UBC1307-CA00 Advanced Wireless
Voice Gateway Safety and Installation
Product Insert

Federal Communications Commission
(FCC) Interference Statement

This device has been tested and found to comply
with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This device generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this device does cause
harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one of the

1 Ubee UBC1307-CA00 – Safety and Installation Product Insert v1.1

following measures:

z Reorient or relocate the receiving antenna.
z Increase the separation between the

equipment and receiver.

z Connect the equipment into an outlet on a

circuit different from that to which the
receiver is connected.

z Consult the dealer or an experienced

radio/TV technician for help.

FCC Regulatory Information

This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.

There is one statement for this product:

Ubee Interactive — www.ubeeinteractive.com

z The device must carry a label stating “FCC

ID: XCNUBC1307.”

FCC Caution: Any changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to
operate this device.

IEEE 802.11b or 802.11g operation of this device
in the U.S.A. is firmware-limited to channels 1
through 11.

FCC Radiation Exposure Statement:

This device complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This device should be installed and
operated at a minimum distance of 20cm
between itself and your body.

This device must not be co-located or operating
in conjunction with any other antenna or
transmitter.

2 Ubee UBC1307-CA00 – Safety and Installation Product Insert v1.1

Safety Notices

Read these instructions carefully before
operating the device. It is important to be aware
of these safety instructions. Install the device
according to these instructions and keep this
guide for future reference.

1. Do not use this device in a humid
space, in the rain, or near splashing
water.

2. Do not install during thunder or
lightening storms.

3. Do not cover any ventila tion openings
in the device case.

4. Do not place the device near heat
sources such as radiators or stoves.

5. Clean the device only with a clean,
dry cloth. Do not use liquid or
chemical cleaners.

6. Avoid static discharge when touching

Ubee Interactive — www.ubeeinteractive.com

the device by first touching the
coaxial connector of the coaxial
cable.

7. Installation of the device should
include grounding the coaxial cable
to the earth at the building entrance
per ANSI/NFPA 70 and the National
Electrical Code (NEC, in particular,
Section 820.93, Grounding of the
Outer Conductive Shield of a Coaxial
Cable).

8. The device is designed for IT power
systems with phase-to-phase voltage
at 100-240V.

9. Disconnecting the Device: If the
device becomes damaged or
encounters some other abnormality,
disconnect the power plug from the
AC wall outlet immediately.

10. The device should be installed in a
location not to exceed the maximum
temperature of 40 degrees Celsius

3 Ubee UBC1307-CA00 – Safety and Installation Product Insert v1.1

(104 degrees Fahrenheit).

11. When the device is placed upright
with the aid of the stand, the stand
must be fixed at a 90 degree angle to
the device. Otherwise, the device will
have the risk of tipping over. This is
the recommended position for best
Wi-Fi performance

12. Keep the device away from Children
and Pets

13. Place the device on a cool surface.
Failure to do so may result in
overheating which can cause
extreme damage.

14. Do not modify or attempt to
disassemble the device. Use it only
according to the instructions.

15. Do not dispose of the device in a
trash container. Please recycle.


