Q-Pak, Rectangular Inductive Sensors

Q14

Rectangular Sensors, Plastic

Plastic Housing with Potted-In Cable & Optional Molded Connector

2-Wire AC/DC microfast
20-250 VAC, 10-300 VDC; Short-Circuit and Overload Protected
Normally Open

Sensor Selection

Part Number

Bi10-Q14-ADZ32X2
Bi10-Q14-ADZ32X2/S34

Bi10-Q14-ADZ32X2-0.2M-SB 3T
Bi10-Q14-ADZ32X2/S34-0.2M-SB 3T••

Embeddable

Rated Operating

•

10

•

10

10
10

Housing

Distance (mm)

14
14

14
14

Normally Open

Height (mm)

••11AA2

••22BB2

Drawing #

Wiring Diagram

# of LEDs

2 •

2 •

Weld Field

Immune (/S34)

6030M4256220

6030M4256290

Switching

Frequency (Hz)

M4256225

M4256294



ID Number

Connection

2 meter cable,
PVC jacket;
22 AWG copper
conductors, PVC
insulated.

microfast

Mating Cordsets

KB 3T-2 (2 meter)
For other styles see
“Cordsets” catalog.

Material

Housing: PBT-GF30-V0 Plastic
Sensing Face: PBT-GF30-V0 Plastic
Connector: Chrome Plated Brass

39 TURCK Inc.

Accessories

Accessories and mounting devices can be found on pages 51 and 52.

Specifications

Wiring Diagrams

Line Frequency . . . . . . . . . . . . . . . 60 Hz

Differential Travel (Hysteresis) . . . . . . . . 3-15% (5% typical)

Voltage Drop Across Conducting Sensor . . . ≤6.0 V at 100 mA

Continuous Load Current . . . . . . . . . . ≥100 mA

Trigger Current for Overload Protection . . . ≤220 mA

Off-State (Leakage) Current . . . . . . . . . <1.7 mA

Minimum Load Current . . . . . . . . . . . ≥3.0 mA

Inrush Current . . . . . . . . . . . . . . . . ≤1.0 A (≤30 ms, 15% Duty Cycle)

Time Delay Before Availability . . . . . . . ≤60 ms

Power-On Effect . . . . . . . . . . . . . . . Per IEC 947-5-2

Reverse Polarity Protection . . . . . . . . . Incorporated

Wire-Break Protection . . . . . . . . . . . . Incorporated

Transient Protection . . . . . . . . . . . . . Per EN 60947-5-2

Operating Temperature . . . . . . . . . . . -25° C to +70° C (-13° F to +158° F)

Enclosure . . . . . . . . . . . . . . . . . . Meets NEMA 1,3,4,6,13 and IEC IP 67

Shock . . . . . . . . . . . . . . . . . . . . 30 g, 11 ms

Vibration . . . . . . . . . . . . . . . . . . 55 Hz, 1 mm Amplitude in all 3 Planes

Repeatability. . . . . . . . . . . . . . . . . ≤2% of Rated Operating Distance

LED On (Green) . . . . . . . . . . . . . . . Power On

LED On (Red) . . . . . . . . . . . . . . . . Output Energized

A Normally Open

B Normally Open

Dimensions
