USER AND INSTALLATION
GUIDE H2
O
K
29005140-ENG
Keep this user guide!
In the event of any problems, please contact the retailer where
you purchased the equipment.
© This publication may not be reproduced, in part or in whole,
without the written permission of Tylö. Tylö reserves the right to
make changes in materials, construction and design.
TABLE OF CONTENTS
User Guide ......................................................................1
The control panel in general .................................................. 1
When starting for the first time ............................................. 2
Start/stop ................................................................................2
Setting temperature ................................................................2
Setting humidity level .............................................................2
Setting start time and calendar programming. ....................... 3
The SETTINGS menu ............................................................3
Locking the panel ...................................................................4
Drying mode ...........................................................................5
External ON/OFF switch (option) ........................................... 5
Extra control panel (option) ....................................................5
Installation Guide ........................................................... 6
Control panel ........................................................................ 6
External ON/OFF switch (option) ........................................... 7
Extra control panel (option) ....................................................7
Troubleshooting the control panel ............................... 8
1
USER GUIDE
The control panel in general
The control panel is automatically activated when you pass your
hand over it.
Use UP (see Figure 1, Page 1 pos 6) and DOWN(pos 9) to
scroll through the menus.
Use UP and DOWN to increase/decrease a value when entering
data.
Confirm menu choices using OK (pos 8).
1
2
3
4
5
6
7
8
9
10
11
12
13 14 15 16 17 18
O
K
19
20
Figure 1: Main menu
1.
ON/OFF
2.
TEMPERATURE
3.
HUMIDITY: Set humidity
4.
TIMER: Program start time
5.
SETTINGS
6.
STATUS BAR: Shows the status of certain functions
(13-20)
7.
UP: One step up in the menu or increase value when enter-
ing data
8.
LIGHT
9.
OK: Confirm choice
10.
DOWN: One step down in the menu or decrease value
when entering data
11.
BACK: Go one step back in the menu or when entering
data
12.
HOME: Return to main menu
13.
ON/OFF STATUS: Shows that the sauna/steam bath is on
14.
LIGHT STATUS: Shows that the light is on
15.
TIMER STATUS: Shows that the control panel is pro-
grammed for delayed start
16.
CALENDAR STATUS: Shows that the system is calen-
dar-programmed
17.
HUMIDITY STATUS: Shows approximate reservoir level
Full symbol = full reservoir, half-full symbol = half reservoir
and flashing empty symbol = empty reservoir. Only applies
to heaters with manual water filling.
18.
LOCKED STATUS: Shows that the panel is locked
19.
DRYING STATUS: Shows that the system is in Dryingset-
ting, replaces ON/OFF STATUS
20.
STANDBY STATUS: Shows that the system is in Stand-
bysetting, replaces ON/OFF STATUS
2
When starting for the first time
Using the control panel for the first time:
1. Check the heater manual for getting started and safety precautions.
2. Pass your hand over the screen to light it up.
3. Select region (Europe, USA, Other). Use UP and DOWN to
scroll through the menu. Confirm using OK (see Figure 2,
Page 2).
Figure 2: UP, DOWN and OK
4. Select language. Confirm with OK.
5. Enter current time. Confirm with OK.
6. Enter current date (yyyy-mm-dd). Confirm with OK.
7. Select System type (Timer-controlled, Monitored or
Private).
Key to system type:
System type Timer-controlled is used for systems in which
calendar programming or delayed start are required. Maximum running time for this choice is 12 hours. After 12 hours, the
system must be shut down for at least 6 hours. A door contact
must also be connected to the sauna door to detect whether
the door is opened after the last shut-down.
System type Monitored is used for systems where there are
always personnel to monitor the sauna. No calendar programming or delayed start can be used with this choice.
System type Private is used for private systems. Max. sauna
time is 6 hours. Delayed start can be used with this choice,
but not calendar programming.
NOTE! A door contact can be used for all system
types. The contact will detect if the sauna door is
opened after the last sauna has been taken. NB:
timer-controlled systems will require a check of the
sauna and confirmation on the control panel.
8. Enter Bathtime limit (maximum time depends on system
type).
9. Enter Door contact (Yes, No).
10. Enter Auto fill and empty (automatic water filling and empty-
ing - applies to the Expression heater).
Start/stop
To start the heater:
1. Pass your hand over the screen to light it up. ON/OFF is
marked (light intensity increases) (see Figure 3, Page 2).
Figure 3: ON/OFF and ON/OFF STATUS
2. If ON/OFF is not marked, use UP to scroll to the correct posi-
tion.
3. Press OK. ON/OFF STATUS will light up in the STATUS BAR
(see Figure 1, Page 1) to show that the sauna heater is
on.
When the heater is on, the temperature and time will be shown if
no other settings are changed.
To switch off, select ON/OFF and press OK.
NOTE! When the heater is switched off or the set operating time expires, it will switch into drying mode. The
heating element will run for 20 minutes to dry out the
sauna cabin. This can be deactivated by pressing ON/
OFF. When the heater is off, the control panel light will
go out. It is automatically activated when you pass your
hand over the panel. Tylö recommends using the drying
mode.
Setting temperature
To set sauna temperature:
1. Select TEMPERATURE (see Figure 4, Page 2) and
press OK.
Figure 4: TEMPERATURE
2. Use UP and DOWN to set the temperature and confirm with
OK.
At temperature settings over 70°C, sauna cabin heating will
be prioritised, and at temperature settings under 70 °C, steam
production will be prioritised. Prioritisation can be changed in
Settings (see The section called The SETTINGS menu, Page
3).
Setting humidity level
To set humidity level:
1. Select HUMIDITY (see ) and press OK.
Figure 5: HUMIDITY/HUMIDITY STATUS for empty, half-full
and full reservoir.
2. Set the desired humidity level on the scale of 0-10 (0 = dry
sauna and 10 = max. humidity). Confirm with OK.
Water level in the reservoir is indicated by HUMIDITY STATUS
(see ) in the STATUS BAR (see Figure 1, Page 1, pos 6). An
illuminated, full drop symbol shows the reservoir is full. An illuminated half-full symbol shows the reservoir is half full and a flashing empty symbol shows the reservoir is empty. When starting, an
empty reservoir will also be indicated by a pulsating audio signal.
If the water runs out during your sauna, it will be indicated by a
pulsating audio signal and flashing symbol on the panel. When
filling with water, HUMIDITY STATUS will first change to half-full
and then to full, and a steady audio signal will indicate that the
reservoir is full.
