Ublox NEO-6, MAX-6, LEA-6 Integration Manual

This document describes the features and specifications of the cost effective and high-performance LEA-6, NEO-6 and MAX-6 GPS and GPS/GLONASS/QZSS modules featuring the u-blox 6 positioning engine.
These compact, easy to integrate stand-alone positioning modules combine exceptional performance with highly flexible power, design, and connectivity options. Their compact form factors and SMT pads allow fully automated assembly with standard pick & place and reflow soldering equipment for cost-efficient, high­volume production enabling short time-to-market.
www.u-blox.com
UBX-14054794 - R15
LEA-6 / NEO-6 / MAX-6
u-blox 6 GLONASS, GPS & QZSS modules
Hardware Integration Manual
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Document Information
Title
LEA-6 / NEO-6 / MAX-6
Subtitle
u-blox 6 GLONASS, GPS & QZSS modules
Document type
Hardware Integration Manual
Document number
UBX-14054794
Revision and Date
R15
26-Sep-2017
Document status
Production Information
Document status explanation
Objective Specification
Document contains target values. Revised and supplementary data will be published later.
Advance Information
Document contains data based on early testing. Revised and supplementary data will be published later.
Early Production Information
Document contains data from product verification. Revised and supplementary data may be published later.
Production Information
Document contains the final product specification.
European Union regulatory compliance
Name
Type number
ROM/FLASH version
LEA-6H
All LEA-6H-0-002
FW6.02, FW 7.01, FW 7.03 FW1.00
LEA-6N
All
FW1.00
LEA-6S
All
ROM6.02, ROM7.03
LEA-6A
All
ROM6.02, ROM7.03
LEA-6T-0
All
ROM6.02, ROM7.03
LEA-6T-1
All
FW 7.03
LEA-6T-2
All
FW 6.02
LEA-6R
All
FW DR 1.0, FW 7.03 DR2.0, FW 7.03 DR2.02
NEO-6G
All
ROM6.02, ROM7.03
NEO-6Q
All
ROM6.02, ROM7.03
NEO-6M
All
ROM6.02, ROM7.03
NEO-6P
All
ROM6.02
NEO-6T
All
ROM7.03
NEO-6V
All
ROM7.03
MAX-6G
All
ROM7.03
MAX-6Q
All
ROM7.03
LEA-NEO-MAX-6 complies with all relevant requirements for RED 2014/53/EU. The LEA-NEO-MAX-6 Declaration of Conformity (DoC) is available at www.u-blox.com within Support > Product resources > Conformity Declaration.
This document applies to the following products:
u-blox reserves all rights to this document and the information contained herein. Products, names, logos and designs described herein may in whole or in part be subject to intellectual property rights. Reproduction, use, modification or disclosure to third parties of this document or any part thereof without the express permission of u-blox is strictly prohibited. The information contained herein is provided “as is” and u-blox assumes no liability for the use of the information. No warranty, either express or implied, is given, including but not limited, with respect to the accuracy, correctness, reliability and fitness for a particular purpose of the information. This document may be revised by u-blox at any time. For most recent documents, visit www.u-blox.com.
Copyright © 2017, u-blox AG. u-blox is a registered trademark of u-blox Holding AG in the EU and other countries.
UBX-14054794 Production Information Preface Page 2 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Preface
u-blox Technical Documentation
As part of our commitment to customer support, u-blox maintains an extensive volume of technical documentation for our products. In addition to our product-specific technical data sheets, the following manuals are available to assist u-blox customers in product design and development.
GPS Compendium: This document, also known as the GPS book, provides a wealth of information
regarding generic questions about GPS system functionalities and technology.
Receiver Description and Protocol Specification: Messages, configuration and functionalities of the u-
blox M8 software releases and receivers are explained in this document.
Hardware Integration Manual: This Manual provides hardware design instructions and information on
how to set up production and final product tests.
Application Note: Provides general design instructions and information that applies to all u-blox GNSS
receivers. See section Related documents for a list of Application Notes related to your GNSS receiver.
How to use this manual
This manual has a modular structure. It is not necessary to read it from the beginning to the end. The following symbols are used to highlight important information within the manual:
An index finger points out key information pertaining to chipset integration and performance.
A warning symbol indicates actions that could negatively impact or damage the receiver.
Questions
If you have any questions about u-blox M8 Hardware Integration:
Read this manual carefully. Contact our information service on the homepage www.u-blox.com. Read the questions and answers on our FAQ database on the homepage.
Technical support
Worldwide web
Our website (www.u-blox.com) is a rich pool of information. Product information, technical documents and helpful FAQ can be accessed 24h a day.
By E-mail
If you have technical problems or cannot find the required information in the provided documents, contact the nearest Technical Support office. Use the email addresses in the contact details at the end of this document rather than a personal email address of our staff. This ensures that your request is processed as soon as possible.
Helpful information when contacting technical support
When contacting Technical Support, have the following information ready:
Receiver type (e.g. LEA-6A-0-000), Datacode (e.g. 160200.0300.000) and firmware version (e.g. FW6.02) Receiver configuration Clear description of your question or the problem together with a u-center logfile A short description of the application Your complete contact details
UBX-14054794 Production Information Preface Page 3 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Contents
Preface ................................................................................................................................ 3
Contents .............................................................................................................................. 4
1 Hardware description .................................................................................................. 7
1.1 Overview .............................................................................................................................................. 7
1.2 Architecture .......................................................................................................................................... 7
1.3 Power management ............................................................................................................................. 8
1.3.1 Connecting power ........................................................................................................................ 8
1.3.2 Operating modes .......................................................................................................................... 9
1.4 Antenna supply - V_ANT (LEA-6) .......................................................................................................... 9
1.5 System functions ................................................................................................................................ 10
1.5.1 System monitoring ...................................................................................................................... 10
1.6 Interfaces ............................................................................................................................................ 10
1.6.1 UART ........................................................................................................................................... 10
1.6.2 USB (LEA-6/NEO-6) ...................................................................................................................... 10
1.6.3 Display Data Channel (DDC) ........................................................................................................ 11
1.6.4 SPI (NEO-6, LEA-6R) ..................................................................................................................... 13
1.7 I/O pins ............................................................................................................................................... 16
1.7.1 RESET_N ...................................................................................................................................... 16
1.7.2 EXTINT - External interrupt pin ..................................................................................................... 16
1.7.3 AADET_N (LEA-6) ........................................................................................................................ 16
1.7.4 Configuration pins (LEA-6S/6A, NEO-6) ....................................................................................... 16
1.7.5 Second time pulse for LEA-6T-0 and LEA-6T-1 ............................................................................. 16
1.7.6 TX ready signal (FW 7.0x) ............................................................................................................ 17
1.7.7 ANTOFF (NEO-6) .......................................................................................................................... 17
1.7.8 Antenna supervision signals for LEA-6T-0 .................................................................................... 17
1.7.9 LEA-6R considerations ................................................................................................................. 18
2 Design-in ..................................................................................................................... 19
2.1 Checklist ............................................................................................................................................. 19
2.1.1 Design-in checklist ....................................................................................................................... 19
2.1.2 Design considerations .................................................................................................................. 21
2.1.3 Automotive Dead Reckoning (ADR) solutions .............................................................................. 22
2.2 LEA-6 design ...................................................................................................................................... 23
2.2.1 LEA-6 passive antenna design ...................................................................................................... 23
2.2.2 GLONASS HW design recommendations (LEA-6N, LEA-6H-0-002) ............................................... 25
2.2.3 LEA-6R design ............................................................................................................................. 28
2.2.1 Pin description for LEA-6 designs ................................................................................................. 32
2.3 NEO-6 design ..................................................................................................................................... 33
2.3.1 Passive antenna design (NEO-6) ................................................................................................... 33
2.3.2 Pin description for NEO-6 designs ................................................................................................ 35
2.4 MAX-6 design .................................................................................................................................... 36
UBX-14054794 Production Information Contents Page 4 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
2.4.1 MAX-6 passive antenna design.................................................................................................... 36
2.4.2 Pin description for MAX-6 designs ............................................................................................... 37
2.5 Layout ................................................................................................................................................ 37
2.5.1 Footprint and paste mask ............................................................................................................ 37
2.5.2 Placement ................................................................................................................................... 39
2.5.3 Antenna connection and grounding plane design ....................................................................... 40
2.5.4 Antenna micro strip ..................................................................................................................... 41
2.6 Antenna and antenna supervisor ........................................................................................................ 42
2.6.1 Passive antenna ........................................................................................................................... 43
2.6.2 Active antenna (LEA-6) ................................................................................................................ 43
2.6.3 Active antenna bias power (LEA-6) .............................................................................................. 44
2.6.4 Active antenna supervisor (LEA-6)................................................................................................ 45
2.6.5 Active antenna (NEO-6 and MAX-6) ............................................................................................ 48
2.6.6 External active antenna supervisor using ANTOFF (NEO-6) ........................................................... 50
2.6.7 External active antenna supervisor using ANTON (MAX-6) ........................................................... 51
2.6.8 External active antenna control (NEO-6) ...................................................................................... 52
2.6.9 External active antenna control (MAX-6) ..................................................................................... 53
2.6.10 GPS antenna placement for LEA-6R ............................................................................................. 53
3 Product handling ........................................................................................................ 54
3.1 Packaging, shipping, storage and moisture preconditioning ............................................................... 54
3.1.1 Population of Modules ................................................................................................................ 54
3.2 Soldering ............................................................................................................................................ 54
3.2.1 Soldering paste............................................................................................................................ 54
3.2.2 Reflow soldering ......................................................................................................................... 54
3.2.3 Optical inspection ........................................................................................................................ 55
3.2.4 Cleaning ...................................................................................................................................... 56
3.2.5 Repeated reflow soldering ........................................................................................................... 56
3.2.6 Wave soldering............................................................................................................................ 56
3.2.7 Hand soldering ............................................................................................................................ 56
3.2.8 Rework ........................................................................................................................................ 56
3.2.9 Conformal coating ...................................................................................................................... 57
3.2.10 Casting ........................................................................................................................................ 57
3.2.11 Grounding metal covers .............................................................................................................. 57
3.2.12 Use of ultrasonic processes .......................................................................................................... 57
3.3 EOS/ESD/EMI Precautions .................................................................................................................... 57
3.3.1 Abbreviations .............................................................................................................................. 57
3.3.2 Electrostatic discharge (ESD) ........................................................................................................ 57
3.3.3 ESD handling precautions ............................................................................................................ 58
3.3.4 ESD protection measures ............................................................................................................. 59
3.3.5 Electrical Overstress (EOS) ............................................................................................................ 59
3.3.6 EOS protection measures ............................................................................................................. 59
3.3.7 Electromagnetic interference (EMI) .............................................................................................. 60
3.3.8 Applications with wireless modules LEON / LISA .......................................................................... 61
3.3.9 Recommended parts ................................................................................................................... 63
UBX-14054794 Production Information Contents Page 5 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
3.4 Safety precautions .............................................................................................................................. 64
4 Product testing ........................................................................................................... 65
4.1 u-blox in-series production test ........................................................................................................... 65
4.2 Test parameters for OEM manufacturer .............................................................................................. 65
4.3 System sensitivity test ......................................................................................................................... 66
4.3.1 Guidelines for sensitivity tests ...................................................................................................... 66
4.3.2 ‘Go/No go’ tests for integrated devices ........................................................................................ 66
4.3.3 Testing LEA-6R designs ................................................................................................................ 66
4.3.4 Testing NEO-6V designs .............................................................................................................. 67
Appendix .......................................................................................................................... 68
A Abbreviations ............................................................................................................. 68
B Migration to u-blox-6 receivers ................................................................................. 68
B.1 Checklist for migration ....................................................................................................................... 68
B.2 Software migration ............................................................................................................................. 70
B.2.1 Software migration from ANTARIS 4 or u-blox 5 to a u-blox 6 GPS receiver ................................. 70
B.2.2 Software migration from 6.02 to 7.03 ......................................................................................... 71
B.2.3 Software migration from 7.03 to FW1.00 GLONASS, GPS & QZSS ............................................... 71
B.3 Hardware Migration ........................................................................................................................... 71
B.3.1 Hardware Migration: ANTARIS 4 u-blox 6 ............................................................................... 71
B.3.2 Hardware Migration: u-blox 5 u-blox 6 ................................................................................... 71
B.4 Migration of LEA modules .................................................................................................................. 72
B.4.1 Migration from LEA-4 to LEA-6 ................................................................................................... 72
B.4.2 Migration of LEA-4R designs to LEA-6R ....................................................................................... 73
B.4.3 Migration from LEA-5 to LEA-6 ................................................................................................... 74
B.5 Migration of NEO modules ................................................................................................................. 74
B.5.1 Migration from NEO-4S to NEO-6................................................................................................ 74
B.5.2 Migration from NEO-5 to NEO-6 ................................................................................................. 75
C Interface Backgrounder ............................................................................................. 76
C.1 DDC Interface ..................................................................................................................................... 76
C.1.1 Addresses, roles and modes ........................................................................................................ 76
C.1.2 DDC troubleshooting .................................................................................................................. 77
C.2 SPI Interface ........................................................................................................................................ 78
C.2.1 SPI basics ..................................................................................................................................... 78
D DR calibration ............................................................................................................. 81
D.1 Constraints ......................................................................................................................................... 81
D.2 Initial calibration drive ......................................................................................................................... 81
Related documents........................................................................................................... 83
Revision history ................................................................................................................ 84
Contact .............................................................................................................................. 85
UBX-14054794 Production Information Contents Page 6 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
RF Front-End
with
Integrated LNA
Baseband Processor
Power
Management
TCXO or
Crystal
RTC
Cry stal
(opti onal )
FLASH EPROM
(optional)
Antenna
Supervision
& Supply
(optional)
Power Control
RF_IN
V_ANT
AADET_N
VCC_RF
VCC
V_BACKUP
G ND
VCC_OUT
UART
EXTINT
RESET_N
USB V2.0
CFG
Digital
IF Filter
Backup
RAM
ROM Code
GPS/GALILEO
Engine
ARM7TDMI-S
®
SRAM
TIMEPULSE
SAW Filter
RTC
DDC
SPI (optional)
VCC_IO
ANTON
1
1 Hardware description
1.1 Overview
The u-blox 6 leadless chip carrier (LCC) modules are standalone GPS and GPS/GLONASS/QZSS1 modules featuring the high performance u-blox-6 positioning engine. These compact, easy to integrate modules combine exceptional GPS performance with highly flexible power, design, and connectivity options. Their compact form factors and SMT pads allow fully automated assembly with standard pick & place and reflow-soldering equipment for cost-efficient, high-volume production enabling short time-to-market.
u-blox positioning modules are not designed for life saving or supporting devices or for aviation and should not be used in products that could in any way negatively impact the security or health of the user or third parties or that could cause damage to goods.
1.2 Architecture
u-blox 6 LCC modules consist of two functional parts - the RF and the Baseband sections. See Figure 1 for block diagrams of the modules.
The RF Front-End includes the input matching elements, the SAW bandpass filter, the u-blox 6 RF-IC (with integrated LNA) and the frequency source.
The Baseband section contains the u-blox 6 Baseband processor, the RTC crystal and additional elements such as the optional FLASH Memory for enhanced programmability and flexibility.
Figure 1: u-blox-6 block diagram
GLONASS and QZSS functionality available with LEA-6N, or LEA-6H-0-002 with firmware upgrade.
UBX-14054794 Production Information Hardware description Page 7 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
VCC
V_BCKP
Voltage
Supervisor
Module Voltage Supply
RTC and Battery Backup RAM (BBR)
J1
1.3 Power management
1.3.1 Connecting power
u-blox 6 receiver modules have three power supply pins: VCC, V_BCKP and VDDUSB.
(No VDDUSB for MAX-6)
1.3.1.1 VCC - main power
The main power supply is fed through the VCC pin. During operation, the current drawn by the u-blox 6 GPS module can vary by some orders of magnitude, especially, if low-power operation modes are enabled. It is important that the system power supply circuitry is able to support the peak power (see data sheet for specification) for a short time. In order to define a battery capacity for specific applications the sustained power figure shall be used.
When switching from backup mode to normal operation or at start-up u-blox 6 modules must charge the
internal capacitors in the core domain. In certain situations this can result in a significant current draw. For low power applications using Power Save and backup modes it is important that the power supply or low ESR capacitors at the module input can deliver this current/charge.
1.3.1.2 V_BCKP - backup battery
In case of a power failure on pin VCC, the real-time clock and backup RAM are supplied through pin V_BCKP. This enables the u-blox 6 receiver to recover from a power failure with either a Hotstart or a Warmstart (depending on the duration of VCC outage) and to maintain the configuration settings saved in the backup RAM. If no backup battery is connected, the receiver performs a Coldstart at power up.
If no backup battery is available connect the V_BCKP pin to GND.
As long as VCC is supplied to the u-blox 6 receiver, the backup battery is disconnected from the RTC and the backup RAM in order to avoid unnecessary battery drain (see Figure 2). Power to RTC and BBR is supplied from
VCC in this case.
Avoid high resistance on the on the V_BCKP line: During the switch from main supply to backup
supply a short current adjustment peak can cause high voltage drop on the pin and possible malfunctions.
Figure 2: Backup Battery and Voltage
1.3.1.3 VDD_USB - USB interface power supply
On LEA-6 and NEO-6 VDD_USB supplies the USB interface. If the USB interface is not used, the VDD_USB pin
must be connected to GND. For more information regarding the correct handling of VDD_USB, see section
1.6.2.1.
UBX-14054794 Production Information Hardware description Page 8 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
1.3.2 Operating modes
u-blox 6 modules with FW 7.0x or ROM6.02 have two continuous operating modes (Maximum Performance and Eco) and one intermittent operating mode (Power Save mode). Maximum Performance mode freely uses the acquisition engine, resulting in the best possible TTFF, while Eco mode optimizes the use of the acquisition engine to deliver lower current consumption. At medium to strong signals, there is almost no difference for acquisition and tracking performance in these modes.
1.3.2.1 Maximum Performance mode
In Maximum Performance mode, u-blox 6 receivers use the acquisition engine at full performance to search for all possible satellites until the Almanac is completely downloaded.
As a consequence, tracking current consumption level will be achieved when:
A valid GPS position is fixed Almanac is entirely downloaded Ephemeris for all satellites in view are valid
1.3.2.2 Eco mode
In Eco mode, u-blox 6 receivers use the acquisition engine to search for new satellites only when needed for navigation:
In cold starts, u-blox 6 searches for enough satellites to navigate and optimizes use of the acquisition
engine to download their ephemeris.
In non-cold starts, u-blox 6 focuses on searching for visible satellites whose orbits are known from the
Almanac.
In Eco mode, the u-blox 6 acquisition engine limits use of its searching resources to minimize power consumption. As a consequence the time to find some satellites at weakest signal level might be slightly increased in comparison to the Maximum Performance mode.
u-blox 6 deactivates the acquisition engine as soon as a position is fixed and a sufficient number (at least 4) of satellites are being tracked. The tracking engine continues to search and track new satellites without orbit information.
1.3.2.3 Power Save mode
u-blox 6 receivers include a Power Save Mode. Its operation is called cyclic tracking and allows reducing the average power consumption significantly. The Power Save Mode can be configured for different update periods. u-blox recommends an update period of 1s for best GPS performance. For more information, see the u-blox 6 Receiver Description including Protocol Specification [4]
Dead Reckoning, PPP and Precision Timing features should not be used together with Power Save Mode. Power Save Mode is not supported in GLONASS mode.
1.4 Antenna supply - V_ANT (LEA-6)
LEA-6 modules support active antenna supply and supervision use the pin V_ANT to supply the active antenna. Use a 10 resistor in front of V_ANT. For more information about antenna and antenna supervisor, see section
2.6.
If not used, connect the V_ANT pin to GND.
UBX-14054794 Production Information Hardware description Page 9 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Module
VDD_USB
LDO
VDD_USB
R4
USB_DP
USB_DM
R5
C24 C23
D2
VBUS
DP
DM
GND
USB Device Connector
U1
EN R11
EN
1.5 System functions
1.5.1 System monitoring
The u-blox-6 receiver modules provide system monitoring functions that allow the operation of the embedded processor and associated peripherals to be supervised. These System Monitoring functions are output as part of the UBX protocol, class ‘MON’.
Please refer to the u-blox 6 Receiver Description including Protocol Specification [4]. For more information on UBX messages, serial interfaces for design analysis and individual system monitoring functions.
1.6 Interfaces
1.6.1 UART
u-blox 6 modules include a Universal Asynchronous Receiver Transmitter (UART) serial interface. RxD1/TxD1 supports data rates from 4.8 to 115.2 kBit/s. The signal output and input levels are 0 V to VCC. An interface based on RS232 standard levels (+/- 12 V) can be realized using level shifters such as Maxim MAX3232. Hardware handshake signals and synchronous operation are not supported.
For more information, see the LEA-6 Data Sheet [1], NEO-6 Data Sheet [3],or MAX-6 Data Sheet [11].
1.6.2 USB (LEA-6/NEO-6)
The u-blox 6 Universal Serial Bus (USB) interface supports the full-speed data rate of 12 Mbit/s.
1.6.2.1 USB external components
The USB interface requires some external components in order to implement the physical characteristics required by the USB 2.0 specification. These external components are shown in Figure 3 and listed in Table 1.
In order to comply with USB specifications, VBUS must be connected through a LDO (U1) to pin VDD_USB of the module.
If the USB device is self-powered it is possible that the power supply (VCC) is shut down and the Baseband-IC core is not powered. Since VBUS is still available, it still would be signaled to the USB host that the device is present and ready to communicate. This is not desired and thus the LDO (U1) should be disabled using the enable signal (EN) of the VCC-LDO or the output of a voltage supervisor. Depending on the characteristics of the LDO (U1) it is recommended to add a pull-down resistor (R11) at its output to ensure VDD_USB is not floating if LDO (U1) is disabled or the USB cable is not connected i.e. VBUS is not supplied.
If the device is bus-powered, LDO (U1) does not need an enable control.
Figure 3: USB Interface
UBX-14054794 Production Information Hardware description Page 10 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Name
Component
Function
Comments
U1
LDO
Regulates VBUS (4.4 …5.25 V)
down to a voltage of 3.3 V.
Almost no current requirement (~1 mA) if the GPS receiver is operated as a USB self-powered device, but if bus-powered LDO (U1) must be able to deliver the maximum current of ~70 mA. A low-cost DC/DC converter such as LTC3410 from Linear Technology may be used as an alternative.
C23, C24
Capacitors
Required according to the specification of LDO U1
D2
Protection diodes
Protect circuit from overvoltage / ESD when connecting.
Use low capacitance ESD protection such as ST Microelectronics USBLC6-2.
R4, R5
Serial termination resistors
Establish a full-speed driver impedance of 28…44
A value of 22 is recommended. R11
Resistor
10 k is recommended for USB self-powered setup. For bus-powered setup R11 can be ignored.
Load Capacitance
Pull-Up Resistor Value R20, R21
50 pF
N/A
100 pF
18 k
250 pF
4.7 k
Table 1: Summary of USB external components
1.6.3 Display Data Channel (DDC)
An I2C compatible Display Data Channel (DDC) interface is available with LEA-6, NEO-6 and MAX-6 modules for serial communication. For more information about DDC implementation refer to the u-blox 6 Receiver Description including Protocol Specification [4]. Background information about the DDC interface is available in Appendix C.1.
u-blox 6 GPS receivers normally run in I2C slave mode. Master Mode is only supported when external
EEPROM is used to store configuration. No other nodes may be connected to the bus. In this case, the receiver attempts to establish presence of such a non-volatile memory component by writing and reading from a specific location.
TX ready indicator (data ready) for FW 7.0x. See section 1.7.6.
The u-blox 6 DDC interface supports serial communication with u-blox wireless modules. See the
specification of the applicable wireless module to confirm compatibility.
With u-blox 6, when reading the DDC internal register at address 0xFF (messages transmit buffer), the
master must not set the reading address before every byte accessed as this could cause a faulty behavior. Since after every byte being read from register 0xFF the internal address counter is incremented by one saturating at 0xFF, subsequent reads can be performed continuously.
Pins SDA2 and SCL2 have internal 13 k pull-ups. If capacitive bus load is very large, additional external pull-ups may be needed in order to reduce the pull-up resistance.
Table 2 lists the maximum total pull-up resistor values for the DDC interface. For small loads, e.g. if just connecting to an external EEPROM, these built-in pull-ups are sufficient.
Table 2: Pull-up resistor values for DDC interface
UBX-14054794 Production Information Hardware description Page 11 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
1.6.3.1 Communicating to an I
2
C EEPROM with the GPS receiver as I2C master
Serial I2C memory can be connected to the DDC interface. This can be used to save configuration permanently. It will automatically be recognized by firmware. The memory address must be set to 0b10100000 (0xA0) and the size fixed to 4 kB.
Figure 4: Connecting external serial I2C memory used by the GPS receiver (see EEPROM data sheet for exact pin orientation)
Figure 5: Connecting external serial I2C memory used by external host (see data sheet for exact pin orientation)
Note that the case shown on Figure 4 is different than the case when EEPROM is present but used by external host / CPU as indicated on Figure 5. This is allowed but precaution is required to ensure that the GPS receiver does not detect the EEPROM device, which would effectively configure the GPS receiver to be MASTER on the bus causing collision with the external host.
To ensure that the EEPROM device (connected to the bus and used by the host) is not detected by the GPS receiver it is important to set the EEPROM’s address to a value different than 0xA0. This way EEPROM remains free to be used for other purposes and the GPS receiver will assume the SLAVE mode.
UBX-14054794 Production Information Hardware description Page 12 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Manufacturer
Order No.
ST
M24C32-R
Microchip
24AA32A
Catalyst
CAT24C32
Samsung
S524AB0X91
u-blox GPS Receiver SPI Master
SS_N
MISO
SCS_N
MI
VDD
MOMOSI
SCK SCK
VDD
At start up ensure that the host allows enough time (250 ms) for the receiver to interrogate any external
EEPROM over the bus. The receiver always performs this interrogation within 250 ms of start up, and the external host must provide the GPS receiver sufficient time to complete it. Only after the interrogation can the host enter MASTER mode and have full control over the bus.
Following I2C serial EEPROM are supported:
Table 3: Recommend parts list for I2C Serial EEPROM memory
1.6.4 SPI (NEO-6, LEA-6R)
A Serial Peripheral Interface (SPI) is available with u-blox 6 NEO modules. The SPI allows for the connection of external devices with a serial interface, e.g. FLASH memories or A/D converters, or to interface to a host CPU.
LEA-6R includes a Serial Peripheral Interface (SPI) for connecting external sensors. The interface can be operated in SPI master mode only. Two chip select signals are available to select external slaves. See section 2.2.3.1.
TX ready indicator (data ready) for LEA-6H (FW 7.0x). See section 1.7.6.
Background information about the SPI interface is available in Appendix C.2.
1.6.4.1 Connecting SPI FLASH memory (NEO-6 modules)
SPI FLASH memory can be connected to the SPI interface to save Assist Now Offline data and/or receiver configuration. It will automatically be recognized by firmware when connected to SS_N.
Figure 6 shows how external memory can be connected. Minimum SPI FLASH memory size is 1 Mbit.
Figure 6: Connecting external SPI Memory to u-blox GPS receivers
UBX-14054794 Production Information Hardware description Page 13 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Manufacturer
Order No.
Winbond
W25X10A
Winbond
W25X20A
AMIC
A25L010
AMIC
A25L020
Table 4: Supported SPI FLASH memory devices
u-blox GPS Receiver SPI Master
SS_N
MISO
SCS_N
MI
VDD
MOMOSI
SCK SCK
VDD
Following SPI serial Flash are supported:
Only use serial FLASH types listed in Table 4. For new designs confirm if the listed type is still available. It is
not possible to use other serial FLASH types than those listed in Table 4 with u-blox 6 receivers.
1.6.4.2 SPI communication (connecting to an SPI master) NEO-6
Figure 7 shows how to connect a u-blox GPS receiver to a host/master. The signal on the pins must meet the conditions specified in the Data Sheet.
Figure 7: Connecting to SPI Master
For those u-blox 6 modules supporting SPI the SPI MOSI, MISO and SCK pins share a configuration
function at start up. To secure correct receiver operation make sure that the SS_N pin is high at start up. Afterwards the SPI function will not affect the configuration pins.
UBX-14054794 Production Information Hardware description Page 14 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Component
Description
Model
Supplier
U1 – U3
Buffer
NC7SZ125
Fairchild
1.6.4.3 Pin configuration with module as one of several slaves
The buffers enabled by the CS_N signal make sure that the GPS receiver starts up with a known defined configuration, since the SPI pins (MOSI, MISO and SCK) are at start up also configuration pins.
Figure 8: Diagram of SPI Pin Configuration
Table 5: Recommended components for SPI pin configuration
Use same power voltage to supply U1 – U3 and VCC.
UBX-14054794 Production Information Hardware description Page 15 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
1.7 I/O pins
1.7.1 RESET_N
LEA-6 modules include a RESET_N pin. Driving RESET_N low activates a hardware reset of the system. RESET_N is only an input and will not reset external circuitry.
Use components with open drain output (i.e. with buffer or voltage supervisor). There is an internal pull up resistor of 3.3 k to VCC inside the module that requires that the reset circuitry can
deliver enough current (e.g. 1 mA). Do not drive RESET_N high. NEO-6 and MAX-6 modules do not include a RESET_N pin. However, this functionality can be implemented for
these modules by connecting the NEO-6 and MAX-6 pin 8 to pin 9 with a 3.3 k resistor, instead of connecting them directly. Pin 8 (NEO-6) or pin 9 (MAX-6) can then be used as a RESET_N input with the same characteristics as the reset pin on LEA-6 modules.
Use caution when implementing RESET_N on NEO-6 and MAX-6 modules since forward
compatibility is not guaranteed.
1.7.2 EXTINT - External interrupt pin
EXTINT0 is an external interrupt pin with fixed input voltage thresholds with respect to VCC (see the data sheet
for more information). It can be used for the time mark function on LEA-6T or for wake-up functions in Power Save Mode on all u-blox 6 LCC modules. Leave open if unused.
1.7.3 AADET_N (LEA-6)
AADET_N is an input pin and is used to report whether an external circuit has detected an external antenna or
not. Low means the antenna has been detected. High means no external antenna has been detected. See section 2.6.4 for an implementation example.
1.7.4 Configuration pins (LEA-6S/6A, NEO-6)
ROM-based modules provide up to 3 pins (CFG_COM0, CFG_COM1, and CFG_GPS0) for boot-time configuration. These become effective immediately after start-up. Once the module has started, the configuration settings can be modified with UBX configuration messages. The modified settings remain effective until power-down or reset. If these settings have been stored in battery-backup RAM, then the modified configuration will be retained, as long as the backup battery supply is not interrupted.
The module data sheets indicate the meaning of the configuration pins when they are high (1) or low (0). In fact no configuration pins need to be pulled high. All have internal pull ups and therefore default to the high (1) state when left open or connected to a high impedance output. They should be left open unless there is a need to pull them low to alter the initial configuration.
Some configuration pins are shared with other functions. During start-up, the module reads the state of the configuration pins. Afterwards the other functions can be used.
The configuration pins of u-blox 6 use an internal pull-up resistor, which determines the default setting.
For more information about settings and messages see the module data sheet.
MAX-6 doesn’t have pins for boot-time configuration.
1.7.5 Second time pulse for LEA-6T-0 and LEA-6T-1
LEA-6T-0 and LEA-6T-1 include a second time pulse pin (TIMEPULSE2). For more information and configuration see the LEA-6 Data Sheet [1] and also the u-blox 6 Receiver Description including Protocol Specification [4]. (LEA­6T-2 provides a single time pulse output only.)
UBX-14054794 Production Information Hardware description Page 16 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
1.7.6 TX ready signal (FW 7.0x)
The TX ready signal indicates that the receiver has data to transmit. A listener can wait on the TX ready signal instead of polling the DDC or SPI interfaces. The UBX-CFG-PRT message lets you configure the polarity and the number of bytes in the buffer before the TX ready signal goes active. The TX ready signal can be mapped to GPIO 05 (TXD1). The TX ready pin is disabled by default.
The TX-ready functionality can be enabled and configured by proper AT commands sent to the involved
u-blox wireless module supporting the feature. For more information see GPS Implementation Application Note, Docu No GSM.G1-CS-09007 [14]
1.7.7 ANTOFF (NEO-6)
The ANTOFF signal can be mapped to GPIO22 (Pin 17). The ANTOFF signal is disabled by default.
To configure the ANTOFF function refer to the u-blox 6 Receiver Description including Protocol
Specification [3].
Use caution when implementing ANTOFF configuration since forward compatibility is not
guaranteed
1.7.8 Antenna supervision signals for LEA-6T-0
With LEA-6T-0, the antenna supervisor GPIOs are numbered differently than the other LEA-6 modules and are wired to specific PIOs:
ANTOFF is internally mapped to GPIO13 ANTSHORT is internally mapped to GPIO17 AADET_N (Active Antenna Detect) is mapped to GPIO8 (Pin 20)
If the unit is reverted to the default configuration, there is no antenna supply. The CFG-ANT command sets the PIOs and enables Power Control, Short Circuit Detection, Power Down on Short
and Short Circuit Recovery. To store the settings permanently send the UBX-CFG-CFG command with the option 'save current parameters'
to BBR AND SPI Flash (!) Also see the schematic of open circuit detection, Figure 46.
To configure this function refer to the u-blox 6 Receiver Description including Protocol Specification [3].
UBX-14054794 Production Information Hardware description Page 17 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Pin
Signal name
Direction
Usage
27
SPEED
Input
Odometer Speedpulses
23
SCK
Output
SPI clock
22
SPI_SCS1_N
Output
Chip Select signal for ADC/turn rate sensor
21
FWD
Input
Direction indication (1 = forward)
9
SPI_SCS2_N
Output
Chip Select signal for temperature sensor
2
MISO
Input
Serial data (Master In / Slave Out)
1
MOSI
Output
Serial data (Master Out / Slave In), leave open
1.7.9 LEA-6R considerations
Figure 9: Block schematic of complete LEA-6R design
LEA-6R includes the following special pins: SPI_MOSI, SPI_MISO, SPI_SCS2_N, FWD, SPI_ SCS1_N, SPI_SCK, and SPEED.
Table 6: LEA-6R special pins
UBX-14054794 Production Information Hardware description Page 18 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
2
2
3
4
5
2 Design-in
For migrating existing ANTARIS®4 product designs to u-blox 6 please refer to Appendix B.
In order to obtain good performance with a GPS receiver module, there are a number of points that require careful attention during the design-in. These include:
Power Supply: Good performance requires a clean and stable power supply. Interfaces: Ensure correct wiring, rate and message setup on the module and your host system. Antenna interface: For optimal performance seek short routing, matched impedance and no stubs.
2.1 Checklist
Good performance requires a clean and stable power supply with minimal ripple. Care needs to be exercised in selecting a strategy to achieve this. Series resistance in the Vcc supply line can negatively impact performance. For better performance, use an LDO to provide a clean supply at Vcc and consider the following:
Wide power lines or even power planes are preferred. Place LDO near the module. Avoid resistive components in the power line (e.g. narrow power lines, coils, resistors, etc.). Placing a filter or other source of resistance at Vcc can create significantly longer acquisition times.
2.1.1 Design-in checklist
Designing-in a u-blox 6 module is easy, especially when based on a u-blox reference design. Nonetheless, it pays to do a quick sanity check of the design. This section lists the most important items for a simple design check. The Design-In Checklist also helps to avoid an unnecessary respin of the PCB and helps to achieve the best possible performance.
Follow the design-in checklist when developing any u-blox 6 GPS applications. This can significantly
reduce development time and costs.
Have you chosen the optimal module?
u-blox 6 modules have been intentionally designed to allow GPS receivers to be optimally tailored to specific applications. Changing between the different variants is easy.
Do you need TCXO performance – Then choose an HDo you want to be able to upgrade the firmware? Then you will have to use a programmable receiver
module: choose an H2 variant.
Do you need USB? All LEA-6 and NEO-6 modules support USB. Do you need Dead Reckoning – Then choose a LEA-6R or NEO-6V (see section 2.1.3) Do you need Precise Point Positioning – Then choose a NEO-6P Do you need Precision Timing – Then choose a LEA-6T or NEO-6T. Do you need onboard Antenna Supervisor circuitry - Then choose the LEA form factor. Do you need onboard Antenna control - Then choose the MAX form factor. Du you need smallest size and forward compatibility- Then choose the MAX form factor. Do you need low power - Then choose 1.8V 6G module variant. Do you need GLONASS - Then choose LEA-6N.
, S3, Q4 or G5 variant.
LEA-6H LEA-6S NEO-6Q / MAX-6Q NEO-6G / MAX-6G
UBX-14054794 Production Information Design-in Page 19 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
6
6
Check Power Supply Requirements and Schematic:
Is the power supply within the specified range? (See data sheet.) Is the voltage VDDUSB within the specified range? Compare the peak current consumption of your u-blox 6 module (~70 mA) with the specification of the
power supply.
GPS receivers require a stable power supply, avoid ripple on VCC (<50 mVpp) For low power applications using Power Save and backup modes, ensure that the power supply or low ESR
capacitors at the module input can deliver the required current/charge for switching from backup mode to normal operation. In certain situations charging the internal capacitors in the core domain can result in a significant instantaneous current draw.
Backup Battery
For achieving a minimal Time To First Fix (TTFF) in Hotstart or a Warmstart, connect a backup battery to
V_BCKP.
Time information is a requirement for AssistNow Offline, AssistNow Autonomous and when in Power Save
Mode with update period longer than 10 s.
Antenna
The total noise figure should be well below 3 dB. If a patch antenna is the preferred antenna, choose a patch of at least 15x15x4 mm. For smaller antennas
an LNA with a noise figure <2 dB is recommended. To optimize TTFF make use of u-blox’ free A-GPS services AssistNow Online and AssistNow Offline.
Make sure the antenna is not placed close to noisy parts of the circuitry. (e.g. micro-controller, display, etc.) For active antennas add a 10 resistor in front of V_ANT
input for short circuit protection or use the
antenna supervisor circuitry.
To optimize performance in environments with out-band jamming sources, use an additional SAW filter.
For information on ESD protection for patch antennas and removable antennas, see section 3.3.4 and if
you use GPS for design in combination with GSM or other radio, then check sections 3.3.6 to 3.3.8.
For more information dealing with interference issues see the GPS Antenna Application Note [5].
Schematic
If required, does your schematic allow using different module variants? Don’t drive RESET_N high! Don’t drive configuration pins high, they already have internal pull-ups. Plan the use of 2nd interface (Testpoints on UART, DDC or USB) for firmware updates or as a service
connector.
Layout optimizations (Section 2.5)
Is the GPS module placed according to the recommendation in section 2.5.2? Has the Grounding concept been followed? (See section 2.5.3.) Has the micro strip been kept as short as possible? Add a ground plane underneath the GPS module to reduce interference. For improved shielding, add as many vias as possible around the micro strip, around the serial
communication lines, underneath the GPS module etc.
Have appropriate EOS/ESD/EMI protection measures been included? (See section 3.3.) This is especially
important for designs including 2G, 3G modules.
Only available with LEA-6 modules
UBX-14054794 Production Information Design-in Page 20 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
7
7
Calculation of the micro strip (Section 2.5.4)
The micro strip must be 50 and be routed in a section of the PCB where minimal interference from noise
sources can be expected.
In case of a multi-layer PCB, use the thickness of the dielectric between the signal and the 1st GND layer
(typically the 2nd layer) for the micro strip calculation.
If the distance between the micro strip and the adjacent GND area (on the same layer) does not exceed 5
times the track width of the micro strip, use the “Coplanar Waveguide” model in AppCad to calculate the micro strip and not the “micro strip” model.
2.1.2 Design considerations
For a minimal design with a u-blox 6 GPS module the following functions and pins need to be considered:
Connect the Power supply to VCC. VDDUSB: Connect the USB power supply to a LDO before feeding it to VDDUSB and VCC. Or connect to
GND if USB is not used.
Assure a optimal ground connection to all ground pins of the module Connect the antenna to RF_IN over a matching 50  micro strip and define the antenna supply (V_ANT)
for active antennas (internal or external power supply)
Choose the required serial communication interface (UART, USB, SPI or DDC) and connect the appropriate
pins to your application
If you need Hot- or Warmstart in your application, connect a backup battery to V_BCKP Decide whether TIMEPULSE or RESET_N7 options are required in your application and connect the
appropriate pins on your module
Only available with LEA-6 modules, but see section 1.7.1 for NEO-6 modules.
UBX-14054794 Production Information Design-in Page 21 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
2.1.3 Automotive Dead Reckoning (ADR) solutions
u-blox’ ADR supports different sensor inputs. The classical setup, called “Gyroscope plus Wheel Tick” (GWT), consists of a gyroscope providing the heading information and wheel tick providing the speed information.
Alternatively, sensor information from left and right wheels (front or rear) or all wheels are used differentially to deduce heading, called “Differential Wheel Tick” (DWT). This results in slightly lower performance compared to GWT, but has the big advantage of saving the cost of a gyroscope.
2.1.3.1 Software sensor interface
Figure 10: Software sensor interface
The industry proven u-blox ADR solution is highly flexible. The application processor can support a vast array of sensors, and must only convert the sensor data into UBX messages and pass them to the GPS receiver via a standard serial interface (USB, SPI, UART, DDC). This makes the u-blox ADR solution very portable between various vehicle platforms and reduces development effort and time-to-market. u-blox ADR is completely self­calibrating, and requires only pre-configuration to the specific vehicle platform.
u-blox’ ADR with software sensor interface is available as NEO-6V module. These components are ideal for factory installed navigation since they use sensor data (wheel tick and gyroscope data) taken directly from the CAN bus.
2.1.3.2 Hardware sensor interface
Figure 11: Hardware sensor interface
The standard quality grade LEA-6R module is a dedicated ADR solution (GWT only) for aftermarket installations with no access to the vehicle bus and no application processor for sensor data processing. Sensors are connected directly to the module: gyroscopes via SPI and ADC and the speed pulse information from the tachometer.
UBX-14054794 Production Information Design-in Page 22 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
USB port
Passive Antenna
Vcc
Micro
Processor
(serial)
(optional)
Backup Battery (optional)
+
Micro
Processor
(USB)
1
SDA2 /SPI_MOSI
SCL2 / SPI_MISO
TxD1
RxD1
NC
VCC
GND
VCC_OUT
CFG_COM1/ NC
SPI_SCS2_N /TIMEPULSE2
RESET_N
V_BCKP
Reserved
GND
GND
RF_IN
VCC_RF
V_ANT
Reserved / FWD
Reserved / SPI_SCS1_N
Reserved / SPI_SCK
VDDUSB
USB_DM
USB_DP
EXTINT0 / SPEED
TIMEPULSE
GND
GND
AADET_N
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
LEA-6
Top View
LDO
Passive Antenna
Vcc
Micro
Processor
(serial)
1
SDA2 / SPI_MOSI
SCL2 / SPI_MISO
TxD1
RxD1
NC
VCC
GND
VCC_OUT
CFG_COM1/ NC
SPI_SCS2_N /TIMEPULSE2
RESET_N
V_BCKP
Reserved
GND
GND
RF_IN
VCC_RF
V_ANT
Reserved / FWD
Reserved / SPI_SCS1_N
Reserved / SPI_SCK
VDDUSB
USB_DM
USB_DP
EXTINT0 / SPEED
TIMEPULSE
GND
GND
AADET_N
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
LEA-6
Top View
2.2 LEA-6 design
2.2.1 LEA-6 passive antenna design
This is a minimal setup for a PVT GPS receiver with a LEA-6 module.
Figure 12: LEA-6 passive antenna design with USB port
Figure 13: LEA-6 passive antenna design with no USB port or backup battery
UBX-14054794 Production Information Design-in Page 23 of 85
For best performance with passive antenna designs use an external LNA to increase the sensitivity up to 2
dB. See figure 12 and Figure 15.
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Passive Antenna
Vcc
Micro
Processor
(serial)
1
SDA2 / SPI_MOSI
SCL2 / SPI_MISO
TxD1
RxD1
NC
VCC
GND
VCC_OUT
CFG_COM1/ NC
SPI_SCS2_N /TIMEPULSE2
RESET_N
V_BCKP
Reserved
GND
GND
RF_IN
VCC_RF
V_ANT
Reserved / FWD
Reserved / SPI_SCS1_N
NReserved / SPI_SCK
VDDUSB
USB_DM
USB_DP
EXTINT0 / SPEED
TIMEPULSE
GND
GND
AADET_N
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
LEA-6
Top View
LNA
SAW L
Passive Antenna
Vcc
Micro
Processor
(serial)
1
SDA2 / SPI_MOSI
SCL2 / SPI_MISO
TxD1
RxD1
NC
VCC
GND
VCC_OUT
CFG_COM1/ NC
SPI_SCS2_N /TIMEPULSE2
RESET_N
V_BCKP
Reserved
GND
GND
RF_IN
VCC_RF
V_ANT
Reserved / FWD
Reserved / SPI_SCS1_N
Reserved / SPI_SCK
VDDUSB
USB_DM
USB_DP
EXTINT0 / SPEED
TIMEPULSE
GND
GND
AADET_N
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
LEA-6
Top View
SAW
LNA
SAW
L
Figure 14: LEA-6 passive antenna design for best performance (with external LNA and SAW)
Figure 15: LEA-6 passive antenna design for best performance and increased immunity to jammers such as GSM
For information on increasing immunity to jammers such as GSM see section 3.3.8.
UBX-14054794 Production Information Design-in Page 24 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
8
8
2.2.2 GLONASS HW design recommendations (LEA-6N, LEA-6H-0-002
)
The Russian GLONASS satellite system is an alternative system to the US-based Global Positioning System (GPS). LEA-6N modules can receive and process GLONASS signals. LEA-6H-0-002 modules are GLONASS ready and are capable of receiving and processing GLONASS signals via a firmware upgrade8.
LEA-6N and LEA-6H-0-002 designs for GLONASS require a wide RF path. Ensure that the antenna and external SAW filter are sufficient to allow GLONASS & GPS signals to pass (see Figure 16).
Use an active GLONASS antenna. For best performance with passive antenna designs use an external LNA. (See section 2.2.2.7.)
LEA-6N and LEA-6H-0-002 modules are pin compatible.
2.2.2.1 Wide RF path
As seen in Figure 16, the GLONASS / GPS satellite signals are not at the same frequency. For this reason the RF path, LNA, filter, and antenna must be modified accordingly to let both signals pass.
2.2.2.2 Filter
Use a GPS & GLONASS SAW filter (see Figure 16) that lets both GPS and GLONASS signals pass. (See the
recommended parts list in section 3.3.9.)
If an active antenna is used, make sure that any filter inside is wide enough.
Figure 16: GPS & GLONASS SAW filter
2.2.2.3 Active antenna
Usually an active GPS antenna includes a GPS band pass filter which might filter out the GLONASS signal (see Figure 16). For this reason make sure that the filter in the active antenna is wide enough to let the GPS and GLONASS signals pass.
In combined GPS & GLONASS antennas, the antenna has to be tuned to receive both signals and the filter has a larger bandwidth to provide optimal GPS & GLONASS signal reception (see Figure 16).
Use a good performance GPS & GLONASS active antenna (for recommended components see section
3.3.9.1).
Figure 17: GPS & GLONASS active antenna
Requires firmware upgrade with FW1.00 GLONASS, GPS & QZSS Flash firmware image, available from u-blox.
UBX-14054794 Production Information Design-in Page 25 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
size
Typical bandwidth
36*36*4 mm
40 MHz
25*25*4 mm
20 MHz
18*18*4 mm
10 MHz
15*15*4 mm
8 MHz
12*12*4 mm
7 MHz
10*10*4 mm
5 MHz
2.2.2.4 Passive Antenna
The bandwidth of a ceramic patch antenna narrows with size (see Table 7).
Table 7: Typical bandwidths for GPS patch antennas
Figure 18 shows a 12*12*4 mm patch antenna with 20*20 mm ground plane, tuned to GPS. This patch bandwidth is so narrow that it cannot be simultaneously matched to GPS and GLONASS.
Figure 18: 12*12*4 patch antenna on 20*20 mm GND plane
Figure 19 shows a 25*25*4 mm patch antenna with 60*60 mm ground plane. Due to the larger bandwidth, it can be matched to GPS and GLONASS.
Figure 19: 25*25*4 mm patch antenna on 60*60 mm GND plane
UBX-14054794 Production Information Design-in Page 26 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Figure 20 show a 36*36*4 mm patch antenna. Due to the large bandwidth, the antenna is also tolerant to changes in the ground plane.
Figure 20 36*36*4 mm patch antenna
Use at least a 25*25*4 mm patch antenna, (a 36*36*4 mm patch antenna is better) and tune it so that
GPS & GLONASS signals are received.
2.2.2.5 Module designs
For GPS & GLONASS designs chose the LEA-6N GLONASS, GPS & QZSS module, which has a wide RF path and includes an internal Flash.
2.2.2.6 Module design with active antenna
Figure 21 shows a GPS & GLONASS active antenna design with the LEA-6N GLONASS, GPS & QZSS module.
Figure 21: Module design with active antenna
Use a good performance GPS & GLONASS active antenna (for recommended components, see section
3.3.9.1).
UBX-14054794 Production Information Design-in Page 27 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Pin
Signal name
Direction
Usage
23
SPI_SCK
Output
SPI clock 22
SPI_SCS1_N
Output
Chip Select signal for ADC/turn rate sensor
9
SPI_SCS2_N
Output
Chip Select signal for temperature sensor
2
SPI_MISO
Input
Serial data (Master In / Slave Out)
1
SPI_MOSI
Output
Serial data (Master Out / Slave In), leave open
2.2.2.7 Module design with passive antenna and an external LNA
Figure 22 shows a GPS & GLONASS passive antenna design with the LEA-6N GLONASS, GPS & QZSS module. For best performance with passive antenna designs use an external LNA.
Figure 22: Module design with passive antenna
A standard GPS LNA has enough bandwidth to amplify GPS and GLONASS.
For recommended SAW Filters for GPS & GLONASS (Part F2 in Figure 22), see section 3.3.9.
2.2.2.8 GLONASS SW integration
To activate GLONASS mode the customer application will have to send UBX proprietary commands for activating and switching to GLONASS reception. The applicable SW commands are documented in the u-blox 6 Receiver Description including Protocol Specification (GPS/GLONASS/QZSS) [5].
2.2.3 LEA-6R design
2.2.3.1 Connecting gyroscope and temperature sensor to the LEA-6R
The LEA-6R acts as SPI master. Following signals are used by the SPI:
Table 8: SPI pins for LEA-6R
UBX-14054794 Production Information Design-in Page 28 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
LEA-6R
Turn Rate Sensor
(MOSI)
22K
10R
leave open
Gyro
SCK
MISO
SPI_SCS2_N
+5V
REF
100nF
GND
GND
CONV
SCK
VCC
SC
CS
V
REF
IN
+
IN
-
12-Bit
A/D Converter
Linear LTC1860
Temperature
Sensor
National LM70-5
SDO
SI/O
V
+
GND
GND
GND
100nF
RATE
100nF
GND
100K
SPI_SCS1_N
10uF
220nF
+5V
+5V
+5V
+5V
+3V
+3V
+3V
+5V
+3V
Parameter
Specification
Supply Voltage
5.0 V ± 0.25 V
Zero Point
2.5 V ± 0.4 V
Scale Factor
25 mV/(°/s) ± 5 mV/(°/s)
Dynamic Range
±60 °/s to ±125 °/s
Linearity
±0.5 % (full scale)
Recommended operating temperature range
-40 to +85°C
The following block schematic specifies the A/D converter and temperature sensor for the LEA-6R.
The LTC1860 and LM70-5 function at 5 V. A level translation with open-drain buffers and pull-up
resistors on the outputs is required.
Figure 23: Attaching A/D converter and temperature sensor using the SPI
Add appropriate coupling capacitances according to the recommendations in the data sheets of the illustrated semiconductor products. All shown resistors shall have 5% accuracy or better. All shown capacitors (X7R types) shall have 10% accuracy or better.
For correct operation with the LEA-6R firmware, this circuit must be adopted without making any modifications such as, but not limited to, using different types of semiconductor devices and changing signal assignment.
LEA-6R default SPI clock is 870 kHz. As LEA-4R default value is 460 kHz, migrating from LEA-4R to LEA-6R
will require a bandwidth verification of the SPI circuits and shall be designed for a bandwidth of 4 MHz.
2.2.3.2 Gyroscope requirements
Gyroscopes should meet the requirements listed below:
Table 9: Requirements for gyroscopes
Follow the gyroscope manufacturer design recommendations for proper analog signal conditioning.
UBX-14054794 Production Information Design-in Page 29 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Manufacturer
Device
Linear Technology
LTC1860
Manufacturer
Device
National Semiconductor
LM70
Pin
Signal name
Direction
Usage
21
FWD
Input
Direction indication (1 = forward)
2.2.3.3 Supported A/D converters
The following table lists the supported A/D converters:
Table 10: Supported A/D converters
2.2.3.4 Supported temperature sensors
The following table lists the supported temperature sensors:
Table 11: Supported temperature sensors
Note, that the temperature sensor inside the EPSON XV-8000 gyroscope sensor is not supported.
2.2.3.5 Forward / Backward indication
Use of the forward / backward indication signal FWD is optional but strongly recommended for good dead reckoning performance. It has an internal pull-up and therefore can be left open or connected to VCC_OUT or VCC if not used.
You need to check the voltage levels and the quality of the vehicle signals. They may be of different voltage levels, for example 12V nominal with a certain degree of variation. Use of optocouplers or other approved EMI protection and filtering is strongly recommended.
If no direction signal is available, the direction must be set to forward by configuring the meaning of the
direction pin appropriately, otherwise DR positioning will be incorrect due to the wrong direction. GPS only navigation is not affected by this configuration.
As the forward/backward direction signal is not available in all cars, try to make use of the reverse gear
light.
Table 12: LEA-6R Forward / Backward indication
UBX-14054794 Production Information Design-in Page 30 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Pin
Signal name
Direction
Usage
27
SPEED
Input
Odometer Speedpulses
2.2.3.6 Odometer / Speedpulses
DR receivers use signals from sensors in the car to establish the velocity and distance traveled. These sensors are referred to as the odometer and the signals can be designated odometer pulses, speedpulses, speed ticks, wheel pulses or wheel ticks. These terms are often used interchangeably which can sometimes lead to confusion. For the sake of consistency, in this document we will be referring to these signals as speedpulses.
Table 13: LEA-6R Odometer / Speedpulses
The speedpulse signal required for DR modules must have a frequency range from 1 Hz to 2 kHz (0 Hz is equal to a speed of 0 km/hour) and must be linear to the driven speed.
For DR calibration see section D.
UBX-14054794 Production Information Design-in Page 31 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Function
PIN
No
I/O
Description
Remarks
Power
VCC 6 I
Supply Voltage
Provide clean and stable supply.
GND
7, 13-15, 17
I
Ground
Assure a good GND connection to all GND pins of the module, preferably with a large ground.
VCC_OUT
8 O
Leave open if not used.
V_BCKP
11 I Backup voltage supply
It’s recommended to connect a backup battery to V_BCKP in order to enable Warm and Hot Start features on the receivers. Otherwise connect to GND.
VDDUSB
24 I USB Power Supply
To use the USB interface connect this pin to 3.0 – 3.6V derived from VBUS. If no USB serial port used connect to GND.
Antenna
RF_IN
16 I GPS/GALILEO signal input from antenna
Use a controlled impedance transmission line of 50 Ohm to connect to RF_IN.
Don’t supply DC through this pin. Use V_ANT pin to supply power.
VCC_RF
18 O Output Voltage RF section
Can be used to power an external active antenna (VCC_RF connected to V_ANT with 10 ). The max power consumption of the Antenna must not exceed the datasheet specification of the module. Leave open if not used.
V_ANT
19 I Antenna Bias voltage
Connect to GND (or leave open) if Passive Antenna is used. If an active Antenna is used, add a 10 resistor in front of V_ANT input to the Antenna Bias Voltage or VCC_RF
AADET_N
20 I Active Antenna Detect
Input pin for optional antenna supervisor circuitry. Leave open if not used.
UART
TxD1
3 O Serial Port 1
Communication interface can be programmed as TX ready for I2C interface. Leave open if not used.
RxD1
4 I Serial Port 1
Serial port input with internal pull-up resistor to VCC. Leave open if not used. Don’t use external pull up resistor.
USB USB_DM
25
I/O
USB I/O line
USB2.0 bidirectional communication pin. Leave open if unused. Implementations see section 1.6.2.
USB_DP
26
I/O
USB I/O line
System
RESET_N
10 I Hardware Reset (Active Low)
Leave open if not used. Do not drive high.
TIMEPULSE
28 O Timepulse Signal
Configurable Timepulse signal (one pulse per second by default). Leave open if not used.
EXTINT0 /SPEED
27 I Ext. Interrupt /Odometer
Ext. Interrupt Pin. Int. pull-up resistor to VCC. Leave open if unused. LEA-6R: Odometer speed
CFG_COM1 /NC /SPI_SCS2_N /TIMEPULSE2
9 I Config. Pin /NC /SPI /TIMEPULSE2
LEA-6S, LEA-6A: Leave open for default configuration. LEA-6H, LEA-6T-2: Do not connect
LEA-6R: SPI select 2 LEA-6T-0, LEA-6T-1: TIMEPULSE2
SDA2 /SPI_MOSI
1
I/O
DDC Pins /SPI
DDC Data. Leave open if not used. LEA-6R: SPI MOSI
SCL2 /SPI_MISO
2
I/O
DDC Pins /SPI
DDC Clock. Leave open if not used. LEA-6R: SPI MISO
Reserved
12 I
Leave open, do not drive low.
NC 5 Leave open for only LEA-6x design. Connect to VCC for backward compatibility to LEA-5x.
NC /FWD
21 Not Connect /Direction
Leave open LEA-6R: Forward / Backward indication
NC /SPI_ SCS1_N
22 Not Connect /SPI
Leave open LEA-6R: SPI select 1
NC /SPI_SCK
23 Not Connect /SPI
Leave open LEA-6R: SPI clock
2.2.1 Pin description for LEA-6 designs
Table 14: Pin description LEA-6
UBX-14054794 Production Information Design-in Page 32 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Vcc
Micro
Processor
(serial)
Passive Antenna
Backup Battery
+
NEO-6
Top View
2
3
4
5
6
8
10
12
24
22
21
20
19
17
15
13
23
GND
Reserved
SS_N
TIMEPULSE
EXTINT0
USB_DM
USB_DP
VDDUSB
Reserved
VCC_RF
GND
GND
RF_IN
GND
VCC
V_BCKP
RxD1
TxD1
SCL2
SDA2
Reserved
CFG_GPS0/SCK
MISO/CFG_COM1
MOSI/CFG_COM0
14
16
11
9
7
1
18
USB port (Optional)
Micro
Processor
(USB)
LDO
2.3 NEO-6 design
2.3.1 Passive antenna design (NEO-6)
This is a minimal setup for a PVT GPS receiver with a NEO-6 module.
Figure 24: NEO-6 passive antenna design (with USB)
The above design is for the USB in self-powered mode. For bus-powered mode pin 14 (CFG_COM0) must
be left open and VCC must be connected to VDDUSB. NMEA baud rate is 38400 when in self-powered mode.
For best performance with passive antenna designs use an external LNA to increase the sensitivity up to 2
dB. See Figure 25 and Figure 26.
UBX-14054794 Production Information Design-in Page 33 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Vcc
Micro
Processor
(serial)
Passive Antenna
Backup Battery
+
NEO-6
Top View
2
3
4
5
6
8
10
12
24
22
21
20
19
17
15
13
23
GND
Reserved
SS_N
TIMEPULSE
EXTINT0
USB_DM
USB_DP
VDDUSB
Reserved
VCC_RF
GND
GND
RF_IN
GND
VCC
V_BCKP
RxD1
TxD1
SCL2
SDA2
Reserved
CFG_GPS0/SCK
MISO/CFG_COM1
MOSI/CFG_COM0
14
16
11
9
7
1
18
USB port (Optional)
Micro
Processor
(USB)
LDO
LNA
SAW
Vcc
Micro
Processor
(serial)
Passive Antenna
Backup Battery
+
NEO-6
Top View
2
3
4
5
6
8
10
12
24
22
21
20
19
17
15
13
23
GND
Reserved
SS_N
TIMEPULSE
EXTINT0
USB_DM
USB_DP
VDDUSB
Reserved
VCC_RF
GND
GND
RF_IN
GND
VCC
V_BCKP
RxD1
TxD1
SCL2
SDA2
(ANTOFF)
CFG_GPS0/SCK
MISO/CFG_COM1
MOSI/CFG_COM0
14
16
11
9
7
1
18
USB port (Optional)
Micro
Processor
(USB)
LDO
SAW
LNA
SAW
inverter
on
VCC
Figure 25: NEO-6 passive antenna design for best performance (with external LNA and SAW)
Figure 26 below shows a passive antenna design for NEO-6 GPS modules with an external SAW-LNA-SAW for best performance and increased immunity to jammers such as GSM. For lowest power in backup mode use ANTOFF
Figure 26: NEO-6 passive antenna design for best performance and increased immunity to jammers such as GSM
For information on increasing immunity to jammers such as GSM, see section 3.3.8.
When using an external LNA in PSM on / off mode, pin 17 can be programmed as ANTOFF.
To configure the ANTOFF function, refer to the u-blox 6 Receiver Description including Protocol
Specification [3].
Use caution when implementing ANTOFF configuration since forward compatibility is not
guaranteed
UBX-14054794 Production Information Design-in Page 34 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Function
PIN
No
I/O
Description
Remarks
Power
VCC
23 I Supply Voltage
Max allowed ripple on VCC=50 mVpp
GND
10,12,13,24
I
Ground
Assure a good GND connection to all GND pins of the module, preferably with a large ground plane.
V_BCKP
22 I Backup voltage supply
It’s recommended to connect a backup battery to V_BCKP in order to enable Warm and Hot Start features on the receivers. Otherwise connect to GND.
VDDUSB
7 I USB Power Supply
To use the USB interface connect this pin to 3.0 – 3.6 V. If no USB serial port used connect to GND.
Antenna
RF_IN
11 I GPS signal input from antenna
The connection to the antenna has to be routed on the PCB. Use a controlled impedance of 50 to connect RF_IN to the antenna or the antenna connector.
VCC_RF
9 O Output Voltage RF section
Pins 8 and 9 must be connected together. VCC_RF can also be used to power an external active antenna.
UART TxD1
20 O Serial Port 1
Communication interface, can be programmed as TX ready for I2C interface.
RxD1
21 I Serial Port 1
Serial input. Internal pull-up resistor to VCC. Leave open if not used.
USB USB_DM
5
I/O
USB I/O line
USB2.0 bidirectional communication pin. Leave open if unused. Implementation see section 1.6.2
USB_DP
6
I/O
USB I/O line
System
TIMEPULSE
3 O Timepulse Signal
Configurable Timepulse signal (one pulse per second by default). Leave open if not used.
EXTINT0
4 I External Interrupt
External Interrupt Pin. Internal pull-up resistor to VCC. Leave open if not used.
SDA2
18
I/O
DDC Pins
DDC Data. Leave open, if not used.
SCL2
19
I/O
DDC Pins
DDC Clock. Leave open, if not used.
Reserved
17
I/O
Reserved
Can be configured as ANTOFF
CFG_COM1 /MISO
15
I/O
Config. Pin /SPI MISO
Leave open if not used.
CFG_COM0 /MOSI
14
I/O
Config. Pin /SPI MOSI
Leave open if not used. Note Connect to GND to use USB in Self Powered mode. See section 1.7.4 and the NEO-6 Data Sheet [3]
Reserved
8 I Reserved
Pins 8 and 9 must be connected together. Can be used as a
RESET_N input. See section 1.7.1
Reserved
1 - Reserved
Leave open.
SS_N
2
I/O
SPI Select
Leave open if not used.
CFG_GPS0 /SCK
16
I/O
Config. Pin /SPI SCK
Leave open if not used.
2.3.2 Pin description for NEO-6 designs
Table 15: Pinout NEO-6
UBX-14054794 Production Information Design-in Page 35 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Vcc
Micro
Processor
(serial)
Passive Antenna
Backup Battery
2
3
4
5
6
8
10
12
17
15
13
Reserved
TIMEPULSE
EXTINT0
TxD1
VCC_IO
V_RESET
VCC_RF
GND
GND
RF_IN
GND
VCC
V_BCKP
RxD1
ANTON
SCL2
SDA2
Reserved
14
16
11
9
7
1
18
MAX-6
Passive Antenna
LNA SAW
Vcc
Micro
Processor
(serial)
Backup Battery
2
3
4
5
6
8
10
12
17
15
13
Reserved
TIMEPULSE
EXTINT0
TxD1
VCC_IO
V_RESET
VCC_RF
GND
GND
RF_IN
GND
VCC
V_BCKP
RxD1
ANTON
SCL2
SDA2
Reserved
14
16
11
9
7
1
18
MAX-6
SAW
Vcc
on
2.4 MAX-6 design
MAX-6 modules provide the following signals:
ANTON Signal (to turn on and off external LNA). To save power consumption in Power Save mode. See
section 2.6.9.
TX ready Signal (to trigger a host, e.g. a u-blox LEON wireless module, when data at DDC interface is ready
to be picked up). To save power consumption on Host side.
2.4.1 MAX-6 passive antenna design
This is a minimal setup for a PVT GPS receiver with a MAX-6 module.
Figure 27: MAX-6 passive antenna design
Figure 28: MAX-6 passive antenna design for best performance and increased immunity to jammers such as GSM
UBX-14054794 Production Information Design-in Page 36 of 85
For information on increasing immunity to jammers such as GSM, see section 3.3.8.
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Function
PIN
No
I/O
Description
Remarks
Power
VCC 8 I
Supply Voltage
Max allowed ripple on VCC=50 mVpp
GND
1,10,12
I
Ground
Assure a good GND connection to all GND pins of the module, preferably with a large ground plane.
V_BCKP
6 I Backup voltage supply
Backup voltage input pin. Connect to GND if not used.
Antenna
RF_IN
11 I GPS signal input from antenna
The connection to the antenna has to be routed on the PCB. Use a controlled impedance of 50 to connect RF_IN to the antenna or the antenna connector. DC block inside.
VCC_RF
14 O Output Voltage RF section
Can be used for active antenna or external LNA supply.
ANTON
13 O
Active antenna or ext. LNA control pin in power save mode. Int. pull-up resistor to VCC
UART TxD1
2 O Serial Port 1
UART, leave open if not used, Voltage level referred VCC_IO. Can be configured as TX ready indication for the DDC interface.
RxD1
3 I Serial Port 1
UART, leave open if not used, Voltage level referred VCC_IO
System
TIMEPULSE
4 O Timepulse Signal
Leave open if not used, Voltage level referred VCC_IO
EXTINT0
5 I External Interrupt
Leave open if not used, Voltage level referred VCC_IO SDA2
16
I/O
DDC Pins
DDC Data. Leave open, if not used.
SCL2
17
I/O
DDC Pins
DDC Clock. Leave open, if not used.
Reserved
18 Reserved
Leave open
VCC_IO
7 I
IO supply voltage Input must be always supplied. Usually connect to VCC Pin 8. If I/O level should be different from VCC, supply VCC_IO with the I/O level required.
V_RESET
9 I VRESET
Must be connected to VCC always. Can be used as reset input pin with additional circuit (connected to VCC by 3.3 k resistor). See section 1.7.1
Reserved
15 Reserved
Leave open
2.4.2 Pin description for MAX-6 designs
Table 16: Pinout MAX-6
2.5 Layout
This section provides important information for designing a reliable and sensitive GPS system. GPS signals at the surface of the Earth are about 15 dB below the thermal noise floor. Signal loss at the antenna
and the RF connection must be minimized as much as possible. When defining a GPS receiver layout, the placement of the antenna with respect to the receiver, as well as grounding, shielding and jamming from other digital devices are crucial issues and need to be considered very carefully.
2.5.1 Footprint and paste mask
Figure 29 - Figure 34 describe the footprint and provide recommendations for the paste mask for u-blox 6 LCC modules. These are recommendations only and not specifications. Note that the Copper and Solder masks have the same size and position.
To improve the wetting of the half vias, reduce the amount of solder paste under the module and increase the volume outside of the module by defining the dimensions of the paste mask to form a T-shape (or equivalent) extending beyond the Copper mask. For the stencil thickness, see section 3.2.1.
UBX-14054794 Production Information Design-in Page 37 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
17.0 mm [669 mil]
22.4 mm [881.9 mil]
1.0 mm [39 mil]
0.8 mm [31.5 mil]
2.45 mm
[96.5 mil]
1.1 mm
[43 mil]
3.0 mm
[118 mil]
2.15 mm
[84.5 mil]
0.8 mm
[31.5 mil]
Figure 29: LEA-6 footprint
Stencil: 150m
15.7 mm [618 mil]
17.0 mm [669 mil]
20.8 mm [819 mil]
0.8 mm [31.5
mil
]
0.6 mm [23.5
mil
]
Figure 30: LEA-6 paste mask
12.2 mm [480.3 mil]
16.0 mm [630
mil
]
1.0 mm
[39.3 mil]
0.8 mm [31.5
mil
]
0.8 mm
[31.5
mil
]
3.0 mm [118.1
mil
]
1.0 mm [39.3
mil
]
1.1 mm [43.3
mil
]
Figure 31: NEO-6 footprint
9.7 mm [382 mil]
10.1 mm [
398
mil
]
1.0 mm
[39.3 mil]
0.7 mm [
27.6
mil
]
0.8 mm
[31.5
mil
]
0.65 mm
[
26.6
mil
]
1.1 mm [43.3
mil
]
0.8 mm [
31.5
mil
]
Figure 32: MAX-6 footprint
Stencil: 150m
10.4 mm [409.5 mil]
14.6 mm [575 mil]
12.2 mm [480 mil]
0.8 mm [31.5
mil
]
0.6 mm [23.5
mil
]
Figure 33: NEO-6 paste mask
Stencil: 150m
7.9 mm [311 mil]
12.5 mm [492 mil]
9.7 mm [382 mil]
0.7 mm [27.6
mil
]
0.5 mm [19.7
mil
]
0.8 mm [31.5
mil
]
0.6 mm [23.5
mil
]
Figure 34: MAX-6 paste mask
UBX-14054794 Production Information Design-in Page 38 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Non 'emitting'
circuits
PCB
Digital & Analog circuits
Non
'emitting'
circuits
Antenna
Digital Part
RF Part
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
RF & heat
'emitting'
circuits
PCB
Digital & Analog circuits
RF& heat 'emitting'
circuits
Antenna
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
MAX Form Factor (10.1 x 9.7 x 2.5): Same Pitch as NEO for all pins: 1.1 mm, but 4 pads in each corner
(pin 1, 9, 10 and 18) only 0.7 mm wide instead 0.8 mm
The paste mask outline needs to be considered when defining the minimal distance to the next
component. The exact geometry, distances, stencil thicknesses and solder paste volumes must be adapted to the specific production processes (e.g. soldering etc.) of the customer.
2.5.2 Placement
A very important factor in achieving maximum performance is the placement of the receiver on the PCB. The connection to the antenna must be as short as possible to avoid jamming into the very sensitive RF section.
Make sure that RF critical circuits are clearly separated from any other digital circuits on the system board. To achieve this, position the receiver digital part towards your digital section of the system PCB. Care must also be exercised with placing the receiver in proximity to circuitry that can emit heat. The RF part of the receiver is very sensitive to temperature and sudden changes can have an adverse impact on performance.
The RF part of the receiver is a temperature sensitive component. Avoid high temperature drift
and air vents near the receiver.
Figure 35: Placement (for exact pin orientation see data sheet)
UBX-14054794 Production Information Design-in Page 39 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
2.5.3 Antenna connection and grounding plane design
u-blox 6 modules can be connected to passive patch or active antennas. The RF connection is on the PCB and connects the RF_IN pin with the antenna feed point or the signal pin of the connector, respectively. Figure 36 illustrates connection to a typical five-pin RF connector. One can see the improved shielding for digital lines as discussed in the GPS Antenna Application Note [5]. Depending on the actual size of the ground area, additional vias should be placed in the outer region. In particular, the edges of the ground area should be terminated with a dense line of vias.
Figure 36: Recommended layout (for exact pin orientation see data sheet)
As seen in Figure 36, an isolated ground area is created around and below the RF connection. This part of the circuit MUST be kept as far from potential noise sources as possible. Make certain that no signal lines cross, and that no signal trace vias appear at the PCB surface within the area of the red rectangle. The ground plane should also be free of digital supply return currents in this area. On a multi layer board, the whole layer stack below the RF connection should be kept free of digital lines. This is because even solid ground planes provide only limited isolation.
The impedance of the antenna connection has to match the 50 impedance of the receiver. To achieve an impedance of 50 Ohms, the width W of the micro strip has to be chosen depending on the dielectric thickness H, the dielectric constant r of the dielectric material of the PCB and on the build-up of the PCB (see section 2.5.4). Figure 37 shows two different builds: A 2 Layer PCB and a 4 Layer PCB. The reference ground plane is in both designs on layer 2 (red). Therefore the effective thickness of the dielectric is different.
UBX-14054794 Production Information Design-in Page 40 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Module
micro strip line
Ground plane
Module
micro strip line
Ground plane
PCB
PCB
Either don't use these layers or fillwith ground planes
H
H
Antenna
Antenna
Antenna
PCB
PCB
PCB
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
Figure 37: PCB build-up for micro strip line. Left: 2-layer PCB, right: 4-layer PCB
General design recommendations:
The length of the micro strip line should be kept as short as possible. Lengths over 2.5 cm (1 inch) should be
avoided on standard PCB material and without additional shielding.
For multi layer boards the distance between micro strip line and ground area on the top layer should at least
be as large as the dielectric thickness.
Routing the RF connection close to digital sections of the design should be avoided. To reduce signal reflections, sharp angles in the routing of the micro strip line should be avoided. Chamfers
or fillets are preferred for rectangular routing; 45-degree routing is preferred over Manhattan style 90-degree routing.
Wrong better best
Figure 38: Recommended micro strip routing to RF pin (for exact pin orientation see data sheet)
Do not route the RF-connection underneath the receiver. The distance of the micro strip line to the ground
plane on the bottom side of the receiver is very small (some 100 µm) and has huge tolerances (up to 100%). Therefore, the impedance of this part of the trace cannot be controlled.
Use as many vias as possible to connect the ground planes. In order to avoid reliability hazards, the area on the PCB under the receiver should be entirely covered with
solder mask. Vias should not be open. Do not route under the receiver.
2.5.4 Antenna micro strip
There are many ways to design wave-guides on printed circuit boards. Common to all is that calculation of the electrical parameters is not straightforward. Freeware tools like AppCAD from Agilent or TXLine from Applied Wave Research, Inc. are of great help. They can be downloaded from www.agilent.com or http://www.hp.woodshot.com/ and www.mwoffice.com.
The micro strip is the most common configuration for printed circuit boards. The basic configuration is shown in Figure 39 and Figure 40. As a rule of thumb, for a FR-4 material the width of the conductor is roughly double the thickness of the dielectric to achieve 50 line impedance.
UBX-14054794 Production Information Design-in Page 41 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
–For the correct calculation of the micro strip impedance, one does not only need to consider the distance between the top and the first inner layer but also the distance between the micro strip and the adjacent GND plane on the same layer
Use the Coplanar Waveguide model for the calculation of the micro strip.
Figure 39: Micro strip on a 2-layer board (Agilent AppCAD Coplanar Waveguide)
Figure 39 shows an example of a 2-layer FR4 board with 1.6 mm thickness and a 35 µm (1 ounce) copper cladding. The thickness of the micro strip is comprised of the cladding (35µm) plus the plated copper (typically 25µm). Figure 40 is an example of a multi layer FR4 board with 18 µm (½ ounce) cladding and 180 µ dielectric between layer 1 and 2.
Figure 40: Micro strip on a multi layer board (Agilent AppCAD Coplanar Waveguide)
2.6 Antenna and antenna supervisor
u-blox 6 modules receive L1 band signals from GPS and GALILEO satellites at a nominal frequency of
1575.42 MHz. The RF signal is connected to the RF_IN pin. u-blox 6 modules can be connected to passive or active antennas.
For u-blox 6 receivers, the total preamplifier gain (minus cable and interconnect losses) must not exceed
50 dB. Total noise figure should be below 3 dB.
u-blox 6 Technology supports short circuit protection of the active antenna and an active antenna supervisor circuit (open and short circuit detection). For further information refer to Section 2.6.2).
UBX-14054794 Production Information Design-in Page 42 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
2.6.1 Passive antenna
A design using a passive antenna requires more attention regarding the layout of the RF section. Typically a passive antenna is located near electronic components; therefore care should be taken to reduce electrical ‘noise’ that may interfere with the antenna performance. Passive antennas do not require a DC bias voltage and can be directly connected to the RF input pin RF_IN. Sometimes, they may also need a passive matching network to match the impedance to 50 .
Some passive antenna designs present a DC short to the RF input, when connected. If a system is
designed with antenna bias supply AND there is a chance of a passive antenna being connected to the design, consider a short circuit protection.
All u-blox 6 receivers have a built-in LNA required for passive antennas.
Consider optional ESD protection (see section 3.3).
2.6.2 Active antenna (LEA-6)
Active antennas have an integrated low-noise amplifier. They can be directly connected to RF_IN. If an active antenna is connected to RF_IN, the integrated low-noise amplifier of the antenna needs to be supplied with the correct voltage through pin V_ANT. Usually, the supply voltage is fed to the antenna through the coaxial RF cable. Active antennas require a power supply that will contribute to the total GPS system power consumption budget with additional 5 to 20 mA typically. Inside the antenna, the DC component on the inner conductor will be separated from the RF signal and routed to the supply pin of the LNA (see Figure 41).
Figure 41: Active antenna biasing (for exact pin orientation see data sheet)
Generally an active antenna is easier to integrate into a system design, but an active antenna must also be placed far from any noise sources to have good performance.
Antennas should only be connected to the receiver when the receiver is not powered. Do not
connect or disconnect the Antenna when the u-blox 6 receiver is running as the receiver calibrates the noise floor on power-up. Connecting the antenna after power-up can result in prolonged acquisition time.
Never feed supply voltage into RF_IN on u-blox LEA-6 modules. Always feed via V_ANT.
To test GPS signal reacquisition, it is recommended to physically block the signal to the antenna, rather
than disconnecting and reconnecting the receiver.
Consider optional ESD protection; see section 3.3 for more information.
UBX-14054794 Production Information Design-in Page 43 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
u-blox 6 Module
GND
RF_IN
GND
Active Antenna
V_ANT
VCC_RF
LNA
R_BIAS
u-blox 6 Module
GND
RF_IN
GND
Active Antenna
V_ANT
VCC_RF
LNA
external antenna
voltage
supply
R_BIAS
2.6.3 Active antenna bias power (LEA-6)
There are two ways to supply the bias voltage to pin V_ANT. For Internal supply, the VCC_RF output must be connected to V_ANT to supply the antenna with a filtered supply voltage. However, the voltage specification of the antenna has to match the actual supply voltage of the u-blox 6 Receiver (e.g. 3.0 V).
Figure 42: Internal supply Antenna bias voltage (for exact pin orientation see data sheet)
Figure 43: External supplying Antenna bias voltage (for exact pin orientation see data sheet)
Since the bias voltage is fed into the most sensitive part of the receiver, i.e. the RF input, this supply should be virtually free of noise. Usually, low frequency noise is less critical than digital noise with spurious frequencies with harmonics up to the GPS/QZSS band of 1.575 GHz and GLONASS band of 1.602 GHz. Therefore, it is not recommended to use digital supply nets to feed pin V_ANT.
An internal switch (under control of the u-blox 6 software) can shut down the supply to the external antenna whenever it is not needed. This feature helps to reduce power consumption.
2.6.3.1 Short circuit protection
If a reasonably dimensioned series resistor R_BIAS is placed in front of pin V_ANT, a short circuit situation can be detected by the baseband processor. If such a situation is detected, the baseband processor will shut down supply to the antenna. The receiver is by default configured to attempt to reestablish antenna power supply periodically.
To configure the antenna supervisor use the UBX-CFG-ANT message. For further information refer to the
u-blox 6 Receiver Description including Protocol Specification [4].
UBX-14054794 Production Information Design-in Page 44 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
References
Value
Tolerance
Description
Manufacturer
R_BIAS
10
10%
Resistor, min 0.250 W
u-blox 6 Module
GND
RF_IN
GND
Active Antenna
V_ANT
VCC_RF
LNA
AADET_N
Antenna
Supervisor
Circuitry
external antenna
voltage
supply
Table 17: Short circuit protection, bill of material
Short circuits on the antenna input without limitation (R_BIAS) of the current can result in
permanent damage to the receiver! Therefore, it’s recommended to implement an R_BIAS in all
risk applications, such as situations where the antenna can be disconnected by the end-user or that have long antenna cables.
An additional R_BIAS is not required when using a short and open active antenna supervisor circuitry as
defined in Section 2.6.4.1, as the R_BIAS is equal to R2.
2.6.4 Active antenna supervisor (LEA-6)
u-blox 6 Technology provides the means to implement an active antenna supervisor with a minimal number of parts. The antenna supervisor is highly configurable to suit various different applications.
Figure 44: External antenna power supply with full antenna supervisor (for exact pin orientation see data sheet)
2.6.4.1 Short and open circuit active antenna supervisor
The Antenna Supervisor can be configured by a serial port message (using only UBX binary message). When enabled the active antenna supervisor produces serial port messages (status reporting in NMEA and/or UBX binary protocol) which indicates all changes of the antenna circuitry (disabled antenna supervisor, antenna circuitry ok, short circuit, open circuit) and shuts the antenna supply down if required. Active antenna status can be determined also polling UBX-MON-HW.
The active antenna supervisor provides the means to check the active antenna for open and short circuits and to shut the antenna supply off, if a short circuit is detected. The state diagram in Figure 45 applies. If an antenna is connected, the initial state after power-up is “Active Antenna OK”.
UBX-14054794 Production Information Design-in Page 45 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
No
Super-
vision
Active
Antenna
OK
Open
Circuit
detected
Short
Circuit
detected
Powerup
Events AADET0_N
User controlled events
Disable Supervision
Enable Supervision
Short Circuit
detected
Disable
Supervision
Antenna connected
Short Circuit
detected
open circuit
detected, given
OCD enabled
Periodic
reconnection
attempts
Figure 45: State diagram of active antenna supervisor
Firmware supports an active antenna supervisor circuit, which is connected to the pin AADET_N. An example of an open circuit detection circuit is shown in Figure 46 and Figure 47. High on AADET_N means that an external antenna is not connected.
Short Circuit Detection (SCD)
A short circuit in the active antenna pulls V_ANT to ground. This is detected inside the u-blox 6 module and the antenna supply voltage will be immediately shut down.
Antenna short detection (SCD) and control is enabled by default.
Open Circuit Detection (OCD)
Figure 46: Schematic of open circuit detection variant A (for exact pin orientation see data sheet)
UBX-14054794 Production Information Design-in Page 46 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
References
Value
Tolerance
Description
Remarks
R1
10
5%
Resistor, min 0.250 W
R2
560
5%
Resistor
R3
100 k
5%
Resistor
U1
LT6000
Rail to Rail Op Amp
Linear Technology
RFVcc
R
RR
R
I _
1
32
2
 
 
GND
RF_IN
GND
V_ANT
VCC_RF
Active Antenna
ADDET_N
V_ANT
Antenna
Supply in
Analog GND
R1
R2
R3 R4 R5
T2 PNP
T1
PNP
C1
C2
FB1
AADET_N
LEA-6x
Table 18: Active antenna supervisor, bill of material
Equation 1: Calculation of threshold current for open circuit detection
If the antenna supply voltage is not derived from Vcc_RF, do not exceed the maximum voltage rating of
AADET_N.
The open circuit detection circuit uses the current flow to detect an open circuit in the antenna. The threshold current can be calculated using Equation 1.
Figure 47: Schematic of open circuit detection variant B (for exact pin orientation see data sheet)
The open circuit supervisor circuitry shown in Figure 47 has a quiescent current of approximately 2mA.
This current can be reduced with an advanced circuitry such as shown in Figure 47.
UBX-14054794 Production Information Design-in Page 47 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
References
Value
Tolerance
Description
Remarks / Manufacturer
C1
2.2 µF
10%
Capacitor, X7R, min 10 V
C2
100 nF
10%
Capacitor, X7R, min 10 V
FB1
600
Ferrite Bead
e.g. Murata BLM18HD601SN1
R1
15
10%
Resistor, min 0.063 W
R2
10
10%
Resistor, min 0.250 W
R3, R4
10 k
10%
Resistor, min 0.063 W
R5
33 k
10%
Resistor, min 0.063 W
T1, T2
BC856B
PNP Transistor
e.g. Philips Semiconductors9
Abbreviation
Description
AC
Antenna Control (e.g. the antenna will be switched on/ off controlled by the GPS receiver)
SD
Short Circuit Detection Enabled
SR
Short Circuit Recovery Enabled
OD
Open Circuit Detection Enabled
PdoS
Power Down on short
Message
Description ANTSTATUS=DONTKNOW
Active antenna supervisor is not configured and deactivated.
ANTSTATUS=OK
Active antenna connected and powered
ANTSTATUS=SHORT
Antenna short
ANTSTATUS=OPEN
Antenna not connected or antenna defective
9
Table 19: Active antenna supervisor, bill of material
Status reporting
At startup and on every change of the antenna supervisor configuration the u-blox 6 GPS/GALILEO module will output a NMEA ($GPTXT) or UBX (INF-NOTICE) message with the internal status of the antenna supervisor (disabled, short detection only, enabled).
None, one or several of the strings below are part of this message to inform about the status of the active
antenna supervisor circuitry (e.g. “ANTSUPERV= AC SD OD PdoS”).
Table 20: Active Antenna Supervisor Message on startup (UBX binary protocol)
To activate the antenna supervisor use the UBX-CFG-ANT message. For further information refer to the
u-blox 6 Receiver Description including Protocol Specification [4].
Similar to the antenna supervisor configuration, the status of the antenna supervisor will be reported in a NMEA ($GPTXT) or UBX (INF-NOTICE) message at start-up and on every change.
Table 21: Active antenna supervisor message on startup (NMEA protocol)
2.6.5 Active antenna (NEO-6 and MAX-6)
NEO-6 and MAX-6 modules do not provide the antenna bias voltage for active antennas on the RF_IN pin. It is therefore necessary to provide this voltage outside the module via an inductor L as indicated in Figure 48. u-blox
recommends using an inductor from Murata (LQG15HS27NJ02). Alternative parts can be used if the inductor’s
resonant frequency matches the GPS frequency of 1575.42 MHz.
Transistors from other suppliers with comparable electrical characteristics may be used.
UBX-14054794 Production Information Design-in Page 48 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Low Noise Amplifier
Active Antenna
RF_IN
VCC_RF
GND
GND
10
R_BIAS
L
Low Noise Amplifier
Active Antenna
RF_IN
VCC_RF
GND
GND
External antenna
supply
voltage
L
GND
Mic rostrip
GND
RF_IN
Antenna Supply Voltage
(e.g. VCC_RF)
Inductor L
GND
GND
Antenna Supply Voltage
(e.g. VCC_RF)
Inductor L
Mic rostrip
RF_IN
Good Bad
Figure 48: Internal antenna bias voltage for active antennas
Figure 49: External antenna bias voltage for active antennas
For optimal performance, it is important to place the inductor as close to the microstrip as possible. Figure 50 illustrates the recommended layout and how it should not be done.
Figure 50: Recommended layout for connecting the antenna bias voltage for LEA-6M and NEO-6
UBX-14054794 Production Information Design-in Page 49 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
References
Value
Tolerance
Description
Remarks / Manufacturer
R1
10
5%
Resistor, min 0.25 W
R2
560
5%
Resistor
R3
100 k
5%
Resistor
R4
100 k
5%
Resistor
U1
LT6000
Rail to Rail Op Amp
Linear Technology
T1
Si1016X-T1-E3
Transistor
Vishay
L1
LQG15HS27NJ02
Inductor
muRata
C1
X5R 100N 10V
10%
Decoupling Capacitor
muRata
RFVcc
R
RR
R
I _
1
32
2
 
 
2.6.6 External active antenna supervisor using ANTOFF (NEO-6)
Figure 51: External active antenna supervisor using ANTOFF (NEO-6)
Table 22: Active antenna supervisor, bill of material
Equation 2: Calculation of threshold current for open circuit detection
The state diagram of active antenna supervisor is in Figure 45. When using an external LNA in PSM on /
off mode, pin 17 can be programmed as ANTOFF (see section 1.7.7). Use ANTOFF_IN and ANTOFF_OUT signals to command antenna power supply when going into Power Save Mode (Backup mode).
Use caution when implementing ANTOFF configuration since forward compatibility is not
guaranteed
UBX-14054794 Production Information Design-in Page 50 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
References
Value
Tolerance
Description
Remarks / Manufacturer
R1
10
5%
Resistor, min 0.25 W
R2
560
5%
Resistor
R3
100 k
5%
Resistor
R4
100 k
5%
Resistor
U1
LT6000
Rail to Rail Op Amp
Linear Technology
T1
Si1016X-T1-E3
Transistor
Vishay
L1
LQG15HS27NJ02
Inductor
muRata
C1
X5R 100N 10V
10%
Decoupling Capacitor
muRata
RFVcc
R
RR
R
I _
1
32
2
 
 
2.6.7 External active antenna supervisor using ANTON (MAX-6)
Figure 52: External active antenna supervisor using ANON (MAX-6)
Table 23: Active antenna supervisor, bill of material
Equation 3: Calculation of threshold current for open circuit detection
State diagram of active antenna supervisor see Figure 45. When using an external LNA in PSM on / off
mode, pin 17 can be programmed as ANTOFF (see section 1.7.7). Use ANTOFF_IN and ANTOFF_OUT signals to command antenna power supply when going into Power Save Mode (Backup mode).
UBX-14054794 Production Information Design-in Page 51 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
References
Value
Tolerance
Description
Remarks / Manufacturer
R1
10
5%
Resistor, min 0.25 W
R4
100 k
5%
Resistor
T1
Si1016X-T1-E3
Transistor
Vishay
L1
LQG15HS27NJ02
Inductor
muRata
C1
X5R 100N 10V
10%
Decoupling Capacitor
muRata
2.6.8 External active antenna control (NEO-6)
Figure 53: External active antenna control (NEO-6)
When using an external LNA in PSM on / off mode, pin 17 can be programmed as ANTOFF (see section
1.7.7).
Use caution when implementing ANTOFF configuration since forward compatibility is not
guaranteed
Table 24: Active antenna control, bill of material
UBX-14054794 Production Information Design-in Page 52 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
References
Value
Tolerance
Description
Remarks / Manufacturer
R1
10
5%
Resistor, min 0.25 W
R2
100 k
5%
Resistor
T1
Si1040X
Power MOSFET
Vishay
L1
LQG15HS27NJ02
Inductor
muRata
C1
X5R 1N 10V
10%
Decoupling Capacitor
muRata
2.6.9 External active antenna control (MAX-6)
ANTON Signal can be used to turn on and off an external LNA. This reduces power consumption in Power Save Mode (Backup mode).
Figure 54: External active antenna control (MAX-6)
Table 25: Active antenna control, bill of material
2.6.10 GPS antenna placement for LEA-6R
For an optimum ADR navigation performance, the following setup recommendations should be considered.
GPS antenna placement, gyro placement and single tick origin
Due to geometric and dynamic aspects of driving vehicles, it is important to correctly place the GPS antenna and the external sensors - from a geometric point of view - in order to get consistent measurement information from the different sensors.
For standard road vehicles: The GPS antenna should be placed above the middle of the rear (unsteered) axis. The gyro can be placed anywhere on the vehicle. Single ticks should origin from the rear (unsteered) wheels. For articulated busses, the sensors should be placed on the front car as if this was a standard road vehicle. In case the GWT solution is used for rail vehicles: The GPS antenna should be placed in the middle of a wagon, while the gyro can be placed anywhere on the same wagon and the single ticks can origin from any wheels of the same wagon.
Large geometrical deviations from the optimal placement - especially of the GPS antenna (e.g.
when placing it above the front axis of a long bus) - can result in significant performance degradation!
UBX-14054794 Production Information Design-in Page 53 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
3 Product handling
3.1 Packaging, shipping, storage and moisture preconditioning
For information pertaining to reels and tapes, Moisture Sensitivity levels (MSD), shipment and storage information, as well as drying for preconditioning see the data sheet of the specific u-blox 6 GPS module.
3.1.1 Population of Modules
When populating our modules make sure that the pick and place machine is aligned to the copper pins of
the module and not on the module edge.
3.2 Soldering
3.2.1 Soldering paste
Use of "No Clean" soldering paste is strongly recommended, as it does not require cleaning after the soldering process has taken place. The paste listed in the example below meets these criteria.
Soldering Paste: OM338 SAC405 / Nr.143714 (Cookson Electronics) Alloy specification: Sn 95.5/ Ag 4/ Cu 0.5 (95.5% Tin/ 4% Silver/ 0.5% Copper) Melting Temperature: 217°C Stencil Thickness: 150 µm for base boards The final choice of the soldering paste depends on the approved manufacturing procedures. The paste-mask geometry for applying soldering paste should meet the recommendations in section 2.5.1.
The quality of the solder joints on the connectors (’half vias’) should meet the appropriate IPC
specification.
3.2.2 Reflow soldering
A convection type-soldering oven is strongly recommended over the infrared type radiation oven.
Convection heated ovens allow precise control of the temperature and all parts will be heated up evenly, regardless of material properties, thickness of components and surface color.
Consider the "IPC-7530 Guidelines for temperature profiling for mass soldering (reflow and wave) processes, published 2001".
Preheat phase
Initial heating of component leads and balls. Residual humidity will be dried out. Please note that this preheat phase will not replace prior baking procedures.
Temperature rise rate: max.3°C/s If the temperature rise is too rapid in the preheat phase it may cause
excessive slumping.
Time: 60 – 120 s If the preheat is insufficient, rather large solder balls tend to be
generated. Conversely, if performed excessively, fine balls and large balls will be generated in clusters.
End Temperature: 150 - 200°C If the temperature is too low, non-melting tends to be caused in
areas containing large heat capacity.
UBX-14054794 Production Information Product handling Page 54 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Heating/ Reflow phase
The temperature rises above the liquidus temperature of 217°C. Avoid a sudden rise in temperature as the slump of the paste could become worse.
Limit time above 217°C liquidus temperature: 40 – 60 s Peak reflow temperature: 245°C
Cooling phase
A controlled cooling avoids negative metallurgical effects (solder becomes more brittle) of the solder and possible mechanical tensions in the products. Controlled cooling helps to achieve bright solder fillets with a good shape and low contact angle.
Temperature fall rate: max 4°C / s
To avoid falling off, the u-blox 6 GPS module should be placed on the topside of the motherboard during
soldering.
The final soldering temperature chosen at the factory depends on additional external factors like choice of soldering paste, size, thickness and properties of the base board, etc. Exceeding the maximum soldering temperature in the recommended soldering profile may permanently damage the module.
Figure 55: Recommended soldering profile
u-blox 6 modules must not be soldered with a damp heat process.
3.2.3 Optical inspection
After soldering the u-blox 6 module, consider an optical inspection step to check whether:
The module is properly aligned and centered over the pads All pads are properly soldered No excess solder has created contacts to neighboring pads, or possibly to pad stacks and vias nearby.
UBX-14054794 Production Information Product handling Page 55 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
3.2.4 Cleaning
In general, cleaning the populated modules is strongly discouraged. Residues underneath the modules cannot be easily removed with a washing process.
Cleaning with water will lead to capillary effects where water is absorbed in the gap between the baseboard
and the module. The combination of residues of soldering flux and encapsulated water leads to short circuits or resistor-like interconnections between neighboring pads.
Cleaning with alcohol or other organic solvents can result in soldering flux residues flooding into the two
housings, areas that are not accessible for post-wash inspections. The solvent will also damage the sticker and the ink-jet printed text.
Ultrasonic cleaning will permanently damage the module, in particular the quartz oscillators.
The best approach is to use a "no clean" soldering paste and eliminate the cleaning step after the soldering.
3.2.5 Repeated reflow soldering
Only single reflow soldering processes are recommended for boards populated with u-blox 6 modules. u-blox 6 modules should not be submitted to two reflow cycles on a board populated with components on both sides in order to avoid upside down orientation during the second reflow cycle. In this case the module should always be placed on that side of the board which is submitted into the last reflow cycle. The reason for this (besides others) is the risk of the module falling off due to the significantly higher weight in relation to other components.
Two reflow cycles can be considered by excluding the above described upside down scenario and taking into account the rework conditions described in Section 3.2.8.
Repeated reflow soldering processes and soldering the module upside down are not recommended.
3.2.6 Wave soldering
Base boards with combined through-hole technology (THT) components and surface-mount technology (SMT) devices require wave soldering to solder the THT components. Only a single wave soldering process is encouraged for boards populated with u-blox 6 modules.
3.2.7 Hand soldering
Hand soldering is allowed. Use a soldering iron temperature setting equivalent to 350°C. Place the module precisely on the pads. Start with a cross-diagonal fixture soldering (e.g. pins 1 and 15), and then continue from left to right.
3.2.8 Rework
The u-blox 6 module can be unsoldered from the baseboard using a hot air gun. When using a hot air gun for unsoldering the module, max 1 reflow cycle is allowed. In general we do not recommend using a hot air gun because this is an uncontrolled process and might damage the module.
Attention: use of a hot air gun can lead to overheating and severely damage the module.
Always avoid overheating the module.
After the module is removed, clean the pads before placing and hand-soldering a new module.
Never attempt a rework on the module itself, e.g. replacing individual components. Such
actions immediately terminate the warranty.
In addition to the two reflow cycles manual rework on particular pins by using a soldering iron is allowed. Manual rework steps on the module can be done several times.
UBX-14054794 Production Information Product handling Page 56 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
3.2.9 Conformal coating
Certain applications employ a conformal coating of the PCB using HumiSeal® or other related coating products. These materials affect the HF properties of the GPS module and it is important to prevent them from flowing into the module. The RF shields do not provide 100% protection for the module from coating liquids with low viscosity; therefore care is required in applying the coating.
Conformal Coating of the module will void the warranty.
3.2.10 Casting
If casting is required, use viscose or another type of silicon pottant. The OEM is strongly advised to qualify such processes in combination with the u-blox 6 module before implementing this in the production.
Casting will void the warranty.
3.2.11 Grounding metal covers
Attempts to improve grounding by soldering ground cables, wick or other forms of metal strips directly onto the EMI covers is done at the customer's own risk. The numerous ground pins should be sufficient to provide optimum immunity to interferences and noise.
u-blox makes no warranty for damages to the u-blox 6 module caused by soldering metal cables or any
other forms of metal strips directly onto the EMI covers.
3.2.12 Use of ultrasonic processes
Some components on the u-blox 6 module are sensitive to Ultrasonic Waves. Use of any Ultrasonic Processes (cleaning, welding etc.) may cause damage to the GPS Receiver.
u-blox offers no warranty against damages to the u-blox 6 module caused by any Ultrasonic Processes.
3.3 EOS/ESD/EMI Precautions
When integrating GPS receivers into wireless systems, careful consideration must be given to electromagnetic and voltage susceptibility issues. Wireless systems include components which can produce Electrical Overstress (EOS) and Electro-Magnetic Interference (EMI). CMOS devices are more sensitive to such influences because their failure mechanism is defined by the applied voltage, whereas bipolar semiconductors are more susceptible to thermal overstress. The following design guidelines are provided to help in designing robust yet cost effective solutions.
To avoid overstress damage during production or in the field it is essential to observe strict
EOS/ESD/EMI handling and protection measures.
To prevent overstress damage at the RF_IN of your receiver, never exceed the maximum input
power (see Data Sheet).
3.3.1 Abbreviations
For a list of abbreviations used see Table 28 in Appendix A.
3.3.2 Electrostatic discharge (ESD)
Electrostatic discharge (ESD) is the sudden and momentary electric current that flows between two objects at different electrical potentials caused by direct contact or induced by an electrostatic field. The term is usually used in the electronics and other industries to describe momentary unwanted currents that may cause damage to electronic equipment.
UBX-14054794 Production Information Product handling Page 57 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Unless there is a galvanic coupling between the local GND (i.e. the
work table) and the PCB GND, the first point of contact when handling the PCB shall always be between the local GND and PCB GND.
Before mounting an antenna patch, connect ground of the device.
GND
Local GND
When handling the RF pin, do not come into contact with any
charged capacitors and be careful when contacting materials that can develop charges (e.g. patch antenna ~10 pF, coax cable ~50­80 pF/m, soldering iron, …)
ESD
Sensitive!
RF_IN
To prevent electrostatic discharge through the RF input, do not
touch any exposed antenna area. If there is any risk that such exposed antenna area is touched in non ESD protected work area, implement proper ESD protection measures in the design.
When soldering RF connectors and patch antennas to the receiver’s
RF pin, make sure to use an ESD safe soldering iron (tip).
RF_IN
ESD Safe
3.3.3 ESD handling precautions
ESD prevention is based on establishing an Electrostatic Protective Area (EPA). The EPA can be a small working station or a large manufacturing area. The main principle of an EPA is that there are no highly charging materials in the vicinity of ESD sensitive electronics, all conductive materials are grounded, workers are grounded, and charge build-up on ESD sensitive electronics is prevented. International standards are used to define typical EPA and can be obtained for example from International Electrotechnical Commission (IEC) or American National Standards Institute (ANSI).
GPS receivers are sensitive to ESD and require special precautions when handling. Particular care must be exercised when handling patch antennas, due to the risk of electrostatic charges. In addition to standard ESD safety practices, the following measures should be taken into account whenever handling the receiver.
Failure to observe these precautions can result in severe damage to the GPS receiver!
UBX-14054794 Production Information Product handling Page 58 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Small passive antennas (<2 dBic and performance critical)
Passive antennas (>2 dBic or performance sufficient)
Active Antennas
A
RF_IN
GPS
Receiver
LNA
B
L
RF_IN
GPS
Receiver
C
D
RF_IN
GPS
Receiver
LNA with appropriate ESD rating
3.3.4 ESD protection measures
GPS receivers are sensitive to Electrostatic Discharge (ESD). Special precautions are required
when handling.
For more robust designs, employ additional ESD protection measures. Using an LNA with appropriate ESD
rating can provide enhanced GPS performance with passive antennas and increases ESD protection.
Most defects caused by ESD can be prevented by following strict ESD protection rules for production and handling. When implementing passive antenna patches or external antenna connection points, then additional ESD measures as shown in Figure 56 can also avoid failures in the field.
Figure 56: ESD Precautions
Protection measure A is preferred because it offers the best GPS performance and best level of ESD
protection.
3.3.5 Electrical Overstress (EOS)
Electrical Overstress (EOS) usually describes situations when the maximum input power exceeds the maximum specified ratings. EOS failure can happen if RF emitters are close to a GPS receiver or its antenna. EOS causes damage to the chip structures.
If the RF_IN is damaged by EOS, it’s hard to determine whether the chip structures have been damaged by ESD or EOS.
3.3.6 EOS protection measures
For designs with GPS receivers and wireless (e.g. GSM/GPRS) transceivers in close proximity, ensure
sufficient isolation between the wireless and GPS antennas. If wireless power output causes the specified maximum power input at the GPS RF_IN to be exceeded, employ EOS protection measures to prevent overstress damage.
For robustness, EOS protection measures as shown in Figure 57 are recommended for designs combining wireless communication transceivers (e.g. GSM, GPRS) and GPS in the same design or in close proximity.
See C26 telematics reference design [12].
UBX-14054794 Production Information Product handling Page 59 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Small passive antennas (<2 dBic and performance critical)
Passive antennas (>2 dBic or performance sufficient)
Active Antennas (without internal filter which need the module antenna supervisor circuits)
D
RF_IN
GPS
Receiver
LNA
GPS
Bandpas s
Filtler
E
RF_IN
GPS
Receiver
L
GPS
Bandpas s
Filtler
F
LNA with appropriate ESD rating and maximum input power
GPS Bandpass Filter: SAW or Ceramic with low insertion loss and appropriate ESD rating
TX
RX
GPS
Receiver
FB
FB
BLM15HD102SN1
>10mm
Figure 57: EOS and ESD Precautions
3.3.7 Electromagnetic interference (EMI)
Electromagnetic interference (EMI) is the addition or coupling of energy originating from any RF emitting device. This can cause a spontaneous reset of the GPS receiver or result in unstable performance. Any unshielded line or segment (>3mm) connected to the GPS receiver can effectively act as antenna and lead to EMI disturbances or damage.
The following elements are critical regarding EMI:
Unshielded connectors (e.g. pin rows etc.) Weakly shielded lines on PCB (e.g. on top or bottom layer and especially at the border of a PCB) Weak GND concept (e.g. small and/or long ground line connections)
EMI protection measures are recommended when RF emitting devices are near the GPS receiver. To minimize the effect of EMI a robust grounding concept is essential. To achieve electromagnetic robustness follow the standard EMI suppression techniques.
http://www.murata.com/products/emc/knowhow/index.html http://www.murata.com/products/emc/knowhow/pdf/4to5e.pdf Improved EMI protection can be achieved by inserting a resistor (e.g. R>20 ) or better yet a ferrite bead
(BLM15HD102SN1) or an inductor (LQG15HS47NJ02) into any unshielded PCB lines connected to the GPS receiver. Place the resistor as close as possible to the GPS receiver pin.
Example of EMI protection measures on the RX/TX line using a ferrite bead:
Figure 58: EMI Precautions
VCC can be protected using a feed thru capacitor. For electromagnetic compatibility (EMC) of the RF_IN pin refer to section 3.3.6
Intended use
In order to mitigate any performance degradation of a radio equipment under EMC disturbance, system
integration shall adopt appropriate EMC design practice and not contain cables over three meters on signal and supply ports.
UBX-14054794 Production Information Product handling Page 60 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
1525 1550 1625
GPS input filter characteristics
1575 1600
0
-110
Jammin g signal
1525 1550 1625
Frequency [MHz]
Power [dBm]
GPS input filter characteristics
1575 1600
0
Jamming
signal
GPS
signals
GPS Carrier
1575.4 MHz
3.3.8 Applications with wireless modules LEON / LISA
GSM uses power levels up to 2 W (+33 dBm). Consult the Data Sheet for the absolute maximum power input at the GPS receiver.
3.3.8.1 Isolation between GPS and GSM antenna
In a handheld type design an isolation of approximately 20dB can be reached with careful placement of the antennas. If such isolation can’t be achieved, e.g. in the case of an integrated GSM/GPS antenna, an additional input filter is needed on the GPS side to block the high energy emitted by the GSM transmitter. Examples of these kinds of filters would be the SAW Filters from Epcos (B9444 or B7839) or Murata.
3.3.8.2 Increasing jamming immunity
Jamming signals come from in-band and out-band frequency sources.
3.3.8.3 In-band jamming
With in-band jamming the signal frequency is very close to the GPS/QZSS band of 1.575 GHz and GLONASS band of 1.602 GHz (see Figure 59). Such jamming signals are typically caused by harmonics from displays, micro­controller, bus systems, etc.
Figure 59: In-band jamming signals
Figure 60: In-band jamming sources
UBX-14054794 Production Information Product handling Page 61 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Measures against in-band jamming include:
Maintaining a good grounding concept in the design Shielding Layout optimization Filtering Placement of the GPS antenna Adding a CDMA, GSM, WCDMA bandpass filter before handset antenna
3.3.8.4 Out-band jamming
Out-band jamming is caused by signal frequencies that are different from the GPS carrier (see Figure 61). The main
sources are wireless communication systems such as GSM, CDMA, WCDMA, WiFi, BT, etc.
Figure 61: Out-band jamming signals
Measures against out-band jamming include maintaining a good grounding concept in the design and adding a SAW or bandpass ceramic filter (as recommend in Section 3.3.6) into the antenna input line to the GPS receiver (see Figure 62).
Figure 62: Measures against in-band jamming
3.3.8.5 GPS and GSM solution with integrated SMT antennas and chip SIM
An example is available on our C16 telematics reference design [12], that combines LEON-G200 GSM/GPRS modem module with NEO-6Q GPS receiver module.
UBX-14054794 Production Information Product handling Page 62 of 85
3.3.9 Recommended parts
Manufacturer
Part ID
Remarks
Parameters to consider
Diode ON Semiconductor
ESD9R3.3ST5G
(3.3.4 C) Standoff Voltage>3.3 V
• Low Capacitance < 0.5 pF
ESD9L3.3ST5G
(3.3.4 C) Standoff Voltage>3.3 V
• Standoff Voltage > Voltage for
active antenna
ESD9L5.0ST5G
(3.3.4 C) Standoff Voltage>5 V
• Low Inductance
SAW
Epcos B9444: B39162-B9444-M410
(3.3.6) 15dBm Max Power Input
B9416: B39162-B9416-K610
(3.3.6) Low insertion loss
B8401: B39162-B8401-P810
GPS and GLONASS
Murata
SAFEA1G57KD0F00
(3.3.6) 1.35x1.05x0.5 mm
SAFZE1G57KA0F90
(3.3.6) 2.5x2.0x1.0 mm
SAFEB1G57KB0F00
(3.3.6) 1.35x1.05x0.6 mm
SAFEA1G57KE0F00
(3.3.6) 1.35x1.05x0.45 mm
•Good wireless band suppression
SAFFB1G58KA0F0A
GPS and GLONASS
High attenuation
SAFEA1G58KA0F00
GPS and GLONASS
High attenuation
CTS
CER0032A
(3.3.6) 4.2x4.0x2.0 mm > 8kV ESD HBM
LNA
Avago
ALM-1106
(3.3.4 A) LNA
pHEMT (GaAS)
ALM-1412
(3.3.6 D) LNA + FBAR Filter
ALM-1712
(3.3.6 D) Filter + LNA + FBAR Filter
ALM-2412
(3.3.4 A) LNA + FBAR Filter
MAXIM
MAX2659ELT+
(3.3.4 A) LNA
SiGe
JRC
NJG1143UA2
LNA
Infineon
BGM1032N16
Filter + LNA
BGM981N11
Filter + LNA + Filter
BGM1052N16
LNA + Filter
Triquint
TQM640002
Filter + LNA + Filter
Inductor
Murata
LQG15HS27NJ02
(3.3.6 F) L, 27 nH
Impedance @ freq GPS > 500
Capacitor
Murata
GRM1555C1E470JZ01
(3.3.6 F) C, 47 pF
Ferrite Bead
Murata
BLM15HD102SN1
(3.3.7) FB
High IZI @ fGSM
Feed thru Capacitor for Signal Murata
NFL18SP157X1A3
Monolithic Type Array Type
Load Capacitance appropriate to Baud rate CL < xxx pF
NFA18SL307V1A45
Feed thru Capacitor
for VCC
Murata
NFM18PC …. NFM21P….
0603 2A 0805 4A
Rs < 0.5
Manufacturer
Order No.
Comments
Inpaq (www.inpaq.com.tw)
GPSGLONASS03D-S3-00-A
25*25*4mm, 2.7 to 3.9 V 6 mA at 3.3V
Taoglas (www.taoglas.com)
AA.160.301111
36*36*6mm, 3 to 5V / 30mA at 5V
Taoglas (www.taoglas.com)
AA.161.301111
36*36*3mm, 1.8 to 5.5V / 10mA at 3V
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Table 26: Recommended parts for ESD/EOS protection
3.3.9.1 Recommended GPS & GLONASS active antenna (A1)
Table 27: Recommend GPS & GLONASS active antenna (A1). If possible, using a 36*36 mm patch antenna is preferred.
UBX-14054794 Production Information Product handling Page 63 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
3.4 Safety precautions
LEA-6 / NEO-6 / MAX-6 modules must be supplied by an external limited power source in compliance with the clause 2.5 of the standard IEC 60950-1. In addition to external limited power source, only separated or Safety Extra-Low Voltage (SELV) circuits are to be connected to the module, including interfaces and antennas.
For more information about SELV circuits, see section 2.2 in Safety standard IEC 60950-1 [15].
UBX-14054794 Production Information Product handling Page 64 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
4 Product testing
4.1 u-blox in-series production test
u-blox focuses on high quality for its products. To achieve a high standard it’s our philosophy to supply fully tested units. Therefore at the end of the production process, every unit is tested. Defective units are analyzed in detail to improve the production quality.
This is achieved with automatic test equipment, which delivers a detailed test report for each unit. The following measurements are done:
Digital self-test (Software Download, verification of FLASH firmware, etc.) Measurement of voltages and currents Measurement of RF characteristics (e.g. C/No)
Figure 63: Automatic Test Equipment for Module Tests
4.2 Test parameters for OEM manufacturer
Because of the testing done by u-blox (with 100% coverage), an OEM manufacturer doesn’t need to repeat firmware tests or measurements of the GPS parameters/characteristics (e.g. TTFF) in their production test.
An OEM manufacturer should focus on:
Overall sensitivity of the device (including antenna, if applicable) Communication to a host controller
UBX-14054794 Production Information Product testing Page 65 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
4.3 System sensitivity test
The best way to test the sensitivity of a GPS device is with the use of a 1-channel GPS simulator. It assures reliable and constant signals at every measurement.
Figure 64: 1-channel GPS simulator
u-blox recommends the following Single-Channel GPS Simulator:
Spirent GSS6100 (GPS) Spirent GSS6300 (GPS/GLONASS)
Spirent Communications Positioning Technology www.spirent.com
4.3.1 Guidelines for sensitivity tests
1. Connect a 1-channel GPS/GLONASS simulator to the OEM product
2. Choose the power level in a way that the “Golden Device” would report a C/No ratio of 38-40 dBHz
3. Power up the DUT (Device Under Test) and allow enough time for the acquisition
4. Read the C/No value from the NMEA GSV or the UBX-NAV-SVINFO message (e.g. with u-center)
5. Compare the results to a “Golden Device” or a u-blox 6 Evaluation Kit.
4.3.2 ‘Go/No go’ tests for integrated devices
The best test is to bring the device to an outdoor position with excellent sky view (HDOP < 3.0). Let the
receiver acquire satellites and compare the signal strength with a “Golden Device”.
As the electro-magnetic field of a redistribution antenna is not homogenous, indoor tests are in most
cases not reliable. These kind of tests may be useful as a ‘go/no go’ test but not for sensitivity
measurements.
4.3.3 Testing LEA-6R designs
When testing the design ensure that no GPS signals are being received or delete the calibration after the
tests. Failure to do so can result in operation errors.
4.3.3.1 Direction signal
This input shall be set once to high level and once to low level. In both states the software parameters are read back with the UBX-NAV-EKFSTATUS. The direction flag shall read forward for a high level at the FWD input and backward for a low level at the FORWARD input.
UBX-14054794 Production Information Product testing Page 66 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
4.3.3.2 Speedpulse signal
A rectangular waveform with 2 kHz frequency shall be fed into the SPEED input. The result can be read back with the UBX-NAV-EKFSTATUS message: Speed Ticks: 1800...2400
4.3.3.3 Gyroscope (rate) input
Do not move the device and check UBX-ESF-MEAS: 2 > Gyro Z: > -2 Quickly turn the device to the right (clockwise), check UBX-ESF-MEAS: Gyro Z: > 50 Quickly turn the device to the left (counterclockwise), check UBX-ESF-MEAS: Gyro Z: < -50
The rate input can only be tested if an A/D converter is connected to LEA-6R.
4.3.3.4 Temperature sensor
The temperature measured by the temperature sensor connected to the LEA-6R shall be read with the UBX-ESF­MEAS message. The measurement tolerance is in the order of about ±5°.
4.3.3.5 Erase calibration
To erase the calibration send a CFG-EKF command with the appropriate clearing flags set.
4.3.4 Testing NEO-6V designs
The NEO-6V ADR algorithm supports a variety of sensors (such as wheel ticks and gyroscope) and receives the sensor data via UBX messages from the application processor. Digital sensor data is available on the vehicle bus. No extra sensors are required for Dead Reckoning functionality. ADR is completely self-calibrating.
For more details on GWT protocol, see u-blox 6 Receiver Description Including Protocol Specification [13] For more details on DWT protocol, contact u-blox. (Contact)
UBX-14054794 Production Information Product testing Page 67 of 85
Appendix
Abbreviation
Definition ANSI
American National Standards Institute
CDMA
Code Division Multiple Access
EMC
Electromagnetic compatibility
EMI
Electromagnetic interference
EOS
Electrical Overstress
EPA
Electrostatic Protective Area
ESD
Electrostatic discharge
GND
Ground
GPS
Global Positioning System
GSM
Global System for Mobile Communications
IEC
International Electrotechnical Commission
PCB
Printed circuit board
A Abbreviations
Table 28: Explanation of abbreviations used
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
B Migration to u-blox-6 receivers
Migrating ANTARIS®4 and u-blox 5 designs to a u-blox 6 receiver module is a fairly straightforward procedure. Nevertheless there are some points to be considered during the migration.
Not all of the functionalities available with ANTARIS®4 are supported by u-blox 6. These include:
RTCM is supported in FW7.0x but not in ROM6.02 and FW6.02 versions. UTM (Universal Transverse Mercator Projection)
B.1 Checklist for migration
Have you chosen the optimal module?
For best GPS performance (i.e. better sensitivity level and acquisition time) select a LEA-6H, LEA-6S, NEO-
6Q or NEO-6G for the advantage of TCXO performance.
If TCXO performance is not required, choose a LEA-6A or NEO-6M. For active antenna applications, choose a LEA-6H, LEA-6S or LEA-6A, since an antenna supply circuit is
already built in or see section 1.4 and section 2.6.
For the ability to upgrade the firmware, choose a LEA-6H. For precision timing choose a LEA-6T or NEO-6T For dead reckoning choose a LEA-6R
UBX-14054794 Production Information Appendix Page 68 of 85
u-blox 6
NEO-4S
NEO
NEO-6M/Q
LEA
Flash memory, Antenna Supervisor
LEA-6H
LEA-6A/S
ROM, Antenna Supervisor
LEA-4T
LEA-4R
LEA-6T
LEA-6R
Precision Timing
Dead Reckoning
NEO-5D/G NEO-6G
ROM, 3.0 V
ROM, 1.8 V
ROM
u-blox 5
ANTARI S 4
NEO-5M/Q
LEA-5T
LEA-4P/H
LEA-5H
LEA-4A/S
LEA-5A/S
LEA-4M LEA-5M/Q
Figure 65: u-blox 6 module migration made easy
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Check u-blox 6 Hardware Requirements:
Check the battery power to supply the battery backup pin, since u-blox 6 draws higher current in
comparison to ANTARIS 4 receivers.
Compare the u-blox 6 module peak current consumption (~70 mA) with the specification of the power
supply.
u-blox 6 modules can be operated in three different modes: Max. Performance mode, Eco mode or
Power Save mode.
NEO-6Q, NEO-6G and NEO-6M feature a Configuration Pin that allows switching between the power
modes: Max Performance mode and Eco mode.
For more information on u-blox6 Power supply specifications and power modes, see the LEA-6 Data
Sheet [1] and NEO-6 Data Sheet [3].
If you use an active antenna supervisor circuitry to detect open conditions, you need to verify resistor
reference recommendations in our integration manuals.
See section 3.3 EOS/ESD/EMI Precautions. If you use the USB interface, the external series resistor values in USB_DM and USB_DP line should be
adjusted, see section 1.6.2.
Check u-blox 6 Software Requirements:
Not all of the functionalities available with ANTARIS 4 are supported by u-blox 6 Firmware version 6.02.
These include:
o FixNow Mode: Low power modes are supported via mapping to the Power Save mode of
FW 7.0x or ROM 6.02. For migration of FXN functionalities consult the u-blox 6 Firmware
Version 7.0x Release Note [8], respectively the u-blox 6 Receiver Description including Protocol Specification [4]
o No UTM (Universal Transverse Mercator Projection). o No RTCM protocol for DGPS support (ROM6.02, FW6.02). o Raw Data support with LEA-6T only.
Check B.2 Software migration
UBX-14054794 Production Information Appendix Page 69 of 85
B.2 Software migration
ANTARIS 4
u-blox6
Remarks
UBX-CFG-NAV2
UBX-CFG-NAV5
UBX-CFG-NAV2 has been replaced by UBX-CFG-NAV5. The new message has additional features.
The default dynamic platform is “Portable”. This platform is rather generic
and allows the receiver to be operated in a wide dynamic range covering pedestrians, cars as well as commercial aircrafts. Automotive applications such as first-mount navigation systems may better utilize the “Automotive” platform, which is better geared to the dynamics of land vehicles but is only of limited use in airborne and high-dynamics environments. UBX-CFG-NAV5 does not support following features: Almanac Navigation Navigation Input filters UBX-CFG-NAV5 has a message length of 36 Bytes (40 Bytes for UBX-CFG­NAV2) UBX-CFG-NAV5 FixMode is set by default to “Auto 3D/2D” as for ANTARIS4. Check the u-blox 6 Receiver Description including Protocol Specification [4]. if this mode needs to be changed.
UBX-CFG-MSG
UBX-CFG-MSG
No support for multiple configurations in one UBX-CFG-MSG command
UBX-CFG-RXM
N/A
Contrary to ANTARIS 4, u-blox6 does not need selecting GPS acquisition sensitivity mode (Fast, Normal, High Sens and Auto mode) since the acquisition engine is powerful enough to search all satellite in one go. FixNow mode is not available anymore. Contact your local u-blox support team should you need further information.
PUBX,01
N/A
Other UBX or NMEA messages can be used to replace this message
UBX-NAV-POSUTM
N/A
UBX-CFG-TP
UBX-CFG-TP
u-blox 6 maintains this message for backwards compatibility only. For new designs use UBX-CFG-TP5.
UBX-CFG-TP5
This is a new u-blox 6 message, for information see u-blox 6 Receiver Description including Protocol Specification [4].
UBX-CFG-ANT
UBX-CFG-ANT
Antenna Open Circuit Detection: The default setting for LEA-4S and LEA-4A
was “enabled”. With all LEA-6 modules the default setting is “disabled”.
Automatic Short Circuit Recovery: With ANTARIS 4 this was “disabled” by
default. With u-blox 6 the default setting is “enabled”.
UBX-CFG-RATE
UBX-CFG- RATE
Set to 1 with u-blox 6
UBX-CFG-TMODE
UBX-CFG-TMODE
With u-blox 6 FW 6.02 and above it is no longer necessary to configure the number of satellites in UBX-CFG-NAV to 1 to enable the timing mode. This is performed automatically.
UBX-MON-HW
UBX-MON-HW
Message length has changed as the number of pins is different with u-blox6.
0s Leap second by default
FW 6.02 and FW7.0x: 15 s Leap second by default
UBX-CFG-RATE
UBX-CFG-RATE
Disable SBAS services to achieve 4Hz navigation
UBX-NAV- EKFSTATUS
UBX-NAV- EKFSTATUS
This message is only provided for backwards compatibility and should not be utilized for future designs. Instead, the messages ESF-STATUS and ESF-MEAS should be used. For u-blox 6 firmware the gyroscope value (gyroMean) is only output if the gyroscope is used in the navigation solution. This message is only available on LEA-4R and LEA-6R GPS Receivers.
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
B.2.1 Software migration from ANTARIS
4 or u-blox 5 to a u-blox 6 GPS receiver
Software migration from ANTARIS 4 or u-blox 5 to a u-blox 6 GPS receiver is a straightforward procedure. Nevertheless there are some differences to be considered with u-blox 5 firmware version 5.00. Like its ANTARIS 4 and u-blox 5 predecessors, u-blox 6 technology supports UBX and NMEA protocol messages. Backward compatibility has been maintained as far as possible. New messages have been introduced for new functions. Only minor differences have to be expected in the UBX-NAV and UBX-AID classes of the UBX protocol and for the standard NMEA messages such as GGA, GLL, GSA, GSV, RMC, VTG and ZDA.
Table 29: Main differences between ANTARIS 4 and u-blox 6 software for migration
UBX-14054794 Production Information Appendix Page 70 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
The default NMEA message set for u-blox 6 is GGA, GLL, GSA, GSV, RMC and VTG. Contrary to ANTARIS 4, ZDA is disabled by default.
Firmware update is supported by all of these interfaces. The firmware update mechanism of u-blox 6 is more sophisticated than with ANTARIS 4. It is now based on UBX protocol messages. Customers, who implemented firmware download in their application processor, will need to replace the software. A template is available from your u-blox support team.
In case migrating from LEA-4T or LEA-5T to LEA-6T-0, the command to save the configuration (UBX-CGF-CFG) changes. This is because in LEA-6T-0 a serial Flash at the SPI is used instead of the parallel Flash (LEA-4T and LEA­5T). So for the LEA-4T, LEA-5T, LEA-6T-1 and LEA-6T-2 the target to save the configuration has to be set to “devFlash”, but for the LEA-6T-0 it has to be set to “devSpiFlash”.
Please refer to the u-blox 6 Receiver Description including Protocol Specification [4] for more information. This document is available on the u-blox website.
B.2.2 Software migration from 6.02 to 7.03
Timing Survey-in Mode: Customers using survey-in should review the changes in the accuracy limit parameters in CFG-TMODE and CFG-
TMODE2 in FW 7.03, as described in the u-blox 6 Firmware Version 7.0x Release Note [8], and the u-blox 6 Receiver Description including Protocol Specification [4]
B.2.3 Software migration from 7.03 to FW1.00 GLONASS, GPS & QZSS
When migrating from 7.03 to FW1.00 GLONASS, GPS & QZSS consult the GPS/GLONASS/QZSS Firmware 1.00 for u-blox 6 Release Note [7], and the u-blox 6 Receiver Description including Protocol Specification (GPS/GLONASS/QZSS) [5].
B.3 Hardware Migration
B.3.1 Hardware Migration: ANTARIS 4 u-blox 6
u-blox 6 modules have been designed with backward compatibility in mind but some minor differences were unavoidable. These minor differences will however not be relevant for the majority of the ANTARIS 4 designs.
Good performance requires a clean and stable power supply with minimal ripple. Care needs to be exercised in selecting a strategy to achieve this. Avoid placing any resistance on the Vcc line. For better performance, use an LDO to provide a clean supply at Vcc and consider the following:
Special attention needs to be paid to the power supply requirements. (currents & backup current see data
sheet for further details)
Wide power lines or even power planes are preferred. Place LDO near the module. Avoid resistive components in the power line (e.g. narrow power lines, coils, resistors, etc.).
Placing a filter or other source of resistance at Vcc can create significantly longer acquisition
times.
B.3.2 Hardware Migration: u-blox 5 u-blox 6
Check the pins RxD1 and EXTINT0 regarding the input voltage threshold. Serial termination resistors: Recommendation has changed from 27 to 22 . See section 1.6.2.1. For more information see the LEA-6 Data Sheet [1] and LEA-5 Data Sheet [10].
UBX-14054794 Production Information Appendix Page 71 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Pin
LEA-4H/LEA-4P/LEA-4T
LEA-6H/LEA-6T
Remarks for Migration
Pin Name
Typical Assignment
Pin Name
Typical Assignment
1
Reserved
VDDIO level I/O; not connected
SDA2
NC 2
Reserved
VDDIO level I/O; not connected
SCL2
NC
3
TXD1
VDDIO level I/O
TxD1
Output
4 RXD1
VDDIO level I/O
RxD1
Input
Leave open if not used.
5
VDDIO
1.65 – 3.60 V
NC
Connect to VCC
Can be left open, but connection to VCC is recommended for compatibility reason. With LEA­6H the I/O voltage is always VCC.
6
VCC
2.70 3.30 V
VCC
2.70 – 3.60 V
Extended power supply range, higher peak supply current.
7
GND
GND
GND
GND
No difference
8
VDD18OUT
NC
VCC_OUT
NC
Internally connected to VCC, if you have circuitry connected to this pin, check if it withstands the VCC voltage.
9
Reserved
NC
Reserved
NC
10
RESET_N
1.8 V
RESET_N
NC
Input only, do not drive high. Internal pull up to VCC.
11
V_BAT
1.50 3.6 V
V_BCKP
1.4 – 3.6 V
Wider voltage range but needs more current. Check your backup supply, regarding the higher consumption.
12
BOOT_INT
NC
Reserved
NC
Do not drive low.
13
GND
GND
GND
GND
No difference
14
GND
GND
GND
GND
No difference
15
GND
GND
GND
GND
No difference
16
RF_IN
RF_IN
RF_IN
RF_IN
No difference
17
GND
GND
GND
GND
No difference
18
VCC_RF
VCC 0.1 V
VCC_RF
VCC – 0.1 V
No difference
19
V_ANT
3.0 V 5.0 V
V_ANT
2.7 V -5.5 V
wider range
20
AADET_N
NC
AADET_N
NC
check resistor R5 in Active antenna supervisor Figure 47
21
EXTINT1
NC
NC
NC
22
Reserved
NC
NC
NC
23
Reserved
NC
NC
NC
24
VDDUSB
Connected to GND or VDD_USB
VDDUSB
Connected to GND or VDD_USB
Do not leave open. (VDD_USB is 3.3V regulated power supply from VBUS.)
25
USB_DM
NC
USB_DM
NC
New serial termination resistors recommended: 22
26
USB_DP
NC
USB_DP
NC
27
EXTINT0
NC
EXTINT0
NC
28
TIMEPULSE
VDDIO level I/O
TIMEPULSE
Output
B.4 Migration of LEA modules
B.4.1 Migration from LEA-4 to LEA-6
See also the migration Table in the u-blox5 Hardware Integration Manual. For u-blox6 the Input Voltage thresholds on the pins RXD1 and EXTINT0 have changed. The Safeboot functionality is inverted compared to Antaris receivers. VCC_OUT is now VCC and not 1.8 V as on Antaris Modules. Also check your power supply requirements with the datasheet (for VCC and VBCKP).
Table 30: Pin-out comparison LEA-4H/LEA-4P/LEA-4T vs. LEA-6H/LEA-6T
UBX-14054794 Production Information Appendix Page 72 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Pin
LEA-4A/LEA-4S
LEA-6A/LEA-6S
Remarks for Migration
Pin Name
Typical Assignment
Pin Name
Typical Assignment
1
TxD2
3.0 V out
SDA2
NC
2
RxD2
1.8 5.0 V
SCL2
NC
3
TxD1
3.0 V out
TxD1
Output
4 RxD1
1.8 – 5.0 V in
RxD1
Input
Leave open if not used. Max. 5 V
5
VDDIO
VCC
NC
Connect to VCC
Leave open for only LEA-6x design. Connect to VCC for backward compatibility to LEA-5x.
6
VCC
2.70 3.30 V
VCC
2.70 – 3.60 V
Extended power supply range, higher peak supply current.
7
GND
GND
GND
GND
No difference
8
VDD18OUT
1.8 V out
VCC_OUT
NC
Internally connected to VCC, if you have circuitry connected to this pin, check if it withstands the VCC voltage.
9
GPSMODE6
NC (GND or VDD18OUT)
CFG_COM1
NC 10
RESET_N
ACTIVE LOW
RESET_N
NC
Input only, do not drive high. Internal pull up to VCC.
11
V_BAT
1.50 3.6 V
V_BCKP
1.4 – 3.6 V
Wider voltage range but needs more current. Check your backup supply, regarding the higher consumption.
12
BOOT_INT
NC
Reserved
NC
Do not drive low.
13
GND
GND
GND
GND
No difference
14
GND
GND
GND
GND
No difference
15
GND
GND
GND
GND
No difference
16
RF_IN
RF_IN
RF_IN
RF_IN
No difference
17
GND
GND
GND
GND
No difference
18
VCC_RF
VCC 0.1 V
VCC_RF
VCC – 0.1V
No difference
19
V_ANT
3.0 V 5.0 V
V_ANT
2.7V -5.5V
wider range
20
AADET_N
NC (1.8 to 5.0 V)
AADET_N
NC
check resistor R5 in Active antenna supervisor Figure 47
21
GPSMODE5
NC (GND or VDD18OUT)
NC
NC
22
GPSMODE2 GPSMODE2 3
NC (GND or VDD18OUT)
NC
NC
23
GPSMODE7
NC (1.8 to 5.0 V)
NC
NC
24
VDDUSB
3.0 3.6V/ GND
VDDUSB
Connected to GND or VDD_USB
Do not leave open. (VDD_USB is 3.3 V regulated power supply from VBUS.)
25
USB_DM
VDDUSB I/O
USB_DM
NC
New serial termination resistors recommended: 22
26
USB_DP
VDDUSB I/O
USB_DP
NC
27
EXTINT0
NC (1.8 to 5.0 V)
EXTINT0
NC
Max. 5 V
28
TIMEPULSE
VDDIO level output
TIMEPULSE
Output
Table 31: Pin-out comparison LEA-4A/LEA-4S vs. LEA-6A/LEA-6S
B.4.2 Migration of LEA-4R designs to LEA-6R
LEA-6R module has been designed with backward compatibility in mind, but some incompatibilities were unavoidable. These minor differences will, however, not be relevant for the majority of ANTARIS 4 designs.
Please check in your design the following points carefully to assure a safe migration:
For u-blox 6 the Input Voltage thresholds on the pins RxD1 and Extint0 have changed. VCC_OUT is now VCC and not 1.8 V as on Antaris Modules. Pin5 is now NC instead of VDDIO. All I/O Voltages are referenced to VCC. Check your power supply requirements with the datasheet (for VCC and VBCKP), u-blox 6 has a higher
peak current and backup current than ANTARIS 4 modules
UBX-14054794 Production Information Appendix Page 73 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Pin
NEO-4S
NEO-6Q/NEO-6M
Remarks for Migration
Pin Name
Typ. Assignment
Pin Name
Typ. Assignment
1 BOOT_INT
NC
Reserved
NC
Do not drive low.
2
SELECT
VDDIO level I/O; not connected
SS_N
NC
3
TIMEPULSE
VDDIO level I/O
TIMEPULSE
Output
4
EXTINT0
NC
EXTINT0
NC
5
USB_DM
NC
USB_DM
NC
New serial termination resistors recommended: 22 Ohms
6
USB_DP
NC
USB_DP
NC
7
VDDUSB
Connected to GND or VDD_USB
VDDUSB
Connected to GND or VDD_USB
Do not leave open. (VDD_USB is 3.3V regulated power supply from VBUS.)
8
Reserved
NC
Reserved
NC
Pins 8 and 9 must be connected.
9
VCC_RF
VCC-0.1 V
VCC_RF
VCC-0.1 V
No difference
10
GND
GND
GND
GND
No difference
11
RF_IN
RF_IN
RF_IN
RF_IN
No difference
12
GND
GND
GND
GND
No difference
13
GND
GND
GND
GND
No difference
14
MOSI
NC
MOSI/CFG_COM0
NC
The function of the CFG pin has changed. See section 2.2.3.1 for more details.
15
MISO
NC
MISO/CFG_COM1
NC
16
SCK/ CFG_USB
NC
CFG_GPS0 /SCK
NC
Leave open if not used. The function of the CFG pin has changed. See section 2.2.3.1 for more details.
17
NCS
NC
Reserved
NC
No difference
18
Reserved
NC
SDA2
NC
19
Reserved
NC
SCL2
NC
20
TXD1
VDDIO level I/O
TxD1
Output
21
RXD1
VDDIO level I/O
RxD1
Input
Leave open if not used.
22
V_BAT
1.5-3.6 V
V_BCKP
1.4-3.6 V
Wider voltage range but needs more current. Check your backup supply, regarding the higher consumption.
23
VCC
2.7-3.3 V
VCC
2.7-3.6 V
Higher peak supply current
24
GND
GND
GND
GND
No difference
The SPI is now running at 870 kHz (against 460 kHz on ANTARIS 4), check that your design supports the
signal path
If you do a redesign, ensure the signal paths of the SPI to support a bandwidth of 4 MHz.
B.4.3 Migration from LEA-5 to LEA-6
For u-blox6 only the Input Voltage thresholds on the pins RXD1 and EXTINT0 have changed. Be aware, that with u-blox 6 there is no LEA anymore, which supports SPI interface. For SPI consider NEO-6 form
factor.
B.5 Migration of NEO modules
B.5.1 Migration from NEO-4S to NEO-6
For u-blox6 the Input Voltage thresholds on the pins RXD1 and EXTINT0 have changed. The Safeboot functionality is inverted compared to Antaris receivers. Also check your power supply requirements with the datasheet (for VCC and VBCKP). Also check the setting of the configuration pins. The pin-outs of NEO-4S and NEO-6M/NEO-6Q differ slightly. Table 32 compares the modules and highlights the
differences to be considered.
Table 32: Pin-out comparison NEO-4S vs. NEO-6
UBX-14054794 Production Information Appendix Page 74 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
B.5.2 Migration from NEO-5 to NEO-6
For u-blox 6 only the Input Voltage thresholds on the pins RXD1 and EXTINT0 have changed. Also check the setting of the configuration pins. Serial termination resistors: Recommendation has changed from 27 to 22 . See section 1.6.2.1.
UBX-14054794 Production Information Appendix Page 75 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
DDC Device A DDC Device B
V
DD
SDA
SCL
GND
RpRp
SDA in
SDA out
SCL in
SDA out
SDA in
SDA out
SCL in
SDA out
Rp
Rp
C Interface Backgrounder
C.1 DDC Interface
Two wires, serial data (SDA) and serial clock (SCL), carry information between the devices connected to the bus. These lines are connected to all devices on the DDC. SCL is used to synchronize data transfers and SDA is the data line. Both SCL and SDA lines are open drain drivers. This means that DDC devices can only drive them low or leave them open. The pull-up resistor (Rp) pulls the line up to VDD if no DDC device is pulling it down to GND. If the pull-up resistors are missing, the SCL and SDA lines are undefined and the DDC bus will not work. For most DDC systems the low and high input voltage level thresholds of SDA and SCL depend on VDD. See the LEA-6 Data Sheet [1] or NEO-6 Data Sheet [3] for the applicable voltage levels.
Figure 66: A simple DDC connection
The signal shape and the maximum rate in which data can be transferred over SDA and SCL is limited by the values of Rp and the wire and I/O capacitance (Cp). Long wires and a large number of devices on the bus increase Cp, therefore DDC connections should always be as short as possible. The resistance of the pull-up resistors and the capacitance of the wires should be carefully chosen.
Figure 67: DDC block diagram
C.1.1 Addresses, roles and modes
Each device connected to a DDC is identified by a unique 7-bit address (e.g. whether it’s a microcontroller, EEPROM or D/A Converter, etc.) and can operate as either a transmitter or receiver, depending on the function
UBX-14054794 Production Information Appendix Page 76 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Transmit
Receive Master: sends the clock and addresses slaves
Sends data to slave
Receives data from slave
Slave: receives the clock and address
Sends data to master
Receives data from master
of the device. The default DDC address for u-blox GPS receivers is set to 0x42. Setting the mode field in the CFG-PRT message for DDC accordingly can change this address.
The first byte sent is comprised of the address field and R/W bit. Hence the byte seen on the bus 0x42 is
shifted by 1 to the left plus R/W bit thus being 0x84 or 0x85 if analyzed by scope or protocol analyzer.
In addition to transmitters and receivers, devices can also be considered as masters or slaves when performing data transfers. A master is the device which initiates a data transfer on the bus and generates the clock signals to permit that transfer. At that time, any device addressed is considered a slave. The DDC-bus is a multi-master bus, i.e. multiple devices are capable of controlling the bus. Such architecture is not permanent and depends on the direction of data transfer at any given point in time. A master device not only allocates the time slots when slaves can respond but also enables and synchronizes designated slaves to physically access the bus by driving the clock. Although multiple nodes can assume the role of a master, only one at any time is permitted to do so. Thus, when one node acts as master, all other nodes act as slaves. Table 33 shows the possible roles and modes for devices connected to a DDC bus.
Table 33: Possible roles and modes of devices connected to DDC bus
u-blox 6 GPS receivers normally run in the slave mode. There is an exception when an external EEPROM is attached. In that case, the receiver attempts to establish presence of such a non-volatile memory component by writing and reading from a specific location. If EEPROM is present (assumed to be located at a fixed address 0xA0), the receiver assumes the role of a master on the bus and never changes role to slave until the following start-up (subject to EEPROM presence). This process takes place only once at the start-up, i.e. the receiver’s role cannot be changed during the normal operation afterward. This model is an exception and should not be
implemented if there are other participants on the bus contending for the bus control (µC / CPU, etc.). As a slave on the bus, the u-blox 6 GPS receiver cannot initiate the data transfers. The master node has the
exclusive right and responsibility to generate the data clock, therefore the slave nodes need not be configured to use the same baud rate. For the purpose of simplification, if not specified differently, SLAVE denotes the u-blox 6
GPS receiver while MASTER denotes the external device (CPU, μC) controlling the DDC bus by driving the SCL line.
u-blox GPS receivers support Standard-Mode I2C-bus specification with 7-bit addressing and a data
transfer rate up to 100 kBit/s and a SCL clock frequency up to 100 kHz.
C.1.2 DDC troubleshooting
Consider the following questions when implementing I2C in designs:
Is there a stable supply voltage Vdd? Often, external I
provided with Vdd.
Are appropriate termination resistances attached between SDA, SCL and Vdd? The voltage level on SDA and
SCL must be Vdd as long as the bus is idle and drop near GND if shorted to GND. [Note: Very few I2C masters exist which drive SCL high and low, i.e. the SCL line is not open-drain. In this case, a termination resistor is not needed and SCL cannot be pulled low. These masters will not work together with other masters (as they have no multi-master support) and may not be used with devices which stretch SCL during transfers.]
Are SDA and SCL mixed up? This may accidentally happen e.g. when connecting I
connectors.
Do all I Do all I If more than one I
2
C devices support the I2C supply voltage used on the bus?
2
C devices support the maximum SCL clock rate used on the bus?
2
C master is connected to the bus: do all masters provide multi-master support?
2
C devices (like I2C masters or monitors) must be
2
C buses with cables or
UBX-14054794 Production Information Appendix Page 77 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
SPI Slave
MISO
MOSI
SCK
SCS
Are the high and low level voltages on SDA and SCL correct during I
2
C transfers? The I2C standard defines the low level threshold with 0.3 Vcc, the high level threshold with 0.7 Vcc. Modifying the termination resistance Rp, the serial resistors Rs or lowering the SCL clock rate could help here.
Are there spikes or noise on SDA, SCL or even Vdd? They may result from interferences from other
components or because the capacitances Cp and/or Cc are too high. The effects can often be reduced by using shorter interconnections.
For more information about DDC implementation refer to the u-blox 6 Receiver Description including
Protocol Specification [4].
C.2 SPI Interface
C.2.1 SPI basics
Devices communicate in master/slave mode where the master device provides the clock signal (SCK) and determines the state of the chip select (SCS/SS_N) lines, i.e. it activates the slave it wants to communicate with. The slave device receives the clock and chip select from the master. Multiple slave devices are allowed with individual slave select (chip select) lines. This means that there is one master, while the number of slaves is only limited by the number of chip selects. In addition to reliability and relatively high speed (with respect to the conventional UART), the SPI interface is easy to use and requires no special handling or complex communication stack implementation in the software.
The standard configuration for a slave device (see Figure 68) uses two control and two data lines. These are identified as follows:
SCS Slave Chip Select (control: output from master, usually active low) SCK Serial Clock (control: output from master) MOSI Master Output, Slave Input (data: output from master) MISO Master Input, Slave Output (data: output from slave)
Alternative naming conventions are also widely used. Confirm the pin/signal naming with specific
components used.
Figure 68: SPI slave
SPI always follows the basic principle of a shift register. During an SPI transfer, command codes and data values are simultaneously transmitted (shifted out serially) and received (shifted in serially). The data is entered into a shift register and then internally available for parallel processing. The length of the shift registers is not fixed, but can vary from device to device. Normally the shift registers are 8Bit or integral multiples thereof. However, they can also have an odd number of bits. For example two cascaded 9Bit EEPROMs can store 18Bit data.
When an SPI transfer occurs, an 8-bit character is shifted out one data pin while a different 8-bit character is simultaneously shifted in a second data pin. Another way to view this transfer is that an 8-bit shift register in the master and another 8-bit shift register in the slave are connected as a circular 16-bit shift register. When a transfer occurs, this distributed shift register is shifted eight bit positions; thus, the characters in the master and slave are effectively exchanged.
The serial clock (SCK) line synchronizes shifting and sampling of the information on the two serial data lines (MOSI and MISO). The chip select (SCS/SS_N) line allows individual selection of a slave SPI device. If an SPI slave
UBX-14054794 Production Information Appendix Page 78 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
SPI Master
SPI Slave
0
Chip Select
MOSI
SCK
Data Input
MISO
SPI Slave
1
SPI Slave
2
SCS
0
SCS
1
SCS
2
Clock
Data Output
MOSI
MOSI
MOSI
SS_N
SS_N
SS_N
SCK
SCK
SCK
MISO
MISO
MISO
device is not selected (i.e. its chip select is not activated), its data output enters a high-impedance state (hi-Z) and does not interfere with SPI bus activities.
The data output MISO functions as the data return signal from the slave to the master. Figure 69 shows a typical block diagram for an SPI master with several slaves. Here, the SCK and MOSI data lines
are shared by all of the slaves. Also the MISO data lines are linked together and led back to the master. Only the chip selects are separately brought to each SPI device.
Figure 69: Master with independent slaves
SPI allows multiple microcontrollers to be linked together. These can be configured according to single or multiple master protocols. In the first variant the microcontroller(s) designated as slave(s) behave like a normal peripheral device. The second variant allows for several masters and allows each microprocessor the possibility to take the role of master and to address another microprocessor. In this case one microcontroller must permanently provide the clock signal.
There are two SPI system errors. The first occurs if several SPI devices want to become master at the same time. The other is a collision error that occurs for example when SPI devices work with different polarities.
Systems involving multiple microcontrollers are beyond the scope of this document.
Cascading slave peripherals is not supported.
Four I/O pin signals are associated with SPI transfers: the SCK, the MISO data line, the MOSI data line, and the active low SCS/SS_N pin. In the unselected state the MISO lines are hi-Z and therefore inactive. The master decides with which peripheral device it wants to communicate. The clock line SCK provides synchronization for data communication and is brought to the device whether or not it is selected.
UBX-14054794 Production Information Appendix Page 79 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
The majority of SPI devices provide all four of these lines. Sometimes MOSI and MISO are multiplexed, or else one is missing. A peripheral device, which must not or cannot be configured, requires no input line but only a data output. As soon as it gets selected it starts sending data. In some ADCs therefore the MOSI line is missing. Some devices have no data output (e.g. LCD controllers which can be configured, but cannot send data or status messages).
The following rules should answer the most common questions concerning these signals:
SCK: The SCK pin is an output when the SPI is configured as a master and an input when the SPI is
configured as a slave. When the SPI is configured as a master, the SCK signal is derived from the internal bus clock. When the master initiates a transfer, eight clock cycles are automatically generated on the SCK pin. When the SPI is configured as a slave, the SCK pin is an input, and the clock signal from the master synchronizes the data transfer between the master and slave devices. Slave devices ignore the SCK signal unless the slave select pin is active low. In both the master and slave SPI devices, data is shifted on one edge of the SCK signal and is sampled on the opposite edge where data is stable. Edge polarity is determined by the SPI transfer protocol.
MISO/MOSI: The MISO and MOSI data pins are used for transmitting and receiving serial data. When the
SPI is configured as a master, MISO is the master data input line, and MOSI is the master data output line. When the SPI is configured as a slave, these pins reverse roles.
SCS/SS_N: In master mode, the SCS output(s) select external slaves (e.g. SCS1_N, SCS2_N). In slave mode,
SS_N is the slave select input. The chip select pin behaves differently on master and slave devices. On a slave device, this pin is used to enable the SPI slave for a transfer. If the SS_N pin of a slave is inactive (high), the device ignores SCK clocks and keeps the MISO output pin in the high-impedance state. On a master device, the SCS pin can serve as a general-purpose output not affecting the SPI.
UBX-14054794 Production Information Appendix Page 80 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
P
60
Find a place with open sky view e.g. a big parking site
Start GPS and stand still for 90 seconds until valid position is calculated
Drive straight route for 500m, at least 40 km/h
Drive curves and straight segments for ca. 5 minutes with good visibility in any order
Exeed 60 km/h for at least 10 sec
Make at least two sharp left turns (90 deg or more)
Make at least two sharp right turns (90 deg or more)
Collect data of active temperature compensation
Phase I
Phase II
Phase III
Phase IV
Initial Calibration
Ongoing Fine
Calibration
D DR calibration
D.1 Constraints
The calibration of the DR sensors is a transparent and continuously ongoing process during periods of good GPS reception:
Gyroscope Bias Voltage level of the gyroscope while driving a straight route or not
moving
Gyroscope Scale Factor Adjusted while in left and right turns; gyro sensitivity Speed Pulse Scale Factor Used to calibrate odometer pulse frequency to GPS speed over ground Temperature Compensation The gyroscope is a temperature-dependent device that requires
temperature compensation
When a new GPS receiver is installed in a vehicle, the accuracy is only moderately good until sufficient calibration data has been collected, e.g. during a first drive. With time, continuous calibration results in continuous improvement of dead reckoning accuracy. Small discontinuities, like deviating wheel diameters after exchanging tires (summer vs. snow tires) or aging of the sensors, will be balanced out by ongoing automatic calibration.
Calibration parameters must be reset, if
a DR module is transferred to a different vehicle and/or a different gyroscope is connected the sensor integrity check has reported any failure from the sensors and set itself into GPS only mode
Calibration can be reset with UBX message UBX – CFG (Config) – EKF (Extended Kalman Filter).
D.2 Initial calibration drive
For optimum navigation performance the system needs some learning time and distance for calibrating the various sensors inputs. The following driving directions are recommended to achieve an efficient calibration so dead reckoning yields high accuracy after the shortest possible period of time.
Figure 70: Initial DR Calibration Drive
The mentioned distances and durations are typical values, a better indication is the sensor calibration status given in UBX – ESF (External Sensor Fusion) – STATUS (Status). The status values indicate which phase of the initial calibration the receiver is in (calibrating, coarse calibration, fine calibration). In Phase IV good DR
UBX-14054794 Production Information Appendix Page 81 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
performance can already be expected, as all sensors are calibrated. Still further fine calibration will be ongoing with good GPS reception and, if a temperature sensor is available, the temperature compensation table will be filled. Gyro offset values are measured as soon as the car stops for more than 3 seconds and are stored in the temperature compensation table to further increase the performance.
The above instructions result in a calibration status within the shortest period of time. Should traffic, road
and regulatory conditions not allow such a calibration drive, the time until optimum calibration will increase. However navigation results are already satisfactory after a relatively short driving distance and time.
The above instructions shall not be made a rule towards any end user. They shall only be
applied in a testing environment where sufficient care is taken that these driving instructions can be carried out without creating any risk of accidents or violation of regulations.
Consequences of a bad/wrong calibration procedure
u-blox SFDR Technology needs well-calibrated sensors to have optimal performance. A poorly calibrated system will report wrong positions and headings during GPS loss. Also the performance is degraded during good GPS performance, as the position output with good GPS performance will be combined with the poor data from the sensors.
As long as the miscalibration is minor (e.g. change of tires from summer to winter tires), the system will recover itself. If the miscalibration leads to a ‘sensor integrity check error’ (the receiver reports GPS only solutions), a reset of the calibration data and new initial calibration is required.
UBX-14054794 Production Information Appendix Page 82 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
Related documents
[1] LEA-6 Data Sheet, Docu. No GPS.G6-HW-09004 [2] LEA-6-N Data Sheet, Docu. No GPS.G6-HW-12004 [3] NEO-6 Data Sheet, Docu. No GPS.G6-HW-09005 [4] u-blox 6 Receiver Description including Protocol Specification, Docu. No GPS.G6-SW-10018 [5] u-blox 6 Receiver Description including Protocol Specification (GPS/GLONASS/QZSS),
Docu. No GPS.G6-SW-10018-E. To obtain this document, contact your nearest u-blox sales rep.
[6] GPS Antenna Application Note, Docu. No GPS-X-08014 [7] GPS/GLONASS/QZSS Firmware 1.00 for u-blox 6 Release Note, Docu. No GPS.G6-SW-12002 [8] u-blox 6 Firmware Version 7.0x Release Note, Docu. No GPS.G6-SW-10024 [9] u-blox 6 Firmware Version 6.02 Release Note, Docu. No GPS.G6-SW-10003 [10] LEA-5 Data Sheet, Docu. No GPS.G5-MS5-07026 [11] MAX-6 Data Sheet, Docu. No GPS.G6-HW-10106 [12] C26 telematics reference design [13] u-blox 6 Receiver Description Including Protocol Specification (NDA version),
Docu. No GPS.G6-SW-10019. This document requires an NDA. For more information or to obtain this document contact your nearest u-blox sales representative.
[14] GPS Implementation Application Note, Docu No GSM.G1-CS-09007 [15] Information technology equipment – Safety Standard IEC 60950-1
https://webstore.iec.ch/publication/4024
Unless otherwise stated, all these documents are available on our homepage (http://www.u-blox.com).
Additional information is available in the FAQ section of our website
(http://www.u-blox.com/en/faq.html).
For regular updates to u-blox documentation and to receive product change notifications please contact
our local support.
UBX-14054794 Production Information Related documents Page 83 of 85
Revision
Date
Name
Status / Comments
-
March 24, 2010
tgri
Initial release
A
July 20, 2010
mdur
Preliminary; updated 1.6.3 DDC, 1.7.1 RESET_N, 1.7.4 Config Pins, 2.1.1 Layout, 3.2 Soldering
B
Dec. 22, 2010
jfur
new: Integration LEA-6R (1.2), FW7, Data ready indicator (1.7.6), Second time pulse for LEA-6T (1.7.5), Figure 41 and Figure 46, External active antenna supervisor NEO-6 (2.6.6), D DR calibration updated: Rework (3.2.8), Recommended parts (3.3.9), RTCM (B), Migration of LEA-4R designs to LEA-6R (B.4.2), Checklist (2.1), 2.2.1 LEA-6 passive antenna design, 2.3.1 Passive antenna design (NEO-6)
C
Feb. 3, 2011
jfur
MAX-6x integration, External active antenna supervisor, ANTOFF, External active antenna control (NEO-6), GPS antenna placement for LEA-6R
D
May 18, 2011
jfur
Repeated Reflow Soldering updated (3.2.5), Soldering u-blox 6 modules in a leaded process removed, updated for FW 7.03/DR2.0, LEA-6T-1 integration
E
Aug. 8, 2011
jfur
LEA-6x / NEO-6x updated for FW 7.03. Section added: 1.7.8 LEA-6T-0 antenna supervision signals. Section 1.6.1 UART maximum baud rate. Section 3.3 EOS / ESD / EMI updated.
F
Sep. 14, 2011
jfur
NEO-6V integration. Section 1.6.4 SPI FLASH For new designs. Sections added: 2.2.2 LEA-6H GLONASS ready module integration. Section B.2.2 Software migration from 6.02 to 7.03. Section 3.3.9 Recommended parts, SAW.
G
Jan. 25, 2011
jfur
New section 2.1.3 Dead Reckoning. Section 2.2.2.1 “u-blox 6 GLONASS module”updated. NEO-6P and NEO-6T integration. Section 1.7.1 RESET_N updated. Section 2.1.3 Updated: Automotive Dead Reckoning (ADR) solutions. New section 2.6.7 External active antenna supervisor using ANTON (MAX-6). Section 1.3.2.3 Power Save mode updated.
H
Feb. 6, 2012
jfur
Section 2.1.3 Automotive Dead Reckoning updated Added section 2.6.7 External active antenna supervisor using ANTON Section 1.3.2.3 Power Save mode updated
I
April 10, 2012
jfur
Added LEA-6N
K
April 22, 2013
jfur
Stencil thickness 150um (Figure 30, 33, 34) LEA-6R: FW 7.03 DR2.02 Added section 3.1.1 Population of Modules
L
July 11, 2013
jfur
1.7.6 TX ready signal updated Last revision with document number GPS.G6-HW-09007
R13
Dec. 19, 2014
amil
Added LEA-6T-2
R14
Jun. 06, 2017
rmak
Added Section 3.4 Safety precautions and Reference [15]
R15
Sep 26, 2017
msul
Added information on RED DoC in European Union regulatory compliance (page 2), added Intended use statement in section 3.3.7 Electromagnetic interference (EMI), updated legal statement in cover page and added Documentation feedback e-mail address in contacts page.
Revision history
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
UBX-14054794 Production Information Revision history Page 84 of 85
LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
u-blox Offices
North, Central and South America
u-blox America, Inc.
Phone: +1 703 483 3180 E-mail: info_us@u-blox.com
Regional Office West Coast: Phone: +1 408 573 3640
E-mail: info_us@u-blox.com
Technical Support:
Phone: +1 703 483 3185 E-mail: support_us@u-blox.com
Headquarters Europe, Middle East, Africa
u-blox AG
Phone: +41 44 722 74 44 E-mail: info@u-blox.com Support: support@u-blox.com
Documentation Feedback
E-mail: docsupport@u-blox.com
Asia, Australia, Pacific
u-blox Singapore Pte. Ltd.
Phone: +65 6734 3811 E-mail: info_ap@u-blox.com Support: support_ap@u-blox.com
Regional Office Australia:
Phone: +61 2 8448 2016 E-mail: info_anz@u-blox.com Support: support_ap@u-blox.com
Regional Office China (Beijing):
Phone: +86 10 68 133 545 E-mail: info_cn@u-blox.com Support: support_cn@u-blox.com
Regional Office China (Chongqing):
Phone: +86 23 6815 1588 E-mail: info_cn@u-blox.com Support: support_cn@u-blox.com
Regional Office China (Shanghai):
Phone: +86 21 6090 4832 E-mail: info_cn@u-blox.com Support: support_cn@u-blox.com
Regional Office China (Shenzhen):
Phone: +86 755 8627 1083 E-mail: info_cn@u-blox.com Support: support_cn@u-blox.com
Regional Office India:
Phone: +91 80 4050 9200 E-mail: info_in@u-blox.com Support: support_in@u-blox.com
Regional Office Japan (Osaka):
Phone: +81 6 6941 3660 E-mail: info_jp@u-blox.com Support: support_jp@u-blox.com
Regional Office Japan (Tokyo):
Phone: +81 3 5775 3850 E-mail: info_jp@u-blox.com Support: support_jp@u-blox.com
Regional Office Korea:
Phone: +82 2 542 0861 E-mail: info_kr@u-blox.com Support: support_kr@u-blox.com
Regional Office Taiwan:
Phone: +886 2 2657 1090 E-mail: info_tw@u-blox.com Support: support_tw@u-blox.com
Contact
For complete contact information, visit us at www.u-blox.com
UBX-14054794 Production Information Contact Page 85 of 85
Loading...
