Overview
The UniFi SmartPower Redundant Power System, model USP-RPS,
is a proprietary redundant power system designed to protect up
to six UniFi SmartPower supported devices from sudden power
supply module failure. The USP-RPS continually monitors all
attached devices. In the event of an internal AC/DC power supply
failure, failover is automatic so your network continues to operate
with no interruption in service. With a 950W DC power budget, the
USP-RPS can protect a variety of high-power devices, including
UniFi PoE switches. An integrated 1.3" color touchscreen LCM
displays system information for convenient monitoring.
Learn more about the USP-RPS and its use cases at:
ubnt.link/UniFi-USP-RPS-Setup-and-Features
USP-RPS
D A T A S H E E T
Dimensions 442.40 x 325.60 x 43.70 mm
(17.42 x 12.82 x 1.72")
Weight
With Mount Brackets
Interfaces
Networking
Management
Power Output
Max. Power Consumption 995W
Power Method (1) Universal AC Input, 100 to 240VAC
Power Supply Internal 350W AC/DC
Supported Voltage Range 100 - 240VAC
Display 1.3"Color Touch Panel
LED
System
RJ45
USP RPS
(1) 10/100/1000 Mbps RJ45 Port
5.500 kg (12.13 lb)
5.590 kg (12.32 lb)
Ethernet In-Band
(6) RPS DC Ports
Internal 645W AC/DC
Status
Link/Activity
Activity
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Operating Temperature -5 to 45° C (23 to 113° F)
Operating Humidity 10 to 90% Noncondensing
Certications CE, FCC, IC
2
Page 3
S P E C I F I C A T I O N S
RPS
Total Output Power
52VDC
11.5VDC
Max. Output Power per RPS Port
52VDC
11.5VDC
Power Buget*
Model 52V 12V
UDM-Pro 0 50W
USW-Pro-24 0 30W
USW-Pro-24-PoE 400W 30W
USW-Pro-48-PoE 600W 50W
11.54A (600W)
30.44A (350W)
11.54A (600W)
30.44A (350W)
* Maximum power consumption per device model
3
Page 4
Overview
One USP Cable is included with the UniFi SmartPower
Redundant Power System. To attach additional devices, the
USP-Cable is sold separately as an accessory.
USP-Cable
Length 1.5 m (4.9 ft)
Conductor Type Tinned Copper
Conductor Wire Gauge (18) 16 AWG, (6) 24 AWG
Insulation Type PVC
Insulation Thickness 0.35 mm (0.014")
Insulation Diameter 2.0 mm (0.079")
D A T A S H E E T
Jacket Material PVC
Jacket Outside Diameter 9.5 × 23.0 mm (0.374 x 0.905")
Specications are subject to change. Ubiquiti products are sold with a limited warranty described at: ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and, where applicable, specify arbitration instead of jury trials or class actions.
©2020 Ubiquiti Inc. All rights reserved. Ubiquiti, Ubiquiti Networks, the Ubiquiti U logo, the Ubiquiti beam logo, and UniFi are trademarks or registered trademarks of Ubiquiti Inc. in the United
States and in other countries. All other trademarks are the property of their respective owners.
AL051220
