Tuuci bay master MAX center post Assembly & Operating Instructions

BLACK & WHITE 1 COLOR

BLACK

to protect your product,

read operating instructions before opening parasol

bay master MAX center post

assembly & operating instructions

INSA4000 4.12.17

ASSEMBLY & OPERATING INSTRUCTIONS BAY MASTER MAX Center Post

Step 1

Remove all packaging from umbrella, including inside the umbrella.

Step 2

Remove deck mount from mast and install
it in selected mounting base

Step 3

Once deck mount is installed, place the
umbrella in and tighten star-knob.

Make sure lock spring pin is in base slot
to secure umbrella in place.

INSA4000 4.12.17

2 | tuuci

applies to:

square

octagon

ASSEMBLY & OPERATING INSTRUCTIONS BAY MASTER MAX Center Post

POSITIONING UNBRELLA FRAME

Step 4

Gently separate each rib individually from
center post, approximately 10 inches.

Step 5

Gently slide main hub handle up center
post until clip bracket engages to slot.

INSA4000 4.12.17

tuuci | 3

ASSEMBLY & OPERATING INSTRUCTIONS BAY MASTER MAX Center Post

Step 6

Connecting rib struts to hub with cotter pins

Note:
You may need to use a
tool to help align the holes.

INSA4000 4.12.17

4 | tuuci

DO NOT OPERATE
WITHOUT CONNECTING
RIB STRUTS TO HUB
WITH COTTER PINS

ASSEMBLY & OPERATING INSTRUCTIONS BAY MASTER MAX Center Post

IF APPLICABLE - LIGHT ACCESSORIES

Step 7

Connect electrical extention cable

Step 9

Use touch sensor detector to control light
brightness from low to high

Step 8

Per job application connect required a/c plug
to the free ends of power supply.

Image for illustration only
a/c plug not included.

INSA4000 4.12.17

tuuci | 5

ASSEMBLY & OPERATING INSTRUCTIONS BAY MASTER MAX Center Post

Step 10

To close umbrella, press down clip bracket
to disengage from slot then slide down
gently.

Note: close umbrella during wind conditions that exceed manufacturer’s specications.

INSA4000 4.12.17

6 | tuuci

ASSEMBLY & OPERATING INSTRUCTIONS CARE & MAINTENANCE

TUUCI frames are constructed from durable, marine-grade, weather resistant materials including: fiberglass,

armor-wall aluminum, Dura-TEAK composites, Aluma-TEAK aluminum and sustainable hardwood. All fasten-

ers (nuts, bolts, pulleys, cam cleats, etc.) are marine-grade stainless steel and will withstand the most corrosive

environments. Proper care and maintenance is important to extend the serviceable life of all TUUCI products.

We recommend the following:

• Fresh water rinses once a week

• Weekly inspection of your TUUCI product is recommended. Loose screws should be tightened and any

broken components replaced immediately to avoid further damage to your product.

• Prior to opening, ensure that the shade product is properly secured to an adequate shade anchor system.

• When opening a TUUCI parasol, separate each rib 10 inches from the center post, before raising the hub.

Do not force hub if it does not rise easily.

• When closing the parasol, pull the fabric out from between the struts to avoid pinching or damaging the

TUFF-SKIN canopy membrane.

• TUUCI recommends that all collapsible shade equipment be closed in wind conditions which exceed 25 MPH.

• Clean above ground parasol bases regularly to maintain appearance. To clean, gently wash with soap and

water using a nonabrasive cloth or pad.

• Check bolts in security stem regularly to ensure that they remain fully tightened.

• Do not roll Aluma-crete (Aluminum Shell, Concrete Filled) bases on their side as damage to shell

or nish can occur.

• Do not use on stairways or over distances which exceed 50 feet, as damage to welded wheel tray may occur.

• Canopy should be cleaned regularly and can be cleaned without being removed from the frame. Hose down

and clean with a mild soap and lukewarm water (no more than 100° F.) using a soft bristle brush. Rinse thor

oughly to remove soap. Allow fabric to air dry. TUUCI Parts can be purchased at [e-mail].

• Do not use a pressure washer to clean canopes.

INSA4000 4.12.17

tuuci | 7
