twaudio QDB30 Operating Manual
QDB30
Operating manual
Operating manual QDB30
NOTE
TIP
CAUTION
WARNING
Introduction
Thank you for choosing a high-quality product “MADE IN GERMANY” from TW AUDiO.
The QDB30 dolly is an accessory for the B30, VERA S30 or VERA S33 loudspeaker.
This accessory set is characterized by a subtle look, a remarkable size to weight ratio and
ease of use.
If you lend your product to another party, inform that party of the safety-related operating procedures and hand over this assembly guide. If you require additional copies of this manual,
you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de
Instructions in this user manual
Strictly adhere to the instructions contained in this operating manual that are marked as
follows:
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to serious injury or even death.
This symbol in combination with the signal word “Caution” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to light or moderate injury.
This symbol in combination with the signal word “Note” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to product damage.
This symbol in combination with the signal word “Tip” identifies additional information or
notes that will simplify working with TW AUDiO products on the basis of practical experience.
2
Notes on the products
Operating manual QDB30
Read manual
before use!
Before using the device, carefully read the operating manual and keep it with the QDB30 dolly.
General information
Operation manual: OM-QDB30
Version 1.0 en, 03/2019
© by TW AUDiO 2019; all rights reserved.
All information contained in this operating manual was correct to the best of our knowledge
at the time of printing.
Quality warranties or assurance of suitability for a certain type of use based on the technical
specifications, dimensions and weights are not granted by TW AUDiO.
TW AUDiO also shall not assume liability for any secondary damage (property damage and/or
personal injury) nor for the failure to comply with this operating manual!
TW AUDiO reserves the right to update this document based on recent developments.
TW AUDiO GmbH
Osterholzallee 140
71636 Ludwigsburg
Germany
Phone : + 49 (0) 71 41-48 89 89 0
Fax: + 49 (0) 71 41-48 89 89 99
E-Mail: info@twaudio.de
WWW: www.twaudio.de
3
Operating manual QDB30
Content
1. Safety | Intended use ...................................................................................................... 5
2. Overview ........................................................................................................................ 6
2.1 Components ........................................................................................................... 6
3. Technical specifications .................................................................................................. 7
3.1 Data sheet ............................................................................................................... 7
4. Commissioning ............................................................................................................... 8
4.1 Using QDB30 dolly with B30 or VERA S30 loudspeaker ........................................... 8
4.2 Using QDB30 dolly with VERA S33 loudspeaker .................................................... 10
5. Transport and Storage .................................................................................................. 12
6. CE Conformity Declaration ............................................................................................ 13
7. Disposal ....................................................................................................................... 13
4
1. Safety | Intended use
WARNING
WARNING
CAUTION
WARNING
WARNING
WARNING
WARNING
To avoid risks please observe the following safety instructions when using accessories.
The QDB30 dolly was developed for professional use in sound systems. The dolly may only
be used by trained and qualified personnel.
Note the operating modes described in this operating manual. Other uses are not permissible.
Damage caused by improper use is not covered by TW AUDiO.
Before each use, check the integrity of the QDB30 dolly and ensure that all components are
in perfect condition.
The QDB30 dolly may only be used with the B30, VERA S30 or VERA S33 loudspeaker.
These operating manual describe how to use the QDB30 dolly. Any other use shall be deemed
improper and may result in damage or even injury.
Operating manual QDB30
Modifications or alterations to individual parts of the QDB30 dolly are not permitted! Danger
to life!
The QDB30 is an accessory designed both for indoor and outdoor use.
The QDB30 dolly may only be used by trained and qualified personnel. Personnel must check
the QDB30 for its full suitability before each use.
When visible damage to any part of the QDB30 dolly is detected, it must be decommissioned
immediately.
When moving the QDB30 dolly, ensure full load-bearing capacity and stability of the substrate.
The QDB30 dolly is specified for a load of not more than four B30 or four VERA S30 or two
VERA S33 loudspeaker. This load capacity must never be exceeded!
During movement (assembly or dismantling, transport to the place of use) of the QDB30 dolly
with the B30, VERA S30 or VERA S33 loudspeaker, ensure sufficient space to prevent collisions with other objects.
5
