Crepe Maker User Manual
Crepe Maker
User Manual
1
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Crepe Maker User Manual
Thank you for purchasing this range of appliance of our company. Proper attention to
preventative maintenance and scheduled maintenance procedures will prolong the life
of the appliance.
Warning:
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this appliance.
1. General Information
Contents
For your safety
Do not store gas oline or other flammable liquid s in the vicinity of this or any ot her
appliance.
WARNING: FIRE HAZARD
The area where t he appliance is i nstalled must be kept clear of combustibles and
flammables. This includes mops , rags, grease, wrapping paper and electrical cords.
Warning
Electrical Grou n d ing Instructions
This appliance i s equipped wi th a three-prong ( grounding) plug for your protect ion against
shock hazard and s hould be plugged directly int o a properly groun ded three-prong
receptacle. Do not cut or remove the groundin g prong from this pl ug. If the output exceeds
a certain value, the plug will not be used. Connect the wire to a suitable air swit ch.
Notice
This appliance i s designed for us e in non-combus tible locations only. Install the appliance
on a firm, level , non-combustible surface.
For servicing, a clearance of 6 inches (15cm) f rom rear of the appli ance to wall shoul d be
kept.
2
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Crepe Maker User Manual
1. General information
1.1 Information about the user’s manual
1.2 Other regulations
1.3 Note
2. Safety
2.1 General information
2.2 Safety instructions for the commercial use of the device
2.3 Intended use
3. Packaging and storage
3.1 Packaging
3.2 Storage
4. Technical data
5. Installation and operation
5.1 Safety instructions
5.2 Installation and connection
5.3 Operation
6. Transportation, Cleaning and maintenance
6.1Transportation
6.2 Safety advice
6.3 Cleaning
6.4 Safety instructions for maintenance
7. Waste disposal
8. Circuit diagram
9. Daily checking
1. General information
1.1 Information about the instruction manual
This instruction manual contains information about the installation, operation and
maintenance of the appliance and should be consulted as an important source of
information and reference guide. Awareness of the safety instructions and instructions
for use in this manual will ensure the safe and correct use of the appliance.
In addition to the information given here, you should comply with any local Health and
Safety Controls and generally applicable safety regulations. The instruction manual
forms part of the product and should be kept near the appliance and easily accessible
for anyone carrying out the installation, servicing, and maintenance or cleaning.
1.2 Other regulations
In addition to the information given here, you should comply with any local Health and
Safety Controls and generally applicable safety regulations. The instruction manual
forms part of the product and should be kept near the appliance and easily accessible
for anyone carrying out the installation, servicing, and maintenance or cleaning.
1.3 Note
NOTE! Read the instruction manual carefully before using the appliance. The user’s
3
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Crepe Maker User Manual
manual should be kept near the appliance, easily accessible for anyone to operate the
unit. We reserve the right to make technical changes for purposes of developing and
improving the useful properties.
2. Safety
This section provides an overview of all important safety aspects.
Attention should be paid to all symbols, markers and labels on the device, which must
be kept in a permanent state of legibility. By following all the important safety advice
you gain an optimal protection against all hazards as well as the assurance of a safe and
trouble-free operation.
2.1 General Information
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled or operated improperly
and inappropriately. Knowing the contents of the user’s manual as well as avoiding
mistakes and thus operating this device safely and in a fault-free manner is very
essential to protect yourselves from the hazards. To prevent hazards and to ensure
optimum efficiency, no modifications or alterations to the device that are not explicitly
approved by the manufacturer can be undertaken. This device may only be operated in
safe condition following the user’s manual.
2.2 Safety instructions for the commercial use of the device
The appliance is intended for commercial use only, and should never be used for
purposes other than stated above. The regional territorial provisions must be complied
with. Besides the industrial safety instructions in the instruction manual, the general
safety and accident prevention regulations as well as environment protection
regulations applicable for area of application of the device must be followed and
complied with.
The device should be never left unattended during operation. Special attention should
be paid to when the unit is in use, if the children are near the appliance.
This manual is considered to be a permanent part of the appliance. Preserve this
manual safely for the reference of operators. When passing on/selling the device to a
third party, the manual must be handed over along with the device.
Every person using the unit must act in accordance to the manuals and under
consideration of the safety advice.
Never use the unit outdoors.
2.3 Intended use
CAUTION! Any use other than intended purpose is forbidden and is not considered as
conventional.
3. Packaging and storage
3.1Packaging
Please do not throw away the packing materials as they might be useful for storage
4
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Crepe Maker User Manual
purposes, when moving or, in case of damages, when the unit must be sent back for
repair. The outer and inner packing material should be removed completely from the
device before installation.
NOTE! Some of the packing materials are re-usable.
3.2 Storage
Do not open the packages until installation. Pay attention to the markings on the carton
surface. Do as the markings indicate. Do not put the whole appliance with the carton
upside down. Care should be taken when moving the appliance. Do not store outdoors.
Keep it dry and dust-free and had better be put in a well-ventilated area. Do not expose
it to aggressive media. Do not expose it to direct sunlight. Avoid mechanical shocks and
vibration. In case of longer storage (> 3 months), make sure you check the state of the
packaging regularly.
4. Technical data
Model
Voltage (V)
Frequency (Hz)
Power Input (W)
Dimension (mm)
TT-E8
220~240
50/60
3000
450×485×240
TT-E9
220~240
50/60
6000
860×485×240
TT-E7
220~240
50/60
3000
400(D)x200
5. Installation and operation
5.1 Safety instructions
WARNING!
Electrical hazard!
The appliance s hould be connected to a suitab l e power receptac l e. The outside body
should be earthed properly. Never yank or pull the power cord viol ently to disconnect from
outlet. Touch of power cord with any hot parts is absolut ely forbidden.
WARNING!
Danger of burning!
During operation, hot plate of the appliance may be very hot. Try to avoid getting burnt and
never touch any hot parts without gloves on.
5
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Crepe Maker User Manual
● Note that the power cord should never touch any heat sources or sharp edges.
Never let the power cord dangle over the counter edge.
● Stop using the appliance immediately if malfunctions of the unit occur. Unplug the
appliance.
● Do not use any accessory or spare parts that have not been recommended or
designated by the manufacturer. This can pose a danger for the user or lead to
damages of the appliance or personal injury.
● Do not lay the power cord over carpets or heat insulations. Do not cover it with any
other objects. Keep away the power cord from operating range and do not immerse it
into water.
● Never touch the power cord, plug or the switch when your hands are wet.
● Do not leave the unit unattended during operation.
● Never move or reposition the unit until the unit cools down completely.
● WARNING! Hazard via electrical current! Make sure that the voltage of local power
supply matches that of the naming plate.
● Behind the housing, there is a copper-material equipotential terminal. The cross
section area of the connecting wire should not be lower than 1.5mm2 .
● The hot plate may be quite hot during operation. Keep your hands off the hot plate.
5.2 Installation and connection
ATTENTION!
The installation of the unit must be performed by a qualified technician only. Place the
device on top of a solid, even, safe and stable surface that tolerates the weight. Level it
back and forth. Then level it side to side.
Not at any time should you place the appliance on top of an inflammable surface (such
as: table cloth, carpet, etc.).
You must not locate the appliance near open fireplaces, electric ovens, electric heaters
or other heat sources.
Position the device appropriately so that the plug is always accessible.
Make sure liquids enter neither the electrical system nor the switch. Dry off the device
thoroughly!
5.3 Operating
ATTENTION!
The operation of the device may only be carried out by personnel that have been
instructed in operation of the device
Connect the wire to suitable power supply. The maximum temperature is 300℃. Rotate
the thermostat knob clockwise to the desired temperature scale. The unit would heat up
gradually. When the set temperature has been reached, the power supply would be cut
off automatically. When the temperature is lower than its set value, the heating function
would resume.
When a day’s work has been finished, rotate the thermostat knob anti-clockwise to its
original starting position. Shut the power supply off. If something unusual occurs, you
had better call a qualified technician for repair.
6
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Crepe Maker User Manual
6. Transportation, Cleaning and maintenance
6.1 Transportation
In the process of transportation, the appliance should be handled carefully, preventing
the intense shaking. The packaged appliance should be stored in a well-ventilated area
free of caustic air. It cannot be placed in the outside area and should never be put
upside down. Keep it dry and dust-free. Do not expose it to direct sunlight. Avoid
mechanical shocks and vibrations. If it is for temporary storage, the weather-proof
method should be taken.
6.2 Safety advice
Before starting repair or cleaning works, make sure the unit has been disconnected
from power socket (pull off the power plug!!!) and has cooled down completely.
Do not use any acid or abrasive detergents and make sure no water runs into the
internal part of the unit.
To protect yourself from electric shock, never immerse the unit, the power cord and the
plug in water or other liquids.
CAUTION! The appliance is not jet-proofed. Therefore, you must not use any kind of
pressure water jet for cleaning it!
6.3 Cleaning
The device should be cleaned regularly.
Pull the power plug and cut off the power cord before cleaning. Make sure it does not
touch any hot or wet areas. Damage will be done to the power cord.
Let the unit cool down completely.
CAUTION!
Do not use any water to clean the control panel. Thereby, ensure no water inside the
unit. Thoroughly dry off the unit before operating the unit again!
Control panel, surface of the device and power cord should only be wiped off with a
piece of soft cloth dipping a mild cleaning detergent solution. You must not let water
enter the switching unit. This may lead to dangerous leakage current and malfunctions
of the appliance.
Do not use any aggressive cleaning agents or abrasive materials as these could damage
the protecting film of the stainless steel and leave the iron particles on the surface of
the unit, which can cause rust.
All parts must be dried thoroughly and reassemble the parts of unit, which have been
dismantled for cleaning.
Do not use a water jet to clean the unit. The unit has not been weather-proofed.
Store the device in a dry and ventilated place if the unit stays idle for a long time. Keep
it away from acid steams and caustic gases.
6.4 Safety instructions for maintenance
●Check the power cord for damage periodically. Never operate the unit when the
power cord has been damaged or broken. If the power cord shows the above signs, call
a qualified electrician for replacement. It is highly recommended that the replaced
power cord should be the special type designated by the manufacturer. Damage may be
7
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Crepe Maker User Manual
done to the whole unit and its internal wire if the wrong type of power cord has been
used for replacement.
●Only qualified electrician or personnel may perform the repair of the unit. All the
necessary replaced parts have to be the types designated by the manufacturer. Never
attempt to repair the unit on your own. Danger may occur if failed to do so.
7. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance to
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit for use
before disposal. For that purpose disconnect device from mains supply and remove
mains connection cable from the device.
NOTE!
For the disposal of the device please consider and act according to the national and
local rules and regulations.
8. Circuit diagram
9. Daily checking
Check the appliance before and after use. Before using, make sure the appliance dose not lean. Be
certain that the power cord is not worn out or broken. When in use, make sure no unpleasant smell
is present and there is no any unusual noise.
This manual must be read and understood by all persons using or installing this appliance. Contact
8
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Crepe Maker User Manual
your local dealer if you have any questions concerning installation, operation or maintenance of this
equipment.
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the owner or
manager of the hotel or restaurant, or to the person responsible for training operators
of this appliance. It should be retained for future reference. Additional manuals are
available from your local dealer.
9
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Loading...
