/n IEEE 802.11d/e/i/h/w ODIN-W260: 2X2 MIMO

Band support Station mode:

2.4 GHz, channel 1-13 5 GHz, channel 36-165* Access Point mode:

2.4 GHz, channel 1-11 5 GHz, channel 36-48

Maximum conducted output power 15 dBm

Maximum radiated output power 18 dBm EIRP

Conducted sensitivity

2.4 GHz: -95 dBm 5 GHz: -90 dBm

Data rates: IEEE 802.11b: 1 / 2 / 5.5 / 11 Mbit/s IEEE 802.11a/g: 6 / 9 / 12 / 18 / 24 / 36 / 48 / 54 Mbit/s IEEE 802.11n SISO: MCS 0-7, HT20 (6.5-65 Mbit/s) IEEE 802.11n 2x2 MIMO: MCS 8-15, HT20 (13-130 Mbit/s)

Maximum, supports 802.11d and depends on region.

***

Table 2: ODIN-W2 series Wi-Fi and Bluetooth characteristics

RF power including maximum antenna gain (3 dBi).

DFS client only.

***

(2.4 GHz only)

Classic Bluetooth v2.1+EDR Maximum number of Peripherals: 7 Bluetooth profiles: SPP, DUN, GATT and

PAN

Band support

2.4 GHz, 79 channels

Maximum conducted output power 11 dBm

Maximum radiated output power 14 dBm EIRP**

Conducted sensitivity

-90 dBm

Data rates: 1 / 2 / 3 Mbit/s

Bluetooth LE 4.2 dual-mode

Band support

2.4 GHz, 40 channels

Maximum conducted output power 7 dBm

Maximum radiated output power 10 dBm EIRP**

Conducted sensitivity

-95 dBm

Data rates: 1 Mbit/s

1.6 AT command support

You can configure ODIN-W2 with the u-blox s-center toolbox software using AT commands. See u-connectXpress AT commands manual [1] for information about supported AT commands.

The s-center evaluation software supporting the AT commands is also available free of charge and can be downloaded from the u-blox website.

1.7 IEEE 802.11d and additional regulatory domains

The ODIN-W2 series modules support IEEE 802.11d. IEEE 802.11d is an amendment to the IEEE

802.11 specification that adds support for “additional regulatory domains”. IEEE 802.11d allows ODIN-W2 based devices to self-configure and operate according to the regulations of the country in

UBX-14039949 - R25 Functional description Page 9 of 53 C1-Public

ODIN-W2 series - Data sheet

Scan complete

No or both FCC and ETSI AP found

Entry start scan

which they operate. Its parameters include country name, channel quantity and maximum transmission level. The country information feature simplifies the creation of 802.11 wireless access points and client devices that meet the different regulations enforced in various parts of the world.

1.7.1 ODIN-W2 IEEE 802.11d implementation description

When ODIN-W2 is used as a Wi-Fi station, the scan is used to detect which regulatory domain it is currently in. Passive scan is used for channels that are not available in all regulatory domains. The device supports the following three domains, where WORLD means all channels that are supported both by FCC, ETSI and most other countries in the world:

• WORLD

• FCC

• ETSI

⚠ ODIN-W263 is configured to always support the ETSI domain and is only allowed to be used

in countries allowing ETSI domain channels (see Table 3).

See Table 3 for detailed information on channels that are supported in the different regulatory domains. The state transition diagram below (Figure 2) describes the algorithm for selecting the current regulatory domain.

start scan every hour

Scan complete

Three or more ETSI AP found and

no FCC AP found

ETSI

FCC found

WORLD

WORLD-FINAL

Scan complete

FCC AP found and no ETSI AP

FCC

Scan complete

ETSI found

Figure 2: ODIN-W2 series IEEE 802.11d state transition diagram

Initial regulatory domain is WORLD. At start up a scan is initiated to detect beacons containing country information.

If at least one scan result contains country information indicating FCC and no country information indicates ETSI, then the regulatory domain is set to FCC.

If at least three scan results contain country information indicating ETSI and no country information indicates FCC, then the regulatory domain is set to ETSI.

If the scan result contains country information indicating both FCC and country information indicating ETSI, then the regulatory domain is set to WORLD. In the state transition diagram this is the state WORLD_FINAL. This state will not be exited until the device is reset.

A new scan is performed every hour to update the regulatory domain.

UBX-14039949 - R25 Functional description Page 10 of 53 C1-Public

ODIN-W2 series - Data sheet

If the current regulatory domain is ETSI and at least one scan result contains country information indicating FCC and then the regulatory domain is set to WORLD. In the state transition diagram this is the state WORLD-FINAL. This state is will not be exited until the device is reset.

If the current regulatory domain is FCC and at least one scan result contains country information indicating ETSI and then the regulatory domain is set to WORLD. In the state transition diagram this is the state WORLD-FINAL. This state is will not be exited until the device is reset.

At restart of the device the algorithm is restarted. It is not possible to override the algorithm described by reconfiguration the device.

Regulatory domain Band Tx channels

WORLD 2.4 GHz 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11

U-NII-1 36, 40, 44, 48

U-NII-2 52, 56, 60, 64

U-NII-2e 100, 104, 108, 112, 116, 132, 136, 140

U-NII-3 -

ETSI 2.4 GHz 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13

U-NII-1 36, 40, 44, 48

U-NII-2 52, 56, 60, 64

U-NII-2e 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140

U-NII-3 149, 153, 157, 161, 165

FCC 2.4 GHz 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11

U-NII-1 36, 40, 44, 48

U-NII-2 52, 56, 60, 64

U-NII-2e 100, 104, 108, 112, 116, 132, 136, 140

U-NII-3 149, 153, 157, 161, 165

Table 3: Channel list for supported regulatory domains

The maximum output power is reduced on some channels depending on regulatory requirements. For example, frequency band edge requirements can limit the output power on channels close to band edges.

1.8 MAC addresses

ODIN-W2 module series has four unique consecutive MAC addresses reserved for each module, from which the three first addresses are stored in the configuration memory during production. The first Bluetooth MAC address is available in the Data Matrix on the label (see section 10.2). The last MAC address is not stored in the configuration memory but is reserved for usage with the module.

MAC address Assignment

Address 1 Bluetooth

Address 2 Wi-Fi

Address 3 RMII/Ethernet

Address 4 Reserved

Table 4: Example MAC address assignment for an ODIN-W2 module

UBX-14039949 - R25 Functional description Page 11 of 53 C1-Public

Example

D4:CA:6E:90:04:90

D4:CA:6E:90:04:91

D4:CA:6E:90:04:92

D4:CA:6E:90:04:93

ODIN-W2 series - Data sheet

2 Interfaces

☞ ODIN-W2 is a surface mounted device (SMD). As the ports supported in the module are not

tested against fast transients, RF common mode, transients and surge, the module must not be connected with cables longer than 3 m.

2.1 Power management

☞ To fulfill EN 60950-1 safety standards, the unit must be supplied by a limited power source.

2.1.1 Module supply input (VCC)

ODIN-W2 series modules must be supplied through the VCC pin by a DC power supply. Voltage must be stable, because during operation the current drawn from VCC can vary significantly based on the power consumption profile of the Bluetooth/Wi-Fi technologies.

2.1.2 Digital I/O interfaces supply output (V_INT)

The ODIN-W2 series modules provide a 1.8 V supply rail output on the V_INT pin, which is internally generated when the module is powered on. The same voltage domain is used internally to supply the generic digital interfaces of the modules. The V_INT supply output can be used instead of an external discrete regulator. See the Electrical specification section for maximum output current.

2.2 Antenna interfaces

The following two different antenna options are available in the ODIN-W2 series:

• ODIN-W260 is equipped with dual U.FL. coaxial connectors for external antennas. Different types of external antennas are available and can be used.

• ODIN-W262 and ODIN-W263 is equipped with an integrated dual-band antenna

☞ While mounting the unit, ensure that it does not interfere with radio communication. The

ODIN-W262 and ODIN-W263 equipped with an internal surface mounted antenna should not be mounted in a metal enclosure. No metal casing or plastics using metal flakes should be used. Avoid metallic based paint or lacquer.

See the Antennas section for information on the external antennas that can be used and for other RF and antenna design advices. For more info about antenna integration, see ODIN-W2 series system integration manual [1].

2.2.1 Antenna connectors and internal antenna

ODIN-W260 has two RF antenna U.FL. coaxial connectors with a characteristic impedance of 50 Ω. The main antenna connector supports both Bluetooth and dual-band Wi-Fi. The second (MIMO) antenna connector adds support for 2x2 MIMO 2.4 GHz single band Wi-Fi.

ODIN-W262 has an internal dual-band PIFA antenna and supports Bluetooth and dual-band Wi-Fi (SISO).

UBX-14039949 - R25 Interfaces Page 12 of 53 C1-Public

ODIN-W2 series - Data sheet

Figure 3: ODIN-W260 with connectors for external antennas and ODIN-W262 with an internal antenna

2.3 Data communication interfaces

The ODIN-W2 series provides several data communication interfaces which are described below.

2.3.1 UART interface

ODIN-W2 series modules include a 6-wire UART for communication with an application host processor (AT commands, data communication and software upgrades).

The following UART signals are available:

• Data lines (RXD as input, TXD as output)

• Hardware flow control lines (CTS as input, RTS as output)

• Link status (DTR as output, DSR as input)

CMOS compatible signal levels are recommended. For more information about the UART interface, see the u-connectXpress AT commands manual [1] and ODIN-W2 series system integration manual [2].

2.3.2 Ethernet interface

ODIN-W2 series modules include an integrated Ethernet MAC to communicate with other networked nodes over a shared medium. It supports 10/100 Mbit/s communication and can operate in both fulland half-duplex (CSMA/CD).

UBX-14039949 - R25 Interfaces Page 13 of 53 C1-Public

ODIN-W2 series - Data sheet

The Ethernet interface includes:

• RMII either for MAC to PHY or Ethernet MAC to MAC communication.

• SMI for PHY configuration

☞ The IO voltage of the ODIN-W2 is 1.8 V, which means that the RMII interface operates outside

the RMII specification v1.2. If the RMII is to be connected to a PHY circuit, then that circuit must support 1.8 V operation. If a direct RMII to RMII connection is used, then a level shifter might be needed depending on the selected host. The selected hardware setup must be verified on the application board to guarantee operation.

2.3.2.1 RMII

The RMII uses seven signals in total. The interface requires an external 50 MHz clock source either from a compatible PHY chip or an external oscillator. ODIN-W2 cannot provide this clock signal by itself.

2.3.2.2 SMI (MDC/MDIO management interface)

The two-wire SMI is used to configure the PHY chips. The interface uses a clock line and a data line to clock data to and from the PHY chips registers.

UBX-14039949 - R25 Interfaces Page 14 of 53 C1-Public

ODIN-W2 series - Data sheet

3 System functions

3.1 Module power modes

The ODIN-W2 series module does not have an internal low power oscillator (LPO) which is required for low power modes. An external 32.768 kHz LPO signal can be supplied externally via the LPO_CLK pin if low power modes are required.

3.2 Module reset

The ODIN-W2 series modules can be reset (rebooted) in one of the following ways:

• Low level on the RESET_N pin, which is normally set high by an internal pull-up. This causes a “hardware reset” of the module. The RESET_N line should be driven by an open drain, open collector or contact switch.

• Using a reset AT command causes a “software reset” of the module, See also u-connectXpress AT commands manual [1]).

3.3 IO signals

3.3.1 System status IO signals

The RED, GREEN and BLUE pins are used to signal the status. They are active low and are intended to be routed to an RGB LED. For more information about connectivity software signal loss, see the u-connectXpress AT commands manual [1].

Mode Status RGB LED color GREEN BLUE RED

Data mode IDLE Green LOW HIGH HIGH

Command mode IDLE Orange LOW HIGH LOW

Data mode, Command mode

* = LED flashes on data activity

Table 5: System status indication

CONNECTING

CONNECTED

3.3.2 System control IO signals

The following input signals are used to control the system:

• RESET_N is used to reset the system. See section 3.2 for detailed information.

• If SWITCH_1 is driven low during start up, the UART serial settings are restored to their default

values.

• SWITCH_0 can be used to open a connection to a peripheral device.

• If both SWITCH_0 and SWITCH_1 are driven low during start up, the system will enter the

bootloader mode.

• If both SWITCH_0 and SWITCH_1 are driven low during start up and held low for 10 seconds, the

system will exit the bootloader mode and restore all settings to their factory defaults.

Purple HIGH LOW LOW

Blue HIGH LOW HIGH

For more information about connectivity software signal Ioss, see the u-connectXpress AT Commands Manual [1])

UBX-14039949 - R25 System functions Page 15 of 53 C1-Public

ODIN-W2 series - Data sheet

3.3.3 UART IO signals

In addition to the normal RXD, TXD, CTS, and RTS signals, the ODIN-W260/ODIN-W262 software adds the DSR and DTR pins to the UART interface. Note that the DSR and DTR pins are not used as originally intended, but to control the state of the module. Depending on the current configuration, the DSR pin can be used to:

• Enter command mode

• Disconnect and/or toggle connectable status

UBX-14039949 - R25 System functions Page 16 of 53 C1-Public

ODIN-W2 series - Data sheet

4 Pin definition

4.1 Pin assignment

Figure 4: ODIN-W2 series pin assignment

The signals are available on castellation pads located on the edge of the PCB. All non-filled round pads are GND pads. Black circular pads are test and production points that should not be used. RSVD = Reserved, do not connect.

UBX-14039949 - R25 Pin definition Page 17 of 53 C1-Public

ODIN-W2 series - Data sheet

No Name I/O Description Remarks

A1 RESET_N I External reset input Internal active pull-up to V_INT

A2 V_INT O Regulated output of the

internal I/O voltage

A3 GND N/A Ground All GND pads must be

A4 VCC I Module power supply 3.0 – 3.6 V power supply

A5 UART_DTR O UART

Data Terminal Ready

A6 SWITCH_0 I Connect on external

signal

A7 RED O Logic Red LED signal Active low.

A8 GREEN/

SWITCH_1

A9 BLUE O Logic Blue LED Signal Active low.

A10 UART_CTS I UART Clear To Send,

O/I This signal is multiplexed:

GREEN: Logic Green LED Signal. SWITCH_1: Default Serial Settings.

Hardware flow control

1.8 V, maximum output current 100mA. The maximum output current can be limited by the internal current consumption of the V_INT rail. See the Power consumption section.

connected to ground

Active low. Can also be used as a System IO. See section 3.3 and uconnect AT Commands Manual

for more information about

[1] the pin functionality.

Active low. A secondary function is that the module will restore all factory settings if both the SWITCH_1

and SWITCH_0 signals are low during start up. See the section

3.3 for more information about the pin functionality.

See the IO section for more information. See section 3.3 for more information about the pin functionality.

Active low. The GREEN signal is not valid until 500ms after startup. See the IO section for more

information. If the level on this pin is pulled-

down during start-up the unit goes back to default serial settings. The SWITCH_1 input is only active during the first 500ms after startup. The module will restore all factory settings if both the SWITCH_1 and SWITCH_0 signals are low during start up. See section 3.3 for more information about pin functionality.

See the IO section for more information.

See section 3.3 for more information about the pin functionality.

Active low

UBX-14039949 - R25 Pin definition Page 18 of 53 C1-Public

ODIN-W2 series - Data sheet

No Name I/O Description Remarks

A11 UART_TXD O UART Transmit

A12 UART_RTS O UART Request To Send,

Hardware flow control.

A13 UART_RXD I UART Receive

A14 RSVD N/A Reserved pin Leave unconnected

A15 RSVD N/A Reserved pin Leave unconnected

A16 RSVD N/A Reserved pin Leave unconnected

A17 RSVD N/A Reserved pin Leave unconnected

A18 UART_DSR I UART Data Set Ready Active low.

B1 RSVD N/A Reserved pin Leave unconnected

B2 RSVD N/A Reserved pin Leave unconnected

B3 RSVD N/A Reserved pin Leave unconnected

B4 RSVD N/A Reserved pin Leave unconnected

B5 RSVD N/A Reserved pin Leave unconnected

B6 RSVD N/A Reserved pin Leave unconnected

B7 RSVD N/A Reserved pin Leave unconnected

B8 RSVD N/A Reserved pin Leave unconnected

C1 GND N/A Ground All GND pads must be

C2 RSVD N/A Reserved pin Leave unconnected

C3 GND N/A Ground All GND pads must be

C4 GND N/A Ground All GND pads must be

C5 RSVD N/A Reserved pin Leave unconnected

C6 RSVD N/A Reserved pin Leave unconnected

C7 GND N/A Ground All GND pads must be

C8 RSVD N/A Reserved pin Leave unconnected

C9 RSVD N/A Reserved pin Leave unconnected

C10 RSVD N/A Reserved pin Leave unconnected

C11 RSVD N/A Reserved pin Leave unconnected

C12 RSVD N/A Reserved pin Leave unconnected

C13 RSVD N/A Reserved pin Leave unconnected

C14 RMII_MDC O Management interface

clock output

C15 RMII_MDIO I/O Management interface

data I/O

Active low

Can also be used as a System IO. For more information about the pin functionality, see section 3.3 and u-connectXpress AT commands manual [1].

connected to ground

According to RMII specification v1.2 with the exception that voltage level is 1.8 V

An external pull-up resistor is required on the bidirectional data signal.

UBX-14039949 - R25 Pin definition Page 19 of 53 C1-Public

ODIN-W2 series - Data sheet

No Name I/O Description Remarks

According to RMII specification v1.2 with the exception that voltage level is 1.8 V.

C16 LPO_CLK I Low power oscillator

clock input

C17 RSVD N/A Reserved pin Leave unconnected

C18 RSVD N/A Reserved pin Leave unconnected

D1 RMII_TXD0 O Transmit data output 0 According to RMII specification

D2 RMII_TXD1 O Transmit data output 1 According to RMII specification

D3 RMII_TXEN O Transmit Enable output Active high.

D4 RMII_CRSDV I Carrier sense/receive

data valid input

D5 RMII_RXD0 I Receive data input 0 According to RMII specification

D6 RMII_RXD1 I Receive data input 1 According to RMII specification

D7 GND N/A Ground All GND pads must be

D8 RMII_REFCLK I Reference Clock input Continuous 50 MHz reference

Table 6: ODIN-W2 series pin-out

The module requires an external

32.768 kHz clock for low power modes. Leave this pin unconnected if not used as LPO clock input.

v1.2 with the exception that voltage level is 1.8 V

According to RMII specification v1.2 with the exception that voltage level is 1.8 V.

Carrier Sense and Receive Data Valid signals are multiplexed together, multiplexing scheme varies with implementation. According to RMII specification v1.2 with the exception that voltage level is 1.8 V.

v1.2 with the exception that voltage level is 1.8 V

connected to ground

clock input. According to RMII specification v1.2 - except that voltage level is 1.8 V.

UBX-14039949 - R25 Pin definition Page 20 of 53 C1-Public

ODIN-W2 series - Data sheet

5 Electrical specification

⚠ Stressing the device above one or more of the ratings listed in the Absolute maximum ratings

section may cause permanent damage. These are stress ratings only. Operating the module at these or at any conditions other than those specified in the Operating conditions section should be avoided. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

5.1 Absolute maximum ratings

Symbol Description Condition Min Maximum Unit

VCC Module supply voltage Input DC voltage at VCC pin -0.3 5.5* V

GDI Generic digital interfaces Input DC voltage at Generic

digital interfaces pins

ERS External reset signal Input DC voltage at RESET_N

Tstg Storage temperature -40 +85 ºC

5.5 V up to 10 s cumulative in 7 years, 5 V cumulative to 250 s, 4.8 V cumulative to 2.33 years – all includes charging dips

and peaks.

Table 7: Absolute maximum ratings

-0.3 2.2 V

-0.3 5.2 V

5.1.1 Maximum ESD

Parameter Maximum Unit Remarks

ESD immunity for antenna connector shielding

ESD indirect contact discharge ±8* kV According to EN 301 489-1

ESD sensitivity for all pins 1000 V Human Body Model according to ANSI/ESDA/JEDEC JS-001

* = Tested on EVK-ODIN-W2 evaluation board.

Table 8: Maximum ESD ratings

6000 V Contact Discharge according to IEC 61000-4-2

8000 V Air Discharge according to IEC 61000-4-2

250 V Charged Device Model according to EIA-JEDEC JESD22-C101E

5.2 Operating conditions

☞ Operating condition ranges define those limits within which the functionality of the device is

guaranteed.

5.2.1 Temperature range

Parameter Min

Storage temperature -40 +85 ºC

Operating temperature -40 +85 ºC

Table 9: Temperature range

Maximum Unit

5.2.2 Power supply

Symbol Parameter Min Typ Maximum Unit

VCC Supply voltage 3.00 3.30 3.60 V

UBX-14039949 - R25 Electrical specification Page 21 of 53 C1-Public

ODIN-W2 series - Data sheet

Symbol Parameter Min Typ Maximum Unit

V_INT Output voltage 1.76 1.80 1.84 V

Supply voltage current drain1 - - 1.0 A

VCC

Output voltage current drain - - 100 mA

V_INT

Table 10: Power supply voltage

5.2.3 I/O DC characteristics

Symbol Parameter Min Typ Maximum Unit

VIL LOW level input voltage

VIH HIGH level input voltage

VOL LOW level output voltage

VOH HIGH level output voltage

IIO I/O pin sink and source current

1.31 1.8 2.0 V

1.34 1.8 V

0 0.5 V

0 0.4 V

4.0

CIO I/O pin input capacitance 5 pF

RPU Internal active pull-up resistance All IO pins except for

30 40 50 kΩ

UART_RXD

UART_RXD 8 11 15 kΩ

RPD Internal active pull-down resistance 30 40 50 kΩ

8.0 mA is possible, but the output voltage level is not guaranteed.

Table 11: I/O DC characteristics

5.2.4 Reset characteristics

Symbol Parameter Conditions Min Typ Maximum Unit

IL(RESET_N)

IH(RESET_N)

hys(RESET_N)

PU(RESET_N)

RESET_N

F(RESET_N)

Table 12: Reset characteristics

RESET_N Input low level voltage 0.5 V

RESET_N Input high level voltage 1.3 V

RESET_N Schmitt trigger voltage

200 mV

hysteresis

Internal RESET_N pull-up resistance 8 kΩ

Internal RESET_N capacitance 100 nF

RESET_N Input filtered pulse 100 ns

5.2.5 LPO clock

The ODIN-W2 series module does not have an internal low power oscillator (LPO) required for low power modes. An LPO can be supplied from an external oscillator if low power modes are required.

Symbol Parameter Min Typ Maximum Unit

LPO

Input slow clock accuracy

Tr/Tf Input transition time Tr/Tf -10% to 90% 100 ns

Frequency input duty cycle 20 50 80 %

See Power consumption section for detailed information.

UBX-14039949 - R25 Electrical specification Page 22 of 53 C1-Public

Input clock frequency 32.768 kHz

32.768kHz

150 ppm

(Initial + temp + aging)

ODIN-W2 series - Data sheet

Symbol Parameter Min Typ Maximum Unit

VIH Input voltage limits

VIL 0 0.5 V

Input capacitance 10 pF

Table 13: External LPO clock characteristics

(Square wave, DC-coupled)

1.31 1.8 V

5.2.6 Universal asynchronous serial interface (UART)

Symbol Parameter Min Typ Maximum Unit

Baud rate 2400 115200 5.25M bit/s

baud

Table 14: UART characteristics

5.3

Power consumption

5.3.1 General power consumption

VCC = 3.3 V, TA = 25 °C unless otherwise specified.

Symbol Parameter Conditions Average Peak Unit

IDD Supply current Reset 5.2 6.0 mA

Startup 300 450* mA

Idle, not connected, default configuration 30 65 mA

Idle, not connected, no running services** 30 60 mA

Stop mode

DD_MAXIMUM

Wi-Fi and Bluetooth calibration during the startup phase causes large, short current peaks.

No server running and Bluetooth Connectable and Discoverable turned off.

***

Feature not supported in the current software version. For more information See the u-connectXpress AT commands

manual [1] .

Table 15: General current consumption

Absolute maximum current drain - 800 mA

***

TBD TBD mA

UBX-14039949 - R25 Electrical specification Page 23 of 53 C1-Public

ODIN-W2 series - Data sheet

5.3.2 Wi-Fi 2.4 GHz power consumption

VCC = 3.3 V, TA = 25 °C unless otherwise specified.

Symbol Parameter Conditions Average Peak Unit

Supply current not

DDW24

connected

Supply current

DDW24_TX

transmitting

DDW24_RX

Supply current receiving

Table 16: Current consumption for Wi-Fi 2.4 GHz

Scan, 11 channels, 300 ms 100 360 mA

Idle, Connected DTIM = 1, T

Idle, Connected DTIM = 5, T

= 100 ms 36 100 mA

beacon

= 100 ms 32 100 mA

beacon

802.11b, 1Mb/s, transmission duty cycle 70-75% 250 350 mA

802.11g, 6Mb/s, transmission duty cycle 25-30% 190 360 mA

802.11n SISO, MCS0, transmission duty cycle 25-30% 190 360 mA

802.11n MIMO, MCS8, transmission duty cycle 15-20% 220 650 mA

802.11b 110 130 mA

802.11g 110 130 mA

802.11n SISO 110 130 mA

802.11n MIMO 140 160 mA

5.3.3 Wi-Fi 5 GHz power consumption

VCC = 3.3 V, T

Symbol Parameter Conditions Average Peak Unit

Supply current not

DDW5

connected

Supply current transmitting 802.11a, 6Mb/s, transmission duty cycle 25-30% 200 370 mA

DDW5_TX

DDW5_RX

802.11n SISO, 6.5Mb/s, transmission duty cycle

Supply current receiving 802.11a 120 130 mA

802.11n SISO 120 130 mA

* * Very short peaks during start of transmission.

Table 17: Current consumption for Wi-Fi 5 GHz

5.3.4 Classic Bluetooth power consumption

VCC = 3.3 V, T

Symbol Parameter Conditions Average Peak Unit

DDBT_NDNC

DDBT_NDC

DDBT_DC

DDBT_INQ

DDBT_IDLE

DDBT_TX1Mb

DDBT_RX1Mb

Table 18: Current consumption for classic Bluetooth

Supply current not

connected

Discoverable, Connectable,

Supply current inquiry 47 120 mA

Supply current connected Idle 32 120 mA

Transmitting 56 120 mA

Receiving 46 120 mA

= 25 °C

amb

= 25 °C

amb

Scan, 4 channels, 100 ms 100 370 mA

Idle, Connected DTIM = 1, T

Idle, Connected DTIM = 5

= 100 ms 36 100 mA

beacon

****

, T

= 100 ms 32 100 mA

beacon

200 370 mA

25-30%

Not discoverable, Not connectable 30 65 mA

Not discoverable, Connectable,

30 65 mA

scan interval = TBD, scan window = TBD

30 65 mA

scan interval = TBD, scan window = TBD

UBX-14039949 - R25 Electrical specification Page 24 of 53 C1-Public

ODIN-W2 series - Data sheet

5.3.5 Bluetooth Low Energy (LE) power consumption

VCC = 3.3 V, T

= 25 °C

amb

Symbol Parameter Conditions Average Peak Unit

DDBLE_CD_NC

DDBLE_CD_INQ

DDBLE_PD_NC

DDBLE_PD_ADV

DDBLE_CD_IDL

DDBLE_CD_TX

DDBLE_CD_RX

DDBLE_PD_IDL

DDBLE_PD_TX

DDBLE_PD_RX

Supply current not

connected

Advertising 29 65 mA

Supply current

Central device Idle 29 65 mA

Low Energy Inquiry 48 80 mA

Peripheral

Idle 29 65 mA

device

Central device Idle 44 100 mA

connected

Transmitting 45 100 mA

Receiving 45 100 mA

Peripheral

Idle 29 100 mA

device

Transmitting 30 100 mA

Receiving 30 100 mA

Table 19: Current consumption for Bluetooth Low Energy (LE)

5.4 RF characteristics

5.4.1 Wi-Fi radio characteristics

VCC = 3.3 V, T

Parameter Operation Mode Specification Unit

= 25 °C

amb

RF Frequency Range 802.11b/g/n 2.400 – 2.500 GHz

802.11a/n 5.180 – 5.825 GHz

Channels 802.11b/g/n 1-13*

802.11a/n 36-165*

Modulation 802.11b CCK and DSSS

802.11a/g/n OFDM

Supported Data Rates 802.11b 1, 2, 5.5, 11 Mbps

802.11a/g 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n MCS0 – MCS15

Supported Bandwidth 802.11n 20 MHz

* Maximum supported channels for 802.11d depends on the region.

Table 20: General Wi-Fi characteristics

5.4.2 Wi-Fi receiver characteristics 2.4 GHz

VCC = 3.3 V, T

Parameter Conditions Antenna port Channel /

Receive sensitivity

= 25 °C

amb

Freq [MHz]

IEEE limit

Typ* Unit

802.11b, Rate = 1 Mbit/s, PER ≤ 8% MAIN port 6 / 2437 -76 -95 dBm

802.11b, Rate = 11 Mbit/s, PER ≤ 8% MAIN port 6 / 2437 -76 -86 dBm

802.11g, Rate = 6 Mbit/s, PER ≤ 10% MAIN port 6 / 2437 -82 -90 dBm

802.11g, Rate = 54 Mbit/s, PER ≤ 10% MAIN port 6 / 2437 -65 -72 dBm

UBX-14039949 - R25 Electrical specification Page 25 of 53 C1-Public

ODIN-W2 series - Data sheet

Parameter Conditions Antenna port Channel /

Freq [MHz]

802.11n SISO, MCS0, PER ≤ 10% MAIN port 6 / 2437 -82 TBD dBm

802.11n MIMO, MCS8, PER ≤ 10% MAIN port 6 / 2437 -82 TBD dBm

802.11n MIMO, MCS8, PER ≤ 10% MIMO port 6 / 2437 -82 TBD dBm

802.11n SISO, MCS7, PER ≤ 10% MAIN port 6 / 2437 -64 TBD dBm

802.11n MIMO, MCS15, PER ≤ 10% MAIN port 6 / 2437 -64 TBD dBm

802.11n MIMO, MCS15, PER ≤ 10% MIMO port 6 / 2437 -64 TBD dBm

Measured conducted on ODIN-W260, measurement tolerance ±1.0 dB.

Table 21: Receiver characteristics for 2.4 GHz Wi-Fi

5.4.3 Wi-Fi receiver characteristics 5 GHz

VCC = 3.3 V, T

Parameter Conditions Channel /

Receive sensitivity

Measured conducted on ODIN-W260, measurement tolerance ±1.0 dB.

Table 22: Receiver characteristics for 5 GHz Wi-Fi

= 25 °C

amb

Freq [MHz]

802.11a, Rate = 6 Mbit/s, PER ≤ 10% 36 / 5180 -82 -90 dBm

100 / 5500 -82 -90 dBm

140 / 5700 -82 -90 dBm

802.11n SISO, MCS0, PER ≤ 10% 36 / 5180 -82 TBD dBm

100 / 5500 -82 TBD dBm

140 / 5700 -82 TBD dBm

802.11a, Rate = 48 Mbit/s, PER ≤ 10% 36 / 5180 -66 -72 dBm

100 / 5500 -66 -72 dBm

140 / 5700 -66 -72 dBm

802.11n SISO, MCS7, PER ≤ 10% 36 / 5180 -64 TBD dBm

100 / 5500 -64 TBD dBm

140 / 5700 -64 TBD dBm

IEEE limit

Typ* Unit

5.4.4 Wi-Fi transmitter characteristics 2.4 GHz

VCC = 3.3 V, T

Parameter Conditions Antenna port Channel /

Transmitting output power

UBX-14039949 - R25 Electrical specification Page 26 of 53 C1-Public

= 25 °C

amb

IEEE EVM

Freq [MHz]

802.11b, Rate = 1 Mbit/s MAIN port 6 / 2437 -14 -28 11.2 dBm

802.11b, Rate = 11 Mbit/s MAIN port 6 / 2437 -14 -26 11.3 dBm

802.11g, Rate = 6 Mbit/s MAIN port 6 / 2437 -5 -21 14.2 dBm

802.11g, Rate = 54 Mbit/s MAIN port 6 / 2437 -25 -29 12.1 dBm

802.11n SISO, MCS0 MAIN port 6 / 2437 -5 -22 14.4 dBm

802.11n MISO, MCS8 MAIN port 6 / 2437 -5 -28 11.5 dBm

802.11n MISO, MCS8 MIMO port 6 / 2437 -5 -25 13.0 dBm

802.11n SISO, MCS7 MAIN port 6 / 2437 -28 -29 12.0 dBm

802.11n MISO, MCS15 MIMO port 6 / 2437 -28 -29 9.3 dBm

802.11n MISO, MCS15 MIMO port 6 / 2437 -28 -30 12.0 dBm

limit

EVM* Typ* Unit

ODIN-W2 series - Data sheet

Measured conducted on ODIN-W260 with maximum output power, measurement tolerance ±1.0 dB.

Regional power limitation can reduce the maximum output power (especially on channels close to band edges).

Table 23: Wi-Fi transmitter characteristics 2.4 GHz

5.4.5 Wi-Fi transmitter characteristics 5 GHz

VCC = 3.3 V, T

Parameter Conditions Channel /

Transmitting output power

Measured conducted on ODIN-W260 with maximum output power, measurement tolerance ±1.0 dB.

Regional power limitation can reduce the maximum output power (especially on channels close to band edges).

Table 24: Wi-Fi transmitter characteristics 5 GHz

= 25 °C

amb

IEEE EVM

Freq [MHz]

802.11a, Rate = 6 Mbit/s 40 / 5180 -5 -26 12.8 dBm

100 / 5500 -5 -25 12.8 dBm

140 / 5700 -5 -26 13.7 dBm

802.11a, Rate = 54 Mbit/s 40 / 5180 -25 -26 12.7 dBm

100 / 5500 -25 -25 12.1 dBm

140 / 5700 -25 -25 13.2 dBm

802.11n SISO, MCS0 40 / 5180 -5 -23 13.1 dBm

100 / 5500 -5 -22 13.2 dBm

140 / 5700 -5 -18 13.3 dBm

802.11n SISO, MCS7 40 / 5180 -28 -29 13.1 dBm

100 / 5500 -28 -28 13.2 dBm

140 / 5700 -28 -28 13.3 dBm

limit

EVM* Typ* Unit

5.4.6 Classic Bluetooth receiver characteristics

VCC = 3.3 V, T

= 25 °C

amb

Parameter Conditions Limit Typ* Min* Unit

Rx sensitivity BR 1Mbit, GFSK, BER ≤ 0.1% -70 -90 dBm

EDR 2Mbit, π/4-DQPSK, BER ≤ 0.007% -70 -90 dBm

EDR 3Mbit, 8DPSK , BER ≤ 0.007% -70 -83 dBm

Maximum input level BR 1Mbit, GFSK, BER ≤ 0.1% -20 -6 dBm

EDR 2Mbit, π/4-DQPSK, BER ≤ 0.1% -20 -10 dBm

EDR 3Mbit, 8DPSK , BER ≤ 0.1% -20 -10 dBm

Measured conducted on ODIN-W260, measurement tolerance ±1.0 dB.

Table 25: Classic Bluetooth receiver sensitivity

5.4.7 Bluetooth Low Energy receiver sensitivity

VCC = 3.3 V, T

Parameter Conditions Limit Typ* Min* Unit

Rx sensitivity PER ≤ 30.8% -70 -95 dBm

Maximum input level PER ≤ 30.8% -10 -6 dBm

Measured conducted on ODIN-W260, measurement tolerance ±1.0 dB.

Table 26: Bluetooth Low Energy receiver sensitivity

= 25 °C

amb

UBX-14039949 - R25 Electrical specification Page 27 of 53 C1-Public

ODIN-W2 series - Data sheet

5.4.8 Classic Bluetooth transmitter characteristics

VCC = 3.3 V, T

Parameter Conditions Typ* Max* Unit

Transmitting output power

Measured conducted on ODIN-W260, measurement tolerance ±1.0 dB.

Table 27: Bluetooth transmitter output power

= 25 °C

amb

BR 1Mbit, GFSK 11.0 11.4 dBm

EDR 2Mbit, π/4-DQPSK 6.5 7.0 dBm

EDR 3Mbit, 8DPSK 6.5 7.0 dBm

5.4.9 Bluetooth Low Energy transmitter characteristics

(VCC = 3.3 V, T

Parameter Test conditions Typ* Max* Unit

Transmitting output power

Measured conducted on ODIN-W260, measurement tolerance ±1.0 dB.

Table 28: Bluetooth Low Energy transmitter characteristics

= 25 °C

amb

6.0 7.0 dBm

UBX-14039949 - R25 Electrical specification Page 28 of 53 C1-Public

ODIN-W2 series - Data sheet

6 Mechanical specifications

6.1 Dimensions

Figure 5: Physical dimensions of ODIN-W260

UBX-14039949 - R25 Mechanical specifications Page 29 of 53 C1-Public

ODIN-W2 series - Data sheet

Figure 6: Physical dimensions of ODIN-W262

6.2 Module weight

Module Typ Unit

ODIN-W260 2 g

ODIN-W262 2 g

Table 29: Module weight

UBX-14039949 - R25 Mechanical specifications Page 30 of 53 C1-Public

ODIN-W2 series - Data sheet

7 Qualification and approvals

7.1 Compliance with the RoHS directive

ODIN-W2 series modules comply with the Directive 2011/65/EU (EU RoHS 2) and its amendment Directive (EU) 2015/863 (EU RoHS 3).

7.2 European Union regulatory compliance

Information about regulatory compliance of the European Union for ODIN-W2 series modules is available in the ODIN-W2 Declaration of Conformity [4]

7.3 Safety compliance

☞ To fulfill EN 60950-1 safety standards, the unit must be supplied by a limited power source.

7.4 FCC and IC Compliance

⚠ ODIN-W263 is configured to always support the ETSI domain and does NOT comply with FCC and

IC. ODIN-W263 is only allowed to be used in countries allowing ETSI domain channels (see Table 3).

7.4.1 IC compliance

This device complies with Industry Canada license-exempt RSS standard(s).

Operation is subject to the following two conditions:

1. this device may not cause interference, and

2. this device must accept any interference, including interference that may cause undesired operation of the device.

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.

⚠ The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the

potential for harmful interference to co-channel mobile satellite systems;

⚠ The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-

5725 MHz shall comply with the e.i.r.p. limit; and

⚠ The maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply

with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate.

⚠ Operation in the 5600-5650 MHz band is not allowed in Canada. High-power radars are

allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.

UBX-14039949 - R25 Qualification and approvals Page 31 of 53 C1-Public

ODIN-W2 series - Data sheet

7.4.2 Conformité aux 32orms d’IC

Cet appareil est conforme à la(aux) norme(s) RSS sans licence d’Industry Canada.

Son utilisation est soumise aux deux conditions suivantes :

1. Cet appareil ne doit pas causer d’interférences et

2. il doit accepter toutes interférences reçues, y compris celles susceptibles d’avoir des effets indésirables sur son fonctionnement.

Conformément aux réglementations d’Industry Canada, cet émetteur radio ne peut fonctionner qu’à l’aide d’une antenne dont le type et le gain maximal (ou minimal) ont été approuvés pour cet émetteur par Industry Canada. Pour réduire le risque d’interférences avec d’autres utilisateurs, il faut choisir le type d’antenne et son gain de telle sorte que la puissance isotrope rayonnée équivalente (p.i.r.e) ne soit pas supérieure à celle requise pour obtenir une communication satisfaisante.

⚠ Le dispositif de fonctionnement dans la bande 5150-5250 MHz est réservé à une utilisation

en intérieur pour réduire le risqué d’interférences nuisibles à la co-canal systèmes mobiles par satellite.

⚠ Le gain d’antenne maximal autorisé pour les appareils dans les bandes 5250-5350 MHz et

5470-5725 MHz doit se conformer à la pire limite, et

⚠ le gain d’antenne maximal autorisé pour les appareils dans la bande 5725-5825 MHz doivent

être conformes avec le pire limites spécifiées à point-à-ponctuelles et non point-à-point de fonctionnement selon qu’il convient.

⚠ Opération dans la bande 5600-5650 MHz n’est pas autorisée au Canada. Haute puissance

radars sont désignés comme utilisateurs principaux (c.-àutilisateurs prioritaires) des bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer des interférences et / ou des dommages à dispositifs LAN-EL.

Cet équipement respecte les limites d’exposition aux rayonnements IC RSS-102 définies pour un environnement non contrôlé. Il doit être installé et utilisé en maintenant une distance minimum de 20 cm entre le radiateur et votre corps.

7.4.3 FCC statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. this device may not cause harmful interference, and

2. this device must accept any interference received, including interference that may cause undesired operation.

☞ This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

UBX-14039949 - R25 Qualification and approvals Page 32 of 53 C1-Public

ODIN-W2 series - Data sheet

This device contains

The ODIN-W2 module is for OEM integrations only. The end-user product will be professionally installed in such a manner that only the authorized antennas are used.

Any changes or modifications NOT explicitly APPROVED by u-blox could cause the module to cease to comply with FCC rules part 15, and thus void the user’s authority to operate the equipment.

7.4.3.1 Cautions

⚠ Any changes or modification could cause the module to cease to comply with

FCC rules part 15 and thus void the user’s authority to operate the equipment.

⚠ §15.407 statement; in case of absence of information to transmit or operational failure the

module types ODIN-W2 will automatically discontinue transmission.

7.4.4 Labeling requirements for end product

For an end product using the ODIN-W260/ODIN-W262 modules there must be a label containing, at least, the following information:

FCC ID: PVH0965 IC: 5325A-0965

The label must be affixed on an exterior surface of the end product such that it will be visible upon inspection in compliance with the modular approval guidelines developed by the FCC.

In accordance with 47 CFR § 15.19 the end product shall bear the following statement in a conspicuous location on the device:

“This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions; (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”

When the device is so small or for such use that it is not practicable to place the statement above on it, the information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed.

In case, where the final product will be installed in locations where the end-user is not able to see the FCC ID and/or this statement, the FCC ID and the statement shall also be included in the end-product manual.

7.4.4.1 IC requirement

If the end product using the ODIN-W2 module is able to operate in the band 5150-5250 MHz within Canada (IC) it is only allowed to be used indoor to reduce the potential for harmful interference to cochannel mobile satellite systems. The label of the end product MUST in this case be marked with the text “For indoor use only”:

UBX-14039949 - R25 Qualification and approvals Page 33 of 53 C1-Public

This device contains FCC ID: PVH0965 IC: 5325A-0965

For indoor use only

ODIN-W2 series - Data sheet

この製品は屋内においてのみ使用可能です

7.5 Japan radio equipment compliance

⚠ ODIN-W263 is configured to always support the ETSI domain and does NOT comply with Japan

radio equipment compliance.

The ODIN-W260/ODIN-W262 module complies with the Japanese Technical Regulation Conformity Certification of Specified Radio Equipment (ordinance of MPT N°. 37, 1981), Article 2, Paragraph 1:

• Item 19 “2.4 GHz band wide band low power data communication system”

• Item 19-3 “Low power data communications system in the 5.2/5.3 GHz band”

• Item 19-3-2 “Low power data communications system in the 5.6 GHz band”

The ODIN-W2 module is restricted on the Japanese market to be used indoors only if the product is operating in the 5.2/5.3 GHz band. The information: “Indoor use only” translated into Japanese (この製品は屋内においてのみ使用可能です) must be visible:

• on the certified end product.

• on the product package in which the end product is marketed.

• in the users / installation manual of the end product.

The indoor usage information is recommended to be printed close to the Giteki mark but it is also permitted to place that information on another prominent position.

☞ The ODIN-W2 MIC certification number is 204-510009. ☞ The very small size of the module makes it not reasonable to fit the GITEKI mark and certification

number onto the module label. Instead the Giteki mark and certification number is available in this document (Figure 7).

When a product integrated with an ODIN-W260/ODIN-W262 module is placed on the Japanese market, it must have either of the following:

• The ODIN-W260/ODIN-W262 module is affixed with a label with the Giteki marking below In this case, it is recommended that the product is marked with “Contains MIC ID: R 204-510009”.

• The product be affixed with a label with the Giteki marking below. The marking must be visible for inspection.

204-510009

Figure 7: Giteki mark, R and the ODIN-W260/ODIN-W262 MIC certification number. The “Indoor use only” information translated into Japanese below is mandatory if the product is operating in the 5.2/5.3 GHz band.

The recommended size of the Giteki mark is Ø5.0 mm but the minimum size is Ø3.0 mm.

The end product holder shall also include a copy of the Japan Radio Certificate to the end product technical documentation. See the Contact information in the end of this document for a copy of the Radio Certificate.

UBX-14039949 - R25 Qualification and approvals Page 34 of 53 C1-Public

ODIN-W2 series - Data sheet

含發射器模組

7.6 SRRC China Radio Transmission Equipment Type Approval

⚠ Only the ODIN-W262 is modular approved for integration in an end product on the Chinese

market.

In accordance with the provisions on the Radio Regulations of the People’s Republic of China, the ODIN-W262 module with the product name ODIN-W262 conforms to the provisions with its CMIIT ID: 2016AJ1533.

7.6.1 ODIN-W262 labeling requirements for end product

The following requirements apply for end products that are sold in China:

• Label with CMIIT ID number of the module is required to be placed on the end product.

• The following statement must be included in Chinese in the Chinese user manual:

CMIIT ID: 2016AJ1533 (This device contains certified RF module which certificate number is CMIIT ID: 2016AJ1533)

7.7 NCC Taiwan compliance

⚠ ODIN-W263 is configured to always support the ETSI domain and does NOT comply with

Taiwan NCC compliance.

7.7.1 Taiwan NCC Warning Statement

• 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變

更原設計之特性及功能。

• 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至

無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

Statement translation:

• Without permission granted by the NCC, any company, enterprise, or user is not allowed to change frequency, enhance transmitting power, or alter original characteristic as well as performance to an approved low power, radio-frequency devices.

• The low power radio-frequency devices shall not influence aircraft security and interfere legal communications; If found, the user shall cease operating immediately until no interference is achieved. The said legal communications means radio communications is operated in compliance with the Telecommunications Act. The low power radio-frequency devices must be susceptible with the interference from legal communications or ISM radio wave radiated devices.

7.7.2 ODIN-W260 labeling requirements for end product

When a product integrated with an ODIN-W260 module is placed on the Taiwan market, the product must be affixed with a label marking as shown below. The label can use wording such as the following:

Contains Transmitter Module

內

or any similar wording that expresses the same meaning may be used. The marking must be visible for inspection.

UBX-14039949 - R25 Qualification and approvals Page 35 of 53 C1-Public

CCAJ16LP1230T0

ODIN-W2 series - Data sheet

含發射器模組

7.7.3 ODIN-W262 labeling requirements for end product

When a product integrated with an ODIN-W262 module is placed on the Taiwan market, the product must be affixed with a label marking as shown below. The label can use wording such as the following:

Contains Transmitter Module

內

or any similar wording that expresses the same meaning may be used. The marking must be visible for inspection.

CCAJ16LP1240T0

7.8 Korean KCC certification

⚠ ODIN-W263 is configured to always support the ETSI domain and does NOT comply with

Korean KCC certification.

The ODIN-W260/ODIN-W262 modules are certified by the Korea Communications Commission (KCC).

The KCC IDs for ODIN-W260 and ODIN-W262 are provided below:

• ODIN-W260 module: MSIP-CRM-ULX-ODIN-W260

• ODIN-W262 module: MSIP-CRM-ULX-ODIN-W262

7.9 Brazil compliance

⚠ ODIN-W263 is configured to always support the ETSI domain and does NOT comply with the

Brazil compliance.

When a product containing ODIN-W260/ODIN-W262 module is placed on the Brazilian market, the product must be affixed with a label or marking containing the Anatel logo, ODIN-W260/ODIN-W262 Homologation number: 03883-16-05903 and a statement claiming that the device may not cause harmful interference but must accept it (Resolution No 506).

03883-16-05903

“Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.”

Statement translation:

“This equipment operates on a secondary basis and, consequently, must accept harmful interference, including from stations of the same kind, and may not cause harmful interference to systems operating on a primary basis.”

UBX-14039949 - R25 Qualification and approvals Page 36 of 53 C1-Public

ODIN-W2 series - Data sheet

APPROVED

TA-2016/2795

In case, where the final product will be installed in locations where the end user is unable to see the Anatel logo, ODIN-W260/ODIN-W262 Homologation number and/or this statement, the Anatel logo, ODIN-W260/ODIN-W262 Homologation number, and the statement shall also be included in the end product manual.

7.10 Australia and New Zealand regulatory compliance

⚠ ODIN-W263 is configured to always support the ETSI domain and does NOT comply with the

Australia or New Zealand regulatory compliance.

The ODIN-W260 and ODIN-W262 modules are compliant with the standards made by the Australian Communications and Media Authority (ACMA).

The modules are compliant with AS/NZS 4268:2012 standard – Radio equipment and systems – Short range devices – Limits and methods of standard measurement. The ODIN-W2 module test reports can be used as part of the product certification and compliance folder. For more information on the test reports, send an email to the respective support team mail address as mentioned in the Contact section based on your location.

To meet overall Australian and/or New Zealand end product compliance, the integrator must create a compliance folder containing all the relevant compliance test reports such as RF, EMC, electrical safety and DoC (Declaration of Conformity) and so on. It is the responsibility of the integrator to know what is required in the compliance folder for ACMA compliance.

For more information on Australia compliance, refer to the Australian Communications and Media Authority web site http://www.acma.gov.au/.

For more information on New Zealand compliance, refer to the New Zealand Radio Spectrum Management Group web site www.rsm.govt.nz.

7.11 South Africa regulatory compliance

⚠ ODIN-W263 is configured to always support the ETSI domain and does NOT comply with the

South Africa regulatory compliance.

The ODIN-W260/ODIN-W262 modules are compliant and certified by the Independent Communications Authority of South Africa (ICASA). End products that are made available for sale or lease or is supplied in any other manner in South Africa shall have a legible label permanently affixed to its exterior surface. The label shall have the ICASA logo and the ICASA issued license number as shown in the figure below. The minimum width and height of the ICASA logo shall be 3 mm. The approval labels must be purchased by the customer’s local representative directly from the approval authority ICASA. A sample of an ODIN-W260/ODIN-W262 ICASA label is included below:

UBX-14039949 - R25 Qualification and approvals Page 37 of 53 C1-Public

ODIN-W2 series - Data sheet

More information on registration as a Responsible Integrator and labeling requirements can be found at the following website:

Independent Communications Authority of South Africa (ICASA) web site – https://www.icasa.org.za

7.12 Bluetooth qualification information

End products are required to be qualified and listed for the Bluetooth Special Interest Group (SIG).

Product declarations are submitted through the Bluetooth SIG Launch Studio website.

The ODIN-W2 series modules have been qualified according to the Bluetooth 4.0 and the 4.2 specification.

To list your product that integrates ODIN-W2 towards the Bluetooth 4.2 specification as an End product with no required testing, combine the pre-qualified Controller Subsystem (QD ID 156961) and the Host Subsystem (QD ID 151198) listed in the table below.

⚠ Listing ODIN-W2 towards the Bluetooth 4.2 specification is only possible for Software version

8.0.0 and onwards.

To list your product that integrates ODIN-W2 towards the Bluetooth 4.0 specification as an End product with no required testing, combine the pre-qualified Controller Subsystem (QD ID 71681) and the Host Subsystem (QD ID 40911) listed in the table below.

End product specification Product type QD ID Listing date

4.2 Controller Subsystem 156961 17-Nov-2020

4.2 Host Subsystem 151198 30-Sep-2020

4.0 Controller Subsystem 71681 28-Aug-2015

4.0 Host Subsystem 40911 29-Jan-2013

Table 30: ODIN-W2 Bluetooth IDs

UBX-14039949 - R25 Qualification and approvals Page 38 of 53 C1-Public

ODIN-W2 series - Data sheet

8 Antennas

This chapter gives an overview of the different external antennas that can be fitted to the ODIN-W2 module.

⚠ This radio transmitter IC: 5325A-0965 has been approved by Industry Canada to operate with

the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.

⚠ Cet émetteur radio IC : 5325A-0965 été approuvé par Industry Canada pour fonctionner avec

les types d’antenne énumérés ci-dessous avec le gain maximum autorisé et l’impédance nécessaire pour chaque type d’antenne indiqué. Les types d’antenne ne figurant pas dans cette liste et ayant un gain supérieur au gain maximum indiqué pour ce type-là sont strictement interdits d’utilisation avec cet appareil.

For each antenna, the “Approvals” field defines in which test reports the antenna is included. Definitions of the «Approvals» field are:

• FCC – The antenna is included in the FCC test reports and thus approved for use in countries that accept the FCC radio approvals, primarily US.

• IC – The antenna is included in the IC (Industrie Canada) test reports and thus approved for use in countries that accept the IC radio approvals, primarily Canada.

• RED – The antenna is included in the ETSI test reports and thus approved for use in countries that accept the Radio Equipment Directive, primarily the European countries.

• MIC – The antenna is included in the Japanese government affiliated MIC test reports and thus approved for use in the Japanese market.

• NCC – The antenna is included in the Taiwan NCC test reports and thus approved for use in Taiwan.

• KCC – The antenna is included in the Korea KCC test reports and thus approved for use in Korea.

• ANATEL – The antenna is included in the Brazil Anatel test reports and thus approved for use in

Brazil.

• ICASA – The antenna is included in the South Africa ICASA test reports and thus approved for use in South Africa.

In general, antennas with SMD connection, Reverse Polarity SMA connector or U.FL connector are included in FCC, IC, RED, NCC, MIC, ANATEL and ICASA radio tests. The antennas with SMA connector are included in RED, NCC, MIC, ANATEL and ICASA radio tests but not in the FCC or IC due to FCC/IC regulations. Only dual band antennas are allowed to be used on the main antenna port (see section 2.2.1) in Korea.

⚠ Only the ODIN-W262 with internal antenna is modular approved for the China market. The

ODIN-W260 with antenna connectors to be used with the external antennas is not approved to be used on the China market.

The external antennas are connected to the board through U.FL connectors. Some antennas are connected directly to the U.FL connector of the board while some are connected using an SMA or reversed polarity SMA connector through a short U.FL to SMA or reversed polarity SMA adapter cable.

UBX-14039949 - R25 Antennas Page 39 of 53 C1-Public

ODIN-W2 series - Data sheet

8.1 Antenna accessories

Name U.FL to SMA adapter cable

Connector U.FL and SMA jack (outer thread and pin receptacle)

Impedance 50 Ω

Cable length 100-125 mm

Minimum cable loss 0.5 dB, The cable loss must be above the minimum

cable loss to meet the regulatory requirements

Comment The SMA connector can be mounted in a panel

Approval RED, MIC, NCC, KCC, ANATEL, and ICASA

Name U.FL to Reverse Polarity SMA adapter cable

Connector U.FL and Reverse Polarity SMA jack (outer thread and

pin)

Impedance 50 Ω

Cable length 100-125 mm

Minimum cable loss 0.5 dB, The cable loss must be above the minimum

cable loss to meet the regulatory requirements

Comment The Reverse Polarity SMA connector can be mounted in

a panel

Approval FCC, IC, RED, MIC, NCC, KCC, ANATEL, and ICASA

8.2 Approved antennas

8.2.1 Single band antennas

Ex-IT 2400 RP-SMA 28-001

Manufacturer ProAnt

Polarization Vertical

Gain +3.0 dBi

Impedance 50 Ω

Size Ø 12.0 x 28.0 mm

Type Monopole

Connector Reverse Polarity SMA plug (inner thread and pin receptacle). To be mounted on

the U.FL to Reverse Polarity SMA adapter cable.

Comment An SMA version antenna is also available but not recommended for use (Ex-IT

2400 SMA 28-001).

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

Ex-IT 2400 MHF 28

Manufacturer ProAnt

Polarization Vertical

Gain +2.0 dBi

Impedance 50 Ω

Size Ø 12.0 x 28.0 mm

Type Monopole

Cable length 100 mm

Connector U.FL. connector

Comment To be mounted on the U.FL connector on the PCB.

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

UBX-14039949 - R25 Antennas Page 40 of 53 C1-Public

ODIN-W2 series - Data sheet

Ex-IT 2400 RP-SMA 70-002

Manufacturer ProAnt

Polarization Vertical

Gain +3.0 dBi

Impedance 50 Ω

Size Ø 10 x 83 mm

Type Monopole

Connector Reverse Polarity SMA plug (inner thread and pin receptacle)

Comment To be mounted on the U.FL to Reverse Polarity SMA adapter cable

(cB-ACC-38). An SMA version antenna is also available but not recommended for use (Ex-IT 2400 SMA 70-002).

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

Ex-IT 2400 MHF 70-001

Manufacturer ProAnt

Polarization Vertical

Gain +3.0 dBi

Impedance 50 Ω

Size Ø 9.4 x 70.5 mm

Type Monopole

Cable length 100 mm

Connector U.FL. connector

Comment To be mounted on the U.FL connector on the PCB.

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

InSide-2400

Manufacturer ProAnt

Gain +3.0 dBi

Impedance 50 Ω

Size 27 x 12 mm (triangular)

Type Patch

Cable length 100 mm

Connector U.FL. connector

Comment To be mounted on the U.FL connector on the PCB.

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

FlatWhip-2400

Manufacturer ProAnt

Gain +3.0 dBi

Impedance 50 Ω

Size Ø 50.0 x 30.0 mm

Type Monopole

Connector SMA plug (inner thread and pin)

Comment To be mounted on the U.FL to SMA adapter cable.

Approval RED, MIC, NCC, KCC*, ANATEL, and ICASA

UBX-14039949 - R25 Antennas Page 41 of 53 C1-Public

ODIN-W2 series - Data sheet

Outside-2400

Manufacturer ProAnt

Gain +3.0 dBi

Impedance 50 Ω

Size 36.0 x 18.0 x 16.0 mm

Type Patch

Cable length 70 mm

Connector U.FL. connector

Comment To be mounted on the U.FL connector on the PCB.

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

In Korea is only dual band antennas allowed on the main antenna port and 2.4 GHz single band antennas are only allowed on

the MIMO antenna port.

8.2.2 Dual-band antennas

InSide-WLAN

Manufacturer ProAnt

Gain +3.0 dBi

Impedance 50 Ω

Size 27 x 12 mm (triangular)

Type Patch

Cable length 100 mm

Connector U.FL. connector

Comment Dual-band (2.4 GHz/ 5 GHz) antenna to be mounted on the U.FL connector

on the PCB.

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

InSide-WLAN Square

Manufacturer ProAnt

Gain +3.0 dBi

Impedance 50 Ω

Size 24x22x1 mm with mounting hole

Type Patch

Cable length 100 mm

Connector U.FL. connector

Comment Dual-band (2.4 GHz / 5 GHz) antenna to be mounted on the U.FL

connector on the PCB.

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

UBX-14039949 - R25 Antennas Page 42 of 53 C1-Public

ODIN-W2 series - Data sheet

Ex-IT WLAN RPSMA / Ex-IT WLAN SMA

Manufacturer ProAnt

Type ½ wave dipole dual-band antenna

Polarization Vertical

Gain +3 dBi

Impedance 50 Ω

Size 107 mm (Straight)

Type Monopole

Connector Reverse Polarity SMA plug (inner thread and pin receptacle)

SMA plug (inner thread and pin)

Comment To be mounted on the U.FL to SMA or reverse polarity SMA adapter

cable.

Approval FCC, IC, RED, MIC, NCC, KCC*, ANATEL, and ICASA

UBX-14039949 - R25 Antennas Page 43 of 53 C1-Public

ODIN-W2 series - Data sheet

9 Product handling and soldering

9.1 Packaging

ODIN-W2 series modules are delivered as hermetically sealed, reeled tapes to enable efficient production, production lot set-up and tear-down. For more information about packaging, see the u-blox package Information guide [3].

9.1.1 Reels

ODIN-W2 series modules are delivered on the reel as described in Table 31:

Parameter Specification

Reel type B2

Delivery quantity 200

Table 31: Reel information for ODIN-W2 series modules

9.1.2 Tapes

Figure 8 shows the position and the orientation of ODIN-W2 modules as they are delivered on the tape, while Figure 9 specifies the tape dimensions.

Figure 8: Orientation for ODIN-W2 modules on tape

UBX-14039949 - R25 Product handling and soldering Page 44 of 53 C1-Public

ODIN-W2 series - Data sheet

Figure 9: ODIN-W2 series tape dimensions

9.2 Moisture sensitivity levels

⚠ ODIN-W2 series modules are Moisture Sensitive Devices (MSD) in accordance with the

IPC/JEDEC specification.

The Moisture Sensitivity Level (MSL) relates to the required packaging and handling precautions. The ODIN-W2 series modules are rated at MSL level 4. For more information regarding moisture sensitivity levels, labeling, and storage, see the u-blox package information guide [3].

☞ For MSL standards, see IPC/JEDEC J-STD-020, which can be downloaded from www.jedec.org.

9.3 Reflow soldering

Reflow profiles are to be selected according to u-blox recommendations. See also the ODIN-W2 series system integration manual [2].

⚠ Failure to observe these recommendations can result in severe damage to the device.

9.4 ESD precautions

⚠ ODIN-W2 series modules contain highly sensitive electronic circuitry and are Electrostatic

Sensitive Devices (ESD). Handling the ODIN-W2 series modules without proper ESD protection may destroy or damage them permanently.

ODIN-W2 series modules are electrostatic sensitive devices (ESD) and require special ESD precautions typically applied to ESD sensitive components. The Maximum ESD section reports the maximum ESD ratings of the ODIN-W2 series modules.

Proper ESD handling and packaging procedures must be applied throughout the processing, handling and operation of any application that incorporates the ODIN-W2 series module. The ESD precautions should be implemented on the application board where the module is mounted as described in the ODIN-W2 series System Integration Manual [2]

⚠ Failure to observe these recommendations can result in severe damage to the device.

UBX-14039949 - R25 Product handling and soldering Page 45 of 53 C1-Public

ODIN-W2 series - Data sheet

10 Labeling and ordering information

10.1 Label information

The labels of the ODIN-W2 series modules include important product information as described in this section.

Figure 8 illustrates the label of all the ODIN-W2 series modules, which includes product type number and revision, production date, Data Matrix with unique serial number (MAC address), u-blox logo and regulatory certification numbers (if applicable). Because of space constraints, all certification numbers are not printed on the label (see Qualification and approvals section for all certification IDs).

Figure 10: Location of product type number on the ODIN-W262-01B module label

Reference Description

1 Text area containing product model name

2 Text area containing regulatory certification IDs

3 Text area containing Product Revision and date of production

3a Major and minor product version info

3b Date of unit production encoded YY/WW (year, week)

4 Data Matrix with unique serial number of 19 alphanumeric symbols. The 3 first symbols represent a

unique module type number. The next 12 symbols represent the unique hexadecimal Ethernet MAC address of the module AABBCCDDEEFF, and the last 4 symbols represent the hardware and software version encoded HHFF.

See section 1.8 for more information about MAC addresses.

5 Certifications logos area

6 u-blox logo. Preprinted on label. The red dot is also indicating pin 1.

Table 32: Label description of ODIN-W260 and ODIN-W262 standard product.

UBX-14039949 - R25 Labeling and ordering information Page 46 of 53 C1-Public

ODIN-W2 series - Data sheet

mode module with dual

band

W263 is configured to always support the ETSI domain and is only allowed to be used in countries

10.2 Explanation of codes

Three different product code formats are used. The Product Name is used in documentation such as this data sheet and identifies all u-blox products, independent of packaging and quality grade. The Ordering Code includes options and quality, while the Type Number includes the hardware and software versions. Table 34 below details these three different formats:

Format Structure

Product Name PPPP-TGRV

Ordering Code PPPP –TGRV-TTQ

Type Number PPPP –TGRV-TTQ-XX

Table 33: Product code formats

Table 35 explains the parts of the product code.

Code Meaning Example

PPPP Form factor ODIN

TG Platform (Technology and Generation)

T – Dominant technology, For example, W: Wi-Fi, B: Bluetooth G – Generation

R Wireless technology; range [0...9] 6: Multi-radio dual-band 2.4+5GHz

V Variant based on the same platform; range [00…99] 0: default mounting, with connector for external

TT Major Product Version 00: first revision

Q Quality grade

A: Automotive B: Professional C: Standard X: ATEX

XX Minor product version (not relevant for certification) Default value is 00

Table 34: Part identification code

W2: Wi-Fi Generation 2

antenna

B: professional grade

10.3 Ordering information

Ordering code Product

ODIN-W260-05B Wi-Fi IEEE802.11a/b/g/n (dual-band) 2.4 GHz 2x2 MIMO and Bluetooth dual-

U.FL. coaxial antenna connectors. u-blox connectivity software version 6.0.0.

ODIN-W260-06B Wi-Fi IEEE802.11a/b/g/n (dual-band) 2.4 GHz 2x2 MIMO and Bluetooth dual-

U.FL. coaxial antenna connectors. u-blox connectivity software version 7.1.0.

ODIN-W262-05B Wi-Fi IEEE802.11a/b/g/n (dual-band) and Bluetooth dual-mode module with internal dual-

antenna. u-blox connectivity software version 6.0.0.

ODIN-W262-06B Wi-Fi IEEE802.11a/b/g/n (dual-band) and Bluetooth dual-mode module with internal dual-

antenna. U-blox connectivity software version 7.1.0.

ODIN-W263-06B Wi-Fi IEEE802.11a/b/g/n (dual-band) and Bluetooth dual-mode module with internal dual-

antenna. u-blox connectivity software version 7.1.0. ODIN-

allowing ETSI domain channels.

Table 35: Product ordering codes

UBX-14039949 - R25 Labeling and ordering information Page 47 of 53 C1-Public

ODIN-W2 series - Data sheet

Appendix

A Glossary

Abbreviation Definition

ADC

BT Bluetooth

CAN Controller area network

CTS Clear to send

DC Direct current

DSR Data set ready

DTR Data terminal ready

EIRP Equivalent isotropically radiated power

GND Ground

GPIO General purpose input output

H High

HW Hardware

I Input (means that this is an input port of the module)

IEEE Institute of Electrical and Electronics Engineers

L Low

LPO Low power oscillator

MIMO Multi-Input Multi-Output

N/A Not applicable

O Output (means that this is an output port of the module)

PCN / IN Product change notification / Information note

PD Pull-Down

PU Pull-Up

RMII Reduced media independent interface

RTS Request to send

RXD Receive data

SMI Station management interface

SPI Serial peripheral interface

TXD Transmit data

UART Universal Asynchronous Receiver-Transmitter serial interface

ASCII American Standard Code for Information Interchange

ARM Arm (Advanced RISC Machines) Holdings

AEC Automotive electronics council

BBR Battery backed RAM

BER Bit error rate

CPU Central processing unit

UTC Coordinated universal time

DCE Data circuit-terminating equipment* / Data communication equipment*

DTE Data terminal equipment

DC Direct current

DRX Discontinuous reception

DDC Display data channel

Analog to digital converter

UBX-14039949 - R25 Appendix Page 48 of 53 C1-Public

ODIN-W2 series - Data sheet

Abbreviation Definition

DL Down link (Reception)

Table 36: Explanation of the abbreviations and terms used

UBX-14039949 - R25 Appendix Page 49 of 53 C1-Public

ODIN-W2 series - Data sheet

Revision history

Revision Date Name Comments

R01

R02 16-Feb-2015 fbro Minor updates

R03 23-Apr-2015 ajoh Updated features list, added

R04 08-July-2015 fbro, kgom Applied u-blox word template.

R05 22-Sept-2015 mwej, kgom

R06 29-Jan-2016 mwej, pber Added ETSI, FCC, IC, Japan approval certification information

R07 16-Jun-2016 mwej, kgom Updated product features (Table 1). Modified Updated to product version ODIN-

R08 18-Jul-2016 mwej, kgom

R09 06-Oct-2016 mwej, kgom Updated the Product features (Table 1

R10 02-Dec-2016 mwej

R11 10-Jan-2017 ajoh, ecar,

R12 30-Mar-2017 mwej Updated Product ordering codes (Table 36). Included support for ODIN-

R13 01-Sep-2017 mwej, kgom Included support for ODIN-W2 software version 4.0.1. Updated Table 1

R14 22-Dec-2017 mwej Added support for ODIN-

R15 26-Jan-2018 ecar, kgom Included support for ODIN-W2 software version 5.0.1. In Table 36

R16 11-Jul-2018 mwej, kgom Included support for ODIN-W2 software version 6.0.0. Updated Table 1.

R17 14-Nov-2018 mwej, mhan Included support for ODIN-W2 software version 6.0.1. Updated information about

UBX-14039949 - R25 Revision history Page 51 of 53 C1-Public

05-Sep-2014 mwej Initial release.

specification.

mechanical outline. Updated performance measurements with ODIN-

Table 1 similar to the ODIN-W2 series Product Summary.

reference to ODIN-W2 Declaration of Conformity (UBXDocument status to Ea characteristics (will be added when supported). Modified Table 1 and Table 2 Updated section 1.1 and section 5.4 (values in Table 21 to Table 28).

W260-01B and ODIN-W262-

10.2). Added MAC address information (section 1.8 implemented and current consumption reduced in idle mode (modified Table 15 – Table 19 (section 7.8 and section 8). Updated order information (Table 36).

and New Zealand (section 7.9).

with Firmware 3.0. Added antenna type information in section 8.2 Australia and New Zealand compliance information (section 7.9 orientation (section 9.1.2 regulatory compliance (section 7.2) and provided reference to the ODINDeclaration of Conformity (UBX-15024695).

points (TP) to 51 in Figure 5. Removed reference to System Integration Manu section 7.5. Added channel information in Access Point mode (Table 2 information about support for IEEE 802.11d/e/i/h (h:DFS client only) in Table 2.

Updated Product ordering codes. Included support for ODIN-

kgom

versions – restriction.

firmware version – Africa (chapters 7 and 8).

7.13, and section 10. Added information about cable length limitation (section 2 and 0). Replaced R&TTE with RED (chapter 8). Replaced firmware with software.

802.11n. Updated the power consumption for Wi-Fi (section 5.3 ordering information (Table 36).

uODIN-W26x-04B.

MAC address example (section 1.8).

ODIN-W2 ATEX certified variants (section 7.13 with additional variants (Table 36).

). Updated product

ODIN-W2 series - Data sheet

Updated product version table on page 2 with hardware version. Removed

Removed

Added

Included RoHS 3 compliance

Added

Revision Date Name Comments

R18 18-Dec-2018 mwej

ODIN-W260-00B and ODIN-W262-00B from orderable products (section 10.3 Added information about Wi-Fi channel bandwidth (sections 1.5 and 5.4.1).

R19 10-Sep-2019 mwej, kgom Included support for ODIN-W2 software version 7.1.0. Updated Table 1.

information about ODIN-W2 software version 4.0.0 and earlier. information about System IO signals (section 3.3). (section 7.1).

R20 19-Dec-2019 mwej Added ODIN-W263-06B product variant.

R21 5-Jun-2020 mwej Updated applicable product version table on page 2.

R22 8-Jun-2020 hekf Added ESD indirect contact discharge and footnote in section 5.1.1.

R23 10-Sep-2020 mlju Updated the product status of applicable products in Document information.

R24 6-Oct-2020 ecar, mape Removed obsolete (EOL) variants from Document information.

Slave -> Peripheral

R25 3-Mar-2021 mwej, fkru Updated to Bluetooth 4.2. Removed -04B and -05X products in Table 36.

Bluetooth 4.2 and Bluetooth SIG listing details.

UBX-14039949 - R25 Revision history Page 52 of 53 C1-Public

ODIN-W2 series - Data sheet

Contact

For complete contact information, visit us at www.u-blox.com.

u-blox Offices

North, Central and South America

u-blox America, Inc.

Phone: +1 703 483 3180 E-mail: info_us@u-blox.com

Regional Office West Coast:

Phone: +1 408 573 3640 E-mail: info_us@u-blox.com

Technical Support:

Phone: +1 703 483 3185 E-mail: support@u-blox.com

Headquarters Europe, Middle East, Africa

u-blox AG

Phone: +41 44 722 74 44 E-mail: info@u-blox.com Support: support@u-blox.com

Asia, Australia, Pacific

u-blox Singapore Pte. Ltd.

Phone: +65 6734 3811 E-mail: info_ap@u-blox.com Support: support_ap@u-blox.com

Regional Office Australia:

Phone: +61 3 9566 7255 E-mail: info_anz@u-blox.com Support: support_ap@u-blox.com

Regional Office China (Beijing):

Phone: +86 10 68 133 545 E-mail: info_cn@u-blox.com Support: support_cn@u-blox.com

Regional Office China (Chongqing):

Phone: +86 23 6815 1588 E-mail: info_cn@u-blox.com Support: support_cn@u-blox.com

Regional Office China (Shanghai):

Phone: +86 21 6090 4832 E-mail: info_cn@u-blox.com Support: support_cn@u-blox.com

Regional Office China (Shenzhen):

Phone: +86 755 8627 1083 E-mail: info_cn@u-blox.com Support: support_cn@u-blox.com

Regional Office India:

Phone: +91 80 405 092 00 E-mail: info_in@u-blox.com Support: support_in@u-blox.com

Regional Office Japan (Osaka):

Phone: +81 6 6941 3660 E-mail: info_jp@u-blox.com Support: support_jp@u-blox.com

Regional Office Japan (Tokyo):

Phone: +81 3 5775 3850 E-mail: info_jp@u-blox.com Support: support_jp@u-blox.com

Regional Office Korea:

Phone: +82 2 542 0861 E-mail: info_kr@u-blox.com Support: support_kr@u-blox.com

Regional Office Taiwan:

Phone: +886 2 2657 1090 E-mail: info_tw@u-blox.com Support: support_tw@u-blox.com

UBX-14039949 - R25 Contact Page 53 of 53 C1-Public

u-blox ODIN-W2 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Abstract

Document information

Contents

1 Functional description

1.1 Overview

1.2 Applications

1.3 Product features

1.4 Block diagram

1.5 Product description

1.6 AT command support

1.7 IEEE 802.11d and additional regulatory domains

1.7.1 ODIN-W2 IEEE 802.11d implementation description

1.8 MAC addresses

2 Interfaces

2.1 Power management

2.1.1 Module supply input (VCC)

2.1.2 Digital I/O interfaces supply output (V_INT)

2.2 Antenna interfaces

2.2.1 Antenna connectors and internal antenna

2.3 Data communication interfaces

2.3.1 UART interface

2.3.2 Ethernet interface

2.3.2.1 RMII

2.3.2.2 SMI (MDC/MDIO management interface)

3 System functions

3.1 Module power modes

3.2 Module reset

3.3 IO signals

3.3.1 System status IO signals

3.3.2 System control IO signals

3.3.3 UART IO signals

4 Pin definition

4.1 Pin assignment

5 Electrical specification

5.1 Absolute maximum ratings

5.1.1 Maximum ESD

5.2 Operating conditions

5.2.1 Temperature range

5.2.2 Power supply

5.2.3 I/O DC characteristics

5.2.4 Reset characteristics

5.2.5 LPO clock

5.2.6 Universal asynchronous serial interface (UART)

Power consumption

5.3.1 General power consumption

5.3.2 Wi-Fi 2.4 GHz power consumption

5.3.3 Wi-Fi 5 GHz power consumption

5.3.4 Classic Bluetooth power consumption

5.3.5 Bluetooth Low Energy (LE) power consumption

5.4 RF characteristics

5.4.1 Wi-Fi radio characteristics

5.4.2 Wi-Fi receiver characteristics 2.4 GHz

5.4.3 Wi-Fi receiver characteristics 5 GHz

5.4.4 Wi-Fi transmitter characteristics 2.4 GHz

5.4.5 Wi-Fi transmitter characteristics 5 GHz

5.4.6 Classic Bluetooth receiver characteristics

5.4.7 Bluetooth Low Energy receiver sensitivity

5.4.8 Classic Bluetooth transmitter characteristics

5.4.9 Bluetooth Low Energy transmitter characteristics

6 Mechanical specifications

6.1 Dimensions

6.2 Module weight

7 Qualification and approvals

7.1 Compliance with the RoHS directive

7.2 European Union regulatory compliance

7.3 Safety compliance

7.4 FCC and IC Compliance

7.4.1 IC compliance

7.4.3 FCC statement

7.4.3.1 Cautions

7.4.4 Labeling requirements for end product

7.4.4.1 IC requirement

7.5 Japan radio equipment compliance

7.6 SRRC China Radio Transmission Equipment Type Approval

7.6.1 ODIN-W262 labeling requirements for end product

7.7 NCC Taiwan compliance
