twisted electrons cells User Manual

user’s manual

Feed it, play it, sequence it

Thanks for adopting Cells!

Cells is a dual unipolar control voltage generator. Each of the 16 touch sensitive pads
can be “fed” two 12bit values (semi-tone quantized or free scale), ranging from 0V to 5V

Although intended to be used as a duo-phonic instrument/sequencer, Cells can also be
used to modulate filters, amps, anything with a cv input

Feed It

-Tap a pad to select it

-Hold a tune button to engage the “feeding process” (left button for channel 1, right for
channel 2).

-Adjust a knob to the desired pitch (left knob for channel 1, right for channel 2).
So long as a tune button is held, the output is automatically changed as you move the
knob

-Release the button, pitch information is stored to Eeprom

You can toggle between free scaling and semi-tone increment modes by pressing both
tune buttons simultaneously.

Play It

Press a pad to trigger both gate and cv outputs
Hold 2 or more pads and Cells will arpeggiate, the rate can now be changed with the left
knob. The right knob changes the octave range.

Sequence It

Sequence the cells using the and trigger inputs.

The input shifts up a row and the input shifts right by one column

The gate outputs mirror the trigger inputs.
