FOCUS
FOCUS+T
Instruction Manual
TweakHearing.com
A sound amplifier for people who are not ready for a hearing aid.
®
Congratulations on your purchase
of Tweak®, a personal sound
amplification product (PSAP) using
innovative, patented technology.
This unique device allows you to
select and set the sound ‘profile’
that you like best, from a range of
acoustic alternatives.
Tweak can help you hear better
in group settings, restaurants,
theaters, meetings, and other
situations where you have
difficulty hearing.
Please read this manual for
complete set-up and operating
instructions before using your
new sound amplifier.
FOCUS+T FOCUS
TweakHearing.com
FEATURE BENEFIT
Slim profiile case, with thin
tube coupling to the ear
Comfortable fit, barely visible, and no
barrel effect
Sophisticated, innovative,
patented technology
More freedom than ever before,
allowing you to choose your listening
preference
Cutting-edge automatic
feedback control
Minimizes ‘whistling’ while allowing the
ear canal to remain open
Fast-acting soundactivated compression
Improves audibility of soft sounds and
softens sudden loud sounds
Digital volume control For subtle volume changes within your
amplification profile
Preset 12 band graphic
equalizer
Finely adjusted tuning curves,
providing smooth, natural sound, with
amplification only where you need it
Low battery tone indicator Early warning system so you have time
to change the battery before it quits
Uses #312 battery Powerful, yet small and economical
Average battery life: 5 to 7 days
Quiet mode “All-around sound,” for quiet
environments
Directional mode Focused hearing reduces background
noise and clatter in noisy environments.
Telecoil mode (Focus+T model only) For better
hearing on the phone and in looped
environments
Dual microphones Two microphones work together to
provide true directionality
Push-button access to
two listening modes:
Quiet and Noise
Allows you to quickly and easily
customize your listening preferences
depending on your situation
Push-button access to
three listening modes:
Quiet, Noise, and Telecoil
Contents
6 General Description
8 Components
9 Battery Information
10 Preparing for Use
11 Inserting a Battery
12 Wearing Your Tweak
13 Set-Up FOCUS Model
15 Set-Up FOCUS+T Model
17 Daily Use
18 Caring for Your Tweak
22 Troubleshooting Tips
25 How to Reset
26 Warranty and Owner Information
7
6 General Description
Tweak comes in two models: Tweak Focus and Tweak
Focus+T.
General Description
Tweak Focus has two listening
modes: omni-directional (for quiet
environments) and directional (for
noisy environments). The noise
mode suppresses background
noise, allowing you to focus on
sounds coming from a particular
direction.
Tweak Focus+T has everything the
Focus model has, plus a telecoil
for use with telephone or loop
systems. It has three modes: omnidirectional, directional, and telecoil.
The rocker switch is used during
initial set up to try out and then lock
in your desired amplification setting
that becomes your amplification
‘profile’, and it stays with you as
you switch between Quiet, Noise
and Telecoil modes. You can still
fine tune it using the rocker switch
volume control.
The program button is used to
switch between listening modes for
Quiet, Noise, and Telecoil.
During set-up you’ll learn how to position the Tweak
on your ear and how to pick your favorite amplification
setting. Your Tweak package includes:
2 Small Tubes (Right and Left) with Sleeve Tips
pre-installed
1 Large Vented Dome Tip
1 Large Closed Dome Tip
The thin tube delivers amp lified sound from Tweak into your ear. It
is important fo r the sound tube and tip to fit properly in your ear.
If you need a different size tip or tube, call 1-888-815-3240 or visit
TweakHeari ng.com to purchase the a ppropriate size.
FOCUS FOCUS+T
QUIET BEEP
n n
NOISE NOISE BURST (Shhhh)
n n
T-COIL DIAL TONE
n
OMNI-DIRECTIONAL
(all-around sound)
OMNI
QUIET
DIRECTIONAL
(focused listening)
FOCUS
NOISE
HEARING LOOP
(for telephone
or loop systems)
TELECOIL
Battery Information 9
8 Components
Components
Battery Information
Included COMPONENTS
Tweak uses a commonly available 312 zinc air battery. With
normal full-time use, the battery will last approximately
five to seven days.
When the battery is depleted, remove and replace it
immediately. When not in use, be sure to turn off your
Tweak by opening the battery door part way.
Low Battery Warning
For your convenience, Tweak warns you when the battery
is almost depleted. You will hear three sets of double
beeps every 10 minutes, which indicates it’s time to
change the battery. Once the voltage drops below 0.95V,
Tweak emits six sets of double beeps, then shuts down.
IMPORTANT —
Always discard used ba tteries.
Small ba tteries can be harmful if
swallowed. Keep ba tteries out of
reach of pe ts and small children.
In case of ingestion, seek medical
atten tion immediately and
call (collect, if necessary) the
National Battery Ingestion
Hotline at 20 2-625-3333. For
more info visit www.poison.org/
batter y
VENTED DOME CLOSED DOME
SLEEVE
pre-installed on tube
CLEANING LINE
1 RETAINING LOCK
2 TIP (sleeve or dome)
See illustrations below.
3 THIN TUBE (for sound)
4 TUBE CONNECTOR HEAD
5 MICROPHONES
6 PROGRAM BUTTON
2
1
3
4
5
6
8
9
7
TWO THIN TUBES (Size 1), LEFT and RIGHT
7 ROCKER SWITCH /
VOLUME CONTROL
8 AMPLIFIER CASE
9 BATTERY COMPARTMENT
DOOR Tweak is turned o
by opening the battery
compartment door par t way.
Inserting a Battery 11
10 Preparing for Use
Your Tweak package includes
two thin tubes, left and right,
with sleeve tips already installed.
Text code near the tip represents
the length of tube (1=small)
and which ear. B=Blue=Left.
R=Red=Right.
1 Lift the notch at the
edge of the battery
compartment and swivel
open the door of the
battery compartment.
2 Remove the brown-
colored tab on a new
battery (size 312). Insert the
battery with the positive
“+” side facing up.
Notice the “+” on the edge
of the battery door to
assist you in finding the
proper orientation.
3 Gently close the battery
door. It should close easily;
do not force the door
closed.
If resistance is experienced
while closing the battery door,
make sure the battery is inserted
properly. When the battery door is
Preparing for Use Inserting a Battery
If you want more bass sound, remove the sleeve tip and
attach one of the dome tips instead. The tips simply pull
straight off. If you change the tip, be sure it is securely
fastened to the sound tube before inserting it in your ear.
Connecting the Tube
to the Case
Choose left or right tube. Align
the tube connector end with the
end of the case, then push the
tube straight onto the sound post
until it snaps into place.
ON–When the battery door is completely closed, your Tweak is on.
OFF–To turn of f your Tweak, open the batter y door part way.
completely closed, your Tweak is ready for operation.
VENTED DOME
CLOSED DOME
TWO THIN TUBES (Size 1), LEFT and RIGHT
Tweak is packaged with sleeve tips
already installed on the tubes.
FIGURE 1
FIGURE 2
FIGURE 3
FIGURE 4
FIGURE 5
Tweak FOCUS Set-up 13
12 Wearing Your Tweak
Wearing Your Tweak Tweak FOCUS Set-up
Place the Tweak over your ear.
Grab the loose end of the tubing
and gently insert the tip into the
ear canal. Position the retaining
lock in the bowl of the ear.
When properly inserted, the
tubing will lay close to the head
around the front of the ear and
into the canal. You can check this
by moving your finger down the
tubing, into the ear. Using a mirror at first may be helpful
to properly position Tweak.
If the loose end doesn’t stay in your ear, you may need a
different length thin tube. Additional sizes are available at
TweakHearing.com or by calling 1-888-815-3240.
Tweak Focus (For Focus+T model, see page 15)
Selecting Your Amplification Setting
With a fresh battery in your Tweak and while wearing the
Tweak, you are ready to choose an amplification setting.
Start out in a relatively quiet environment. The first time
you turn Tweak on, it will be at the lowest amplification
setting. How does it sound?
To try the next level of
amplification, press and
release the upper portion
of the rocker switch. You
will hear two beeps,
indicating you are now in
Amplification Setting 2.
How does it sound?
Press and release the upper
portion of the rocker switch
again and you’ll hear 3
beeps. This is the loudest option. You can use the rocker
switch to go back through the settings. The beeps will tell
you where you are.
Once you’ve decided which setting you like best, lock
it in by pressing and HOLDING the rocker switch for six
seconds, until you hear one long beep.
Insert tip
in your
ear canal.
RETAINING
LOCK
ROCKER
SWITCH
PROGRAM
BUTTON
UPPER
PORTION
LOWER
PORTION
FIGURE 6
FIGURE 7
Tweak FOCUS+T Set-up 15
14 Tweak FOCUS Set-up
Congratulations! From now on, Tweak remembers your
preferred amplification setting. Every time you turn on
your Tweak it will start out at the amplification profile you
just locked in.
From this point forward, you have two listening modes.
Every time you turn on your Tweak it will start in the Quiet
mode. Use the program button to switch between Quiet
and Noise modes.
Tweak FOCUS S et-up continued
To change modes:
Press and hold the
program button for one
second. Once you release
NOTE:
If you decide later that you want to reset your Tweak to a
different amplification profile, see page 25.
Tweak FOCUS+T Set-up
Tweak Focus+T (For Focus model, see page 13)
Selecting Your Amplification Setting
With a fresh battery in your Tweak and while wearing the
Tweak, you are ready to choose an amplification setting.
Start out in a relatively quiet environment. The first time
you turn Tweak on, it will be at the lowest amplification
setting. How does it sound?
To try the next level of
amplification, press and
release the upper portion
of the rocker switch. You
will hear two beeps,
indicating you are now in
Amplification Setting 2.
How does it sound?
Press and release the upper
portion of the rocker switch
again and you’ll hear 3
beeps. This is the loudest option. You can use the rocker
switch to go back through the settings. The beeps will tell
you where you are.
Once you’ve decided which setting you like best, lock
it in by pressing and HOLDING the rocker switch for six
seconds, until you hear one long beep.
the button, you will hear a special sound that indicates
which mode or “program” you have just entered. Quiet
program–you will hear a beep. Noise program–you will
hear a “shhhh” sound.
Fine-tuning Your Tweak with the Volume Control
In both listening modes you can still make minor adjustments
to the volume by simply tapping the rocker switch.
To increase volume: tap the upper portion of the rocker
switch.
To decrease volume: tap the lower portion of the rocker
switch.
QUIET BEEP
NOISE NOISE BURST (Shhhh)
FOCUS model
ROCKER
SWITCH
PROGRAM
BUTTON
UPPER
PORTION
LOWER
PORTION
FIGURE 8
Daily Use 17
16 Tweak FOCUS+T Set-up
Congratulations! From now on, Tweak remembers your
preferred amplification setting. Every time you turn on
your Tweak it will start out at the amplification profile you
just locked in.
From this point forward, you have three listening modes.
Every time you turn on your Tweak it will start in the Quiet
mode. Use the program button to switch between Quiet,
Noise, and Telecoil modes.
Tweak FOCUS +T Set- up continued
QUIET BEEP
NOISE NOISE BURST (Shhhh)
T-COIL DIAL TONE
FOCUS+T model
Daily Use (Focus and Focus+T)
To change modes:
Press and hold the
program button for one
second. Once you release
the button, you will hear a
ON When the battery door is completely closed, your Tweak is
on.
OFF Open the battery door part way to turn off your Tweak.
Tweak Focus: You have two listening modes
available – Quiet and Noise. To switch
between Quiet and Noise programs, press
and hold the program button for ONE (1)
second. Once you release it you will hear a
confirmation tone: a single beep for Quiet,
“Shhh” for Noise. In either program, you can
still adjust the volume by quickly tapping the
rocker switch.
Tweak Focus+T: You have three listening modes
available – Quiet, Noise, and Telecoil. To
switch between Quiet, Noise, and Telecoil
programs, press and hold the program
button for ONE (1) second. Once you release
it you will hear a confirmation tone: a single
beep for Quiet, “Shhh” for Noise, dial tone
for Telecoil. In all three programs, you can still
adjust the volume by quickly tapping the rocker
switch.
IMPORTANT:
To extend the battery life, turn off your Tweak by openi ng the
battery door wheneve r the device is not in use.
Be sure to keep your Tweak dry at all times. See page 21 for
additional tips on caring for your Tweak.
special sound that indicates which mode or “program” you
have just entered. Quiet program–you will hear a beep.
Noise program–you will hear a “shhhh” sound. Telecoil
program–you will hear a dial tone.
Fine-tuning Your Tweak with the Volume Control
In all three listening modes you can still make minor adjustments to
the volume by simply tapping the rocker switch.
To increase volume: tap the upper portion of the rocker
switch.
To decrease volume: tap the lower portion of the rocker
switch.
NOTE:
If you decide later that you want to reset your Tweak to a
different amplification profile, see page 25.
19
18 Caring for Your Tweak
Caring for Your Tweak
The following instructions will assist in extending the life
of your Tweak amplifier.
Cleaning the Exterior
You should inspect and clean your Tweak every day. To
clean, gently wipe the surface with a soft, dry cloth or a
moist non-alcohol disinfecting wipe. Do not allow water
or liquid to enter any openings.
The most common causes of amplifier problems are
moisture and wax. The daily use of a Dry & Store®
appliance is recommended to reduce moisture and wax
buildup. Dry & Store products may be purchased
at www.dryandstore.com.
Re-attach the tube by aligning the tube connector end
with the end of the amplifier case, then push the
connector straight onto the sound post until it snaps into
place. There is no need to rotate the tube when
re-attaching.
Do not rinse or submerge these parts in water. There is
a risk of damage if a water drop becomes trapped in
the tube. If this should occur, it will prevent sound from
coming through the tube and may be harmful to Tweak’s
electronics.
Cleaning the Tip and Tube
Remove the tube from the case
by twisting the tube connector at
least 45° then pulling it off.
Wipe the exterior of the tube
and tip. Use the cleaning line
provided to clean the tube and
tip, by pushing the cleaning line
through the tube.
(Insert the cleaning line at the
connector end where the tube
attaches to the amplifier case
and push out through the tip.)
IMPORTANT:
Do not use cleaning line while tube is a ttached to device.
Tube must be detached from the instrument before cleaning.
Changing the Tube and Tip
The tube and tip should be changed periodically, typically
2 or 3 times per year. When the tube or tip become soft,
discolored, kinked, or damaged, obtain replacements by
calling 1-888-815-3240 or visiting
TweakHearing.com
When you change the tip, make sure it is securely fastened
to the sound tube before inserting it in your ear.
CLEANING LINE
FIGURE 9
FIGURE 10
DO
DON’T
21
20 Caring for Your Tweak
Caring for Your Tweak continued
* Drying appliances by Dry & Store include the Global II, Zephyr,
DryDome,® or DryCaddy.®
Extended Storage
If it is necessary to store your Tweak amplifiers for an
extended amount of time, follow these steps:
Remove the batteries. Clean your Tweak according
to instructions in this manual. A full cycle in a drying
appliance* by Dry & Store® is recommended prior to
extended storage. Place Tweak in an airtight container
with a desiccant such as a Dry-Brik® or DryCaddy® disc.
Then store in a cool, dry place.
Do Place your Tweak amplifiers in a dryer by
Dry & Store every night to remove moisture and
prevent corrosion.
Do Always carry spare batteries.
Do Safely store Tweak when not in use. Keep out of
reach of small children and pets. In particular, dogs
may be irritated by the feedback (“whistling”) sound
and attracted by the owner’s scent. This often results
in a chewed and/or ingested device. (A drying
appliance by Dry & Store is recommended for storage
whenever Tweak is not being worn.)
Don’t Leave Tweak on the radiator, near a stove, in
a sunny window, in a car or in any other hot place.
Excessive heat or cold can damage the instrument.
Don’t Wear Tweak when using a hair dryer or when at
the beauty salon, spa or barber.
Don’t Apply hair spray when wearing your Tweak. It
can damage the microphone or other components.
Don’t Wear Tweak while taking a bath, shower, spa
treatment or while swimming.
Don’t Store Tweak in the bathroom during a shower or
near a steam room, as moisture created by the steam
may cause damage.
23
22 Troubleshooting Tips
Troubleshooting Tips
Whistling
(“Feedback”)
Your Tweak has a best-in-class feedback
management system. However, when your
hand is near the device, you may hear a
whistling noise, which is called “feedback.”
This may be caused by amplified sound
bouncing off your hand back into the
instrument. The noise usually quits when
you take your hand away.
If the whistling doesn’t stop once you’ve
moved your hand away, ensure that the
amplifier case is positioned properly behind
the ear, and that the tip is positioned
properly in the ear canal.
Try adjusting the volume. Tap the lower
portion of the rocker switch to decrease
volume.
If already using amplification setting 3
consider using one of the domes instead of
the sleeve tip.
Your Tweak may need to be reset. See
page 25 for instructions. (For example: If
you’re currently on Amplification Setting 3,
consider Amplification Setting 2.)
If the above fails to reduce feedback, call
Tweak Support at 1-888-815-3240.
No Sound or Not
Loud Enough
Ensure that the battery door is closed.
Replace the battery.
Make sure the tip is not clogged.
Make sure the amplifier case and tubing are
clean and dry.
Make sure that the amplifier case is
positioned properly behind the ear, and
that the tip is positioned properly in the
ear canal.
Make sure the volume is turned up, by
tapping the upper portion of the rocker
switch.
Remove the sleeve tip and attach one of the
dome tips. Try the vented dome first, and if
still not enough sound, try the closed dome.
Be sure to secure the tip. See page 19.
Excessive ear wax can prevent sound from
entering the ear. Contact your physician.
Changes in your hearing can affect how
you hear with Tweak. Contact a hearing
healthcare professional if you suspect any
change in your hearing condition.
Your Tweak may need to be reset for more
volume. See page 25 for instructions
How to Reset 25
24 Troubleshooting Tips
Troubleshooting Tips continued
How to Reset
After wearing Tweak for a while, you may decide you want
to try a different Amplification Profile than the one you
initially selected. However, if you simply want more bass
sound, remove the sleeve tip and attach one of the dome
tips instead. This may resolve the issue and resetting is no
longer necessary.
Tweak may be reset by following these simple steps:
1 With a battery inserted, open the battery door.
2 Press and hold the rocker switch.
3 While still pressing and holding the rocker switch,
close the battery door.
4 Wait at least 14 seconds, then release the rocker
switch.
5 Open the battery door.
6 When you close the battery door again, Tweak is
reset.
You may now proceed to select a new
Amplification Profile. See page 13 for Focus model
or page 15 for Focus+T model.
Sound is
Distorted,
Unclear,
Intermittent or
has Static Noise
Replace the battery.
Make sure the tube and tip are not
clogged. (Refer to page 18-20 for cleaning
instructions.)
Make sure the amplifier is clean and dry.
We recommend nightly use of a drying
appliance by Dry & Store to remove
moisture and prevent corrosion.
If you are near an electromagnetic field
(e.g. near a computer screen or fluorescent
lights), step away to see if the static clears.
Your Tweak may have a poor bat tery contact
or may not be set up properly. Call Tweak
Support at 1-888-815-3240.
Warranty and Owner Information 27
26
This page is intentionally left b lank.
Warranty
See warranty card for more information.
Owner information
Each Tweak has a serial number (S/N) located on the
underside of the amplifier case. Please record this serial
number in the owner information section below.
Owner Name: ________________________________________
Tweak Purchase Date: __________________
LEFT RIGHT
Focus / Focus+T (circle one)
Serial Number
Color
Amplification Setting Selected
FOCUS
FOCUS+T
TweakHearing.com
1-888-815-3240
A PSAP is a wearable electronic product that is not intended to
compensate for impaired hearing, but rather is intended for non-hearing
impaired consumers to amplify sounds in the environment for a number
of reasons, such as for recreational activities. PSAPs are not intended to
diagnose, treat, cure or mitigate disease.
If you think you have an undiagnosed hearing loss or have a history of
excessive wax build-up, consult a hearing healthcare professional prior to
using this product.
worldwide patents: www.eartech.com/patents
A sound amplifier for people who are not ready for a hearing aid.
®
TW150_INS (F/F+T) ENG 0217
Loading...
