Turck TBEN-LG-8DIP-8DOP User Manual

Compact multiprotocol I/O module for Ethernet
8 Digital PNP Inputs and 8 Digital PNP Outputs 2 A
TBEN-LG-8DIP-8DOP

Type designation TBEN-LG-8DIP-8DOP

Ident no. 6814066

Supply

Supply voltage 24 VDC
Admissible range 18…30 VDC

Total current max. 9 A per voltage group

Total current V1 + V2 max. 11 A per module
Voltage supply connection 4-pin male 7/8" connector X1
Sensor/Actuator supply V

Sensor/Actuator supply V

Electrical isolation galvanic isolation of the voltage groups V1 and V2,

AUX1

AUX2

supply of ports C0-C3 from V1

short-circuit proof, 120 mA per port

supply of ports C4-C7 from V2

short-circuit proof, 120 mA per port

voltages up to 500 VAC

■ PROFINET device, EtherNet/IP device or

Modbus TCP slave

■ Integrated Ethernet switch

■ Supports 10 Mbps / 100 Mbps

■ 2x M12, 4-pin, D-coded, Ethernet field-

bus connection

■ Glass fiber reinforced housing

■ Shock and vibration tested

■ Fully potted module electronics

■ Protection classes IP65, IP67, IP69K

■ 7/8", 4-pin connectors for power supply

■ Galvanically isolated voltage groups

■ Input diagnostics per port

■ Max. 2 A per output

■ Output diagnostics per channel

System data

Fieldbus transmission rate 10 Mbps/100 Mbps
Fieldbus connection technology 2 × M12, 4-pin, reverse-keyed
Protocol detection automatic
Web server Default: 192.168.1.254
Service interface Ethernet via P1 or P2
Product code 14066

Modbus TCP

Addressing Static IP, DHCP
Supported function codes FC1, FC2, FC3, FC4, FC5, FC6, FC15, FC16, FC23
Number of TCP connections 8
Input register start address 0 (0x0000 hex)
Output register start address 2048 (0x0800 hex)

Ethernet/IP

Addressing acc. to EtherNet/IP specification
Quick Connect (QC) < 150 ms
Device Level Ring (DLR) supported
Class 3 connections (TCP) 3
Class 1 connections (CIP) 10
Input Assembly Instance 101
Output Assembly Instance 102
Configuration Assembly Instance 106

PROFINET

Addressing DCP
Conformance class B (RT)
MinCycleTime 1 ms
Fast Start-Up (FSU) < 150 ms
Diagnostics acc. to PROFINET alarm handling
Topology detection supported
Automatic addressing supported
Media Redundancy Protocol (MRP) supported

Edition • 2021-04-09T09:33:24+02:00

1 / 5 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [e-mail] ñ www.turck.com

Compact multiprotocol I/O module for Ethernet
8 Digital PNP Inputs and 8 Digital PNP Outputs 2 A
TBEN-LG-8DIP-8DOP

Digital inputs

Number of channels 8
Connectivity inputs M12, 5-pin
Input type PNP
Type of input diagnostics Group diagnostics
Switching threshold EN 61131-2 Typ 3, PNP
Low level signal voltage < 5 V
High level signal voltage > 11 V
Low level signal current < 1.5 mA
High level signal current > 2 mA
Input delay 2.5 ms
Electrical isolation Galvanically isolated to the fieldbus

Voltage proof up 500 VDC

Digital outputs

Number of channels 8
Connectivity outputs M12, 5-pol
Output type PNP
Type of output diagnostics Channel diagnostics
Output voltage 24 VDC from potential group
Output current per channel 2.0 A per port, short-circuit proof
Output delay 1.3 ms
Load type EN 60947-5-1: DC-13
Short-circuit protection yes
Electrical isolation Galvanically isolated to the fieldbus

Voltage proof up 500 VDC

Standard/Directive conformity

Vibration test acceleration to 20 g

acc. to EN 60068-2-6
Shock test acc. to EN 60068-2-27
Drop and topple acc. to EN 60068-2-31/IEC 60068-2-32
Electromagnetic compatibility acc. to EN 61131-2
Approvals and certificates CE,

FCC,

UV-resistant in accordance with DIN EN ISO

4892-2A (2013)
UL Certificate cULus LISTED 21 W2, Encl.Type 1 IND.CONT.EQ.

General Information

Dimensions (W x L x H) 60.4 x 230.4 x 39mm
Operating temperature -40…+70 °C
Storage temperature -40 °C … +85 °C
Altitude max. 5000 m
Protection class IP65

IP67

IP69K
MTTF 205 years acc. to SN 29500 (Ed. 99) 20 °C
Housing material PA6-GF30
Housing color Black
Window material Lexan
Material screw 303 stainless steel
Material label Polycarbonate
Halogen-free yes
Mounting 2 mounting holes � 6.3 mm

Edition • 2021-04-09T09:33:24+02:00

2 / 5 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [e-mail] ñ www.turck.com

Compact multiprotocol I/O module for Ethernet
8 Digital PNP Inputs and 8 Digital PNP Outputs 2 A
TBEN-LG-8DIP-8DOP

Note

Ethernet cable (example):

RSSD-RSSD-441-2M/S2174

Ident. no. 6914218

Note

Actuator and sensor cable / PUR connection cable (for example):

RKC4.4T-2-RSC4.4T/TXL

Ident. no. 6625608

Y extension cable for single occupancy

FSM4-2WAK3-1/1/P00

Ident. no. 8009560

M12 x 1 Ethernet

M12 x 1 Input

M12 x 1 Output

Note

Power supply cable (example):

RKM43-1-RSM43

Ident. no. 6914312

7/8'' Power Supply

Edition • 2021-04-09T09:33:24+02:00

3 / 5 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [e-mail] ñ www.turck.com

Compact multiprotocol I/O module for Ethernet
8 Digital PNP Inputs and 8 Digital PNP Outputs 2 A
TBEN-LG-8DIP-8DOP

Module Status LED

LED Color Status Description

ETH1 / ETH2 Green On Ethernet Link (100 Mbps)

Flashing Ethernet communication (100 Mbps)

yellow On Ethernet link (10 Mbps)

Flashing Ethernet communication (10 Mbps)

Off No Ethernet link

BUS Green On Active connection to a master

Flashing Steady flashing: Ready

Sequence of 3 flashes in 2 seconds: FLC/ARGEE active

Red On IP-address conflict or Restore Mode or Modbus timeout

Flashing Blink/Wink command active

Green/Red Alternating Autonegotiation and/or waiting for DHCP/Boot-P addressing

Off Power off

ERR Green ON Diagnostics disabled

Red ON Diagnostics enabled

PWR ON V1 and V2 power on

LED Status I/O

LED Color Status Description

LED 0…7 Green ON Input active

LED 0…7 Green ON Output active

Green

flashing V2 power off or below defined tolerance

OFF V1 power off or below defined tolerance

Red Flashing Power overload at the corresponding port. Both port LEDs are flashing.

OFF Input inactive

Red ON Output active with overload/short circuit

Flashing Power overload at the corresponding port. Both port LEDs are flashing.

OFF Output inactive

Edition • 2021-04-09T09:33:24+02:00

4 / 5 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [e-mail] ñ www.turck.com

Compact multiprotocol I/O module for Ethernet
8 Digital PNP Inputs and 8 Digital PNP Outputs 2 A
TBEN-LG-8DIP-8DOP

Process Data Mapping of the Single Protocols

For more details on the corresponding protocols see manual.

Modbus TCP Register Mapping

Reg Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Inputs (RO) 0x0000 DI7

Status (RO) 0x0001 - FCE - - CFG COM V1 - V2 - - - - - - Diag

Diag (RO) 0x0002 - - - - - - - - - - - - - - - I/O

Inputs (RW) 0x0800 DI7

Outputs (RW) 0x0800 DO7

I/O Diag (RO) 0xA000 SCO7 SCO6 SCO5 SCO4 SCO3 SCO2 SCO1 SCO0 SCS7 SCS6 SCS5 SCS4 SCS3 SCS2 SCS1 SCS0

EtherNet/IP™ data mapping with activated scheduled diagnostics, default settings

Word Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Input data (station -> scanner)

GW status 0 - FCE - - CFG COM V1 - V2 - - - - - - Diag

Inputs 1 DI7

Diag 1 2 - - Sched

Diag

Diag 2 3 SCO7 SCO6 SCO5 SCO4 SCO3 SCO2 SCO1 SCO0 SCS7 SCS6 SCS5 SCS4 SCS3 SCS2 SCS1 SCS0

Output data (scanner -> station)

Control 0 reserved

Outputs

EtherNet/IP™ data mapping with activated summarized diagnostics

Input data (station -> scanner)

GW status 0 - FCE - - CFG COM V1 - V2 - - - - - - Diag

Inputs 1 DI7

Diag 1 2 - I/O

Output data (scanner -> station)

Control 0 reserved

Outputs

PROFINET Process Data

Inputs 0 DI7

Outputs 0 DO7

Key:

DIx Digital input channel x CFG I/O Configuration error

DOx Digital output channel x FCE I/O-ASSISTANT Force Mode active

Cx Port x I/ODiag I/O diagnostics connected

Px Pin x SchedDiag Manufacturer-specific diagnostics configured and active

DiagWarn Diagnostic at least on 1 channel SCSx Short-circuit at port x

V1 Undervoltage V1 SCG1 Short-circuit supply ports C0-C3

V2 Undervoltage V2 SCG2 Short-circuit supply ports C4-C7

COM Communication error on internal module bus SCOx Short-circuit output channel x

Edition • 2021-04-09T09:33:24+02:00

5 / 5 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. [phone] ñ Fax [phone] ñ [e-mail] ñ www.turck.com

1 DO7

Word Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

1 DO7

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

C3P2

C7P2

- - - - - - - - - - - - I/O

DI6

C3P4

DO6

C7P4

DI5

C2P2

DO5

C6P2

DI4

C2P4

DO4

C6P4

C3P2

C3P2

C7P2

C3P2

C7P2

C3P2

C7P2

DI3

C1P2

DO3

C5P2

DI6

C3P4

DI6

C3P4

DO6

C7P4

DI6

C3P4

DO6

C7P4

DI6

C3P4

DO6

C7P4

DI5

C2P2

DI5

C2P2

DO5

C6P2

DI5

C2P2

DO5

C6P2

DI5

C2P2

DO5

C6P2

DI2

C1P4

DO2

C5P4

DI4

C2P4

DI4

C2P4

DO4

C6P4

DI4

C2P4

DO4

C6P4

DI4

C2P4

DO4

C6P4

DI3

C1P2

DI3

C1P2

DO3

C5P2

DI3

C1P2

DO3

C5P2

DI3

C1P2

DO3

C5P2

DI1

C0P2

DO1

C4P2

DI2

C1P4

DI2

C1P4

DO2

C5P4

DI2

C1P4

DO2

C5P4

DI2

C1P4

DO2

C5P4

DI1

C0P2

DI1

C0P2

DO1

C4P2

DI1

C0P2

DO1

C4P2

DI1

C0P2

DO1

C4P2

DI0

C0P4

Warn

Diag

DI0

C0P4

DO0

C4P4

Warn

DI0

C0P4

Diag

DO0

C4P4

Warn

DI0

C0P4

Diag

DO0

C4P4

DI0

C0P4

DO0

C4P4
