UbiBot WS1 Pro User Manual

E-mail: [e-mail]
Website: www.ubibot.io
Manufacturer: Dalian Cloud Force Technologies CO., LTD

WS1 Pro – the Smartest Multi-Sensor IoT Device

USER GUIDE

www.ubibot.io

CATALOG

INTRODUCTION

TECHNICAL SPECIFICATIONS

TECHNICAL HIGHLIGHTS

DEVICE OPERATIONS

DATA SYNC MODES

APP INSTALLATION

WIFI SETUP

MOBILE DATA* SETUP

DATA EXPORTATION VIA PC OFFLINE TOOLS

ERROR CODES

TROUBLESHOOTING

PRODUCT CARE

WARRANTY INFORMATION

WARRANTY CARD

REPAIR HISTORY

01

04

05

06

08

09

10

13

15

16

18

22

23

24

25

INTRODUCTION

01

Depending on the specific model purchased.

The UbiBot® WS1 Pro is a smart mul-sensor device with both WiFi and

mobile data* capabilies. It makes environmental monitoring easier than ever
with its accurate sensors and automac wireless data synchronisaon. The
device comes with a free subscripon to our advanced IoT Plaorm offering
custom monitoring, analysis, reports and alerts. Device readings are displayed
on the built-in LCD screen and are synchronised to the IoT Plaorm. You can
access the data any me using our App or via the web. Some models come
with a built-in RS485 ModBus*.

02

INTRODUCTION

Ambient Light

Sensor

Micro USB 1

Micro USB 1

Micro USB 2

Micro USB 2

Status Indicator

Menu Buon

Power Buon

Used for USB charging or external DS18B20 temperature probe (oponal extra). Oponal
built-in RS485 ModBus

Used for USB charging or external DS18B20 temperature probe (oponal extra). Also provides
PC connecvity.

03

INTRODUCTION

Overview of LCD Display

USB Connected
Error Code
SIM Installed*
Mobile Data Strength

Leak Warning*

Disk Formatting
WiFi Setup Mode
Sending Data

Network Connection/
Failure

Temperature

RH

%

Lux

X100

%

usage

EXT1

%

EXT2

%

××

SIM

SIM

WiFi Connection/
Failure

Battery Level

Relative
Humidity

Storage
Status

External
Temp/Hum. 1

External
Temp/Hum. 2

Ambient Light

Icon indicates optimal temperature and humidity range
(20-26℃, 30-70% RH)
See ISO7730 ASHRAE 55-1992 standard

Battery level calculated based on 4
standard 1.5v AA alkaline batteries

04

TECHNICAL SPECIFICATIONS

WiFi, 2.4GHz, channels 1-13
Flame resistant ABS + PC

4.96'' x 0.88'' x 3.38''

Built-in Memory: >300,000 sensing data

℃, 10-90% RH

Micro USB power (DC 5V/2A)

Supports Micro SIM card (15mm x 12mm x 0.8mm)

SIM

05

TECHNICAL HIGHLIGHTS

The UbiBot WS1 Pro uses state-of-the-art industrial-grade sensors from

Sensirion and Texas Instruments. The device integrates these sensors to create

① Quoted temperature precision applies between 0-60℃; ② Quoted precision for temperature of 25℃
Otherwise the precision is ±4% RH. ③ Quoted precision applies when light level >40 lux.

on page 04.

Temperature Sensor
Precision ± 0.3℃

①

Range -20 to 60℃

Humidity Sensor
Precision ± 3%RH
Range 0—100%

Ambient Light Sensor
Precision ± 2%

③

Range 0.01—83K lux

Supports external waterproof
DS18B20 temperature probe
(optional extra).
RS485 communication via
built-in ModBus.

Accurate

and reliable

environmental

monitoring

06

DEVICE OPERATIONS

Switch On

Switch Off

WiFi Setup Mode

Manual Data Synchronisation

To switch the device on, press and hold the power buon for 3 seconds unl
the indicator starts blinking green. Release the buon and the indicator will
turn off aer a couple of seconds. The device is now on.

To switch the device off, press and hold the power buon for 3 seconds. The
indicator will flash red once and the device is now off.

With the device switched on, press and hold the menu buon for 3 seconds.
The indicator will start flashing alternate red and green and the AP icon will dis­play on the screen. Release the buon at this point.

With the device switched on, press the power buon once to trigger a manual
data sync. The indicator will flash green while the data is being transferred. If
the server cannot be contacted, the indicator will flash red once.

07

DEVICE OPERATIONS

Reset to Default Settings

Switch On/Off Voice Guide

Display Backlight

Toggle Celsius or Fahrenheit

IMPORTANT

ALL STORED DATA WILL BE LOST IF YOU RESET YOUR DEVICE TO DEFAULT SETTINGS!
REMEMBER TO SYNCHRONISE THE SENSING DATA TO THE UBIBOT® IoT PLATFORM OR EXPORT THE DATA TO

YOUR COMPUTER BEFORE RESETTING IT.

Switch the device off. Now press and hold the menu buon and power buons
together for at least 8 seconds. Release the buons when the indicator is con­stantly flashing red.

Press the menu buon twice in quick succession to enable or disable the voice
guide. This will also refresh the last sensing data.

Pressing either of the buons will switch on the display backlight for a short
me.

Press the power buon twice to toggle between displaying Celsius or
Fahrenheit.

08

DATA SYNC MODES

The device includes a SIM card
slot to allow mobile data sync if

WiFi is unavailable.

The device supports fast,
secure data sync over WiFi
using 2.4GHz, channels 1-13.

Depending on the specific model purchased.

Sync via Mobile Data*

Automatic Network Selection

Direct Data Access without Network

Sync via WiFi

The device can preferenally
connect to WiFi if both WiFi and
mobile data are available. This
saves you monthly data.

The device connues to collect data even
without a network connecon. When the
network becomes available, it will sync the
data. Alternavely you can connect to your
PC via USB1 to manually export the data.

09

App INSTALLATION

Download the App from www.ubibot.io/setup
Or
Search for “UbiBot” on the App Store or Google Play.

Download the Tool from www.ubibot.io/setup

(The UbiBot App requires Android 6.0+, iOS 9.0+)

(The PC Offline Tools needs Winows 7+)

1

2

ＰＣ　Ｏｆｆｌｉｎｅ　Ｔｏｏｌｓ　Ｉｎｓｔａｌｌａｔｉｏｎ

Please note that this tool is specially used for offline data exportaon and pro­fessional use.

10

Device Management

Launch the App, register an account if needed and log in. On the home screen

click the “+” to add your device. Scan the QR code on the back of the device,

or manually enter the serial number.

WiFi SETUP

Add your device Scan the QR code

11

WiFi SETUP

ＳＴＥＰ２．

Put your device into WiFi setup mode (see p.06). The indicator should flash
alternately red and green and the AP icon is shown on the screen.

ＳＴＥＰ３．

The device will ask you to enter your
WiFi password. Check that the correct
SSID is selected and enter the password.
The App will now prompt you to go to
your phone sengs screen. Change to
the UbiBot-xxx network and return to
the App.

ＷＬＡＮ

Ｕｂｉｂｏｔ－５０８４６　

ＷＬＡＮ

Next Step

Serial No.

SSID

Password

12

The device will now complete the setup process, register with the server and

you entered the correct WiFi details in step 3.

Ｄｅｖｃｉｅ　Ｓｅｔｕｐ

Ｓｕｃｃｅｓｓｆｕｌ！　

WiFi SETUP

13

MOBILE DATA * SETUP

With the device off, insert a Micro SIM card into the slot in the direcon shown
(with the notch facing out and the silver contacts downwards). Now switch the
device on.

Ｍｉｃｒｏ

ＳＩＭ

Ｍｉｃｒｏ　ＳＩＭ　Ｓｌｏｔ

Insert a Micro SIM card into the slot

＊

Depending on the specific model purchased.

14

MOBILE DATA * SETUP

Launch the app, register if needed and log in. On the main screen, click the “+”
to add your device. Scan the QR code on the back of the device, or manually
enter the serial number.

Please select your operator and make sure the APN info. is correct.

Now follow the onscreen instrucons and the device will automacally con­tact the server and synchronise over mobile data. NB, if you have no data
allowance on the SIM card, this step will fail.

With the device switched on, use the Micro USB cable provided to connect
your device to the computer. You can now perform a data export to your com­puter using the PC Offline Tools.
Note: only USB1 supports PC connecvity.

15

DATA EXPORTATION VIA PC OFFLINE TOOLS

My Device

WiFi SSID

Device Name
Latest Data
Product ID ubibot-ws1p-io
Storage Used
Network Usage

Export Data

WiFi Password
Encryption Mode

Serial No.: 42H0WS1Pro
Channel ID: 335

0%

0B/20G

0B/20G

16

ERROR CODES

０１

０２

０３

０４

０５

System Protecon.
Please follow the instrucons to properly configure the device.
Unconfigured devices will revert to system protecon mode to save power.

WiFi Connecon Failed
Please refer to the Troubleshoong secon 4 on page 21.

Failed to Connect to Server
Please refer to the Common Qesons at www.ubibot.io/category/faqs.

Device Acvaon Failed
Please refer to the Troubleshoong secon 1 on page 18.

Data Save Failure
This can happen when there is a power disrupon while saving data when
the power is disrupted while data is being saved.

17

ERROR CODES

Incorrect Data Format
This can happen when there is a power disrupon while saving data.

Data Sync Failed
Please refer to the Troubleshoong secon 2 on page 19.

No SIM Card Found
Please check the SIM card is correctly inserted.

Mobile Data Network Failure
Please check your SIM card is set up correctly and has been acvated.

18

TROUBLESHOOTING

1.Device setup failure when using the UbiBot App

There are several factors that can affect the setup process. The followings are common
issues:

①WiFi setup mode: Make sure you turn on the WiFi setup mode. (The device indicator

flashes alternate red and green).

②WiFi frequency: The WS1 can only connect to 2.4GHz networks, channels 1-13.
③WiFi password: Go through the WiFi setup again and ensure that you have set the

correct WiFi password for the network.

④WiFi security type: The WS1 supports OPEN, WEP, or WPA/WPA2 types.
⑤WiFi channel width: Make sure it is set to 20MHz or "Auto".
⑥Baery problems: WiFi uses a lot of power. Your device may be able to power on but

may not have enough power for the WiFi. Try replacing the baeries.

⑦Signal strength. Check you are in range for your WiFi, or if using mobile data, make

sure you have a good signal.

19

TROUBLESHOOTING

2.Failure to Sync Data

Please check the following:

①Press the power buon to manually sync data. If the indicator flashes green, then the

sync is working. If it flashes red once then there is another problem. Try the next steps.

②Check that the device has sufficient baery power for the WiFi to work. WiFi takes a

lot of power -- the device may be on, but unable to connect to the WiFi. If you have
access to recent readings from the device, check if the voltage has dropped below 2.6v.
If so, try changing the baeries.

③Make sure your device's WiFi router has a working Internet connecon (for instance,

try to access www.ubibot.io using a mobile connected to the same WiFi).

④If you are using mobile data, check that your SIM card is acvated. If it is, check that

your baeries or USB power connecon are able to provide 2A current. Check if your
mobile data allowance is used up.

20

3.Can I Use the Device without a Network Connection? How do I Access the
Data?

The device will connue working without a network connecon and can store over
300,000 readings in its memory. Real-me readings are displayed on screen and you can
access the data in the following ways:

①Move the device to an area where there is a WiFi connecon which the device can

connect to. Press the buon to trigger a manual data sync. The indicator should flash
green for a few seconds. You can now take the device back to the measurement locaon
(Recommended).

②Use your mobile phone and enable Internet Connecon Sharing. This can work well

when your devices are installed in an area with limited or no WiFi coverage.

③Use a Windows laptop and the Micro USB cable to connect to the device manually.

You can now perform a data export to your computer using the PC Offline Tools.

④Set it up with a mobile data card* (see p.13). Once you are in range of the network,

press the power buon once to sync all data with the IoT plaorm.

TROUBLESHOOTING

Depending on the specific model purchased.

21

4. WiFi Connection Problems

Please refer to the list of potenal issues above.
If your WiFi password has changed, or if you move the device to a new WiFi environ­ment, you need to go through the WiFi setup again (p.06).

5.Why are my device Temperature readings not accurate?

The measured temperature may be affected by several factors, thus the device may
temporarily show inaccurate temperatures during and aer the inial setup. Please visit

www.ubibot.io/category/faqs/ to view the specific causes and corresponding soluons.

Please ensure you are using a USB data cable with 4 wires. Many cheap USB cables are
only able to provide power.

For any other problems, please visit www.ubibot.io/category/faqs. Alternatively,
email customer support at [e-mail] to get assistance.

TROUBLESHOOTING

6.Failure to Download Data Using the PC Offline Tools

22

PRODUCT CARE

Please always follow the instrucons contained in this manual.

The device is not waterproof. Please keep away from water during opera­on, storage and shipping. The oponal DS18B20 temperature probe is
water proof.

Always mount the device on a stable surface.

Keep away from acidic, oxidising, flammable or explosive substances.

When handling the device, avoid using excessive force and never use
sharp instruments to try and open it.

23

WARRANTY INFORMATION

1. This device is warranted to be free of defects in materials and workmanship for a period of up
to one year from the original purchase date. This warranty does not cover damage caused by

normal wear, misuse, abuse or incorrect repair. To claim under this limited warranty and to obtain

on how to pack and ship the product back to us.

①

②

③

ity range, damage from contact with water, damage from applying excessive force to the device
or any cables and connectors.

④ Natural wear and aging of materials.

⑤ Failure or damage caused by unauthorized removal of the product.

⑥ We are only liable for faults due to manufacturing or design. We are not responsible for damage

caused by Force Majeure or acts of God.

24

WARRANTY CARD

Product Name
Product ID
Product Serial No.
Date of Purchase
Online Purchase Store

Name
Phone
Address
Email

Thank you for buying the UbiBot WS1 Pro. If you have any problems and wish to claim under the
limited warranty, first contact our customer service team using the email address on the back of
this book. If Customer Service asks you to return you product to us, please complete the following
details and include this form in the package.

25

REPAIR HISTORY

First Repair

Second Repair

Date of Repair: Repaired by:

Date of Repair:

Only to be completed by UbiBot technicians

Repaired by:

Problems Descripon Reason for Problems Repair Descripon

Problems Descripon Reason for Problems Repair Descripon
