u blox JODYW164 Data Sheet
Abstract
This technical data sheet describes the JODY-W1 series modules
with 2x2 MIMO 802.11n/ac and dual-mode Bluetooth® v4.2.
JODY-W1 is ideal for in-vehicle-infotainment and telematics
applications with simultaneous use cases requiring high data rates,
such as in-car hotspots, Wi-Fi display applications such as Apple
CarPlay, or video streaming across multiple clients. Connection to a
host processor is through PCIe, SDIO, or High-Speed UART
interfaces.
www.u-blox.com
UBX-16013635 -
JODY-W1 series
Host-based multiradio modules with Wi-Fi
and Bluetooth
Data Sheet
JODY-W1 series - Data Sheet
Document Information
Title
JODY-W1 series
Subtitle
Host-based multiradio modules with Wi-Fi and Bluetooth
Document type
Data Sheet
Document number
UBX-16013635
Revision and date
R10_draft
15-Jun-2018
Disclosure restriction
Confidential
Product Status
Corresponding content status
Functional Sample
Draft
For functional testing. Revised and supplementary data will be published later.
In Development /
Prototype
Objective Specification
Target values. Revised and supplementary data will be published later.
Engineering Sample
Advance Information
Data based on early testing. Revised and supplementary data will be published later.
Initial Production
Early Prod. Information
Data from product verification. Revised and supplementary data may be published later.
Mass Production /
End of Life
Production Information
Final product specification.
Product name
Type number
Chipset
PCN reference
Product Status
JODY-W163-A
JODY-W163-04A-00
CYW89359
N/A
Engineering Sample
JODY-W163-A
JODY-W163-05A-00
CYW88359
N/A
Engineering Sample
JODY-W164-A
JODY-W164-03A-01
CYW89359
N/A
Engineering Sample
JODY-W164-A
JODY-W164-04A-00
CYW89359
N/A
Engineering Sample
JODY-W164-A
JODY-W164-05A-00
CYW88359
N/A
Engineering Sample
JODY-W164-A
JODY-W164-07A-01
CYW88359
N/A
Engineering Sample
JODY-W167-A
JODY-W167-00A-00
CYW88359
N/A
Engineering Sample
JODY-W167-A
JODY-W167-03A-00
CYW89359
N/A
Engineering Sample
JODY-W167
JODY-W167-00B-00
CYW88359
N/A
Engineering Sample
This document applies to the following products:
u-blox reserves all rights to this document and the information contained herein. Products, names, logos and designs described herein may in
whole or in part be subject to intellectual property rights. Reproduction, use, modification or disclosure to third parties of this document or
any part thereof without the express permission of u-blox is strictly prohibited.
The information contained herein is provided “as is” and u-blox assumes no liability for the use of the information. No warranty, either
express or implied, is given, including but not limited, with respect to the accuracy, correctness, reliability and fitness for a particular purpose
of the information. This document may be revised by u-blox at any time. For most recent documents, visit www.u-blox.com.
Copyright © 2018, u-blox AG.
u-blox is a registered trademark of u-blox Holding AG in the EU and other countries.
UBX-16013635 - R10_draft Confidential Page 2 of 50
JODY-W1 series - Data Sheet
Contents
Contents .............................................................................................................................. 3
1 Functional description .................................................................................................. 6
1.1 Overview .............................................................................................................................................. 6
1.2 Applications .......................................................................................................................................... 6
1.3 Product features ................................................................................................................................... 7
1.4 Product description ............................................................................................................................... 7
1.5 Block diagrams ..................................................................................................................................... 7
1.6 Operation modes .................................................................................................................................. 9
1.6.1 Dual-band ..................................................................................................................................... 9
1.6.2 Single-band ................................................................................................................................. 10
1.7 Supported features ............................................................................................................................. 11
1.7.1 Wi-Fi Features.............................................................................................................................. 11
1.7.2 Bluetooth features ....................................................................................................................... 11
1.7.3 General product features ............................................................................................................. 11
1.7.4 Compliance ................................................................................................................................. 11
2 Interfaces .................................................................................................................... 12
2.1 Host interface configuration ............................................................................................................... 12
2.2 SDIO interface .................................................................................................................................... 12
2.2.1 Default speed and High speed modes ......................................................................................... 13
2.2.2 SDR12, SDR25, SDR50 Modes (up to 100 MHz) (1.8 V) ............................................................... 14
2.2.3 SDR104 Mode (208 MHz) (1.8 V) ................................................................................................ 15
2.2.4 DDR50 Mode (50 MHz) (1.8 V) .................................................................................................... 16
2.3 PCI Express interface ........................................................................................................................... 17
2.4 High Speed UART interface ................................................................................................................. 18
2.5 PCM Interface ..................................................................................................................................... 19
2.5.1 PCM Interface specifications ........................................................................................................ 20
2.6 I²S Interface ........................................................................................................................................ 24
2.6.1 I2S Interface specifications ............................................................................................................ 24
2.7 LTE Coexistence interface ................................................................................................................... 25
3 Pin definition .............................................................................................................. 26
3.1 Pin description .................................................................................................................................... 26
4 Electrical specification ................................................................................................ 29
4.1 Absolute maximum ratings ................................................................................................................. 29
4.2 Operating conditions .......................................................................................................................... 29
4.3 Digital pad ratings .............................................................................................................................. 29
4.4 Wi-Fi power consumption ................................................................................................................... 30
4.5 Bluetooth power consumption ........................................................................................................... 31
4.6 Radio specifications ............................................................................................................................ 31
UBX-16013635 - R10_draft Confidential Contents
Page 3 of 50
JODY-W1 series - Data Sheet
4.6.1 Wi-Fi ........................................................................................................................................... 31
4.6.2 Bluetooth .................................................................................................................................... 32
5 Host drivers and firmware ......................................................................................... 33
5.1 General principle ................................................................................................................................ 33
5.2 Supported operating systems .............................................................................................................. 33
5.2.1 Linux ........................................................................................................................................... 33
6 Mechanical specifications .......................................................................................... 34
7 Approvals .................................................................................................................... 35
7.1 European Union regulatory compliance .............................................................................................. 35
7.2 FCC and IC compliance ...................................................................................................................... 35
7.2.1 FCC and ISED IDs ........................................................................................................................ 36
7.2.2 FCC compliance statement .......................................................................................................... 36
7.2.3 ISED compliance statement ......................................................................................................... 36
7.3 Certification in other countries ........................................................................................................... 38
7.4 Approved antennas ............................................................................................................................ 38
7.4.1 Wi-Fi operation............................................................................................................................ 38
7.4.2 Bluetooth operation .................................................................................................................... 38
7.5 Bluetooth qualification ....................................................................................................................... 39
7.5.1 Bluetooth host stack .................................................................................................................... 39
8 Product handling ........................................................................................................ 40
8.1 Packaging ........................................................................................................................................... 40
8.1.1 Reels ........................................................................................................................................... 40
8.1.2 Tapes .......................................................................................................................................... 40
8.2 Shipment, storage and handling ......................................................................................................... 40
8.2.1 Moisture sensitivity levels ............................................................................................................. 40
8.2.2 Mounting process and soldering recommendations ..................................................................... 41
8.2.3 ESD handling precautions ............................................................................................................ 42
9 Labeling and ordering information ........................................................................... 43
9.1 Product labeling .................................................................................................................................. 43
Table ...................................................................................................................................................... 44
9.2 Explanation of codes........................................................................................................................... 44
9.3 Ordering codes ................................................................................................................................... 44
Appendix .......................................................................................................................... 46
A Glossary ...................................................................................................................... 46
Related documents........................................................................................................... 48
Revision history ................................................................................................................ 49
UBX-16013635 - R10_draft Confidential Contents
Page 4 of 50
JODY-W1 series - Data Sheet
Contact .............................................................................................................................. 50
UBX-16013635 - R10_draft Confidential Contents
Page 5 of 50
JODY-W1 series - Data Sheet
1 Functional description
1.1 Overview
The JODY-W1 series is a compact module based on the Cypress CYW88359 and CYW89359 AEC-Q100
compliant chipsets. It enables Wi-Fi, Bluetooth®, and Bluetooth low energy communication, and is thus ideal for
in-vehicle-infotainment and telematics applications with simultaneous use cases requiring high data rates, such
as in-car hotspots, Wi-Fi display applications such as Apple CarPlay, or video streaming across multiple clients.
The JODY-W1 modules can be operated in the following modes:
Wi-Fi 2x2 MIMO 802.11n/ac in 2.4 GHz or 5 GHz
Wi-Fi 1x1 802.11ac in 2.4 / 5 GHz real simultaneous dual band
Dual-mode Bluetooth v4.2, including audio, can be operated fully simultaneous with both Wi-Fi modes
The JODY-W1 undergoes extended automotive qualification according to ISO 16750-4 and is manufactured in
line with ISO/TS 16949. Connection to a host processor is through PCIe, SDIO, or High-Speed UART interfaces.
The radio type approvals for JODY-W1 is pending for many countries, and more certifications are planned.
1.2 Applications
Automotive applications
In-car Access Point for internet access
Usage of applications such as Apple CarPlay, Miracast etc., in the car
Rear-seat display
Rapid sync-n-go applications and fast content download to the vehicle
Hands-free equipment (Bluetooth)
Industrial applications
Manufacturing floor automation, wireless control terminals and point-to-point backhaul
Machine control
Medical in-hospital applications
Security and surveillance
Outdoor content distribution
Robust wireless connectivity in a broad range of industrial applications
UBX-16013635 - R10_draft Confidential Functional description
Page 6 of 50
1.3 Product features
Model
Description
JODY-W163-A
Automotive grade module with 2 antenna pins, RSDB mode with a single antenna pin. Support for SDIO host
interface only.
JODY-W164-A
Automotive grade module with 2 antenna pins, RSDB mode with a single antenna pin. Support for PCIe host
interface, except JODY-W164-07A-01.
JODY-W167-A
Automotive grade module with 3 antenna pins, RSDB mode with two antenna pins
JODY-W167
Professional grade module with 3 antenna pins, RSDB mode with two antenna pins
Table 1: Key features of JODY-W1 series
JODY-W1 series - Data Sheet
1.4 Product description
Table 2: Description of the module variants
JODY-W167-A is recommended for applications that need 802.11n 2x2 MIMO operation in the 2.4 GHz
band.
1.5 Block diagrams
The block diagrams of the JODY-W1 series are provided in this section.
UBX-16013635 - R10_draft Confidential Functional description
Page 7 of 50
JODY-W1 series - Data Sheet
Product type
Antenna configuration
Band-pass filters
ANT0
ANT1
BPF_1
BPF_2
JODY-W164-03A-01
5 GHz Wi-Fi and Bluetooth
2.4 and 5 GHz Wi-Fi (RSDB
operation supported)
Non-LTE coexistence
Non-LTE coexistence
JODY-W163-04A-00,
JODY-W163-05A-00
JODY-W164-04A-00,
JODY-W164-05A-00
Bluetooth
2.4 and 5 GHz Wi-Fi (RSDB
operation supported)
Non-LTE coexistence
Non-LTE coexistence
JODY-W164-07A-01
Bluetooth
2.4 and 5 GHz Wi-Fi (RSDB
operation supported)
LTE coexistence
Non-LTE coexistence
Figure 1: Block diagram of JODY-W163-A and JODY-W164-A
See Table 3 for available configurations and the corresponding product type numbers of JODY-W163-A and
JODY-W164-A.
Table 3: Supported JODY-W164-A / JODY-W163-A configurations
JODY-W163-A and JODY-W164-A differ only in the offered host interface (SDIO or PCIe). The host
interface configuration is programmed at production time into the module.
UBX-16013635 - R10_draft Confidential Functional description
Page 8 of 50
Figure 2: Block diagram of JODY-W167(-A)
JODY-W1 series - Data Sheet
1.6 Operation modes
1.6.1 Dual-band
5 GHz Wi-Fi (1x1 SISO) / 2.4 GHz Wi-Fi (1x1 SISO) RSDB (+ Bluetooth). See Table 4 for further
information.
UBX-16013635 - R10_draft Confidential Functional description
Page 9 of 50
JODY-W1 series - Data Sheet
2.4 GHz band
5 GHz band
Supported host interfaces
Notes
AP
AP
PCIe, SDIO
Any channel
STA
STA
PCIe, SDIO
Any channel
P2P (GO)
P2P (GO)
PCIe, SDIO
Any channel. Supported via single
wpa supplicant.
P2P (GC)
P2P (GC)
PCIe, SDIO
Any channel. Supported via single
wpa supplicant.
AP
STA
PCIe, SDIO
Any channel
STA
AP
PCIe, SDIO
Any channel
AP
P2P (GO)
PCIe, SDIO
Any channel
P2P (GO)
AP
PCIe, SDIO
Any channel
AP
P2P (GC)
PCIe, SDIO
Any channel
P2P (GC)
AP
PCIe, SDIO
Any channel
P2P (GO)
STA
PCIe, SDIO
Any channel
STA
P2P (GO)
PCIe, SDIO
Any channel
P2P (GC)
STA
PCIe, SDIO
Any channel
STA
P2P (GC)
PCIe, SDIO
Any channel
AP+STA
AP
PCIe, SDIO
Any channel. AP+STA on the
same 2.4 GHz channel.
AP
AP+STA
PCIe, SDIO
Any channel. AP+STA on the
same 5 GHz channel.
AP+STA
P2P (GO)
PCIe, SDIO
Any channel. AP+STA on the
same 2.4 GHz channel.
P2P (GO)
AP+STA
PCIe, SDIO
Any channel. AP+STA on the
same 5 GHz channel.
AP
P2P (GO) + STA
PCIe, SDIO
Any channel. P2P (GO) + STA on
the same 5 GHz channel.
P2P (GO) + STA
AP
PCIe, SDIO
Any channel. P2P (GO) + STA on
the same 2.4 GHz channel.
P2P (GO)
P2P (GO) + STA
PCIe, SDIO
Any channel. P2P (GO) + STA on
the same 5 GHz channel.
P2P (GO) + STA
P2P (GO)
PCIe, SDIO
Any channel. P2P (GO) + STA on
the same 2.4 GHz channel.
Table 4: Supported RSDB configurations
1.6.2 Single-band
5 GHz Wi-Fi (2x2 MIMO on JODY-W167(-A) and JODY-W164-03A-01)
JODY-W163-A / JODY-W164-A: 2.4 GHz Wi-Fi (1x1 SISO) (+ Bluetooth)
JODY-W167 / JODY-W167-A: 2.4 GHz Wi-Fi (2x2 MIMO) (+ Bluetooth)
Wi-Fi operation as AP, STA, P2P (GO), and P2P (GC) is supported on any 2.4 GHz or 5 GHz channel.
Configuration of simultaneous operation of AP+STA, P2P (GO)+STA and P2P (GC)+STA is also supported on the
same 2.4 or 5 GHz channel. These configurations are independent of the used host interface (PCIe or SDIO).
UBX-16013635 - R10_draft Confidential Functional description
Page 10 of 50
JODY-W1 series - Data Sheet
2
3
4
2
3
4
1.7 Supported features
1.7.1 Wi-Fi Features
Wi-Fi standards:
o IEEE 802.11a/b/g/n/ac/e/i/v/w/h
o IEEE 802.11d/u in station mode only
Simultaneous client and access point operation (up to 10 clients supported in total)
Supports Wi-Fi direct/P2P mode
IEEE 802.11ac 2x2 antenna configuration
IEEE 802.11 PHY data rates up to 866 Mbps
WPA/WPA2 and WAPI STA encryption is supported by hardware
WPA/WPA2 Enterprise 802.1X
Wi-Fi channels:
o 2.4 GHz: 1-13
o 5 GHz: 36-165
RSDB mode
SU-MIMO configurations
SDIO 3.0 host interface for Wi-Fi
PCIe 3.0 at Gen1 speed host interface for Wi-Fi
MWS/LTE coexistence serial transport interface for connecting an external and co-located LTE device
in station and access point modes
1.7.2 Bluetooth features
Bluetooth v4.2 with Bluetooth Low Energy and Classic Bluetooth v2.1+EDR over high-speed UART
interface
PCM / I
2
S interface for voice applications
MWS/LTE coexistence serial transport interface for connecting an external and co-located LTE device
1.7.3 General product features
Driver support for Linux 3.x/4.x
Low-power and sleep modes for Bluetooth and Wi-Fi core
Coexistence arbitration for Wi-Fi/Bluetooth/LE/LTE operation
Small footprint (19.8 mm x 13.8 mm), LGA package
Automotive qualification tests (climatic, mechanical, and operating life tests) according ISO 16750-4
planned
1.7.4 Compliance
RoHS compliant
Radio type approvals for Europe, USA, Canada, Japan, Korea, and Taiwan
The DFS master mode supported in non-RSDB firmware only.
The SDIO interface is supported only in Automotive grade.
Approvals are pending.
UBX-16013635 - R10_draft Confidential Functional description
Page 11 of 50
JODY-W1 series - Data Sheet
PCIe enable
Pin 6
SDIO disable
Pin 7
SDIO VDD select
Pin 8
VIO_SD supply
Pin 4
Wi-Fi interface
1 1 1
3.3 V or 1.8 V
PCIe
0 0 1
1.8 V
SDIO 1.8 V
0 0 0
3.3 V
SDIO 3.3 V
Product Name
Order Number
Host interface
JODY-W163-A
JODY-W163-04A
SDIO
JODY-W163-A
JODY-W163-05A
SDIO
JODY-W164-A
JODY-W164-03A
PCIe
JODY-W164-A
JODY-W164-04A
PCIe
JODY-W164-A
JODY-W164-05A
PCIe
JODY-W164-A
JODY-W164-07A
SDIO
JODY-W167-A
JODY-W167-00A
PCIe
JODY-W167-A
JODY-W167-03A
PCIe
JODY-W167
JODY-W167-00B
PCIe
2 Interfaces
2.1 Host interface configuration
JODY-W1 series module uses the Pin 6, Pin 7, and Pin 8 pins as host interface configuration input to set the
desired operation mode following a reset. When you need to configure the pins for a certain module operation
mode, you need to provide a 10 kΩ or less pull down resistor to the ground. No external circuitry is required to
set a configuration pin to high logical level.
External reset is not needed for proper operation due to internal power-up reset logic though it can be used by
the host controller through the WL_EN / BT_EN (active high) in case of an abnormal module behavior.
Depending on the module variant, either SDIO or PCIe Wi-Fi host interface must be used:
Table 5: Module configuration
JODY-W1 series modules are programmed at factory to support either SDIO or PCIe host interface.
The following sections specify the electrical characteristics of the two host interfaces. Refer to
Table 6 for an overview of the supported host interface by product type.
Table 6: Supported host interfaces per product
2.2 SDIO interface
The SDIO device interface conforms to the industry standard SDIO 3.0 specification (UHS-I, up to 104 MByte/s)
and allows a host controller using the SDIO bus protocol to access the Wi-Fi functions of the JODY-W1 series
modules. The interface supports 4-bit SDIO transfer mode at the full clock range of 0 to 208 MHz.
UBX-16013635 - R10_draft Confidential Interfaces
Page 12 of 50
2.2.1 Default speed and High speed modes
SDIO_CLK
INPUT
OUTPUT
fPPt
THLtWLtWHtTLH
t
ODLY
(max)
t
ODLY
(min)
t
ISUtIH
SDIO_CLK
INPUT
OUTPUT
fPPt
THLtWLtWHtTLHtODLYtOHtISUtIH
50% VCC
Figure 3: SDIO Protocol timing diagram- Default speed mode (3.3 V)
JODY-W1 series - Data Sheet
Figure 4: SDIO Protocol timing diagram – High speed mode (3.3 V)
UBX-16013635 - R10_draft Confidential Interfaces
Page 13 of 50
JODY-W1 series - Data Sheet
Symbol
Parameter
Condition
Min.
Typ
Max.
Units
fPP
Clock frequency – Data
Transfer Mode
Normal
0 - 25
MHz
High speed
0 - 50
MHz
fOD
Clock frequency –
Identification Mode
Normal
0 400
kHz
High speed
0 - 400
kHz
tWL
Clock low time
Normal
10 - -
ns
High speed
7 - -
ns
tWH
Clock high time
Normal
10 - -
ns
High speed
7 - -
ns
t
TLH
Clock rise time
Normal
- - 10
ns
High speed
- - 3
ns
t
THL
Clock low time
Normal
- - 10
ns
High speed
- - 3
ns
t
ISU
Input setup time
Normal
5 - -
ns
High speed
6 - -
ns
tIH
Input hold time
Normal
5 - -
ns
High speed
2 - -
ns
t
ODLY
Output delay time – Data
Transfer Mode
Normal
0 - 14
ns
High speed
- - 14
ns
t
ODLY
Identification Mode
Normal
0 - 50
ns
t
ODLY
Output delay time CL ≤ 40 pF
(1 card)
Normal
0 - 14
ns
tOH
Output hold time
High speed
2.5 - -
ns
CL
Total system capacitance
(each line)
High speed
0 - 40
pF
SDIO_CLK
INPUT
OUTPUT
fPPtCFtCRt
ODLYtOHtIStIH
50% VCC
T
CLK
Table 7: SDIO Timing data – Default speed, High speed modes (3.3 V)
2.2.2 SDR12, SDR25, SDR50 Modes (up to 100 MHz) (1.8 V)
Figure 5: SDIO Protocol timing diagram – SDR12, SDR25, SDR50 modes (up to 100 MHz) (1.8 V)
UBX-16013635 - R10_draft Confidential Interfaces
Page 14 of 50
Symbol
Parameter
Condition
Min.
Typ
Max.
Units
fPP
Clock frequency
SDR12
0 - 25
MHz
SDR25
0 - 50
MHz
SDR50
0 - 100
MHz
tIS
Input setup time
SDR12/25/50
3 - -
ns tIH
Input hold time
SDR12/25/50
0.8 - -
ns
t
CLK
Clock time
SDR12/25/50
10 - 40
ns
-
Clock duty
SDR12/25/50
30 70
%
t
CR, tCF,
Rise time, fall time
TCR, TCF < 2 ns (max) at 100 MHz
C
CARD
= 10 pF
SDR12/25/50
- 0.2*T
CLK
ns
t
ODLY
Output delay time
CL ≤ 30 pF
SDR12/25
- - 14
ns
SDR50
- 7.5
tOH
Output hold time
CL = 15 pF
SDR12/25/50
1.5 - -
ns
Table 8: SDIO Timing data – SDR12, SDR25, SDR50 modes (up to 100 MHz) (1.8 V)
Symbol
Parameter
Condition
Min.
Typ
Max.
Units
fPP
Clock frequency
SDR104
0 - 208
MHz
TIS
Input setup time
SDR104
1.4 - -
ns
TIH
Input hold time
SDR104
0.8 - -
ns
T
CLK
Clock time
SDR104
4.8 - -
ns
t
CR, tCF,
Rise time, fall time
TCR, TCF < 0.96 ns (max) at 208 MHz
C
CARD
= 10 pF
SDR104
- 0.2*T
CLK
ns
TOP
Card output phase
SDR104
0 - 2
UI
dTOP
Delay variation due to temperature change after
tuning
SDR104
-350 +1550
ps
T
ODW
Output timing of variable data window
SDR104
0.6 - -
UI
SDIO_CLK
INPUT
OUTPUT
fPPtCFtCRtOPt
ODWtIStIH
50% VCC
T
CLK
2.2.3 SDR104 Mode (208 MHz) (1.8 V)
JODY-W1 series - Data Sheet
Figure 6: SDIO Protocol timing diagram – SDR104 mode (208 MHz)
Table 9: SDIO Timing data – SDR104 mode (208 MHz)
UBX-16013635 - R10_draft Confidential Interfaces
Page 15 of 50
Loading...
