Touchmonitor User Guide
1915L 19-inch LCD Desktop Touchmonitor
[Model ET1915L]
User Guide
19-inch LCD De sktop
1915L Touchmonitor
Revision C
P/N E731143
Copyright © 2008 Tyco Electronics. All Rights Reserved.
No part of this publication may be reproduced, tra nsmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in a ny f orm or by any means, including, but
not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written
permission of Elo T ouchSyste ms.
Disclaimer
The information in this document is subject to cha nge without notice. Elo TouchSystems makes no
representations or warranties with respect to the contents hereof, and specifically disclaims any
implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves the right to revise this publication and to make changes from time to time in the content
hereof without obligation of Elo T ouchSystems to notify any person of such revisions or changes.
Trademark Acknowledgments
IntelliTouch, SecureTouch, AccuTouch, and MonitorMouse are trademarks of Elo TouchSystems.
Other product names mentioned herein may be trademarks or registered trademarks of their
respective companies. Elo TouchSystems claims no interest in trademarks other than its own.
iii
Table of Contents
Chapter 1
Introduction 1
Product Description ..................................................1
Precautions ...............................................................1
About the product .....................................................2
Chapter 2
Installation and Setup.................................... 3
Unpacking Your Touchmonitor ..................................3
Touch Interface Connection ......................................4
Product Overview ......................................................5
Main Unit .............................................................5
Rear View ............................................................5
Installing the Driver Software ....................................6
Installing the Serial Touch Driver ........................7
Installing the Serial Touch Driver for Windows
XP, Windows 2000, Me, 95/98 and NT 4.0 .. 7
Installing the Serial Touch Driver for
MS-DOS and Windows 3.1 ...........................8
Installing the USB Touch Driver ..........................9
Installing the USB Touch Driver for Windows
XP, Windows 2000, Me, 95/98 and NT 4.0 .. 9
Installing USB Touch Driver for Acoustic
Pulse Recognition Monitors..........................10
Chapter 3
Operation 11
About Touchmonitor Adjustments............................11
Front Panel Controls...........................................12
Controls and Adjustment ..........................................13
OSD Menu Functions .........................................13
OSD Control Options ..........................................14
Preset Modes ......................................................15
Power Management System..............................16
Display Angle ............................................................16
Chapter 4
Troubleshooting 17
Solutions to Common Problems..............................17
Appendix A
Native Resolution ......................................................19
Appendix B
Touchmonitor Safety .................................................21
Care and Handling of Your Touchmonitor.................22
iv
Appendix C
Technical Specifications...........................................23
Touchmonitor Specifications ....................................24
19" LCD Touchmonitor (ET1915L) Dimensions .......25
Regulatory Information .............................. 16
Warranty....................................................... 29
Index ......................................................................30
C H A P T E R
1
INTRODUCTION
Product Description
Your new touchmonitor combines the reliable perf ormance of touch technology with the latest
advances in LCD display design. This combination of f eatures creates a natural flow of information
between a user and your touchmonitor.
This LCD monitor incorporates 19” color active matrix thin-film-transistor (TFT) liquid crystal
display to provide superior display performa nce. A maximum resolution of SXGA 1280 x 1024 is
ideal for displaying graphics and images. Other outstanding designs that enhance this LCD monitor’s
performa nce are Plug & Play compatibility, and OSD (On Screen Display) controls.
Precautions
Follow all warnings, precautions a nd maintena nce a s recommended in this user’s manual to
maximize the life of your unit. See Appendix B f or more inf ormation on touchmonitor safety.
1
About the Product
Your LCD Desktop Touchmonitor is a 19” SXGA TFT color display with the f ollowing feature s:
• The internal microprocessor digitally controls auto-scanning, for horizontal scan frequencie s
between 31.5 KHz a nd 80 KHz, and vertical sca n frequencies between 56.3 Hz and 75.0 Hz. In
each frequency mode, the microprocessor -based circuitry allows the monitor to function at the
precision-of a fixed frequency.
• High contrast color TFT LCD display supports resolutions up to SXGA 1280 x 1024. It is
Compatable with VGA, SV GA, XGA, SXGA (non-interlaced) a nd most Ma cintosh compatible color
video cards.
• Power manage ment system conf orms to VESA DPMS standard.
• Supports DDC1/2B for Plug & Play compatibility.
• Advanced OSD control for picture quality adjustment.
• Detachable stand for wall-mounting application.
• Integrated touch screen function.
For full Product Specifications refer to Appendix C.
2 Elo Touchsystems 1915L User’s Guide
C H A P T E R
2
INSTALLATION AND SETUP
This chapter discusses how to install your LCD touchmonitor and how to install the driver software.
Unpacking Your Touchmonitor
Check that the following 8 items are present and in good condition:
LCD monitor V GA cab le USB cable
Serial Cable European power cable Power cable US/Canada
CD and Quick Install Guide
3
Elo QuickStart
CD
Software
Touch Interface Connection
Note: Before connecting the cables to your touchmonitor and PC, be sure that the computer
a n d touchmonitor are turned off.
1. Connect one end of the power cord to the monitor a nd the other end to the outlet.
2. Connect one end of either the touchscreen serial(RS232) cable or the touch screen USB cable
(but not both) to the rear side of the computer a nd the other end to the LCD monitor. Tighten by
turning the two thumb screws clockwise to ensure proper grounding(USB cable does not have
thumb screws)
3. Connect one end of the video cable to the rear side of computer a nd the other to the LCD monitor.
Tighten by turning the two thumb screws clockwise to ensure proper grounding.
4. Press the power button on the front panel to turn the monitor power on.
4 Elo Touchsystems 1915L User’s Guide
Product Overview
Main Unit
Rear View
5
Installing the Driver Software
Elo TouchSystems provides driver software that allows your touchmonitor to work with your
computer. Drivers are located on the enclosed CD-ROM.
Additional drivers and driver information for other operating systems are available on the Elo
TouchSystems web site at www.elotouch.com.
Your Elo touchmonitor is plug-and-play compliant. Information on the video capabilities of your
touchmonitor is sent to your video display adapter when Windows starts. If Windows detects your
touchmonitor, follow the instructions on the screen to install a generic plug-and-play monitor.
Refer to the appropri ate f ollowing section f or driver installation instructions.
Depending upon whether you connected the serial communication cable or the USB
communication cable, you should install only the serial driver or the USB driver.
6 Elo Touchsystems 1915L User’s Guide
Installing the Serial Touch Driver (not applicable to Acoustic
Pulse Recognition monitors)
Installing the Serial Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT4.0
NOTE: For Windows 2000 and NT 4.0 you must have administrator access rights to install
the driver.
1 Insert the Elo CD-ROM in your computer's CD-ROM drive.
2 If the AutoStart f eature f or your CD-ROM drive is a ctive, the syste m automatically detects the
CD and starts the setup program.
3 Follow the directions on the screen to complete the driver setup for your version of Windows.
4 If the AutoStart f eature is not a ctive:
5 Click Start > Run.
6 Click the Browse button to locate the EloCd.exe program on the CD-ROM.
7 Click Open, then OK to run EloCd.exe.
8 Follow the directions on the screen to complete the driver setup for your version of Windows.
To install Windows 2000 a nd Windows XP, you must use the "update driver" method; you will not
find a setup.exe file within the download.
7
Installing the Serial Touch Driver for MS-DOS and Windows 3.1
(not applicable to Acoustic Pulse Recognition monitors)
You must have a DOS mouse driver (MOUSE.COM) installed for your mouse if you wish to
continue using your mouse along with your touchmonitor in DOS.
T o install Windows 3.x a nd MS-DOS from Windows 95/98, follow the directions below:
1 Insert the CD-ROM in your computer’s CD-ROM drive.
2 From DOS, type d:\EloDos_W31 to change to the correct directory on the CD-ROM (your
CD-ROM drive may be mapped to a different drive letter).
3 T ype install and press Enter to start the installation.
4 Align the touchscreen.
You must have already completed Steps 1 and 2 before proceeding.
T o run the INST ALL progra m:
1 T ype INSTALL at the DOS prompt in the directory containing the driver install files .
2 INST ALL asks you to select the software to install. Then choose d:\EloDos_W31 from the
displayed list.
3 INST ALL also a sks you for the paths to use during installation, or you may use its defaults.
INST ALL creates directorie s a s necessary, a nd warns you if they exist.
If you are updating your software, you may wish to specify the paths containing the earlier versions,
a nd overwrite the obsolete files. All executable programs are upward compatible. For a list of
differences from ea ch previous version of the drivers, be sure to select "Diff erences from Previous
Versions" during the installation process.
INST ALL updates your AUT OEXEC.BA T file with the drivers you select. INST ALL makes a copy
of your original AUT OEXEC.BAT file, called AUTOEXEC.OLD. If you alrea dy have Elo driver
comma nds in your AUTOEXEC.BAT file, they will be commented out.
When INSTALL is finished, it leaves a file called GO.BAT in the subdirectory you specified. GO
loads the touchscreen driver, runs the calibration program ELOCALIB, and gives you some final
instructions.
If you are using W indows 3.1, you will also calibrate the touchscreen within W indows 3.1 with the
T ouchscreen Control Panel.
8 Elo Touchsystems 1915L User’s Guide
Installing the USB Touch Driver (not applicable to Acoustic Pulse
Recognition monitors)
Installing the USB Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT4.0
1 Insert the Elo CD-ROM in your computer’s CD-ROM drive.
If W indows 98, W indows Me or W indows 2000 starts the Add New Hardware W izard:
2 Choose Next. Select “Search for the best driver for your device (Recommended)” and choose
Next.
3 When a list of search locations is displayed, place a checkmark on “Specify a location” and use
Browse to select the \EloUSB directory on the Elo CD-ROM.
4 Choose Next. Once the Elo USB touchscreen driver has been detected, choose Next again.
5 Y ou will see several files be ing copied. Insert your Windows 98 CD if prompted. Choose Finish.
If Windows 98, W indows Me or Windows 2000 does not start the Add New Hardware Wizard:
NOTE: For Windows 2000 you must have administrator access rights to install the driver.
1 Insert the Elo CD-ROM in your computer’s CD-ROM drive. If the AutoStart f eature for your
CD-ROM drive is active, the system automatically detects the CD and starts the setup program.
2 Follow the directions on the screen to complete the driver setup for your
version of Windows.
If the AutoStart f eature is not a ctive:
1 Click Start > Run.
2 Click the Browse button to locate the EloCd.exe program on the CD-ROM.
3 Click Open, then OK to run EloCd.exe.
4 Follow the directions on the screen to complete the driver setup for your version of Windows.
To install Windows 2000 a nd Windows XP, you must use the "update driver" method; you will not
find a setup.exe file within the download.
9
Installing USB Touch Driver for Acoustic Pulse Recognition Monitors
Insert the ELO APR CD-ROM in your computer’s CD-ROM driver .
Follow the directions on the screen to complete the APR 2.0 driver setup.
1 Click Start > Run.
2 Click the Browse button to locate the SW600117.exe progra m on the CD-ROM.
3 Click Open, then OK to run SW600117.exe.
4 Follow the directions on the screen to complete the driver setup.
10 Elo Touchsystems 1915L User’s Guide
C H A P T E R
3
OPERATION
About Touchmonitor Adjustments
Most likely there will be no need to be adjust your touchmonitor. However, variations in video
output a nd application may require adjustments to optimize display quality.
For best performance, your touchmonitor should be operating in native resolution, that is 1280 x
1024 at 80k-75 Hz. Use the Display control panel in Windows to choose 1280 x 1024 resolution.
Operating in other resolutions will degrade video perf ormance. For further information, please
refer to Appendix A.
All adjustments you make to the controls are automatically me morized. This feature saves you from
having to reset your choices every time you unplug or power your touchmonitor of f and on. If there
is a power failure, your touchmonitor settings will not default to the factory specifications.
11
Front Panel Controls
Control Function
1 Menu/Exit Display/Exits the OSD menus.
2 1. Enter contrast of the OSD.
2. Increase value of the a djustment ite m.
3. Select item.
3 1. Enter brightness adjustment.
2. Decrea se value of the adjustment item.
3. Select item counter-clockwise.
4 Select Selects the adjustment ite ms from the OSD menus.
5 Power Switch Switches the power of the monitor.
12 Elo Touchsystems 1915L User’s Guide
1
2
3
4
5
Controls and Adjustment
OSD Menu Functions
T o Display and Select the OSD Functions:
1 Press the Menu key to activate the OSD menu.
2 Use or to move clockwise or counterclockwise through the menu. Press the Enter key,
the parameter will be highlighted when selected.
3 T o quit the OSD screen at any time during the operation, press the Menu key . If no keys are
pressed for a short time period, the OSD automatically disappears.
NOTE: The OSD screen will disappear if no input activities are detected from 45 seconds to 255
seconds, depending on the setting set on the osd of the monitor . The monitor defaults is 45
seconds.
13
OSD Control Options
Control Description
Brightness Increases or decrease s brightness.
Contrast Increases or decrease s contrast.
H-Position Moves the screen left or right.
V-Position Moves the screen up or down.
Phase Increases or decrease s the snow noise of the image after auto
adjustment is ma de.
Clock The dot clock is fine-adjusted after auto adjust.
Sharpness Adjusts sharpness of video.
OSD H-Position Moves the OSD position horizontally on the screen. When the
button is pressed, the OSD control menu will move to the right
side of the screen. Likewise, when the button is pressed, the
OSD control menu will move to the left side.
OSD V-Position Moves the OSD position vertically on the screen. When the
button is pressed, the OSD control menu will move to the top side
of the screen. Likewise, when the button is pressed, the OSD
control menu will move to the lower side.
OSD T ime Adjusts the amount of the OSD menu is displayed.
Color Balance Press or to select 9300, 6500, 5500, 7500 a nd USER. Only when
selecting USER ca n you make a djustments to the R/G/B content.
Press Enter to restore to factory default setting.
Auto-Adjust Press Auto to ena ble this function. The Auto-Adjust will automatically
adjust V-Position, H-Position, Clock and Clock-Phase.
Recall Defaults Returns the monitor to its default settings.
OSD La nguage Select from English, French, German ,Spanish a nd Japanese.
Information Descri ption Indicates the current resolution, H-Frequency a nd V-Frequency.
14 Elo Touchsystems 1915L User’s Guide
Preset Modes
To reduce the need for adjustment for different modes, the monitor has default setting modes that
are most commonly used as given in the ta ble below . If any of these display modes are detected, the
monitor automatically adjusts the picture size and centering. When none of the mode is matched,
the user can store their preferred modes in the user modes. The monitor is ca pa ble of storing up to
7 user modes. The only condition to store a s a user mode is the new display information must have
1 KHz difference for horizontal frequency or 1 Hz for vertical frequency or the sync signal
polarities are different from the default modes.
H. Freq. Ba nd W idth
Mode Resolution (KHz) (MHz) H V
1 V GA 640x350 70 Hz 31.47 28.322 + -
2 V GA 720x400 70 Hz 31.47 28.322 - +
3 V GA 640x480 60 Hz 31.47 25.175 - -
4 MAC 640x480 66 Hz 35.00 32.24 - -
5 VESA 640x480 72 Hz 37.86 31.5 - -
6 VESA 640x480 75 Hz 37.50 31.5 - -
7 VESA 800x600 56 Hz 35.16 36 + +
8 VESA 800x600 60 Hz 37.88 40 + +
9 VESA 800x600 75 Hz 46.88 49.5 + +
10 VESA 800x600 72 Hz 48.08 5 0 + +
11 MAC 832x624 75 Hz 49.72 57.283 - -
12 VESA 1024x768 60 Hz 48.36 65 - -
13 SUN 1024x768 65 Hz 52.45 70.49 - -
14 VESA 1024x768 70 Hz 56.48 75 - -
15 VESA 1024x768 75 Hz 60.02 78.75 + +
16 SXGA 1280x1024 60 Hz 64 108 + +
17 SXGA 1280x1024 75 Hz 80 135 + +
18 SXGA 1152x864 75 Hz 67.5 1 08 + +
19 SXGA 1280x960 60 Hz 60 108 + +
15
Power Management System
The monitor is equipped with the power ma nagement function which automatically reduces the power
consumption when not in use.
Power
Mode Consumption
On <50W
Sleep <4W
Off <2W
We recommend switching the monitor off when it is not in use for a long time.
NOTE: The monitor automatically goes through the Power Management System (PMS) steps
when it is idle. To release the monitor from PMS state, press any key on the keyboard
or move mouse.
Display Angle
For viewing clarity , you ca n tilt the LCD forward (up to -5 degrees) or backward (up to 90 degrees.)
CAUTION In order to protect the LCD, be sure to hold the base when adjusting the LCD,
and take care not to touch the screen.
16 Elo Touchsystems 1915L User’s Guide
C H A P T E R
4
TROUBLESHOOTING
If you are experiencing trouble with your touchmonitor, refer to the f ollowing ta ble. If the proble m
persists, please contact your local dealer or our service center.
Solutions to Common Problems
Problem Suggestion(s)
The monitor does not respond Check that the monitor’s Power Switch is on.
after you turn on the system. Turn off the power and check the monitor’s power cord
a nd signal ca ble f or proper connection.
Characters on the screen are di m Refer to the About Touchmonitor Adjustments section to
adjust the brightness.
The screen is bla nk During operation, the monitor screen may automatically turn
off as a result of the Power Saving feature. Pre ss any key to see
if the screen reappears.
Refer to the About Touchmonitor Adjustments section to
adjust the brightness.
Screen flashes when initi alized T urn the monitor off then turn it on again.
“Out of Ra nge” display Check to see if the resolution of your computer is higher than
that of the LCD display.
Reconfigure the resolution of your computer to make it less
than or equal to 1280 x 1024. See Appendix A for more information
on resolution.
T ouch doesn’t work M ake sure the touch ca ble is securely atta ched at both ends.
17
18 Elo Touchsystems 1915L User’s Guide
A P P E N D I X
A
NATIVE RESOLUTION
The native resolution of a monitor is the resolution level at which the LCD panel is designed to
perform best. For the LCD touchmonitor, the native resolution is 1280 x 1024 for the 19 inch size.
In almost all cases, screen image s look be st when viewed at the ir native re solution. Y ou can lower
the resolution setting of a monitor but not increase it.
Input Video 19" LCD
640 x 480 (VGA) Transforms input format to 1280 x 1024
800 x 600 (SVGA) Transforms input format to 1280 x 1024
1024 x 768 (XGA) T ransforms input format to 1280 x 1024
1280 x 1024 (SXGA) Displays in native Resolution
The native resolution of an LCD is the actual number of pixels horizontally in the LCD by the
number of pixels vertically in the LCD. LCD resolution is usually represented by the
following symbols:
VGA 640 x 480
SVGA 800 x 600
XGA 1024 x 768
SXGA 1280 x 1024
UXGA 1600 x 1200
19
As a n exa mple, a XGA resolution LCD panel has 1024 pixels horizontally by 768 pixels vertically.
Input video is also represented by the same terms. SXGA input video has a format of 1280 pixels
horizontally by 1024 pixels vertically. When the input pixels contained in the video input format
match the native resolution of the panel, there is a one to one correspondence of mapping of input
video pixels to LCD pixels. As an example, the pixel in column 45 and row 26 of the input video is in
column 45 a nd row 26 of the LCD. For the case when the input video is at a lower re solution tha n the
native resolution of the LCD, the direct correspondence between the video pixels and the LCD
pixels is lost. The LCD controller can compute the correspondence between video pixels and LCD
pixels using algorithms contained on its controller. The accuracy of the algorithms determines the
fidelity of conversion of video pixels to LCD pixels. Poor fidelity conversion can result in artifacts
in the LCD displayed i mage such a s varying width characters.
20 Elo Touchsystems 1915L User’s Guide
A P P E N D I X
B
TOUCHMONITOR SAFETY
This manual contains information that is important for the proper setup and maintenance of your
touchmonitor. Bef ore setting up a nd powering on your new touchmonitor , rea d through this manual,
especially Chapter 2 (Installation), and Chapter 3 (Operation).
1 T o reduce the risk of electric shock, f ollow all saf ety notices and never open the touchmonitor
case.
2 Turn off the product bef ore cleaning.
3 Y our new touchmonitor is equi pped with a 3-wire, grounding power cord. The power cord plug
will only fit into a grounded outlet. Do not atte mpt to fit the plug into an outlet that has not been
configured for this purpose. Do not use a da maged power cord. Use only the power cord that
comes with your touchmonitor . Use of a n unauthorized power cord may invalidate your warranty.
4 The slots located on the sides and top of the touchmonitor case are for ventilation. Do not block
or insert a nything inside the ventilation slots.
5 It is important that your touchmonitor remains dry . Do not pour liquid into or onto your
touchmonitor. If your touchmonitor becomes wet do not attempt to repair it yourself.
21
Care and Handling of Your Touchmonitor
The following tips will help keep your touchmonitor functioning at the opti mal level.
• To avoid risk of electric shock, do not disassemble the brick supply or display unit cabinet. The
unit is not user serviceable. Rem e mber to unplug the display unit from the power outlet bef ore
clea ning.
• Do not use alcohol (methyl, ethyl or isopropyl) or a ny strong solvent. Do not use thinner or
benzene, abrasive cleaners or compressed air.
• To clean the display unit cabinet, use a cloth lightly dampened with a mild detergent.
• Avoid getting liquids inside your touchmonitor . If liquid doe s get inside, have a qualified
service technician check it before you power it on again.
• Do not wipe the screen with anything abrasive that could scratch the surface.
• To clean the touchscreen, use window or glass cleaner . Put the cleaner on a clean cloth and wipe
the touchscreen. Never apply the cleaner directly on the touchscreen.
Warning
This product consists of devices that may contain mercury, which must be recycled or disposed
of in accordance with local, state, or federal laws. (Within this system, the backlight lamps in the
monitor display contain mercury.)
Waste Electrical and Electronic Equipment (WEEE) Directive
In the Europea n U nion, this la bel indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling.
22 Elo Touchsystems 1915L User’s Guide
A P P E N D I X
C
TECHNICAL SPECIFICATIONS
23
Touchmonitor Specifications
Model ET1915L
LCD Display 19” TFT Active Matrix Panel
Display Size 376.32(H) x 301.06(V) mm
Pixel Pitch 0.294(H) x 0.294(V) mm
Display Mode V GA 640 x 350 (70Hz)
V GA 720 x 400 (70Hz)
V G A 640 x 480 (60 / 72/ 75Hz)
SV GA 800 x 600 (56 / 60 / 72/ 75Hz)
XGA 1024 x 768 (60 / 70 / 75Hz)
Max. Resolution SXGA 1280 x 1024 (60 / 70 / 75Hz)
SXGA (1280 x 1024) at 75Hz maxi mum
Contrast Ratio 550 : 1 (typical)
Brightness NonTouch: typical 270 Cd/m2 ; Min 215 Cd/m
2
AccuTouch: typical 221 Cd/m2 ; Min 176 Cd/m
2
IntelliTouch: typical 248 Cd/m2 ; Min 197 Cd/m
2
Acoustic Pulse Recognition:
typical 248 Cd/m2 ; Min 197 Cd/m
2
Response Time Tr: 5.6 ms Tf: 2.4 ms (Typ.)
Display Color 16.2M
Viewing Angle Vertical -60o ~ +75o (Typ.)
Horizontal -70o ~+70o (Typ.)
Input Signal Video R.G.B. Analog 0.7V p-p, 75 ohm
Sync TTL Positive or Negative
Signal Connector Mini D-Sub 15 pin
Front Control Menu, , , Select, Power
OSD Contrast, Brightness, H-Position, V-Position, Sharpness
Color Temperature, Phase, Clock, OSD Time, Recall,
Language: English, French, Germa n, Spanish, Japanese
Plug & Play DDC1 / 2B
Touch Panel (optional) IntelliTouch, AccuT ouch, APR
Power Adapter Input AC 100-240V, 50/60Hz
Operating Conditions Temperature 0oC ~ 40oC (32oF ~ 104oF)
Humidity 20% ~ 80% (No Condensation)
Altitude T o 12,000 Feet
Storage Conditions Temperature -20oC ~ 60oC (-4oF ~ 140oF)
Humidity 10% ~ 90% (No Condensation)
Dimensions (HxWxD) 429 x 390 x 212mm
Weight (Net) 8.4Kg
Certifications UL, C-UL, FCC-B, CE, VCCI, C-Tick, MPRII , TUV,
EK, MIC
24 Elo Touchsystems 1915L User’s Guide
19” LCD Touchmonitor (ET1915L) Dimensions
25
26 Elo Touchsystems 1915L User’s Guide
REGULATORY INFORMATION
I. Electrical Safety Information:
A) Complia nce is required with re spect to the voltage, frequency, and current requirements
indicated on the manufa cturer’s label. Connection to a different power source than those
specified herein will likely result in improper operation, da mage to the equi pment or pose a fire
hazard if the limitations are not followed.
B) There are no operator serviceable parts inside this equi pment. There are hazardous voltage s
generated by this equipment which constitute a safety hazard. Service should be provided only
by a qualified service technicia n.
C) This equipment is provided with a deta cha ble power cord which ha s a n integral saf ety ground
wire intended for connection to a grounded safety outlet.
1) Do not substitute the cord with other than the provided approved type. Under no
circumsta nces use an adapter plug to connect to a 2-wire outlet a s this will defeat the
continuity of the grounding wire.
2) The equipment requires the use of the ground wire a s a part of the saf ety certification,
modification or misuse ca n provide a shock hazard that can result in serious injury or
death.
3) Contact a qualified electrici an or the manufacturer if there are questions about the
installation prior to connecting the equipment to mains power .
II. Emissions and Immunity Information
A) Notice to Users in the U nited States: This equi pment has been tested a nd f ound to comply
with the limits for a Cla ss B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasona ble protection against harmful interference in a residential installation.
This equipment generates, uses, and ca n ra di ate radio frequency energy , and if not installed a nd
used in accordance with the instructions, may cause harmful interference to radio
communications.
B) Notice to Users in Canada: This equipment complie s with the Cla ss B li mits f or radio noise
emissions from digital apparatus a s established by the Ra dio Interf erence Regulations of Industrie
Cana da.
C) Notice to Users in the European Union: Use only the provided power cords and
interconnecting cabling provided with the equipment. Substitution of provided cords and cabling
may compromise electrical safety or CE Mark Certification for emissions or immunity as
required by the following sta ndards:
This Information T echnology Equipment (ITE) is required to have a CE M ark on the manufa cturer’s
label which mea ns that the equi pment ha s been tested to the f ollowing Directives and Sta ndards:
This equipment has been tested to the require ments f or the CE M ark a s required by EMC
Directive 89/336/EEC indicated in European Standard EN 55022 Class B and the Low Volt
age Directive 73/23/EEC as indicated in European Standard EN 60950.
D) General Information to all Users: This equipment generates, uses and can radiate radio
frequency energy . If not installed and used according to this manual the equi pment may cause
interference with ra dio and television communications. There is, however, no guarantee that
interference will not occur in a ny particular installation due to site-specific factors.
1) In order to meet emission and immunity requirements, the user must observe the following:
a) Use only the provided I/O cables to connect this digital device with any computer.
b) T o ensure compli ance, use only the provided ma nufacturer’s a pproved line cord.
c) The user is cautioned that changes or modifications to the equipment not expressly
approved by the party responsible for compli ance could void the user’s authority to operate
the equipment.
2) If this equipment a ppears to cause interference with radio or television reception, or any other
device:
a) Verify as an emission source by turning the equipment off and on.
b) If you determine that this equipment is causing the interference, try to correct the
interference by using one or more of the following measures:
i) Move the digital device away from the affected receiver.
ii) Reposition (turn) the digital device with respect to the af fected receiver.
iii) Reorient the affected receiver’s antenna.
iv) Plug the digital device into a different AC outlet so the digital device and the
receiver are on different branch circuits.
v) Disconnect and remove any I/O ca bles that the digital device doe s not use.
(Unterminated I/O cable s are a potenti al source of high RF e mission levels.)
vi) Plug the digital device into only a grounded outlet receptacle. Do not use AC
ada pter plugs. (Re moving or cutting the line cord ground may increa se RF emission
levels a nd may also present a lethal shock hazard to the user.)
If you need additional help, consult your dealer , manufacturer, or a n experienced radio or television
technician.
27
III. Agency Certifications
The following certifications have been issued for this monitor:
• North America/Worldwide: USA UL, Canada cUL
• EMEA: Germany TUV, Sweden MPRII
• Asia: Australia C-Tick, China CCC, Japan VCCI, Korea MIC
Taiwan BSMI
• Elo Declarations: RoHS, China RoHS, WEEE, IMERC, CE, FCC/ICES Class B
28 Elo Touchsystems 1915L User’s Guide
WARRANTY
Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warra nts
to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the
touchmonitors and components of the product is 3 (three) years.
Seller makes no warra nty regarding the model life of components. Seller’s suppliers may at a ny ti me
and from time to time make cha nge s in the components delivered a s Products or components.
Buyer shall notify Seller in writing promptly (a nd in no case later tha n thirty (30) days after discovery)
of the failure of a ny Product to conf orm to the warranty set forth above; shall describe in commercially rea sona ble detail in such notice the symptoms a ssoci ated with such failure; and shall provide
to Seller the opportunity to inspect such Products as installed, if possible. The notice must be received by Seller during the Warranty Period for such product, unless otherwise directed in writing
by the Seller. W ithin thirty (30) days after submitting such notice, Buyer shall package the allegedly
defective Product in its original shipping carton(s) or a functional equivalent and shall ship to Seller
at Buyer’s expense a nd risk.
Within a rea sonable time after receipt of the allegedly def ective Product and verification by Seller
that the Product fails to meet the warranty set forth above, Seller shall correct such failure by, at
Seller’s options, either (i) modifying or repairing the Product or (ii) replacing the Product. Such
modification, repair, or replacement and the return shipment of the Product with minimum insur a nce to Buyer shall be at Seller’s expense. Buyer shall bear the risk of loss or da mage in transit, an d
may insure the Product. Buyer shall reimburse Seller for transportation cost incurred for Product
returned but not found by Seller to be defective. Modification or repair, of Products may, at Seller’s
option, take place either at Seller’s facilities or at Buyer’s premises. If Seller is unable to modify,
repair, or repla ce a Product to conf orm to the warranty set forth above, then Seller shall, at Seller’s
option, either refund to Buyer or credit to Buyer’s account the purchase price of the Product less
depreciation calculated on a straight-line basis over Seller’s stated W arranty Period.
29
I N D E X - 30
INDEX
A
About the Product, 2
About Touchmonitor Adjustments, 17
B
Brightness, 17
C
Care and Handling of Your Touchmonitor, 22
Certifications, 24
Contrast Ratio, 24
Controls and Adjustment, 13
D
Dimensions (HxWxD), 25
Display Angle, 16
Display Color, 24
Display Mode, 24
Display Size, 24
F
Front Control, 24
Front Panel Controls, 12
I
Input Signal, 24
Installing USB Touch Driver for Acoustic
Pulse Recognition , 10
Installation and Setup, 3
Installing the Driver Software, 6
Installing the Serial Touch Driver, 7
Installing the Serial Touch Driver for MS-DOS and
Windows 3.1, 8
Installing the Serial Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT 4.0, 7
Installing the USB Touch Driver, 9
Installing the USB Touch Driver for Windows XP,
Windows 2000, Me, 95/98 and NT 4.0, 7
M
Main Unit, 5
Max. Resolution, 24
N
Native Resolution, 19
O
Operating Conditions, 24
OSD, 24
OSD Control Options, 14
OSD Menu Functions, 13
P
Pixel Pitch, 24
Plug & Play, 24
Power Adapter , 24
Power Management System, 16
Precautions, 1
Product Description, 1
Product Overview, 5
I N D E X - 31
R
Rear View, 5
Response Time, 24
S
Signal Connector, 24
Solutions to Common Problems, 17
Storage Conditions, 24
SVGA, 24
SXGA, 24
T
Technical Specifications, 23
Touch Interface Connection, 4
Touch Panel (optional), 24
Touchmonitor Safety, 21
Touchmonitor Specifications, 23
Troubleshooting, 17
U
Unpacking Your Touchmonitor, 3
UXGA, 19
V
VGA, 24
Viewing Angle, 24
W
Warranty, 29
Weight (Net), 24
X
XGA, 24
Check out Elo’s Web site!
www.elotouch.com
Get the latest...
• Product information
• Specifications
• News on upcoming events
• Press release
• Software drivers
• Touchmonitor Newsletter
Getting in Touch with Elo
To find out more about Elo’s extensive range of touch solutions, visit our Web site at www.elotouch.com or simply call the office
nearest you:
North America Germany Belgium Asian-Pacific
Elo TouchSystems Tyco Electronics Raychem GmbH Tyco Electronics Raychem GmbH Sun Homada Bldg. 2F
301 Constitution Drive, (Elo TouchSystems Division) (Elo TouchSystems Division) 1-19-20 Shin-Yokohama
Menlo Park, CA 94025 Finsinger Feld 1 Diestsesteenweg 692 Kanagawa 222-0033
USA D-85521 Ottobrunn B-3010 Kessel-Lo Japan
Germany Belgium
(800) ELO-TOUCH
(800-356-8682) Tel +49(0)(89)60822-0 Tel +32(0)(16)35-2100 Tel +81(45)478-2161
Tel 650-361-4800 Fax +49(0)(89)60822-180 Fax +32(o)(16)35-2101 Fax +81(45)478-2180
Fax 650-361-4722 elosales@elotouch.com elosales@elotouch.com www.tps.co.jp
eloinfo@elotouch.com
Loading...
